FORMAL SPECIFICATION AND VERIFICATION OF THE OMA

LICENSE CHOICE ALGORITHM IN THE OTS/CAFEOBJ

METHOD

Nikolaos Triantafyllou, Iakovos Ouranos

School of Electrical and Computer Engineering, National Technical University of Athens, Athens, Greece

Petros Stefaneas, Panayiotis Frangos

School of Applied Mathematical and Physical Sciences, National Technical University of Athens, Athens, Greece

School of Electrical and Computer Engineering, National Technical University of Athens, Athens, Greece

Keywords: Mobile Digital Rights Systems, OMA-Rights Expression Language, CafeOBJ, Observational Transition

Systems, License choice algorithm.

Abstract: OMA-Digital Rights Management System is a standard proposed by the Open Mobile Alliance (OMA) for

protecting digital content distribution via mobile networks. To solve the decision problem, in the case that

multiple licenses refer to the same content, OMA suggests a license choice algorithm. This algorithm

ensures the fine grained consumption of contents. CafeOBJ is a new generation algebraic specification

language. We apply the OTS/CafeOBJ method to formally model, specify and verify the above mentioned

license choice algorithm. More specifically, we develop the mathematical model of the OMA decision

algorithm as an OTS, a kind of transition system expressed in an equational CafeOBJ specification style.

Finally, we verify that this algorithm fulfills the following safety property: Whenever a license is chosen for

a given content, then the license is valid at that specific time.

1 INTRODUCTION

Digital Rights Management Systems (DRMSs) are

apart from a set of cryptographic methods to forbid

unauthorized usage, a method for expressing

permissions and obligations on a content. A set of

such permissions and obligations is called a license.

Such licenses are written in languages known as

Rights Expression Languages (RELs). The most

commonly used such languages today are ODRL

(Iannella, 2002

), XrML (ContentGuard, 2007) and

MPEG REL (Rightscom, 2007

)

Open Mobile Alliance (OMA) is an organization

created to be the center of mobile service enabler

specification work. OMA REL (OMA-TS-DRM-

REL-V2_0-020060303-A, 2007) is a digital rights

expression language that specifies the syntax and the

semantics of rights governing the usage of DRM

contents in the OMA DRM system (OMA-TS-

DRM-REL-V2_0-020060303-A, 2007). It is based

on ODRL and is defined as a mobile profile of it.

Together with the specification of the language, in

(OMA-TS-DRM-REL-V2_0-020060303-A, 2007),

OMA proposes an algorithm that comes to lift the

burden of the user when he faces the problem of

having more than one license that refers to the same

content. This algorithm takes into consideration the

constraints each license contains, and decides for the

user the “best” suited license to use for a desired

action on the content. Since this algorithm does not

have an official name, we will refer to it for the rest

of the paper as the “Choice Algorithm”.

Digital Right protected contents are a commodity

and as such their success highly depends on their

acceptance by the market. DRM systems need to

protect the interests of both the publisher and the end

user. As a result, licenses intended to work in one

manner but end up working differently cause

discomfort to both of the parties involved. The end

user is dissatisfied because they may end up

purchasing a service that does not respond to the

advertised manner and the producer might end up

173

Triantafyllou N., Ouranos I., Stefaneas P. and Frangos P. (2010).

FORMAL SPECIFICATION AND VERIFICATION OF THE OMA LICENSE CHOICE ALGORITHM IN THE OTS/CAFEOBJ METHOD.

In Proceedings of the International Conference on Wireless Information Networks and Systems, pages 173-180

DOI: 10.5220/0002944501730180

 SciTePress

losing the consumption control of his contents if the

licenses behave unexpectedly.

