SECURE KNOWLEDGE EXCHANGE BY POLICY ALGEBRA AND
ERML
Steve Barker
Dept Computer Science, King’s College, London, U.K.
Paul Douglas
Westminster University, London, U.K
Keywords:
Database, Security, Logic Programming.
Abstract:
In this paper, we demonstrate how role-based access control policies may be used for secure forms of knowl-
edge module exchange in an open, distributed environment. For that, we define an algebra that a security
administrator may use for defining compositions and decompositions of shared information sources, and we
describe a markup language for facilitating secure information exchange amongst heterogeneous information
systems. We also describe an implementation of our approach and we give some performance measures, which
offer evidence of the feasibility of our proposal.
1 INTRODUCTION
We address the problem of securely exchanging
knowledge modules in the context of the Semantic
Web. The approach that we propose involves using a
form of Role-based Access Control (RBAC) (Barker,
2003), a module algebra, and a new form of markup
language. RBAC provides us with a way of defining
access control requirements to help to ensure the se-
curity of information sources that are represented as
identifiable modules, which can be composed using
algebraic operators; the markup language that we in-
troduce provides a way of securely exchanging acces-
sible information modules.
In related work, Bonatti et al (2002) describes an
approach for composing sets of authorization facts.
However, the advocated approach is applicable only
to “simple Horn clause” programs where composi-
tion of the least fixed point of programs is possi-
ble. The work of Wijesekera and Jajodia (2001) is
similar to Bonatti et al’s but Wijesekera and Jajodia
use a state transformation-based approach on (s,a,o)
triples, rather than using Horn clauses, to derive au-
thorization atoms. In both approaches, policy alge-
bras for discretionary access control policies are con-
sidered.
In our algebra, non-Horn specifications of policies
are possible and rather than viewing policy compo-
sition at the level of authorizations, composition op-
erators are defined on shareable information sources.
Moreover, our emphasis is on the use of RBAC poli-
cies represented by using rule-based specifications
with a meta-program used to process access requests.
The use of rule-based representations of access poli-
cies is well known in the security literature (see, for
example, Jajodia (2001), Barker (2000), and Barker
(2003)). Our work is also related to work on secure
XML (see Bhatti (2003), and Bertino (2004)), and to
work on RuleML (Boley, 2001). However, our ap-
proach is concerned with secure information sharing
amongst heterogeneous information systems, rather
than XML documents; for this, we propose an exten-
sion of RuleML.
The approach that we describe is based on a con-
cept that we call security filtering. That is, when a
user requests to access a set of information sources or
a subset of a information source then only the frag-
ment of knowledge that the user is authorized to see
is made available to them. The different informa-
tion systems that we consider in this paper are strat-
ified normal deductive databases (Baral, 1994), con-
straint databases (Marriott, 1998), and null-free and
aggregate-free SQL databases (Date, 2003).
The rest of the paper is organized thus. In Sec-
tion 2, preliminary notions are described. In Sec-
tion 3, we present an algebra for policy composition.
212
Barker S. and Douglas P. (2007).
SECURE KNOWLEDGE EXCHANGE BY POLICY ALGEBRA AND ERML.
In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 212-217
DOI: 10.5220/0002358402120217
Copyright
c
 SciTePress

In Section 4, we describe our markup language. In
Section 5 we describe a candidate implementation and
performance measures. Finally, in Section 6, conclu-
sions are drawn, and further work is suggested.
2 PRELIMINARIES
In this section, we briefly describe background ma-
terial to help to make the paper self-contained. Fur-
ther details on the databases that we consider may be
found in, for example, Abiteboul (1995) and Kuper
(2000).
Definition 2.1 A normal database is a finite set of
formulas of the form:
A ← A
1
,A
2
,... ,A
m
,not A
m+1
,not A
m+2
,. .. ,not A
m+n
.
The head A of the clause in Definition 2.1 is a sin-
gle atom. In the body of a clause
A
1
,A
2
,.. .,A
m
,not A
m+1
,not A
m+2
,.. .,not A
m+n
A
1
,A
2
,.. .,A
m
is a conjunction of atoms, and
not A
m+1
,not A
m+2
,.. .,not A
m+n
is a conjunction of
atoms negated by not where not is negation-as-failure
(Baral, 1994). A literal is an atom or its negation.
A clause with an empty body (i.e., A ←
/
0) is a fact.
In the discussion that follows, we represent the fact
A ←
/
0 by A, and we use the term rule to refer to a fact
or a clause with a non-empty body.
