DESIGN AND IMPLEMENTATION OF A LOW-COST ATTITUDE

AND HEADING NONLINEAR ESTIMATOR

Philippe Martin and Erwan Sala

¨

un

Centre Automatique et Syst

`

emes,

´

Ecole des Mines de Paris, 60 boulevard Saint-Michel, 75272 Paris Cedex 06, France

Keywords:

Observers, sensor fusion, nonlinear ﬁlters, strapdown systems, invariance, inertial navigation, extended

Kalman ﬁlters.

Abstract:

In this paper we propose a nonlinear observer (i.e. a “ﬁlter”) for estimating the orientation of a ﬂying rigid

body, using measurements from low-cost inertial and magnetic sensors. It has by design a nice geometrical

structure appealing from an engineering viewpoint; it is easy to tune, computationally very economic, and with

guaranteed (at least local) convergence around every trajectory. Moreover it behaves sensibly in the presence

of acceleration and magnetic disturbances. We illustrate its good performance on experimental comparisons

with a commercial system, and demonstrate its simplicity by implementing it on a 8-bit microcontroller.

1 INTRODUCTION

Aircraft, especially Unmanned Aerial Vehicles

(UAV), commonly need to know their orientation to

be operated, whether manually or with computer as-

sistance. When cost or weight is an issue, using very

accurate inertial sensors for “true” (i.e. based on the

Schuler effect due to a non-ﬂat rotating Earth) iner-

tial navigation is excluded. Instead, low-cost sys-

tems –often called Attitude Heading Reference Sys-

tems (AHRS)– rely on light and cheap “strapdown”

gyroscopes, accelerometers and magnetometers. The

various measurements are “merged” according to the

motion equations of the aircraft assuming a ﬂat non-

rotating Earth, usually with some kind of Extended

Kalman Filter (EKF). For more details about avionics,

various inertial navigation systems and sensor fusion,

see for instance (Collinson, 2003; Kayton and Fried,

1997; Grewal et al., 2007) and the references therein.

While the EKF is a general method capable of

good performance when properly tuned, it suffers sev-

eral drawbacks: it is not easy to choose the numerous

parameters; it is computationally expensive, which is

a problem in low-cost embedded systems; it is usually

difﬁcult to prove the convergence, even at ﬁrst-order,

and the designer has to rely on extensive simulations.

An alternative route is to use an ad hoc nonlinear

observer as proposed in (Thienel and Sanner, 2003;

Mahony et al., 2005; Hamel and Mahony, 2006; Mar-

tin and Sala

¨

un, 2007; Mahony et al., 2008). In the

absence of a general method the main difﬁculty is of

course to ﬁnd such an observer. In this paper we use

the rich geometric structure of the attitude-heading

problem to derive an observer by the method devel-

oped in (Bonnabel et al., 2007), building up on the

preliminary work (Martin and Sala

¨

un, 2007). It has

by design a nice geometrical structure appealing from

an engineering viewpoint; it is easy to tune, computa-

tionally very economic, and with guaranteed (at least

local) convergence around every trajectory. Moreover

it behaves sensibly in the presence of acceleration and

magnetic disturbances. We illustrate its good perfor-

mance on experimental comparisons with the com-

mercial Microbotics MIDG II system, and demon-

strate its simplicity by implementing it on a 8-bit At-

mel AVR microcontroller.

2 THE PHYSICAL SYSTEM

2.1 Motion Equations

The motion of a ﬂying rigid body (assuming the Earth

is ﬂat and deﬁnes an inertial frame) is described by

˙q =

1

2

q ∗ ω

˙

V = A + q ∗ a ∗ q

−1

,

where:

• q is the quaternion representing the orientation of

the body with respect to the Earth-ﬁxed frame

• ω is the instantaneous angular velocity vector

53

Martin P. and Salaün E. (2008).

DESIGN AND IMPLEMENTATION OF A LOW-COST ATTITUDE AND HEADING NONLINEAR ESTIMATOR.

In Proceedings of the Fifth International Conference on Informatics in Control, Automation and Robotics - SPSMC, pages 53-61

DOI: 10.5220/0001502100530061

Copyright

c

SciTePress

• V is the velocity vector of the center of mass with

respect to the Earth-ﬁxed frame

• A = ge

3

is the (constant) gravity vector in North-

East-Down coordinates (the unit vectors e

1

,e

2

,e

3

point respectively North, East, Down)

• a is the speciﬁc acceleration vector, in this case

the aerodynamic forces divided by the body mass.

