AN ONTOLOGY-BASED APPROACH FOR SEMANTIC

INTEROPERABILITY IN P2P SYSTEMS

Deise de Brum Saccol, Rodrigo Perozzo Noll, Nina Edelweiss and Renata de Matos Galante

Instituto de Informática, Universidade Federal do Rio Grande do Sul,

Bento Gonçalves 9500, Porto Alegre, Brazil

Keywords: Ontology, peer-to-peer, schema matching, similarity.

Abstract: In peer-to-peer (P2P) systems, files from the same application domain are spread over the network. When

the user poses a query, the processing relies mainly on the flooding technique, which is quite inefficient for

optimization purposes. To solve this issue, our work proposes to cluster documents from the same

application domain into super peers. Thus, files related to the same universe of discourse are grouped and

the query processing is restricted to a subset of the network. The clustering task involves: ontology

generation, document and ontology matching, and metadata management. In this paper, we focus on the

matching step.

1 INTRODUCTION

P2P refers to a class of application systems that use

distributed resources to perform tasks in a

decentralized context

1,2,3

. The usability of such

systems is mainly dependent on techniques used to

find and retrieve results. However, the searching

optimization faces two problems: how to find

relevant files for the user query with a low cost, and

how to deal with the poor semantics of the

resources.

Files that belong to the same application domain

and that are needed for answering a specific query

may be stored in several peers. The use of the

flooding technique would be necessary in order to

access all the relevant files. But this technique is

expensive and time-consuming, since all the peers

get the query message and usually only some of

them are able to answer it. Another attempt for

balancing cost is to use any flooding variation

technique, such as breadth-first traversal (over the

network with depth limit D measured in hops) or

depth-first traversal with depth limit D (Yang,

2002). However, their use does not guarantee the

optimal results, since not all the peers get the

Gnutella. Available at http://www.gnutella.com

Kazza. Available at http://www.kazaa.com

eMule. Available at http://www.emule-project.net

requesting message.

Related to the semantics, let us consider two

applications that need to exchange data. One

possible approach is to build an adapter that

transforms data and structure between them.

However, the adapter construction is a hard task that

requires knowing the data organization in both

applications. Furthermore, the complexity and the

developing time tend to be quadratic in relation to

the number of component applications (Staab,

2004). A possible solution should use some kind of

metadata for describing the semantics of the

underlying repositories. But this scenario states two

critical questions (Mena, 2001): (i) how to deal with

different concepts used to describe the same

information; and (ii), how to acquire and maintain

the necessary metadata to solve the vocabulary

sharing issue.

To overcome these problems we propose an

ontology-based approach that can be used for

improving traditional searching techniques in P2P

systems. We focus on two important issues: (i) the

extra traffic produced by traditional flooding

techniques when the optimal results are required;

and (ii) the lack of semantics regarding the

information storage and searching. In order to avoid

such unnecessary traffic caused by the flooding

solution, our approach relies on file clustering into

super peers, based on the application domain of the

peer files. The file grouping criteria is based on the

310

de Brum Saccol D., Perozzo Noll R., Edelweiss N. and de Matos Galante R. (2008).

AN ONTOLOGY-BASED APPROACH FOR SEMANTIC INTEROPERABILITY IN P2P SYSTEMS.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - DISI, pages 310-316

DOI: 10.5220/0001711503100316

 SciTePress

similarity analysis between the files and the domain.

In order to increase the semantics, we adopt an

ontology for describing the document concepts.

The main contributions of this paper are:

- The specification of the ontology manager, a

component used for allowing semantic

interoperability in P2P systems;

- The definition/implementation of a mechanism for

file and ontology matching, based on lexical and

semantic similarity between concepts.

The functionalities of this mechanism are

performed by the ontology manager, as part of

DetVX (Saccol, 2007), as following described.

