ON EXTENDING THE PRIMARY-COPY

DATABASE REPLICATION PARADIGM

M. Liroz-Gistau, J. R. Ju´arez-Rodr´ıguez, J. E. Armend´ariz-I˜nigo, J. R. Gonz´alez de Mend´ıvil

Universidad P´ublica de Navarra, 31006 Pamplona, Spain

F. D. Mu˜noz-Esco´ı

Instituto Tecnologico de Inform´atica, Universidad Polit´ecnica de Valencia, 46022 Valencia, Spain

Keywords:

Database Replication, Generalized Snapshot Isolation, Read One Write All, Replication Protocols, Middle-

ware Architecture.

Abstract:

In database replication, primary-copy systems sort out easily the problem of keeping replicate data consistent

by allowing only updates at the primary copy. While this kind of systems are very efﬁcient with workloads

dominated by read-only transactions, the update-everywhere approach is more suitable for heavy update loads.

However, it behaves worse when dealing with workloads dominated by read-only transactions. We propose a

new database replication paradigm, halfway between primary-copy and update-everywhere approaches, which

permits improving system performance by adapting its conﬁguration to the workload, by means of a determin-

istic database replication protocol which ensures that broadcast writesets are always going to be committed.

1 INTRODUCTION

Database replication is considered as a joint venture

between database and distributed systems research

communities. Each one pursues its own goals: per-

formance improvement and affording site failures, re-

spectively. These issues bring up another important

question that is how different replicas are kept con-

sistent, i.e. how these systems deal with updates that

modify the database state. During a user transaction

lifetime it is a must to decide in which replica and

when to perform updates (Gray et al., 1996). We fo-

cus on eager solutions and study the different alterna-

tives that exist according to where to perform updates.

The primary copy approach allows only one

replica to perform the updates (Daudjee and Salem,

2006; Plattner et al., 2008). Changes are propagated

to the secondary replicas, which in turn apply them.

Data consistency is trivially maintained since there is

only one server executing update transactions. Secon-

daries are just allowed to execute read-only transac-

tions. This approach is suitable for workloads dom-

inated by read-only transactions, as it tends to be in

many modern web applications (Daudjee and Salem,

2006; Plattner et al., 2008). However, the primary

replica represents a bottleneck for the system when

dealing with a large amount of update transactions

and, furthermore, it is a single point of failure. The

opposite approach, called update-everywhere (Lin

et al., 2005; Kemme and Alonso, 2000), consists of

allowing any replica to perform updates. Thus, sys-

tem’s availability is improved and failures can be tol-

erated. Performance may also be increased, although

a synchronization mechanism is necessary to keep

data consistent. This may suppose a signiﬁcant over-

load in some conﬁgurations.

Several recent eager update-everywhere ap-

proaches (Kemme and Alonso, 2000; Kemme et al.,

2003; Lin et al., 2005; Wu and Kemme, 2005)

take advantage of the total-order broadcast prim-

itive (Chockler et al., 2001). Certiﬁcation-based

and weak-voting protocols are the ones which ob-

tain better results (Wiesmann and Schiper, 2005).

Certiﬁcation-based algorithms decide the outcome of

a transaction by means of a deterministic certiﬁcation

test, mainly based on on a log of previous commit-

ted transactions (Lin et al., 2005; Wu and Kemme,

2005; Elnikety et al., 2005). On the contrary, on

weak-voting protocols the delegate replicadecides the

outcome of the transactions and informs the rest of

the replicas by sending a message. In an ideal repli-

cation system all message exchange should be per-

formed in one round (as in certiﬁcation-based) and

delivered writesets should be committed without stor-

Liroz-Gistau M., R. Juárez-Rodríguez J., E. Armendáriz-Iñigo J., R. Gonzalez de Mendivil J. and D. Muñoz-Escoí F. (2009).

ON EXTENDING THE PRIMARY-COPY DATABASE REPLICATION PARADIGM.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 99-106

DOI: 10.5220/0002256600990106

 SciTePress

ing a redundant log (as it is done in weak-voting).