The ﬁrst equation describes the kinematics of the

body, the second is Newton’s force law. It is custom-

ary to use quaternions instead of Euler angles since

they provide a global parametrization of the body

orientation, and are well-suited for calculations and

computer simulations. For more details see (Stevens

and Lewis, 2003) or any other good textbook on air-

craft modeling, and section 7 for useful formulas used

in this paper.

2.2 Measurements

We use three triaxial sensors providing nine scalar

measurements: 3 gyros measure ω

m

= ω + ω

b

, where

ω

b

is a constant vector bias; 3 magnetometers mea-

sure y

B

= b

s

q

−1

∗ B ∗ q, where B = B

1

e

1

+ B

3

e

3

is the

Earth magnetic ﬁeld in NED coordinates and b

s

> 0

is a constant scaling factor; 3 accelerometers measure

a

m

= a

s

a, where a

s

> 0 is a constant scaling factor.

As customary in low-cost unaided attitude heading

systems we assume the linear acceleration

˙

V small,

hence approximate the accelerometers measurements

by y

A

:= a

s

q

−1

∗ A ∗ q (the sign is reversed for conve-

nience). All the nine measurements are of course also

corrupted by noise.

There is some freedom in modeling the sensors

imperfections. A simple ﬁrst-order observability

analysis reveals that up to six unknown constants can

be estimated: besides the gyro bias ω

b

, it is possible

to estimate two imperfections on y

B

and one on a

m

, or

one on y

B

and two on a

m

. Nevertheless it is impossible

to model three imperfections on a

m

: in particular if

we write a

m

= a + a

b

, with a

b

a constant vector bias,

only two components of a

b

are observable; moreover,

only one imperfection on a

m

can be estimated without

relying on the possibly disturbed magnetic measure-

ments. On the other hand it is also impossible to es-

timate the three components of the magnetic ﬁeld B,

but only the North and Down components.

In an AHRS it is usually desirable to use the mag-

netic measurements to estimate only the heading, so

that a magnetic disturbance does not affect the es-

timated attitude. We will see this can be achieved

by considering y

C

:= y

A

× y

B

= c

s

q

−1

∗C ∗ q, where

c

s

:= a

s

b

s

> 0 and C := A × B, rather than the direct

measurement y

B

. Notice that hy

A

,y

C

i = hA,Ci = 0, so

that we are left with 8 independent measurements; as

a consequence only ﬁve unknown constants can now

be estimated. This is not a drawback and is even ben-

eﬁcial since the observer will then not depend on the

latitude-varying B

3

.

2.3 The Model

To design our observer we thus consider the system

˙q =

1

2

q ∗ (ω

m

− ω

b

) (1)

˙

ω

b

= 0 (2)

˙a

s

= 0 (3)

˙c

s

= 0 (4)

with the output

y

A

y

C

=

a

s

q

−1

∗ A ∗ q

c

s

q

−1

∗C ∗ q

. (5)

This system is observable since all the state vari-

ables can be recovered from the known quantities

ω

m

,y

A

,y

C

and their derivatives: from (5), a

s

=

1

g

k

y

A

k

and c

s

=

1

B

1

g

k

y

C

k

; hence we know the action of q on

the two independent vectors A and C, which com-

pletely deﬁnes q in function of y

A

,y

C

,a

s

,c

s

. Finally

(1) yields ω

b

= ω

m

− 2q

−1

˙q.

3 THE NONLINEAR OBSERVER

3.1 Invariance of the System Equations

There is no general method for designing a nonlinear

observer for a given system. When the system has a

rich geometric structure the recent paper (Bonnabel

et al., 2007) provides a constructive method to this

problem. In short, when a system of state dimen-

sion n is invariant by a transformation group of di-

mension r ≤ n, the method yields the general invariant

preobserver. More importantly the error between the

estimated and actual states is described in suitable in-

variant coordinates by a system of dimension 2n − r;

in particular the error system has dimension n when

the group has dimension n. This result, which is rem-

iniscent of the linear case, greatly simpliﬁes the con-

vergence analysis.

In our case the transformation generated by con-

stant rotations and translations in the body-ﬁxed

frame and output scaling

ICINCO 2008 - International Conference on Informatics in Control, Automation and Robotics

54

ϕ

(q

0

,ω

0

,a

0

,c

0

)

q

ω

b

a

s

c

s

=

q ∗ q

0

q

−1

0

∗ ω

b

∗ q

0

+ ω

0

a

0

a

s

c

0

c

s

ψ

(q

0

,ω

0

,a

0

,c

0

)

(ω

m

) = q

−1

0

∗ ω

m

∗ q

0

+ ω

0

ρ

(q

0

,ω

0

,a

0

,c

0

)

y

A

y

C

=

a

0

q

−1

0

∗ y

A

∗ q

0

c

0

q

−1

0

∗ y

C

∗ q

0

,

where q

0

is a unit quaternion, ω

0

a vector in R

3

and

a

0

,c

0

> 0, is easily seen to be a transformation group

with the same dimension as the system (1)–(4).

