Improvements in Detection and Classiﬁcation of Passing

Objects for a Security System

Ricardo S

anchez-S

aez

, Alfons Juan

Taizo Umezaki

, Yuki Inoue

, Masahiro Hoguro

and Setta Takefumi

Institut Tecnol

ogic d’Inform

atica–DSIC, Universitat Polit

ecnica de Val

encia

Cam

ı de Vera s/n, 46022 Val

encia, Spain

Nagoya Institute of Technology, Gokiso-cho, Showa-ku, Nagoya, Aichi, 466-8555, Japan

CHUBU Electric Power Co., Inc., Higashi-shincho, Higashi-ku, Nagoya 461-8680, Japan

Abstract. Pattern recognition techniques are used in the construction of video

surveillance systems. In this work a video-based security system that detects and

classiﬁes laterally crossing objects, introduced in a previous paper, is reviewed.

More reliable results for the system are presented, obtained by performing a leav-

ing one out on the data corpus rather than employing a manual approach. Other

alternatives in the pattern preprocessing are explored: we employ greyscale pat-

terns, and implement a different method for calculating difference images of con-

secutive video frames. A ﬁnal benchmark of the classiﬁcation part is done com-

paring the results obtained using dynamic time warping, to the ones obtained

using discrete hidden Markov models plus vector quantization.

1 Introduction

With the latest advances in computing power and the advent of consumer level digital

video cameras, commodity video vigilance systems are more and more affordable. A

necessary step building a security system concerns isolating the interest objects from the

background. Efforts in this area are shown in [1], in which the background is removed

using the local binary pattern (LBP) texture operator. This method calculates texture

features over blocks of pixels, rather than taking into account just the color or intensity

of individual pixels.

Another technique is presented in [2], in which the classical background subtrac-

tion method (the background is computed frame by frame by the difference between the

current frame and the previously stored background model) is improved by adding ob-

ject knowledge in the segmentation part, that allows discrimination of objects, shadows

and ghosts (false objects), and calculates the background in a more reliable way. Further

approaches to background modeling can be found following the references therein [2,

Table 1].

Work supported by the EC (FEDER) and the Spanish MEC under the MIPRCV “Con-

solider Ingenio 2010” research programme (CSD2007-00018), the iTransDoc research project

(TIN2006-15694-CO2-01), and the FPU fellowship AP2006-01363.

Sánchez-Sáez R., Juan A., Umezaki T., Inoue Y., Hoguro M. and Takefumi S. (2008).

Improvements in Detection and Classiﬁcation of Passing Objects for a Security System.

In Proceedings of the 8th International Workshop on Pattern Recognition in Information Systems, pages 205-212

 SciTePress

Calculating the trajectory of moving objects is another closely related problem, cov-

ered in [3]. There, a background and a camera model are used to obtain a real world

representation of the moving objects based on invariant 3D shapes. In [4] we can see

a complete surveillance system that classiﬁes objects using simple image metrics, and

then tracks them using a combination of template matching, and the temporal consis-

tency information of the detected objects.

Our system develops on another of such classiﬁcation systems, which uses a sim-

ple approach but shows promising results, originally discussed in [5]. There, a system

is presented that detects objects passing laterally in front of a camera and classiﬁes

them as people, bicycle, car, or bus. The background removal and object detection is

performed using the classical background subtraction method, which despite its sim-

plicity, provides good results. Once the background is removed, patterns are obtained

from the moving objects. The authors describe two successive approaches for scanning

the passing objects: the ﬁrst one constructs patterns from the objects without taking

into account their speed. In the second the speed of the objects is used in order to obtain

speed-invariant patterns. The obtained patterns are then classiﬁed using Dynamic Time

Warping (DTW).

This work parts from the mentioned system and presents several contributions. After

a revision of the speed invariant system shown there, we offer a more objective evalu-

ation of the results. This is done by presenting results obtained using a leaving one out

approach, which avoids the manual intervention employed in the cited paper. We pro-

pose two different improvements to the preprocessing of the speed invariant the system:

patterns of different greyscale are experimented with, and a new method for generating

the intensity information of the pattern images is introduced. Finally we evaluate the

DTW classiﬁcation part by comparing its results to the ones obtained using discrete

hidden Markov models (dHMM) plus vector quantization.

This paper is organized as follows. In section 2 we review how the system works.