In this paper we propose a novel approach that

circumvents the problems of the primary-copy and

update-everywhereapproaches. Initially,a ﬁxed num-

ber of primary replicas is chosen and, depending on

the workload, new primaries may be added by send-

ing a special control message. A deterministic mech-

anism governs who is the primary at a given time.

Thus, at a given time slot, only those writesets coming

from a given replica are allowed to commit: A pri-

mary replica applies the writesets in order (aborting

local conﬂicting transactions if necessary), and when

its turn arrives, local transactions waiting for commit

are committed and their writesets broadcast to the rest

of the replicas. Moreover, replicas conﬁguration can

be modiﬁed dynamically both by changing the role of

existing replicas (turning a primary into a secondary

or vice versa) or by adding new secondaries.

If we assume that the underlying DBMS at each

replica provides Snapshot Isolation (SI) (Berenson

et al., 1995), the proposed protocol will provide

Generalized SI (Elnikety et al., 2005; Gonz´alez de

Mend´ıvil et al., 2007) (GSI). The rest of this paper

is organized as follows: Section 2 depicts the system

model. The replication protocol is introduced in Sec-

tion 3 and fault tolerance is discussed in Section 4.

Experimental evaluation is described in Section 5. Fi-

nally, conclusions end the paper.

2 THE SYSTEM MODEL

We assume a partially synchronous distributed sys-

tem where message propagation time is unknown but

bounded. The system consists of a group of sites

M = (R

, ..., R

M−1

), N primary replicas and M − N

secondaries, which communicate by exchanging mes-

sages. Each site holds an autonomous DBMS provid-

ing SI that stores a physical copy of the replicated

database schema (i.e. we consider a full-replicated

system). An instance of the replication protocol is

running on each replica over the DBMS. It is encap-

sulated at a middleware layer that offers consistent

views and a single system entry point through a stan-

dard interface, such as JDBC. Middleware layer in-

stances of different sites communicate among them

for replica control purposes.

A replica interacts with other replicas by means

of a Group Communication System (Chockler et al.,

2001) (GCS) that provides a FIFO reliable multicast

communication service. This GCS includes also a

membership service with the virtual synchrony prop-

erty (Chockler et al., 2001;Birman and Joseph, 1987),

which monitors the set of participating replicas and

provides them with consistent notiﬁcations in case of

failures, either real or suspected. Sites may only fail

by crashing, i.e. Byzantine failures are excluded. We

assume a primary-partition membership service.

Figure 1: Startup conﬁguration with one primary and main

components of the system.

Clients access to the system through their delegate

replicas to issue transactions. The way the delegate

replica is chosen depends on the transaction type. A

transaction is composed by a set of read and/or write

operations ended either by a commit or an abort op-

eration. A transaction is said to be read-only if it

does not contain write operations and an update one,

otherwise. Read-only transactions are directly exe-

cuted (and committed, without any further coordina-

tion) over primary or secondaryreplicas, while update

ones are forwarded to the primaries where their exe-

cution is coordinated by the replication protocol.

3 REPLICATION PROTOCOL

The main idea of our proposal is to extend the

primary-copyapproach in order to improvethe capac-

ity for processing update transactions and fault toler-

ance. In fact, its basic operation (working with one

primary and several secondaries) follows a classical

primary copy strategy, as shown in Figure 1. The

protocol separates read-only from update transactions

and it executes them on different replicas: updates on

the primary replica and reads on any replica. This

scheduler may be easily implemented in a middle-

ware architecture, as the one presented in (Mu˜noz-

Esco´ı et al., 2006). This middleware provides a stan-

dard transactional interface to clients, such as JDBC,

isolating them from the internal operation of the repli-

cated database. All transactions are executed locally.

At commit time, read-only transactions are commit-

ted straightforwardly, whilst update transactions must

spread their modiﬁcations. Thus, writesets are broad-

cast to the secondaries and they are applied (and com-

mitted) in the same order in which the primary site

committed them, as explained later. This guarantees

that secondary replicas converge to the same snap-

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

100

shot as the primary and therefore reads executed over

secondaries will always use a consistent snapshot in-

stalled previously on the primary.

