Building the Security Foundation to Embrace Public

Software-as-a-Service (SaaS)

Security Policies for SaaS Data Protection

Yuyu Chou

, Jan Oetting

and Olga Levina

Systems Analysis and IT, Berlin Institute of Technology, Berlin, Germany

Consileon Business Consultancy GmbH, Karlsruhe, Germany

Keywords: Software as a Service, Cloud Computing, Security Policy, Data Protection, Security Management.

Abstract: To mitigate the risk of confidentiality breaches when adapting public SaaS solutions, enterprises should

build their security policies by setting up a system of security awareness. This paper presents a systematic

approach to developing security policies, which includes the method and process used during the public

SaaS system development life cycle. Hence, all employees will have the well-grounded concept to protect

confidential data in the cloud.

1 INTRODUCTION

The security policy defines targets to be reached and

serves as management’s tool to meet business

objectives in a public SaaS system as well as in in-

house systems. By setting the rules for expected

behaviour, security policies can protect information

outside of internal IT system, and help a frim to

comply with regulations as well as on-coming cloud

legal requirements.

Information security policies may vary widely

from company to company and no standard sample

that can be copied (Diver, 2007). Firm size, culture,

industry sector, country, regulation, the business

process and the IT support will influence the

statements. Among those companies which have

security policies are often driven by compliance, not

from their own convictions; therefore many

companies do not have a fit security policy, and their

security policies only used to a small extent (Oracle,

2009).

Up to now, most of the companies deploying

Cloud Computing solutions have no cloud-specific

security policies and procedures in place (Hickey,

2010). It is essential for enterprises to be equipped

with reliable security policies, to have a systematic

and an objective judgement for managing a SaaS

system development life cycle (SDLC). There is

already some literature suggesting guidelines for

creating general security policies, e.g., from (ISC)

(Tipton and Henry, 2007), SANS Institute (Diver,

2006), and addressing the importance of Cloud

security policy (Jaeger et al., 2008); (Hickey, 2010).

However, there is little literature guiding enterprises

how to build security policies to reduce the risk of

using public SaaS services. To solve the problem,

this paper presents a method and process for

companies to develop cloud specific security

policies during an SaaS SDLC.

The structure of the remaining part of this paper

is as follows: Section Two presents the concept of a

security policy set; it enables enterprises to build

different security policies for different users and

purposes. In Section Three, the policy development

and management is introduced. The approach of

applying the policy set based on the SaaS SDLC is

suggested in Four Section. Finally, conclusion and

work-in-process are presented in Section Five.

2 POLICY TYPE FOR SAAS

SDLC

For an enterprise to develop a single good policy

document that addresses all types of users and

information security controls is very complicated

(Diver, 2007). Different users will need different

documents. Therefore, for building effective and

systematic policies to embrace a new SaaS

integrated IT system, this paper suggests using the

227

Chou Y., Oetting J. and Levina O..

Building the Security Foundation to Embrace Public Software-as-a-Service (SaaS) - Security Policies for SaaS Data Protection.

DOI: 10.5220/0004024702270232

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 227-232

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

concept of a hierarchical security policy set (Diver,

2006). It can help enterprises build solid and clear

security policies step by step under tight resource

conditions, rather than compiling unmethodical and

scattered security rules. Table 1 summarizes the

characteristics of these three level policies.

Table 1: Different types of security polices.

Address Audiences

Update

frequency

Governing

policy

What

Managers, technical

members, end users

Low

Technical

policy

What, where,

who, when

Technical members Middle

Detailed

requirement

What, where,

who, when, how

End users, developers,

service providers

High

2.1 Governing Policy (Level One)

The security governing policy is on top of the

security policy framework. Security governing

policy should focus on desired results, not on means

of implementation (Guel, 2007).It is designed to set

out clearly the strategic aims and control objectives

that will guide the security development of the new

cloud integrated IT systems. Organizations should

aim for writing their security policy on not more

than three pages of A4 (Calder et al., 2010). Detailed

policy statements should be left out and be written

on the second or third level of the documentation. In

this way the governing policy can remain constant

over a longer period of time without conflicting with

the regular technology changes.