For these reasons we believe that formal

semantics and specification in order to achieve the

unambiguous licenses and software that control

them, is the key to ensure the success and longevity

of these commercial DRM systems. In this paper we

formally analyze the Choice Algorithm and verify

that it behaves in a correct manner using the

Observational Transition System (OTS) / CafeOBJ

method (Diaconescu, Futatsugi, 1998, CafeOBJ

home page, 2009), thus showing both how such

techniques can be applied to the field of Mobile

DRM and provide at the same time a proof of a

fundamental property for the algorithm

The rest of the paper is organized as follows:

Section 2 gives a brief introduction to the

OTS/CafeOBJ method (Ogata, Futatsugi, 2006,

Ogata, Futatsugi, 2003). In section 3 we describe the

Choice Algorithm and its specification as an OTS in

CafeOBJ while in section 4 we present the invariant

property and the corresponding proof scores.

Finally, section 5 concludes the paper.

2 THE OTS/CAFEOBJ METHOD

2.1 Observational Transition Systems

An Observational Transition System, or OTS

(Ogata, Futatsugi, 2006, Ogata, Futatsugi, 2003), is a

transition system that can be written in terms of

equations. We assume that there exists a universal

states space called



and we also assume that each

data type we need to use in the OTS, including the

equivalence relationship for that data type, has been

declared in advance. An OTS S is the triplet

,,OIT

where:



is a finite set of observers. Each



is a

function

:oD

, where D is a data type

that may differ from observer to observer.

Given an OTS S and two states

,uu





the equivalence (

usu

) between them

wrt. S is defined as

,( ) ( )o Oou ou 



is the set of initial states such that

I 



A set of conditional transitions. Each





is a function





, such that

() ()





for each

uu 

. For each

,()uu





is called the successor state of u wrt

τ. The condition



of τ is called the effective

condition. Also for each

u 

()uu





()Cu





Observers and transitions may be parameterized.

Generally observers and transitions are denoted as

,...,

and

,...,



respectively provided that

,0mn

and there exist data types

 where

jjiik ,...,,,...,



2.2 OTSs in CafeOBJ

An OTS S is written in CafeOBJ. The universal state

space Y is denoted by a hidden sort, say H. An

observer oi1 , ...,im ∈ O is denoted by a CafeOBJ

observation operator. We assume that there exist

visible sorts Vk and V corresponding to the data

types Dk and D, where k = i1, ..., im. The CafeOBJ

observation operator denoting oi1, ...,im is declared

as follows: bop o : Vi1 ... Vim H -> V. Any state in

I, namely any initial state, is denoted by a constant,

say init, which is declared as follows: op init :-> H

The initial value returned by oi1 , ...,im is

denoting by the term o(Xi1 , ..., Xim , init) where Xk

is a CafeOBJ variable whose sort is Vk, where k = i1,

..., im. A transition τj1 , ..., jn ∈ T is denoted by a

CafeOBJ action operator as follows: bop a : Vj1 ...

Vjn H -> H with Vk a visible sort corresponding to

the data type Dk, where k = j1, ..., jn.

Each transition is defined by describing what the

value returned by each observer oi1 , ...,im in the

successor state becomes when τj1 , ..., jn

is applied

in a state u. When c − τj1 , ..., jn (u) holds, this is

expressed generally by a conditional equation that

has the form ceq o(Xi1,...,Xim, a(Xj1,...,Xjn,S)) =

e-a(Xj1,...,Xjn, Xi1,...,Xim, S) if c-a(Xj1,...,Xjn, S) .

S is a CafeOBJ variable whose sort is H and Xk is a

CafeOBJ variable whose sort is Vk, where k = j1, ...,

jn. a(Xj1 , ..., Xjn , S ) denotes the successor state of

S w.r.t. τj1 , ..., jn plus Xj1 , ..., Xjn . e-a(Xj1 , ..., Xjn

, Xi1 , ..., Xim, S ) denotes the value returned by oi1 ,

...,im in the successor state. c-a(Xj1 , ..., Xjn , S )

denotes the effective condition c − τj1 , ..., jn . The

value returned by oi1 , ...,im is not changed if τj1,...,

jn is applied in a state u such that ￢c − τj1, ...,jn (u),

which can be written generally as follows: ceq

o(Xi1,Xim, a(Xj1,Xjn,S)) = o(Xi1,Xim, S) if not c-

a(Xj1,Xjn, S) .

