REMOTE ALGORITHMIC COMPLEXITY ATTACKS AGAINST

RANDOMIZED HASH TABLES

Noa Bar-Yosef

∗

School of Computer Science

Tel Aviv University, Ramat Aviv 69978, Israel

Avishai Wool

School of Electrical Engineering

Tel Aviv University, Ramat Aviv 69978, Israel

Keywords:

Algorithmic complexity attack, denial of service, packet ﬁlter.

Abstract:

Many network devices, such as routers, ﬁrewalls, and intrusion detection systems, usually maintain per-

connection state in a hash table. However, hash tables are susceptible to algorithmic complexity attacks,

in which the attacker degenerates the hash into a simple linked list. A common counter-measure is to ran-

domize the hash table by adding a secret value, known only to the device, as a parameter to the hash function.

Our goal is to demonstrate how the attacker can defeat this protection: we demonstrate how to discover this

secret value, and to do so remotely, using network trafﬁc. We show that if the secret value is small enough,

such an attack is possible. Our attack does not rely on any weakness of a particular hash function and can

work against any hash — although a poorly chosen hash function, that produces many collisions, can make

the attack more efﬁcient. We present a mathematical modeling of the attack, simulate the attack on different

network topologies and ﬁnally describe a real-life attack against a weakened version of the Linux Netﬁlter.

1 INTRODUCTION

1.1 Background

Many network devices, such as routers, ﬁrewalls, and

intrusion detection systems, need to maintain per-

connection state. One commonly used data struc-

ture of choice is a hash table. This choice is mainly

based on the fact that in the average case retrieving

elements from a hash table takes an expected O(1)

operations, independent of the number of connection

states. However, in the worst case, a hash table can

also degenerate into a linked list, and operate in O(n)

steps. Because of this, (Crosby and Wallach, 2003)

showed that an attacker can remotely mount an “algo-

rithmic complexity attack” against the hash table: if

the attacker knows the victim’s hash function, she can

force this worst case behavior by producing a long

sequence of items that are placed in the same hash

bucket, thereby exhausting the device’s CPU time.

∗

Supported by the Deutsch Institute

A common counter-measure is to randomize the

hash table: this is the approach taken by Netﬁlter (Fil-

ter, ). To do so, the hash function calculation includes

a secret random value known only to the device. Ran-

domizing the details of the hash calculation is sup-

posed to disable the attacker’s ability to manufacture

items that, predictably, fall into the same hash bucket.

In this work, we show that randomized hash tables are

not necessarily the correct measure to apply, and that

under certain circumstances, given enough time and

space, an adversary can still force the device’s hash

table to perform in its worst case behavior and mount

an algorithmic complexity attack.

1.2 Related Work

Our research builds upon the work of (Crosby and

Wallach, 2003). In their paper they introduce a fam-

ily of low-bandwidth denial of service attacks called

algorithmic complexity attacks, which exploit algo-

rithms’ worst-case behaviors. The focus of their work

is on deterministic hash tables. Using their method,

117

Bar-Yosef N. and Wool A. (2007).

REMOTE ALGORITHMIC COMPLEXITY ATTACKS AGAINST RANDOMIZED HASH TABLES.

In Proceedings of the Second International Conference on Security and Cryptography, pages 117-124

DOI: 10.5220/0002118101170124

 SciTePress

the adversary can create speciﬁc inputs that all fall

into the same hash bucket, causing the hash table to

degenerate into a simple linked list. They successfully

carried out their attacks on different applications, such

as the IDS, Bro (Paxson, 1999) and several Perl ver-

sions. They showed how within 6 minutes they were

able to cause the server to consume all of its CPU as

well as to drop most of its received packets.

A low-bandwidth attack differs from other com-

mon TCP attacks that exhaust the server’s resources,

such as memory or bandwidth, resulting in a denial of

service (Needham, 1993). A typical (high bandwidth)

attack that exhausts the server’s backlog queue is the

well-known syn-ﬂooding attack (SYN ﬂood, 1996).

The attacker basically ﬂoods the victim with more

trafﬁc than the victim can process.

