K-ANNOTATIONS

An Approach for Conceptual Knowledge Implementation using Metadata

Annotations

Eduardo S. E. Castro, Mara Abel and R. Tom Price

Instituto de Informática, UFRGS, Av. Bento Gonçalves, 9500, Bloco IV, Campus do Vale, Porto Alegre, Brazil

Keywords: Knowledge System, Conceptual Model Implementation, Metadata Annotations for Knowledge

Interpretation, Aspect Oriented Programming.

Abstract: A number of Knowledge Engineering methodologies have been proposed during the last decades. These

methodologies use different languages for knowledge modelling. As most of these languages are based on

logic, knowledge models defined using theses languages cannot be easily converted to the Object-Oriented

(OO) paradigm. This brings a relevant problem to the development phase of KS projects: several complex

knowledge systems are developed using OO languages. So, even if the conceptual model can be modelled

using the logical paradigm, it is important to provide a standard knowledge representation with the OO

paradigm. This paper introduces the k-annotations, an approach for conceptual knowledge implementation

using metadata annotations and the aspect oriented paradigm. The proposed approach allows the

development of the conceptual model using the OO paradigm and it establishes a standard path to

implement this model. The main goal of the approach is to provide ways to reuse both the knowledge design

and related programming code of the model based on a single model representation.

1 INTRODUCTION

Several Knowledge Engineering methodologies

have been proposed during the last decades for

building knowledge systems (KS). For instance,

VITAL (Meseguer & Preece, 1995), MIKE (Angele

et al., 1998), CommonKADS (Schreiber et al.,

2000), XP.K (Knublauch, 2002), RapidOWL (Auer,

2006) and KM-IRIS (Chalmeta & Grangel, 2008).

Almost all those methodologies have focused on the

modelling phase of the project, specifically, in the

knowledge model elaboration. This model is

composed by three components according to

Schreiber et al. (2000):

 Conceptual Component: describes the static

information/knowledge structure (concepts,

attributes, relations, rules and axioms) related to

the application domain;

 Task Component: defines the strategies used by

the system (on the conceptual component) to

solve problems;

 Inferential Component: defines the basic

reasoning steps used to complete a task.

These methodologies use different languages for

knowledge modelling. For instance, AI-based

languages (e.g.: Ontolingua, CML) and ontology

markup languages (eg: RDF, OWL). As most of

these languages are based on logic, knowledge

models defined using theses languages cannot be

easily converted to the Object-Oriented (OO)

paradigm. This brings a relevant problem to the

development phase of KS projects: several complex

knowledge systems are developed using OO

languages. So, even if the conceptual model can be

modelled using the logical paradigm, it is important

to provide a standard knowledge representation with

the OO paradigm, because many projects use Java

and C# as languages for KS development.

However, in spite of all the methodological

efforts, there is not yet a methodology that offers an

extensive approach composed by guidelines and

tools for the representation of the conceptual model

using the OO paradigm. Currently each KS project

uses an ad-hoc solution for the implementation in

OO of the conceptual model. For instance, an ad-hoc

solution in use by a project complex KS for

underground oil reserves evaluation (Castro et al.,

2008) defines the following mapping between the

conceptual model and its implementation using the

OO paradigm:

Castro E., Abel M. and Price R. (2009).

K-ANNOTATIONS - An Approach for Conceptual Knowledge Implementation using Metadata Annotations.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Artiﬁcial Intelligence and Decision Support Systems, pages

67-73

DOI: 10.5220/0001863100670073

 SciTePress

 Concepts map to classes;

 Concept attributes map to class properties;

 Facets (for constraint definition), Axioms and

Rules map to external classes (validator design

pattern (Fowler, 1997)) or to methods of the

conceptual classes.

In consequence, not only the aforementioned ad-

hoc approach but also several KS projects face the

following problems:

 The ad-hoc solution design can cope with the

current system requisites, but, it may become

quickly inadequate because of the frequent

changes in system requirements due to

knowledge evolution;

 In most of cases, the ad-hoc solution generates

components that merge the conceptual model

with other requirements. In the aforementioned

example, it is hard to distinguish methods that

implement facets from methods that implement

other requirements. This ambiguity of method

role turns much harder to understand the code

goals and structure and to perform testing and

maintenance. Also, it is almost impossible to

extract documentation about the conceptual

model from the code and it is hard to maintain

the documentation of the conceptual model

coherent with its implementation;

 The model implementation is well-know only by

the team of programmers of the project. This

increases this risk of maintenance problems.

