Checking Inherently Fair Linear-Time Properties in a

Non-Na

¨

ıve Way

?

Thierry Nicola, Frank Nießner and Ulrich Ultes-Nitsche

Department of Computer Science, University of Fribourg

Boulevard de P

´

erolles 90, CH-1700 Fribourg, Switzerland

Abstract. In [9], an alternative veriﬁcation relation for linear-time properties is

introduced which uses an inherent fairness condition. That relation is speciﬁcally

tailored to the veriﬁcation of distributed systems under a relaxed version of strong

fairness. We will call it the inherently fair linear-time veriﬁcation relation in this

paper, or IFLTV relation for short. We present an analysis of the mathematical

structure of the IFLTV relation, which enables us to obtain an improved non-

na

¨

ıve procedure for checking the IFLTV relation.

1 Introduction

The results of [9] yield an immediate procedure for checking the satisfaction of the

IFLTV relation on B

¨

uchi automata describing the behavior of a system and a linear-time

property, respectively. We refer to that procedure as the na

¨

ıve procedure. Even though

the IFLTV relation is practically applicable as it comes with an abstraction concept

based on so-called weakly continuation-closed abstractions [9], which can be computed

efﬁciently from trace reductions of the automaton representing the behavior [10, 12], the

na

¨

ıve procedure for checking the IFLTV relation is sub-optimal and somehow limiting

the applicability of the entire veriﬁcation approach.

In this paper we analyze the IFLTV relation and apply the results to the structure

of the involved automaton representations of system behavior and property. By doing

so we deﬁne a procedure for checking IFLTV which requires fewer computation steps

than the na

¨

ıve one. This procedure is the main result of this paper and we will refer it

as being the non-na

¨

ıve procedure.

This paper is structured as follows: Sect. 2 gives a very brief motivation for the

deﬁnition of the IFLTV relation; more motivating information can be found in [9]. Af-

ter introducing some preliminary concepts in Sect. 3, we deﬁne in Sect. 4 the IFLTV

relation formally. In Sect. 5, the IFLTV relation is analyzed to the extent that we can

construct from it an IFLTV checking procedure for automaton representations of be-

havior and property in Sect. 6, analyzing its correctness in Sect. 7 and discussing its

complexity in Sect. 8. Finally Sect. 9 concludes the paper.

?

Supported by the Swiss National Science Foundation under grant # 200021-103985/1 and by

the Hasler Foundation under grant # 1922.

Nicola T., Nießner F. and Ultes-Nitsche U. (2008).

Checking Inherently Fair Linear-Time Properties in a Non-Näıve Way.

In Proceedings of the 6th International Workshop on Modelling, Simulation, Veriﬁcation and Validation of Enterprise Information Systems, pages 49-58

DOI: 10.5220/0001736600490058

Copyright

c

SciTePress

2 Motivation

Assume two systems, both randomly selecting initially an unbounded positive integer

n. The ﬁrst system will operate n steps and then stop. The second system will either

operate n steps and stop, or may decide nondeterministically to operate forever. Only in-

ﬁnitely long observations could distinguish the two systems, which are apparently prac-

tically impossible. So, system one is as good as system two from the point of view of

an outside observer. Linear-time veriﬁcation, however, distinguishes the two systems as

the second system does not satisfy the property ‘always performing only ﬁnitely many

operations’ where the ﬁrst one does. Besides being insensitive to such differences re-

quiring inﬁnite observations, IFLTV is as powerful as the usual linear-time veriﬁcation

relation. The two veriﬁcation relations coincide, for instance, in safety properties [9]

and differ only in liveness properties [2]. We consider IFLTV the more practical veri-

ﬁcation relation, as it is related to only those differences in system behavior which can

practically (in a ﬁnite amount of time) be observed.