WINSYS 2010 - International Conference on Wireless Information Networks and Systems

174

3 OMA LICENSE CHOICE

ALGORITHM

Because the process of manually choosing which

license to use, when dealing with multiple licenses

referring to the same contents, may cause discomfort

to the user, the following algorithm is proposed by

OMA (OMA-TS-DRM-REL-V2_0-020060303-A,

2007):

1) Only rights that are valid at the given time

should be taken into account from the

algorithm.

2) Rights that are not constrained should always

be preferred over constrained rights.

3) Any right that includes a Datetime constraint,

and possibly others, should be preferred over

rights that are constrained but do not have

such a restriction.

4) If there exist more than one rights with a

Datetime constraint, the one with the further

in the future End element should be preferred.

5) If there exist a choice between many rights

and none of them contains a Datetime

constraint the one containing an Interval

constraint should be preferred if there exists

such.

6) Rights that contain a Count constraint should

be preferred after rights that contain a Timed-

Count constraint.

This algorithm basically states an ordering on the

constraints of the licenses. Based on this ordering,

the decision for the best license to use is made

between licenses that are valid at the given time, and

refer to the desired right.

We will clarify the above algorithm through the

use of an example. We assume that Alice has the

following two licenses installed in her DRM agent:

License 1: You can listen before the tenth of the

month songs A or B one time

License 2: You can listen to songs A or C up to

ten times

Notice that the first license contains a datetime

constraint, which is stated above as the constraint

“before the tenth of the month”. The right to listen to

songs A or B is further constrained using a count

constraint stated by “up to one time”, while the

second license contains only a count constraint

stated as “up to ten times”.

We assume the case where Alice decides to use

these licenses installed in her DRM agent to listen to

song A. The DRM agent is supposed (OMA-TS-

DRM-REL-V2_0-020060303-A, 2007) to include an

implementation of the above License Choice

Algorithm.

When Alice gives the command to listen to song

A, the algorithm will search the licenses installed in

her DRM agent to find a corresponding right that is

valid at that given time based on their constraints,

say “listen song A”, will check the constraints of the

“matching” licenses and based on the ordering

provided by the OMA Choice Algorithm it will

select a license as the best to use the “listen song A”

right, and finally exercises it. In our example this

license will be the first one.

3.1 Basic Data Types

Before introducing the OTS model of the OMA

Choice Algorithm, we define the basic data types we

need to use.

1) Action: Defines the data type of an action

that a user wants to apply to a content, as they

are defined by OMA REL.

2) Content: Is the data type that represents the

unique identification of a specific content.

3) Use: represents an action enforced to some

content. This is defined in our model as

:,use action content



. The only actions

allowed by OMA REL are play, display, print,

execute and export.

4) Cons: Defines the data type of the

constraints defined by OMA REL.

5) Right, RightSET: define a granted right

by a license and a set of such rights

respectively. A right is an expression of the

form U under C, where U is a Use and C a

Cons. RightSET is defined as a super type

(Right is a sub sort of RightSET, in CafeOBJ

terms) of the data type Right. It has added

functionalities such as a “belong” operator (in)

and the union of sets. In addition to those, in

the definition of these data types we define

operators “check”, “belong” and

“?”. The “check” operator takes a Use

and a Right element and checks whether that

Use belongs to that Right. The “belong”

operator works in a similar way but checks if a

Use belongs to a RightSET. Finally the “?”

operator takes a RightSET and returns true or

false if the constraints of it hold or not

respectively.