This is usually worsened because of high staff

turnover.

The proposed approach allows the development

of the conceptual model using the OO paradigm and

it establishes a standard path to implement this

model. The main goal of the approach is to provide

ways to reuse both the knowledge design and related

programming code of the model based in a single

model representation.

The approach is based on a set of metadata

annotations integrated with the aspect-oriented

paradigm (AOP). According to Stephens (2004)

metadata is traditionally defined as ‘information

about information’. In the proposed approach,

annotations are used to distinguish conceptual model

elements from the rest of the code, and these

annotations are stored within the metadata

components of the interpreters. In the case of Java

and C#, metadata is information about the elements

of a class., for instance, constructors, methods and

properties.

Widely used OO languages provide annotations

for metadata definition, so the proposed approach

uses this resource to add metadata. Annotations are

used to clearly and visually distinguish conceptual

model elements in the software code, marking them

as such. As these annotations are identifying

knowledge elements, they are here called K-

Annotations (KA). Concepts, attributes, facets,

axioms and rules are defined using k-annotations.

Each annotation must be processed by the KA-

Processor tool that generates the correspondent code

for each annotation. Section 3.1 defines the set of k-

annotations proposed in this article and the KA-

Processor that generates code based on the

annotations.

Integrated to the k-annotations, the Aspect

Oriented Paradigm is used to avoid the proliferation

of auxiliary properties and methods in the class that

implements the conceptual model. For instance, in

the ad-hoc solution, if a facet that inhibits null

values is used four times, the developer must

implement four times the correspondent value

comparison. The code for each check is manually

inserted for each use, so the system is more

susceptible to bugs. An aspect is defined (Kiczales et

al., 2001) as a software entity that captures a

transversal functionality in relation of an application.

Regarding this definition, k-annotations identifies

aspects which must be managed by the tool that

generates code.

The management is performed by a tool that

injects the correspondent code for each annotation.

So, the developers do not need anymore to insert

repetitively the code, thus avoiding the phenomenon

of dispersion and reducing the risk of bugs and the

cost of maintenance. The activation of the code

generated for each annotation is automatically

configured by the annotation processor tool. It is not

necessary anymore for the developer to define when

it must be called. Also, a code library is part of this

approach, so, the code generated by the annotation

processor tool can be reduced using calls to the

library.

Regarding the above propositions, several KS

projects can use the proposed notation and

interpreting tool for developing the conceptual

model, avoiding ad-hoc solutions for every project.

In section 2, related works are discussed, in

particular XP.K that includes KBeans (Knublauch,

2002), a proposition of an OO implementation for

the conceptual model. In section 3, the central

concepts of the proposed annotations and

interpreting tool are briefly described, and the set of

annotations to be used, with their roles, are defined.

Also, in section 3, the description of a tool for code

generation and a tool for monitoring the

K-ANNOTATIONS - An Approach for Conceptual Knowledge Implementation using Metadata Annotations

maintenance of the knowledge body is presented. In

section 4, a case study using the proposed tools is

presented. In section 5, conclusions and future work

are presented.

2 RELATED WORK

Among the methodologies for KS development,

XP.K is distinguished because it proposes the OO

paradigm as a starting point. It proposes an OO

solution called KBeans for implementing the

conceptual model. Section 2.1 is uses XP.K

(Knublauch, 2002) as source base.

2.1 KBeans

KBeans is based on JavaBeans and code conventions

for defining transparently the semantics of the

conceptual model elements. Semantic transparency

can be reduced to formal information about the

model elements and their relations (Knublauch,

2002). KBeans proposes the use of code conventions

to provide metadata information related to the model

elements and their relations. It uses reflection to

process each metadata and to generate the

correspondent code.