The system (1)–(4) is indeed invariant by the

transformation group since

˙

z

}|{

q ∗ q

0

= ˙q ∗ q

0

=

1

2

(q ∗ q

0

) ∗

(q

−1

0

∗ ω

m

∗ q

0

+ ω

0

)

− (q

−1

0

∗ ω

b

∗ q

0

+ ω

0

)

˙

z }| {

q

−1

0

∗ ω

b

∗ q

0

+ ω

0

= q

−1

0

∗

˙

ω

b

∗ q

0

= 0

˙

z}|{

a

0

a

s

= a

0

˙a

s

= 0

˙

z}|{

c

0

c

s

= c

0

˙c

s

= 0.

Notice also that from a physical and engineering

viewpoint, it is perfectly sensible for an observer us-

ing measurements expressed in the body-ﬁxed frame

not to be affected by the actual choice of coordinates,

i.e. by a constant rotation in the body-ﬁxed frame.

Similarly, a translation of the gyro bias by a vector

constant in the body-ﬁxed frame and output scalings

should not affect the observer. This is precisely what

the method of (Bonnabel et al., 2007) achieves.

3.2 The General Invariant Observer

Following the theory developed in (Bonnabel et al.,

2007), see also (Martin and Sala

¨

un, 2007) for details,

the general invariant observer writes

˙

ˆq =

1

2

ˆq ∗ (ω

m

−

ˆ

ω

b

) + (LE) ∗ ˆq (6)

˙

ˆ

ω

b

= ˆq

−1

∗ (ME) ∗ ˆq (7)

˙

ˆa

s

= ˆa

s

NE (8)

˙

ˆc

s

= ˆc

s

OE. (9)

Here the invariant output error E is the 5 × 1 vector

E :=

hE

A

,e

1

i,hE

A

,e

2

i,hE

A

,e

3

i,hE

C

,e

1

i,hE

C

,e

2

i

T

made up of the projections of the vectors

E

A

:= A −

1

ˆa

s

ˆq ∗ y

A

∗ ˆq

−1

E

C

:= C −

1

ˆc

s

ˆq ∗ y

C

∗ ˆq

−1

.

Only 5 of the 6 possible projections are independent

since hA,Ci = 0 and hy

A

,y

C

i = 0 imply

hE

A

,E

C

i = hA,E

C

i + hE

A

,Ci;

L,M are 3 × 5 matrices and N,O are 1 × 5 matrices

with entries possibly depending on the components

of E and of the complete invariant I deﬁned by

I := ˆq ∗ (ω

m

−

ˆ

ω

b

) ∗ ˆq

−1

.

It is easy to check this observer is invariant. No-

tice also the two built-in desirable geometric features:

k

ˆq(t)

k

=

k

ˆq(0)

k

= 1 since LE is a vector of R

3

(see

section 7); ˆa

s

(t), ˆc

s

(t) > 0 provided ˆa

s

(0), ˆc

s

(0) > 0.

3.3 The Invariant Error System

Following (Bonnabel et al., 2007), an invariant state

error is given by

η

β

α

γ

=

ˆq ∗ q

−1

q ∗ (

ˆ

ω

b

− ω

b

) ∗ q

−1

a

s

ˆa

s

c

s

ˆc

s

.

Therefore,

˙

η =

˙

ˆq ∗ q

−1

− ˆq ∗ (q

−1

∗ ˙q ∗ q

−1

) = (LE) ∗ η −

1

2

η ∗ β

˙

β = q ∗ (

˙

ˆ

ω

b

−

˙

ω

b

) ∗ q

−1

+ ˙q ∗ (

ˆ

ω

b

− ω

b

) ∗ q

−1

− q ∗ (

ˆ

ω

b

− ω

b

) ∗ q

−1

∗ ˙q ∗ q

−1

= (η

−1

∗ I ∗ η) × β + η

−1

∗ (ME) ∗ η

˙

α = −

a

s

˙

ˆa

s

ˆa

2

s

= −αNE

˙

γ = −

c

s

˙

ˆc

s

ˆc

2

s

= −γOE.

Since E is obtained from

E

A

= A −

a

s

ˆa

s

ˆq ∗ (q

−1

∗ A ∗ q) ∗ ˆq

−1

= A − αη ∗ A ∗ η

−1

E

C

= C − γη ∗C ∗ η

−1

we ﬁnd as expected that the error system

˙

η = (LE) ∗ η −

1

2

η ∗ β (10)

˙

β = (η

−1

∗ I ∗ η) × β + η

−1

∗ (ME) ∗ η (11)

˙

α = −αNE (12)

˙

γ = −γOE (13)

depends only on the invariant state error (η, β, α, γ)

and the “free” known invariant I, but not on the tra-

jectory of the observed system (1)–(4). This property

greatly simpliﬁes the convergence analysis of the ob-

server.

