CPCPU: COREFUL PROGRAMMING ON THE CPU

Why a CPU can Beneﬁt from Massive Multithreading

G. De Samblanx

1,2

, Floris De Smedt

1,2

, Lars Struyf

, Sander Beckers

, Joost Vennekens

1,2

and Toon Goedem

Campus De Nayer, Lessius, Belgium

Department of Computing Science, K.U.Leuven, Leuven, Belgium

Keywords:

GPGPU, CUDA, OpenCL, Massive Multicore.

Abstract:

In this short paper, we propose a refreshing approach to the duel between GPU and CPU: treat the CPU as if

it were a GPU. We argue that the advantages of a massive parallel solution to a problem are twofold: there

is the advantage of an excessive number of simple computing cores, but there is also the advantage in speed

up by having a large number of threads. By treating the CPU as if it was a GPU, one might end in the best

of two worlds: the combination of high performing cores, with the massive multithreading advantage. This

approach supports the paradigm shift towards massive parallel design of all software, independent of the type

of hardware that it is aimed for.

1 INTRODUCTION

By introducing the concept of a ‘general purpose

GPU’,manufacturers of graphical processors promote

the use of their hardware more as a replacement of a

CPU than as a classical numerical coprocessor. Nev-

ertheless, the CPU is still the core in a system that

sources out the bulk of its work (Beckers, 2011).But

maybe it is time to turn the table. In this text we ex-

plore the advantages of using a CPU in the role of a

‘supporting’ GPU.

Note: the experiments in this article were run on a

Intel i5-2400 Quadcore 3.1Ghz and a NVidia GTX480

graphical card.

2 THE POWER OF GPGPU

In recent years, a large interest arose around the use

of graphical processing units (GPU) for general com-

puting purposes. Advocates of GPU programming

claim that the use of these ‘massive’ number of par-

allel working units will lead to a cheap but vast army

of computational power. NVidia predicts for its Tesla

hardware combined with CUDA software technology,

a speed advantage factor of 100 by the year 2021 –

that is 100×, not 100% speed up (Brookwood, 2010).

ATI observes a more humble factor of 19× with cur-

rent technology (Munshi, 2011). Using OpenCL, the

ViennaCL benchmarks (Rudolf et al., 2011) report a

speed up factor between 3 and 18, depending on the

application, with minimal optimization. So the idea

is: laying your hand on few teraﬂops at the cost of a

netbook, who could refuse?

Even though the old school parallel computing

community has been reluctant to admit it, massive

parallelism is a different paradigm. The classical ap-

proach is to divide an algorithm in a sequential and a

parallel part. Then the parallel part is executed on the

multiprocessor. In contrast, massive parallel comput-

ing often requires a new algorithm design (Beckers,

2011).

But it also suffers from Amdahl’s law. Simply

stated, Amdahl’s law says that the speed (up) of an

algorithm is limited by its sequential fraction S, since

only the parallel fraction P = 1 − S can beneﬁt from

parallelization:

speedup =

S +

#cores

If the number of parallel cores becomes very large, as

is the case in a GPU, the speedup levels off at approx-

imately 1/S. Therefore, it might be a good idea to

use faster cores, instead of more cores, and jump to a

higher performance curve, as is shown in Figure 1.

Notice that if we would replace the ’number of cores’

on the x-axis by a ’number of threads on a limited set

of cores’, then the results even get worse. Additional

196

De Samblanx G., De Smedt F., Struyf L., Beckers S., Vennekens J. and Goedemé T..

CPCPU: COREFUL PROGRAMMING ON THE CPU - Why a CPU can Beneﬁt from Massive Multithreading.

DOI: 10.5220/0003904901960199

In Proceedings of the 2nd International Conference on Pervasive Embedded Computing and Communication Systems (PECCS-2012), pages 196-199

ISBN: 978-989-8565-00-6

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Amdahl’s law: computational speed versus the

number of cores; logarithmic scale with S = 5%.

overhead discourages this approach mst strongly.

3 PEAK PERFORMANCE IS NOT

A CONSTANT NUMBER

The real-life peak performance if a computer core is,

unlike commercial statements, not a constant number.

It depends on the size and the type of the problem that

runs on the hardware. E.g. problems that are too small

do not result in an optimally ﬁlled hardware pipeline,

whereas large problems do not ﬁt in local memory.

A typical ’peak’ performance curve as a function of

the problem size has the staircase-pyramid shape as

shown in Fig. 1. To the left of point A, the curve rises

Figure 2: The evolution of peak performance as a function

of the problem size (log scale).

while the pipline ﬁlls up and overhead decreases. At

the right of point B, the performance drops when the

different caches fail to store the data. In this example,

the region B-C uncovers the Level1 cache, whereas

C-D shows the L2 cache. The curve was drawn by

running repeatedly the very simple BLAS1 routine

snorm2 on one CPU core (Duff et al., 2002). This

is a routine with almost no overhead.

The problem with this curve is that the region A-

B of maximal performance is also the region where

this performance is not really needed: the problem is

too small. In practice, this performance will probably

be hidden behind the overhead of setting up the next,

small problem. For very large data, beyond point D,

on the other hand, the performance is at the level of

really cheap hardware.

Moreover, performance can only be achieved by

optimization. Optimization implies the mapping of an

implemented solution on speciﬁc hardware; in some

cases, it can make the porting of software to different

hardware awkward. In practice, one starts by mak-

ing a sequential design that is easier to debug. Then,

as many parts of the design as possible are imple-

mented in parallel. after which they are optimized and

mapped on the hardware.. If the software is ported

from/to CPU/GPU afterwards, then the optimization

must be redone in a very fundamental way.Sometimes

the whole algorithm must be thought over again.