3.1 Extending Primary-Copy Approach

In this paper, we extend the primary copy approach to

improve its performance (mainly increasing the ca-

pacity of handling a high number of updates) and

its fault tolerance. This new approach allows dif-

ferent replicas to be primaries alternately (and hence

to execute updates) during given periods of time by

means of a deterministic protocol. As pointed out be-

fore, this protocol follows at each replica (primary

or secondary) the most straightforward scheduling

policy: at a given slot, only those writesets coming

from a given primary replica are allowed to commit.

In the primaries, other conﬂicting local transactions

should be aborted to permit those writesets to com-

mit (Mu˜noz-Esco´ı et al., 2006). Secondary replicas

do not raise this problem since they are not allowed

to execute update transactions (read-only transactions

do not conﬂict under SI).

As it can be easily inferred, a primary replica will

never multicast writesets that ﬁnally abort. There-

fore, this protocol makes it possible to share the up-

date transaction load among different primary repli-

cas, while secondary replicas are still able to handle

consistently read-only transactions, usually increas-

ing the system throughput. Moreover, the most im-

portant feature is that a unique scheduling is gener-

ated for all replicas. Hence, considering that the un-

derlying DBMS at each replica provides SI, transac-

tions will see a consistent snapshot of the database,

although it may not be the latest version existing in

the replicated system. Therefore, this protocol will

provide GSI. The atomicity and the same order of ap-

plying transactions in the system have been proved

in (Gonz´alez de Mend´ıvil et al., 2007) to be sufﬁcient

conditions for providing GSI.

3.2 Protocol Description

In the following, we explain the operation of the de-

terministic protocol executed by the middleware at a

primary replica R

(Figure 2), considering a fault-free

environment. Note that secondary replicas may exe-

cute the same protocol, considering that some steps

will be never executed or may be removed.

All operations of a transaction T are submitted to

the middleware of its delegate replica (explicit abort

operations from clients are ignored for simplicity).

Note that, at a primary copy, a transaction may sub-

mit read or update operations, whilst at a secondary

just read-only operations. At each replica, the middle-

ware keeps an array (towork) that determines the same

scheduling of update transactions in the system by a

round-robin scheduling policybased on the identiﬁers

of the primary replicas.

In general, towork establishes at each replica which

writesets have to be applied and in which order, en-

suring that writesets are committed in the same order

at all the replicas. Among primary replicas, towork

is also in charge of deciding which primary is al-

lowed to send a message with locally performed up-

dates. Each element of the array represents a slot that

stores the actions delivered from a primary replica.

These actions are processed cyclically according to

the turn, which deﬁnes the order in which the actions

have to be performed. There exists a mapping func-

tion (map turn()) that deﬁnes which turn is assigned to

which primary replica.

The middleware of a primary replica forwards all

the operations but the commit operation to the lo-

cal database replica (step I of Figure 2). Each pri-

mary replica maintains a list (wslist) which stores local

transactions (T.replica = R

) that have requested their

commit. Thus, when a transaction requests its com-

mit, the writeset (T.WS) is retrieved from the local

database replica (Plattner et al., 2008). If it is empty

the transaction will be committed straight away, oth-

erwise the transaction (together with its writeset) will

be stored in wslist. Secondary replicas work just with

read-only transactions. Thus, there is no need to use

the wslist, since transactions do not modify anything

and hence they will always commit directly in the lo-

cal database without delaying.

In order to commit transactions that have re-

quested it, their corresponding delegate primary

replica has to multicast their writesets in a tocommit

message, to spread their changes, and wait for the re-

ception of this message to ﬁnally commit the trans-

actions (this is just for fault-tolerance issues). Since

our protocol follows a round-robin scheduling among

primary replicas, each primary has to wait for its turn

(turn=map turn(R

) in step III) so as to multicast all

the writesets contained in wslist using a simple reli-

able broadcast service. Note that secondary replicas

are not represented in the towork queue and therefore

they will never have any turn assigned to them and

hence they will never broadcast any message. Secon-

daries simply execute read-only transactions and ap-

ply writesets from primaries.