DESIGN AND IMPLEMENTATION OF A LOW-COST ATTITUDE AND HEADING NONLINEAR ESTIMATOR

55

The linearized error system around the no-error

equilibrium point (η,β,α,γ) = (1,0,1,1) then reads

δ

˙

η = LδE −

1

2

δβ (14)

δ

˙

β = I × δβ + MδE (15)

δ

˙

α = −NδE (16)

δ

˙

γ = −OδE, (17)

where δE is the 5 × 1 vector

hδE

A

,e

1

i,hδE

A

,e

2

i,hδE

A

,e

3

i,hδE

C

,e

1

i,hδE

C

,e

2

i

T

= g

−2δη

2

,2δη

1

,−δα,2B

1

δη

3

,−B

1

δγ

T

made up from the projections of the vectors

δE

A

= A ∗ δη − δη ∗ A − δαA = 2A × δη − δαA

δE

C

= 2C ×δη − δγC.

4 DESIGN OF L,M,N, O

Up to now, we have only investigated the structure of

the observer. We now must choose the gain matri-

ces L,M,N,O to meet the following requirements:

• the error must converge to zero, at least locally

• the local error behavior should be easily tunable,

if possible with a clear physical interpretation

• the magnetic measurements should not affect the

attitude estimate, but only the heading

• the behavior in the face of acceleration and/or

magnetic disturbances should be sensible and un-

derstandable.

4.1 Local Design

It turns out that the previous requirements can easily

be met locally around every trajectory by taking

L :=

1

2g

0 −l

1

0 0 0

l

2

0 0 0 0

0 0 0 −

1

B

1

l

3

0

M :=

1

2g

0 m

1

0 0 0

−m

2

0 0 0 0

0 0 0

1

B

1

m

3

0

N :=

1

g

0 0 −n 0 0

O :=

1

B

1

g

0 0 0 0 −o

for all constant l

1

,l

2

,l

3

,m

1

,m

2

,m

3

,n,o > 0. This will

follow from the very simple form of the linearized er-

ror system (14)–(17). We insist that it is not usually

obvious to come up with a similar convergence result

for an EKF.

Indeed, (14)–(17) now reads

δ

˙

η = D

l

δη −

1

2

δβ (18)

δ

˙

β = D

m

δη + I × δβ (19)

δ

˙

α = −nδα (20)

δ

˙

γ = −oδγ (21)

where

D

l

=

−l

1

0 0

0 −l

2

0

0 0 −l

3

D

m

=

m

1

0 0

0 m

2

0

0 0 m

3

.

When I = 0 (i.e. the system is at rest) the system

completely decouples into:

• the longitudinal subsystem

δ

˙

η

2

δ

˙

β

1

=

−l

1

−

1

2

0 m

1

δη

2

δβ

1

• the lateral subsystem

δ

˙

η

1

δ

˙

β

2

=

−l

2

−

1

2

0 m

2

δη

1

δβ

2

• the heading subsystem

δ

˙

η

3

δ

˙

β

3

=

−l

3

−

1

2

0 m

3

δη

3

δβ

3

• the scaling subsystem

δ

˙

α = −nδα

δ

˙

γ = −oδγ.

When I 6= 0 the longitudinal, lateral and heading sub-

systems are slightly coupled by the biases errors δβ.

We now prove (δη,δβ,δα,δγ) → (0,0,0,0) what-

ever (l

1

,l

2

,l

3

,m

1

,m

2

,m

3

,n,o) > 0. The scaling sub-

system obviously converges. For the other variables

we consider the Lyapunov function

V =

l

1

2

δη

2

1

+

l

2

2

δη

2

2

+

l

3

2

δη

2

3

+

1

4

kδβk

2

.

Differentiating V and using hδβ, I × δβi = 0, we get

˙

V = − (l

1

m

1

δη

2

1

+ l

2

m

2

δη

2

2

+ l

3

m

3

δη

2

3

) ≤ 0.

Since V is bounded from below, this implies that

V (δη(t),δβ(t)) converges as t → ∞. Since

lim

t→∞

Z

t

0

˙

V (δη(τ),δβ(τ))dτ = lim

t→∞

V (δη(t),δβ(t))

−V (δη(0),δβ(0)),

ICINCO 2008 - International Conference on Informatics in Control, Automation and Robotics

56

we conclude lim

t→∞

R

t

0

˙

V (δη(τ),δβ(τ))dτ exists and

is ﬁnite. On the other hand,

˙

V ≤ 0 also implies

0 ≤ V (δη(t),δβ(t)) ≤ V (δη(0),δβ(0)).

