Architecture of Plagiarism Detection Service that

Does Not Violate Intellectual Property of the Student

Sergey Butakov

, Craig Barber

, Vadim Diagilev

and Alexey Mikhailov

SolBridge International School of Business, Woosong University, Daejeon, South Korea

Department of Math and Simulation, Altai State Technical University, Barnaul, Russia

Department of Public Safety, Altai State Technical University, Barnaul, Russia

Abstract. Plagiarism detection services (PDS) have become a vital part of

Learning Management Systems (LMS). Commercial or non-commercial PDS

can be easily attached to the most popular LMS these days. In most such sys-

tems, to compare a submitted work with all possible sources on the Internet a

university has to transfer the student submission to the third party. Such an ap-

proach is often criticized by students who may see a violation of copyright law

in this process. This paper outlines an improved approach for PDS development

that should allow universities to avoid such criticism. The major proposed alte-

ration of the mainstream architecture of the improved PDS is a move of docu-

ment preprocessing and search result clarification from the server side to the

client side. Such a split allows users to submit only limited information to the

third party, and to do so in a way that will not make it possible to fully recover

the submitted work but will allow the PDS to maintain the same search quality.

1 Introduction

Digital plagiarism is not a new phenomenon any more. The rapid development of the

Internet along with increasing computer literacy made it easy and tempting for digital

natives to “borrow” someone’s work. Plagiarism is now a burning issue in education,

industry and the research community. For example, in education one paper estimated

the number of students in American high schools involved in different kinds of pla-

giarism to be as high as 90% [12]. Worse, there have been a number of cases of re-

search communities in which people misrepresent other’s work as their own [13].

There are a number of research areas concentrated around plagiarism. In this study we

concentrate on plagiarism detection with particular focus on the technical and legal

sides of it.

One of the problems that arises before anyone searching for the sources of the sus-

pected paper is the degree of effort necessary to perform a “one-to-many” comparison

where the “many” part of the relationship represents all possible sources. This part can

be relatively small if the search has to be performed in the scope of a single learning

Butakov S., Barber C., Diagilev V. and Mikhailov A..

Architecture of Plagiarism Detection Service that Does Not Violate Intellectual Property of the Student .

DOI: 10.5220/0003568701230131

In Proceedings of the 8th International Workshop on Security in Information Systems (WOSIS-2011), pages 123-131

ISBN: 978-989-8425-61-4

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

community. Such a case occurs if for example, someone wants to check a submitted

paper across all the papers submitted in the same college in the last five years. In this

case the scope of search will be on the order of tens of thousands of documents. At the

other extreme, if the same searcher wants to check the paper against all the publicly

available web pages then the searcher must consider billions of documents. Global

comparison can be done either by tools available at the school or it can be outsourced.

Such a search performed at school would require the school to have its own web craw-

ler and therefore to own infrastructure comparable to the ones employed by major

Internet search engines. This option looks prohibitively expensive for most of the

universities worldwide. The second option – outsourcing the search - may lead to

Intellectual Property (IP) protection charges from the students. This paper proposes a

much improved way to build a PDS, an architecture that would allow the school to

avoid such concerns and yet allow the PDS to maintain an acceptable search quality.

The rest of the paper is organized as following. The second section describes the

major options how a general purpose PDS can be built, it also outlines why current

architectures may be considered inappropriate from the IP protection point of view.

Third section discusses a few legal cases against one of the major commercial PDS

available and proposes a way that would allow educators to avoid such cases. The

fourth section provides more technical details on the proposed solution, outlining the

modified client server architecture for PDS.

2 Typical Architecture for Plagiarism Detection Tools

The PDS architecture for local (or in-house) search is very straight forward. The

school maintains a database of all student works and compares each new document

with the existing ones upon submission. IP-protection-wise the school can inform

students that their submissions will remain in digital form in the school database and

will be used solely for PDS. Global search on the other hand assumes that the paper

has to be compared against all possible sources in on the open web. Under the open

web paradigm we assume the publicly accessible web (rather than the “deep” web of

company portals and resources available to subscribers only) is the proper field of

search. As mentioned above, such a search theoretically can be performed on the

school side or outsourced to a company that specializes in plagiarism detection. Prac-

tically the first option looks impossible for the vast majority of educational institutions

around the world. Outsourcing, the second option, can be done in two major ways:

outsourcing the whole process or outsourcing the most difficult parts of it.

