AN ADAPTIVE MIDDLEWARE FOR

MOBILE INFORMATION SYSTEMS

Volker Gruhn and Malte H¨ulder

Applied Telematics/e-Business Group, Dept. of Computer Science, University of Leipzig, Klostergasse 3, Leipzig, Germany

Keywords:

Mobile applications, Dynamic reconﬁguration, Reconﬁguration triggers, Adaptive middleware, Reactive sys-

tems.

Abstract:

The advances in mobile telecommunication networks as well as in mobile device technology have stimulated

the development of a wide range of mobile applications. While it is sensible to install at leastsome components

of applications on mobile devices to gain independence of rather unreliable mobile network connections, it is

difﬁcult to decide about the suitable application components and the amount of data to be provided.Because

the environment of a mobile device can change and mobile business processes evolve over time, the mobile

system should adapt to these changes dynamically to ensure productivity.

In this paper, we present a mobile middleware that targets typical problems of mobile applications and dynam-

ically adapts to context changes at runtime by utilizing reconﬁguration triggers.

1 INTRODUCTION

Over the past years, the development of mobile ap-

plications has increased signiﬁcantly, and more and

more specialized applications are introduced that sup-

port mobile business processes performed by mobile

ﬁeld workers.

For example, let us consider an information sys-

tem that enables an insurance agent to perform his

business processes. Supplementing ofﬁce work, the

agent visits his clients at their homes or at the site of

insured objects. Particularly in claims management,

he has to visit the insured object, ascertain necessary

data and organize the claim settlement. Depending

on the type of claim, the claims management process

can be very different: for a damaged car, e.g., in a cat-

alog containing all parts of the particular model, the

affected parts have to be marked. For other objects,

the agent has to take photos of the affected objects.

From this example, we can see two major issues

that need to be considered in supporting mobile busi-

ness processes (Gruhn et al., 2007): On one hand, the

processes may be very speciﬁc and complex, and on

the other hand, data used during a process may only

be used for this particular process (like the catalog

containing all parts of a particular car). Traditionally,

these issues have been addressed in two ways:

1. A complex application is installed on the mobile

device, which comprises the knowledge of all pro-

cesses and their necessary data. This approach al-

lows working with the application autonomously, but

it may also consume a lot of storage space on the mo-

bile device. Moreover, it is rather expensive in devel-

opment, operation, and maintenance.

2. Alternatively, the complex application is installed

on a server, while the mobile device only holds a thin

client that only renders the data. Resource consump-

tion on the mobile device, as well as development and

maintenance costs, remain low. However, such a thin

client application depends on a permanent network

connection to the server (Jing et al., 1999).

Our approach proposes to dynamically mobilize

components and data at runtime, based on knowl-

edge of business processes and the current environ-

ment context. We therefore present a mobile, service-

oriented middleware that allows transferring applica-

tions (or parts of them) from a server to mobile client

devices. The middleware provides an execution en-

vironment that allows execution of the same imple-

mentation on both the server and the mobile clients.

It also dynamically adapts to the current environment

context, e.g. it considers the current network connec-

tion when invoking services on the local device or

the remote server. The considered context informa-

tion, possible adaptations, and the rules controlling

dynamic reconﬁguration are presented in sect. 4.2.

108

Gruhn V. and Hülder M. (2009).

AN ADAPTIVE MIDDLEWARE FOR MOBILE INFORMATION SYSTEMS.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Software Agents and Internet Computing, pages 107-112

DOI: 10.5220/0002001601070112

 SciTePress

In sect. 2, we discuss typical problems experi-

enced by mobile applications, followed by an outline

of related work (sect. 3). Subsequently, we introduce

our mobile middleware in sect. 4, which is completed

by a validation in sect. 5. The paper is rounded off by

our conclusions and future outlook (sect. 6).