The difﬁculty with a low-bandwidth attack is that

it is much harder to detect than a ﬂooding attack. The

aim in low-bandwidth attacks is not to explode the

server’s resources in an aggressive manner, but rather

to exploit vulnerabilities in the server slowly, culmi-

nating in a denial of service. For example, (Kuz-

manovic and Knightly, 2003) discuss a low-rate de-

nial of service attack that exploits the retransmission

timeout mechanism in TCP. By sending small bursts

of packets at just the right frequency, the attacker can

cause all TCP ﬂows sharing a bottleneck link to si-

multaneously stop indeﬁnitely. And because the at-

tacker only needs to burst periodically, the attack traf-

ﬁc will be difﬁcult to distinguish from normal trafﬁc.

The notion of a low-bandwidth attack exploiting

an algorithm’s worst case can be traced back to an

attack using nested HTML tables. Some browsers’

algorithms perform super-linear work to determine

the layout of the table. Thus, a maliciously crafted

web page can cause the browser to freeze (Garﬁnkel,

1996). (Dean and Stubbleﬁeld, 2001) propose a so-

lution to an attack against an SSL server that may

lead to the paralysis of e-commerce websites. In their

scenario, the attacker requests the server to engage

in expensive RSA decryptions without ﬁrst having

done any work. An algorithmic complexity attack

can also be performed against the quicksort algorithm

as shown by (McIlroy, 1999). Quicksort is a com-

mon choice of sorting algorithm because of its ex-

pected average-case running time of O(nlogn). How-

ever, McIlroy provides a way to force quicksort into

achieving its worst case running time of O(n

). An-

other example includes the attack presented in (Gal

et al., 2004). In their work, the attacker takes ad-

vantage of the fact that the Java bytecode veriﬁca-

tion scales quadratically with the size of the program

and so keeps the veriﬁer busy in order to constitute

a denial of service. The authors develop this no-

tion in order to construct complexity attacks against

mobile-code systems. They show the difﬁculty of

conventional defenses thwarting the attack since the

attack not only is located ahead of the point at which

run-time resource control sets in but it also attacks

the mechanism that ensures safety in regards to the

Java Bytecode veriﬁer. It is worthwhile to mention a

more recent paper by the aforementioned authors (Gal

et al., 2005) where they warn that algorithmic com-

plexity attacks are going to be prevalent on all sys-

tems, from mobile code systems, to software appli-

cations, and hardware. These authors then advocate a

new security paradigm based on complexity-hardened

systems.

Our attack strategy involves guessing the secret

random value of the hash function parameter. The

technique resembles those implemented in timing at-

tacks where the attacker determines a victim’s secret

by analyzing the victim’s processing time remotely

over the Internet. For example, (Boneh and Brumley,

2003) devise a timing attack against OpenSSL where

the client is able to extract the private key stored on

the server by measuring the time the server takes to

respond to decryption queries. More recently (Kohno

et al., 2005) showed how to ﬁngerprint a device re-

motely by ﬁnding microscopic deviations according

to each computer’s unique clock skew. A practi-

cal timing attack is mentioned in RFC 4418, Mes-

sage Authentication Code using Universal Hashing

(UMAC) (RFC4418, ), which warns of a possible tim-

ing attack in the UMAC algorithm since the behav-

ior of the algorithm differs according to the length

of the inputted string. In (Shacham et al., 2004),

the authors show a practical timing attack in which

they overcame anti-buffer overﬂow memory random-

ization protection techniques. Many operating sys-

tems now randomize their initial address space as a

way to avoid buffer overﬂow attacks. However, the

authors show a feasible way to ﬁnd the random value,

and thus the address space is calculated in a straight-

forward manner leaving the system once again vulner-

able to buffer overﬂow attacks. They further investi-

gate various strengthing address-space randomization

techniques.

1.3 Contributions

Our starting point is the observation that if the at-

tacker can discover the secret value that is used inside

the server’s hash function calculation, then she can

mount the algorithmic complexity attack of (Crosby

and Wallach, 2003). Therefore, our goal is to demon-

strate how the attacker can discover the secret value,

and to do so remotely, using network trafﬁc. We show

SECRYPT 2007 - International Conference on Security and Cryptography

118

that if the secret value is small enough, such an attack

is possible. Our attack does not rely on any weakness

of a particular hash function and can work against any

hash, including cryptographic hashes

— although a

poorly chosen hash function, that produces many col-

lisions, can make the attack more efﬁcient.

