Flexible Information Management, Exploration and Analysis in

SAP HANA

Christof Bornhoevd, Robert Kubis, Wolfgang Lehner, Hannes Voigt and Horst Werner

SAP Labs, LLC, 3412 Hillview Ave, Palo Alto, CA 94304, U.S.A.

Keywords: Schema-flexible Database Management System, Graph Database, Flexible Information Management.

Abstract: Data management is not limited anymore to towering data silos full of perfectly structured, well integrated

data. Today, we need to process and make sense of data from diverse sources (public and on-premise), in

different application contexts, with different schemas, and with varying degrees of structure and quality.

Because of the necessity to define a rigid data schema upfront, fixed-schema database systems are not a

good fit for these new scenarios. However, schema is still essential to give data meaning and to process data

purposefully. In this paper, we describe a schema-flexible database system that combines a flexible data

model with a powerful data query, analysis, and manipulation language that provides both required schema

information and the flexibility required for modern information processing and decision support.

1 INTRODUCTION

The monolithic databases of the past, representing

self-contained fully integrated information univer-

ses, are giving way to much more fragmented

ecosystems of data sources. This trend is culmi-

nating in the form of today’s Web, which offers a

breathtaking amount of structured, irregularly

structured, and unstructured information.

To make use of multiple diverse data sources, the

traditional data integration approach is to integrate

those sources into a single context so as to get a

comprehensive and consolidated view on the data.

As the schema of data must be known in advance

and then coded explicitly in the database, the efforts

for data source connection, data integration, and data

cleansing, severely limit the viable number and

complexity of information sources. As a conse-

quence, many needs for data analysis remain

unfulfilled, since required data is not available in an

integrated and consolidated form.

SAP is developing a comprehensive solution to

better support data exploration and analysis in highly

dynamic and heterogeneous business contexts, based

on the HANA main-memory centric data mana-

gement system. The need to tap into a mostly

unpredictable set of heterogeneous data sources in

short time frames is necessary for agile business

analysis and decision support (Cohen et al., 2009).

In contrast to conventional approaches, the

solution outlined in this paper follows an “integrate

as you go” paradigm to support transformation and

consolidation steps on demand. By handling data

together with soft-coded metadata, it is relatively

easy to consolidate data from different sources with

similar meaning and overlapping attribute sets.

Firstly, object types are imported together with

the data without requiring upfront modeling.

Secondly, it is easier to identify gaps and

inconsistencies in a model where data and metadata

are treated similarly, because the existence or

nonexistence of a property type in a set of data

objects can be treated in the same way as the

occurrence of a property value. As a consequence, a

stepwise integration allows a more agile use of a

broader range of data sources with different schemas

and with varying degrees of structure and quality

(Franklin et al., 2005); (Das Sarma et al., 2008);

(XML Query Language, 2007).

While the data foundation of applications gets

more diverse, there is also a shift to new end user

devices, such as smart phones, tablets, and electronic

whiteboards, which dramatically change how people

interact with data. The traditional form-based

interfaces are commonly based on a three-step

interaction pattern of posting a search request,

picking a data object from the result list and

manipulating that object. This decade-old interaction

pattern limits the amount of data a user is able to

Bornhoevd C., Kubis R., Lehner W., Voigt H. and Werner H..

Flexible Information Management, Exploration and Analysis in SAP HANA.

DOI: 10.5220/0004011500150028

In Proceedings of the International Conference on Data Technologies and Applications (DATA-2012), pages 15-28

ISBN: 978-989-8565-18-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

review without getting lost, and is insufficient for

mass manipulation of data objects. The search step

does not allow real exploration but merely helps to

shrink the result list; hence, it still requires the user

to know what he is looking for.

Modern and future devices allow a more intuitive

tactile- and gesture-based interaction, and provide

various kinds of context information (e.g. location,

orientation and acceleration). Based on the capabi-

lities of these devices, new user interfaces offer a

freely interactive and explorative way to work with

data. With the ability to present data at instantly and

easily changeable levels of detail and to dynamically

create context-sensitive views or filters, these new

interfaces supply the user with exactly the

information that is relevant for his current situation.

This flexible and intelligent way of data presentation

and interaction lets users search, view, handle, and

manipulate very large datasets of varying kinds and

structure (Perlin et al., 1993); (Morris et al., 2010);

(Werner et al., 2011).

Putting the large variety of available data and the

new UI capabilities together, a wide range of new

applications that leverage potentially large weakly

structured and only partially integrated data becomes

possible. For instance, in the area of competitive

market intelligence future applications can analyze

customer sentiment, but can also be used to discover

market trends, competitor moves, regulatory

constraints, and so on, early, and handle these

proactively. Such applications will be able to crawl

the Web and combine information extracted from

unstructured content (typically blogs, news pages,

press releases) with publicly available structured

information (e.g., from Freebase) and private

structured information (contained mostly in business

applications).

In contrast to the established transactional

applications, the content of these collaborative

applications - a shared and incrementally composed

work context - is less predictable. Hence, it does not

fit well with a predefined rigid schema, which is the

key design concept of relational database systems.

More flexibility in the data model is provided by

key-value stores or document-oriented database

management solutions. However, abandoning a rigid

up-front defined database schema also implies that

the intended meaning of data, which so far has been

contained in the schema, must be made explicit and

completely handled within the application coding.

Semantic Web technology is one attempt to

create a more explicit representation of the meaning

of data. But representing meaning by complete and

consistent sets of computer-processable rules requi-

res a rigid standardization of metadata vocabularies,

and does not provide a concept for dealing with

different context-specific views on identical entities,

with incompleteness and inconsistencies.

In summary, we see this kind of heterogeneity

and the strong scalability demand resulting from the

fast growing amount of available and potentially

relevant data as one of the main challenges for

database technology. Future data repositories need to

support the coexistence of heterogeneous content

and its incremental integration to the degree needed,

based on specific application knowledge and

requirements. We therefore see the need for data

management systems that do not require the upfront

definition of rigid database schemas and that support

the efficient representation and processing of large

volumes of irregularly structured, not necessarily

fully integrated data.

In this paper, we describe an extension to SAP’s

HANA data management and analytics engine.

(Färber et al., 2011); (Gupta et al., 2012). HANA is

a main-memory centric database system that

leverages new technologies such as multi-core, SSD,

and large main-memory capacities to significantly

increase performance of analytical and transactional

applications. HANA is based on a fundamentally

new system architecture that allows storing data

either column- or row-oriented. We leverage HANA

as the foundation of a new schema-flexible data

management system that we call Active Information

Store (AIS). AIS capabilities are realized directly on

top of the HANA database engine to guarantee good

query performance and scalability.

