A PATENT RETRIEVAL METHOD USING SEMANTIC

ANNOTATIONS

Youngho Kim, Jihee Ryu and Sung-Hyon Myaeng

KAIST, 335 Gwahak-ro Yuseong-gu, Daejeon, South Korea

Keywords: Patent retrieval, Invalidity search, Semantic annotation, Cluster-based retrieval.

Abstract: Automatic annotation of key phrases for their semantic categories can help improving effectiveness of a

variety of text-based systems including information retrieval, summarization, question answering, etc. In

this paper, we exploit semantic annotations for patent retrieval (i.e., patent invalidity search). We first

annotated key phrases for two semantic categories, PROBLEM (e.g. “pattern matching”) and SOLUTION

(e.g. “dynamic programming”) in a patent document, which constitute a particular technology. Semantic

clusters are formed by grouping patent documents with the same PROBLEM or SOLUTION tag. A

language modelling approach to information retrieval is extended to consider the semantically oriented

clusters as well as document models. Our retrieval evaluation of the proposed approach using a collection of

United States patent documents shows a 22% improvement over the baseline, a smoothed language

modelling approach without using the semantic annotations.

1 INTRODUCTION

Patent texts are a rich resource for semantic

knowledge discovery as they contain many

technological concepts and their semantic relations.

Some previous studies attempted to analyze patent

texts to discover meaningful information (Shinmori

et al., 2003; Yoon and Park, 2004; Fujii et al, 2007a;

Kim et al., 2009). The results are often targeted at

developing automatic or semi-automatic analytical

tools that help patent analysis experts identify past

technical progresses and estimate future directions.

On the other hand, patent retrieval, searching

past relevant patents to a target technology, can also

assist examiners (i.e., experts) in patent offices in the

context of invalidity search (Fujii et al, 2007b). The

main purpose of retrieving patent documents is to

validate the genuineness of the technology in a

patent application. This task has newly emerged as a

focus of recent workshops including the NTCIR

workshops (Kando, 2004, 2005, 2007) and the

CIKM workshop on patent information retrieval

(Tait, 2008). Examining the invalidity (i.e., finding

prior patents that contain some conflicting claims)

through search is critical for a newly applied patent

to be granted.

Our research focuses on the intersection of the

two areas: semantic annotation and patent retrieval.

Among a variety of possible types of semantic

annotations, we opted for two key aspects of patent

documents, namely, PROBLEM and SOLUTION

that constitute a technology (Kim & Myaeng, 2009).

We feel that especially for patent invalidity search,

identifying patents with the same PROBLEM and

SOLUTION as those in the query patent would be a

critical task.

Unlike ad hoc retrieval, mostly targeting at news

articles, patent retrieval is unique in that it has to

deal with lengthy and structured documents. A

patent document usually consists of title, abstract,

claim, and description sections. As observed

previously (Iwayama et al., 2003), a patent

document is 24 times longer than a news document

on average, and the variance of the lengths in patent

documents is about 20 times larger than that of new

articles. These characteristics need to be considered

when patent documents are semantically annotated

and processed for retrieval and when various

language models are constructed.

Another unique aspect of patent retrieval is that

every patent has a classification code called IPC

(International Patent Classification) manually

assigned to it. Since the IPC codes are semantic in

nature and organized in taxonomy, they can be

utilized effectively to group similar patents for

retrieval (Kang et al., 2007). For example, all the

211

Kim Y., Ryu J. and Myaeng S. (2009).

A PATENT RETRIEVAL METHOD USING SEMANTIC ANNOTATIONS.

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval, pages 211-218

DOI: 10.5220/0002310302110218

 SciTePress

patents with the IPC code G10L 17 have something

to do with “speech recognition”, the description of

the IPC code. If a query patent belongs to the cluster

of patents sharing the same IPC code, it is highly

probable to find a conflicting patent in the cluster.

The IPC codes make cluster-based retrieval since

they can be the basis for semantic clustering (Kang

et al., 2007).