The first way is to completely outsource the whole process, asking the external PDS to

provide a detailed report on plagiarism if it was detected in the submitted document.

There are two important points that should be highlighted here:

1. The complete student submission is transmitted to the PDS.

2. The PDS retains a copy of the document to use for the comparison with other

submissions in the future.

Such an approach is used by one of the major players on PDS market - iParadigms

LLC – in its well known Turnitin(tm) service (www.turinitin.com). This approach

124

raises concerns from students that the PDS is making profits using their submissions

and therefore violates their IP rights. The next section of this paper discusses this

issue further.

The second way is to outsource the most difficult part of the detection process – the

global search for the documents that may be similar to the submission. In another

words this part of the process should narrow down the scope of search from tens of

billions to just tens of documents. Such an approach is actively used by language

teachers: when they see a perfectly written sentence from a non-native speaker they

often put it in the quotes and use a search engine to look for exact phrase on the web.

Of course such manual search is slow and not very granular. A similar and very sim-

ple technique which employs Google Alerts has been proposed to monitor inappro-

priate copying from blogs [7]. Crot, one of the free PDS, uses similar brute force ap-

proach for search. It uses a sliding window of X words length, thus sending to the

search engine all the phrases from the document that have been formed by this sliding

window and so performing a very exhaustive search [6].

Two reports indicated that actually exhaustive search is not required to detect plagiar-

ism. As Culwin & Child have indicated, the exact phrase search technique with use of

public search engine can be effective to locate the source [10]. Crot authors also indi-

cated that if a significant part of the paper was plagiarized from the Internet there is no

need to send all possible queries to the search engine: even as low as 10% of these

queries can help to locate the source [6]. This reduction can be very helpful for IP

protection and will be discussed further in section 4.

Let’s take a closer look at outsourcing global search to an external service. The inter-

net search experiment with the Crot software indicated a linear dependence of the

search time on the number of words in a document. The experiment has been per-

formed on a set of 60 documents with length ranging from 350 to 3500 words. It was

done on a dedicated server with a 100Mbs internet channel. Experiment indicated that

the search time was about 5 minutes per 1000 words of the document. This time con-

sists of the following elements: (1) time required for querying the search engine, (2)

time required for downloading the suspected sources; (3) time for detailed comparison

and (4) document hashing time. The latter two can be ignored because the documents

were relatively small (average size of ~1200 words) and there were only a few hun-

dred documents in the local database, which makes the detailed comparison very fast.

Thus we can state that querying the search engine and downloading the suspected

sources consume most of the time required for the search. Further investigation indi-

cated that on average 26% of the search time can be attributed to the first component –

querying the search engine. Therefore a significant reduction of total detection time

can be achieved if either one or both of these steps is performed more quickly: send-

ing queries and downloading documents.

From the IP protection point of view the approach of using an external service only to

narrow down the search scope is better than the outsourcing of the whole PDS

process. The external service is not getting the student submission in the same form as

it was submitted and the original submission can barely be restored by the third party

(search engine) from the search queries.

The solution to the problem of slow search would be to change the mode of submitting

the search queries. Crot and similar systems submit the search queries one by one to

the search engine and receive and process replies after that. They may use a multi-

125

thread approach at this point to improve the speed at this stage but multi-thread im-

poses certain requirements on Internet bandwidth. As the small experiment above

indicated, querying the search engine causes a significant delay in the search time.

Improvement could be made if the download and preliminary comparison could be

outsourced to the search engine, e.g. if there is a service, complimentary to the con-

ventional internet search engine, that would work as a proxy to the search engine faci-

litating the plagiarism detection process. Such a labor division where the on-premises

part of PDS performs only detailed comparison and out-of-premises part does the

global search could help to improve the speed. Such architecture has to be justified

whether it can be subject to IP violation concerns. The next section analyzes a few

cases on IP protection and provides insights on how the information flow could be

organized to avoid collisions with IP protection mechanisms.