2 DeTVX FRAMEWORK

The proposed framework (Detector of Replicas and

Versions of XML Documents) stores files according

to the super peer architecture. Files stored in peers

are related to a specific application domain,

described by an ontology (e.g., curriculum or

research projects domain). We use the ontology as

peer grouping criterion into super peers. The

ontologies are automatically generated (from the

schema integration process). All the peers belonging

to the same domain are clustered in the same super

peer. Since one domain is represented in only one

super peer, two files belonging to the same domain

cannot be found in different super peers. With this

assumption, a certain query related to a domain will

be forwarded only within a specific super peer

network, reducing unnecessary network traffic.

2.1 Ontology Manager

The ontology manager is responsible for maintaining the

ontology repository and for associating ontologies to

super peers. In this proposal, ontologies are represented

in OWL

format. The activities are presented in Figure 1

and are described as follows:

Figure 1: UML activity diagram for the ontology manager.

Web Ontology Language (OWL). Available at

http://www.w3.org/2004/OWL/

- Show available ontologies – this activity returns a

short description of existent ontologies stored in

the repository. The user can choose an ontology to

be used for a (set of) document (s) belonging to

this domain (i.e., select a super peer to connect).

- Match the file to a proper ontology – for

document and ontology matching, our work

assumes one of the following approaches:

o There is a compatible ontology for the

document – thus, the peer that stores the file is

connected to the super peer described by this

ontology. To figure out which ontology best

describes a certain file, our proposal relies on

using similarity techniques between the file and

the ontologies. The ontology that presents the

higher similarity is chosen to represent the file

domain, as described in Section 3.

o There is not a compatible ontology for the

document – thus, we create a new ontology

(generate ontology activity) that represents the

concepts and relationships of this domain.

- Generate ontology - The ontology is created from

the schema integration process. The integration

activity uses a thesaurus for helping to infer

terminological relationships in order to match

equivalent concepts. The full description of this

task is presented in (Saccol, 2008).

- Update ontology repository – this activity is

responsible for storing the created ontology into

the ontology repository.

- Associate the ontology to a super peer – this

activity is responsible for associating the new

ontology to an existent super peer. Some

administrative metadata also need to be

maintained.

Load balancing must be considered when choosing a

super peer to associate to an ontology. In our work,

load balancing is performed based on the number of

peers in super peers. The goal is to keep the same

number of peers in each super peer. The mean

number (A) of peers (p) in each super peer is defined

as: A(p)=(number of peers)/(number of super

peers)+range. The range value allows some

flexibility in terms of number of peers before

performing load balancing. The load balancing must

agree with the grouping criteria (belong to the same

ontology). Thus, the load balancing regrouping may

imply on associating ontologies to other super peers.

- Update metadata – this activity updates the

metadata.

In this paper, we focus on file and ontology

matching.

AN ONTOLOGY-BASED APPROACH FOR SEMANTIC INTEROPERABILITY IN P2P SYSTEMS

311

3 ONTOLOGY AND DOCUMENT

MATCHING

The matching task aims to define the ontology that

best describes a XML file, by measuring the overall

similarity between both representations. Given a

XML file d and a set of n ontologies

O={

,…,o

}, the procedure computes the

similarity score sim(d,O). The ontology o

(0<m<=n)

with the highest score (greater than a threshold t) is

chosen to represent the corresponding file domain

application.

The strategy aims to find resemblances between

classes. Two questions must be answered: ‘which

pairs of classes will be compared’ and ‘what are the

criteria to determine how similar the classes are’.

Several approaches address similarity analysis

(Madhavan, 2001), (Maedche, 2002). These

approaches are usually based on three main steps:

- Normalization: determines which elements are

semantically equivalent;

- Categorization: separates the elements into

classes, in order to reduce the number of

comparisons;

- Comparison: defines the similarity score

computed among the elements in their categories.

To evaluate the similarity between files, two types of

perspectives are considered: the lexical perspective

evaluates the relations between terms by comparing

the strings, while the semantic perspective focuses

on the meaning and conceptual correlation among

terms. For the similarity analysis, we consider both

types, as follow described:

- Lexical Similarity Analysis: two main

approaches are used:

o Edit distance functions (Levenshtein, 1966): this

approach analyses the minimum number of

operations to transform one character sequence

into another;

o Stemmer algorithms

: this approach reduces the

character sequence to the stem (i.e., the form of

a word after all affixes are removed).