Definition 2.2 A constraint database (CDB) consists
of a finite set of rules of the following form (an
extended form of normal deductive rules):
A ← C
1
,C
2
,.. .,C
m
| L
1
,L
2
,.. .,L
n
(m ≥ 0, n ≥ 0).
The elements of the set {L
1
,L
2
,.. .,L
n
} are liter-
als, A is an atom, and C
1
,C
2
, . .. ,C
m
is a conjunction
of constraints.
1
Definition 2.3 A primitive constraint c has the form
p(t
1
,.. .,t
n
) where p is a (predefined) constraint rela-
tion of arity n and t
1
,.. .,t
n
are terms.
Definition 2.4 A constraint C is a conjunction of
primitive constraints c
1
∧ · ·· ∧ c
k
where ∧ is the logi-
cal ‘and’ operation.
In the normal databases that we use later, variables
appear in the upper case and using characters from the
end of the alphabet; constants appear in the lower case
and using characters from the start of the alphabet.
1
The | symbol is simply used to separate the conjunction
of constraints from the conjunction of literals L
1
,L
2
, ... ,L
n
;
the translators we describe later may be modified for use
with specific CDB systems.
We assume that the reader is familiar with basic
SQL, and recognises that a normal clause and a nor-
mal rule in the CDBs that we consider may be equiv-
alently represented in SQL and conversely.
In this paper, we restrict attention to the RBAC
F
model that is formally defined in Barker (2003) (i.e.,
flat RBAC as described by Sandhu (2001)).
2
From Barker (2003), we recall that, in formula-
tions of RBAC
F
policies, users are assigned to a role
by using definitions of a 2-place ura predicate (where
ura is short for “user role assignment”). The assign-
ment of an access privilege on an object to a role is ex-
pressed by using definitions of a 3-place pra predicate
in RBAC
F
policy specifications (where pra is short for
“permission role assignment”).
Example 2.5 Suppose that the users u
1
and u
2
are
assigned to the roles r
2
and r
1
respectively, and that
write (w) permission on object o
1
is assigned to r
1
and read (r) permission on o
1
is assigned to r
1
and
r
2
. Then, the following set of facts may be used to
represent the RBAC
F
policy in force:
{ura(u
1
,r
2
),ura(u
2
,r
1
), pra(w,o
1
,r
1
),
pra(r,o
1
,r
1
), pra(r,o
1
,r
2
)}.
A user u has the a access privilege on an object o
(i.e., the authorization (u,a,o) holds) from an RBAC
F
policy specification if a user u is assigned to a role r,
and r has been assigned the a access privilege on o.
In terms of normal clauses, authorization triples are
defined thus:
access(U,A,O) ← ura(U,R), pra(A,O,R).
Example 2.6 By inspection of the user-role and
permission-role assignments that are specified in Ex-
ample 2.5, it follows that the following set of au-
thorizations apply (the extension of the predicate
access/3):
{access(u
1
,w,o
1
),access(u
1
,r, o
1
),access(u
2
,r, o
2
)}.
As a final point on preliminaries, in our proposal
each information source to be protected is uniquely
identifiable. We use the notation, υ ≡
I (where υ may
be subscripted) to denote that the information source
I is identified by υ (e.g., in a Web context, υ is a
uniform resource identifier).
3 A POLICY ALGEBRA
In this section, we describe an algebra for information
source definition and manipulation. Our algebra is in-
dicative of the type of algebra that security adminis-
trators may use to define access control requirements.
2
Extending our approach to allow for richer RBAC mod-
els is a straightforward matter.
SECURE KNOWLEDGE EXCHANGE BY POLICY ALGEBRA AND ERML
213

The algebra may be extended to permit other forms of
policy to be defined.
3.1 Grammar
The grammar that we propose for the algebra of infor-
mation sources that are identified by υ
i
and υ
j
may be
expressed thus:
| υ
i
| υ
i
∪ υ
j
| υ
i
∩ υ
j
| υ
∗
i
| υ
i
◦ υ
j
|
The operators in our algebra are defined next. In
these definitions, B (possibly subscripted) denotes the
body of a rule in normal database, a CDB, or the SE-
LECT clause in a view definition.
Definition 3.1 Let υ
i
and υ
j
be the identifiers for two
information sources, then:
υ
i
∪ υ
j
de f
= {L ← B : L ← B ∈ υ
i
∨ L ← B ∈ υ
j
}.