However, IPC-based clusters may present a

problem when searches are performed within each of

them. Since the documents in a cluster are similar to

each other, they share many terms, making it

difficult to discriminate among each other. Since the

goal of invalidity search is to pinpoint the patent

documents claiming the same technology, retrieving

many grossly similar documents with ordinary index

terms would not be very helpful, especially when the

size of a cluster is large. Since identifying

discriminating features would be difficult but critical

for patent invalidity search, we need semantically

annotated terms that would help making a fine

distinction between the patents claiming the same

technology or method from those that are grossly

similar to each other based on all the index terms.

The main thrust of this paper, therefore, is to link

problem/solution-based semantic annotations,

clustering, and patent retrieval. We describe a patent

retrieval model based on semantic clusters. The

system proposed in this paper consists of two parts:

semantic annotation for the PROBLEM and

SOLUTION categories and cluster-based retrieval

based on extracted semantic key phrases. For the

retrieval part, we attempt to distinguish patent

documents in a cluster for the same PROBLEM or

SOLUTION from those in other clusters, assuming

that documents belonging to the same semantic

cluster are more likely to be similar and hence

conflicting among each other.

The rest of this paper is organized as follows. In

Section 2, we present the related work in patent

retrieval and cluster-based retrieval. In Section 3, we

describe the semantic clustering method based on

the problem and solution annotations and a semantic

patent retrieval model. We illustrate and interpret the

experimental results in Section 4 and finally present

our conclusion in Section 5.

2 RELATED WORK

A cluster-based model for Information Retrieval (IR)

takes advantages of document clusters by assuming

that relevant documents would be grouped within

the same cluster. In general, documents are

automatically grouped by their topical relatedness

and relevant clusters are chosen with respect to a

given query (Croft, 1980; Voorhees, 1985), so that

the query terms in the relevant cluster are heavily

weighted in the retrieval model. In order to verify

the superiority of cluster-based retrieval model, Liu

and Croft (2004) compared with the cluster-less

model in a large test collection, using the language

modeling approach.

Prior to the series of workshops related to patent

retrieval, Larkey (1999) utilized IPC codes to divide

an entire corpus of patents into sub-corpora. The

patents in each sub-corpus compose a large virtual

document, and a query patent was mapped to each

virtual document to select n-best sub-collections. In

this approach, the search techniques in distributed IR

(Callan et al., 1995) were applied in order to reduce

long search time in several sub-collections. The

work is considered an important attempt to use a

unique aspect of patent documents.

Chen et al. (2003a) proposed a patent document

retrieval system concerning semantic and syntactic

properties. They utilized Latent Semantic Index to

recognize synonymous expressions. The system first

finds the patent documents whose vectors lie in the

neighbourhood of the query vector. It then uses the

template matching algorithm developed by Chen &

Tokuda (2003b) to calculate the similarity of the

document and the query. Takaki (2004) proposed an

associative document retrieval method. They

extracted sub-topics from each query and weighted

them by a term frequency-based entropy model.

They applied this method in patent invalid search by

using a query patent claim.

Many previous studies were presented in the

series of the NTCIR workshops (Kando, 2004, 2005,

2007). Among the work related to this paper is the

one by Konishi et al. (2004) that used an IPC code

as a category for each patent and combined TF/ICF

(term frequency and inverse category frequency)

with a general TF/IDF scoring formula. Fujii (2007)

integrated content and citation information to

identify an authoritative page by citation information

(i.e., a patent is cited by a large number of other

patents – foundation patent) like the PageRank

method, which was combined with the Okapi BM25

model. His system performed the best among all the

participants in the task of patent retrieval in NTCIR-

6 (Fujii et al., 2007b).

The work by Kang et al. (2007) seems to be most

relevant to our research. They proposed a cluster-

based retrieval model utilizing IPC classes. Since the

same IPC class would be assigned to somewhat

relevant patents, this approach is quite effective to

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

212

enhance the baseline model (i.e., language model

based approach). Our work is different from this

approach in that we utilize semantic annotation

results in constructing semantic clusters that are

simply borrowed as a vehicle to incorporate such

semantic annotations for patent retrieval.