Consider the following abstract model of a server, see Fig. 1a. If the server resource

is free, the server reacts to a request by an internal event yes, followed by sending

result, but if the resource is locked, then a request is rejected by the server. A desired

property of a server is that it eventually returns a result. This property can be expressed

by the automaton in Fig. 1b. However, our model does not satisfy this property using the

classical linear-time veriﬁcation relation, see for instance [14, 13], because the model,

and any reasonable model of such a system, contains the extreme execution scenario

in which whenever a request is made the resource is locked. In our model, for instance

lock · (request · no · reject)

ω

is such a behavior violating the linear-time satisfaction

of the property. However, such a behavior is highly unfair, and such extreme executions

are normally ignored by using an explicit fairness assumption restricting the allowed

executions of the system. In our example assuming strong fairness [6] would do the

job. For linear-time satisfaction it is therefore necessary to add such an explicit fairness

condition.

2 Motivation

Assume two systems, both randomly selecting initially an unbounded positive integer

n. The ﬁrst system will operate n steps and then stop. The second system will either

operate n steps and stop, or may decide nondeterministically to operate forever. Only in-

ﬁnitely long observations could distinguish the two systems, which are apparently prac-

tically impossible. So, system one is as good as system two from the point of view of

an outside observer. Linear-time veriﬁcation, however, distinguishes the two systems as

the second system does not satisfy the property ‘always performing only ﬁnitely many

operations’ where the ﬁrst one does. Besides being insensitive to such differences re-

quiring inﬁnite observations, IFLTV is as powerful as the usual linear-time veriﬁcation

relation. The two veriﬁcation relations coincide, for instance, in safety properties [9]

and differ only in liveness properties [2]. We consider IFLTV the more practical veri-

ﬁcation relation, as it is related to only those differences in system behavior which can

practically (in a ﬁnite amount of time) be observed.

Consider the following abstract model of a server, see Fig. 1a. If the server resource

is free, the server reacts to a request by an internal event yes, followed by sending

result, but if the resource is locked, then a request is rejected by the server. A desired

property of a server is that it eventually returns a result. This property can be expressed

by the automaton in Fig. 1b. However, our model does not satisfy this property using the

classical linear-time veriﬁcation relation, see for instance [14, 13], because the model,

and any reasonable model of such a system, contains the extreme execution scenario

in which whenever a request is made the resource is locked. In our model, for instance

lock · (request · no · reject)

ω

is such a behavior violating the linear-time satisfaction

of the property. However, such a behavior is highly unfair, and such extreme executions

are normally ignored by using an explicit fairness assumption restricting the allowed

executions of the system. In our example assuming strong fairness [6] would do the

job. For linear-time satisfaction it is therefore necessary to add such an explicit fairness

condition.

result

lock

free

free

reject request

lock

request

lock

reject

free

yes

no

s

0

s

1

s

2

s

3

s

4

s

5

s

6

(a) Server

p

0

p

1

Σ

Σ

result

(b) Property

Fig. 1: An abstract server model and a property automaton.

Fig. 1. An abstract server model and a property automaton.

Applying IFLTV frees one from the need of ﬁnding an explicit fairness constraint

on the system model by having the fairness assumption inherently in the veriﬁcation

relation’s deﬁnition. Therefore, not having to deal with fairness explicitly, can make

IFLTV quite useful in practice.

50

3 Preliminaries

We assume the reader is familiar with the most common notions of formal languages

and automata theory [8, 11]. For a ﬁnite set of system events Σ, let Σ

∗

be the set of all

ﬁnite strings over Σ, let Σ

ω

be the set of all inﬁnite strings, and let Σ

∞

= Σ

∗

∪ Σ

ω

.

A language is a set L ⊆ Σ

∞

.

Let L be a language. Then the set of all ﬁnite preﬁxes of L is pre(L) = {w ∈

Σ

∗

|∃x ∈ Σ

∞

: wx ∈ L}. The continuation of w ∈ pre(L) in language L is

cont(w, L) = {x ∈ Σ

∞

|wx ∈ L}, and the set of all events en(w, L) which are

enabled in L after event sequence w occured is en(w, L) = pre(cont(w, L)) ∩ Σ.