The ∪ operator is used to combine the rules in dif-
ferent databases. For example, given υ
10
≡ p(X) ←
q(X) and υ
11
≡ p(X) ← r(X), for υ
10
∪ υ
11
we have:
p(X) ← q(X).
p(X) ← r(X).
Definition 3.2 Let υ
i
and υ
j
be the identifiers for two
information sources in a universe, then:
υ
i
∩ υ
j
def
= {L ← B : L
i
← B
1
∈ υ
i
∧ L
j
← B
2
∈ υ
j
∧
θ = mgu(L
i
,L
j
) ∧ L = L
i
θ ∧ B = {B
1
,B
2
}θ}
where mgu(L
i
,L
j
) is the most general unifier of L
i
and L
j
(see Apt, 1997).
The ∩ operator is used when rules that are com-
mon to a information source need to be included in a
composite information source. As a simple example,
{p(a,b),q(a,b)} ∩ {p(a,b)} generates {p(a,b)}.
Definition 3.3 Let υ
i
denote an information source
in a universe and let β(υ
i
) be the closure of the infor-
mation source identified by υ
i
under a consequences
operator |= (i.e., β(υ
i
) is the set of all literal con-
sequences of the information source identified by υ
i
)
then:
υ
∗
i
de f
= {L : L ∈ HBASE(υ
i
) ∧ L ∈ β(υ
i
)}
where HBASE(υ
i
) is the Herbrand Base of υ
i
(see
Abiteboul, 1995).
The ∗ operator is useful from a security view-
point for restricting a information source
K to just
the atomic consequences of
K .
Definition 3.4 Let υ
i
and υ
j
be the identifiers for two
information sources, in a universe, let LIT(L) denote
the predicate symbols of literals in HBASE(υ
i
) ∪
HBASE(υ
j
), and let γ(υ
i
) be the literals defined in
the information source identified by υ
i
, then:
L υ
i
◦ υ
j
de f
= υ
i
∪
{L ← B : L ← B ∈ υ
j
∧ LIT(L) 6∈ γ(υ
i
)}.
The algebraic expression υ
i
◦ υ
j
is used to specify
that the definitions in υ
i
override the definitions in υ
j
when common predicates are defined. For example,
for υ
10
≡ p(X) ← q(X) ◦ υ
11
≡ p(X) ← r(X), we
have υ
10
≡ p(X) ← q(X).
To understand the use of our algebra, we present
some examples of its use. For the examples, we con-
sider the following normal database
υ
1
≡
(
p(X,Y) ← q(X,Y).
q(a,2).
the constraint database
υ
2
≡
(
p(X,Y) ← Y < 2 | r(X,Y).
r(b, 2).
and the SQL database, identified by υ
3
, that includes
the view definition
create view s as select * from v
where v.A 6= b ;
together with the SQL table, called v, in Figure 1.
A B
a 1
b 2
Figure 1: The SQL table v in υ
3
.
Example 3.5 Consider υ
1
and υ
2
from the set of
databases above. Then, υ
1
∪ υ
2
defines the following
information source:
p(X,Y) ← q(X,Y).
p(X,Y) ← Y < 2 | q(X,Y).
q(a,2).
r(b, 2).
Example 3.6 The algebraic expression
∪(υ
∗
3
,◦(υ
1
,υ
2
))
defines the following information source:
p(X,Y) ← q(X,Y).
q(a,2).
r(b, 2).
s(a,1).
where υ
∗
3
= s(a,1).
ICEIS 2007 - International Conference on Enterprise Information Systems
214

3.2 Access Request Evaluation
To process a user’s access request, we use the follow-
ing meta-program (in which a is short for “access”):
a(U,read,X) ← ura(U,R), pla(read, X,R).
a(U,read,∪(X,Y)) ← a(U,read,X),a(U,read,Y).
a(U,read,∩(X,Y)) ← a(U,read,X),a(U,read,Y).
a(U,read,◦(X,Y)) ← a(U, read, X), a(U,read,Y).
The following points should be noted about the
meta-program:
• We restrict attention to retrieval/read requests.
However, any number of access privileges may be
supported in our approach.
• Request evaluation is always performed with re-
spect to propositional theories because the meta-
program processes module identifiers.
• The meta-program may be used to process access
requests in the case where an agent requests to ei-
ther retrieve a knowledge module that a security
administrator has predefined, by using the secu-
rity algebra, or to retrieve a specific knowledge
module that the agent wishes to retrieve.
