EVALUATION OF ANTHROPOMORPHIC USER INTERFACE

FEEDBACK IN AN EMAIL CLIENT CONTEXT AND

AFFORDANCES

Pietro Murano

, Amir Malik

and Patrik O’Brian Holt

School of Computing Science and Engineering, University of Salford, Gt. Manchester, M5 4WT, U.K.

Interactive Systems Research Group, School of Computing, The Robert Gordon University

St. Andrew Street, Aberdeen, AB25 1HG, Scotland

Keywords: Anthropomorphism, User interface feedback, Evaluation, Affordances.

Abstract: This paper describes an experiment and its results concerning research that has been going on for a number

of years in the area of anthropomorphic user interface feedback. The main aims of the research have been to

examine the effectiveness and user satisfaction of anthropomorphic feedback. The results are of use to all

user interface designers. Currently the work in the area of anthropomorphic feedback does not have any

global conclusions concerning its effectiveness and user satisfaction capabilities. This research is

investigating finding a way for reaching some global conclusions concerning this type of feedback. This

experiment, concerned the context of downloading, installing and configuring an email client which is part

of the domain of software for systems usage. Anthropomorphic feedback was compared against an

equivalent non-anthropomorphic feedback. The results indicated the anthropomorphic feedback to be more

effective and preferred by users. It was also the aim to examine the types of feedback in relation to

Affordances. The results obtained can be explained in terms of the Theory of Affordances.

1 INTRODUCTION

The user interface is one of the most important

aspects of any software system used by humans.

Badly designed user interfaces can lead to decreased

productivity, less profits for a company (due to

reduced productivity and more errors) and

frustration for the end users.

The aim of this research is to improve user

interface feedback and discover which methods may

be best. The authors are particularly investigating

the effectiveness and user satisfaction of

anthropomorphic feedback. To achieve this direct

comparisons are being made with non-

anthropomorphic feedback in an experimental

setting. Furthermore, the authors of this paper are

also trying to explain the results of conducted

experiments in terms of appropriate theories. One

such theory that is being investigated in conjunction

with the experimental results is the Theory of

Affordances.

Anthropomorphism at the user interface usually

involves some part of the user interface, taking on

some human quality (De Angeli, Johnson, and

Coventry, 2001). Some examples include a synthetic

character acting as an assistant or a video clip of a

human (Bengtsson, Burgoon, Cederberg, Bonito and

Lundeberg, 1999).

The area of anthropomorphic feedback has been

investigated for several years by various different

researchers. One aspect that is clear is that the

results available do not reveal an overall consistent

pattern. In some cases anthropomorphic feedback is

shown to be more effective and preferred by users

and in some cases the converse has been shown.

This is also shown in the work of Murano and his

collaborators (see Murano, 2002a, 2002b, 2003,

2005, Murano, Gee and Holt, 2007 and Murano, Ede

and Holt, 2008).

An example can be seen in a study by Moreno

Mayer and Lester (2000). The main thrust of their

experiment involved comparing anthropomorphic

and non-anthropomorphic information presented in

the context of tutoring about plant designs. Their

results suggested that the anthropomorphic

information was better for ‘transfer’ issues (i.e.

using the knowledge to solve new similar problems)

Murano P., Malik A. and O’Brian Holt P. (2009).

EVALUATION OF ANTHROPOMORPHIC USER INTERFACE FEEDBACK IN AN EMAIL CLIENT CONTEXT AND AFFORDANCES.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Human-Computer Interaction, pages 15-20

DOI: 10.5220/0001856000150020

 SciTePress

and better in terms of users’ having a more positive

attitude and inclination towards learning more about

plant designs.

However a contrasting example can be seen in a

study by Moundridou and Virvou (2002). They also

tested anthropomorphic information and equivalent

non-anthropomorphic information in the context of

algebra tutoring. They found no significant

differences to do with issues of effectiveness of the

feedback types. However they did find significant

differences in terms of user attitudes, where the

anthropomorphic feedback fostered better user

attitudes.