2 REQUIREMENTS

We studied a broad range of uses cases, such as ad-

hoc data integration and analysis, competitive

market intelligence, social network analysis, idea

management business user enablement, and next-

generation collaboration tools. Based on these use

cases, we identified common requirements for an

optimal underlying data store. A data store

developed specifically for such applications has to

be able to efficiently manage schema-flexible,

irregularly structured and partially integrated data

with a soft-coded or system generated schema.

With such a data store, schema information does

not need to be defined upfront. Instead, the data is

self-describing (a soft-coded schema). Data objects

of similar structure, or representing similar kinds of

entities, do not need to have the same semantic type

(are not fully integrated), and data objects of the

DATA2012-InternationalConferenceonDataTechnologiesandApplications

same semantic type do not need to exhibit the same

structure (are irregularly structured). Once the data

is in the data store, changing the schema of data

objects has to be possible at any point in time, and

must be processed as efficiently as any other first-

class data operation (schema-flexible). In short, the

data store needs to support the coexistence of

heterogeneous content and its incremental integra-

tion to the degree needed by the specific application

at hand.

In addition, the provided data model must

provide strong support for links between data

instances of different types to support information

correlation and re-organization. Functionally, the

data store has to provide the following mass data

operations:

 Load, insert, update, and delete objects with

possibly irregular structure and without a predefined

fixed schema.

 Efficiently add and remove attributes and

links/associations to and from data objects.

 Efficiently filter and classify data objects.

 Efficiently traverse links between data objects.

 Calculate the union, difference, and intersection

of large sets of objects.

 Group, aggregate, and consolidate possibly

heterogeneous data objects.

All operations are mass-data oriented, i.e., they

process large sets of data objects at once.

Additionally, these operations have to treat data

objects as a whole and preserve a data object’s

integrity as a logical unit.

3 SYSTEM OVERVIEW

We have developed the Active Information Store

(AIS) as an extension to the existing HANA engine

to provide a powerful schema-flexible data store to

address the posed data management challenges. In

this section, we will summarize the design principles

that guided the development of AIS:

(1) In AIS, a data object consists of a group of

semantically and technically typed values that form

a semantic unit, e.g. to describe a person or a

product. Semantic types, e.g. person, describe the

intended meaning of a data object, whereas technical

types like Integer or String describe the

representation of data in the system. Semantically

typed associations represent links between these data

objects. For efficient value processing, such as

aggregation, all attributes of the same semantic type

have the same technical representation type. To

remain structurally flexible, semantic types do not

impose restrictions on other semantic types related

to a data object, e.g. the type person does not

determine the attributes a person instance can have.

(2) AIS strengthens the integrity and identity of a

data object as a logical unit of storage and retrieval.

Each data object instance has a single identifier that

is immutable during regular query processing. Only

consolidation or aggregation of data objects will

result in new data object instances.

(3) AIS provides light-weight support for semantic

data processing. AIS is primarily a data store that

incorporates a number of helpful semantic features:

(a) Semantic types, which are modeled

(conceptually) through the means of the AIS data

model; (b) Taxonomies, to organize semantic types;

and transitivity, which can be used in queries.

(4) AIS uses URIs as the primary mechanism for all

identifiers exposed outside of AIS. URIs are a well-

established standard for identifiers, and the XML

namespace mechanism is adopted.

(5) AIS generally processes data objects in sets, with

good support for mass data processing through built-

in mass operations in the query language.

(6) To allow for complex operations, all elementary

operations of AIS must have minimal side-effects,

so that they can be freely combined. This implies

that all operations should be as general as possible,

and closed in regards to the AIS data model, i.e.

produce output that can be used directly as input for

other operations. By this principle AIS tries to

provide a set of operations that combine

compactness with expressiveness.

(7) With AIS, a statement can encompass many

complex operations. Multiple insert, update, delete,

and query operations can be combined within a

single statement. This helps to reduce the number of

round trips between client and server, and provides a

context for cross-operation optimizations.

(8) AIS leverages the highly efficient in-memory

storage layer of SAP HANA. AIS capabilities are

implemented directly on top of the HANA engine to

guarantee good performance and scalability.

(9) AIS provides a stateless, RESTful client API. The use

of complex statements allows the definition of client

actions that involve larger units of work that need to be

processed as one atomic unit.

FlexibleInformationManagement,ExplorationandAnalysisinSAPHANA

4 DATA MODEL

The AIS offers a very flexible data representation

model that allows the uniform handling and combi-

nation of structured, irregularly structured, and un-

structured text data. All data managed and processed

by AIS is converted to this common data model.

In this model, data objects are represented as Info

Items. Info Items are organized and persisted in

Workspaces, which establish a scope for visibility

and access control.

An Info Item provides a single uniquely

identifiable data instance, holding a set of

Properties, which describe the Info Item. A property

can be either an Attribute or an Association. Info

Items and their properties have an attached semantic

type label that indicates the assumed item class (e.g.

person), attribute type (e.g. age), and relationship

type (e.g. is-parent-of or works-for), respectively.

We call these type labels Terms.

Formally, an Info Item  is a quadruple

(

,,,



)

, where  represents the item’s URI,  is

a set of  property Terms

{





,…,



}

,  is the value

function and 



is the item’s Term. The value

function : →





×…×





maps every property

Term 



to a list of all values of the Info Item’s

property of Term 



An Attribute associates a value with an Info Item,

and is labeled with a Term. A multi-valued attribute

can be represented by multiple attributes of the same

Term. An Association describes a unidirectional

typed relationship between a pair of Info Items. An

Association is labeled with a Term indicating the

semantic type of the Association. The same pair of

Info Items can be related via multiple Associations

of different types, and Info Item instances of the

same semantic type can be related through different

types of Associations.

Figure 1: Example of info items and associations.

Figure 1 shows an example of Info Items taken

from a data integration and analysis example. The

two Info Items on the left side represent entities

from a developer community (DC). The two Info

Items on the right side originate from an ERP

database. The work-as and the posted Associations

link Info Items as their corresponding entities are

associated in the respective source databases. The

same-as Association has been added later as the

result of integrating the datasets for analysis. By this

means, the data is integrated to the level sufficient to

analyze how actively employees participate in the

developer community, for example.

As mentioned earlier, a Term represents the

semantic type of an Info Item or Property. In

addition to its semantic meaning, a Term also has an

assigned Technical Type that determines the

physical representation of the corresponding data

element. In the case that a Term describes an Info

Item or an Association, the technical type is Info

Item or Association, respectively. For Attributes, the

technical type can be Integer, String, Date, etc.