• We adopt a file-oriented semantics for our alge-
bra (not a consequence-oriented semantics). This
is because we do not restrict attention to informa-
tion sources that are categorical; our approach is
file-based rather than rule-based because the lat-
ter raises a number of semantic and practical is-
sues relating to rule identification. Although, at
first sight, it may be argued that file level access
is overly blunt, it must be noted that the security
administrator can use the algebra to define very
fine-grained information sources.
Example 3.7 Consider the user-role and permission-
role assignments from Example 2.5 together with the
following expression:
access(bob,read, ∪(υ
1
,∩(υ
2
,◦(υ
∗
3
,υ
4
)))).
The
access/3 expression represents a request by an
agent Bob to access the information source that is
specified by:
∪(υ
1
,∩(υ
2
,◦(υ
∗
3
,υ
4
))).
Conversely, suppose that a security administrator
has included the following expressions in an access
policy specification:
υ
8
≡ ∪(υ
1
,∩(υ
2
,◦(υ
∗
3
,υ
4
))).
pla(read,υ
8
,r
1
).
Then, access(bob,read, υ
8
) may be used to gen-
erate (for Bob) the information source defined by
∪(υ
1
,∩(υ
2
,◦(υ
∗
3
,υ
4
))).
4 ERML
In this section, we describe the markup language that
we propose for use for secure knowledge exchange
between heterogeneous information sources. Our
markup language, called ERML (see Barker, 2004),
is an extended form of RuleML (version 0.9) that
enables, amongst other things, the set of operators
{+,−,÷, ×,<,≤,=,6=,≥,>} to be represented in:
the body of a normal clause, the specification of a
WHERE clause in an SQL view definition, and for
constraint formulation in a CDB. In the ensuing dis-
cussion, we use Φ to denote the set of comparison
operators {<, ≤,=,6=,≥, >}, and Γ to denote the set
of arithmetic operators {+,−,÷, ×}.
The general format for a rule in ERML is as
follows:
<imp>
<
head> conc </ head>
<
body>
<
constraint>
<and>
<builtin>
<cop> φ < /cop >
< /builtin >
< builtin >
< aop > γ < /aop >
< /builtin >
</and>
</
constraint>
<and>
<atom>
...
</atom>
<builtin>
<cop> φ < /cop >
< /builtin >
< builtin >
< aop > γ < /aop >
< /builtin >
</and>
</
body>
</imp>
Here, < imp > is a tag that is used to denote an
implication i.e., a normal rule, a rule in a CDB, or
a view definition in SQL. The < head > tag is used
to represent the head of a normal rule, the head of a
rule in a CDB (with arguments if any), or the name of
the view definition v
de f
together with the attributes of
v
de f
. The < body > tag, as the name suggest, is used
to represent the body of a normal rule, a CDB rule,
or the SELECT statement that defines a view. The
SECURE KNOWLEDGE EXCHANGE BY POLICY ALGEBRA AND ERML
215

tag < cop > is used to refer to a comparison operator
φ ∈ Φ, and < aop > is a tag for markup that refers
to an arithmetic operator γ ∈ Γ. We use strings of
characters to denote the operators in Φ ∪ Γ when
these operators are used in ERML documents. For
example, gteq is used for ≥; all of the operators in
Φ ∪ Γ can be assigned a literal value that may be
used in ERML documents.
The negation of an atom is expressed by using a
<not> A </not> element where not is interpreted
as negation-as-failure and A is an atom.
3
The general format for a fact in ERML is as
follows:
<fact>
<
head> conc </ head>
<
body>
<atom>
...
</atom>
</
body>
</fact>
The var value in the tag < var > is short for vari-
able. To represent constants, < ind > is used e.g.,
< ind > 10 < /ind > denotes the constant 10.
A user’s request to access a knowledge source r
k
is handled by a 2-phase process:
• In the initial phase, evaluation of an access request
is performed using the meta-program and a speci-
fication of an RBAC policy to determine whether
u
i
is permitted to exercise the p
j
privilege on r
k
.
• In the second phase, the authorized actions involv-
ing r
k
are performed. If permitted by the access
policy in force, r
k
(and DTDs or XML Schema
declarations, as appropriate) is transmitted to the
requester in ERML form.
The information, in ERML form, returned to a re-
quester can be manipulated using the rule engines that
are available on the requester’s machines. To enable
this, we have developed XSLT stylesheets to trans-
form ERML into XSB, SQL, and CDBs. For the
translation of SQL view definitions, we adopt a 2-
step approach that involves converting SQL to normal
clause form and then calling the XSB to ERML trans-
lator to generate the ERML form of the SQL view
definition. Our conversion software converts facts in
a base table
T to ERML by converting each row in
3
We do not consider ERML with a <neg> A </neg>
element, for explicit negation, because the information
sources that we consider are normal databases, CDBs and
SQL databases. However, our DTD includes a <not> A
</not> element to accommodate a classical negation op-
erator.