KBeans maps concepts to classes and attributes

to class properties. Also, it provides a pre-defined

catalog of facets for constraint checking. Each facet

is defined on a class using a code convention related

to properties and methods. For instance, to define

that a class property named age can not be less than

0, another class property named ageMinValue must

be defined as 0. However, some disadvantages arise

when using only this sort of code conventions to

provide metadata:

 The use of code conventions creates ambiguities

related to method and property roles. Properties

and methods that define facets can be confused

with properties and methods related to the

application domain. For instance, a property

named ageMin can be defined as a property of a

concept, but it can be mistakenly be understood

as a facet;

 There is a proliferation of auxiliary properties

and methods in the class that implements the

conceptual model. This increases the code and

turns it harder to read and to maintain the

knowledge base and the application;

 A large set of code conventions must be learnt

by the developers. However, the language

interpreter is not capable to identify the misuse

of conventions. For instance, a code can be

syntactically correct, but convention mistakes

are not identified;

 The use of code conventions reduces the power

of code refactoring. As semantic is defined

using conventions, a refactoring can generate

bugs in the code. For instance, if a property

called age is refactored to personAge, a facet

named ageMinValue will not be automatically

refactored to personAgeMinValue.

To address the above disadvantages, the k-

annotation approach is proposed. It is detailed in the

next section.

3 K-ANNOTATION APPROACH

The discussed disadvantages can be reduced using

the k-annotations approach. Annotations reduce or

may eliminate the use of code conventions. This is

so because each annotation has a well defined role

and the related code is automatically generated by

the interpreter. Annotations are checked by the

interpreter and code conventions are not checked

(Piveta et al., 2007). Avoiding code convention

eliminates the problem of ambiguity related to the

role of properties and methods. Concepts, attributes,

facets, axioms and rules can be clearly identified in

the code.

The proliferation of auxiliary properties and

methods is reduced using annotations. Annotations

can be easily processed by a tool for generating code

and documentation.

The developer team does not need to use a large

set of code convention which is not verified by the

compiler. Annotations are validated by the language

interpreter. So, it helps the developer to avoid

mistakes.

The problem of code refactoring is reduced. For

instance, a facet to restrict the minimum value of a

property is defined using @FacetMinValue. If the

property is renamed, it does not affect the facet.

The K-Annotations process (Figure 1) starts

when a conceptual model (CM) specification is

received by the developer. It is necessary to

implement the specification in the OO using k-

annotations (Section 3.1). After implementing the

CM, the KA-processor tool verifies if the code

contains any mistake. When the KA-processor

detects some problem, it cancels the process of

annotation interpretation and it sends warnings to the

developer. If the code does not contain mistakes, the

KA-processor calls the KA-DocGen that generates

documentation for the CM model. The KA-DocGen

ICEIS 2009 - International Conference on Enterprise Information Systems

is provided to allow visual and textual comparisons

between the CM specification and the CM

implementation. Besides the documentation, the

KA-Processor generates the code necessary to

implement the semantic associated to an annotation.

The generated CM implementation by the KA-

Processor is interpreted with all code by the Java or

C# language processor and an executable CM

implementation is generated.



ExecutableCM

lementation

KA‐Processor

Java/C#Interpreter

CMimplementation

withcoderelatedto

OOCMimplementation

KA‐DocGen

CMdocumentation

forrevision

Isthe

codeok?

Yes

No

Sendwarnings to

developer.

Figure 1: K-Annotation Process.

3.1 K-Annotations

The set of annotations proposed clearly distinguishes

the CM elements in the OO implementation, which

contains other elements related to other

requirements. The k-annotations defined in Table 1

allow defining the following CM elements

(examples are presented in section 4):

 @Concept: it is used with a class declaration to

define that a class is a concept. The

interpretation of this annotations does not

directly generate code, but visually

distinguishes classes from concepts;

 @Attribute: defines that a property is an

attribute of a concept. The interpretation of

this annotation does not directly generate

code, but visually distinguishes properties

from attributes of a concept;

 @HasParts: defines the parts of a concept. Each

part is defined in a different class;

 @PartOf: defines that a concept is a part of

another concept. It must be used with the class

declaration. For instance, when this annotation

is declared as @PartOf(value=B.class) in a

class named A, the KA-Processor verifies if

there is a class constructor that contains a

parameter of type B. If it does not detect the

parameter of the specified type, it cancels the

interpretation process and it alerts the

developer;

 @FacetMinCardinality/MaxCardinality: these

annotations can be used to define the

cardinality of collections and thus also

relations;

 @Facet<Name>: all annotations whose names

start with Facet are based on the KBeans facet

catalog (Knublauch 2002, p. 109). Facets are

used to define restrictions over the valid

values of an attribute;

 @OnKnowledgeViolation: defines the class

that manages a runtime exception generated

by an event that violates a facet of an attribute.

