ROBUST AUTHENTICATION USING LIKELIHOOD

ATIO

BASED SCORE FUSION OF VOICE AND FACE

Messaoud Bengherabi, Lamia Mezai, Farid Harizi

Division Architecture des Systèmes et Multimédia, Centre de Développement des Technologies Avancées

Cité 20 Aout, BP 11, Baba Hassen, Algiers, Algeria

Abderrazak Guessoum

Université Saad Dahlab de Blida, Route De Soumaa BP 270 BLIDA, Algeria

Mohamed Cheriet

École des Technologies Supérieur, 1100, Rue Notre-Dame Ouest, Montréal H3C1K3, Canada

Keywords: Biometrics, Score fusion, Face, Voice, Likelihood ratio, GMM.

Abstract: With the increased use of biometrics for identity verification, there has been a similar increase in the use of

multimodal fusion to overcome the limitations of unimodal biometric systems. While there are several types

of fusion (e.g. decision level, score level, feature level, sensor level), research has shown that score level

fusion is the most effective in delivering increased accuracy. Recently a promising framework for optimal

combination of match scores based on the likelihood ratio test is proposed; where the distributions of

genuine and impostor match scores are modelled as finite Gaussian mixture model. In this paper, we

examine the performance of combining face and voice biometrics at the score level using the LR classifier.

Our experiments on the publicly available scores of the XM2VTS Benchmark database show a consistent

improvement in performance compared to the famous efficient sum rule preceded by Min–Max, z-score and

tanh score normalization techniques.

1 INTRODUCTION AND

MOTIVATION

Nowadays, biometric verification systems based on

face images and/or speech signals have been shown

to be quite effective in various security applications

such as local or distant secure access, identity check

at an airport, , forensics ...etc. However, their

performance easily degrades in the presence of a

mismatch between training and testing conditions.

For speech based systems this is usually in the form

of channel distortion and/or ambient noise; for face

based systems it can be in the form of a change in

the illumination direction, varying pose, occlusion,

non-uniform background, etc. In order to achieve

better recognition performance and to overcome

other limitations of unimodal biometric systems;

information fusion from multiple biometric systems

has already been the subject of an intensive research

(Ross et al., 2006), (Toh et al., 2004).

Multibiometric systems are categorized into four

system architectures according to the strategies used

for information fusion: at the sensor, feature

extraction, matching score and decision levels (Ross

and Jain, 2003).

The score level fusion is generally preferred

because of its good performance and simplicity

(Alsaade, 2008). Combining match scores is a

challenging task because the scores of different

matchers don’t have the same nature and scale.

According to (Nandakumar et al., 2007), score

fusion techniques can be divided into the following

three categories: transformation-based score fusion

(Jain et al., 2005), (Snelick, et al., 2005), classifier-

based score fusion (Ma et al., 2005), (Fierrez-

Aguilar et al., 2003) and density-based score fusion

(Dass et al., 2005), (Nandakumar, 2008), the last

Bengherabi M., Mezai L., Harizi F., Guessoum A. and Cheriet M. (2009).

ROBUST AUTHENTICATION USING LIKELIHOOD RATIO BASED SCORE FUSION OF VOICE AND FACE.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 57-61

DOI: 10.5220/0002232200570061

 SciTePress

category is based on the likelihood ratio test and it

requires explicit estimation of genuine and impostor

match score densities. Density based approach

followed by a classifier based on the Neyman-

Pearson theorem (Lehmann and Romano, 2005) has

the advantage that it directly achieves optimal

performance at any desired operating point (FAR),

provided the score densities are estimated

accurately.

The authors in (Nandakumar et al., 2007)

highlight that finite Gaussian mixture model (GMM)

is quite effective in modelling the genuine and

impostor score densities and the likelihood ratio

based fusion rule with GMM-based density

estimation achieves consistently low verification

errors rates without the need for parameter tuning by

the system designer, and they conclude their work

by saying “while other fusion schemes such as sum

rule and SVM can provide performance comparable

to that of LR fusion, these approaches require

careful selection of parameters (e.g., score

normalization and fusion weights in sum rule, type

of kernel and kernel parameters in SVM) on a case-

by-case basis”.

However, their tests on the XM2VTS database

(Poh and Bengio, 2006) were restricted only to the

fusion of the best face and voice matchers, although

we have a total of 8 matchers (5 for face and 3 for

voice) yielding to a total of 15 bimodal

combinations.