When the turn of a primary replica arrives and

there are no transactions stored in wslist, the replica

will simply advance the turn to the next primary

replica, sending a next message to all the replicas.

This message allows also secondary replicas to know

ON EXTENDING THE PRIMARY-COPY DATABASE REPLICATION PARADIGM

101

Initialization:

1. ws run := false

2. wslist :=

3. nprimaries := N

4. towork[i] :=

0 with i ∈ 0..N-1

5. turn := 0

I. Upon operation request for T from local client

1. if

SELECT

then

a. execute operation at R

and return to client

2. else if

UPDATE

INSERT

DELETE

then

a. if ws run = true then wait until ws run = false

b. execute operation at R

and return to client

3. else if

COMMIT

then

a. T.WS := getWriteset(T) from local R

b. if T.WS =

0 then commit T and return to client

c. else

- T.replica := R

- T.pre commit := true

- wslist := wslist · hTi

II. Upon receiving message msg from R

1. Store msg in towork[R

]

III. Upon replica’s turn /* turn = R

1. if wslist =

0 then R multicast(hnext, R

2. else R multicast(htocommit, R

, wslisti)

IV. Upon hnext, R

i in towork[turn]

1. Remove hnext, R

i from towork[turn]

2. turn := (turn+1) mod nprimaries

V. Upon htocommit, R

, seq txnsi in towork[turn]

1. while seq txns 6=

0 do

a. T

′

:= ﬁrst in seq txns

b. if T

′

.replica = R

then /* T

′

is local */

- commit T

′

and return to client

c. else /* T

′

is remote */

- ws run := true

- apply T

′

.WS to local R

/* T

′

may be reattempted */

- commit T

′

2. Remove htocommit, R

0i from towork[turn]

3. turn := (turn+1) mod nprimaries

4. ws run := false

VI. Upon block detected between T

and T

/* T

.replica 6= R

/* T

.replica = R

, i.e. local */

1. abort T

and return to client

2. if T

.pre commit = true then remove hT

i from wslist

Figure 2: Determ-Rep algorithm at a primary replica R

that there is nothing to wait for from that replica.

Upon delivery of any of these messages (next and

tocommit) at each replica, they are stored in their

corresponding positions in the towork array (step II),

according to the primary replica which the message

came from and the mapping function (map turn(R

)).

It is important to note that, although these messages

were sent since replica’s turn was reached at their cor-

responding primary replicas, replicas run at different

speeds and there can be replicas still handling pre-

vious positions of their own towork. At each replica,

messages from a same replica will be delivered in the

same order, since we considerFIFO channelsbetween

the replicas. However, messages from different repli-

cas may be delivered disordered (as we do not use

total order), but this is not a problem since they are

processed one after another as their turn arrives. Dis-

ordered messages are stored in their corresponding

positions in the array and their processing will wait

for the delivery and processing of the previous ones.

This ensures that all the replicas process messages in

the same order and as a resultall transactions are com-

mitted in the same order in all of them.

The towork array is processed in a cyclical way. At

each turn, the protocol checks the corresponding po-

sition of the array (towork[turn]). If a next message is

stored, the protocol will simply remove it from the ar-

ray and change the turn to the following one (step IV)

so as to allow the next position to be processed. If it is

a tocommit message, we can distinguish between two

cases (step V). When the sender of the message is the

replica itself (a primary replica), transactions grouped

in its writeset (seq txns) are local (already exist in

the local DBMS) and therefore the transactions will

be straightforwardly committed. In the other case, a

remote transaction has to be used to apply and com-

mit the sequence of transactions seq txns at the remote

replicas (other primaries and secondaries). In both

cases, once committed the transaction, the protocol

changes the turn to the following one to continue the

process.

At primary replicas, special attention must be paid

to local transactions, since they may conﬂict with the

remote writeset application, avoiding it to progress.