Section 3 shows the use of greyscale patterns rather than binarized ones, and in section 4

we describe the new method for calculating the difference images between consecutive

frames. Empirical results are reported in section 5 and the main conclusions drawn are

given in section 6.

2 The Speed Invariant System

The system, which obtains patterns that represent the crossing objects and classiﬁes

them, can be seen schematized in Fig. 1. It can be roughly subdivided into data acquisi-

tion, preprocessing plus object scanning, and classiﬁcation. Now we will brieﬂy review

each of the parts, further details on what is the process followed for each can be found

in [5] and [6].

The video is acquired from the video camera and subsampling is performed if

needed. The next step is to crop the video ﬁle, discarding what is outside of the scan

zone. The scan zone is our area of interest and should intersect with the trajectory of the

passing objects. The size and position of the scan zone is manually chosen depending

on the scene (possible obstacles) and the proximity of the moving objects to the camera.

206

Next, the color information is discarded from the cropped scan zone, and a simple even

smoothing ﬁlter is applied.

The system detects the passing objects by comparing successive frames to deter-

mine when a moving body crosses the scan zone. For this, the difference operation is

continuously applied to the scan zone images. Applying this to 8-bit greyscale images

produces 16-bit difference images, having a [−255, 255] range for their pixel values.

In order to store them as regular 8-bit greyscale images, the absolute operator is ap-

plied, mapping the negative part to the positive one (see section 4 for an alternate way

of mapping the 16-bit difference images to 8-bit ones). The difference operation pro-

duces blank images except when change is present, movement between two consecutive

frames can be detected.

When activity is detected, a pattern of the object is created by extracting vertical

lines from the difference image. The objects’ speeds vary, so a method for obtaining

patterns invariant to the speed was devised. It works by obtaining positional information

of the objects while they are going through the scan zone. The speed is calculated when

the object leaves the zone, and it is used to determine the number of columns to extract

from each snapshot of the difference scan zone. Fig. 2 shows a simple synthetic example

of the speed calculation and scanning process. Note that to calculate the speed of a

moving object, at least two different readings of the object’s edge position from the

same screen side are needed. With this in mind, we see that a scan zone of width w will

only reliably calculate the velocity of objects passing from 1 to w/2 pixels per frame.

Preprocessing is then applied to the obtained pattern: binarization by thresholding,

trimming of upper and lower whitespace, and height normalization, maintaining the

aspect ratio.

Lastly, the preprocessed patterns are classiﬁed by dynamic time warping (DTW) as

shown by Sakoe and Chiba in [7]. In our case, the elements that are locally compared

to determine the optimum path are the columns of the patterns, so in a sense the pat-

terns are contracted or expanded horizontally. Two symmetric DTW algorithms were

implemented by dynamic programming. Both were based on production sets involving

the three usual operations of insertion, deletion and substitution. The only difference be-

tween them is the slope constraint condition used: SC0 has no slope constraint, whereas

SC1 has a slope constraint of 1 (see [7, table 1] for more details).

3 Greyscale Patterns

In this work we study the use of grey patterns of different number of grey shades for

classiﬁcation, rather than binarized ones. For it, a greyscale downsampling algorithm

with thresholding has been implemented.

The algorithm accepts three parameters: white threshold, number of grey shades,

and whether to enable normalization. Its input is a 8 bit (256 shades) greyscale image,

and the output is an image with the speciﬁed number of grey shades, evenly distributed

between 0 and 255 (e.g., 2 grey shades get values 0 and 255; 3 get 0, 127 and 255; 4

get 0, 85, 170, 255; etc.). Note that in the following examples, 0 is white and 255 black.

The algorithm works as follows:

208

This new mapping method for difference images needs modiﬁcations in the trim-

ming algorithm, as well as in the greyscale downsampling one. The newDiff version of

the trimming algorithm works similarly to oldDiff version, but uses grey value 127 as

the neutral value, instead of using 0 as in the baseline version.

Likewise, the newDiff greyscale downsampling algorithm works in a similar fash-

ion to the one described in section 3. The newDiff greyscale downsampling can be

understood if we imagine splitting the unprocessed 256 greyscale newDiff image into

two: the positive one featuring the [127, 255] range of grey values; and the negative

one, which after mirroring would feature the [126, 0] range of grey values. The newDiff

greyscale downsampling algorithm simply applies the oldDiff greyscale downsampling

consecutively to both images, unmirrors the negative one, and combines them again.