For instance, during runtime, an attribute

could receive a null value, but a facet denies

null value for it. So, an exception must be

thrown to alert about the violation and this

allows repairing the invalid state. The

application should block all operations until

the repair of the invalid state;

 @Axiom: it can be used with concepts to define

expressions that always must be true. It

requires a parameter named value that

identifies the class that implements an axiom.

An axiom must be defined in the object level

using OO expressions, for instance, if-then-

else. This annotation can be used to create

custom facets;

 @Rule: it can be used with concepts to define

rules that are related to a concept. It requires a

parameter named value that identifies the class

that implements a rule. When the KA-

Processor detects this annotation, it modifies

all methods that modify attribute values to call

the rule instance after a modification of an

attribute value. It is necessary to invoke the

rule method after a value modification to

validate the state of the instance.

K-ANNOTATIONS - An Approach for Conceptual Knowledge Implementation using Metadata Annotations

Simple inheritance among concepts is directly

expressed using OO. It is not necessary to provide

an annotation with this purpose. Multiple inheritance

is not supported by OO, neither by this approach. To

verify if a concept is a super-type of another

concept, Java and C# offer reflection mechanisms

that provides this information.

Table 1: The K-Annotations for CM Implementation.

Annotation Role

@Concept(name = x) Identifies a concept.

@Attribute(name = y) Identifies a concept attribute.

@PartOf

(value=Element.class)

Defines that a class is a part of

Element.class.

@HasParts(values=’

…’)

Defines the parts of a concept.

@FacetNotNull Defines that an attribute value

can not be null.

@FacetDefaultValue

(value = x)

Defines the default value of an

attribute as x.

@FacetMinInclusive

@FacetMaxInclusive

(value = x)

Defines that an attribute value

must be greater/less or equal

than x.

@FacetMinExclusive

@FacetMaxExclusive

(value = x)

Defines that an attribute value

must be greater/less than x.

@FacetMinLength

@FacetMaxLength

(value = x)

Defines the minimal/maximum

length of a string.

@FacetFractionDigits

(value = x)

Defines the maximum length of

digits.

@FacetMaxCardinalit

@FacetMinCardinalit

y (value = x)

Defines the

maximum/minimum cardinality

of a collection.

@FacetValidClasses

@FacetInvalidClasses

Defines the classes that a

collection (does not) supports.

Parameters omitted.

@FacetPattern

(pattern = x)

Defines the string pattern x that

an attribute value must respect.

@FacetOrdered Defines that a collection must

be ordered.

@FacetDuplicateFree Defines that a collection must

not contain duplicated values.

@FacetValidValues

@FacetInvalidValues

Defines the valid/invalid values

of an attribute. Parameters

omitted.

@OnKnowledgeViola

tion(value =

Handler.class)

Defines the class that manages

the exception generated by an

event that violates a facet of an

attribute.

@Rule(value =

RuleImpl.class)

Defines the class that

implements a rule.

@Axiom(value =

AxiomImpl.class)

Defines the class that

implements an axiom.

3.2 KA-Processor: Code Generation

Tool

The KA-Processor tool validates the declaration of

k-annotations and it generates any code related to k-

annotations. This tool process the CM

implementation enriched with annotations. It adds

the necessary code to implement the expected

behaviour for each annotation. To comprehend this

section, it is necessary to bear in mind the concepts

pointcut and advice of Aspect Oriented Paradigm

(Kiczales et al., 2001). Pointcut is a point in a

software where a transversal functionality must be

invoked. For instance, when @FacetMinLength is

defined on a concept attribute, at this point, an

advice must be invoked. Advice is the additional

code necessary to implement an aspect. For instance,

the code that validates the length of a string.

The annotations @Concept and @Attribute do

not generate additional code. However, they are

mandatory to identify elements of the CM models.

Also, they are used to extract the model

documentation.

For annotations of facets, the KA-Processor

generates a pointcut that activates the advice related

to the defined facet. For instance, if the facet

@FacetPattern is used, before invoking the method

that defines the value of a string variable, the

pointcut is called to validate the pattern of the value.

This group of annotations is responsible for

constraint validations.

The annotation @HasParts is used by the tool to

generate validation code related to the method with

the signature addPart(Object part). This method

allows adding parts to its owner. So, part instances

can be directly accessed by the owner. It must

validate the class type of the parameter part. If the

class type is not declared in @PartOf, a knowledge

violation must be thrown by the method. Section 4

shows a detailed example.