In this paper, we examine the performance of

combining face and voice biometrics at the score

level using the LR classifier and a finite Gaussian

mixture model (GMM) in modelling the genuine and

impostor score densities. The tests are done for all

the 15 possible combinations with different GMM

model orders. The results are compared with the

famous efficient sum rule preceded by Min–Max, z-

score and tanh score normalization techniques.

This paper is organized as follows: in section 2

we review the likelihood ratio based score fusion

using GMM. Section 3 is dedicated to the

elaboration and analysis of experimental results.

Finally in the last section we conclude this work and

highlight a possible perspective.

2 OVERVIEW OF LIKELIHOOD

RATIO BASED SCORE FUSION

The Likelihood Ratio Test (LRT) has been used in

fusion by many researchers (Nandakumar et al.,

2007). Let be a random variable denoting the match

score provided by a matcher. Let the distribution

function for the genuine scores be denoted as P

gen

(s)

(i.e., P(S≤s|S is genuine)=Pgen(s)) with the

corresponding density function p

gen

(s). Similarly, let

the distribution function for the impostor scores be

denoted as Pimp(s) with the corresponding density

function p

imp

(s). Suppose we need to decide between

the genuine and impostor classes (to verify a

claimed identity) based on the observed match score

s. The likelihood ratio criterion can be expressed as:

()

(

)

()

threshold

simp

sgen

sL >=

(1)

The likelihood ratio method avoids the priors of

the genuine and the impostor required by the

Bayesian decision method, which are hard to

estimate or to guess in reality. Instead it calculates

the ratio and then thresholds it according to certain

performance criterion such as false accept rate

(FAR) or false reject rate (FRR). It can be formally

proved that the likelihood ratio criterion is optimal

in the Neyman-Pearson sense, i.e., when the FAR is

fixed, the likelihood ratio criterion minimizes the

FRR, and vice versa.

Assuming that both the genuine class and the

impostor class have a mixture of Gaussians

distribution, as expressed by

()

()()

exp

jj j

ps p

μμ

−

⎛⎞

−Σ−

⎜⎟

=−

⎜⎟

⎝⎠

∑

(2)

where

is match score vector, d is its

dimensionality,

is the mean vector,

is the

covariance matrix and

is the number of mixture.

Introducing logarithm, the criterion in Eq(1) can be

rewritten:

(

)

[

]

(

)

[

]

()

[

]

thresholdsplnsplnsLln

impgen

−

(3)

In our study, the operating threshold used for

performance comparison is the equal error rate

obtained when the false accept rate (FAR) is equal to

the false reject rate (FRR). From equation (3) we can

remark that for a single multidimensional Gaussian

the logarithm essentially reduces the probability

measure to the difference between the two squared

Mahalanobis distances in the genuine and the

impostor class.

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

3 EXPERIMENTAL RESULTS

3.1 The XM2VTS Database and the

Lausanne Protocols

The performance of likelihood ratio based fusion

rule was evaluated on the score of the XM2VTS

Benchmark database available from the website

(http://personal.ee.surrey.ac.uk/Personal/Norman.Po

h/), (Poh and Bengio, 2006). This database contains

synchronised video and speech data from 295

subjects, recorded during four sessions taken at one

month intervals. The database is divided into three

sets: a training set, an evaluation set and a test set.

The training set (LP Train) was used to build client

models, while the evaluation set (LP Eval) was used

to compute the decision thresholds used by

classifiers. Finally, the test set (LP Test) was used to

estimate the performance.

The 295 subjects were divided into a set of 200

clients, 25 evaluation impostors and 70 test

impostors. There exist two configurations or two

different partitioning approaches of the training and

evaluation sets. They are called Lausanne Protocol I

and II, denoted as LP1 and LP2 (Poh and Bengio,

2006), the description of the Lausanne Protocol is

shown in Table 1. In this paper, we have used the

Lausanne Protocol I (LP1).

3.2 Test Protocol

We have used combination of classifiers and face

and speech features like in (Poh and Bengio, 2006).

So we have 15 possible combinations. In the fusion

based on Likelihood ratio, we have varied the

number of mixtures to estimate the density of

impostor and genuine. We have used 1, 2, 4 and 8

mixtures. The simple sum rule preceded with the

min-max and tanh normalization methods (Snelick

et al., 2005) is used for the aim of comparison.

The min-max normalization method maps the

score to the [0, 1] range, the quantities Smax and

Smin specify the end points of the score range

(Snelick et al., 2005) and Sn (the normalized score)

is given by:

minmax

min

−

(4)

where Smin=min(s1, …, sK) and Smax=max(s1, …,

sK).