Also in the realm of the author’s work (Murano,

2002b, 2005), a study conducted in the context of

English as a foreign language pronunciation,

anthropomorphic and non-anthropomorphic

feedback types were compared. This experiment

indicated with significant results that the

anthropomorphic feedback was more effective and

preferred by users.

However in another experiment conducted by

the author (Murano et al, 2008) in the context of PC

building, comparing anthropomorphic and non-

anthropomorphic feedback, the results showed no

difference in terms of effectiveness. However there

was a marginal result showing the anthropomorphic

feedback to be preferred by users.

This brief review of some of the literature

indicates that the study of anthropomorphism as a

means of user interface feedback is incomplete.

While some of the differences in results could be

attributed to experimental design issues, some of the

differences could be attributed to issues of

affordances at the user interface.

The original Theory of Affordances (Gibson,

1979) has been extended by Hartson (2003) to cover

user interface aspects. Hartson identifies cognitive,

physical, functional and sensory affordances. He

argues that when a user is doing some computer

related task, they are using cognitive, physical and

sensory actions. Cognitive affordances involve ‘a

design feature that helps, supports, facilitates, or

enables thinking and/or knowing about something’

(Hartson, 2003). One example of this aspect

concerns giving feedback to a user that is clear and

precise. If one labels a button, the label should

convey to the user what will happen if the button is

clicked. Physical affordances are ‘a design feature

that helps, aids, supports, facilitates, or enables

physically doing something’ (Hartson, 2003).

According to Hartson a button that can be clicked by

a user is a physical object acted on by a human and

its size should be large enough to elicit easy

clicking. This would therefore be a physical

affordance characteristic. Functional affordances

concern having some purpose in relation to a

physical affordance. One example is that clicking on

a button should have some purpose with a goal in

mind. The converse is that indiscriminately clicking

somewhere on the screen is not purposeful and has

no goal in mind. Lastly, sensory affordances concern

‘a design feature that helps, aids, supports, facilitates

or enables the user in sensing (e.g. seeing, feeling,

hearing) something’ (Hartson, 2003). Sensory

affordances are linked to the earlier cognitive and

physical affordances as they complement one

another. This means that the users need to be able to

‘sense’ the cognitive and physical affordances so

that these affordances can help the user.

Therefore the remaining sections in this paper

will discuss the results of an unpublished experiment

and links will be made to the affordances as

identified by Hartson (2003).

2 EMAIL CLIENT EXPERIMENT

2.1 Aims

The aim of this experiment was to gather data

regarding effectiveness and user satisfaction in the

downloading, installing and configuring of an email

client context which is part of the domain of

software for systems usage. Specifically the aim was

to find out if anthropomorphic user interface

feedback fostered a better interaction experience

with fewer errors and therefore a better task

completion rate.

Two identical prototypes were developed with

only the feedback methods varying. The first had

textual feedback available and the second had

anthropomorphic feedback in the form of the MS

Agent Merlin character with voice and speech

bubbles. The system was built to identically emulate

the basic task of downloading, installing and

applying a basic configuration to the Kerio (2006)

email client.

Further, the authors were also interested to find

out if the user interfaces designed were appropriately

facilitating the affordances.

2.2 Users

 20 participants were used in the experiment.

These were selected by means of contacts at

local colleges and personal acquaintances.

 All the participants taking part in the study were

in the 18-40 age groups.

ICEIS 2009 - International Conference on Enterprise Information Systems

 Although gender was not the main issue of this

research, the participants were all adult males

and females.

 All the participants were novices in terms of

overall computing experience.

 All participants had downloaded software

from the Internet in the past, but had not

downloaded email clients. However most

participants had experienced difficulty with the

downloading and installation process.

2.3 Design

A between users design was used. The 20

participants were randomly assigned to one of the

two conditions being tested. Random allocation to

one of the two experimental groups was achieved by

alternately assigning an individual to one of the

groups.

2.4 Variables

The independent variable was the type of feedback,

(Textual instructions - Non-anthropomorphic and

MS Agent synthetic character – Anthropomorphic).