Therefore δη(t) and δβ(t) are bounded. Equation

(18) implies that δ

˙

η(t) is bounded too, and ﬁnally that

¨

V is bounded. Hence

˙

V is uniformly continuous and

by Barbalat’s lemma

˙

V → 0 ⇒ δη → 0.

Integrating (18), we get

Z

t

0

δ

˙

η(τ)dτ = δη(t) − δη(0)

=

Z

t

0

(D

l

δη(τ) −

1

2

δβ(τ))dτ.

Since δη(t) → 0, it follows

lim

t→∞

Z

t

0

(D

l

δη(τ) −

1

2

δβ(τ))dτ = −δη(0).

We assume I is bounded, which is physically sensible.

Since δη(t) and δβ(t) are bounded, D

l

δ

˙

η(t) −

1

2

δ

˙

β(t)

is bounded too. Hence D

l

δη(t) −

1

2

δβ(t) is uniformly

continuous. Applying Barbalat’s lemma once again

yelds

lim

t→∞

(D

l

δη(t) −

1

2

δβ(t)) = 0.

Since δη → 0, we conclude δβ → 0, which ends the

proof.

4.2 Global Design

We now look for correction terms ensuring global

convergence whereas preserving the previous nice

ﬁrst-order properties. It is useful to deﬁne the fol-

lowing vectors and error output:

D = C × A

y

D

= y

C

× y

A

E

D

= D −

1

ˆa

s

ˆc

s

ˆq ∗ y

D

∗ ˆq

−1

.

If we deﬁne the matrix L by

LE :=

l

a

g

2

A × E

A

+

l

c

(B

1

g)

2

C × E

C

+

l

d

(B

1

g

2

)

2

D × E

D

it is easy to see that the zero-order part of L is the

same as the constant L of section 4.1 with

l

1

= l

a

+ l

c

l

2

= l

a

+ l

d

l

3

= l

c

+ l

d

.

To ﬁnd a candidate Lyapunov function we also select

the matrices (M,N,O) by

ME := σLE

NE := n

l

a

g

2

E

T

A

(E

A

− A) +

l

d

(B

1

g

2

)

2

E

T

D

(E

D

− D)

OE := o

l

c

(B

1

g)

2

E

T

C

(E

C

−C) +

l

d

(B

1

g

2

)

2

E

T

D

(E

D

− D)

with (l

a

,l

c

,l

d

,σ,n,o) > 0. The positive function V :=

1

σ

k

β

k

2

+

l

a

g

2

k

E

A

k

2

+

l

c

(B

1

g)

2

k

E

C

k

2

+

l

d

(B

1

g

2

)

2

k

E

D

k

2

satisﬁes

˙

V ≤ 0. The convergence proof follows the

main lines of (Hamel and Mahony, 2006), with added

technicalities.

With these choices the ﬁrst-order behavior is the

same as in section 4.1. The difference is the existence

of the proportional factor σ between the l

0

i

s, m

0

i

s co-

efﬁcients. We now have only 4 independent gains for

the lateral, longitudinal and heading subsystems in-

stead of 6. We choose to ﬁx ﬁrst the natural frequen-

cies of the lateral (ω

l

), longitudinal (ω

L

) and heading

(ω

h

) subsystems. There is only 1 parameter left to ﬁx

the free damping ratios.

5 EFFECTS OF DISTURBANCES

Two main disturbances may affect the model.

When

˙

V 6= 0, the accelerometers measure in fact

a

s

q

−1

∗ A

∗

∗ q where A

∗

:= −

˙

V + A. Magnetic distur-

bances will also change B into some B

∗

. For simplic-

ity we consider that A

∗

, B

∗

are constant. The mea-

sured outputs now become

y

A

∗

y

C

∗

=

a

s

q

−1

∗ A

∗

∗ q

c

s

q

−1

∗C

∗

∗ q

.

The error system is unchanged but E is now the 5 × 1

vector

E :=

hE

A

,e

1

i,hE

A

,e

2

i,hE

A

,e

3

i,hE

C

,e

1

i,hE

C

,e

2

i

T

made up of the projections of the vectors

E

A

:= A −

1

ˆa

s

ˆq ∗ y

A

∗

∗ ˆq

−1

E

C

:= C −

1

ˆc

s

ˆq ∗ y

C

∗

∗ ˆq

−1

.