6) Lic, LicSET: These data types define a

license and a set of licenses respectively. As in

Right and RightSET, Lic is a sub sort of

LicSET. A Lic is constructed by operator, C

about R, where C is a Cons and R is a

RightSET. Lics are defined likewise, to

FORMAL SPECIFICATION AND VERIFICATION OF THE OMA LICENSE CHOICE ALGORITHM IN THE

OTS/CAFEOBJ METHOD

175

capture the fact that in a license written in

OMA REL a constraint can apply to a set of

rights that can be further more constrained and

refer to different contents. LicSET is again

defined as a set of Lic data types with the

usual set functions. Again, we use the

operators “belong”, “belongLS”,

“existLi”, “exist” and “?”. The

“belong” operator determines whether or

not a Use element belongs in a Lic element

and “belongLS”, if a Use element belongs

to a set of licenses. The operator “existLi”

checks whether there exists a suitable right for

a Use element in a license, while “exist“

performs the same check for a set of licenses.

Finally the “?” operator determines if a

license is valid at a given time. As an example

of this specification in CafeOBJ, we present

the corresponding code for Use data type:

Table 1: Definition of the Use data type.

3.2 OTS Model and its Specification

According to the methodology presented in section 3

the hidden state space is denoted by a hidden sort,

*[Sys]*.

The observers we will use are: lics, chosenSet,

bestLic, user and valid. The lics observer is

specified by the behavioral operator bop lics:

Sys -> LicSet and returns the installed

licenses on the agent at any given time. The observer

chosenSet defined in CafeOBJ by the behavioral

operator bop chosenSet: Sys -> LicSet

denotes the set of licenses that refer to the same

content and the same action as the users choice at

the current time. The bestLic observer defines the

most appropriate license to use for a user request

according to the OMA Choice Algorithm. This

observer is defined in CafeOBJ by the following

behavioral operator bop bestLic: Sys ->

Lic. The observer user denotes the current user

request and it is specified in CafeOBJ as bop

user: Sys -> Use. Finally the valid observer

shows whether or not a license is valid at a given

time and is denoted as bop valid: Sys Lic -

> Bool

The actions we used in order to specify the OMA

Choice Algorithm are the following: request, use,

hold, NoHold.

1) The action request is declared through the

action operator bop request: Sys

Action Cont -> Sys and defines the

request by a user to use an action on some

content. The transition can only occur if there

is such a license in the set of currently

installed license of the agent. This is specified

using the effective condition for this transition

eq c-request(S,A,CONT)=

existsLi((A,CONT);lics(S)).

The action use defines the consumption of a

usage right on some content. This is denoted

by the following action operator: bop _

use _ with _: Sys Use Lic ->

Sys. This transition can only occur if the

license is valid at that given time, is the best

license as that is defined by the Choice

Algorithm and finally the usage right about

that content belongs to that license. This is

defined in CafeOBJ again through the

effective condition of the transition rule:

eq c-use(S,A ,CONT),L)

=exist((A,CONT);L) and valid(S ,L)

and (L=bestLic(S)) .

Hold is used to specify the fact that after the

execution of a usage right, that right remains

valid, i.e. its constraints are not depleted. This

is defined by the action operator: bop

hold: Sys Lic -> Sys. Since the

only time a usage right can be exercised is if it

belongs to the best license, defined by the

OMA Choice Algorithm, and for this

transition to occur it must remain valid the

effective condition of this transition rule is

defined as:

eq c-hold(S,L)=(L in lics(S)) and

(L)? and (L= bestLic(S)) .

NoHold is the opposite transition of hold. That

is after the execution of the usage right, it is

no longer valid. This transition is defined in

CafeOBJ as: bop NoHold: Sys Lic ->

Sys. The only difference with the above

effective condition is that for this transition to

mod* USe { pr(ACtion + COntent)

[Use]

op _,_ : Action Cont -> Use {constr}

op none : -> Use

ops play display print execute

export: -> Action

op _ = _ : Use Use -> Bool {comm}

var U : Use

eq (U = U) = true . }

WINSYS 2010 - International Conference on Wireless Information Networks and Systems

176

occur the license must no longer be valid. The

is specified as:

eq c-NoHold(S,L)= (L in

lics(S))andnot(L)? and

(L=bestLic(S)).