The AIS data model is strict and consistent in its

semantic and technical typing of data. All Info Items

and all Properties have a semantic type. All Property

values of the same semantic type have the same

Technical Type. To gain flexibility, the AIS data

model loosens consistency regarding the structural

implication between semantic Info Item types and

semantic Property types. Info Items that have

assigned the same semantic type may, and in general

do, have different sets of properties. However, the

structural information about which Info Item types

expose which Property types is not lost; it can be

captured with Templates. A template is associated

with a specific Term and provides information about

the structure, i.e., the Properties of the Info Items

currently in the store of the corresponding Term. A

Template describes the set of frequent Properties

that are available for most (e.g. 95%) of the

currently available Info Items, and the optional

Properties that are only given for some of the Info

Items of the corresponding type.

Terms are represented as Info Items. This allows

their retrieval and manipulation either as Terms, i.e.,

as metadata, or (possibly together with other Info

Items) as Info Items, i.e., as data. By allowing Terms

to be treated and used as regular Info Items, we give

up a strict, and in some applications artificial,

separation of data from metadata.

Terms can be taken from domain-specific

Taxonomies that can be provided to AIS as semantic

metadata. Terms from a specific taxonomy are

assigned to Info Items and their Associations when

they are loaded into AIS, but can be changed later.

In this way, Terms can provide a first hook to make

DATA2012-InternationalConferenceonDataTechnologiesandApplications

the intended meaning of an Info Item, its Attributes,

and Associations, more explicit, by putting it into

the context of a taxonomy of type denominators.

Figure 2 illustrates the use of Terms. Terms form

a subsumption tree. If a knowledge worker, for

example, wants to analyze all Info Items represent-

ting a person, i.e., employees from the ERP system

and members of the developer community, she could

easily introduce a new common Super Term, e.g.,

person for employee and member, as shown in the

figure. Additionally, she might let AIS create a

Template based on all Info Items that the Term

person subsumes.

Figure 2: Example of info items and terms.

In summary, AIS provides a very generic and

flexible graph-oriented data model, where Info Items

form the nodes and Associations the edges of a

graph. The data model does not enforce a tight

integration of and structural consistency among data

items, which typically come from different hetero-

geneous sources into one common data schema.

Rather, it supports the coexistence of data items

from different sources and their stepwise integration.

While providing rich schema information, AIS does

not require defining the schema of the data upfront

in a rigid way. Rather, the schema evolves as new

Info Items are imported or created, new attributes

are added, new Associations between Info Items are

established, and new Terms are introduced.

5 QUERY LANGUAGE

AIS offers a powerful data query and manipulation

language called WIPE. In this section, we outline the

basic structure of an AIS statement, and describe the

set of operations supported in WIPE.

In the case of AIS, a statement can be composed

of multiple data manipulation operations and may

return multiple result sets. The data operations of a

given statement are executed in their order of

declaration as one logical unit of work. More

formally, an AIS statement is defined as a triple

(,,), where  is the workspace the statement is

operating in,  is a set of namespace definitions and

=



,…,



is a list of data operations.

Figure 3: Example of an AIS statement.

During execution, every statement has a

statement context , to keep track of all execution-

related information. Primarily, a statement context

encom-passes a set of local identifiers, which can be

used to structure a statement. In that sense, a

statement context  is a function defined by a set

=

{





,…,



}

of local names and a set =

{





,…,



}

of expressions so that 

(





)

=



Figure 3 shows a statement to find employees

contributing to the development community. First,

the statement specifies the workspace it will be exe-

cuted in. Second, it establishes associations between

employee items and member items having the same

email address. Third, it defines two Info Item sets,

one containing all employees that have contributed

to the community and one containing employees that

have recently contributed. Forth, it retrieves some

basic counts, to give an overview of what the data

looks like. Fifth, the statement retrieves the recently

contributing employees. The example illustrates the

use of the update, assign, and retrieval operations

within a single statement.

AIS offers Load, Insert, Update, and Delete as

manipulation operations, Retrieval to retrieve data,

and Assign for structuring complex statements. In

the next two sections, we describe these data

operations in more detail.

Load and insert operations allow to bulk load and

to create new Info Items in a workspace. Update

operations allow changing the values of properties

well as adding new properties or removing

properties from Info Items. The example statement

shown in

Figure 3 adds an association same-as to all

employees (line 2). The target of an association can

be specified by any valid AIS expression that

represents a set of Info Items.

FlexibleInformationManagement,ExplorationandAnalysisinSAPHANA

The retrieval operation allows fetching data and

is defined as a triple (,,), where  is an expres-

sion,  is an optional URI, and  is an optional set

of  property Terms

{





,…,



}

. Expression 

defines the set of Info Items to retrieve. Any valid

AIS expression that results in a set of Info Items

may be used here. In case of multiple retrieval

operations within a single statement, the name (i.e.

URI) of a result set can be used to distinguish the

result sets on the client side. The example statement

retrieves two result sets (line 4 and 5), called

overview and recentContributers, respectively.

When an Info Item is shipped to the client, only a

subset of the item’s properties might be of interest to

the client. If  is provided, the retrieval operation

will select only properties of the Terms in  to the

result set (projection). Formally, for every Info Item

(

,



,,



)

an Info Item I



(

,′,



,



)

shipped so that T′ = ∩



and ′ is only defined

for ∈′. In the example, the second retrieval

operation projects only the properties

uri, name and

email.

Finally, the assign operation allows the client to

structure a complex statement by naming and re-

using sub-expressions. In particular, an assign

operation is defined as a pair (,), with  being the

local name and  being the expression that  will be

bound to. The binding is stored in the statement

context , so that  will be defined by =∪

{



}

and =∪

{



}

after the assignment. The example

statement illustrates that in line 3.

Expressions form the core of the AIS query

language. In particular, an AIS expression is defined

to be a literal, a reference (e.g. a URI), a local name

or an operation applied to one or more sub-

expressions. As a starting point, AIS provides the

built-in local name

$ALL, which represents the set of

all Info Items persisted in the current workspace. A

set of all Info Items of a specific Term can simply be

referenced by the URI of the Term. For example

uri:member references the set of all members of the

developer community.

Based on these initial sets of Info Items,

expressions allow the refinement of the requested

Info Item set in a retrieval operation. Besides

standard numeric algebra, Boolean algebra, string

operations, and other value-type specific operations,

set operations are most crucial for mass data

processing. AIS offers six essential kinds of set

operations: (1) Set Algebra, (2) Graph Traversal, (3)

Filtering, (4) Quantification, (5) Aggregation

Functions, and (6) Grouping. We will describe these

categories in the following.