The dependent variables were the participants’

performance in carrying out the tasks and their

subjective opinions.

The dependent measures were that the

performance was measured by counting the number

of input errors made, the number of incorrect

selections, the number of requests for help, the

number of manifested participant hesitations – minor

or major in nature (A minor hesitation was of the

kind that involved a participant taking longer than

ten seconds to choose an option after having

obtained some feedback. A major hesitation was

when a participant was given some feedback and

then proceeded to not take any action at all) and

whether the participant completed a task. These

factors were then used in a scoring formula in order

to achieve a single score per participant (see note

below). The formula was devised because it was felt

that the factors of errors, hesitations and actually

completing the tasks, were related to overall success.

These factors were recorded by means of an

observation protocol.

The subjective opinions were measured by

means of a post-experiment questionnaire, which

included questions regarding the user interface and

the users’ experience etc.

(NOTE – The formula used was as follows:

 Each participant (unknown to them) was started

on ten points for each task.

 For every incorrect selection made, one point

was deducted. An example of this ‘error’ was

the participant not selecting the ‘next’ option to

begin the installation process.

 For every input error made, one point was

deducted. An example of this ‘error’ was the

participant not entering a password for the email

account.

 For every obvious minor (>ten seconds)

hesitation, e.g. taking longer than ten seconds to

make choose an option after having received

feedback, half a point was deducted.

 For every obvious major hesitation, e.g. the

participant being given some feedback and then

not acting on the feedback at all, one point was

deducted.

 For every help request made, one point was

deducted.

 If the participant completed a task correctly the

score was left as described above.

 If the participant did not complete a task a

further one and a half points were deducted to

give a final score.)

In the actual experiment no major hesitations

were observed and all participants completed the

task, therefore two elements of the formula

described above were not used in practice.

2.5 Apparatus and Materials

The equipment used for the experiment was: A

laptop running Windows XP and 448 Mb RAM, the

laptop’s own speakers and TFT display were used,

Microsoft Agent 2.0 ActiveX component and

Lernout and Hauspie TruVoice Text-To-Speech

engine. Lastly the prototype was engineered with

Visual Basic 6.

2.6 Procedure and Tasks

The first step was to recruit a suitable number of

participants particularly meeting the requirement of

being novices to computers, not having downloaded

and installed email clients in the past and if any

other software had been downloaded in the past that

some degree of difficulty had been experienced on

their part (see Users section above). The recruitment

process was achieved by the participants completing

a pre-experiment questionnaire. The questionnaire

had various questions which were mainly designed

to elicit prospective participants’ experience with

computers, the Internet and downloading and

installing software (including email clients).

Each participant was briefed with the same

information, i.e.: 1. A brief narrative regarding the

EVALUATION OF ANTHROPOMORPHIC USER INTERFACE FEEDBACK IN AN EMAIL CLIENT CONTEXT

AND AFFORDANCES

purpose of the experiment. 2. The purpose of the

experiment was not to test the participant. 3.

Participants should do their best to concentrate

whilst carrying out the tasks. 4. Each participant was

given an explanation regarding the type of feedback

they would be using. 5. Most of their interaction

would be mouse based. 6. Feedback would be given

by the system if the participant made any errors. 7.

Participants were asked if the instructions were clear

and if not, further (un-biasing) explanations were

given. The further instructions did not use leading

language which would have given clues on how to

complete the task. Also no specific examples were

used to further attempt better control on the matter.

8. A post-experiment questionnaire would need to be

completed at the end of the experiment. 9. It was

verbally made clear that if they wanted to leave at

any time, they could do so and if they did not want

their data to be used at the end of the experiment,

that this was their prerogative. Also data collected as

part of the experiment would be kept confidential.

10. Completing the whole experiment would mean

each participant would be entered into a prize draw

for a £20 Selfridges voucher.

Then the procedure described below was carried

out in the same way for all participants using the

same environment, equipment and

questionnaires/observation protocols. Each

participant was treated in the same manner. This was

all in an effort to control any confounding variables.