In our approach, we use a stemmer algorithm for

lexical similarity analysis.

- Semantic Similarity Analysis: two main

approaches are commonly used:

o Thesaurus: used to figure out the terminological

relationships (e.g., WordNet

The Lancaster Stemming Algorithm. Available at

http://www.comp.lancs.ac.uk/computing/research/stemming

WordNet. Available at http://wordnet.princeton.edu

o Taxonomic Overlap procedure (Maedche,

2002): it does not individually analyze the

element, but the element context. For

calculating the similarity degree between two

sets of elements, we use the Jaccard coefficient

(Manning, 1999).

Our mechanism aggregates and extends the

advantages of some existent approaches, as

described in the next section.

3.1 Matching Approach

We use the following process to compute the

similarity score sim(d,o

) between a XML file d and

an ontology o

. The first step corresponds to the

normalization and categorization tasks, as follows.

- Normalization and Categorization Phase: for

each file (XML and OWL), we map all the

component elements, by traversing the document

and storing the stem (key) and a list with the

complete names for each element. If the element

name is composed by n-words, then the list also

consists of each component. This initial mapping

corresponds to the lexical perspective and is

presented in Figure 2.

Key List

skill skillArea skill area

Figure 2: Lexical normalization of XML elements.

The next step considers the element synonyms. The

list of synonyms is retrieved from WordNet. The

resulting list is presented in Figure 3.

Key List

skill skillArea skill area accomplishment acquisition domain

Figure 3: Semantic normalization of XML elements.

The normalization occurs in two steps. First, we

normalize the ontology elements, as above

described. We traverse the XML elements and verify

in their lists the existence of any lexical

correspondence with other elements from the OWL

list. These correspondences are analyzed by looking

only at the stems, using a stemmer. At last, we have

two normalized and categorized lists (XML and

OWL elements). In this phase, the system is able to

identify the existent correspondences between the

XML and OWL elements, providing the initial step

for element comparison.

- Comparison Phase: this step analyzes the

taxonomic overlap. For each element that consists of

a root-leaf set (i.e., a path from the root to the leaf

ICEIS 2008 - International Conference on Enterprise Information Systems

312

nodes), the system knows the existence of

correspondences in the ontology (obtained during

the normalization task). To get the similarity degree,

we define the union as the total number of XML

elements in the root-leaf set. The intersection is

defined as the number of relations with a

correspondence between the XML and the ontology

elements. By relations, we mean: an OWL class that

relates to an OWL subclass; an OWL class that

relates to Object or Datatype properties; and the

relations between OWL classes.

The taxonomic overlap method traverses the left-

side tree and analyzes only the nodes that have

correspondence with the right-side tree. This

procedure is repeated for all the root-leaf sets. Thus,

we obtain a list with the all the similarity values. The

final value is calculated as the arithmetical mean of

this list.

3.2 Matching Example

Let us consider the XML file presented in Figure 4.

Figure 4: XML document.

Figure 5 presents part of the resume ontology (some

properties are not shown, such as the address

properties - city, state, street and zip). Let us also

suppose the existence of another ontology

representing another domain, e.g., academic

research. We aim to figure out which ontology best

describes the XML document, by measuring the

similarity among the XML file and the ontologies.

Figure 5: The resume ontology.

By following the mechanism previously presented in

Section 3.1, the matching approach produces the

similarity values described in Table 1. By looking at

the last line, we can see that the first ontology

(resume.owl) presents the highest similarity (0.899).

Thus, this ontology is chosen for describing the

XML file domain.

While analyzing the partial similarities, the

mechanism is capable to store information about

mappings between concepts in the XML document

and concepts in the ontology. Basically, for each

term in the ontology the mapping information is

represented as a transforming function. The

transforming functions are represented in XPath

For instance, the concept fullName can be mapped in

different documents, such as name and

firstName+lastName. The mappings are extensively

used in query transformation.