To partially avoid this problem, we stop the execu-

tion of write operations in the system (see step I.2.a

in Figure 2) when a remote writeset is applied at a

replica, i.e. turning the ws run variable to true. How-

ever, this is not enough to ensure the writeset appli-

cation in the replica; the writeset can be involved in

a conﬂict with local transactions that already updated

some data items that intersect with the writeset.

Progress is ensured by a block detection mecha-

nism, presented in (Mu˜noz-Esco´ı et al., 2006), which

aborts all local conﬂicting transactions (VI) allowing

the writesets to be successfully applied. Besides, this

mechanism prevents local transactions that have re-

quested their commit (T.precommit = true) from being

aborted by other local conﬂicting transactions, en-

suring their completion. Note also that the writeset

application may be involved in a deadlock situation

that may result in its abortion and hence it must be

re-attempted until its successful completion. Secon-

daries do not require this mechanism since they only

execute read-only transactions that never conﬂict with

the remote writesets.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

102

Figure 3: The process of adding a new primary to the replicated system.

3.3 Dynamic Load-Aware Replication

Protocol

Initial system conﬁguration sets the number of pri-

mary and secondary replicas which compose the

replicated system. However, this is not a ﬁxed con-

ﬁguration. Our protocol may easily adapt itself dy-

namically to different transaction workloads by turn-

ing primaries into secondaries and vice versa. This

makes it possible to handle different situations ensur-

ing the most appropriate conﬁguration for each mo-

ment.

VII. Upon hnew primary, R

i in towork[turn]

1. Remove message from towork[turn]

2. nprimaries := nprimaries + 1

3. Increase towork capacity in 1

VIII. Upon hremove primary, R

i in towork[turn]

1. Remove message from towork[turn]

2. nprimaries := nprimaries - 1

3. Reduce towork capacity in 1

Figure 4: Modiﬁcations to Determ-Rep algorithm to add or

remove new primaries to the system.

Note that a great number of primary replicas in-

creases the overhead of the protocol, since delay be-

tween turns is increased and there are more update

transactions from other primary replicas that need to

be locally applied. Therefore, it is clear that this leads

to higher response times of transactions. However,

this improves the system capacity to handle work-

loads predominated by update transactions. On the

other hand, increasing the number of secondary repli-

cas does not involve a major problem, since data con-

sistency is trivially maintained in these replicas as

they are only allowed to execute read-only transac-

tions. Thus, this improves the system capacity to

handle this type of transactions, although it does not

enhance the possibility of handling update ones or

putting up with failures of a single primary. There-

fore, the system performance is a trade-off between

the number of primaries and the number of secon-

daries, depending on the workload characteristics.

In this way, our protocol is able to adapt itself to

the particular behavior of the workload processed in

the replicated system. Considering a set of replicas

where one is primary and the others are secondaries,

we can turn a secondary easily into a new primary in

order to handle better a workload where update trans-

actions become predominant (see Figure 3). For this,

it is only necessary that a primary replica broadcasts

a message, pointing which secondary replica should

start behaving as a primary (new primary). A sepa-

rate dynamic load-aware protocol should be in charge

of doing this, according to the workload processed by

the system. Its study and implementation is not an

aim of this paper and this protocol simply provides

the required mechanisms. When delivering this mes-

sage, each replica will update the number of primaries

working in the system (nprimaries). They will also add

a new entry in the working queue (towork) to store

messages coming from that replica so as to process

them as stated. With these two minor changes, both

primary and secondary replicas will be able to han-

ON EXTENDING THE PRIMARY-COPY DATABASE REPLICATION PARADIGM

103

dle the incorporation of the secondary as a primary

replica. In the same way, when the workload becomes

dominated by read-only transactions, we can turn a

primary replica into a secondary one through a similar

process that updates the number of primaries and re-

moves the corresponding entry in the working queue

at each replica of the system.