2 PROBLEMS OF DISTRIBUTED

MOBILE APPLICATIONS

One of the most crucial problems of distributed mo-

bile applications is volatile network connectivity. Mo-

bile network connections are rather slow compared

to wired networks and also they often vanish without

warning. Applications depending on a network con-

nection cannot be used under these circumstances.

On the other hand, mobile information systems

may be very helpful, if they can be used in places

where no network connection is available, e.g. in

a building’s basement, out in the ﬁeld, or even in a

disaster area. Therefore, mobile information systems

should be capable of disconnected operation.

Another crucial problem is the limited storage

space of mobile devices. The limited resources do

not allow placing a complex application and all of its

data on a mobile device. Hence, only selected parts

of complex applications can be made available on the

device to support the current mobile business process.

Similarly, only a carefully chosen subset of the data in

a central data store can be replicated to a mobile de-

vice to support these activities.

In both cases, it is difﬁcult to decide about the

appropriate selection of data and components which

ought to be transferred to the mobile device. Further-

more, such a decision should not be ﬁxed, but has to

be made repeatedly to adapt to the current situation of

the device and the mobile business process.

Another challenge lies in the fact that mobility and

size of mobile devices causes them to be lost or stolen

more easily than ﬁxed ofﬁce computers. Providing

applications and data on a mobile device brings about

increased security requirements. For example, conﬁ-

dential data should be removed from the device when

it gets lost or at least the data has to be encrypted so

that it is useless for an unauthorized ﬁnder.

Applications installed on mobile devices may

have to be updated from time to time. Calling the

devices in to be updated by an administrator is time-

consuming and requires logistical effort. Distributing

updates on compact discs or other media requires the

users to be able to perform the updates themselves

and increases the risk of updates being installed with

signiﬁcant delays or not at all. Thus, online updates

via the Internet have become popular. However, pro-

viding an update management tool for each mobile

application individually, increases development effort

and resource consumption on mobile devices.

Advances in mobile device technology have

brought about numerous different devices and an in-

creasingly faster development of even more device

types. Keeping up with this development by provid-

ing applications tailored for speciﬁc devices becomes

more and more complex and expensive. An execution

environmentthat levelsdevice differences may reduce

development and maintenance costs signiﬁcantly.

We consider these problems relevant for such a

number of mobile applications that they ought to be

addressed in a general way. Our approach is based

on an adaptive mobile middleware, which targets the

stated problems for the class of mobile information

systems, and is variable enough to support a great va-

riety of mobile business processes. Sect. 4 describes

the main aspects of our approach in more detail.

3 RELATED WORK

In this section, we give a brief overview on selected

related work:

Hong et al. give an introduction to context-

awareness. They group context information in com-

puting, user and physical context (Hong et al., 2005).

We do not see the necessity to handle these three

types of context differently, and therefore we propose

a generic context interface for components and re-

conﬁguration triggers. While currently only the mo-

bile business process context and the most impor-

tant computing context sensors (CPU, memory, disk

space, bandwidth) have been implemented, other sen-

sors may easily be added at a later stage.

Coda (Kistler and Satyanarayanan, 1992) is a dis-

tributed ﬁle system that provides ﬁle operations for

mobile systems which are temporarily disconnected,

by implementing client-side caching, and server repli-

cation mechanisms. Files can be stored on several

servers so that a client may copy them from another

server, if one is not available. However, Coda is based

on the notion of ﬁles, which is too coarse-grained

to support service orientation and synchronization of

business object attributes.

The Odyssey system (Noble and Satyanarayanan,

1999) has evolved from Coda. While Coda hides

environment data from applications, Odyssey allows

quality-based access to data, notifying the application

when a parameter (e.g. the available network band-

width) is out of bounds and thus enabling it to re-

act to this situation accordingly. However, Odyssey

AN ADAPTIVE MIDDLEWARE FOR MOBILE INFORMATION SYSTEMS

109

is also based on the notion of binary ﬁles which is not

suitable for service orientation and synchronization of

ﬁne-grained business object attributes.