Let us deﬁne the points (η,β,α,γ) as following

β = 0

η ∗ A

∗

∗ η

−1

= (0 0

k

A

∗

k

)

η ∗C

∗

∗ η

−1

= (0

k

C

∗

k

0)

α =

k

A

∗

k

k

A

k

and γ =

k

C

∗

k

k

C

k

DESIGN AND IMPLEMENTATION OF A LOW-COST ATTITUDE AND HEADING NONLINEAR ESTIMATOR

57

Doing the frame rotation deﬁned by η we can deﬁne

the new variables

˜

η = η ∗ η

−1

˜

β = η ∗ β ∗ η

−1

˜

α = αα

˜

γ = γγ.

The error system with these new variables writes

˙

˜

η = −

1

2

˜

η ∗

˜

β + (

˜

L

˜

E) ∗

˜

η

˙

˜

β = (

˜

η

−1

∗

˜

I ∗

˜

η) ×

˜

β +

˜

η

−1

∗ (

˜

M

˜

E) ∗

˜

η

˙

˜

α = −

˜

α

˜

N

˜

E

˙

˜

γ = −

˜

γ

˜

O

˜

E

where the new output error

˜

E is made up of the pro-

jections of the vectors

˜

E

A

= A −

˜

α

˜

η ∗ A ∗

˜

η

−1

˜

E

C

= C −

˜

α

˜

η ∗C ∗

˜

η

−1

.

So (

˜

η,

˜

β,

˜

α,

˜

γ) verify the same error system as

(η,β,α,γ). In the new frame (A

∗

,C

∗

) play the same

role as (A,C). All the properties of the observer are

therefore preserved.

An important case is when only the magnetic ﬁeld

is perturbed, where we consider A and C

∗

= (C

∗

1

C

∗

2

0)

(instead of C = (0 gB

1

0)). Expliciting the new equi-

librium point (η,β,α,γ) of the error system it can be

seen that

φ = θ = 0 and ψ = arctan

C

∗

1

C

∗

2

β = α = 0 and γ =

k

C

∗

k

k

C

k

,

where (φ, θ, ψ) are the Euler angles corresponding to

η. In particular only the yaw angle ψ and γ are af-

fected by the magnetic disturbance.

6 EXPERIMENTAL VALIDATION

We now compare the behavior of our observer with

the commercial Microbotics MIDG II system used in

Vertical Gyro mode. The following results have been

obtained with the observer

˙

ˆq =

1

2

ˆq ∗ (ω

m

−

ˆ

ω

b

) + (LE) ∗ ˆq + k(1 −

k

ˆq

k

2

) ˆq

˙

ˆ

ω

b

= ˆq

−1

∗ (ME) ∗ ˆq

˙

ˆa

s

= ˆa

s

NE

˙

ˆc

s

= ˆc

s

OE

and the choice of matrices deﬁned by the parameters

below. The added term k(1 −

k

ˆq

k

2

) ˆq is a well-known

numerical trick to keep

k

ˆq

k

= 1. Notice this term is

also invariant.

We feed the observer with the raw measurements

from the MIDG II gyros, acceleros and magnetic

sensors. The observer is implemented in Matlab

Simulink and its values are compared to the MIDG II

results (computed according to the user manual by

some Kalman ﬁlter). In order to have similar behav-

iors, we have chosen

l

a

= 6e − 2 l

c

= 1e − 1 l

d

= 6e − 2

m

a

= 3.2e − 3 m

c

= 5.3e − 3 m

d

= 3.2e − 3

n = 0.25 o = 0.5.

6.1 Comparison with a Commercial

Device (Figure 1)

We ﬁrst want to put in evidence the different proper-

ties of our observer we mentioned before. Therefore

we did a long experience which can be divided into 3

parts:

• for t < 240s the system is left at rest until the

biases reach constant values. Fig.1(a) highlights

the importance of the correction term in the angle

estimation: without correction the estimated roll

angle diverges with a slope of −0.18

◦

/s (bottom

plot), which is indeed the ﬁnal value of the esti-

mated bias (middle plot) (Fig.1(a) and 1(b)).

• for 240s < t < 293s we move the system in all di-

rections. The observer and the MDG II give very

similar results (Fig.1(c)).

• at t = 385s the system is motionless and a magnet

is put close to the sensors for 10s. As expected

only the estimated yaw angle is affected by the

magnetic disturbance (Fig.1(d)); the MIDG II ex-

hibits a similar behavior.

6.2 Inﬂuence of the Observer

Correction Terms (Figure 2)

We have chosen the correction terms so as the mag-

netic measurements correct essentially the yaw angle

and its corresponding bias, whereas the accelerom-

eters measurements act on the other variables. We

highlight this property on the following experiment

(Fig.2). Once the biases have reached constant val-

ues, the system is left at rest during 35 minutes:

• for t < 600s the results are very similar for the

observer and the MIDG II.

