CONDITIONAL RANDOM FIELDS FOR TERM EXTRACTION

Xing Zhang, Yan Song

Dialogue Systems Group, Department of Chinese, Translation and Linguistics, City University of Hong Kong

TatChee Avenue, Kowloon, Hong Kong SAR

Alex Chengyu Fang

Dialogue Systems Group, Department of Chinese, Translation and Linguistics, City University of Hong Kong

TatChee Avenue, Kowloon, Hong Kong SAR

Keywords: Term extraction, Conditional Random Fields, Syntactic function, Term ratio.

Abstract: In this paper, we describe how to construct a machine learning framework that utilizes syntactic information

in extraction of biomedical terms. Conditional random fields (CRF), is used as the basis of this framework.

We make an effort to find the appropriate use for syntactic information, including parent nodes, syntactic

paths and term ratios under the machine learning framework. The experiment results show that syntactic

paths and term ratios can improve precision of term extraction, including old terms and novel terms.

However, the recall rate of novel terms still needs to be increased. This research serves as an example for

constructing machine learning based term extraction systems that utilizes linguistic information.

1 INTRODUCTION

This paper investigates the use of Conditional

Random Fields (CRF) in novel medical term

extraction. A variety of methods have been used in

term extraction, some are linguistics focused, some

are base on statistically motivated, and recent

approaches try to combine these two together.

Recently, with the development of machine learning

models, a lot of work has attempted to extract terms

using machine learning methods.The widely used

standard features for machine learning include

orthographic features, POS tags, prefix, and suffix

information. However, few studies have tried to

make use of dynamic linguistic features in respect of

term usage in real text. As Zhang and Fang (2010)

found out, syntactic functions can be used

effectively in selecting and ranking term candidates,

which means termhood can be captured by

computing term ratios in syntactic paths.

Furthermore, as studies concerning novel terms

are not so common, this paper considers how

syntactic information integrated under a machine

learning framework can be helpful in discovering

novel terms. As early as in 1995, Justeson and Katz

defined novel terminology as terms that are newly

introduced and not yet widely established, or terms

that are current only in more advanced or specialized

literature than that with which the intended audience

can be presumed to be familiar. In MeSH, there will

be annual changes to its descriptors (terms). As

quoted from their website, ‘In biomedicine and

related areas, new concepts are constantly emerging,

old concepts are in a state of flux and terminology

and usage are modified accordingly.’ Therefore,

novel terms may not only refer to those new words

that are newly and specifically created for some

meaning in a certain domain, but also could be some

known word whose meaning is changed from

common to special. In this study, systematic

experiments are performed to explore how syntactic

information can be used as effective features to

extract terms under CRF model.

2 RELATED WORKS

Different machine learning methods have been used

in term identification and term recognition. Zheng et

al. (2009) uses six kinds of features in their CRF

template, including POS, semantic information, left

information entropy, right information entropy,

414

Zhang X., Song Y. and Fang A..

CONDITIONAL RANDOM FIELDS FOR TERM EXTRACTION.

DOI: 10.5220/0003077304140417

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 414-417

ISBN: 978-989-8425-28-7

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

mutual information and TF/IDF. They test their

method on military materials, the precision achieved

was 79.63 %, recall was 73.54%, and F-measure was

76.46%. Takeuchi and Collier (2004) use Support

Vector Machines to study the effects of training set

size, feature sets, boundary identification and

window size on biomedical entity extraction. The

features they choose include surface word forms,

POS tags, orthographic features and head-noun

features.Tsai et al. (2005) also adopt some linguistic

features, orthographical features, context features,

POS features, word shape features, prefix and suffix

features, and dictionary features to CRF framework.

On GENIA 3.02 corpus, their system achieves an F-

score of 78.4% for protein names.

3 CRF MODEL

Conditional Random Field is an effective undirected

graph learning framework first introduced in

(Lafferty, et al., 2001), which has been successfully

applied in many natural language processing tasks

(Song et al, 2009; Zhao et al, 2006). The learning

task for CRF is to maximize the formula

∏

Φ=

),(

);,(

)(

)|(

xyp

(1)

where x denotes the input samples of the training or

testing data, y refers to the corresponding outputs,

and λ is the parameter vector for weighting attached

to the feature function Φ. Z(x) is the normalization

factor over all output values. We use the linear chain

form of CRF, in which x and y are the sequence

texts and output labels respectively. Feature

templates used are shown in Table 1.

Table 1: Feature templates in CRF based term tagging.