Other than Coda and Odyssey, Xerox PARC’s

Bayou (Terry et al., 1998) does not try to resolve data

inconsistency itself. It rather notiﬁes the applications

which themselves can provide methods to resolve the

conﬂicts. Like other ﬁle-based systems, Bayou has

not been designed for service-oriented architectures.

The SATIN component system (Zachariadis et al.,

2006) follows a similar approach to ours of providing

a light-weight middleware for mobilizing application

parts. However, we put a strong emphasis on service

orientation as well as managing user data during off-

line operation. Furthermore, we propose a solution

to decide about mobilizing components at runtime,

based on knowledgeabout mobile business processes.

Popa et al. introduce a mechanism called ”code

collection” for code execution on mobile devices in

(Popa et al., 2004). Code collection is a management

concept combining caching techniques and garbage

collection techniques for memory management. It dy-

namically loads and removes methods to and from the

device’s memory depending on the amount of mem-

ory available. Similar to data caching, subsequent

calls to removed methods lead to a miss and require

reloading those methods via the network. Thus, it is

not suitable for offline operation. We still consider

this approach interesting as it may help to improve

the selection of components most likely being used

during disconnected mode as we discuss in sect. 6.

A rather recent development is Google Gears

(Google, 2007; Herrington, 2007). It solely tar-

gets web applications for which it supports an off-

line mode. The execution of business logic in off-

line mode is restricted to logic implemented in Java-

Script which can be executed in the browser. In our

approach we focus on mobilizing and executing the

same implementations on server and mobile clients.

4 MobCo MIDDLEWARE

Our mobile middleware was developed as part of the

MobCo project. It is implemented on top of the OSGi

framework standard (OSGi Alliance, 2005), which it-

self is a service oriented component layer based on

the Java programming language.

4.1 Subsystems

The architecture of MobCo middleware is shown in

Figure 1. It comprises a number of subsystems, each

of which is responsible for different aspects.

Communication

Monitoring

Persistence

MobCo Middleware

MobCo Component

Component

Framework

Component

Manager

Trigger

Figure 1: Subsystems of MobCo Middleware

The component framework provides the inter-

face used by components to interact with the mobile

middleware. For example, it allows a component to

lookup and invoke services provided by other compo-

nents. It also provides access to the persistence sub-

system allowing a component to query, load and store

data, and to the monitoring system allowing to inspect

the current environment’s context.

The component manager is responsible to de-

ployment and removal of components. On that basis,

it also has to manage the transfer of new or updated

components and control the update process of unde-

ploying an outdated and deploying the updated ver-

sion of a component. The component manager also

resolves component dependencies and automatically

transfers required dependencies to the mobile system.

The persistence subsystem realizes a distributed

data store which consists of a local data store on each

mobile device and a central database on the server. It

allows selecting a number of data objects to be repli-

cated to the mobile device and synchronized with the

server when necessary.

The persistence subsystem uses the object ori-

ented database db4o (Versant Corp., 2008) as a ba-

sis for its functionality, but it hides the db4o inter-

faces behind the component framework. This way,

the database may be substituted, if necessary.

The communication subsystem controls the com-

munication between two middleware instances and it

controls the routing of service calls by components.

The R-OSGi extension (Rellermeyer et al., 2007)

is used for the incorporation of remote services pro-

vided on another device.

The monitoring subsystem collects information

about the system’s environment. In particular, it ob-

serves the device’s network connectivity, its storage

space, memory and computational load.

The trigger subsystem manages the dynamic re-

conﬁguration of our mobile middleware by means of

reconﬁguration triggers, which decide about neces-

sary reconﬁgurations based on the information col-

lected by the monitoring subsystem.

ICEIS 2009 - International Conference on Enterprise Information Systems

110

4.2 Dynamic Reconﬁguration

Dynamic reconﬁguration means changing the distri-

bution or the behavior of a mobile application at run-

time, according to changes in the environment. As we

have seen in sect. 2, mobile applications often suffer

from similar problems and thus, they may adapt to en-

vironment changes in similar ways. Our middleware

provides several standard reconﬁgurations, some of

which can be applied independently of the current ap-

plication, and some that may be utilized by applica-

tion developers for their individual applications.