• at t = 600s the “magnetic correction terms” are

switched off, i.e. the gains l

c

,l

d

,m

c

,m

d

and o are

ICINCO 2008 - International Conference on Informatics in Control, Automation and Robotics

58

0 20 40 60 80 100

−1

−0.5

0

0.5

Measured roll angular rate

(°/s)

0 20 40 60 80 100

−0.2

−0.1

0

Estimated roll angular rate bias

(°/s)

0 20 40 60 80 100

−10

0

10

Estimated roll angle

time(s)

(°)

With correction

Without correction

(a) Motionless estimated roll angle.

0 20 40 60 80 100 120 140 160

0

20

40

60

80

Estimated Euler angles

(°)

Roll

Pitch

Yaw

0 20 40 60 80 100 120 140 160

−1.4

−0.85

−0.3

0.25

0.8

time (s)

(°/s)

Estimated biases and scalings

0 20 40 60 80 100 120 140 160

0.7

0.775

0.85

0.925

1

Roll bias

Pitch bias

Yaw bias

Scaling a

s

Scaling c

s

(b) Motionless estimated gyros biases and Eu-

ler angles.

240 250 260 270 280 290 300 310

−200

0

200

Estimated Euler angles

(°)

φ MIDGII

estimated φ

240 250 260 270 280 290 300 310

−100

0

100

(°)

θ MIDGII

estimated θ

240 250 260 270 280 290 300 310

−200

0

200

time(s)

(°)

ψ MIDGII

estimated ψ

(c) Dynamic estimated Euler angles.

380 390 400 410 420 430 440 450 460 470

0

10

20

Estimated Euler angles with magnetic disturbance

(°)

380 390 400 410 420 430 440 450 460 470

0

10

20

(°)

380 390 400 410 420 430 440 450 460 470

0

50

100

time(s)

(°)

φ MIDGII

estimated φ

θ MIDGII

estimated θ

ψ MIDGII

estimated ψ

(d) Estimated Euler angles with magnetic dis-

turbances.

Figure 1: Experimental validation using Matlab.

0 500 1000 1500 2000

−20

−10

0

Estimated Euler angles

(°)

φ MIDGII

estimated φ

0 500 1000 1500 2000

−5

0

5

(°)

θ MIDGII

estimated θ

0 500 1000 1500 2000

140

145

150

time(s)

(°)

ψ MIDGII

estimated ψ

Figure 2: Inﬂuence of correction terms.

180 185 190 195 200

0

500

1000

1500

2000

2500

Estimations of the roll angle with acceleration

milli−g

180 185 190 195 200

−60

−40

−20

0

20

40

(°)

time(s)

norm(y

A

)

θ MIDGII with GPS

estimated θ

Figure 3: Estimated roll angle at

˙

V 6= 0.

set to 0. The yaw angle estimated by the ob-

server diverges because the corresponding bias is

not perfectly estimated. Indeed, these variables

are not observable without the magnetic measure-

ments. The other variables are not affected.

• at t = 1300s the “accelerometers correction

terms” are also switched off, i.e. l

a

,m

a

and n are

set to 0. All the estimated angles now diverge.

6.3 Acceleration Disturbance:

˙

V 6= 0

(Figure 3)

The hypothesis

˙

V = 0 may be wrong. In this case the

observer does not converge any more to the right val-

ues. Indeed we illustrate this point on the ﬁgure 3 by

comparing the roll angle estimated by our observer

and the roll angle estimated by the MIDG II in INS

mode (in this mode the attitude and heading estima-

tions are aided by a GPS engine, hence are close to

the “true” values).

DESIGN AND IMPLEMENTATION OF A LOW-COST ATTITUDE AND HEADING NONLINEAR ESTIMATOR

59

Figure 4: Experimental protocol.

7 IMPLEMENTATION ON A 8-BIT

MICROCONTROLLER

In the preceding section we validated the Matlab

Simulink implementation of our observer. To demon-

strate its computational simplicity we have also im-

plemented it on a 8-bit microcontroller (Atmel AT-

mega128 running at 11.0592MHz on development kit

STK500/501). The computations are done in C with

the standard ﬂoating point emulation. The microcon-

troller is fed with the MIDG II raw data at a 50Hz rate.

We have used a simple Euler explicit approximation

for the integration scheme.

The experimental protocol was the following:

1. move the sensors in all directions and save the

MIDG II raw measurements and estimations at

50Hz.

2. use of xPCTarget to feed the ATmega with these

data at 50Hz via a serial port and send at the same

time the estimated variables. given by the micro-

controller via a serial port to a computer

3. save these estimations.