Description Template

Word Unigrams W-3, W-2, W-1, W0,

W+1, W+2, W+3

Word Bigrams W-2W-1, W-1W0,

W0W+1, W+1W+2

Word Jump Bigram W-1W+1

POS tag O

Syntactic Functions S

Parent node F

Singe or Compound C

Scale of Term Ratio L

Syntactic Paths P

Our implementation of sequence tagging process for

term extraction uses the CRF++ package by Taku

Kudo (http://chasen.org/˜taku/software/CRF++/).

4 EXPERIMENTS

4.1 Resources Construction

For the purpose of studying behavior of novel terms

in a special period, i.e. the year of 2009, the corpora

used in this study are built up from MEDLINE

abstracts (Medical Literature Analysis and Retrieval

System Online by U.S. National Library of

Medicine) limited to the year of 2009 only. Among

these abstracts, 20,020 abstracts are sampled and

parsed by Survey Parser (Fang, 1996) first. The

Survey parser can produce detail syntactic

information of each constituent. We partitioned this

corpus into 10 subsets, each consisting of 2002

abstracts.

Two lists of medical terms were created from

Medical Subject Headings beforehand as gold

standard. The first term list used in this study is

novel term list in 2009. This novel term list collects

this special group of terms which are included into

MeSH in the year of 2009 and are considered as

novel terms of 2009 in current study. This novel

term list contains 422 terms. The second term list

collects terms from 1954 to 2008 and contains

594,854 terms. This MeSH list was released in 2009,

therefore referred as MeSH 2009.

4.2 Feature Selection

Feature selection is very important in machine

learning systems. In this study, 7 kinds of features

are used, including POS tags, syntactic functions,

parent nodes, single or compound, scale of term

ratio, syntactic paths and term ratios. For the feature

‘Scale of Term Ratio’, it means a scale from 1 to 3

to indicate three categories of term ratio. And term

ratios of syntactic paths are obtained from training

corpus under a separate system (Zhang and Fang,

2010). At first, training corpora will be matched

against the MeSH term list and term occurrence

frequencies in each syntactic path will be calculated,

and proportion of term occurrence frequencies in

this syntactic path over all term occurrence

frequencies is computed as term ratios.

In order to convert term ratios into an index that

can be recognized by CRF, a scale from 1 to 3 is

adopted instead. This index is based on the span

between minimum term ratio and maximum term

CONDITIONAL RANDOM FIELDS FOR TERM EXTRACTION

415

ratio calculated from all the sentences among

training corpora. This span is divided into 3 scales,

numbered as 1 (the weakest level), 2 (the middle

level) and 3 (the strongest level).

4.3 10-folds Cross Validation

The experiment uses 10-folds cross validation to test

system performance. And the evaluation of CRF

framework is based on how well it automatically

determines the term status of a word. CRF

framework will tag 1 to a word in a matrix if it

determines the word to be a MeSH term, and 0

otherwise. Therefore, the precision of it is the ratio

of the number of correctly determined terms to the

number of terms it tags as MeSH terms, and Recall

is the ratio of the number of correctly determined

terms to the number of true MeSH terms in this

testing corpora.

The evaluation will use the standard formula F-

score, which is defined as F = (2PR)/ (P + R), where

P denotes the precision and R denotes the recall.

Results of 10-folds cross validation, with respect to

old terms and novel terms, are shown separately in

following tables.

Table 2: Performance on general terms.

Old terms Precision Recall F-score

1 0.992 0.936 0.963

2 0.993 0.943 0.967

3 0.992 0.939 0.965

4 0.993 0.945 0.968

5 0.993 0.945 0.968

6 0.992 0.936 0.963

7 0.993 0.943 0.967

8 0.992 0.941 0.966

9 0.992 0.941 0.966

10 0.993 0.943 0.967

Average 0.992 0.941 0.966

From Table 2, we can see average precision on

general terms of the ten subsets is 0.992, which is

Table 3: Performance on novel terms.

Novel terms Precision Recall F-score

1 0.902 0.538 0.674

2 0.902 0.500 0.643

3 0.902 0.459 0.609

4 0.900 0.472 0.620

5 0.900 0.724 0.803

6 0.902 0.538 0.674

7 0.900 0.765 0.827

8 0.901 0.767 0.828

9 0.901 0.615 0.731

10 0.900 0.591 0.713

Average 0.901 0.598 0.712

quite good. On average recall is 0.941, which is also

very good. The F-score for them is as good as

0.966. On the whole, this table shows performance

on old terms across these ten subsets is consistently

good as standard deviation of precision is 0.000, and

of recall is 0.003 and of F-score is 0.002.

For 422 novel terms in 2009 (see Table 2), the

performances are not as good as on old terms, but

the highest recall among these 10 subsets still

reaches 0.767 and the highest F-score is 0.828,

which are fairly competitive compared to other

reported results mentioned earlier.