3 Legal Issues Related to Plagiarism Detection

There has been considerable controversy about the anti-plagiarism service by iPara-

digms LLC called “Turnitin®”. Turnitin® requires the teacher or student to submit

the student paper to them whole. Turnitin® then creates a “digital fingerprint” of the

paper and archives the paper. This had generated considerable outrage on the part of

students, and interestingly, in certain parts of the academic world [11]. The complaints

have gone as far as legal action including law suits against iParadigms LLC, discussed

in some studies [18, 4]. The threat of lawsuit is a severe disincentive for schools to

using an anti-plagiarism system. The major problem here is that the university sends

the student work to the third party (iParadigms LLC) and this third party stores the

submission, using it to generate profit.

To see how to make PDS architecture viable from the IP protection point of view we

now analyze the legal cases related to Turnitin®.

In legal cases against the Turnitin® service, iParadigms LLC was using fair use doc-

trine to protect its way of doing business. “Fair Use” is defined in the Copyright Act §

107, 17 USC § 107 [19] as follows:

“ ...the fair use of a copyrighted work... for purposes such as criticism, comment,

news reporting, teaching (including multiple copies for classroom use), scholarship,

or research, is not an infringement of copyright.

In determining whether the use made of a work in any particular case is a fair use the

factors to be considered shall include —

(1) the purpose and character of the use, including whether such use is of a commer-

cial nature or is for nonprofit educational purposes;

(2) the nature of the copyrighted work;

(3) the amount and substantiality of the portion used in relation to the copyrighted

work as a whole; and

(4) the effect of the use upon the potential market for or value of the copyrighted

work” [19].

Before examining the four factor test for the proposed architecture, we consider the

small number of cases decided to date in regard to Turnitin ®.

126

The situation of the proposed architecture legally is somewhat dependent upon the

situation of Turnitin®, not just because Turnitin® is being used to establish the legal

standards but also because Turnitin® problems are likely to impact the proposed ar-

chitecture commercially, either for benefit or detriment. The standing of the proposed

architecture in relationship to Turnitin® and similar systems becomes important.

There have been four US Turnitin® cases, and Turnitin® won all four [1, 9, 2, 15].

The important case [1] is one in which the lawyer for the students managed to get the

court to consider the issue of copyright infringement, in contrast to the other cases,

which were determined on secondary grounds. In this case, iParadigms LLC and the

court had to resort to the “Fair Use” doctrine to defend the Turnitin® software. The

cases show the very high level of resistance to Turnitin®, and the persistence of the

opposition. As can be seen from the cases, the court is well aware that Turnitin® is

copying copyright materials without the permission of the copyright owners. However,

other courts, especially courts in countries other than the USA, may not be as helpful

in the future.

The brief analysis provided above shows that the architecture for a PDS will be less

subject to legal actions if it is based on the following principles:

• Do not transfer the student work to third party computers in a form that can be

considered a copy of the work.

• Do not store the copy of the paper on the third party computers for later use.

4 Proposed Plagiarism Detection Service Architecture

Figure 1 shows the main concepts of the proposed architecture for plagiarism detec-

tion service. The service itself is divided into an internal part running on university

computers and an external part running on a third party computer. The internal part

plays a service role when it communicates with the university portal and a client role

when it submits search requests to the external part of the service. Most of the work is

happening on university computers. The only outsourced part performed on third party

software is pre-selection of probable sources of plagiarized paper from the web.

Like in the typical architecture outlined earlier, the process starts with student submis-

sion. The university portal prepares the document for the checkup, wrapping it with

information on course, assignment, type of required checkup, etc. The internal part of

PDS checks the document against the local database and prepares queries for external

part. The distinctive feature of the proposed architecture is the way these queries are

prepared. According to the legal requirements provided in the previous section these

queries should not contain enough information to recover the submission but from an

information retrieval point of view these queries should be enough to find similar

documents on the web. Experiments indicate that even limited numbers of properly

selected search queries can help to locate plagiarism sources on the web [6]. Essential-

ly this means that the part of the PDS located on school infrastructure can prepare

some queries from the key parts of the text, randomly shuffle them and send them as

one large query to the external part of the PDS. Such a submission will not be subject

to attack on IP grounds.