Set Algebra. Set Algebra operations encompass the

three basic operations Union ∪, Intersection ∩ and

Difference \ (asymmetric difference). Given two

sets  and  of Info Items the three operations are

defined as follows:

∪=

{

:∈∨∈

}

∩ =

{

:∈∧∈

}

\ =

{

:∈∧∉

}



For example, the set of all developer community

posts and blog articles can be expressed as:

uri:post UNION uri:blog-article

Graph Traversal. The traversal operation allows

resolving properties, i.e., associations and attributes.

It is defined as a pair

(

,

)

, where  is the set of

Info Items to start the traversal from and  is the set

of property Terms to traverse over. The resulting set

contains all values that the properties of any Term

∈ have on all Info Items ∈:

(

,

)













,

with 



∈



∈∧



∈

In the case of Associations, the result is a set of Info

Items. In the case of attributes, the result is a set of

primitive values. Terms for Attributes and Terms for

Associations cannot be mixed in a single traversal

step to avoid a result set consisting of both Info

Items and primitive values.

For association traversals, the operation can be

marked with the Reverse flag (

<-) or the Transitive

flag (

*). In the first case, the associations will be

traversed in the opposite direction. In the second

case, the traversal results in all items reachable from

 by any association path in 



. In our example, all

emails of the employees can be retrieved with the

expression:

uri:employee->uri:email

while the expression

{uri:com.sap.std.erp.ui}<-uri:works-for

retrieves all employees of the ERP UI team. Note

that the traversal operation strictly works on sets and

we have to create a set containing the specific team

Info Item, referenced by its URI. Assuming that

teams have sub-teams, we can get all emails of all

team members and sub-team members with:

{uri:erp.ui}->uri:subteam*<-uri:works-for

Filter. With the filter operation, Info Item sets can

be filtered according to a given condition. Formally,

a filter operation is defined as a pair

(

,: →

{

false,true

})

, where  is the Info Item set to filter

on, and  is a condition function that maps every

Info Item of  to a Boolean value. The resulting set

DATA2012-InternationalConferenceonDataTechnologiesandApplications

contains only Info Items of  mapped to true:

(

,

)

{

: ∈ ∧

(



)}

.

The condition function  is a logical expression tree

which can consist of Boolean operations, relational

conditions and quantification. A relational condition

represents a basic value comparison. It has a left

value expression, a comparator, and a right value

expression, and returns true if the comparison holds

for the two values. For example, we can filter all

employees by their salary:

$e: uri:employee

WITH $e->uri:salary > 100k

Quantification. Quantification conditions check

whether a given quantity of elements of an Info Item

set or a value set satisfy a condition function. A

quantification operation is defined as a triple



(

,,

)

, where  is a quantifier,  is the set, and 

is the condition function. The quantifier specifies the

required quantity for a quantification to yield true.

AIS supports the existential quantifier ∃ and the

universal quantifier ∀:

(

∃,,

)

=∃∈,

(



)





(

∀,,

)

=∀∈,

(



)



In the example, the quantification condition allows

us to filter all teams with at least one high-income

earner:

$t : uri:team

WITH ONE $e : $t<-uri:works-for

WITH $e->uri:salary > 100k

Aggregation Functions. Aggregation functions map

a set or a list of Info Items to a single value. AIS

supports the basic aggregation functions COUNT

(number of element), SUM (summation), AVG

(average), MIN (minimum), and MAX (maximum).

For instance, the following expression filters

development community members according to the

number of posts they made:

$m : uri:dc-member

WITH COUNT($m->posted) > 500

Grouping. AIS offers a very general grouping

operation, where we understand grouping as the

creation of a new Info Item from a group of existing

Info Items. A grouping operation is defined as a

triple

(

,



,

)

, where  is the base set, 



is a set of

grouping expressions, and  is an Info Item

constructor function. All Info Items  in S with

equivalent results on all expressions in 



form a

group . The resulting set of a grouping operation

contains new Info Items created by applying  to

every :

(

,



,

)

{

: = 

(



)

∧∈



(



)

}

Assuming that  is the domain of all Info Items, an

Info Item constructor function :

(



)

→ maps a

subset of Info Items to a new Info Item. An Info

Item constructor can be defined (similar to an Info

Item) as a quadruple

(

,,



,

)

, where  is the new

item’s URI,  is a set of  property Terms

{





,…,



}

, 



is a set of  expressions, and  is the

item’s Term. When applied to a group , 

(



)

results in a new Info Item of Term  with 

properties, so that the -th property is of Term 



∈

and is assigned with the evaluation of expression





∈



, where 



is evaluated against group .

(

,,,

)

(

,,:

(





)

=



(



)

,

)

For instance, to query the average number of posts

of DC members, we would define the grouping as:

uri:post,



(

,,



,

)

 with:





=

uri:posted









=

{

uri:email,uri:numberOfPosts

}







=

uri:posted









uri:email







,COUNT

(



)

.

In statement syntax that is:

GROUP $s : uri:posts AS $g BY $s<-

uri:posted

TO ITEM {

uri:email = $g<-uri:posted->uri:email,

uri:numberOfPosts = COUNT($g)

}

Grouping can also group Info Items based on

aggregates. For example, listing for each team size

the ratio of heavy posters can be done with the

expression:

GROUP $e : uri:employees AS $g BY

COUNT($e->uri:works-for<-uri:works-for)

TO ITEM {

uri:sizeOfTeam =

COUNT($e->uri:works-for<-uri:works-for),

uri:heavyPosterRatio =

COUNT($e : $g WITH

COUNT($e->same-as->posted) > 500) /

COUNT($e : $g WITH

COUNT($e->same-as->posted) < 500)

}

A. Term Operations. Most of the described AIS

operations rely on Terms. AIS organizes Terms in

taxonomies to allow an explicit description of

subsumption relationships between Terms.

Formally, subsumption is a function τ

(

)

that results

in a set

 =

{





:issuper-typeof



}

∪{}

with respect to the underlying taxonomy. Obviously,

other operations have to deal with this resulting set

FlexibleInformationManagement,ExplorationandAnalysisinSAPHANA

of types so that their result reflects the meaning of

subsumption. For AIS, we allow subsumption for

Term URIs representing Info Item sets, association

traversal, and for the filtering on the type property of

Info Items.

B. Life Cycle. As mentioned before, single Info

Items are the granularity of data storage, but sets of

Info Items reflect the granularity of processing data.

Therefore, Info Items and Info Item sets are subject

to different life cycles when being processed via

query language statements.