Let A = (Q, Σ, δ, q

0

, F ) be a ﬁnite automaton, where Q is a ﬁnite set of states,

Σ is a ﬁnite set of symbols, q

0

∈ Q is the initial state, F ⊆ Q is a set of ﬁnal states,

and δ : Q × Σ → 2

Q

is a transition relation. If δ(q, a) 3 p then we call (q, a, p) a

transition. For the rest of this paper, we assume the transition relation to be extended to

δ : 2

Q

× Σ

∗

→ 2

Q

in the usual way.

Let w = α

1

α

2

. . . ∈ Σ

ω

be an inﬁnite string. A run of automaton A on w is a

sequence ρ(w) = r

0

r

1

. . ., such that r

i+1

∈ δ(r

i

, α

i+1

) for i ≥ 0. A run is called

successful if r

0

= q

0

and ω(ρ(w)) ∩ F 6= ∅ where ω(ρ(w)) is the set of all states

that occur inﬁnitely often in ρ(w). Automaton A B

¨

uchi-accepts w if there is a suc-

cessful run of A on w. The inﬁnite-string language accepted by B

¨

uchi automaton A is

L(A ) = {w ∈ Σ

ω

|A B

¨

uchi-accepts w}[3].

A state q ∈ Q of the automaton A is said to be reachable if there exists a path

from q

0

to q in A . A state q ∈ Q of A is said to be co-reachable if there exists a run

ρ(w) = q

1

q

2

. . . of A on some inﬁnite string w such that q

1

= q and ω(ρ(w))∩F 6= ∅.

The behavior of a system and the properties are sets of inﬁnitely long event se-

quences over Σ. We consider here behaviors and properties which can be represented by

B

¨

uchi automata. A behavior B satisﬁes the linear-time property P (written: ‘B |= P ’)

if and only if B ⊆ P . The satisfaction relation deﬁned in this way is called linear-time

satisfaction relation. It follows that B ∩P = B is an equivalent deﬁnition of linear-time

satisfaction, since B can only be a subset of P if B = B ∩ P .

Throughout this paper, let P be a property and P = (Q

P

, Σ, δ

P

, q

P

, F

P

) be a B

¨

uchi

automaton such that L(P) = P , and let B be a behavior and B = (Q

B

, Σ, δ

B

, q

B

, F

B

)

be a B

¨

uchi automaton such that L(B) = B. An additional requirement for automaton

B is that all its states are accepting states, in other words F

B

= Q

B

,

1

and it can

therefore be assumed to be deterministic.

4 The IFLTV Relation and its Na

¨

ıve Checking Procedure

Instead of demanding B = B ∩ P as in the linear-time satisfaction relation, the deﬁ-

nition of the IFLTV relation is obtained by relaxing the deﬁnition, requiring only that

ﬁnite preﬁxes of B have to equal the ﬁnite preﬁxes of B ∩ P . Thus, we deﬁne IFLTV

as

B satiﬁes P inherently fairly ⇔ pre(B) = pre(B ∩ P ). (1)

1

The behavior is the Eilenberg-limit of a preﬁx-closed regular language, which immediately

implies that the corresponding B

¨

uchi automaton contains only accepting states.

51

Because pre(B ∩ P ) ⊆ pre(B) always holds (since B ∩ P ⊆ B), we can reﬁne the

above deﬁnition to

B satiﬁes P inherently fairly ⇔ pre(B) ⊆ pre(B ∩ P ). (2)

Informally, this deﬁnition states that a behavior satisﬁes a property inherently fairly, if

and only if all ﬁnite behaviors can be continued to an inﬁnite behavior satisfying the

property. This observation, written more formally, gives us another way of representing

the IFLTV relation:

B satiﬁes P inherently fairly ⇔ ∀v ∈ pre(B) : ∃x ∈ cont(v, B) : vx ∈ P. (3)

Formal proofs of the equivalence of the above-mentioned deﬁnitions can be found

in [9]. If B satisﬁes P inherently fairly, we write ‘B P ’.