127

The sliding window algorithm that is implemented in Crot uses all possible queries

that can be generated from the text. For example, for the Shakespearean quote «to be,

or not to be: that is the question» with window length X=4 the algorithm will prepare

seven queries: «to be or not», «be or not to», «or not to be», «not to be that», «to be

that is », «be that is the», «that is the question». Obviously that if text has Y words the

total number of queries can be defined as N=Y-X+1. Since we know that Y will be

much larger than X we can say that sliding window algorithm will form almost Y que-

ries. The initial student submission may be easily required from these queries because

two neighboring queries q

and q

+1 have X-1 common words. The total number of

words that will be sent to the search engine will be about Y*X. If we decide to select

only Y

queries and Y

satisfies inequality (1) than there is a guarantee that it will be

impossible to fully recover the initial student submission from the queries that will be

sent to the external part of PDS.

< Y/X (1)

The essential queries that will go out to the third party must be sent in the plain text

form. Any encryption / alternation of these queries will make impossible the use of

web crawlers to narrow down the search scope. Of course inequality (1) does not

guarantee that parts of the document cannot be restored but such partial recovery may

not be considered as significant violation of student IP rights.

Fig. 1. Outline of the proposed architecture for PDS.

There are a number of researches that deal with detection of duplicated material

available on the Internet. They vary from straightforward plagiarism detection in texts

and program source codes [5] to web indexing [8, 14] and writing style detection for

identification of individuals on anonymous web sites [3]. However we have not found

any information on architectures for PDS that would enforce student IP protection

128

while performing the plagiarism detection process. The proposed architecture is fo-

cused on this issue and leaves room for a school to be flexible in IP protection man-

agement. When it is necessary to decide how much of student submission can go to

the external PDS the school may decide on the tradeoff between the probability of

catching small scale plagiarism (one sentence to a few paragraphs) versus sending of

the copyrighted material to the third party. Inequality (1) can provide a boundary for

that decision.

The proposed architecture increases the requirements to available computational pow-

er and storage capacity of university infrastructure. Additional storage is required to

keep digital fingerprints of submitted documents. If such algorithms as Winnowing

[17] or T9 will be used to compile fingerprints then we can expect additional 20-100%

of plain text size increase in terms of required storage. Such an increase can be consi-

dered as insignificant as plain text does not consume much of the space and storage

prices have followed a declining trend for years.

Additional computational power is required for calculation of a single document fin-

gerprint, which is necessary for fast comparison of documents. Since there are many

algorithms available that are linear to the document size such an increase can be also

considered as insignificant. Additional requirements will arise to perform one-to-many

detailed comparison on the internal part of PDS. These requirements impose high load

on DBMS and therefore cost of DBMS licensing and maintenance on the university

side will be the main factor that can affect the price of service in the proposed archi-

tecture. In most of the cases universities already own and maintain DBMS and there-

fore licensing cost increase may not be significant. Hardware investments should be

also considered on the university side in this project. On the other hand there are no

such heavy requirements to the DBMS on the third party infrastructure. This factor

can decrease the cost of third party service and improve the possibility for start-ups to

enter the PDS market, thus promoting competition.

5 Conclusions

In this study we concentrated on an architecture for a plagiarism detection service.

The proposed solution contributes to many aspects of service architecture develop-

ment. First of all this novel architecture makes student copyright protection a main

goal and guarantees that no third party directly or indirectly makes any profit out of

student work. Those small and scrambled portions of the student work that depart

from the school IT infrastructure cannot be even used to fully recover the student

work. A second distinctive feature is the outsourcing of the most time consuming part

of the plagiarism checkup to the third party, thereby reducing the workload on the

university IT infrastructure. Such outsourcing removes the necessity for the PDS in-

stance in each school to have its own private web crawler and allows reliance on a

common search engine for PDS in different schools.

In future research we will work on improvements of the details of the proposed archi-

tecture. One of the possible directions will be to include stylometry on the external

part of the PDS to do preliminary checkups. This improvement could lead to better

scalability of the service allowing the external part of the PDS to download more

129

suspicious sources of plagiarism and filter them before submitting results to the inter-

nal part of the PDS.

Acknowledgements

The authors would like to acknowledge a great help from Ms. Marina Kim and Ms.

Svetlana Kim for conducting the experiment with Crot PDS.In this study we concen-

trated on an architecture for a plagiarism detection service.