3 SEMANTIC PATENT

RETRIEVAL

We begin with an explanation about the PROBLEM

and SOLUTION annotation method (Kim et al.,

2009) because it is the basis for making the proposed

retrieval method semantic in nature. The semantic

clustering method should be considered just one way

of incorporating the semantics for patent retrieval.

We first extract key phrases in each document,

which become the candidates for PROBLEM and

SOLUTION annotations and generate semantic

clusters: PROBLEM and SOLUTION clusters

starting from each patent document. Semantically

clustered documents now allow us to measure the

probabilistic relatedness between a patent document

and a query patent.

Assuming that a patent makes claims for a

unique method (solution) to perform a specific task

(problem), it would be useful to identify the

technology described in a patent in terms of problem

and solution as proposed previously (Kim et al.,

2009). For example, when “a dynamic programming

method for speech pattern recognition” is the new

technology in a patent, the problem and solution

parts are “speech recognition” and “dynamic

programming method”, respectively. This type of

semantic annotation of key phrases would make

them more unique and help the task of

discriminating the patents in a cluster.

For the semantic annotation task, we employ the

method proposed recently (Kim et al., 2009), which

combines a probabilistic language modeling

approach and linguistic clues. The features including

linguistic clues are integrated within a statistical

classifier framework (i.e., Support Vector Machine).

As a result of the semantic annotation, all the

problems and solutions of each patent are identified.

Patents sharing the same key-phrases with the same

semantic annotation (PROBLEM or SOLUTION)

can be clustered, and such semantic clusters can be

exploited for patent retrieval. Unlike the patent

retrieval model using a language modelling

approach and citation links (Fujii et al., 2007a), ours

is to use semantic links that connect patents sharing

the same problems and/or solutions. Since the key

phrases are semantically represented with the

annotations, our retrieval method is also considered

semantically based.

In the context of patent invalidity search, in

addition, identifying PROBLEM and SOLUTION

key phrases can facilitate finding the conflicts that

would invalidate the target patent. If we can identify

and group the patents that share the same

PROBLEM as in the query patent, the invalidity

search in the group would be a matter of determining

whether the SOLUTIONS are sufficiently different.

Similarly, if the patents are clustered with the same

solution, the remaining task would be just to ensure

the problems are the same.

3.1 Semantic Annotation

The task of semantic annotation is basically to

identify PROBLEM and SOLUTION key terms in

each patent document. In other words, specific

semantic knowledge for a patent are first discovered

before it is used to index the document. In this work,

a technology is viewed as an association of

PROBLEM and SOLUTION key terms, e.g.,

“recognize signal pattern” (SOLUTION) for “noise

reduction” (PROBLEM). The annotation task is

accomplished in three steps as follows (Kim et al.,

2009).

Step 1. All the key phrases from each patent

document are extracted as candidates for semantic

annotation. A key phrase is recognized as an atomic

noun phrase (i.e., the smallest noun phrase, tagged

as NP) from the result of parsing a sentence in a

patent document by a statistical parser (Klein and

Manning, 2003). A noun phrase is then expanded, if

possible, to a verb phrase by adding a related verb

that has a syntactic dependency with the noun phrase.

The result of this step is a list of candidate phrases

for annotation.

Step 2. PROBLEM phrases are identified based on

language model probabilities and linguistic patterns

that signal the existence of a problem phrase (e.g. in

a pattern consisting of “system for” + [noun phrase],

[noun phrase] is annotated as PROBLEM). The

linguistic patterns are generalized and integrated into

a machine learning framework (i.e. SVM). Since

many cited patents share the same PROBLEM key

phrase (i.e., patents providing a solution to the same

problem), in addition, the language model including

the cited patents is constructed.