The second condition of checking whether or not pre(B) ⊆ pre(B ∩ P ) is equiv-

alent to checking whether or not pre(B) ∩ Σ

∗

\ pre(B ∩ P ) = ∅. Therefore we can

check the IFLTV relation na

¨

ıvely by (note that the following automata are interpreted

as B

¨

uchi or ﬁnite-string automata as appropriate):

1. Computing the product of B and P and reducing it if necessary (yielding B ∩ P ).

2. Changing all states in the resulting automaton to be ﬁnal states (yielding pre(B ∩

P ))

3. Determinizing this automaton, making it complete, and interchanging ﬁnal and

non-ﬁnal states (yielding the complement automaton Σ

∗

\ pre(B ∩ P )).

4. Computing the product of the resulting automaton and B (yielding pre(B) ∩ (Σ

∗

\

pre(B ∩ P ))).

5. Checking whether or not the resulting automaton is empty (yielding the test pre(B)∩

(Σ

∗

\ pre(B ∩ P )) = ∅).

5 Checking Whether Linear-Time Properties are Satisﬁed

Inherently Fairly

With the help of some auxiliary lemmas, we will prove that the IFLTV relation can be

represented by the following conditions on a behavior B and a property P (the result is

stated in Corollary 2):

1. ∀v ∈ pre(B) : en(v, B) ∩ en(v, P ) = en(v, B) and

2. ∀v ∈ (pre(B) ∩ pre(P )) : cont(v, B ∩ P ) 6= ∅.

So checking IFLTV can be reduced to checking enabled conditions of individual

events in the behavior and the property (ﬁrst condition), and checking the possible con-

tinuation of ﬁnite behaviors in the correct sub-behavior B ∩ P of behavior B (second

condition).

We ﬁrst prove that IFLTV implies the following subset condition.

Lemma 1. B P ⇒ pre(B) ⊆ pre(P ).

52

Proof. Let v ∈ pre(B). Then, by deﬁnition of “”, there is a w ∈ cont(v, B) such that

vw ∈ P . Hence v ∈ pre(P ). ut

We prove now that the subset condition is equivalent to the enabling condition we

want to show for the IFLTV relation.

Lemma 2. pre(B) ⊆ pre(P ) ⇔ ∀v ∈ pre(B) : en(v, B) ∩ en(v, P ) = en(v, B).

Proof. “⇒”: Let v ∈ pre(B) and let a ∈ en(v, B). Then va ∈ pre(B) and hence, by

Lemma 1, va ∈ pre(P ), implying a ∈ en(v, P ). Thus en(v, B) ⊆ en(v, P ), implying

en(v, B) ∩ en(v, P ) = en(v, B).

“⇐”: Let v ∈ pre(B) and let a ∈ en(v, B). Because en(v, B) ∩ en(v, P ) =

en(v, B), we get a ∈ en(v, P ). Therefore va ∈ pre(P ) and consequently v ∈ pre(P ).

Hence pre(B) ⊆ pre(P ). ut

Lemmas 1 and 2 together result in the following corollary:

Corollary 1. B P ⇒ ∀v ∈ pre(B) : en(v, B) ∩ en(v, P ) = en(v, B).

To complete the prove in one direction, it remains to show that the second condition is

a consequence of the IFLTV relation, too.

Lemma 3. B P ⇒ ∀v ∈ (pre(B) ∩ pre(P )) : cont(v, B ∩ P ) 6= ∅.

Proof. Let v ∈ (pre(B) ∩ pre(P )). Then in particular v ∈ pre(B). Then, by deﬁnition

of “”, there exist w ∈ cont(v, B) such that vw ∈ P . Hence vw ∈ B ∩ P , or equiva-

lently: w ∈ cont(v, B ∩ P ). Therefore cont(v, B ∩ P ) is not empty. ut

Having shown that the two conditions stated at the beginning of this section are a

consequence of the IFLTV relation, it remains to show that the two conditions together

also imply the IFLTV relation.