In order to design the ways in which such a dy-

namic reconﬁguration takes place, we have to deﬁne

the context information to react to, and the set of pos-

sible reactions which can be performed according to

the current situation. We call the rules that decide

about whether a reaction has to follow the current sit-

uation reconﬁguration triggers or just triggers.

Triggers collect information about the environ-

ment and the executed mobile business processes and

decide whether a reconﬁguration is necessary. Thus,

triggers provide a mapping from the set of environ-

mental and mobile business process information to

the set of possible reconﬁgurations, which will be de-

ﬁned in the following sections.

4.2.1 Relevant Context Information

For the sake of brevity, we will only name (rather

than discuss) the parameters that are considered for

the set of mobile business processes and environmen-

tal information that triggers base their decisions on:

Network type, bandwidth, latency, CPU power, CPU

load, device type, storage space, memory, component

size, component dependencies, component version,

user information, and the currently executed mobile

business process.

4.2.2 Possible Reconﬁgurations

The set of reactions that may be initiated by reconﬁg-

uration triggers can be divided into reactions that have

to be provided by a mobile middleware, and reactions

that change the behavior of an application. In order to

keep the middleware small and lightweight for mobile

devices, the set of middleware reactions contains only

the reactions necessary for dynamic changes in com-

ponent distribution, dynamic routing of service calls

and handling of replicated data. This comprises the

following activities:

Mobilization. A trigger may decide to mobilize a

component, i.e. transfer it to the mobile host for

local execution.

Removal. A trigger can react to outdated or unneces-

sary components or low storage space by remov-

ing a component from the local system.

Routing. Components can reside on a mobile host as

well as on the server. A trigger may decide for

the application to employ the local or the remote

installation, depending on the current situation.

Replication. The trigger can initiate the replication

of selected business objects, when a connection

becomes available, or when a replicated business

object is changed on the server.

Synchronization. When a business object has been

changed during offline mode and a network con-

nection becomes available, synchronization of the

replicated business object has to be initiated. Dur-

ing synchronization, possible conﬂicts and incon-

sistencies between local and remote copy have to

be resolved.

Application Reaction. If a mobile application pro-

vides its own adaptations to different situations,

triggers can be used to invoke the according func-

tionality in the appropriate situation.

4.3 Standard Triggers

Based on the monitored environment data and the

possible reconﬁgurations, we have implemented a

number of standard triggers, which can be conﬁgured

for individual application needs, if required.

Application developers may implement their own

reconﬁgurationtriggers to control dynamic adaptation

of the middleware, or to allow their applications to

adapt to context changes by application reactions.

Network Class Triggers. are used to group low level

network information like network type, latency

and bandwidth into high level network classes.

Network classes may be deﬁned by the developer,

e.g. ”low speed”, ”high speed”, or ”WLAN”,

”GPRS”, and ”UMTS” could be such classes.

Routing Triggers. adjust the preferred routing of

service calls based on the current network class,

the availability or unavailability of certain compo-

nents, or the occurrence of certain process events.

Ofﬂine Readiness Triggers. control the mobiliza-

tion of components to ensure their availability

during offline mode. There are Offline Readiness

Triggers that mobilize components necessary for

complete applications, selected mobile business

processes, or according to a developers’ selection.

Update Triggers. control checking and provision of

updates. If updates are available, selective triggers

AN ADAPTIVE MIDDLEWARE FOR MOBILE INFORMATION SYSTEMS

111

can prioritize them according to their relevance

for the currently executed application or process.

Download Management Triggers. control enqueu-

ing component downloads to the download queue,

aborting currently enqueued downloads, and ad-

justing the number of parallel downloads.

5 EXPERIENCE

To show the feasibility of our approach, we have im-

plemented the mobile middleware as described above,

and we have built a mobile information system appli-

cation that utilizes the middleware’s features.