Step 3. SOLUTION key phrases are identified from

the rest of the key phrase candidates, mostly based

on linguistic clues. Unlike the PROBLEM

A PATENT RETRIEVAL METHOD USING SEMANTIC ANNOTATIONS

213

annotation step, SOLUTIONS are revealed not only

by pure linguistic patterns but also by PROBLEM

tags added in the previous step because a

SOLUTION key phrase occurs frequently together

with a PROBELM key phrase, often a PROBLEM

followed by a SOLUTION as in “speech recognition

system using speaker language model.” Note that no

language modelling is used for SOLUTIONS as they

do not occur frequently across different patent

documents. The extracted SOLTUTION key phrases

are also integrated into the SVM classifier. Finally,

each patent document is associated with the set of

PROBLEM and SOLUTION key phrases. The

annotation methods were evaluated to obtain 76%

and 75% in accuracy for PROBLEM and

SOLUTION annotations, respectively (Kim et al.,

2009).

3.2 Semantic Retrieval Model

In general, the IR task is defined to be a ranking

method for a set of documents by topical relatedness

to a given query. Among many approaches to this

task, we focus on cluster-based approaches based on

the cluster hypothesis (van Rijsbergen, 1979), which

states that closely associated documents tend to be

relevant to the same requests. In addition, we were

encouraged by a recent result that showed the value

of a cluster-based model for patent retrieval using

IPC (International Patent Classification) code (Kang

et al., 2007). However, the cluster-based method

proposed in this paper is just one way of using

semantic annotations for IR.

While previous research on using clustering for

information retrieval are primarily based on

document similarities or classification results based

on a classification scheme as in (Kang et al., 2007),

we posit that relevant patent documents would share

the same PROBLEM and/or SOLUTION key

phrases. Our approach coincides with the idea of

using citation links, which is motivated by the

tendency that cited documents often contain

solutions to a similar problem. Our work differs

from others in that we explicitly utilize semantic

annotations discovered automatically for problems

and solutions in patent documents.

Our retrieval model is based on the language

modeling approach (Ponte & Croft, 1998) where the

probability of generating the query from a document

language model is estimated to rank documents.

Instead of taking a document alone for language

model construction, however, we make use of a

semantic cluster that includes the document as in the

work by Kang et al. (2007).

term 1 term 2

()(1)() ()

(1 ) ( ) ( )

mle mle

pQD p QD p QS

pqD pqS

ππ

∈

≅− +

⎧

⎫

⎪

≅− +

⎨

⎬

⎪

⎩⎭

∑



  

where mle indicates maximum-likelihood estimation,

q is a query term in query Q, and S is the semantic

cluster constructed for the document D using

PROBLEM and SOLUTION annotations, and

is a

mixing weight.

By assuming that a query is generated from both

of the document and the semantic cluster containing

it, we can divide the query generation probability

into two parts: document model (term 1) and

semantic cluster model (term 2). The mixture of two

models is almost the same as the cluster-based

model proposed by Kang et al. (2007), but the actual

estimation process is different. Instead of using IPC

class based clusters, we assume the semantically

driven clusters should play a key role in generating a

query. This mixture model is estimated as:

(: )

()

(: )

(:)

()

(: )

mle

cnt q D

pqD

cnt t D

cnt q S

pqS

cnt t S

∈

∑

where V

is a vocabulary set of S, V

is a vocabulary

set of D, and cnt(q : S) is the frequency of q in S.

We assume that the language model follows a

unigram word distribution, and the term in our

model would be a unigram word. As such, we count

a unigram frequency for each model, which is

assumed to express the topicality of a document and

a semantic cluster. In addition, we use a weight to

mix the two models. A different mixing weight is

assigned to each query term as some terms are more

related to the cluster than others. The mixing bias

(

) is estimated by:

(:)

(: )

Dfreq q S

Dfreq q C

where Dfreq (q : C) is the number of documents

containing a query term q in the collection C. Its

inverse (IDF) is multiplied by Dfreq (q: S),

document frequency of q in the semantic cluster S,

so that a query term appearing in the semantic

cluster S is considered more important. With the

mixing bias for each query, the retrieval model is

rewritten as:

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

214

() (1)() ()

qmle q

pQD p qD pqS

ππ

∈

≅− +

∑

The next step is to determine which cluster is more

applicable to the retrieval task since many clusters

can be formed. For an extracted PROBLEM key

phrase

pD∈

and a SOLUTION key phrase

∈

clusters can be formed as follows:

{ (), (), () (), () ()}

pspsps

CL CL D CL D CL D CL D CL D CL D∈ ∩∪

where

( ) { , ,...} s.t.