Table 1: Individual (ISim), partial and final similarity

values for the files presented in Figure 4 and Figure 5.

XML (Resume)

Ontology

(Resume) ISim

Ontology

(Academic

Research) ISim

[header, name,

firstname]

[Name,

Firstname] 0.667

[firstName,

firstName] 0.333

[header, name,

surname]

[Name,

LastName] 0.667

[firstName,

lastName] 0.333

[header, name] [name] 0.500 [name] 0.500

[header, address,

street]

[Address,

street] 0.667 [address] 0.333

[header, address,

city]

[Address,

city] 0.667 [address] 0.333

[header, address,

state]

[Address,

state] 0.667

[address,

Department] 0.667

[header, address,

zip]

[Address,

zip] 0.667 [address, nil] 0.333

[header, address] [address] 0.500 [address] 0.500

[header, contact,

phone] [phone] 0.333 [phone] 0.333

[header, contact,

email] [email] 0.333 [email] 0.333

[header, contact,

url] [url] 0.333 [url] 0.333

[header, contact] [] 0.000 [] 0.000

[header] [] 0.000 [] 0.000

… … … … …

Partial similarity value 0.462 0.333

Final similarity value 0.899 0.433

Some metadata are also maintained, but not

presented in this paper.

4 IMPLEMENTATION

Our approach is implemented in a tool named The

Matcher. The tool measures the lexical and semantic

similarity among XML files and ontologies. The

Matcher was implemented using the following APIs:

Paice/Husk stemmer

, for the lexical analysis (word

XML Path Language. Available at http://www.w3.org/TR/xpath20/

The Lancaster Stemming Algorithm. Available at

http://www.comp.lancs.ac.uk/computing/research/stemming

<city>Garbonzoville</city><state>NX</state>

</header><

/resume>

AN ONTOLOGY-BASED APPROACH FOR SEMANTIC INTEROPERABILITY IN P2P SYSTEMS

313

stems); WordNet

, for the semantic analysis

(synonyms); JWNL

, for accessing the WordNet

dictionary; Jena

, for manipulating the OWL files;

and Xerces

, for manipulating the XML files.

We ran some experiments to calculate the

similarity between a curriculum XML file and some

ontologies. The goal is to prove that a file belonging

to a domain D has higher similarity with the

ontology that describes that domain than others. The

input consists of one XML file and six OWL files.

The output is a similarity value for each pair of

representations. The ontologies are related to the

following domains: academic research, amino acids,

wine, pets and owners, travel, and curriculum. The

similarity results are presented as follows.

Academic_research.owl: 0.496 Amino_acid.owl: 0.377

People_pets.owl: 0.448 Resume.owl: 0.899

Travel.owl: 0.382 Wine.owl: 0.39

The similarity values show that the ontology

Resume.owl has the highest similarity with the XML

document used in the experiments (89.9%). Other

ontologies from different domains presented very

low similarities (between 38% and 49%). Thus, the

Resume ontology is chosen for describing the

document. In these experiments, we considered that

ontology with the highest similarity is always

chosen. However, it may occur that even the most

similar ontology is still not proper to describe a

document (i.e., low similarity). In this case, our

proposal relies on a threshold-based approach. The

threshold definition is not addressed in this paper.

Our mechanism allows users to formulate queries

over ontologies and the system takes the

responsibility for managing the heterogeneity and

distribution in the peers.

5 RELATED WORK

The usability of P2P systems is mainly dependent on

the techniques used for finding and retrieving the

resources. The result quality can be measured by

some metrics (Yang, 2002), such as: the size of the

result set, the user satisfaction, and the time to get

the results. However, there is a relation between cost

and quality that must be balanced. The use of the

flooding technique guarantees the optimal results,

but it is expensive and time-consuming, since all the

peers get the query message and usually only some

of them are able to answer it. Another attempt for

WordNet. Available at http://wordnet.princeton.edu

JWNL Java WordNet Library. Available at http://jwordnet.sourceforge.net

Jena-Semantic Web Framework. Available at http://jena.sourceforge.net

Xerces. Available at http://xerces.apache.org

balancing cost is to use any flooding variation

techniques, such as breadth-first traversal

(over the

network with depth limit D measured in hops) or

depth-first traversal

with depth limit D. However,

their use does not guarantee the optimal results,

since not all the peers get the requesting message.