Every Info Item, as the primary unit of storage, is

generally considered to be persistent and can be

identified among all Info Items in a workspace by its

URI. Operations, except Info Item constructor

functions, do not create new Info Items.

Info Item constructor functions are the only

operations to create new Info Items. These newly

created items are transient, i.e., they are not

persistent by default, and will live only as long as

the statement in which the transient items were

created is processed. Transient Info Items do not

necessarily have a unique identity. For that reason,

transient Info Items cannot be mixed with persistent

items in operations and sets. However, AIS can

return transient Info Items to the client or persist

transient Info Items with an Insert operation within

the same statement.

A set of Info Items, as the primary unit of

processing, is generally transient. Every operation

that results in a set of Info Items conceptually

creates a new set. However, sets can be explicitly

persisted for later retrieval, or re-use in other

statements.

6 ARCHITECTURE

AIS provides an extension of the SAP HANA in-

memory database engine. The existing HANA

storage and query processing layer fits well the

needs for scalability, speed, and built-in analytical

processing capabilities.

Figure 4 outlines the conceptual architecture of

AIS. At the front-end AIS exposes a RESTful client

API. A client sends its statements as requests to this

service. Inside AIS, a REST server receives this

request, extracts the statement, and hands it over to

the parser. The parser transforms the statement into

an internal representation and a rule-based statement

simplification procedure prepares it for execution. A

complex AIS statement, which can be divided into

an operational processing step and a result fetch

step, usually involves multiple storage layer

interactions before shipping the result sets back to

the client.

Figure 4: System architecture overview.

AIS does not preserve any state with regard to

the client. For scalability over the number of

concurrent clients, the processing of client requests

can be easily distributed over multiple worker

threads within a single machine and over multiple

machines. The HANA storage layer already provides

excellent scalability by being able to distribute data

across multiple machines.

In the following subsections, we describe (1) the

capability of the storage layer, (2) how we map the

AIS data model to a fixed schema as required by the

storage layer, and (3) how we process AIS

statements on top, while utilizing as much of the

existing storage layer capabilities as possible.

A. Storage Layer Capabilities. In the storage layer,

data is stored in fixed-schema tables. Data can easily

and highly efficiently be inserted, removed,

modified, and queried. To retrieve data, the storage

layer supports “Select Group Order Project”

(SGOP) queries and join views to join tables on

predefined join conditions over an arbitrary set of

tables with potentially different join semantics.

A SGOP query

(

,,,,

)

selects all rows that

match the predicate  from table or join view ,

groups the rows by all columns ∈, creates

aggregation columns ∈, sorts the result by all

columns ∈, and finally projects to all columns

∈∪. If  is empty,  will be a regular

projection. If  is empty, the query will return all

available columns. An aggregation column 

(



)

aggregates a column  of  with the aggregation

function  (sum, minimum, etc.). Predicate  is a

logical expression of arbitrarily nested conjunctions

and disjunctions of conditions of the form 

(

,

)

where  is a relation (equal, less, greater, in, etc.),

is a column of , and  is a value literal.

B. Mapping to the Storage Layer. We need to

provide the required flexibility in the AIS data

DATA2012-InternationalConferenceonDataTechnologiesandApplications

model

storage

fixed sc

determi

and the

Logical

and cha

efficient

data is

has to

“

logical

storage

Technic

efficient

storage

aggrega

technica

the exec

cast on

xisten

space-e

The ma

for non-

not a so

stored

existing

The ba

entity o

level of

as data

entity a

are gen

storage

followin

for AIS

(1) Irreg

and un

the expl

we chos

(2) The

type pr

coding.

and st

corresp

artition

ull v

property

(3) Entit

means

more fl

e tailo

workloa

hile relying

ayer, i.e. w

ema. The po

ed by the AI

torage layer

Type Flexibi

nge logical

y. In additio

nknown at

“

soft-code”

type inform

ayer.

l Type

y utilize the

layer, suc

ions. The

value types

ution of suc

very value it

e Represent

iciently and

ping has to

xisting valu

lution for no

ore efficien

values shoul

ic dimensio

ientation, i.e.

soft coding, i

r is mapped

straction an

ralized and

ayer. Regar

g considerati

ata.

larly struct

redictable n

cit represent

a vertical o

equired logi

servation al

ence, we re

re all val

nding techn

the value ta

lues for n

and technica

abstraction

o make an

xible. For an

ed based on

. AIS is an

n an underl

need to ma

ssible mappi

requiremen

apabilities o

. We want

ypes at any

, the set of l

eployment ti

all logical ty

tion as reg

reservation.

type-specific

as value

apping has

of property

an operatio

operates on.

tion. We w

not waste

void an expl

s. In particul

-existence,

ly than reg

be explicitly

s for a ma

, horizontal

.e., how muc

to storage l

decompositi

ecomposed i

ing these bu

ns justify

red Info Ite

mber of pro

tion of non-e

er a horizont

al type flexib

eady define

resent all lo

es in colu

ical type.

le by techn

on-existing

type.

and decom

existing wel

application,

the applicat

pplication-in

ing schema-

Info Items

g alternative

s on the one

the other ha

to create, re

time easily

gical types i

e. The map

es, i.e., trea

lar data in

We want

operations o

comparisons

to preserve

alues. Other

would inclu

ant to store

emory resou

cit represent

r, Null value

ince they ar

lar values.

stored.

ping are (1)

r vertical, (2

)

typing is tr

yer elements

n, i.e., if en

to chunks o

lding blocks

mapping w

s have a var

erties. To a

isting prope

l orientation.

lity and tech

the level of

ical types as

ns with

dditionally,

cal type to a

combinations

osition are

-defined sc

ntity chunks

on’s schema

ariant reposi

ixed

to a

are

and

ove

and

the

ing

the

ise,

de a

data

ces.

tion

are

not

nly

the

)

the

ated

, (3)

ities

the

use

ying

void

ties,

ical

soft

data

heir

void

ood

ema

can

and

ory,

abs

inf

ref

the

rel

tec

ter

ind

rep

rel

Att

tec

col

ful

act

att

req

util

re schema

ance. Hence

traction and

ping.

summarize,

itioned valu

ompasses the

Item. Thi

rmation of e

I, its Term,

rence the ite

ps the basic

Term’s uniq

Term’s supe

m’s instance

ed on basic

antic type, b

Term rel

tionship are

nical types

column t

ms. The col

sed for Info

cate the te

esenting a T

Figu

ociation. Th

tional schem

een Info It

rce item, th

antic type) o

ibute. Finall

he Info Ite

nical type p

mns and en

y utilize

abilities of t

al value, t

ibute’s Term

h this map

ired for the

ize as much

sible.