CL D d d p d=∈

( ) { , ,...} s.t.

CL D d d s d=∈

We basically generate a PROBLEM cluster,

(D), and a SOLUTION cluster, CL

(D), and from

these, we further define their intersection and union.

One of the four clusters for a particular key phrase

can be used as the cluster in the language model

defined above.

However, the cluster-based retrieval model

defined above can encounter a data sparseness

problem. As in other unigram language models

(Ponte & Croft, 1998), we use the Jelinek-Mercer

smoothing method (Zhai & Lafferty 2001) as

follows to alleviate the problem:

() (1-) () ()

where is a collection

pqD pqD pqC

λλ

≅+

When we apply the smoothing method to our

model, we have two options: smoothing only the

document model or smoothing both the semantic

cluster and document models, resulting in the

following:

{}

() ()

(1 ) (1 ) ( ) ( )

mle q mle

qmle

pqD pqS

pqD pqC

πλ λ

≅

+− − +

(1)

{

}

{}

() (1) () ()

(1 ) (1 ) ( ) ( )

mle q mle

qmle

pqD pqS pqC

pqD pqC

πα α

πβ β

′

≅− +

+− − +

(2)

In equation (1), only the document language model

is smoothed with an assumption that the cluster

model would be less vulnerable from the word

paucity. In equation (2), we smooth both of the

models without the assumption. Also, the parameters

,,and

βλ

are mixing weights for the smoothing

scheme.

4 EXPERIMENT

For evaluation of the proposed patent retrieval

method using the semantic annotations, we

conducted a set of experiments for patent retrieval

tasks on an English patent corpus from USPTO

(United States Patent and Trademark Office). The

collection includes a set of queries that are the claim

section of a patent document to mimic invalidity

search. For each query, a set of relevant patent

documents were pre-determined. As in the ad hoc

retrieval task, different retrieval models were

evaluated in terms of precision and recall. To build

semantic clusters, we utilized the semantic

annotation system in (Kim et al., 2009) whose

effectiveness was 76% and 75% in accuracy for

PROBLEM and SOLUTION annotations,

respectively.

4.1 Experimental Setup

The evaluation of the proposed semantic patent

retrieval method was done with a test set extended

from the NTCIR-6 patent retrieval test set, which

consists of 981,948 USPTO patent documents

published from 1993 to 2000, covering 3,221 topics

that are basically the granted USPTO patents during

the period from 2000 to 2001. Among these, we

randomly selected 100 topic patents, and each topic

patent contains the sections of title, claim, citation,

date, and other patent components. Among those

components, we used only claim parts as actual

queries, i.e., query terms are only from the claim

parts, and this is the same condition as that of the

NTCIR-6 patent retrieval participants did (Fujii et al.,

2007b).

In the NTCIR collection, there are two different

relevance judgment sets. Type A means that relevant

patent documents must be cited among each other

but their IPC subclasses are not necessarily identical.

Type B means that relevant patent documents are not

only cited among each other but also under the same

IPC subclass. In our experiments, we used Type A

because the answers for Type B were too sparse –

only two or three patent documents are marked as

relevant per query. Further details of the gold

standard for the experiments are specified in (Fujii et

al., 2007b).