4. compare ofﬂine the estimations given by the mi-

crocontroller and those given by the observer writ-

ten in the Matlab embedded function.

This protocol can be illustrated by the ﬁgure 4 where

xPCTarget has been replaced by the MIDG II.

We obtain the results of the ﬁgure 5. The two es-

timations are very similar. We see on the bottom plot

the discretization at 50Hz due to the microcontroller.

REFERENCES

Bonnabel, S., Martin, P., and Rouchon, P. (2007). Invari-

ant observers. arxiv.math.OC/0612193. Accepted for

publication in IEEE Trans. Automat. Control.

240 250 260 270 280 290 300 310

−200

−100

0

100

200

Comparison ATmega/Matlab

(°)

253.25 253.3 253.35 253.4

70

75

80

85

90

(°)

time(s)

φ ATmega

φ Matlab

φ ATmega

φ Matlab

Figure 5: Comparison ATmega/Matlab.

Collinson, R. (2003). Introduction to avionics systems.

Kluwer Academic Publishers, second edition.

Grewal, M., Weill, L., and Andrews, A. (2007). Global po-

sitioning systems, inertial navigation, and integration.

Wiley, second edition.

Hamel, T. and Mahony, R. (2006). Attitude estimation

on SO(3) based on direct inertial measurements. In

Proc. of the 2006 IEEE International Conference on

Robotics and Automation, pages 2170–2175.

Kayton, M. and Fried, W., editors (1997). Avionics naviga-

tion systems. Wiley, second edition.

Mahony, R., Hamel, T., and Pﬁmlin, J.-M. (2008). Non-

linear complementary ﬁlters on the special orthogonal

group. IEEE Trans. Automat. Control. To appear.

Mahony, R., Hamel, T., and Pﬂimlin, J.-M. (2005). Comple-

mentary ﬁlter design on the special orthogonal group

SO(3). In Proc. of the 44th IEEE Conf. on Decision

and Control, pages 1477–1484.

Martin, P. and Sala

¨

un, E. (2007). Invariant observers for

attitude and heading estimation from low-cost inertial

and magnetic sensors. In Proc. of the 46th IEEE Conf.

on Decision and Control.

Stevens, B. and Lewis, F. (2003). Aircraft control and sim-

ulation. Wiley, second edition.

Thienel, J. and Sanner, R. (2003). A coupled nonlinear

spacecraft attitude controller and observer with an un-

known constant gyro bias and gyro noise. IEEE Trans.

Automat. Control, 48(11):2011–2015.

APPENDIX: QUATERNIONS

Thanks to their four coordinates, quaternions provide

a global parametrization of the orientation of a rigid

body (whereas a parametrization with three Euler an-

gles necessarily has singularities). Indeed, to any

quaternion q with unit norm is associated a rotation

matrix R

q

∈ SO(3) by

q

−1

∗~p ∗ q = R

q

·~p for all ~p ∈ R

3

.

ICINCO 2008 - International Conference on Informatics in Control, Automation and Robotics

60

A quaternion p can be thought of as a scalar

p

0

∈ R together with a vector ~p ∈ R

3

,

p =

p

0

~p

.

The (non commutative) quaternion product ∗ then

reads

p ∗ q ,

p

0

q

0

−~p ·~q

p

0

~q + q

0

~p +~p ×~q

.

The unit element is e ,

1

~

0

, and

(p ∗ q)

−1

= q

−1

∗ p

−1

.

Any scalar p

0

∈ R can be seen as the quaternion

p

0

~

0

, and any vector ~p ∈ R

3

can be seen as the

quaternion

0

~p

. We systematically use these iden-

tiﬁcations in the paper, which greatly simpliﬁes the

notations.

We have the useful formulas

p × q , ~p ×~q =

1

2

(p ∗ q − q ∗ p)

(~p ·~q)~r = −

1

2

(p ∗ q + q ∗ p) ∗ r.

If q depends on time, then ˙q

−1

= −q

−1

∗ ˙q ∗ q

−1

.

Finally, consider the differential equation

˙q = q ∗ u + v ∗ q where u,v are vectors ∈ R

3

. Let q

T

be deﬁned by

q

0

−~q

. Then q∗q

T

=

k

q

k

2

. Therefore,

˙

z}|{

q ∗ q

T

= q ∗ (u + u

T

) ∗ q

T

+

k

q

k

2

(v + v

T

) = 0

since u, v are vectors. Hence the norm of q is con-

stant.

DESIGN AND IMPLEMENTATION OF A LOW-COST ATTITUDE AND HEADING NONLINEAR ESTIMATOR

61