2.2 Technical Policy (Level Two)

Technical policy includes system-specific and

functional policies. It should cover a part of the

governing policy topics, but it is more precise than

the governing policy. The statements should depend

upon the business needs, and focus on the different

domains of security control belonging to general

technical topics, e.g., access control, applications

development policy. Detail requirements should be

defined in level three policies because these level

two policies will be applied by technical custodians

as they carry out their system security

responsibilities, or they will be used for specific

applications. Following, a number of SaaS topics to

be addressed in the technical policy are given:

First, when defining requirements for external cloud

services, cloud specific requirements for providers

(BSI, 2010), legal requirements, and company

specific rules for critical data protection should be

observed. Companies have to be careful with too

detailed statements on this technology-independent

level, because valid options could be ruled out

without noticing it.

Second, extra internal compensating security

controls should be implemented if needed. IT and

security teams should do the corresponding tests and

implementations when selecting an SaaS solution.

Data should be protected from the source or before

sending out to the servers of a public SaaS provider.

Third, set up mobile usage policy for using cloud

web application. Mobile applications have different

risks compared to a traditional web application

model (OWASP, 2011). The policy should therefore

additionally define what kind of business processes

may be accessed by mobile devices and what kind of

data may be processed and stored on them.

2.3 Detailed Requirement (Level

Three)

Level three policies should give detailed guideline

directions for employees “how” to carry out the

policy statements (Diver, 2007). Based on the survey

of the Computer Security Institute, roughly one in

four believed that more than 40 percent of their total

financial losses from attacks were due to insider

activities (CSI, 2007). Implementing precise and

comprehensive policies is the solution for dealing

with insider threats like decision errors, skill-based

errors, perceptual errors and routine violations

(Predd et al., 2008). Therefore, both external and

internal threats could be greatly alleviated when

enterprises know how to build and execute level

three policies well. Furthermore, these documents

can act as a backup facility; once a staff leaves, the

knowledge will not be lost and the policy

requirements can still be carried out.

The relationship between level two and level

three policies can be none, one-to-one or one-to-

many (Diver, 2006). The following explains the

types of level three policies:

 Guideline. Guideline is not a required element of

a policy framework, but it helps users to understand

the complete scope of flows and options. If an item

is considered mandatory, then this should be defined

in higher level policies, standards or baselines.

 Standard. Standards provide the specification of

the technology to effectively enable the organization

to comply with the policies and provide

interoperability within the enterprise through the use

of common protocols (Tipton and Henry, 2007). It

SECRYPT2012-InternationalConferenceonSecurityandCryptography

228

also can be referred in many existing public

standards.

 Procedure. Procedures are step by step

instructions (Guel, 2007). They can reduce cloud

risks by indicating how the policy should be

implemented and who should do what in order to

accomplish the tasks as an effective and consistent

method.

 Baseline. It provides a description of how to

implement and stipulate the minimal requirements to

secure the data internally as well as in clouds. The

requirements should be consistent throughout the

organization. Usually, the baselines are specific

rules supporting the policy and standards that have

already been developed.

3 MANAGEMENT OF A

SECURITY POLICY

Policy Management is the process of managing and

maintaining policies effectively within the

organization (Rasmussen, 2011). Developing good

security policies for managing SaaS systems, the

developers need to consider business, legal,

technical, cultural and security aspects.

3.1 Policy Development and

Management Process

To avoid being “blind men feeling the elephant”,

this paper proposes nine steps of policy development

process. This management cycle is started with the

“preparation” and ends with an integrated “periodic

review and update policy” into the security

management process.

3.1.1 Step One: Preparation

There are some preparations that should be taken

before the kick-off of the security policy

development project. First, understand the business

goals and direction. Second: determine resource

involvement. Designing the governing security

policies is usually more complicated than others.

Therefore, the primary involvement for a governing

policy might be just the security team, and the

optimum size for the core team is around 3 people

(Kee, 2001). The members can be external

employees or security consultants, but it needs to be

made sure that they can be trusted and signed a non-

disclosure agreement (NDA).

3.1.2 Step Two: The Project Kick-off and

Top Management Buy-in

It may take longer time, if security policies are

defined for the first time. Therefore, same with other

important security projects, the top managers’

acceptance and support for the policy development

is the stepping stone. Without the commitment of

top management, the project will be given up

halfway or will easily be a perfunctory policy.

3.1.3 Step Three: Reviewing of Existing

Policy

Many enterprises may not have a security policy.

But if a company has existing security policies, even

though they are weak, a review will help when

developing a new security policy.