For systems focusing on availability, search

techniques such as those presented in (Ratnasamy,

2001) and (Rowstron, 2001) are well-suited, because

they guarantee location of content if it exists.

However, to achieve these goals, these techniques

strongly control the data placement and work only

for a delimited number of hops. In our proposal, it is

fundamental to retrieve all the relevant files, while

using an optimized searching technique.

Furthermore, keyword-based systems do not

retrieve the necessary document if a synonym is

used as part of the query. This situation happens

because different but related terms may be used to

describe similar information. Besides, automatic

systems lack to find and extract relevant information

and fail to integrate information spread over

different sources (Fensel, 2001). To address these

issues, semantic annotations in our proposal allow

structural and semantic definitions of documents,

providing an intelligent query processing that allows

users to pose queries in a P2P system without being

aware of the location and structure of the files.

The peer aggregation into super peers is an

important issue and it is the basis of our proposal for

searching enhancement. This task is usually

performed based on some features, such as subject

and location (Nejdl, 2002). In this paper, we

consider both the domain application of the files

(described by an ontology) and a quantitative metric

defined by the desired mean number of peers in

super peers.

There are some works based on similarity

techniques that can be used for figuring out the

application domain of a XML document (Bertino,

2004). These works are usually based on structural

(Francesca, 2003), (Dalamagas, 2004), (Lian, 2204)

or content similarity (Baeza-Yates, 1999). Diff

algorithms are commonly used for detecting

differences between the files. However, our problem

is to identify semantic correspondences, which may

exist even between representations that are quite

differently in structure and content. Although an

ontology and a XML file can present low structural

and content similarity, they can describe the same

application domain. Thus, traditional similarity

techniques are not proper for our problem.

Gnutella. Available at http://www.gnutella.com

Freenet. Available at http://freenet.sourceforge.net

ICEIS 2008 - International Conference on Enterprise Information Systems

314

6 CONCLUDING REMARKS

Search engines provide support for automatic

information retrieval which helps in finding data

sources. However, the tasks of extracting the

relevant information remain for the user. Thus, there

are some bottlenecks that must be passed, such as

(Fensel, 2001): lack of a means for representation

and translation and lack of a means for content

descriptions.

Considering P2P systems, there is an extra issue:

to increase the result quality while optimizing the

search space. In this scenario, two problems must be

addressed: how to find relevant files for the user

query and how to increase the semantics in the

information resources. To overcome these issues, we

proposed an ontology-based approach that can be

used for improving searching techniques. With this

proposal, we have reduced the extra traffic produced

by traditional flooding techniques when the optimal

results are required, and increased the semantics

regarding the information storage and searching. The

search space optimization is achieved by clustering

files into super peers, based on file similarity. The

increasing of the semantics is done by adopting

ontologies, making explicit the information content

in a manner independent of the underlying structures

used to store the information.

We have presented the ontology manager, by

defining and implementing a tool for matching

ontologies to XML documents. By matching the

ontology to a XML file, the system can connect the

peer to a proper super peer that is described by a

specific ontology. The matching phase basically

considers the concept name, the structure similarity

and stemmer algorithms. The ontologies are

generated from an integration process among the

conceptual schemas that describe the XML files.

We implemented a tool named The Matcher that

identifies the similarity between XML files and

OWL ontologies. To evaluate the results, we have

performed a set of experimental tests, which clearly

demonstrated the accurate results. As future work,

we are going to incorporate this tool into DetVX, a

framework for detecting, managing and querying

XML replicas and versions in P2P scenarios. We are

currently developing a graphic tool for peer

management based on JXTA platform (Gong, 2001).

The system will allow managing the super peers,

peers and corresponding files, as well to assess the

performance when using the presented approach.