Lemma 4. Conditions

1. ∀v ∈ pre(B) : en(v, B) ∩ en(v, P ) = en(v, B) and

2. ∀v ∈ (pre(B) ∩ pre(P )) : cont(v, B ∩ P ) 6= ∅.

imply B P.

Proof. Rewriting ∀v ∈ (pre(B) ∩ pre(P )) : cont(v, B ∩ P ) 6= ∅ yields

∀v ∈ (pre(B) ∩ pre(P )) : ∃w ∈ cont(v, B) : vw ∈ P. (4)

From ∀v ∈ pre(B) : en(v, B) ∩ en(v, P ) = en(v, B), taking into account Lemma 2,

we get pre(B) ⊆ pre(P ), implying pre(B) ∩ pre(P ) = pre(B). Then, substituting

pre(B) for pre(B) ∩ pre(P ) in Equation (4) yields ∀v ∈ pre(B) : ∃w ∈ cont(v, B) :

vw ∈ P , which is just the deﬁnition of B P . ut

Summarizing the previous results, we establish a main result of this paper, which

we will use to construct a non-na

¨

ıve checking procedure for the IFLTV relation.

Corollary 2. B P if and only if

1. ∀v ∈ pre(B) : en(v, B) ∩ en(v, P ) = en(v, B)

2. ∀v ∈ (pre(B) ∩ pre(P )) : cont(v, B ∩ P ) 6= ∅.

Proof. This corollary follows immediately from Corollary 1 and Lemmas 3 and 4. ut

53

6 The Non-Na

¨

ıve IFLTV Procedure

Both the behavior and the property are speciﬁed by automata. Since it is neccessary

to decide a subset condition on the intersection of these languages, we consider an

automaton A

B∩P

which accepts B∩P in order to check the IFLTV relation. So initially,

we construct the automaton A

B∩P

and throughout this construction, we check whether

for all preﬁxes of the behavior the enabled actions in the behavior are enabled actions in

the property as well, i.e., we check for a potential violation of the ﬁrst condition given

in Corollary 2. If this condition is violated, the construction immediately aborts with

the result pre(B ) 6⊆ pre(B ∩ P ), i.e. B does not satisfy P inherently fairly. Otherwise

the construction succeeds and we obtain the automaton A

B∩P

. During the reduction of

A

B∩P

, we verify the second condition of Corollary 2.

For the purpose of checking the conditions of Corollary 2 we compute in parallel,

during the construction of A

B∩P

, sets of states of the property automaton. These sub-

sets correspond to the states of a ‘determinized’ version of P . They indicate whether

or not Corollary 2 is violated.

Let B = (Q

B

, Σ, δ

B

, q

0

, Q

B

) be the deterministic behavior automaton (recall that

behavior automata are always deterministic) and P = (Q

P

, Σ, δ

P

, p

0

, F

P

) be the

property automaton (potentially nondeterministic). Then

A

B∩P

= (Q

B

× Q

P

, Σ, δ, (q

0

, p

0

), Q

B

× F

P

),

where δ is deﬁned by:

δ((u, r), a) 3 (v, s) ⇔

δ

B

(u, a) = v and δ

P

(r, a) 3 s, ∀u, v ∈ Q

B

, r, s ∈ Q

P

, a ∈ Σ.

We construct A

B∩P

stepwise starting with the initial state (q

0

, p

0

) and proceed as fol-

lows: Let (q, r) be a state of A

B∩P

not yet considered (at the beginning, there is just

the state (q

0

, p

0

)). Now, for every transition (q, a, p) of B and every matching transition

(r, a, s) of P we add the transition ((q, r), a, (p, s)) to A

B∩P

. If (p, s) is not yet a state

of A

B∩P

, we add it as well. If there exists no transition in (q, r) matching (q, a, p) and

furthermore, there is no alternative state (q, r

0

) in A

B∩P

with a matching transition,

then we abort, because in that case there exists a v ∈ pre(B ) such that v 6∈ pre(B ∩ P ),