There was one basic global task with several

stages. This was to download, install and prepare an

email domain with the Kerio email client. The

following stages were required to complete the

overall global task:

1. Click the appropriate download link. 2.

Choose a folder for storing the downloaded file. 3.

Await the download process to complete. 4. Initiate

the installation process. 5. Choose the appropriate

language. 6. Await the file extraction process to

complete. 7. Read the welcome message and choose

proceed. 8. Read the licence information and choose

proceed. 9. Select a folder for the Kerio email client.

10. Select the install type. 11. Await the installation

process to complete. 12. Use the Kerio configuration

wizard to create an email domain. 13. Enter an email

domain. 14. Enter a user name. 15. Enter a

password. 16. Complete the installation.

The session was started by the system presenting

a small tutorial using the feedback mode of the

relevant condition. The tutorial explained what the

task was and gave instructions regarding what had to

be done if help was required during the carrying out

of the task.

Once the tutorial material had been received by

the participants the actual task was undertaken with

the appropriate feedback condition. The simulation

that was built, emulated the actual stages required

for the task. Therefore each stage of the interaction

was accompanied by either anthropomorphic or non-

anthropomorphic instructions (depending on

experimental condition) regarding what had to be

done to complete the stage and go on to the next

stage. The instructions were basically of the kind

which instructed the user on what had to be done,

e.g. choosing a ‘typical’ installation and clicking

next etc. During the carrying out of the task, each

participant was observed and data was recoded on

the appropriate observation protocol.

Lastly the participants were asked to complete a

post-experiment questionnaire regarding their

subjective opinions about the software.

2.7 Results

The data was analysed using a multifactorial

analysis of variance (MANOVA) and when

significance was found, the particular issues were

then subjected to post-hoc testing using in all cases

either t-tests or Tukey HSD tests. The following

significant results were observed (NB: DF = Degrees

of Freedom, SS = Sum of Squares, MSq = Mean

Square):

For the variables ‘total score’ and ‘group’, there

is a significant (p < 0.05) difference. The

anthropomorphic group scored significantly higher

scores than the non-anthropomorphic group, with an

F-ratio of 4.87*. Table 1 shows the F Table:

Table 1: MANOVA, total score/group.

Source DF SS MSq F Ratio

Model 2 5.63 2.81 4.87

Error 17 9.81 0.58 Prob > F

C. Total 19 15.44 0.02

For the variables ‘Understandable UI feedback’

and ‘group’, there is a significant (p < 0.05)

difference. The anthropomorphic group felt that the

user interface feedback was significantly more

understandable when compared to the non-

anthropomorphic group, with an F-ratio of 3.83*.

Table 2 shows the F Table:

Table 2: MANOVA, understandable feedback/group.

Source DF SS MSq F Ratio

Model 2 1.80 0.90 3.83

Error 17 4.00 0.24 Prob > F

C. Total 19 5.80 0.04

ICEIS 2009 - International Conference on Enterprise Information Systems

For the variables ‘Sufficient UI Feedback’ and

‘group’, there is a significant difference. The

anthropomorphic group felt that the user interface

feedback was significantly (p < 0.01) more sufficient

compared to the non-anthropomorphic group, with

an F-ratio of 10.37**. Table 3 shows the F Table:

Table 3: MANOVA, sufficient feedback/group.

Source DF SS MSq F Ratio

Model 2 2.50 1.25 10.37

Error 17 2.05 0.12 Prob > F

C. Total 19 4.55 0.001

For the variables ‘Friendly UI Feedback’ and

‘group’, there is a significant (p < 0.01) difference.

The anthropomorphic group felt that the user

interface feedback was significantly more friendly

compared to the non-anthropomorphic group, with

an F-ratio of 20.40***. Table 4 shows the F Table:

Table 4: MANOVA, friendly feedback/group.

Source DF SS MSq F Ratio

Model 2 7.20 3.60 20.40

Error 17 3.00 0.18 Prob > F

C. Total 19 10.20 <.0001

For the variables ‘UI Feedback not Intimidating’

and ‘group’, there is a significant (p < 0.01)

difference. The anthropomorphic group felt that the

user interface feedback was significantly less

intimidating compared to the non-anthropomorphic

group, with an F-ratio of 41.00***. Table 5 shows

the F Table:

Table 5: MANOVA, not intimidating feedback/group.