3.1.4 Step Four: Data Gathering

The policy development team needs to know who

the potential attackers are, what they can do against

them and decide how to enhance security to protect

the information assets in internal systems as well as

in the cloud. A number of security standards,

guidelines and cloud articles can offer the team

sufficient cloud security knowledge. Besides, clearly

understanding cloud related industrial standards,

national or local legal requirement, the company

resource, risk appetite from managers, technical

limitations, and SLA as well as contract from SaaS

providers is also important. Hence, the policy

development team can gather sufficient information

to define rational and enforceable policies which

links to internal and external mandates for staffs to

comply.

3.1.5 Step Five: Writing Initial Draft

Six suggestions are provided below:

First, mandatory: Policies are expected to be

complied with; therefore statements including words

such as “must”, “will”, “need to” are better than

using weaker directives such as “should”, “may” or

“can” (Tipton and Henry, 2007).

Second, keep to a minimum length. The length of

each policy should be limited (Calder et al., 2010);

otherwise few employees will read it attentively.

Third, do not use abstract language. A quantitative

description is usually better than qualitative one.

Fourth, ensure that roles and responsibilities are

defined and clearly understood. Easy to understand

instructions are very important because the aim of

BuildingtheSecurityFoundationtoEmbracePublicSoftware-as-a-Service(SaaS)-SecurityPoliciesforSaaSData

Protection

229

security policy is to communicate with both

technical and non-technical users (in technical

requirements it is acceptable to use technical terms).

Fifth, rules must be followed and enforceable;

otherwise, employees will try to work around them.

Sixth, when formulating the policies, it should be

mentioned if failure to comply with the policy will

result in disciplinary action and punishment;

otherwise, the policy will not be thoroughly

executed.

3.1.6 Step Six: Reviewing Process

The completed draft security policy must be

reviewed, and feedback must be asked for from the

appropriate parties such as executive, business

leaders, IT and security managers, human resources,

legal staff, audit departments and employee union.

Make sure the policy is closely aligned with existing

as well as future Human Resource guidelines and

other company policies. In addition, make sure the

policy is understandable for end users. Typos or

errors that are not seen by the authors should be

corrected. Last but not least, before publishing

policies, the security team should check if any policy

statements are not currently in force or only partially

exist in the enterprises organization (Diver, 2007).

To document these gaps and to determine which

groups or individuals are responsible for closing

them, can make the implementation more efficient.

3.1.7 Step Seven: Final Sign-on and Publish

The final review and sign-off is typically accepted

by all management levels, and done by the business

leaders, the chief security officer (CSO) or IT

Managers. However, publishing and communicating

with employees can be a challenge, in particular

when the policy changes. Hence, there are four

suggestions shown below, which may be helpful to

efficiently publish the security policies and

communicate with employees.

First, make it as a contractual requirement.

Second, security awareness should be part of

required training. Campaigns must convey the

seriousness of new cloud related specific policies,

and explain the reasons why it is necessary.

Otherwise, employees will not change their

behaviour, even if the new process is more

beneficial and easier.

Third, Email is a good way to inform employees

about security policy changes quickly.

Fourth, documents should be easily accessible and

available for download, printing as well as saving.

However, if the content contains confidential

information, these documents should be only

accessible by the security team and properly secured

from general distribution (Tipton, 2007).

3.1.8 Step Eight: Compliance and

Enforcement

Education and training are the best way to make

employees understand how to comply with the

policies. Once the compliance grace period is

exceeded, and the policy is enforced, auditors should

ensure that policies are surely followed.

Management should take care that based on one of

the principle “separation of duties”, the auditors

monitoring compliance with the security policy

should not be the persons who implemented the

policy. Policies should be enforced strictly and

noncompliance should be punished (Kee, 2001).

3.1.9 Step Nine: Regularly Review and

Update

Security policy needs to be updated when for

example, compliance with new cloud regulatory

requirements, new important project rollouts,

customer request, technology change, and editorial

errors occur. To ensure policies do not become out

of date, the security team should review the high

level policy at least every 2-3 years, and detailed

requirements every year (Guel, 2007). In case an

SaaS solution is used and security policies are

established, the security team has to ensure that the

policies related to such as data handling and access

control are addressing the Cloud specific logic.

3.2 Good Security Policy Requirements

Characteristics of good data protection policies can

be hierarchical (Petrocelli, 2005) and should reach

the following requirements:

 They must be written down (Petrocelli, 2005).

 They must be specific to the organization, but

not be cloud vendor specific.

 Roles and responsibilities must be defined in

accordance with the security policies (ISO/IEC,

2005).

 They must be easy to understand.

 They must achieve a balance between current

practice and preferred future (Diver, 2007).