However, we can see precisions across the 10

subsets are around 0.901 on average (Table 3),

which is a satisfying result of applying CRF model

into recognizing novel terms, especially considering

that only syntactic knowledge is used in this

experiment.

In following figure (Figure 1), as far as general

terms are concerned, we can see the line for

precision is rather smooth, and there are some

changes among recalls and F-scores. Still, these

changes are within a small range.

Figure 1: Performance on old terms.

However, in Figure 2 we can find greater

fluctuations in lines of either recall or F-score for

novel terms. This may indicate novel term

recognition is greatly affected by sampling. The

possible reason may be that novel terms are much

sparser than general terms. They are scattered more

broadly across testing corpora.

Figure 2: Performance on novel terms.

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

416

4 CONCLUSIONS

Through above experiments, we find performance

on old term recognition is quite consistent across ten

subsets of testing corpora. While for novel terms, the

performance is influenced by sampling more greatly.

Different sampling will have quite different recalls.

The reason may be novel terms are scattered

sparsely in corpora; and if some novel terms never

appeared in training corpora, there is no chance that

CRF model could learn its features and label it

correspondingly. In such case, it would not be

tagged as true term in testing corpora; therefore, this

term would not be retrieved.

All in all, this research studies the performance

of CRF framework on term extraction with the use

of two kinds of unique syntactic information:

syntactic paths and term ratios. The conclusion can

be drawn that syntactic functions and syntactic paths

can be used as effective features under the CRF

framework. And the system performs quite well with

respect to old term extraction. For novel term

extraction, the precisions are also promising, though

the recalls are quite low compared to old term

extraction. This limitation indicates that more

distinguishing features are needed to improve the

performance, like semantic features of potential

novel terms to help novel term extraction. And also,

this work will be helpful for other machine learning

based term extraction system in respect of exploiting

effective syntactic features.

ACKNOWLEDGEMENTS

Research described in this article was supported in

part by research grants from City University of

Hong Kong (Project No. 7002387, 7008002, and

9610126).

REFERENCES

Justeson, J. S., and Katz, S.M. (1995). Technical

Terminology: some linguistic properties and an

algorithm for identification in text. Natural Language

Engineering 1(1):9--27.

Fang, A. C. (1996). The Survey Parser: Design and

Development. In S. Greenbaum (Ed.), Comparing

English World Wide: The International Corpus of

English (pp. 142-160). Oxford: Oxford University

Press.

Lafferty, J. D., McCallum, A. and Pereira, F. C. N.:

Conditional random fields: Probabilistic models for

segmenting and labeling sequence data. In ICML '01:

Proceedings of the Eighteenth International

Conference on Machine Learning, pp 282-289, San

Francisco, CA, USA, 2001.

National Library of Medicine. Fact sheet: medical subject

headings (MeSH). [Web document]. Bethesda, MD:

National Institutes of Health. 2010. [Last updated: 01

April 2010; cited 9 April 200].

<www.nlm.nih.gov/pubs/factsheets/mesh.html>.

Song Y., Kit, C. Y., Xu, R. F., Zhao, H. How

Unsupervised Learning Affects Character Tagging

based Chinese Word Segmentation: A Quantitative

Investigation, in Proceedings of International

Conference on Machine Learning and Cybernetics,

Jul, 2009.

Takeuchi, K., and Collier, N. (2004). Bio-medical entity

extraction using support vector machines, Artificial

Intelligence in Medicine, Volume 33, Issue 2, Pages

125-137.

Tsai, T. H., Chou, W. C. and Wu, S. H.(2005). Integrating

linguistic knowledge into a conditional random field

framework to identify biomedical named entities.

Expert Systems Appl. v30 i1. 117-128.

Zheng, D, Zhao, T. and Yang, J. (2009). Computer

Processing of Oriental Languages. Language

Technology for the Knowledge-based Economy, 22nd

International Conference, ICCPOL 2009, Hong Kong,

March 26-27. Proceedings 2009.

Zhao H., Huang C. N., and Li M.

An Improved Chinese Word Segmentation System

with Conditional Random Field, Proceedings of the

Fifth SIGHAN Workshop on Chinese Language

Processing (SIGHAN-5), pp.162-165, Sydney,

Australia, July 22-23, 2006.

Zhang, X. and Fang. A. C. (2010). An ATE System based

on Probabilistic Relations between Terms and

Syntactic Functions. In 10th International Conference

on Statistical Analysis of Textual Data. Sapienza,

University of Rome (Italy), 9 to 11 June 2010.

CONDITIONAL RANDOM FIELDS FOR TERM EXTRACTION

417