As stated in section 3, a state of an OTS is

characterized by the values the observation operators

return. Here we present such an example for our

specification, for the case of the NoHold transition:

Table 2: Definition of the NoHold action in CafeOBJ.

In the above table the numbers at the beginning

of each line are not part of the code. In line 1 the

signature of the effective condition for the transition

rule is declared, as a predicate that takes a system

state and a license. In line 2 the equation defining

the effective condition is declared as: the license

belongs on the set of licenses installed in the agent

in S, its constraints no longer hold in S and it is the

license chosen by the OMA Choice Algorithm in S.

In line 3 we declare that the successor state of the

application of the NoHold transition is S if the

effective condition does not hold.

Lines 4 to 8 denote the values returned by the

observers of the OTS when the NoHold transition is

applied to the arbitrary state S for an arbitrary

license L.

In line 4 we declare that the lics observer

returns the same set of licenses as the one in S where

license L is removed from the set, if the effective

condition of the transition holds. In line 5 the

observer chosenSET observes the empty set, if the

effective condition of the transition holds. In line 6

the observer bestLic observes nil, a dummy

license constant that denotes the fact that no license

exists. In line 7 the user observer, observes again a

dummy use constant to denote that no user choice is

made in that state. Finally in line 8 the valid

observer for the license L returns false, when the

effective condition holds.

4 VERIFICATION OF OMA

CHOICE ALGORITHM

The invariant property that corresponds to the proper

function of the algorithm is the following: Whenever

a license is chosen for a given content, then the

license is valid at that specific time. In order to

prove such a property, several steps need to be taken

(Futatsugi, Goguen, Ogata 2005, Ogata, Futatsugi,

2008).

Express the property in a formal way as a

predicate, say invariant pred(p,x), where p is a free

variable for states and x denotes other free variables

of pred.In a module, usually called INV, pred(p,x) is

expressed in CafeOBJ

op inv : H V -> Bool

eq inv(P, X) = pred(P, X) .

where V the list of visible sorts corresponding to x,

P is a CafeOBJ variable for H, the state space and X

is a list of CafeOBJ variables for V.

In a proof score we show that our predicate holds

at any initial state, say init.

open INV

red inv(init, x) .

red is a command that reduces a given term by

regarding declared equations as left-to-right rewrite

rules.

We write a module, usually ISTEP, where the

predicate to prove in each inductive case is

expressed in CafeOBJ, using two constants p, p’

denoting any state and the successor state after

applying a transition in the state:

op istep : V -> Bool

eq istep(X)=inv(p,X) implies inv(p’,X).

For each case we write the proof score. It usually

looks like the following:

open ISTEP

Declare constants denoting arbitrary

objects.

Declare equations denoting the case.

Declare equations denoting the facts if

necessary.

1.op c-NoHold : Sys Lic -> Bool

2.eq c-NoHold(S,L)=(L in lics(S))

and not(L)? and

L=bestLic(S)).

3.ceq NoHold(S,L) = S

if not c-NoHold(S,L) .

4.ceq lics(NoHold(S ,L))

= (lics(S) del L) if c-NoHold(S,L) .

5.ceq chosenSet(NoHold(S,L)) = empty

if c-NoHold(S,L) .

6.ceq bestLic(NoHold(S,L))=nil

if c-NoHold(S,L) .

7.ceq user(NoHold(S,L))=none

if c-NoHold(S,L) .

8.ceq valid(NoHold(S,L),L)= false

if c-NoHold(S,L) .

FORMAL SPECIFICATION AND VERIFICATION OF THE OMA LICENSE CHOICE ALGORITHM IN THE

OTS/CAFEOBJ METHOD

177

eq p’ = a(p, y) .

red istep(x) .

Where y is a list of constants that are used as the

arguments of CafeOBJ action operator a, which are

declared in this proof score and denote arbitrary

objects for the intended sorts. If istep(x) is reduced

to true, it is shown that the transition preserves

pred(p, x) in this case. Otherwise, we may have to

split the case, may need some invariants that will be

used as lemmas (lemma discovery), or we may show

that the predicate is not invariant to the system.