With this discussion paper, we propose a different ap-

proach: avoid the choice between CPU/GPU, but try

to design the software solution from the start within

a massive parallel paradigm. As we will argue in the

following paragraph, this is not necessarily bad for

the CPU. In fact, the CPU may even beneﬁt from be-

ing treated like a GPU.

4 CPU MASSIVE

MULTITHREADING

Let us review the graph of Amdahl’s law. It is easy to

see that the ‘number of cores/threads’ on the x-asis of

Figure 1 are related directly to the problem size-per-

thread:

size per thread =

total problem size

number of threads

+ overhead.

By ignoring the overhead, we can combine Fig. 1

and Fig. 2. The points A-D appear in reverse order

on the combined graph, since the problem size is re-

lated to the inverse of the number of cores. Becaouse

these points indicate where the performance of one

core jumps to a higher/lower curve, they indicate the

points where an application jumps to a faster/slower

Ahmdal curve, as is shown in Figure 3. The good

news here is that the A-B region of maximal perfor-

mance, is located much more to the right of the curve

(where the problem size is large). So with a ﬁxed

CPCPU: COREFUL PROGRAMMING ON THE CPU - Why a CPU can Benefit from Massive Multithreading

197

Figure 3: Combination of Amdahl’s law with single-core

performance; performance speed versus log(number of

cores).

problem size per thread, the implementation will run

faster for larger problems. On a GPU, the problem

size per thread is not ﬁxed. It depends on the num-

ber of cores versus the overall problem size, which

are both ﬁxed. But on a CPU with e.g. 4 cores, the

number of threads can vary in a continuous fashion to

any number, changing the problem-size-per-thread at

will.

Figure 4 shows the results of this experiment on

our test system. We ran the same problem from Fig-

ure 1 using 1 to 480 threads on a quadcore Intel i5.

Since every core runs at about 3GHz, a maximal per-

formance of 12GFlops can be expected – assuming

1 ﬂop per clock cycle. Obviously, the performance

doubles when going from 1 thread to 2 and quadru-

ples for four threads. But all of those four imple-

mentations level off around the same point at approx-

imately 1GFlops. In other words, for problems larger

that 2 megabytes, the four cores combined perform as

poorly as only one. Now, if we run the same prob-

Figure 4: Running snorm2 with 1 to 480 threads, on 4 cores

for increasing problem size (logarithmic scale).

lem with 48 to 480 threads on the 4 CPU cores, then

the region of maximal performance clearly shifts to

the right. This ‘optimal’ region also tends to be much

broader, remember that the x-axis is labeled logarith-

mically. Very little performance is lost in the extra

overhead of launching the threads.

Of course, this level of optimisation could also be

achieved by classical optimization and by probing the

speed of the internal busses and the size of the caches.

But by massive multithreading, the number of threads

is an optimization parameter that is quite independent

of the hardware. This makes the porting and the reuse

of software easier.

5 CONCLUSIONS

With the advent of massively multicore GPUs came

the new programming paradigm of massively paral-

lel computing. In this paper, we have argued that the

usefulness of this new paradigm need not be limited

to the GPU: there are sound theoretical reasons to ex-

pect that the same programming style may also be

beneﬁcial for programs run on CPUs. In particular,

it may helps to shift the performance curve towards

the end of the spectrum where performance is most

needed, i.e., the large instances. At the negligible cost

of solving the small instance slightly less quickly, the

number of instances that can actually be solved can

be drastically increased, as demonstrated by the pre-

liminary experiment discussed in this paper.

A second advantage is of course that, by using the

same programming paradigm on both CPU and GPU,

the choice between those different types of hardware

can be postponed. A suitably designed algorithm

may be deployed on either one with only minimal

changes. Moreover, if a platform-independent paral-

lel programming language such as OpenCL is used, it

may not even be necessary to change the implemen-

tation either.

It is not necessary to know at design time how

many cores the hardware will have, since the num-

ber of threads (not cores) is a possible optimization

parameter. While executing these threads, CPUs can

address a larger amount of memory than GPUs and

have still more efﬁcient pipelines. On the other hand,

the CPU cores are deﬁnitely much lower in number.

Finally, debugging software on a CPU platform is

much better supported than on a GPU. So if designed

software can be transferred between CPU and GPU as

if they were highly similar, then the debugging prob-

lem of GPUs is somewhat relieved.

PECCS 2012 - International Conference on Pervasive and Embedded Computing and Communication Systems

198

ACKNOWLEDGEMENTS

Parts of this research is funded by the IWT project

”S.O.S. OpenCL - Multicore cooking”.

REFERENCES

Beckers, S. (2011). Parallel sat-solving with opencl. In

Proceedings of the IADIS Applied Computing.

Brookwood, N. (2010). Nvidia Tesla GPU computing, rev-

olutionizing high performance computing.

Duff, I. S., Heroux, M. A., and Pozo, R. (2002). An

overview of the sparse basic linear algebra subpro-

grams: The new standard from the blas technical fo-

rum. ACM Trans. Math. Softw., 28:239–267.

Munshi, A. (2011). OpenCL and heterogeneous computing

reaches a new level. AMD DeveloperCentral.

Rudolf, F., Rupp, K., and Weinbub, J. e. a. (2011). Vien-

naCL User Manual. Institute for Microelectronics,

TU Wien.

CPCPU: COREFUL PROGRAMMING ON THE CPU - Why a CPU can Benefit from Massive Multithreading

199