T to an ERML fact (see above). We have chosen
the 2-step approach to implementation, rather than us-
ing Eberhardt’s OntoSQL translator (see Eberhardt,
2002), for a number of reasons. For instance, our ap-
proach enables arbitrary n-ary relations to be manipu-
lated (not just binary relations) and our approach en-
ables SQL, with arithmetic, to be translated into CDB
form for efficient processing. Our two-stage approach
imposes no significant overhead relative to the pro-
cessing costs incurred using a single phase translator
like OntoSQL.
Example 4.1 Consider the request
access(bob,read, ∪(υ
14
,υ
15
)) such that Bob is
permitted read access on υ
14
and υ
15
and where
υ
14
≡ {q(a, 2)} and υ
15
≡ {p(X,Y) ← r(X,Y)}.
Then, the following ERML code is what Bob is
permitted to have delivered to his machine:
<rulebase>
<fact>
<atom>
<_opr><rel>q</rel></_opr>
<ind>a</ind>
<ind>2</ind>
</atom>
</fact>
<imp>
<_head>
<atom>
<_opr><rel>p</rel></_opr>
<var>X</var>
<var>Y</var>
</atom>
</_head>
<_body>
<atom>
<_opr><rel>r</rel></_opr>
<var>X</var>
<var>Y</var>
</atom>
</_body>
</imp>
</rulebase>
5 PRAGMATICS
In this section, we describe implementation issues and
some performance measures.
We note that one of the first declarative transla-
tors was GEDCOM (Dean, 2001), which (in alter-
native versions) uses XSLT to produce output suit-
able for use with either XSB Prolog or Jess (Grosof,
2002). However, we have tested the XSB version of
GEDCOM and found it rather unreliable when used
with real-world marked-up Prolog programs. More-
over, as XSLT only works on tags embedded within
ICEIS 2007 - International Conference on Enterprise Information Systems
216

an XML document, and as these are necessarily ab-
sent from, for example, a Prolog program, a declar-
ative translator in the style of GEDCOM is not pos-
sible. SweetJess (Grosof, 2002) offers robust proce-
dural, bi-directional translation from RuleML to XSB
Prolog; however, it is significantly more cumbersome
to deploy than a declarative system.
For our implementation, we have written a parser
in C (for the details, see www.cscs.wmin.ac.uk/ ∼
douglap/translator.c). Our parser is able to trans-
form Prolog and various CDB forms into ERML,
and can generate ERML from XSB Prolog, SQL or
ECLIPSE. We have tested our translator on a infor-
mation source containing 3,000 facts and rules (in
normal clause form). The C translator took an av-
erage (over 10 runs) of 0.043 seconds to convert the
information source into a ERML format. We used
the Saxon XSLT processor (Kay, 2001) to convert
the ERML file back into normal clause form/Prolog,
which took an average of 2.455 seconds.
4
Thus, the
bidirectional translator for ERML-SQL conversion
adds no appreciable computation costs to access re-
quests. The time taken by our meta-program to eval-
uate access requests is of the order of a few millesec-
onds; the size of the access control program has very
little affect on the timings. It follows that access re-
quest checking and authorized knowledge base gener-
ation can be performed in a time of the order of a few
seconds (for large information sources).
6 CONCLUSIONS
The principal contributions of our work have been: to
specify an algebra that may be used by security ad-
ministrators to define information sources that may
be securely exchanged between agents using hetero-
geneous systems; to define a small but powerful ac-
cess control program that determines what a user is
permitted to access given an RBAC
F
policy specifica-
tion; and to introduce a markup language that permits
secure forms of information sources to be exchanged
between heterogeneous information systems.
In future work, we wish to investigate implemen-
tations of our approach with more expressive alge-
bras. Although RBAC
F
policies are adequate for the
work that we have carried out, we intend to experi-
ment with more expressive forms of RBAC policies in
future work. The approach that we describe may be
applied to problems in secure business rule process-
ing, secure e-commerce, and secure e-contracting. A
4
These results were obtained on a Sun Sparc Ultra 10
machine with a 440MHz CPU and 1Gb RAM running So-
laris 10.
matter for further work is to investigate these applica-
tions.