Following the procedure presented above several

lemmas where required to prove the desired

invariant safety property. Their informal description

is presented in table 3, where property 1 is the main

property. The formal definition of invariant 1 in

terms of CafeOBJ specification is:

op inv1 : Sys Lic -> Bool

eq inv1(S,L) = ((L = bestLic(S)) and

not (L = nil) ) implies valid(S,L) .

Table 3: Properties to verify.

No.

Informal definition of Properties to be proven

Whenever a license is chosen for a given

content, then the license is valid at that specific

time.

If a license L is the chosen license by the OMA

Choice Algorithm for a given set S and that

license exits, i.e. is not nil then L belongs to the

set S.

If the choice made by the OMA choice algorithm

for the set R union S, where R is an arbitrary

license containing one usage right and S is a set

of Licenses, is not R nor is it a choice made

solely on S then the chosen license is nil, i.e. not

valid license is available

If the set of licenses contains only a single

license, say L and the choice made by the OMA

Choice Algorithm is not nil, i.e. there exists a

valid license, then the choice is this license L

If the choice made by OMA Choice Algorithm

when the license set contains two licenses L and

L’ is not nil, and if the choice made is not that

made based on the second license L’ then the

chosen license is L

Some of the properties presented above are

stateless, meaning that they do not depend on the

state of our OTS. We can prove such properties in a

similar manner, the only difference relies on the fact

that the induction does not occur on the states of our

OTS but on the complexity of the data types,e.g. on

the way a set is constructed

In module ISTEP, the following operator

denoting the predicate to prove is declared and

defined:

op istep1 : Lic -> Bool

eq istep1(l)=inv1(s,l)implies

inv1(s’,l)).

Using the follow proof passage we prove that the

predicate holds for any initial state, say init.

open INV

red inv1(init,l) .

This proof passage returns true, so the base case

is proven.

Next we write the proof passage for each of the

transition rules used in the OTS. For the case of the

request, transition rule.

open ISTEP

op s' : -> Sys .

op a : -> Action .

op c : -> Cont .

eq s' = request(s,a,c) .

red istep1(l).

The above case returns neither true nor false. In

this case we need to split the case to help the

CafeOBJ system reduce it. The most natural choice

is to split the effective condition of the transition

rule based on whether it holds or not.

open ISTEP

op s' : -> Sys .

op a : -> Action .

op c : -> Cont .

eq s' = request(s,a,c) .

eq c-request(s,a,c) = false .

red istep1(l).

The above refers to the case that effective

condition of the transition is false, that is not c-

request(s,a,l) and CafeOBJ returns true.

Now that this case is covered we must cover its

symmetrical one, i.e. when c-request (s,a,l)

is true. This is shown in the following proof passage:

WINSYS 2010 - International Conference on Wireless Information Networks and Systems

178

open ISTEP

op s' : -> Sys .

op a : -> Action .

op c : -> Cont .

eq s' = request(s,a,c) .

eq existsLi((a,c);lics(s)) = true .

red istep1(l).

Here we replaced the equation c-

request(s,a,c)= true with the definition of

c-request(s,a,c), that is the equation

existsLi((a,c);lics(s)) = true, to

help CafeOBJ with the reductions.

In this case CafeOBJ returns again nor true nor

false and we need more case splitting based on the

returned formula (interactive computer – human

proof).

open ISTEP

op s' : -> Sys .

op a : -> Action .

op c : -> Cont .

eq s' = request(s,a,c) .

eq existsLi((a,c) ; lics(s)) = true .

eq (l=chooseLic(belongLS((a,c);

lics(s)) ))=false .

red istep1(l).

The above proof passage corresponds to the case

existsLi((a,c);lics(s)) l=

chooseLic( belongLS((a,c);lics(s))).