Statement

erful stora

and workloa

we do not

ecompositio

e selected

ables. The

tables shown

central ta

ery Info Ite

and a uni

in the othe

attributes of

e identifier,

term, and t

. This tabl

fo Item attr

fore accessi

tionship a

emantically

re hard-cod

store the s

mn for the

tems but, if

hnical type

rm.

e 5: Storage la

second m

records uni

ms, includin

target ite

the associati

, the third ta

s. Using a s

eserves the

bles the AI

the selecti

e HANA st

e table sto

nd of the In

ing, we m

AIS data

f the storage

rocessing

e layer at

d are not

incorporate

into our sto

vertical sch

storage laye

in Figure 5.

le keeps t

including

ue identifier

tables. This

each Term,

URI, the id

e technical t

is used fo

butes, in par

g the value t

d the Sup

different, bu

d, we can

per term r

echnical typ

eeded, is le

if the Info

er schema.

jor table of

irectional as

the identifi

, and the

on.

le stores the

eparate table

ypes of the

execution

n and a

rage layer.

es identifier

o Item it bel

intain the

odel, and ar

layer’s capa

verview.

hand, the

nown in

ny entity

age layer

ma with

r schema

e header

e item’s

used to

able also

including

ntifier of

pe of the

filtering

icular its

bles.

r Term

since all

e-use the

lation of

remains

eraged to

em is

the AIS

ociations

rs of the

erm (i.e.

attributes

for each

ndividual

ngine to

gregation

eside the

s of the

ngs to.

lexibility

able to

ilities as

aving a

statement

FlexibleInformationManagement,ExplorationandAnalysisinSAPHANA

processing engine of AIS remains lean and does not

replicate any of the capabilities of the storage layer.

Thus, our processing model tries to delegate as much

of the query processing to the powerful storage layer

as possible, and the process-sing model is designed

to leave the payload data in the storage layer until

Info Items have to be shipped to the client. Since the

processing of Load, Insert, Update, and Delete

operations is straight-forward, we focus here on the

Retrieval operation.

Since the AIS query language is more expressive

than the query language of the underlying storage

layer an AIS statement, in general, results in

multiple storage layer interactions (Figure 6). After

parsing, AIS represents a Retrieval operation as a

statement tree. Every node in this statement tree

presents one of the operations of the AIS query

language as used in the specific Retrieval operation.

Assuming that its sub-expressions have been

processed, an operation can be processed either

without, with one, or with multiple storage layer

interactions.

In order to optimize the number of storage layer

interactions, the AIS statement simplifier removes

all idempotent operations, e.g., multiple negations,

and processes all operations that can be executed

without any storage layer interaction. Also, the sim-

plifier integrates all traversal operations on attributes

into their parent operation in the statement tree.

Figure 6: Statement processing model.

The AIS statement simplifier is based on an

extensible rule set. The simplification algorithm

traverses the statement tree top-down and then

bottom-up again. At each node of the tree, it rewrites

the tree according to the matching rules. Each rule

itself defines whether it is applied during the top-

down or bottom-up run, and whether the simplifier

should try to apply the rule repeatedly to the same

node. After the simplification step, the statement tree

is ready for the actual operation processing.

D. Operation Processing. After parsing and

simplification, AIS processes all operations of the

statement tree bottom-up, as illustrated in Figure 6.

The result of each operation is a Retrieval Reference

Table (RRT). An RRT is a set or list of Info Item

identifiers or values, respectively. Additionally, an

RRT can contain a set of Info Item identifiers as

back references for each of its entries. After an

operation has been processed, it is replaced with its

resulting RRT in the statement tree. The RRT then

forms the input to the operations higher up in the

tree. Eventually, the statement tree collapses into a

single RRT, which will be handed over to the result

fetch step.

Back references in RRTs are an important

mechanism for mass data processing. Many of the

AIS operations comprise Foreach semantics. If these

operations contain sub-operations that require

separate processing, the sub-operation would have to

be processed iteratively. With back references, an

operation keeps track of which elements of its output

resulted from which elements of its input. By this,

the iteration can be avoided and the sub-operation

can be processed in a single step. Nevertheless, this

approach trades space for time, and is therefore

bound by the available resources.

A Retrieval operation processes results in the

form of an RRT and may involve a number of

interactions with the storage layer, depending on the

operation being processed.

Set Algebra. Set Algebra operations are processed in

AIS without any storage layer interaction. Two input

RRTs are directly united, intersected or subtracted.

Traversal. Traversal operations require querying the

association table. The traversal

(

,

)

will result in a

storage layer query (Association,,,∅,), with

=

(

sourceItemID ∈  ∧termID ∈ 

)

and =

{

targetItemID,sourceItemID

}



Transitive traversal is realized iteratively. In every

iteration, we set S to the Info Item identifiers fetched

in the previous iteration and execute the storage

layer query again. More specifically, the predicate 

is adjusted for each iteration to avoid traversing the

same associations multiple times. Assume S as the

set of Info Item identifiers fetched in the previous

step, and R as the set of Info Item identifiers

retrieved in all iterations before the previous one,

then  is set to

(

sourceItemID ∈  ∧targetItemID

∉∧termID∈

)

If the storage layer query has an empty result, we

have reached the fixed point. Theoretically, a

transitive traversal can result in a very large set of

Info Items, in an extreme case encompassing the

DATA2012-InternationalConferenceonDataTechnologiesandApplications

complete workspace. Hence, processing a traversal

operation can become very time and space

consuming. Practically, however, we have not

encountered this problem for our use cases so far.

The traversal operation is also defined for attri-

butes. However, we always integrate the processing

of an attribute traversal in its nesting operation.

Filter. The processing of a filter operation depends

on its condition function, and we distinguish two

cases: (1) the condition function consists only of

logical operators and property-value comparisons, or

(2) it is a more complex expression.

In the first case, the statement simplifier has

transformed the condition function into disjunctive

normal form. The atoms are property-value

comparisons 

(

,

)

, each stating that a property of

Term  has to be in relation  with value , e.g., the

property salary has to be greater than 50k. Although

the storage layer is able to process predicates of this

class directly, the processing is more complex

because of the vertical schema. Therefore, we

directly push down disjunctions, but resolve

conjunctions by executing them as disjunctions on

the storage layer and post-processing the

conjunction within the AIS context. For instance, the

predicate

uri:a>5 AND uri:b=2 is executed as

(termID = 



∧value>5)∨(termID=



∧

value = 2)

We partition attributes in the storage layer by their

technical type, and therefore have to execute

comparisons of attributes of different technical types

in separate storage layer queries. Assuming a

condition function involves  conjunctions and 

technical types, we have to execute ∙ storage

layer queries. In practice,  and  appear to be

rather small, so that this approach is feasible.