The attack scenario we envision consists of two

stages: (i) An ofﬂine calculation and information

gathering stage, followed by (ii), a full-blown algo-

rithmic complexity attack. In this paper we focus on

the ﬁrst stage.

Our attack is an exhaustive search performed

against all possible choices of the secret value. For

each candidate secret value, X

, we produce a set of

packets that would hash to the same bucket, send them

to the server, and measure the round-trip time (RTT).

If the server’s secret value is X

, then there will be a

slowdown in the RTT. After trying all the possible val-

ues X

the one causing the longest RTT is likely to be

the correct secret X

. The challenges we face are: (i)

Being able to produce enough attack packets so that

RTT slowdown will be signiﬁcantly longer than nor-

mal network RTTs, and (ii), doing so in a way that lets

the attacker receive the server’s responses, so she can

measure the RTT — i.e., without spooﬁng the source

IP address.

We demonstrate, via mathematical analysis, that

the attack is plausible. We then conducted a simula-

tion study, followed by an actual implementation of

the attack against Netﬁlter. Both simulations and im-

plementation show that the attack is very realistic for

secret values of 13-14 bits using current hardware.

Organization: In Section 2 we describe the al-

gorithmic complexity attack of (Crosby and Wal-

lach, 2003) and the Linux Netﬁlter. In Section 3 we

describe our attack and provide some mathematical

modeling about its properties. In Section 4 we de-

scribe an attack implementation against a weakened

version of the Linux Netﬁlter stateful ﬁrewall. We

conclude in Section 5.

The reason is that the number of buckets in the hash ta-

ble is, intentionally, rather small—the default value for net-

ﬁlter is 8192 buckets. Even a strong cryprographic hash will

produce many bucket collisions once its output is reduced

modulo 8192.

2 PRELIMINARIES

2.1 Algorithmic Complexity Attacks

Against Hash Tables

In a hash data structure, an item is hashed through

a hash function which produces a hash output. The

output is then stored in the hash bucket, correspond-

ing to the output modulo the number of buckets in

the hash table. Items that hash into the same bucket

form a linked list in that hash bucket. In order to re-

trieve a stored item, the server ﬁrst computes the hash

function to ﬁnd the correct bucket, and then traverses

through the list in the corresponding hash bucket to

locate the item. A properly implemented hash func-

tion will distribute its inputs evenly throughout the ar-

ray, creating very short lists in the buckets, so that

retrieving a stored item will perform in an O(1) av-

erage lookup time. However, if an adversary knows

the details of the hash function, can control its input,

and if the number of buckets is small enough, then

she can produce inputs that all collide into the same

hash bucket. In the worst case scenario one will have

to traverse a list of all the items stored, resulting in

the same lookup time complexity as that of a regular

linked list, O(n), assuming n elements were hashed.

What (Crosby and Wallach, 2003) did was to demon-

strate that an attacker can force such worst-case be-

havior, over the Internet, against a variety of network

devices. If the attacker can cause all the hash lookups

to run in O(n) steps — she can waste enough CPU

time on the server to create a denial of service condi-

tion.

Note that a malicious attacker can induce such

worst-case behavior against any hash function, in-

cluding cryptographic hash functions. Our method

does not rely on the strength of the algorithm itself,

but rather on the search space of the secret input key.

Since the input space is much larger than the hash ta-

ble size, many hash collisions are bound to occur. If

the hash function is weak, then the attacker can easily

ﬁnd many inputs with the same hash. But even for

an ideal hash function the attacker can run an ofﬂine

computation and ﬁnd a large set of items that fall into

the same bucket.

2.2 Linux Netﬁlter

We tested our attack against the hash table stored

in Linux’ Netﬁlter (Filter, ), which is the Linux IP

ﬁrewall. The current Netﬁlter release is used in the

2.4 and 2.6 Linux kernels. Netﬁlter contains a state-

ful packet ﬁltering module called ip conntrack which

keeps state for each connection. Prior to the work of

REMOTE ALGORITHMIC COMPLEXITY ATTACKS AGAINST RANDOMIZED HASH TABLES

119

(Crosby and Wallach, 2003), users of Netﬁlter com-

plained already in July 2002 of a server slowdown

that was attributed to a poor choice of hash function.