This proof passage returns true, so we must

continue with the symmetric case once again.

open ISTEP

op s' : -> Sys .

op a : -> Action .

op c : -> Cont .

eq s' = request(s,a,c) .

eq existsLi((a,c) ; lics(s)) = true .

eq l=chooseLic(belongLS((a,c);lics(s)))

red istep1(l).

This case corresponds to existsLi((a,c);

lics(s))

 l=chooseLic(belongLS((a,c);

lics(s)))

and CafeOBJ returns again nor true nor

false. Once again we need to split the case based on

the formula returned by CafeOBJ.

Following this procedure we reach state

existsLi((a,c);lics(s))  l=chooseLic(

belongLS((a,c);lics(s)))



(chooseLic(

belongLS((a,c);lics(s)))=nil)



(chooseLic(belongLS((a,c);lics(s))inlic

s(s)) where CafeOBJ has returned true to all the

symmetrical subcases.

Here CafeOBJ returns nor true nor false again.

Normally we would, and can, apply more case

splitting, but we notice that these predicates cannot

hold simultaneously in our OTS (another example of

the interactive proving procedure). So we can use

these contradicting predicates to conjuncture a

lemma and discard this case. These predicates

constitute lemma 2 we described in table 3 and it is

formally defined as:

eq inv2(LS,L,A,C)=((L=chooseLic

(belongLS ((A,C);LS)))and not(L=nil))

implies(L in LS).

Using this lemma we can discard this case as is

show in the following proof passage:

open ISTEP

op s' : -> Sys .

op a : -> Action .

op c : -> Cont .

eq s' = request(s,a,c) .

eq existsLi((a,c) ; lics(s)) = true .

l=chooseLic(belongLS((a,c);lics(s))).

eq (chooseLic(belongLS((a,c);lics(s)))

= nil) = false .

eq (chooseLic(belongLS((a,c);lics(s)))

in lics(s)) = false .

red inv2(lics(s),l,a,c)implies

istep1(l) .

CafeOBJ returns true for the above proof passage

and hence, once we prove lemma 2, this concludes

the proof for the request transition rule of our safety

property.

Applying the same technique, CafeOBJ returned

true for all transitions. Finally, all the lemmas

presented in table 3 were proven using the same

technique and thus our proof concludes.

5 CONCLUSIONS AND FUTURE

WORK

We have modeled OMA Choice Algorithm as an

Observational Transition System in CafeOBJ, and

verified that the algorithm possesses an important

invariant property using CafeOBJ system as an

interactive theorem prover. We are not the first to

use algebraic specification techniques for modeling

and verification of Digital Rights Management

Systems (Xiang, Bjørner, Futatsugi, 2008). This

FORMAL SPECIFICATION AND VERIFICATION OF THE OMA LICENSE CHOICE ALGORITHM IN THE

OTS/CAFEOBJ METHOD

179

paper is a part of our work in modeling,

specification and verification of algorithms and

protocols used in mobile settings, using algebraic

specification techniques (Ouranos, Stefaneas, 2007).

We have also proposed an abstract syntax for

OMA Rights Expression Language in (Triantafyllou,

Ouranos, Stefaneas, 2009). Some problems for the

OMA Choice Algorithm are presented in (Barth,

Mitchell, 2006). More specifically, let us consider

the example of section 3.In this example if the user

tries to exercise the right “play song A” the OMA

Choice Algorithm will decide that the best license to

use is license A. By doing so, the user is deprived of

the right to listen to song B because license A will

no longer be valid after the execution of the above

right. So, the user ends up losing some of the rights

the initial license set contained without exercising

them. This malfunction could have been avoided if

the OMA Choice Algorithm decided the most

fitting license to use for the right “play song A” was

license B. After the execution of the right the user

would retain the rights to play songs A, B and C.

We intend to redesign the OMA Choice

Algorithm so that problems like the ones presented

in (Barth, Mitchell, 2006) do not occur. The redesign

method will include Falsification techniques (Ogata,

Nakano, Kong, Futatsugi, 2006) for CafeOBJ

together with the OTS/CafeOBJ method.