The annotation @PartOf is used by the tool to

verify if the annotated class contains a constructor

with a single parameter. The class type of this

parameter must be the same type defined in the

annotation. If the constructor is not detected, the tool

alerts the developer. See section 4 for a detailed

example.

By using axioms, it is possible to define custom

facets. An axiom is declared with a class and the

processor tool generates a pointcut in each method

that modifies an attribute value. So, when a value

changes, all axioms are validated by invoking their

advices.

ICEIS 2009 - International Conference on Enterprise Information Systems

Rules can be linked to concepts using the

annotation @Rule. The KA-Processor tool generates

a pointcut in each method that modifies attributes

values. The advice is invoked after the modification

of the attribute value. For instance, if an attribute has

a value dependent of another attribute, when the

value of the later attribute changes, the advice must

be invoked.

The next section presents a case study using k-

annotations and the KA-Processor tool.

4 CASE STUDY

The following case study is initially presented on a

semi-formal specification based on CML (Schreiber

et al., 2000) of a conceptual model (Table 2). CML

is the language used by CommonKADS to build

knowledge models.

Table 2: Model of the concepts Sample and Identification.

Concept Sample

Is-a Object

Name string(40)

Concept Identification

Is-a Object

Part-of Concept Sample

Depth

real, range [0.0 - 9999.99]

Use string, list-of [Depositional, Diagenetic,

Ecologic, Provenance], MAX (3

occurrences)

Date date, (DD/MM/YYYY)

Table 3: Java implementation of the concept Sample.

Concept Sample

@Concept

@HasParts(values=Identification.class)

public interface Sample{

@Attribute(name = 'Name')

@FacetMinLength(value = 1)

@FacetMaxLength(value = 40)

@OnKnowledgeViolation(value =

SampleExceptionHandler.class)

String name;

addPart(Object part);

}

In this case study, only a small fraction of the

conceptual model is presented, the complete model

can be found in (Abel, 2001). This model is part of a

complex knowledge system for underground oil

reserves evaluation. After the presentation of the

model fragment (Table 2), an implementation in

Java using k-annotations is presented (Tables 3 and

4) and the results are evaluated.

The concept named Sample (Table 2) results in

the code defined in Table 3. It is possible to notice

that k-annotations can be declared in both Java/C#

interfaces and classes. The support for interfaces is

offered to increase the re-use of the model

implementation. The annotation @Concept is

mandatory to define that KA-Processor must process

any k-annotation declared in the class or interface.

Table 4: Java implementation of the concept

Identification.

Concept Identification

@Concept(name='Identification')

@PartOf(value=Sample.class)

@OnKnowledgeViolation(value =

MacroExceptionHandler.class)

public class Identification{

@Attribute(name='Depth')

@FacetMinInclusive(value = 0)

@FacetMaxInclusive(value = 9999.99)

@FacetNotNull

Float Depth;

@Attribute(name='Use')

@MaxCardinality(value = 3)

@FacetValidValues(values =

'Depositional, Diagenetic,

Ecologic, Provenance')

List<String> Use;

@Attribute(name='Date')

@FacetPattern(pattern =

'DD/MM/YYYY')

String date;

//Constructor

Identification(Sample owner);

Sample getOwner(){…}; //Parent

}

For identifying the parts of this concept,

@HasParts is used with the list of parts. This

annotation also requires the definition of a method

with the signature addPart(Object part). This

method is mandatory to allow the storage of parts of

Sample. When the mandatory method is not

identified, the KA-Processor alerts the developer.

The annotations @Attribute and @Facet<Function>

is used with properties (e.g.: name) and it identifies

attributes of a concept and its facets, respectively.

The annotation @OnKnowledgeViolation

identifies a class that manages the violation of one or

more facets. A class that manages knowledge

violations must contain a method with the signature

manageException (Map context). Variable context is

K-ANNOTATIONS - An Approach for Conceptual Knowledge Implementation using Metadata Annotations

a map that contains the instance of the class that

generated the exception and the value that violates

the facet. The map is offered to allow the developer

to manager or alert the user about the exception.

Standard method signatures are used instead of pre-

defined classes to avoid blocking the use of

inheritance by classes of the conceptual model. A

pre-defined abstract class would consume the single

inheritance offered by OO languages.

The concept named Identification (Table 2)

results in the code defined in Table 4. In this case, k-

annotations were used directly in a class declaration.