to wit B 6 P . Here, an alternative state (q, r

0

) is a state that can be reached by the

same v ∈ Σ

∗

which passes A

B∩P

into (q, r). Due to the determinism of the behavior

automaton, the ﬁrst component of each state that represents an alternative to state (q, r)

must still be q. Thus, we just have to collect the set of states of P that may occur in

the second entry, i.e., we maintain sets R

q

⊆ 2

Q

P

such that r

0

∈ R

q

if and only if there

exists a state (q, r

0

) in A

B∩P

which is an alternative to (q, r). Of course, the set which

corresponds to the state q

0

is initially {{p

0

}}

q

0

.

There are two possible termination scenarios: Either no more states and transitions

can be added, then the construction of the product automaton A

B∩P

is completed, or

we may have aborted the construction since we know already that B does not satisfy P

inherently fairly.

To check the second condition of Corollary 2, we remove from A

B∩P

all states

that are not co-reachable. The resulting automaton is denoted by A

B∩P,red

. Note that

54

due to our construction, each state in A

B∩P

is reachable. Detection of states which are

not co-reachable can be performed by using a combination of standard algorithms that

determine the strongly connected components of the transition graph of A

B∩P

and stan-

dard algorithms that reduce ﬁnite automata (see, for instance, [1, 5]). Now assume the

algorithm has determined the set of useless

2

states and has removed each of its elements

from A

B∩P

. Thus, after the reduction process, each state of A

B∩P,red

is reachable by

a v ∈ Σ

∗

such that cont(v, B ∩ P ) 6= ∅.

The last step of our IFLTV algorithm consists of updating the sets R

q

of sets of

states of P that are attached to each state of A

B∩P

. Of course, if a set R

q

contains

r

0

such that (q, r

0

) has been identiﬁed to be useless, then we have to remove r

0

from

each set in R

q

since (q, r

0

) no longer represents an alternative state. Now, if during

this deletion process a set R

q

of second-component-states becomes empty, we have

identiﬁed a v ∈ (pre(B )∩pre(P )) such that cont(v, B ∩ P ) = ∅, violating Corollary 2

and thus B 6 P . Otherwise, the reduction step terminates and all state sets R

q

contain

at least one state. Then we have B P .

7 Correctness of the Construction

Given automata that accept the behavior B and the property P respectively, we ap-

ply the usual product construction to obtain the automaton A

B∩P

which accepts the

intersection B ∩ P . Note that the computation of the sets R

q

of alternative second com-

ponents of states in A

B∩P

does affect in no way the ﬁnal product automaton A

B∩P

but

rather is supplementary. Hence L(A

B∩P

) = B ∩ P .

Mainly, we will prove that our construction implements accurately the two condi-

tions of Corollary 2 and for this reason veriﬁes correctly whether or not B satisﬁes P

inherently fairly. So we verify ﬁrst

Theorem 1. For all v ∈ pre(B ): en(v, B)∩en(v, P ) = en(v, B) ⇔ The construction

of A

B∩P

succeeds.

Proof. “⇒” To each v ∈ pre(B ) there is a state q ∈ Q

B

such that δ

B

(q

B

, v) = q. The

set en(v, B) contains all symbols a ∈ Σ such that δ

B

(q, a) 6= ∅. Furthermore, these

symbols are elements of en(v, P ) as well. It follows that in P, there is at least one

state r such that δ

P

(q

P

, v) 3 r and δ

P

(r, a) 6= ∅. But then, due to the deﬁnition, r is in

the set of alternative second-component-states R

q

and δ

P

(R

q

, a) 6= ∅. This shows the

existence of a matching transition. Since this holds for all v ∈ pre(B ), the construction

of A

B∩P

succeeds.