In response to this issue, the developers of Netﬁl-

ter switched their hash function to the Jenkins’ hash

(Jenkins, 1997), and additionally included a random

secret value, known only to the server, as a param-

eter to the hash function. Thus, the Netﬁlter hash is

protected against the basic attack of (Crosby and Wal-

lach, 2003).

As it is used in Netﬁlter, the Jenkins’ hash receives

4 parameters, each of 32 bits in length as follows: (i)

the packet’s source IP address, (ii) the packet’s des-

tination IP address XORed with the connection pro-

tocol number, (iii) a concatenation of the source and

destination ports, and (iv) the secret random value

known only to the ip conntrack module.

Rather than analyzing the uniformity of the bit-

mixing in the Jenkins’ hash (thus ﬁnding hash colli-

sions), we consider the Jenkins’ hash as a “black-box”

which receives the above 4 parameters for each con-

nection and returns a 32-bit output modulo the num-

ber of hash buckets. Our attack is based on creating

packets that cause enough bucket collisions to achieve

a recognizable slowdown.

The default conntrack hash table size is 2

buck-

ets. It is worth noting that the Linux developers rec-

ommend that a server used only as a ﬁrewall should

increase the size of the hash table. Furthermore, the

Netﬁlter developers limit the total number of connec-

tions in the hash table to 8 times the number of buck-

ets, giving a default maximum of 2

connections.

This limited capacity is actually a security measure:

the attacker cannot attack the hash table by exploding

the memory. On the other hand, as we shall see, the

capacity is not small enough to avoid a server perfor-

mance degradation. Throughout this paper, we con-

sider ip conntrack in its default settings.

3 ATTACK OVERVIEW

3.1 Attack Constraints

To conduct an efﬁcient remote algorithmic complex-

ity attack against a hash table, the following prereq-

uisites must be met: (i) the hash function (except the

secret value) must be known to the attacker, (ii) the

attacker must be able to produce enough packets that

In fact, the number of possible connections stored in

the hash is 2

. However, each connection and its reversed

tuple gets stored in the hash table, giving us a hash table

capacity of 2

fall into the same bucket, and (iii), the attacker must

be able to deliver these packets to the victim’s server.

For network devices that track TCP/UDP connec-

tions, the items to be hashed are usually deﬁned by

the 96-bit tuple < src addr, src port, dst addr, dst

port >. The IP addresses are 32 bits each, and each

port is of 16 bits length. However, the attacker can-

not manipulate all 96 bits to produce collisions. First,

the destination must be ﬁxed to contain the victim’s

IP address. Next, most servers do not have all their

ports open. In fact, many only have as few as two

or three open ports. Therefore, for a basic algorith-

mic complexity attack (Crosby and Wallach, 2003),

the attacker can manipulate the 32-bit source address,

the 16-bit source port, and a few choices for destina-

tion port, which we take as another 2 bits, giving a

total of 50 bits. As a result, the attack relies heavily

on source IP address spooﬁng.

However, when we are attempting to determine

the secret value in a randomized hash table (in the

information gathering stage), we need to compute the

RTT so we can detect the server’s slowdown — i.e.,

the attacker needs to receive the server’s SYN-ACK

packets. This implies that the attacker must place her

true IP address in the source IP address ﬁeld, other-

wise the server’s responses will not be routed back to

her. At a ﬁrst glance, this seems to create a serious

difﬁculty for the attacker: she only has about 18 bits

to manipulate (only the source port and the open des-

tination ports). For example, the default number of

buckets in Netﬁlter for a server with 1GB of RAM is

. Assuming that the hash function distributes its

input uniformly across the hash table, even if all 2

possible packets are tried, the expected chain size is

only 32, which is too small to achieve a considerable

list traversal slowdown.

3.2 Producing a Noticeable Slowdown

As noted in Section 3.1, if the attacker wants to mea-

sure the RTT then the source and destination IP ad-

dresses, as well as most of the destination ports bits,

are ﬁxed. The key observation is that the attacker

is interested in the return trip time of a connection

sent after the bucket ﬁlled up. In other words, while

the bucket is ﬁlling up, the adversary does not care

about the server’s replies. Our solution, then, is to

create 2 classes of attack packets per candidate secret

value. Class A consists of many packets, with spoofed

source IP addresses, that all fall into the same bucket.