As Identification is a part of Sample, it used

@PartOf. When this annotation is used, it is

mandatory to define a constructor with a single

parameter. This class type of the parameter must be

the same as the part owner (e.g.: Sample). Also, the

method getOwner is implemented for obtaining the

instance of the owner from its parts.

It is possible to notice that

@OnKnowledgeViolation is defined with the class

declaration instead of with a property. When this

annotation is declared with a class, all knowledge

violations are managed by it. This functionality

avoids defining the same annotation multiple times

in the same class. Also, the facet @FacetPattern is

used with an attribute that is a string. This facet is

very useful to avoid errors related to string patterns,

for instance, the pattern of dates.

5 CONCLUSIONS

This paper presents an approach based on metadata

annotations for implementing the conceptual model

of a KS. The proposed approach defines a common

vocabulary and tools that can be shared among

multiples projects. Also, it is compatible with

multiple knowledge modelling languages.

The approach defines a standard path for the task

of implementing the conceptual model, so the

problems related to the use of ad-hoc solutions can

be reduced and even eliminated. This may help to

reduce the implementation time and improve the

reusability of conceptual knowledge models.

As future work, the CM model presented in

section 4 will be completely implemented using k-

annotations to identify important improvements to

this approach. In addition, the next step of this

research is to define connections between the CM

implementation based on k-annotations and the

implementation of the task model. A link between

both implementations can provide ways to develop

inferences machines based on the use of aspects.

Using aspects, redundant code for each inference

machine implementation could be reduced or

eliminated. The future investigation will focus on k-

aspects, an approach to build reusable inference

machines using the aspect oriented paradigm.

ACKNOWLEDGEMENTS

This work is supported by Finep and ENDEEPER

Co. that retails PETROLEDGE, the described KS.

REFERENCES

Abel, M 2001, ‘Estudo da perícia em petrografia

sedimentar e sua importância para a engenharia de

conhecimento’, PhD thesis, Universidade Federal do

Rio Grande do Sul.

Angele, J, Fensel, D, Landes, D & Studer, R 1998,

‘Developing Knowledge-Based Systems with MIKE’,

Automated Software Engg, vol. 5, no. 2, pp. 389-418.

Auer, S 2006, ‘Towards Agile Knowledge Engineering:

Methodology, Concepts and Applications’, PhD

thesis, University of Leipzig.

Castro, ESE, Victoreti, FI, Fiorini, SF, Abel, M & Price,

RT 2008, ‘Um Caso de Integração de Gerenciamento

Ágil de Projetos à Metodologia CommonKADS’, In

Proceedings of the 1st Workshop of Software Project

Management, Brazil, pp. 12-21.

Chalmeta, R & Grangel, R 2008, ‘Methodology for the

implementation of knowledge management systems’,

Journal of American Society for Information Science

and Technology, vol. 59, no. 5, pp. 742-755.

Fowler, M 1997, Analysis Patterns: Reusable Object

Models, Addison-Wesley, California.

Kiczales, G, Hilsdale, E, Hugunin, J, Kersten, M, Palm, J

& Griswold, W 2001, ‘An overview of AspectJ’, In

Proceedings of the 15th European Conference on

Object-Oriented Programming, UK, pp. 327-353.

Knublauch, H 2002, ‘An Agile Development

Methodology for Knowledge-Based Systems’, PhD

thesis, Universidade of Ulm.

Meseguer, P & Preece, A 1995, ‘Verification and

Validation of Knowledge-Based Systems with Formal

Specifications’, The Knowledge Engineering Review,

vol. 10, no. 4, pp. 331-343.

Piveta, E, Moreira, A, Pimenta, M, Araújo, J, Guerreiro, P

& Price, T 2007, ‘Avoiding Bad Smells in Aspect-

Oriented Software’, In Proceedings of the 19th

International Conference on Software Engineering

and Knowledge Engineering, USA, pp. 81-84.

Schreiber, G, Akkermans, H, Anjewierden, A, Hoog, RD,

Shadbolt, N, Velde, D & Wielinga, B 2000,

Knowledge Engineering and Management: The

CommonKADS Methodology, MIT Press, Cambridge.

Stephens, RT 2004, ‘Utilizing Metadata as a Knowledge

Communication Tool’, in Proceedings of IEEE

IPCC2004, UK, pp. 55-60.

ICEIS 2009 - International Conference on Enterprise Information Systems