4 FAULT TOLERANCE

In the system treated so far, replicas may fail, re-

join or new replicas may come to satisfy some per-

formance needs. The proposed approach deals also

with these issues. We suppose that the failure and re-

covery of a replica follows the crash-recovery with

partial amnesia failure model (Cristian, 1991). Fail-

ures and reconnections of replicas are handled by the

GCS by means of a membership service providing

virtual synchrony under the primary-component as-

sumption (Chockler et al., 2001) . In order to avoid in-

consistencies the multicast protocol must ensure uni-

form delivery (Chockler et al., 2001) and prevent con-

tamination (D´efago et al., 2004).

The failure of a replica R

involves ﬁring a view

change event. Hence, all the nodeswill install the new

view with the excluded replica. The most straightfor-

ward solution for a primary failure is to silently dis-

card the position of towork associated to the primaryR

at each alive replica R

. Failures of secondary repli-

cas need no processing at all.The no contamination

property (D´efago et al., 2004) prevents that correct

replicas receive messages from faulty primaries.

After a replica has crashed, it may eventually re-

join the system, ﬁring a view change event. This re-

covering replica has ﬁrst to apply the possible write-

sets missed on the view it crashed and then the write-

sets while it was down. Thanks to the strong virtual

synchrony, there is at least one replica that completely

contains all the system state. Hence, there is a process

for choosing a recoverer replica among all living pri-

mary nodes; this is an orthogonal process and we will

not discuss it here. Let us assume that there exists a

recoverer replica. Initially, a recovering node will join

the system as a secondary replica; later depending on

the system load it may become a primary. Upon ﬁring

the view change event, we need to rebuild the towork

queue including the primary replicas available in the

system. The recovering node will discard, in turn,

messages coming from working primary replicas un-

til it ﬁnishes its recovery. The recoverer will wait for

its turn to send the missed information to the recover-

ing replica, in order to include other writesets coming

from other replicas which the recovering will discard.

Concurrently to this, the recovering replica will

store all writesets delivered from primary replicas

in an additional queue called pending WS where they

may be compacted (Pla-Civera et al., 2007). It is not

necessary that another replica stores the committed

writesets and discards the ones that have to abort (e.g.

after a certiﬁcation process), since in our proposal de-

livered writesets are always supposed to have to com-

mit. Once all missed updates transferred by the recov-

erer have been applied at the recovering, it will ﬁnally

apply the compacted writesets stored in pending WS

and, thus, ﬁnish the recovery. From then on, recover-

ing replica will process the towork queue as usual. As

it may be seen, we have followed a two phase recov-

ery process very similar to the one described in (Ar-

mend´ariz-I˜nigo et al., 2007).

5 EXPERIMENTAL RESULTS

To verify the validity of our approach we per-

formed some preliminary tests. We have implemented

the proposed protocol on a middleware architecture

called MADIS (Mu˜noz-Esco´ı et al., 2006), taking ad-

vantage of its capabilities provided for database repli-

cation. For the experiments, we used a cluster of

4 workstations (openSUSE 10.2 with 2.6.18 kernel,

Pentium4 3.4GHz, 2Gb main memory, 250Gb SATA

disk) connected by a full duplex Fast Ethernet net-

work. JGroups 2.1 is in charge of the group com-

munication. PostgreSQL 8.1 was used as the under-

lying DBMS, which ensured SI level. The database

consists of 10 tables each containing 10000 tuples.

Each table contains the same schema: two integers,

one being the primary key. Update transactions mod-

ify 5 consecutive tuples, randomly chosen from a ta-

ble of the database. Read-only transactions retrieve

the values from 1000 consecutive tuples, randomly

chosen from a table of the database too. The Post-

greSQL databases were conﬁgured to enforce the syn-

chronization of write operations (enabling the fsync

function). We used a load generator to simulate dif-

ferent types of workloads depending on the ratio of

update transactions (10%, 50%, 90%). We simulated

12 clients submitting 500 transactions each one with

no delay between them. The load generator estab-

lished with each working replica the same number of

connectionsthan simulated clients. Transactionswere

generated and submitted through connectionsto repli-

cas according to their role: update transactions to pri-

mary ones and read-only transactions to both primary

and secondary ones. Note that, as these are prelimi-

nary tests, we have not paid much attention to the way

transactions were distributed among the replicas and

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

104

(a) Primary-copy approach of the system. (b) Update-everywhere operation. (c) Balancing the system conﬁguration.