Class B packets are a small set of packets, with the

source containing the true IP address of the attacker,

that fall into the same bucket as those of the Class A

packets. Note that the attacker creates all Class A and

SECRYPT 2007 - International Conference on Security and Cryptography

120

Class B packets, for every possible secret value, in

advance.

During the attack, the adversary iterates over all

possible secret values, sending for each random value,

, a “large enough” number of Class A packets, fol-

lowed by a small number of Class B packets. The

attacker only measures the RTT of the Class B pack-

ets. Sending this relatively small number of packets

will not result in a denial of service, but will produce

a detectable slowdown, which is sufﬁcient for us to

identify the correct secret X.

3.3 Modeling the Attack Viability

3.3.1 Distribution of the Longest Chain

Let n denote the number of connections inserted into

the hash table of size m. For the attack to be vi-

able, the attacker must be able to construct at least

a few Class B packets. As a concrete example, we

consider m = 2

hash buckets, as in Netﬁlter, and

n = 2

possible Class B packets. To ﬁnd the dis-

tribution of the longest chain in any bucket, we con-

sider a cell that follows a binomial distribution with

µ = n/m = 2

= 32. Let M be a random vari-

able representing the length of the chain in some cell.

We want to ﬁnd K such that Pr(M > K) ≥ 1/2, which

derives to:

≤ Pr(M > K) = 1−Pr(M ≤ K) = 1−[F(K)]

(1)

Where F(K) is the resulting cumulative distribution

function. Substituting m to be 8192, we obtain the

condition:

[F(K)]

8192

≤ 1/2 (2)

The normal approximation to the binomial distribu-

tion (with the error complementary function) yields:

≥





K +

−

n(m−1)



8192

= (3)





K +

− 32

8191

8192



8192





K − 31.5

5.6565



8192

(4)



K − 31.5

5.6565



≤ 0.5

(1/8192)

≈ 0.99992 (5)

K − 31.5

5.6565

. 3.891 (6)

K . 53.5 ⇒ K ≤ 54 (7)

Thus, we see that with high probability we can create

chains of length 54, even for an ideal hash function —

this is more than enough for Class B packets.

3.3.2 Calculating the Number of Class A Packets

We also need to estimate the number of packets

needed to be sent for each secret value, in the informa-

tion gathering stage, for the attacker to achieve a rec-

ognizable slowdown. Assume that the normal RTT is

T. Let T

(n) denote the RTT for Class B packets, after

sending n Class A packets, assuming a secret value of

r. We would like to achieve T

(n) > (1+ α)T if r is

the correct secret value, for some ﬁxed α > 0.

Let t

to be the time to traverse from one node to

another in a linked list (the lookup time) and let t

twice the network propagation delay between the at-

tacker and victim, i.e., the “network” part of the RTT.

When all the connections are distributed uniformly

throughout the hash table, we calculate the follow-

ing expectation to receive a reply from the server after

creating n connections: T = t

(n/m)+t

since, on av-

erage, the servers needs to examine n/m tuples in the

hash function. When all the connections fall into the

same hash bucket, the time that it takes to receive a

reply after sending n packets is: T

(n) = nt

+ t

. To

achieve T

(n) ≥ (1+ α)T we need

(1+ α)[(

)] < nt

(8)

which implies that

n−

(1+ α)

(9)

For simplicity we set α = 1 (for a slowdown of 2).

Then for m = 2

we have

n(1−

) >

(10)

As a crude estimate, if we set the ratio t

to be

1000, we see that n ≈ 1000 Class A packets would

sufﬁce to produce a factor of 2 slowdown in the RTT

when we test the correct secret value.

Such a ratio is reasonable when the propagation

delay is, e.g., ≈ 1ms (an attacker is stationed just a

few hops away from the victim), and the lookup time

is ≈ 1µs. Clearly, as the noise in the network in-

creases, or the distance between the attacker and the

victim increases, t

increases which means that we

need to create more connections to recognize a slow-

down. Likewise, a faster victim machine would re-

quire more connections.

Note that in reality we don’t really require a slow-

down of 2, all we need is that the RTT for the correct

secret value should be largest among the RTTs com-

puted for all possible candidates.

REMOTE ALGORITHMIC COMPLEXITY ATTACKS AGAINST RANDOMIZED HASH TABLES

121

4 ATTACK IMPLEMENTATION

AGAINST NETFILTER

Before we implemented our attack, we conducted an

extensive simulation study using NS2 (McCanne and

Floyd, ). We omit the details due to space constraints.