5.1 About the Application

The application is taken from the telecommunications

domain and supports service technicians performing

their work in the ﬁeld. In particular, service techni-

cians have to visit customers and install or repair their

telephone or Internet connections, and they have to

maintain infrastructure appliances.

The application comprises more than 90 compo-

nents that provide small application units to allow for

ﬁne-grained distribution on mobile devices.

Currently, computers running Microsoft Windows

XP and Vista, MacOS 10.5 and mobile devices run-

ning MS Windows CE and Mobile are supported.

5.2 Mobile Business Process

The mobile business processes supported by the ap-

plication are easy to understand. Still, the complete

mobile business process model which provides the

foundation for our implementation is too complex and

beyond the scope of this paper.

In brief, the service technician receives a number

of tasks from his dispatcher on his mobile device. Be-

fore he starts his work, the service technician sorts the

tasks in a convenientorder he intends to follow for the

rest of the day. This sequence is reported back to the

dispatcher who may assign additional tasks during the

course of the day, if they ﬁt the technician’s plan, e.g.

because they are close to the current task’s location.

During his working day, the technician attends

the customers’ locations and installs or repairs their

telecommunication connections. On completion of

such a task, he ﬁles an activity report and updates the

vehicle log. Additionally, he may give advice on ad-

ditional equipment (e.g. a WLAN router) and order

appropriate devices from an online procurement sys-

tem. As the service technician has direct customer

contact, he may also perform a customer survey.

5.3 Component and Data Distribution

From the mobile business process model, the mobile

middleware gains knowledge about the components

necessary to execute a certain process. This knowl-

edge is used to provide the relevant components on

the local device in time, when the process is started.

This way, it can be assured that all necessary compo-

nents are locally available to execute and complete the

current process, even if the device gets disconnected.

5.4 Update Management

The application uses an update trigger that checks for

updates upon starting the middleware, typically on a

daily basis. The service technician performs the cus-

tomer surveyafter the execution of a task that involves

customer contact. Therefore, when such a task is ex-

ecuted, another update trigger checks for updates and

ensures that the latest version of survey components

is provided before the survey is to be performed.

5.5 Utilizing Context Information

The developer only has to care about component lo-

cations and routing of service calls, if the application

shall behave in different ways depending on the en-

vironment’s context. In our example, the application

comprises a simple procurement system that allows

ordering additionaltelephone or computer equipment.

If the device has an online connection to the sever

when the procurement system is accessed, the list of

products can be loaded from the server including up-

to-date price and stock information. If the device

is disconnected when the procurement system is ac-

cessed, only the ten most popular products can be

loaded from the local data store. The number of prod-

ucts stored on the mobile device has been reduced

signiﬁcantly to save local storage resources, while

still providing basic procurement system functional-

ity in disconnected mode. Additionally, there is no

up-to-date information about the availability of prod-

ucts in stock. Therefore, the procurement system has

to behave differently depending on the network con-

nection: In online mode, the order can be placed di-

rectly on customer’s request, but in offline mode, only

a quotation for the selected products can be requested.

This request is stored locally on the device until it re-

connects to the server. After reconnection, the quo-

tation request is transmitted to the server which pro-

cesses the request and creates an individual quotation

including the current price list and stock information.

Note that this use of context information is

application-speciﬁc – customers’ satisfaction is ex-

ICEIS 2009 - International Conference on Enterprise Information Systems

112

pected to increase when an order can only be placed if

up-to-date pricing and stock information is available.

As we have seen, our middleware cares about in-

corporating local or remote services automatically,

based on the current context and developers’ prefer-

ences. But it allows applications to observe the cur-

rent context and adapt their behavior as well.

6 CONCLUSIONS AND

OUTLOOK

We have developed a middleware for mobile devices

that allows execution of application components on

mobile hosts as well as dynamic reconﬁguration of

its behavior by evaluating triggers and realizing their

reactions. On top of that, we have implemented a mo-

bile application from the telecommunications domain

utilizing the mobile middleware’s features.