Figure 5: Throughput for different analyzed workloads and conﬁgurations.

therefore results are not the best ones.

Experimental results are summarized in Figure 5.

In the ﬁrst two tests, we have tested the perfor-

mance of our proposal working as a primary-copyand

an update-everywhere approach respectively. Thus,

starting from a primary replica (needed in both cases),

we have increased the number of replicas depend-

ing on the evaluated approach: primaries for the

update-everywhere operation and secondaries for the

primary-copy one. As shown in Figure 5a, increasing

the number of secondaries permits the system han-

dling better read-only predominant loads (10% up-

dates). However, in this primary-copy approach, it

is impossible to enhance its performance when work-

ing with loads with a great number of updates (50%

or 90% updates). In these cases, increasing the num-

ber of secondariesmeansno improvement, since addi-

tional secondaries do not increase the system capacity

to process update transactions. In fact, all the update

transactions are executed in the primary replica, and

this overloads the replica.

On the other hand, the update-everywhere opera-

tion provides better results (see Figure 5b) than the

primary-copy approach with loads including many

update transactions (50% and 90% updates). In these

cases, increasing the number of primaries allows to

handle a greater number of update transactions and

therefore the performance is improved. However, all

the replicas are able to execute update transactions

that may overload them and this may lead to higher

response times when executing read-only transactions

in these replicas. Besides, the coordination of the pri-

mary replicas involves also a greater overhead in their

protocols than in a secondary protocol. For these rea-

sons, the performance of the update-everywhere ap-

proach is poorer than the primary-copy one when the

system works with a great number of read-only trans-

actions.

We have seen that each approach behaves better

under different loads. Hence, it is interesting to test

how an intermediate approach (mixing several pri-

maries and secondaries) performs. We have tested

the behavior of mixed compositions, considering a

ﬁxed number of replicas. As shown in Figure 5c,

mixed conﬁgurations with 4 replicas provide in gen-

eral near the same and usually better results for each

load considered in our tests. In particular, for a 10%-

update load the best behavior (192TPS) is not pro-

vided by a pure primary-copy approach but by 2 pri-

maries and 2 secondaries. This happens because us-

ing a single primary that concentrates all update trans-

actions penalizes a bit the read-only transactions in

such single primary replica, but with two primaries

none of them gets enough update transactions for de-

laying read-only transaction service. Once again, for

a 50%-update load the best throughput (76TPS) is

given by 3 primaries and 1 secondary, outperforming

a primary-copy conﬁguration (51TPS) and an update-

everywhere one (69TPS). This proves that intermedi-

ate conﬁgurations are able to improve the throughput

achievable.

ON EXTENDING THE PRIMARY-COPY DATABASE REPLICATION PARADIGM

105

6 CONCLUSIONS

This paper has presented a new database replication

approach, halfway between primary-copyand update-

everywhere paradigms. The result is an improved

performance, which is obtained since the protocol

can change its conﬁguration depending on the load.

Moreover, it also allowsto increase the fault-tolerance

of primary-copy protocols. This is feasible thanks to

the use of a deterministic database replication proto-

col that takes the best qualities from both certiﬁcation

and weak-voting approaches. This protocol estab-

lishes a unique schedule in all replicas based on pri-

maries identiﬁers, which ensures that broadcast write-

sets are always going to be committed.

We have also discussed how this protocol can

adapt itself dynamically to different environments (by

turning secondaries into primaries to handle heavy-

update workloads or primaries into secondaries when

read-only transactions become predominant). Finally,

we have performed some preliminary experiments to

prove the feasibility of this approach, showing how

system can provide better performance adapting its

conﬁguration to the load characteristics, although we

have still to make a great effort to achieve more sig-

niﬁcant results.

ACKNOWLEDGEMENTS

This work has been supported by the Spanish Govern-

ment under research grant TIC2006-14738-C02-02.