REFERENCES

Iannella, R., 2002. Open Digital Rights Language (ODRL)

version 1.1. Available at: http://odrl.net/1.1/ODRL-

11.pdf .

ContentGuard, 2007. XrML 2.0 Technical Overview

version 1.0. Available at: http://www.xrml.org/

Reference/ XrMLTechnicalOverviewV1.pdf

Rightscom, 2007. The MPEG-21 Rights Expression

Language - A Whitepaper. Available at:

http://www.xrml.org/reference/MPEG21_REL_

whitepaper _ Rightscom.pdf“.

Diaconescu, R, Futatsugi, K., 1998. CafeOBJ Report.

World Scientific.

Open Mobile Alliance, 2006. OMA-TS-DRM-REL-V2_

0-020060303-A. Available at: http://www.

openmobilealliance.org.

CafeOBJ home page, 2009, http://www.ldl.jaist.ac.jp/

cafeobj/.

Ouranos, I., Stefaneas, P., Frangos, P., 2007. An Algebraic

Framework for Modeling of Mobile Systems, In:

IEICE Trans. Fund., Vol. E90-A, No. 9, pp. 1986-

1999.

Ouranos, I., Stefaneas, P., 2007. Verifying Security

Protocols for Sensor Networks using Algebraic

Specification Techniques. In: Proc. CAI 2007,

Thessalonica, Greece, May 2007, LNCS 4728, pp.

247-259, Springer.

Barth, A., Mitchell, J.C., 2006. Managing Digital Rights

using Linear Logic. In: 21th IEEE Symposium on

Logic in Computer Science (LICS), pp. 127-136.

Futatsugi, K., Goguen, J.A., Ogata, K., 2005. Verifying

Specifications with Proof Scores in CafeOBJ. In: B.

Meyer, J. Woodcock (Eds.), Verified Software:

Theories, Tools, Experiments, First IFIP TC 2/WG 2.3

Conference, VSTTE, LNCS 4171, pp. 277-290.

Futatsugi, K., Ogata, K., 2008.

Simulation-based

Verification for Invariant Properties in the

OTS/CafeOBJ Method. In: Electronic Notes Theor.

Comp. Science 201, pp. 127-154.

Futatsugi, K., Ogata, K., 2006. Some Tips on Writing

Proof Scores in the OTS/CafeOBJ Method. In: K.

Futatsugi, J.-P. Jouannaud, J. Meseguer (Eds.),

Algebra, Meaning, and Computation, Essays

Dedicated to Joseph A. Goguen on the Occasion of

His 65th Birthday, LNCS 4060, pp. 596-615, Springer.

Futatsugi, K., Ogata, K., 2003. Proof Scores in the

OTS/CafeOBJ Method. In: Proc. of the 6th IFIP

WG6.1 Intl. Conf. on Formal Methods for Open

Object-Based Distributed Systems, LNCS 2884,

pp.170--184, Springer .

Diaconescu, R. 2000. Behavioral Coherence in Object -

Oriented Algebraic Specification. J. Universal

Computer Science. 6(1), pp. 74—96

Ogata, K., Nakano, M., Kong, W., and Futatsugi, K.,

2006. Induction-Guided Falsification. Formal

Methods and Software Engineering, LNCS 4260, pp.

114-131, Springer.

Triantafyllou, N., Ouranos, I., Stefaneas, P., 2009.

Algebraic Specifications for OMA REL Licenses. In

Proc: IEEE International Conference on Wireless and

Mobile Computing, Networking and Communications.

wimob, pp.376-381.

Xiang, J., Bjørner, D., Futatsugi, K., 2008 Formal digital

license language with OTS/CafeOBJ, method.

IEEE/ACS International Conference on Computer

Systems and Applications 2008, pp. 652 – 660.

WINSYS 2010 - International Conference on Wireless Information Networks and Systems

180