Source DF SS MSq F Ratio

Model 2 4.10 2.05 41.00

Error 17 0.85 0.05 Prob > F

C. Total 19 4.95 <.0001

For the help’ and ‘group’, there is a significant

(p < 0.01) difference. The anthropomorphic group

felt that the help given was significantly more

friendly compared to the non-anthropomorphic

group, with an F-ratio of 18.94***. Table 6 shows

the F Table:

Table 6: MANOVA, friendly help/group.

Source DF SS MSq F Ratio

Model 2 11.70 5.85 18.94

Error 17 5.25 0.31 Prob > F

C. Total 19 16.95 <.0001

For the variables ‘friendly error info’ and

‘group’, there is a significant (p < 0.01) difference.

The anthropomorphic group felt that the error

information given was significantly more friendly

compared to the non-anthropomorphic group, with

an F-ratio of 9.13**. Table 7 shows the F Table:

Table 7: MANOVA, friendly errors/group.

Source DF SS MSq F Ratio

Model 2 6.50 3.25 9.13

Error 17 6.05 0.36 Prob > F

C. Total 19 12.55 0.0020

2.8 Discussion of Results

The clearest result shows that the anthropomorphic

feedback was more effective for the global task of

downloading, installing and preparing an email

domain with the Kerio email client. The scores

achieved in the task were significantly higher in the

anthropomorphic condition.

As expected the perceptions of participants in the

anthropomorphic condition tended to be more

positive about the system. They clearly found the

task easier to complete and therefore had more

positive perceptions about the system. Specifically

they felt that the feedback was more understandable,

sufficient, friendly and less intimidating. Also the

anthropomorphic group felt that the help was more

friendly and that the error information was more

friendly in nature. The suggestion is that a higher

success rate in a task can elicit more positive

perceptions about a system.

Overall the results suggest that in the specific

context of downloading, installing and preparing an

email domain, the anthropomorphic feedback was

more effective and fostered more user satisfaction.

3 THE EXPERIMENT AND

AFFORDANCES

This experiment had results where the

anthropomorphic Merlin character condition was

significantly more effective and significantly more

satisfying for the participants. The anthropomorphic

condition had the Merlin character utter explanatory

speech, which was also displayed in speech bubbles

on the screen. The textual non-anthropomorphic

condition had the same text displayed in text boxes.

The difference in display design was that the text

boxes in the non-anthropomorphic condition were

not placed close to the area on the screen that they

were attempting to explain – compared to the

anthropomorphic condition. The result of this could

have been that the cognitive affordances would have

been negatively affected with respect to the

EVALUATION OF ANTHROPOMORPHIC USER INTERFACE FEEDBACK IN AN EMAIL CLIENT CONTEXT

AND AFFORDANCES

facilitation of the participant ‘knowing’ or ‘thinking’

appropriately about accomplishing the tasks. Further

the sensory affordances would have also been

affected and not provided the appropriate support for

the cognitive affordances. This could have happened

because part of the explanations for the download,

installation and configuring of the email client

involved completing form based aspects as part of

an on-screen dialogue. If the text boxes were not

close enough to the area requiring the interaction,

the sensory affordance concerning ‘seeing’ could

have been also negatively affected and therefore not

supported appropriately the cognitive affordance

aspect. The physical affordances in this experiment

tended to be the fields and buttons of the email client

dialogue, which were used by the participants with

the keyboard and mouse. These were the same under

both conditions and should therefore not have

affected matters either way. The functional

affordances should therefore not have been affected

either, as the experiment aimed to ‘explain’ or guide

the user through the various steps of the field filling

and dialogue stages. The actual results of the

statistical analysis give some support to this

argument because the participants in the non-

anthropomorphic condition significantly perceived

the feedback to be less understandable, insufficient,

less friendly and more intimidating. Lastly this

group achieved significantly lower performance

scores compared to the anthropomorphic group.