4.2 Retrieval Performance

We tested our cluster retrieval model that uses

semantic clusters constructed based on PROBLEM

and SOLUTION annotations. Our baseline was the

A PATENT RETRIEVAL METHOD USING SEMANTIC ANNOTATIONS

215

Jelinek-Mercer language model as used by Kang et

al. (2007). We adopted the model since the general

language model approach (Ponte & Croft, 1998) can

be problematic with data sparseness. In order to

optimize the smoothing parameter λ in the baseline

model, we experimented with varying λ values

increasing from 0.0 to 0.9. As can be seen in Figure

1, the average precision value is peaked when λ is

0.2 although past research showed that the λ bias

over 0.5 would perform the best (Zhai & Lafferty,

2001). We believe this is due to the fact that patent

documents are usually long enough to ameliorate

some of the sparseness problems. This performance

level is quite competitive in comparison with the

results reported in (Fujii, 2007b) where most

precision values are below 10%. Although the

precision values are not directly comparable due to

the fact that our queries are only a subset of the

queries in the collection, it indicates that the system

based on the Jelinek-Mercer language model can be

used as a reasonable baseline, in addition to the

other evidence in (Kang et al., 2007).

Figure 1: Average precision on each lambda bias.

As described in Section 3.2, there are two different

smoothing biases, α and β, which were empirically

set to 0.1 and 0.3, respectively. Since α is the bias

for the semantic cluster that usually has less severe

sparseness, it is set to a lower value. We used λ=0.2

as explained above. Table 1 shows the results in

MAP (Mean Average Precision) for different cluster

types (column) and smoothing methods (rows)

(equations (1) and (2) in Section 3.2) together with

the baseline. The four cluster methods correspond to

those defined in Section 3.2: PROBLEM based

clusters, SOLUTION based clusters, and the union

and intersection of both (CL

(D), CL

(D) ∪

(D), and CL

(D) ∩CL

(D)). Smoothing was

applied to both cases: documents only and a

combination of documents and clusters.

Table 1: MAP for semantic patent retrieval.

Prob Sol Uni Inter

Doc

mle

(q|D)

0.281

(21.7%)

0.239

(3.5%)

0.273

(18.2%)

0.232

(0.4%)

Doc

+ Cluster

P’

mle

(q|D)

0.260

(14.3%)

0.238

(3.0%)

0.257

(11.3%)

0.232

(0.4%)

Baseline 0.231 (0.0%)

The best result was obtained when the clusters

were constructed based on PROBLEM annotations

and smoothing was done for documents only (i.e.,

equation (1)), whereas the improvement made by

SOULTION annotations was almost negligible.

Combining two sets of clusters with a union or an

intersection operation was no better than using the

PROBLEM clusters only.

These results coincide with the discussion in

(Kim et al., 2009). Many PROBLEM keywords are

shared by those patent documents that are linked by

citations. In addition, PROBLEM keywords are

likely to represent the key theme of the patents

containing them. On the other hand, the SOLUTION

clusters are far less useful because patent documents

rarely share the same SOLUTION keywords for the

same PROBLEM. This is due to the fact that in

order for a patent to be granted, the solution must be

different from those already patented.

It was also found that a key term can rarely be

annotated as both PROBLEM and SOLUTION even

across patent documents although it is possible. This

explains why the intersection case is almost the

same as the baseline case. The difference between

the two cases in smoothing seems to be due to the

fact that sparseness in a unigram language model is

less problematic in patent documents as they are

relatively long. In addition, smoothing clusters

seems to do more harm than good because they

contain enough words.

To better understand how semantic annotations

help patent retrieval, we compared the best case

(PROBLEM-based clustering with the document

smoothing) with the baseline for individual queries.

For each query q, a comparison was made by

computing the ratio using MAP as follows:

() ()

( ) 100

()

where is the best system's MAP for

is the baseline's MAP for

best q base q

base q

best q

base q

−

=×

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

216

In Figure 2, the x-axis and y-axis represent

individual queries and percent increase values,

respectively. It can be seen that except for the two

queries below the x-axis and three on the axis, all the

queries show improvements, the majority of which

range between 20% and 45%. In those exceptional

cases with no improvement, most relevant

documents were not included in the clusters partly

because there are only a very small number of

PROBLEM and SOLUTION keywords in the

collection that no clusters were formed. In other

words, as long as semantic clusters were formed

(and in most cases, semantic clusters were indeed

formed), the semantic annotations, especially the

PROBLEM annotations, helped improving retrieval

effectiveness. This is strong evidence that our

semantic retrieval model is effective for the task of

patent retrieval.