 They must develop sanctions for non-

compliance. (Tipton and Henry, 2007).

 They must provide sufficient protections against

SECRYPT2012-InternationalConferenceonSecurityandCryptography

230

all threats, and the statements should also be

implementable, measureable and enforceable.

4 APPLIED IN AN SAAS SDLC

Managers often know the importance of security, but

run it with a low priority (Martin, 2011). Although

public SaaS providers usually offer non-negotiated

service level agreements (SLAs) and generally they

will not customize their service to fulfill the security

requirements of each client (ENISA, 2009), the

security level of the client company should not be

downgraded because of adapting a new public SaaS

application.

An SaaS system development life cycle (SDLC)

is composed of nine phases (Chou et al., 2011), as

shown in Figure 1. From the beginning of the SaaS

system design preparation, managers should

integrate the security concepts based on defined

security policies into development, thus the system

can be securer and more cost-saving (BSI, 2008)

than ameliorate it afterwards. The following explains

briefly how a company uses these policies to build a

data secured SaaS SDLC.



System

Identification

Provider

Decision

Preparation

Requirement

Building

Flow 1

Flow 2

Flow 3

Flow 4

Flow 9

Flow 12

Flow 6

Flow 5

Operation

Management

Flow 1

Termination

Flow 13

Flow 8

Risk

Assessment

Implementation

Flow 7

Flow 10

Treatment

Decision

Figure 1: SaaS system development cycle (revised from

Chou et al. (2011)).

First part, during the phases “Preparation” and

“Requirement Building”. When a company wants to

adapt a first SaaS solution, either the selected SaaS

solution can follow the existing governing policy, or

the governing policy should be updated. It is

important to build the security policy set before

using an SaaS system, although this is hard to fulfil

for many of the companies. Enterprises should at

least set down or update the governing policy before

starting the SaaS system development cycle. Other

policies can be verbally agreed on by managers, and

should preferably be written down. All candidates

need to be checked if they can reach the vendor

requirement baseline, and can follow the IT service

outsourcing policy. The supportive documents for

data protection in the SaaS system development life

cycle are shown in Table 2.

Second part, during the phases “System

Identification” and “Risk Assessment”. These

phases establish the base for the decision in field of

business, technique, security, and legal aspects. The

responsibility of the security team is: to check if

related internal systems miss any control based on

security requirements and test the candidates’

solutions against standard security weaknesses. In

addition, the security team should clarify the

security responsibility among the internal team and

SaaS providers. Then co-work with the IT team to

execute the basic risk evaluation based on the risk

assessment procedure and report the risk summary

from each solution to managers.

Table 2: Suggested supportive security polices during

SaaS system development life cycle.

Phase Supportive policy documents

Preparation Security governing policy, vendor requirement

baseline, applications development policy

Requirement

building

Data classification guidelines, data protection

policy

System

identification

Web security testing procedures, security

control baselines, IT service outsourcing policy

Risk assessment Risk assessment procedure (method)

Solution

decision

Outsourcing service approval process

Treatment

decision

Cryptography policy, network security

management policy, access control policy, etc.

Implementation System testing procedure

Operation

management

Operational procedures, disaster Recovery

policy, equipment usage policy, audit policy,

change control procedures, business continuity

management policy, etc.

Termination System termination guideline or procedure

Third part, during the phases of “Treatment

Decision” and “Implementation”. Once the

managers decide to use an SaaS solution, this SaaS

solution needs to be further checked in detail if the

solution has any vulnerabilities, can comply with the

data protection policy, and if it follows IT service

outsourcing policy. Once unacceptable risks in a

decided SaaS application are found, extra

compensating security controls should be designed

during the treatment decision. Thus, these extra

controls can provide an equivalent or comparable

level of protection for the system when data

processed, stored or transmitted (NIST, 2009). After

the implementation, the security team needs to check

if the new SaaS integrated system is under risk

acceptable status based on security testing

procedure. If the result is not acceptable, the

development team needs to go back to

“Identification Phase” and run the cycle (7-10

BuildingtheSecurityFoundationtoEmbracePublicSoftware-as-a-Service(SaaS)-SecurityPoliciesforSaaSData

Protection

231

Flows) again to decide new security treatments.

Fourth part, during the ”Operation Management”

and “Termination” phases. After the successful

completion of the system go-live test, operational

procedures should be delivered to end users. Then,

this system is going to the normal operation status of

security management process. Before the application

phases out, employees should have the termination

guideline or procedure on hand. Therefore, the data

can completely and without harm be moved back to

the internal system or to other systems.