All queries order their results by Info Item

identifiers. AIS then merges the result sets using

interleaved scans. The merge results in a stream of

(,) pairs, where  is an Info Item identifier, and 

a set of Term identifiers. After that the stream is

filtered to check whether every Info Item has

matches for every property Term of one conjunction.

In our example, we would check that every Info

Item had matches for

uri:a and uri:b.

In the second case, if a condition function is

more complex and involves other operations, e.g., a

traversal operation, all nested operations will be

child nodes of the filter operation in the statement

tree. The sub-operations can be seen as a function

: →



, where  is the set that needs to be filtered

and 



is the set the property-value comparisons are

defined on. For example, in the filter operation:

$e : uri:employee

WITH COUNT($e->same-as->posted) > 0

 is the set of employees and 



is the set of count

values. The sub-operations are two traversals and an

aggregation function. The processing of these sub-

operations results in an RRT with back references to

the Info Items in  (employees in our example).

Then, we regularly process the actual filter (in our

example: count value greater zero) on this RRT as

described in the first case, and unite all remaining

back references to get the final result.

Quantification. Quantification relies on filter

processing. The existential quantifier is weaved into

the filter processing to exploit early-out opportu-

nities. Here, we return true as soon as we see an item

successfully passing the post filter predicate . For

the universal quantifier, we use an interleaved scan

of  and the filter result ′, both already ordered by

item id, and return false as soon as we have an item

in  that is not in ′.

Aggregation Functions. A group of aggregation

functions 



,…,



applied to attribute traversal ope-

rations

(

,



)

,…,

(

,



)

can be executed directly in

the storage layer. Assuming all attribute Terms

∈=

⋃









have value type , AIS executes

the query (table

,,

{

termID

}

,,

{

termID

}

) with

=

(

itemID ∈ ∧ termID ∈ 

)



and =

{







(

value

)

,…,





(

value

)}

where 





is the corresponding aggregation function

at the storage layer for 



. If all attribute Terms ∈

are not of the same value type, then one storage

layer query per involved value type is executed.

Grouping. The grouping operation consists of the

grouping expressions (the set 



) and the creation of

new Info Items. Each grouping expression results in

an RRT of the grouping values that have resulted

from the expression and back references to the Info

Items to be grouped. Each RRT is sorted by the Info

Item identifiers. With interleaved scans, AIS merges

all RRTs into a single RRT, which now consists of

the grouping values of all grouping expressions plus

the back references. Now, AIS determines the actual

groups of Info Item identifiers. All back references

that belong to equal grouping values form one

group.

The item constructor creates a new Info Item for

each group of Info Item identifiers. Each group is

processed separately. Given an item constructor

function

(

,,



,

)

, we process each value expres-

sion in 



on the Info Item identifiers in the group,

and assign the resulting value to the corresponding

property of the new item.

FlexibleInformationManagement,ExplorationandAnalysisinSAPHANA

All grouping expressions 



, and likewise all

value expressions 



, have to be executed on the

same set, the set of Info Items to group, and a group

of Info Items, respectively. For that, we leverage a

number of shortcuts and optimizations. First, we

group traversals on the same source set for

execution. Second, we similarly group aggregation

functions on traversals. Third, for expressions with

identical sub-operations on the same source set, we

execute the sub-operation only once and re-use the

resulting RRT. Fourth, if a value expression is

identical to a grouping expression, we take the result

directly from the RRT used to determine the groups.

E. Result Fetch. Finally the result fetch retrieves the

actual payload data of the retrieval. Assuming a

Retrieval operation

(

e,u,T

)

whose query expression

e has been processed to an RRT S (a set of Info Item

identifiers), AIS now fetches all rows from the

property table whose item id is in S and whose Term

id is in T, by executing for every value type vt of the

property Terms in T the query

(table

,p,

{

itemID,termID

}

,∅,

{

itemID

}

) with

=

(

itemID ∈ ∧termID ∈ 

)

.

Two more storage layer queries are necessary: (1)

the Info Item table is queried for the header data of

the items, and (2) a join view over the association

table and the Info Items table is queried for

associations. All of these queries order their result

by Info Item id. With interleaved scans, AIS finally

merges the values into Info Items.

7 RELATED WORK

AIS clearly falls into the category of NoSQL

databases. The term NoSQL covers a wide range of

data stores, which vary considerably in the data

model used and the query and interaction

capabilities offered.

In terms of data models used in NoSQL

databases, key-value based, hierarchical, and graph-

based data models can be distinguished. The group

of key-value stores includes document stores (for

instance CouchDB (CouchDB, 2012)), pure key-

value stores (for instance Amazon S3 (Amazon S3,

2012)), and wide column stores (such as Bigtable

(Chang et al., 2008), or Cassandra (Lakshman et al.,

2009)). Generally, a key-value based data model

associates one to three hierarchical keys with non-

typed byte arrays. Although very general and

extremely flexible, the key-value concept does not

offer any inherent higher means to type and

associate entities. Approaches to work around these

conceptual shortcomings rely on interpretation by

the client application and are transparent to the data

store, including its query mechanisms.

Document stores typically follow a hybrid

approach nesting two data models. Being primarily

key-value stores, document stores additionally

structure values using a hierarchical data model such

as XML (Extensible Markup Language, 2008) or

JSON (Crockford, 2006). A tree of flat objects

allows modeling an entity’s structure and preserving

its integrity as a unit. Furthermore, it is possible to

hierarchically associate entities by nesting them.

Graph-based data models are more general and

allow arbitrary associations. Probably the most

general graph-based data model is RDF (RDF/XML

Syntax Specification, 2004). RDF stores statements

about entities as subject-predicate-object triples,

which form a labeled graph. Consequently, when

stored in RDF, entities are decomposed into

statements. The entity’s integrity as a unit is lost and

must be reassembled during retrieval. RDF is

probably the most general data model. However,

RDF is too general if the representation and

management of composite data objects is required.

The AIS data model resembles a graph of plain

objects. Plain objects graphs are a very flexible

representation of data, where values and links can be

easily added and removed, and the entity integrity is

preserved at the same time. Comparable to AIS,

Neo4J (Neo4J, 2012) is a graph database with a data

model incorporating only a very weak type system.

Besides missing support for taxonomy and

subsumption, semantic attribute types in Neo4J do

not imply any technical value type. Weak technical

typing allows more flexibility at the price of

required type casts. AIS avoids type casting for

better aggregation performance. Freebase (Bollacker

et al., 2008) is a public graph database operated by

Google. Freebase offers an advanced type system

without hard-coded schema but type-specific

metadata defined (at runtime) before data can be

stored. The Freebase concept lacks taxonomy and

subsumption support.