Figure 2: Improvements for individual queries when the

PROBLEM clusters were used

5 CONCLUSIONS

In this paper, we proposed a novel patent retrieval

method exploiting two kinds of semantic annotations,

which identifies key terms for PROBLEM and

SOLUTION categories in patent analysis. The

annotation method is borrowed from a recent patent

analysis work. Based on the identified PROBLEM

and SOLUTION annotations, we investigated on the

effectiveness of using such semantic annotations for

patent retrieval. We proposed a new semantic

clustering method based on the PROBLEM and

SOLUTION key phrases whose occurrences make

two documents belong to the same cluster. A cluster-

based retrieval method was adapted to our situation

by adding semantic cluster information to a

conventional language model based retrieval method.

The experimental result shows that the annotation

based semantic retrieval method in fact improves

retrieval effectiveness significantly, making it

possible to conclude that our semantic retrieval

method is desirable for enhancing retrieval

performance in patent retrieval.

For future work, we plan to identify additional

semantic categories that can help patent retrieval.

Once they are identified, the same model can be

used to improve patent retrieval further. As a shorter

term plan, we consider to compare and combine the

semantic clustering with conventional document

clustering based on words. We also plan to devise

and test different ways of incorporating semantic

annotations for retrieval, such as incorporating

semantically annotated phases as index terms and

conducting two-level retrieval, one for PROBEM-

based retrieval and the other for SOLUTION-based

matching, especially for an invalidity search task.

ACKNOWLEDGEMENTS

This work was supported by Microsoft Research

Asia and the IT R&D program of MKE/IITA [2008-

F-047-02, Development of Urban Computing

Middleware].

REFERENCES

Ahmad, K., Al-Thubaity, A. 2003. Can text analysis tell us

something about technology progress? In Proceedings

of the ACL-03 workshop on patent corpus processing,

pages 41-45.

Callan, J., Ku, Z., Croft, B. 1995. Searching distributed

collections with inference networks. In Proceedings of

the 18th annual international ACM SIGIR conference

on research and development in information retrieval

(SIGIR ’95), pages 21-28.

Chen, L., Tokuda, N., Adachi, H. 2003. A patent

document retrieval system addressing both semantic

and syntactic properties. In Proceedings of the ACL-03

workshop on patent corpus processing, pages 1-6.

Chen, L., Tokuda, N. 2003. Robustness of regional

matching scheme over global matching scheme.

Artificial Intelligence, Vol. 144(1-2), pages 213–232.

Croft, B. 1980. A model of cluster searching based on

classification. Information Systems, Vol. 5, pages 189–

195.

Fujii, A., Iwayama, M., Kando, N. 2004. Overview of

patent retrieval task at NTCIR-4. In Proceedings of

NTCIR-4 Workshop Meeting, pages 225-232.

Fujii, A., Iwayama, M., Kando, N. 2007a. Introduction to

the special issue on patent processing. Information

Processing & Management, Vol .43 (5), pages 1149-

1153.

Fujii, A., Iwayama, M., Kando, N. 2007b. Overview of the

A PATENT RETRIEVAL METHOD USING SEMANTIC ANNOTATIONS

217

patent retrieval task at the NTCIR-6 workshop. In

Proceedings of NTCIR-6 Workshop Meeting, pages

359-365.

Fujii, A. 2007. Integrating content and citation information

for the NTCIR-6 patent retrieval task. In Proceedings

of NTCIR-6 Workshop Meeting, pages 377-380.

Iwayama, M., Fujii, A., Kando, N., Marukawa, Y. 2003.