5 CONCLUSIONS

Although security policy is only one of the security

controls, this is the fundamental base for building a

secure public SaaS system development life cycle.

To solve the problem of confidentiality breaches in

public SaaS solutions, a company needs to have

multiple layers of defense and strategies against

potential threats. These strategies must be consistent

with the business needs, be well defined in the

security policy and be effectively published for

every employee to comply. Based on the process and

the methods shown in this paper, companies can

proceed step by step and build their policy

systematically even under tight resource conditions.

Therefore, the customer data, employee data and

confidential business information will be better

protected during the whole SaaS system

development life cycle. Our on-going work is to

build an automatic data protection tool based on the

enterprises’ data classification policy. This control is

independent from the support of public SaaS

providers; thus, the tool can enforce the security

policy requirements and help to avoid confidentiality

breaches. To sum up, although there are many

security control objects, having a good tailored

security policy set is the first priority for enterprises

before using SaaS applications. Based on the well-

defined and executed security policies, companies

will not only take advantage of using an SaaS

solution, but will also protect their data on the

business battlefield.

REFERENCES

BSI, 2008, Information security management systems

(ISMS), BSI-Standard 100-1, v 1.5. German

Information Security Agency, Bonn.

BSI, 2010, Minimum security requirements for Cloud

Computing providers, draft BSI Standard (in German),

German Information Security Agency, Bonn.

Calder, A., Watkins S. and Watkins S.G., 2010,

Information security risk management for ISO27001

/ISO27002, IT Governance Ltd, UK.

Chou, Y., Levina, O., and Oetting, J., 2011, ‘Enforcing

confidentiality in a SaaS cloud environment’

Proceedings of the 2011 19th Telecommunications

Forum (TELFOR), 22-24 Nov. 2011, pp. 90-93, IEEE

Digital Library, IEEE Portal.

CSI, 2007, Computer crime and security survey 2007,

Computer Security Institute, viewed 20 Oct. 2011, <

http://www. gocsi.com/forms/csi_ sur vey.jhtml >

Diver S., 2007, Information security policy –a

development guide for large and small companies,

SANS Institute, viewed 28 February 2012, <

http://www.sans.org/reading_room/whitepapers/policy

issues/information-security-policy-development-

guide-large-small-companies_1331 >

ENISA (European Network and Information Security

Agency), 2009, Cloud Computing: benefits, risks and

recommendations for information security.

Guel, M. D., 2007, A short primer for developing security

policies, SANS Institute.

Hickey, A. R., 2010, Cloud computing security policies,

procedures lacking, CRN, viewed 28 February 2012,

<http://www.crn.com/news/security/224201359/cloud-

computing-security-policies-procedures-lacking.htm>

ISO/IEC 2005, Information technology – security

techniques – information security management

systems – requirements, ISO/ IEC 27001 Standard.

Jaeger, P., Lin J., and Grimes, J., 2008, ‘Cloud Computing

and information policy: computing in a policy

Cloud?’, Journal of Information Technology Politics ,

vol. 5, no.3, pp. 269-283.

Kee, C. K., 2001, Security policy roadmap - process for

creating security policies, NANS Institute.

Martin, E., 2011, ‘What’s wrong with security?’

Information Security, vol.13, no. 9, November, pp.8-

10.

NIST, 2009, Recommended security controls for federal

information systems and organizations, NIST SP 800-

53 v3 Standard.

Oracle, 2009, Securing data at the source: a guide to oracle

database security, viewed 28 February 2012, <

http://media.techtarget.com/Syndication/SECURITY/

SecuringDataSource.pdf>

OWASP, 2011, Mobile top 10 risk, viewed 28 February

2012,<https://www.owasp.org/index.php/OWASP_M

obile_Security_Project#tab=Top_Ten_Mobile_Risks >

Predd, J., Pfleeger, S. L., Hunker, J. and Bulford, C., 2008.

‘Insiders behaving badly’, Journal of IEEE Security &

Privacy, vol. 6, no. 4, July/August, pp. 66 – 70.

Rasmussen, M., 2011, Accountability in Policy

Management, Corporate Integrity, viewed 28 February

2012, < http://www.corp-integrity.com/compliance-

management/accountability-in-policy-management>

Tipton, H. F. and Henry, K., 2007. Official (ISC)

Guide

to the CISSP CBK, Auerbach Publications, New York.

SECRYPT2012-InternationalConferenceonSecurityandCryptography

232