The results show the feasibility of our approach.

Instead of solving the typical problems of mobile ap-

plications named in sect. 2 from scratch, they have

been targeted by our mobile middleware. Application

developers therefore may concentrate on the actual

business logic of their mobile information systems.

While the validation has shown the approach to

be feasible, both mobile middleware and the imple-

mented application have not yet reached production

status. Before the middleware may be used in pro-

ductive environments, we have to increase its stabil-

ity and user friendliness, and we have to address some

security and performance issues.

For future research, we see a great potential in

actively utilizing mobile business process models to

transfer the required components to the mobile device

early during process execution, to allow for seamless

operation in offline mode. Currently, the selection

of needed components has to be done manually by

implementing an appropriate trigger, or automatically

based on dependencies.

Popa et al. propose the inspection of code depen-

dencies and object references to reclaim memory (like

in garbage collection) to be combined with data about

invocation frequencies of methods (similar to caching

strategies) (Popa et al., 2004). We believe that enrich-

ing code dependencies, object references, and mo-

bile business process information with user behavior

information may additionally aid the decision about

mobilizing the code that is likely to be used in future.

Proving this hypothesis is subject of future research.

ACKNOWLEDGEMENTS

The Applied Telematics/e-Business group is endowed

by Deutsche Telekom AG. The mobile middleware

was developed in the MobCo project which was co-

founded by Deutsche Telekom Laboratories.

REFERENCES

Google (2007). Google Gears. http://gears.google.com/.

Gruhn, V., K¨ohler, A., and Klawes, R. (2007). Modeling

and analysis of mobile business processes. Journal of

Enterprise Information Management, 20(6):657–676.

Herrington, J. (2007). The Power of Google Gears.

http://www.oreilly.de/artikel/2007/07/googlegears.html.

Hong, D., Chiu, D. K. W., and Shen, V. Y. (2005). Re-

quirements elicitation for the design of context-aware

applications in a ubiquitous environment. In Proceed-

ings of the 7th international conference on Electronic

commerce (ICEC ’05), pages 590–596, NY, USA.

Jing, J., Helal, A. S., and Elmagarmid, A. (1999). Client-

server computing in mobile environments. ACM Com-

put. Surv., 31(2):117–157.

Kistler, J. J. and Satyanarayanan, M. (1992). Disconnected

Operation in the Coda File System. ACM Transactions

on Computer Systems, 10(1):3–25.

Noble, B. and Satyanarayanan, M. (1999). Experience with

adaptive mobile applications in Odyssey. Mobile Net-

works and Applications, 4.

OSGi Alliance (2005). OSGi Service Platform - Release 4.

Technical report, OSGi Alliance.

Popa, L., Raiciu, C., Teodorescu, R., Athanasiu, I., and

Pandey, R. (2004). Using code collection to sup-

port large applications on mobile devices. In Mobi-

Com ’04: Proceedings of the 10th annual interna-

tional conference on Mobile computing and network-

ing, pages 16–29, New York, NY, USA. ACM.

Rellermeyer, J. S., Alonso, G., and Roscoe, T. (2007).

R-OSGi: Distributed Applications Through Software

Modularization. In Middleware ’07, volume 4834 of

LNCS. Springer.

Terry, D. B., Petersen, K., Spreitzer, M. J., and Theimer,

M. M. (1998). The Case for Non-transparent Replica-

tion: Examples from Bayou. IEEE Data Engineering,

pages 12–20.

Versant Corp. (2008). db4objects. http://www.db4o.com/.

Zachariadis, S., Mascolo, C., and Emmerich, W. (2006).

The SATIN Component System–A Metamodel for

Engineering Adaptable Mobile Systems. IEEE Trans-

actions on Software Engineering, 32(11):910–927.

AN ADAPTIVE MIDDLEWARE FOR MOBILE INFORMATION SYSTEMS

113