“⇐” For all v ∈ pre(B ) there is a state q ∈ Q

B

such that δ

B

(q

B

, v) = q. Moreover,

en(v, B) 6= ∅ and for all a ∈ en(v, B) there is a p ∈ Q

B

and δ

B

(q, a) = p. Since

the construction of A

B∩P

succeeded and was not aborted due to lack of a matching

transition, it follows that each transition of B has at least one corresponding transi-

tion in A

B∩P

. Consequently, there exist states (q, r) and (p, s) of A

B∩P

such that

δ((q

B

, q

P

), v) 3 (q, r) and δ((q, r), a) 3 (p, s). This implies that in P we have

δ

P

(q

P

, v) 3 r and δ

P

(r, a) 3 s. Hence, a ∈ en(v, P ) implying en(v, B) ∩ en(v, P ) =

en(v, B) for all v ∈ pre(B ). ut

2

We refer to a state as being useless, whenever this state is not co-reachable.

55

Theorem 2. For all v ∈ (pre(B ) ∩ pre(P )) : cont(v, B ∩ P ) 6= ∅ ⇔ No set R

q

,

q ∈ Q

B

, becomes empty after removing useless states.

Proof. “⇒” For all v ∈ (pre(B) ∩ pre(P )), we have δ((q

B

, q

P

), v) 6= ∅ due to the

construction of A

B∩P

. Since L(A

B∩P

) = B ∩ P and there is a w ∈ cont(v, B ∩ P ),

at least one element of δ((q

B

, q

P

), v) is co-reachable. Thus, there exists a successful

run ρ(vw) of A

B∩P

on vw. Obviously, none of the states of ρ(vw) will be removed by

the reduction process, or in other words, all corresponding sets of second-entry-states

contain at least one element after A

B∩P

has been reduced and the sets R

q

have been

updated. According to the construction of A

B∩P

, each of its states can be reached by a

v ∈ (pre(B)∩pre(P )), and thus occurs in a successful run. This means that each of the

sets R

q

of second-component-states, which are attached to a state in that run, contains

at least one element even after the reduction- and update-process.

“⇐” It follows that for each v ∈ (pre(B )∩pre(P )) that leads A

B∩P

to one of its states,

there is at least one state in the reduced automaton A

B∩P

that is reached by v. Since

each state of the reduced A

B∩P

is co-reachable and the reduced automaton A

B∩P

still

recognizes B ∩ P , it implies the existence of a w ∈ cont(v, B ∩ P ). Furthermore, due

to the construction of A

B∩P

, every v ∈ (pre(B) ∩ pre(P )) leads A

B∩P

to one of its

states. Thus, for all v ∈ (pre( B ) ∩ pre(P )) there is a w ∈ cont(v, B ∩ P ). ut

Corollary 3. The presented IFLTV procedure veriﬁes correctly whether or not B sat-

isﬁes P inherently fairly.

Proof. Follows immediately from the theorems above and Corollary 2. ut

8 Complexity of the Procedure

It has been shown that deciding IFLTV is PSPACE-complete [9]. So the only complex-

ity criterion for evaluating our algorithm is whether or not it requires less computation

steps than the previously known algorithms, even though it remains inefﬁcient in the

worst case. However, it can be seen that the presented procedure is more efﬁcient than

the na

¨

ıve one, and, we think that it is worth being considered as an alternative to current

model-checking algorithms for verifying liveness properties under fairness constraints.

Our procedure for the IFLTV relation is divided into two major steps, construction

of the product automaton and reduction of this automaton. During the construction of

the product automaton, we compute the sets we need for the veriﬁcation task. These sets

corresponds to the states of a determinized product automaton, so what we do is in fact

a determinization of the product automaton. The second step of reduction, is obtained

by computing the strongly connected components of the product automaton.

Compared to the na

¨

ıve algorithm for IFLTV, which needs to compute the product

automata twice, build the complement automaton, determinize once and do an empti-

ness check, the described procedure is more efﬁcient, which only needs to compute one

product automaton, one determinization and one reduction of the automaton. Further,

our procedure has an integrated on-the-ﬂy check, which means the procedure may stop

whenever a violation of one of the two criteria mentioned above has been detected.