An empirical study on retrieval models for different

document genres: patents and newspaper articles. In

Proceedings of the 26th annual international ACM

SIGIR conference on research and development in

information retrieval (SIGIR ’03), pages 251–258.

Itoh , H., Mano, H., Ogawa, Y. 2003. Term distillation in

patent retrieval. In Proceedings of the ACL-03

workshop on patent corpus processing, pages 41-45.

Kando, N. 2004. Overview of the Forth NTCIR

Workshop. In Proceedings of 4th NTCIR Evaluation

Workshop, pages 1-9.

Kando, N. 2005. Overview of the Fifth NTCIR Workshop.

In Proceedings of 5th NTCIR Evaluation Workshop,

pages 1-9.

Kando, N. 2007. Overview of the Sixth NTCIR

Workshop. In Proceedings of 6th NTCIR Evaluation

Workshop, pages 1-9.

Kang, I-S., Na, S-H., Kim, J. 2007. Cluster-based patent

retrieval. Information Processing & Management, Vol

.43 (5) pages 1173-1182.

Kim, Y., Tian, Y., Jeong, Y., Ryu, J., Myaeng, S-H. 2009.

Automatic discovery of technology trends from patent

text. In Proceedings of the 24th Symposium on Applied

Computing (SAC ’09). pages. 1480-1487.

Klein, D., Manning, C. 2003. Accurate unlexicalized

parsing. In Proceedings of the 41st Annual Meeting of

the Association for Computational Linguistics (ACL

’03) pages 423-430.

Konishi, K., Kitauchi, A., Takaki, T. 2004. Invalidity

patent search system of NTT data. In Proceedings of

NTCIR-4 Workshop Meeting, pages 250-255.

Larkey, L. 1999. A patent search and classification system.

In Proceedings of the 4th ACM Conference on Digital

Libraries, pages 179-187.

Liu, X., Croft, B. 2004. Cluster-based retrieval using

language models. In Proceedings of the 27th annual

international ACM SIGIR conference on research and

development in information retrieval (SIGIR ’04),

pages 186-193.

Ponte, J. M., Croft, W. B. 1998. A language modelling

approach to information retrieval. In Proceedings of

the 21st annual international ACM SIGIR conference

on research and development in information retrieval

(SIGIR ’98) pages 275–281.

Tait, J. 2008. Proceeding of the 1st ACM workshop on

patent information retrieval, Publication dept. ACM,

Inc. Denver, MA, US.

Takaki, T., Fujii, A., Ishikawa, T. 2004. Associative

document retrieval by query subtopic analysis and its

application to invalidity patent search. In

Proceedings

of the 13

ACM international conference on

Information and Knowledge Management (CIKM ’04)

pages 399-406.

Takeuchi, K., Collier, N. 2003. Biomedical entity

extraction using Support Vector Machines. In

Proceedings of the ACL-03 workshop on natural

language processing in biomedicine pages 57-64.

van Rijsbergen, C. J. 1979. Information retrieval. Newton,

MA: Butterworth-Heinemann.

Shinmori, A., Okumura, M., Marukawa, Y., Iwayama, M.

2003. Patent claim processing for readability: structure

analysis and term explanation. In Proceedings of the

ACL-03 workshop on patent corpus processing, pages

56–65.

Voorhees, E. 1985. The cluster hypothesis revisited. In

Proceedings of the 8th annual international ACM

SIGIR conference on research and development in

information retrieval (SIGIR ’85), pages 188–196.

Yoon, B., Park, Y. 2004. A text mining-based patent

network: analytical tool for high-technology trend.

Journal of High Technology Management Research,

Vol. 15 (1), pages 37–50.

Zhai, C., Lafferty, J. 2001. A study of smoothing methods

for language models applied to ad hoc information

retrieval. In Proceedings of the 24th annual

international ACM SIGIR conference on research and

development in information retrieval (SIGIR ’01)

pages 334–342.

KDIR 2009 - International Conference on Knowledge Discovery and Information Retrieval

218