5 Experiments

Our experiments use a video ﬁle shot at the entrance of a facility. It comprises 16 min-

utes of footage, in which a number of objects pass in front of the camera. There are 56

people, 30 bicycles, 14 cars, and 8 buses, for a grand total of 108 objects. The video

runs at 30 fps and has a resolution of 720 x 480 pixels.

A leaving one out protocol was followed for our experiments. We built an automatic

system in which each scanned pattern was compared to all the patterns present in the

video ﬁle, and the class of the nearest one was selected. This allowed us to obtain the

most reliable estimation of the classiﬁcation error for our system, given the small num-

ber of available objects in the corpus, improving over the manual protocol employed in

[5].

The following results error rates were obtained for our systems using SC0-SC1:

baseline 27%-6%, speed invariant 21%-6%. The results for the implemented improve-

ments can be graphically seen in Fig. 3.

Regarding DTW production sets, we can see that in both cases the speed invariant

system obtains better results than the baseline system. SC1 was the DTW method that

provided the best results with the baseline system, and it provides similar results us-

ing the speed invariant system. Also note the small improvement observed using SC0,

which despite providing not very relevant results compared to SC1, supports the cor-

rectness of the speed invariant system.

Not using a slope constraint provides more ﬂexibility when matching patterns of

different widths. This ﬂexibility disserves our objectives; it is better to have a slope

constraint that, by disallowing the matching of patterns that have very different widths,

this measure is taken into account as discriminant information.

Additionally, we obtained the classiﬁcation error replacing the DTW in the classiﬁ-

cation part with dHMM and vector quantization. We experimented with different sizes

for the model (5 to 500 states) and the codebook (8 to 512 words), and the best result

was a recognition rate of 6 %, obtained around 50 states and 64 words. These results,

similar to the ones obtained with DTW, conﬁrm that DTW is performing well for our

problem

Looking at the greyscaling results we see that, as expected, using normalization

provides better results than not using it. The results using normalized greyscale patterns

210

We have presented two improvements, and compared the obtained results to the

ones of the base systems. The examined modiﬁcations have been: the use of greyscale

downsampling in the pattern preprocessing part, rather than using binarized patterns;

and the use of a new difference image calculation method for the object scanning part.

Using greyscale patterns in the classiﬁcation yields similar results to to those ob-

tained using binarization. With normalization disabled in this algorithm, the error rate

rises with the number of grey shades. The normalized version provides us with greyscale

images that make a better use of the grey range, accentuating the differences between

classes, fact which provides results that present a slight improvement as the number of

grey shades increases.

A new difference image calculation method, newDiff, has been experimented with,

testing different values for its associated greyscale downsampling algorithm. It provides

similar results to the old difference image calculation method improving them in some

cases. It produces coherent successive results as we increase the number of grey shades,

with a soft and expected variation, which indicates than this new method is more stable

and reliable than the old one.

References

1. Heikkila, M., Pietika, M.: A texture-based method for modeling the background and detecting

moving objects IEEE Transactions on Pattern Analysis and Machine Intelligence, Vol. 28, No.

4, April 2006

2. Cucchiara, R., Grana, C., Piccardi, M., Prati, A.: Detecting moving objects, ghosts, and shad-

ows in video streams IEEE Transactions on Pattern Analysis and Machine Intelligence, Vol.

25, No. 10, October 2003

3. Zhao, T., Nevatia, Fellow, R.: Tracking multiple humans in complex situations IEEE Transac-

tions on Pattern Analysis and Machine Intelligence, Vol. 26, No. 9, September 2004

4. Lipton, A., Fujiyoshi, H., and Patil, R.: Moving target classiﬁcation and tracking from real-

time video. Proceedings of the 1998 DARPA Image Understanding Workshop (IUW’98),

November, 1998.

5. S

anchez, R., Umezaki, T., Inoue, Y., Hoguro, M., Fujino, M.: Detection and classiﬁcation of

passing objects for a security system. Proceedings of the Visualization, Imaging, and Image

Processing conference 2005. Benidorm. 71-76.

6. S

anchez, R.: Detection and classiﬁcation of passing objects for a security system. Technical

Report (BSc Thesis). 2006. http://www.dsic.upv.es/∼rsanchez/.

7. Sakoe, H., Chiba, S.,: Dynamic programming algorithm optimization for spoken word Recog-

nition. Readings in Speech Recognitions, pages 159-165. Kaufmann, San Mateo, CA, 1990.

212