On other hand the hyperbolic tangent (Tanh) is a

robust statistical method which maps the scores to

the [0, 1] range (Snelick et al., 2005):

()

(

)

()

⎥

⎦

⎤

⎢

⎣

⎡

⎟

⎠

⎞

⎜

⎝

⎛

−

= 1

Sstd

SmeanS

01.0tanh

gen

(5)

where std stands for the standard deviation and gen

for the genuine scores (it was proven via

experiments that it is better to use the genuine scores

rather than both the genuine and impostor scores).

We have also compared the Likelihood ratio with

the work of (Poh and Bengio, 2006) in which, he

have used the simple sum rule with z-score

normalization.

3.3 Performance Evaluation

The Half Total Error Rate (HTER) (Poh and Bengio,

2006) of the likelihood ratio based fusion, simple

sum rule using min-max and z-score and tanh

normalization techniques is used to compare the

performance of the different fusion techniques. Note

that the HTER is defined as:

is the optimal threshold that minimizes the Error

Equal Rate (EER) on a development set. It can be

()

(

)

(

)

FRRFAR

HTER

ΔΔ

(6)

Table 1: Description of Lausanne Protocols.

Lausanne Protocol I Lausanne Protocol II

Number of

subjects

Number of recording

per subject

Number of

Scores

Number of

subjects

Number of recording

per subject

Number

of Scores

Training set Clients 200 3 600 200 4 800

Impostors / / / / / /

Evaluation set Clients 200 3 600 200 2 400

Impostors 25 8 40000 25 8 40000

Test set Clients 200 2 400 200 2 400

Impostors 70 8 112000 70 8 112000

ROBUST AUTHENTICATION USING LIKELIHOOD RATIO BASED SCORE FUSION OF VOICE AND FACE

Table 2: Comparison of the HTER between the likelihood ratio based fusion and the simple sum rule.

No. Fusion candidates Face Voice

(log-likelihood ratio) Simple sum rule

1 2 4 8 zscore Min-max Tanh

1 (FH,MLP)(LFCC,GMM) 1,883 1,148 1,108 0,426 0,565 0,297 0,795 0,862 0,737

2 (FH,MLP)(PAC,GMM) 1,883 6,208 1,441 1,097 0,992 1,079 1,133 1,161 1,026

3 (FH,MLP)(SSC,GMM) 1,883 4,494 1,339 1,054 0,962 0,963 0,868 1,072 0,778

4 (DCTs,GMM)(LFCC,GMM) 4,250 1,148 0,574 0,571 0,575 0,568 0,526 0,492 0,583

5 (DCTs,GMM)(PAC,GMM) 4,250 6,208 1,417 1,331 1,428 1,422 1,436 1,417 1,376

6 (DCTs,GMM)(SSC,GMM) 4,250 4,494 1,201 1,197 1,152 1,155 1,144 1,218 1,132

7 (DCTb,GMM)(LFCC,GMM) 1,734 1,148 0,499 0,476 0,479 0,486 0,553 0,503 0,467

8 (DCTb,GMM)(PAC,GMM) 1,734 6,208 1,106 1,087 1,068 1,066 1,127 1,093 1,661

9 (DCTb,GMM)(SSC,GMM) 1,734 4,494 0,764 0,747 0,849 0,841 0,747 0,720 0,733

10 (DCTs,MLP)(LFCC,GMM) 3,363 1,148 1,193 0,574 0,597 0,575 0,841 0,972 0,728

11 (DCTs,MLP)(PAC,GMM) 3,363 6,208 1,982 1,000 0,894 0,961 1,119 1,413 0,822

12 (DCTs,MLP)(SSC,GMM) 3,363 4,494 1,721 1,111 0,909 0,965 1,372 1,594 1,036

13 (DCTb,MLP)(LFCC,GMM) 6,225 1,148 1,693 0,719 0,609 0,682 1,621 3,278 0,874

14 (DCTb,MLP)(PAC,GMM) 6,225 6,208 3,547 2,579 2,167 2,410 3,653 4,121 2,623

15 (DCTb,MLP)(SSC,GMM) 6,225 4,494 3,722 2,038 1,671 1,831 2,883 4,329 2,058

Table 3: Comparison of the average of the HTER between the likelihood ratio based fusion and the simple sum rule.