References

1. A. V. ex rel. Vanderhye v. iParadigms, LLC, 562 F.3d 630, 2009 Copr.L.Dec. P 29,743, 90

U. S. P.Q.2d 1513 (4th Cir. 2009).

2. A. V. v. iParadigms, LLC, 544 F.Supp.2d 473, 232 Ed. Law Rep. 176 (4th Cir. 2008)

3. Abbasi A. & Chen H. (2008). Writeprints: A stylometric approach to identity-level identifi-

cation and similarity detection in cyberspace. ACM Trans. Inf. Syst. 26, 2, Article 7 (April

2008), 29 pages. DOI=10.1145/1344411.1344413

4. Bennett M. G.. (2009) A Nexus of Law & Technology: Analysis and Postsecondary Impli-

cations of A.V. et al. v. iParadigms, LLC Journal of Student Conduct Administration, 2009,

Vol. 2, no.1. p. 40-45

5. Burrows S., Uitdenbogerd A.L., and Turpin A. (2009). Application of Information Retriev-

al Techniques for Source Code Authorship Attribution. In Proceedings of the 14th Interna-

tional Conference on Database Systems for Advanced Applications (DASFAA '09), Xiao-

fang Zhou, Haruo Yokota, Ke Deng, and Qing Liu (Eds.). Springer-Verlag, Berlin, Heidel-

berg, 699-713. DOI=10.1007/978-3-642-00887-0_61

6. Butakov, S. and Shcherbinin, V. (2009) On the Number of Search Queries Required for

Internet Plagiarism Detection. In Proceedings of the 2009 Ninth IEEE international Confe-

rence on Advanced Learning Technologies - Volume 00 (July 15 - 17, 2009). ICALT. IEEE

Computer Society, Washington, DC, 482-483

7. Carter M. (2008). How to Use Google Alerts to Detect Plagiarism. Retrieved on December

15, 2010 from http://www.suite101.com/content/how-to-use-google-alerts-for-web-writers-

a86525

8. Chowdhury A., Frieder O., Grossman D., and McCabe M. C.. (2002). Collection statistics

for fast duplicate document detection. ACM Trans. Inf. Syst. 20, 2 (April 2002), 171-191.

DOI=10.1145/506309.506311

9. Christen v. Iparadigms, LLC, August 4, 2010, 2010 WL 3063137, Copr.L.Dec. P 29,960,

(E. D. Va. 2010).

10. Culwin F., & Child M. (2010) Optimizing and Automating the Choice of Search Strings

when Investigating Possible Plagiarism. In Proceedings of 4th International Plagiarism

Conference, Newcastle, June 2010. Retrieved on November 20, 2010 from

http://www.plagiarismadvice.org/

11. Horovitz, S. (2008). Two wrongs don't negate a copyright. Florida Law Review, 60, 229.

12. Jensen, L.A., Arnett, J.J., Feldman, S.S. & Cauffman, E. (2002), It’s wrong, but everybody

does it: academic dishonesty among high school students, Contemporary Educational Psy-

chology, 27(2), 209-228

130

13. Kompas (2010) Saving Indonesia from Traps of Plagiarism. Retrieved on November 5,

2010 from http://english.kompas.com/read/2010/04/28/02563687/

Saving.Indonesia.from.Traps.of.Plagiarism

14. Manku G. S., Jain A., and Sarma A. D.. (2007). Detecting near-duplicates for web crawl-

ing. In Proceedings of the 16th international conference on World Wide Web (WWW '07).

ACM, New York, NY, USA, 141-150. DOI=10.1145/1242572.1242592

15. Mawle v. Texas A & M University Kingsville, 2010 WL 1782214 (S.D.Tex. 2010).

16. Scanlon P. M. and Neumann D. R. (2002), Internet Plagiarism Among College Students,

43 J. C. STUDENT DEV. 374, 379 (May–June 2002).

17. Schleimer S., Wilkerson D., and Aiken A. (2003). Winnowing: Local Algorithms for Doc-

ument Fingerprinting. Proceedings of the ACM SIGMOD International Conference on

Management of Data, pages 76-85, June 2003.

18. Sharon, S. (2009) Do Students Turn Over Their Rights When They Turn in Their Papers?

A Case Study of Turnitin.com (June 1, 2009). Available at SSRN:

http://ssrn.com/abstract=1396725

19. The Copyright Act § 107, 17 USC § 107 (1976)

131