Regarding query and interaction capabilities,

everything from simple APIs to proper query

languages can be found in the zoo of NoSQL

databases. APIs are offered by the majority of the

key-value stores. These APIs are typically very

limited in their expressiveness – comparable to the

internal record access methods of a standard

relational database system.

Query languages usually come with the more

advanced hierarchical and graph-based data models.

DATA2012-InternationalConferenceonDataTechnologiesandApplications

XQuery (XML Query Language, 2007), SPARQL

(SPARQL, 2008), Gremlin (Gremlin, 2012), MQL,

and Cypher (Cypher Query Language, 2012) are the

most important ones to mention here. XQuery is a

powerful language to work with XML. It strictly

builds on the hierarchical nature of XML, which

makes it not a good fit for graph-structured data.

SPARQL is designed to query RDF data sets. A

SPARQL query matches a graph pattern to a labeled

graph. Like RDF, SPARQL has no notion of an

entity as a unit. To query an entity, all properties of

this entity have to be known in advance. Further,

SPARQL lacks means to aggregate values or

objects, which makes it inappropriate for most graph

analytics tasks.

Gremlin is a language for graph querying,

analysis, and manipulation. Since Gremlin heavily

builds on graph traversals it is a powerful language

to operate with graphs. However, Gremlin is a

programming language rather than a query language.

There is no inherent language support for set

operations, aggregation, or consolidation.

MQL is the query language of Freebase. It

strictly follows the query-by-example paradigm.

Thereby, it allows a relatively simple composition of

powerful queries. Nevertheless, by that simplicity it

narrows the granularity of client interaction to single

queries per roundtrip.

Cypher is the query language of Neo4j. With an

SQL-like syntax, Cypher offers filtered traversal

from a given node set and projects out the value of

interest found along the traversal. It supports

ordering an aggregation. Cypher is the graph query

language closest to WIPE. However, it lacks WIPE’s

support for complex retrieval and manipulation

statements.

8 CONCLUSIONS

We presented the challenges faced by existing and

emerging applications that require a schema-flexible

DBMS that: (1) needs to handle data of different

schemas and with different degrees of structure

without upfront expensive data integration, (2) has

to support changes in the data schema during data

query and processing efficiently, but (3) still needs

to incorporate the notion of data schemas and a

proper type system, so that types can be used to

manipulate and retrieve data.

We described AIS as SAP’s answer to the

challenges of these new kinds of business applica-

tions. In this paper we provided a system overview,

and described our data model and data query and

manipulation language. We sketched the system’s

architecture and how its statement processing is

implemented. A description of experimental results,

in particular performance experiments, are planned

for upcoming publications.

Finally, we discussed existing approaches related

to our data model and data query language. We

pointed out that existing data models either are

structurally too weak or lack an adequate type

system. For query languages, we argued that the

discussed approaches are either not expressive

enough or too specialized in data models or

operations to be suitable for our target applications.

We are currently using AIS in Semantic Business

Applications where we represent user and

application context in the form of semantic

networks, our Business Network Services platform,

where we use AIS to efficiently represent and

analyze company relationship networks, and in

Sentiment Analysis applications, where we combine

and analyze internal structured business data with

external irregularly structured social media data.

Ongoing work includes the implementation of

dedicated physical storage structures and graph

specific operations, e.g., graph traversal operators,

directly inside the HANA database engine to further

optimize query performance.

REFERENCES

Amazon S3. 2012. http://aws.amazon.com/de/s3/.

Apache CouchDB. 2012. http://couchdb.apache.org/.

Aulbach, S. et al., 2008. Multi-tenant Databases for

Software as a Service: Schema-mapping Techniques.

In SIGMOD.

Bollacker, K. et al., 2008. Freebase: A Collaboratively

Created Graph Database for Structuring Human

Knowledge. In SIGMOD.

Chang F. et al., 2008. Bigtable: A Distributed Storage

System for Structured Data. In ACM Transactions on

Computer Systems, 26(2).

Cohen, J. et al., 2009. MAD Skills: New Analysis

Practices for Big Data. In VLDB Endowment, 2(2).

Crockford, D., 2006. The Application/JSON Media Type

for JavaScript Object Notation (JSON). RFC 4627,

http://tools.ietf.org/pdf/rfc4627.

Cypher Query Language for Neo4j. 2012. http://docs.-

neo4j.org/chunked/stable/cypher-query-lang.html.

Das Sarma, A., at al., 2008. Bootstrapping pay-as-you-go

data integration systems. In SIGMOD.

Färber, F. et al., 2011. SAP HANA Database – Data

Management for Modern Business Applications.

SIGMOD Record, 40(4).

Franklin, M. J. et al., 2005. From Databases to

Dataspaces: A New Abstraction for Information

FlexibleInformationManagement,ExplorationandAnalysisinSAPHANA

Management. In SIGMOD Record, 34(4).

Gremlin – A Graph-based Programming Language

http://github.com/-tinkerpop/gremlin/wiki.

Gupta, U. et al., 2012. SAP HANA Overview and

Roadmap. SAP Community Network,

http://www.sdn.sap.com/irj/scn/index?rid=/library/uui

d/6015ec1d-7f7d-2e10-06b8-edfa52a4c981.

Lakshman, A., Malik, P., 2009. Cassandra: Structured

Storage System on a P2P Network. In PODC.

Morris, M. R. et al., 2010. Search on Surfaces: Exploring

the Potential of Interactive Tabletops for Collaborative

Search Tasks. In IPM, 46(6)

Neo4J. http://neo4j.org/. 2012.

Perlin, K., et al., 1993. Pad: An Alternative Approach to

the Computer Interface. In SIGGRAPH.

Shen, W. et al., 2008. Toward Best-effort Information

Extraction. In SIGMOD.

An XML Query Language. W3C, January 23rd, 2007.

http://www.w3.org/TR/xquery/ .

Extensible Markup Language (XML). W3C, Nov 26th,

2008. http://www.w3.org/TR/xml/.

RDF/XML Syntax Specification (Revised). W3C, Feb

10th, 2004. http://www.w3.org/TR/REC-rdf-syntax/.

SPARQL Query Language for RDF. W3C, Jan 15th, 2008.

http://www.w3.org/TR/rdf-sparql-query/.

Werner, H. et al., 2011. MOAW: An Agile Visual

Modeling and Exploration Tool for Irregularly

Structured Data. In BTW.

DATA2012-InternationalConferenceonDataTechnologiesandApplications