(log-likelihood ratio)

Number of mixtures

Simple sum rule

1 2 4 8 zscore Min-max Tanh

Average of HTER of the 15 combinations 1,554 1,067 0,994 1,020 1,616 1,321 1,109

calculated as follows:

()

ΔΔ

EERminarg

(7)

where

() ()()

ΔΔ

FRRFAR

EER +=

(8)

where FAR and FRR designate the false acceptance

rate and false rejection rate respectively.

We can notice from table 2, that using LR test with

only one Gaussian gives the worst results. This is

expected because only one Gaussian is not sufficient

to estimate efficiently the score distributions.

However a consistent performance improvement is

obtained by increasing the number of Gaussians to 4

where the best performance are abstained, good

results are obtained with eight Gaussians but it is

clear that 8 Gaussians are more than enough to

estimate the client and impostor distributions and

also this is due to the lack of data.

To summarize Table 2, we have computed the

average HTER of the 15 possible matcher

combinations, the results are summarized in Table 3.

It is so clear from this table the superiority of the LR

test using GMM for modelling the genuine and

impostor classes. We can conclude that although the

sum rule can obtain a better performance with an

appropriate normalisation (min-max or tanh in our

case) the gain compared to the LR is not significant.

4 CONCLUSIONS

In this paper, we have analyzed the performance of

combining face and voice biometrics at the score

level using the LR classifier. Our experiments on the

publicly available scores of the XM2VTS

Benchmark database show a consistent high

performance regardless of the score nature of

different speech and face matchers. As a perspective

of this work is the introduction of user specific

information jointly with the LR test and GMM score

modelling.

REFERENCES

Alsaade, F. 2008. Score-Level Fusion for Multimodal

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

Biometrics. Phd thesis, University of Hertfordshire,

England.

Dass, S. C., Nandakumar, K., Jain, A. K. 2005. A

Principled Approach to Score Level Fusion in

Multimodal Biometric Systems. Lecture Notes in

Computer Science proceedings of the Audio- and

Video-Based Biometric Person Authentication

conference AVBPA’2005, 1049-1058 Springer Berlin /

Heidelberg.

Fierrez-Aguilar, J., Ortega-Garcia, J., Gonzalez-

Rodriguez, J. 2003. Fusion Strategies in Multimodal

Biometric Verification. Proceedings of the IEEE

International Conference on Multimedia and Expo,

ICME ’03, pp 5 – 8.

Jain, A., Nandakumar, K., Ross, A. 2005. Score

normalization in multimodal biometric systems.

Pattern Recognition, vol. 38, No. 12, pp. 2270-2285.

Lehmann, E. L., Romano, J. P. 2005. Testing Statistical

Hypotheses. Springer.

Ma, Y., Cukic, B., Singh, H. 2005. A Classification

Approach to Multi-biometric Score Fusion. In

Proceedings of Fifth International Conference on

AVBPA, Rye Brook, pp. 484–493.

Nandakumar, K. 2008, Multibiometric Systems: Fusion

Strategies and Template Security. Phd Thesis,

Michigan State University, Department of Computer

Science and Engineering.

Nandakumar, K., Chen, Y., Jain, K. 2007. Likelihood

Ratio Based Biometric Score Fusion. IEEE

Transactions on Pattern Analysis and Machine

Intelligence.

Poh N., Bengio, S. 2006. Database, Protocol and Tools for

Evaluating Score-Level Fusion Algorithms in

Biometric Authentication. Pattern Recognition, vol.

39, no. 2, pp. 223–233.

Ross, A., Jain, A. K. 2003. Information Fusion in

Biometrics. Pattern Recognition Letters.

Ross, A., Nandakumar, K., Jain, A. K. 2006. Handbook of

Multibiometrics.Springer-Verlag.

Snelick, R., Uludag, U., Mink, A., Indovina, M., Jain, A.

2005. Large Scale Evaluation of Multimodal

Biometric Authentication Using State-of-the-Art

Systems. IEEE Transactions on Pattern Analysis and

Machine Intelligence, Vol. 27, No. 3, pp 450-455.

Toh, K.-A., Jiang, X., Yau, W.-Y. 2004. Exploiting Global

and Local Decisions for Multimodal Biometrics

Verification. IEEE Transactions on Signal Processing,

(Supplement on Secure Media), vol. 52, no. 10, pp.

3059–3072.

ROBUST AUTHENTICATION USING LIKELIHOOD RATIO BASED SCORE FUSION OF VOICE AND FACE