56

9 Conclusions and Outlook

The presented construction avoids several steps of the na

¨

ıve procedure, and the veriﬁca-

tion is done on-the-ﬂy. Part of our immediate future work will be experimenting with an

implementation of our approach to tackle complex, industrial-sized case studies. In ad-

dition, the resulting procedure still seems to offer scope for improvement. For example,

the construction of the product states of the property automaton in parallel with the con-

struction of the behavior-and-property product automaton could be improved by giving

up the requirement of being able to detect a violation of Condition 1 of Corollary 2 on

the ﬂy, i.e. immediately during the construction of the product automaton: Checking

the second condition ﬁrst, and only then the ﬁrst condition would make it possible to

reduce the automaton before determinization, but on the cost of losing the on-the-ﬂy

effect. Exploring these potential improvements will also be part of our future work.

We believe the IFLTV is tailored to model checking liveness properties under fair-

ness constraints. And as model-checkers do not or only partly offer fairness implemen-

tation, we will try to integrate the given procedure into an existing model-checker. Such

an implementation would allow us to compare our approach with existing algorithms.

References

1. A. V. Aho, J. E. Hopcroft, and J. D. Ullman. The Design and Analysis of Computer Algo-

rithms. Addison-Wesley, Reading, Mass., ﬁrst edition, 1974.

2. B. Alpern and F. B. Schneider. Deﬁning liveness. Information Processing Letters, 21(4):181–

185, October 1985.

3. J. R. B

¨

uchi. On a decision method in restricted second order arithmetic. In E. Nagel et al.,

editors, Proceedings of the International Congress on Logic, Methodology and Philosophy

of Science 1960, pages 1–11. Stanford University Press, 1962.

4. E. M. Clarke, O. Grumberg, and D. A. Peled. Model Checking. The MIT Press, 1999.

5. S. Eilenberg. Automata, Languages and Machines, volume A. Academic Press, New York,

1974.

6. N. Francez. Fairness. Springer Verlag, New York, ﬁrst edition, 1986.

7. R. Gerth, D. Peled, M. Y. Vardi, and P. Wolper. Simple on-the-ﬂy automatic veriﬁcation of

linear temporal logic. In P. Dembinski and M. Sredniawa, editors, Protocol Speciﬁcation,

Testing, and Veriﬁcation XV ’95, pages 3–18. Chapman & Hall, 1996.

8. J. E. Hopcroft, R. Motwani, and J. D. Ullman. Introduction to Automata Theory, Languages

and Computation. Addison Wesley Longman, 2001.

9. U. Nitsche and P. Wolper. Relative liveness and behavior abstraction (extended abstract).

In Proceedings of the 16th ACM Symposium on Principles of Distributed Computing

(PODC’97), pages 45–52, Santa Barbara, CA, 1997.

10. S. St James and U. Ultes-Nitsche. Computing property-preserving behaviour abstractions

from trace reductions. In Proceedings of the 20th Annual ACM Symposium on Principles of

Distributed Computing (PODC 2001), pages 238–245. ACM Press, August 2001.

11. W. Thomas. Automata on inﬁnite objects. In J. van Leeuwen, editor, Formal Models and Se-

mantics, volume B of Handbook of Theoretical Computer Science, pages 133–191. Elsevier,

1990.

12. U. Ultes-Nitsche and S. St James. Improved veriﬁcation of linear-time properties within fair-

ness — weakly continuation-closed behaviour abstractions computed from trace reductions.

Software Testing, Veriﬁcation and Reliability (STVR), 13(4):241–255, 2003.

57

13. M. Y. Vardi and P. Wolper. An automata-theoretic approach to automatic program veriﬁca-

tion. In Proceedings of the 1st Symposium on Logic in Computer Science, Cambridge, June

1986.

14. M. Y. Vardi and P. Wolper. Reasoning about inﬁnite computations. Information and Compu-

tation, 115(1):1–37, November 1994.

58