REFERENCES

Armend´ariz-I˜nigo, J. E., Mu˜noz-Esco´ı, F. D., Ju´arez-

Rodr´ıguez, J. R., de Mend´ıvil, J. R. G., and Kemme,

B. (2007). A recovery protocol for middleware repli-

cated databases providing GSI. In ARES,pages 85–92.

IEEE-CS.

Berenson, H., Bernstein, P. A., Gray, J., Melton, J., O’Neil,

E. J., and O’Neil, P. E. (1995). A critique of ANSI

SQL isolation levels. In SIGMOD, pages 1–10. ACM

Press.

Birman, K. P. and Joseph, T. A. (1987). Exploiting vir-

tual synchrony in distributed systems. In SOSP, pages

123–138.

Chockler, G., Keidar, I., and Vitenberg, R. (2001).

Group communication speciﬁcations: a comprehen-

sive study. ACM Comput. Surv., 33(4):427–469.

Cristian, F. (1991). Understanding fault-tolerant distributed

systems. Commun. ACM, 34(2):56–78.

Daudjee, K. and Salem, K. (2006). Lazy database repli-

cation with snapshot isolation. In VLDB, pages 715–

726. ACM.

D´efago, X., Schiper, A., and Urb´an, P. (2004). Total order

broadcast and multicast algorithms: Taxonomy and

survey. ACM Comput. Surv., 36(4):372–421.

Elnikety, S., Pedone, F., and Zwaenopoel, W. (2005).

Database replication using generalized snapshot isola-

tion. In Symposium on Reliable Distributed Systems,

Orlando, FL, USA, pages 73–84. IEEE-CS.

Gonz´alez de Mend´ıvil, J. R., Armend´ariz-I˜nigo, J. E.,

Mu˜noz-Esco´ı, F. D., Ir´un-Briz, L., Garitagoitia, J. R.,

and Ju´arez-Rodr´ıguez, J. R. (2007). Non-blocking

ROWA protocols implement GSI using SI repli-

cas. Technical Report ITI-ITE-07/10, Instituto Tec-

nol´ogico de Inform´atica.

Gray, J., Helland, P., O’Neil, P. E., and Shasha, D. (1996).

The dangers of replication and a solution. In SIGMOD

Conference, pages 173–182. ACM.

Kemme, B. and Alonso, G. (2000). A new approach to de-

veloping and implementing eager database replication

protocols. ACM Trans. Database Syst., 25(3):333–

379.

Kemme, B., Pedone, F., Alonso, G., Schiper, A., and Wies-

mann, M. (2003). Using optimistic atomic broad-

cast in transaction processing systems. IEEE TKDE,

15(4):1018–1032.

Lin, Y., Kemme, B., Pati˜no-Mart´ınez, M., and Jim´enez-

Peris, R. (2005). Middleware based data replication

providing snapshot isolation. In SIGMOD Confer-

ence, pages 419–430. ACM.

Mu˜noz-Esco´ı, F. D., Pla-Civera, J., Ruiz-Fuertes, M. I.,

Ir´un-Briz, L., Decker, H., Armend´ariz-I˜nigo, J. E., and

de Mend´ıvil, J. R. G. (2006). Managing transaction

conﬂicts in middleware-based database replication ar-

chitectures. In SRDS, pages 401–410. IEEE-CS.

Pla-Civera, J., Ruiz-Fuertes, M. I., Garc´ıa-Mu˜noz, L. H.,

and Mu˜noz-Esco´ı, F. D. (2007). Optimizing

certiﬁcation-based database recovery. In ISPDC,

pages 211–218. IEEE-CS.

Plattner, C., Alonso, G., and

Ozsu, M. T. (2008). Extending

DBMSs with satellite databases. VLDB J., 17(4):657–

682.

Wiesmann, M. and Schiper, A. (2005). Comparison of

database replication techniques based on total order

broadcast. IEEE TKDE, 17(4):551–566.

Wu, S. and Kemme, B. (2005). Postgres-R(SI): Combin-

ing replica control with concurrency control based on

snapshot isolation. In ICDE, pages 422–433. IEEE-

CS.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

106