These aspects do suggest that due to the textual

instructions being laid out onto the screen in the

manner described, could have negatively affected

the various strands of affordances.

4 CONCLUSIONS

As has been considered in this paper, the study of

anthropomorphic feedback is still incomplete.

Various researchers have obtained disparate sets of

results with unclear reasons for these. However, the

authors of this paper, suggest that potentially the

issues of whether anthropomorphic feedback is more

effective and preferred by users, is strongly linked

with how the affordances are dealt with at the user

interface. This aspect could also provide a reason

regarding why there are so many disparate sets of

results in the wider research community, concerning

anthropomorphic feedback. Further, the principal

author of this paper is continuing to investigate these

issues and the affordances in light of other work by

the principal author of this paper and work of the

wider research community.

REFERENCES

Bengtsson, B, Burgoon, J. K, Cederberg, C, Bonito, J, and

Lundeberg, M. (1999) The Impact of

Anthropomorphic Interfaces on Influence,

Understanding and Credibility. Proceedings of the

32nd Hawaii International Conference on System

Sciences, IEEE.

De Angeli, A, Johnson, G. I. and Coventry, L. (2001) The

Unfriendly User: Exploring Social Reactions to

Chatterbots, Proceedings of the International

Conference on Affective Human Factors Design,

Asean Academic Press.

Gibson, J. J. (1979) The Ecological Approach to Visual

Perception, Houghton Mifflin Co.

Hartson, H. R. (2003) Cognitive, Physical, Sensory and

Functional Affordances in Interaction Design,

Behaviour and Information Technology, Sept-Oct

2003, 22 (5), p.315-338.

Kerio (2006) http://www.kerio.co.uk/ Accessed 2008.

Moundridou, M. and Virvou, M. (2002) Evaluating the

Persona Effect of an Interface Agent in a Tutoring

System. Journal of Computer Assisted Learning, 18, p.

253-261. Blackwell Science.

Moreno, R., Mayer, R. E. and Lester, J. C. (2000) Life-

Like Pedagogical Agents in Constructivist Multimedia

Environments: Cognitive Consequences of their

Interaction. ED-MEDIA 2000 Proceedings, p. 741-

746. AACE Press.

Murano, P, Ede, C. and Holt, P. O. (2008) Effectiveness

and Preferences of Anthropomorphic User Interface

Feedback in a PC Building Context and Cognitive

Load. 10

International Conference on Enterprise

Information Systems, Barcelona, Spain, 12-16 June,

2000 - INSTICC.

Murano, P, Gee, A. and Holt, P. O. (2007)

Anthropomorphic Vs Non-Anthropomorphic User

Interface Feedback for Online Hotel Bookings, 9th

International Conference on Enterprise Information

Systems, Funchal, Madeira, Portugal, 12-16 June 2007

- INSTICC.

Murano, P. (2005) Why Anthropomorphic User Interface

Feedback Can be Effective and Preferred by Users, 7th

International Conference on enterprise Information

Systems, Miami, USA, 25-28 May 2005. INSTICC.

Murano, P. (2003) Anthropomorphic Vs Non-

Anthropomorphic Software Interface Feedback for

Online Factual Delivery, 7th International Conference

on Information Visualisation, London, England, 16-18

July 2003, IEEE.

Murano, P. (2002a) Anthropomorphic Vs Non-

Anthropomorphic Software Interface Feedback for

Online Systems Usage, 7th European Research

Consortium for Informatics and Mathematics

(ERCIM) Workshop - 'User Interfaces for All' -

Special Theme: 'Universal Access'. Paris(Chantilly),

France 24,25 October 2002. Published in Lecture

Notes in Computer Science - Springer.

Murano, P. (2002b) Effectiveness of Mapping Human-

Oriented Information to Feedback From a Software

Interface, Proceedings of the 24th International

Conference on Information Technology Interfaces,

Cavtat, Croatia, 24-27 June 2002.

ICEIS 2009 - International Conference on Enterprise Information Systems