ACKNOWLEDGEMENTS

This work has been partially supported by CNPq

under grant No. 142396/2004-4 for Deise de Brum

Saccol; Pronex Project – FAPERGS under grant No.

0408933 and CNPq Universal under grant No.

481055/2007-0 for Renata de Matos Galante.

REFERENCES

Baeza-Yates, R.A. and Ribeiro-Neto, B.A., 1999. Modern

Information Retrieval. ACM Press / Addison-Wesley.

Bertino, E.; Guerrini, G. and Mesiti, M., 2004. A

Matching Algorithm for Measuring the Structural

Similarity between an XML Document and a DTD and

its Applications. Information Systems, Elsevier

Science Ltd., 29, 23-46.

Dalamagas, T.; Cheng, T.; Winkel, K.J. and Sellis,

T.,2004. Clustering XML Documents using Structural

Summaries. In: EDBT Work. on Clustering

Information over the Web, Greece.

Fensel, D., 2001. Ontologies: A Silver Bullet for

Knowledge Management and Electronic Commerce.

Springer.

Francesca, F.D.; Gordano, G.; Ortale, R. and Tagarelli,

A.., 2003. Distance-based Clustering of XML

Documents. In: Work. on Mining Graphs, Trees and

Sequences, Croatia.

Gong, L., 2001. JXTA: A Network Programming

Environment. IEEE Internet Computing, 5(3):88–95,

May/June.

Kantrowitz, M., Mohit, B. and Mittal, V., 2000.

Stemming and its effects on TFIDF ranking. In: SIGIR

Conf. on Research and Development in Information

Retrieval. Athens.

Levenshtein, V., 1966. Binary Codes capable of correcting

deletions, insertions, and reversals. Cybernetics and

Control Theory, 10(8):707–710.

Lian, W.; Cheung, D.; Mamoulis, N. and Yiu, S., 2004.

An Efficient and Scalable Algorithm for Clustering

XML Documents by Structure. IEEE Trans. on

Knowledge and Data Engineering , 16, 82-96.

Madhavan, J., Bernstein, P. A. and Rahm, E., 2001.

“Generic schema matching using Cupid”. In:

VLDB’01, Rome, Italy.

Maedche, A.; Staab, S., 2002. “Measuring similarity

between ontologies”. In: EKAW.

Manning, C. D. and Schütze, H., 1999. Foundations of

Statistical Natural Language Processing. 1

ed.

Cambridge, MA: MIT Press.

Mena, E., and Illarramendi, A., 2001. Ontology-based

query processing for global information systems.

Springer.

Nejdl, W., Wolf, B., Qu, C., Decker, S., Sintek, and et. al.,

2002. EDUTELLA: A P2P Networking Infrastructure

Based on RDF. In: WWW’02, Hawaii, EUA.

AN ONTOLOGY-BASED APPROACH FOR SEMANTIC INTEROPERABILITY IN P2P SYSTEMS

315

Ratnasamy, S., Francis, P., Handley, M., Karp, R., and

Shenker, S., 2001. A scalable content-addressable

network. In: SIGCOMM.

Rowstron, A., and Druschel, P., 2001. Pastry: Scalable,

distributed object location and routing for large-scale

peer-to-peer systems. In: Middleware.

Saccol, D.B., Edelweiss, N. , Galante, R.M. and Zaniolo,

C., 2007. Managing XML Versions and Replicas in a

P2P Context. In: SEKE, Boston, USA.

Saccol, D.B. et al., 2008. Gerenciamento de Domínios de

Aplicação através do Uso de Ontologias. In: ERBD,

Florianópolis, Brazil – in Portuguese. (to be

presented).

Staab. S. and Studer, R., 2004. Handbook on Ontologies

(International Handbooks on Information Systems).

Springer.

Yang, B. and Garcia-Molina, H., 2002. Efficient Search in

Peer-to-Peer Networks. In: ICDCS, Vienna, Austria.

ICEIS 2008 - International Conference on Enterprise Information Systems

316