4.1 Implementation Setup

We implemented this attack by running a real-life

experiment between 2 machines sitting on the same

network switch. A computer containing a 3.4GHz

Intel Pentium 4 CPU with 1GB RAM, running Fe-

dora Core 4 distribution with a Linux kernel ver-

sion 2.16.14, served as the attacked server. The victim

machine had only 3 open ports and an installed Net-

ﬁlter with ip conntrack version 2.3. We changed the

Netﬁlter module, ip conntrack, so that it can receive

the size of the random value in bits as a parameter to

the module. The attacker machine, composed of an

Intel Pentium 4 2.4GHz and 512MB RAM, ran a Red

Hat 9 Linux distribution with a 2.4.2 kernel.

We wrote a simple C program to generate 40 Class

B tuples for each candidate secret value (with the at-

tacker’s source IP address) which all enter the same

hash bucket, assuming that the current candidate se-

cret value is the one used in the server. With hind-

sight, 10 class B would have been sufﬁcient.

After generating 40 Class B tuples, the program

then generates another 1500 Class A tuples that fall

into that same bucket, but with fake source IP ad-

dress. For the forged addresses, we chose to use the

10.X.X.X address space (2

choices) to avoid the

true IP addresses from sending RST packets which

would cause a connection to be purged from the hash

table.

Constructing the tuples with these forged IP

addresses, leaves us with 42 bits of freedom, still

enough to cause hundreds of bucket collisions. Once

we generated all the tuples for the experiment (an

ofﬂine computation), we can test sending packets in

bursts of different sizes between the attacker and the

victim in order to recognize a slowdown.

To inject and capture TCP packets we used the

packit (Bounds, 2003) application with minor modi-

ﬁcations of our own to accommodate the experiment.

When we used totally random source addresses, the

victim’s SYN-ACK packets were routed towards the Inter-

net. The campus PIX ﬁrewall would trap them in its egress

ﬁltering mode, identify them as “out-of-state”, and send a

spoofed TCP-RST back to the victim, causing the victim

machine to tear down the half open connection and thwart

the attack. This counter-measure would not affect the attack

in a real scenario when the attacker is outside the perimeter

because the border ﬁrewall would see both the attack SYN

and the victim’s SYN-ACK.

We iterated over all possible secret values, sending

ﬁrst a variable-length burst of Class A packets to the

server, and then 10 Class B packets (with the real

source IP address). We ran this experiment in bursts

of 200, 500, 600, 750, 900, 1000, 1200, 1350, 1500

packets and repeated this sequence twenty times.

For each burst sent for each secret value, we cal-

culated the average RTT over the Class B packets and

performed our statistical tests on this data. However,

we noticed that occasionally the average RTT of a

certain value was unreasonably high due to transient

network congestion on the switch. Thus, we consid-

ered these abnormally high times as outliers which

we excluded from our statistical tests. The thresh-

old to consider a data point as an outlier was set to

1500µs, taken as 10 times the average RTT between

the 2 machines under normal circumstances. Note

though that on some of the tests, also the correct se-

cret value showed up as an outlier and so was dropped

from the statistics as well. We calculated the fraction

of times the highest average RTT was detected for the

actual secret value, the fraction of times the true se-

cret value RTT was in the top-5, and when it was in

the top-10.

We ran this experiment twice: The ﬁrst experi-

ment set the random value’s size to 13 bits while the

second set the size to 14 bits.

4.2 Experiments Results

4.2.1 13-bit Secret Values

In the ﬁrst experiment the random value had 13 bits.

The ofﬂine generation of packets lasted about 54

hours and produced 350MB of ﬁle space. On av-

erage, it took 83,000 different combinations to ﬁnd

40 Class B tuples for each random value when hash-

ing with the attacker’s real source IP addresses, and it

took 12,000,000 different combinations to ﬁnd 1500

Class A tuples that collide into the same bucket as the

Class B tuples for the same secret value. The online

slowdown recognition experiment lasted 15 days.

Note that a slow information gathering stage is

not unreasonable. In fact, the attacker may choose

to use a low transmission rate to avoid being detected

as an old-fashioned SYN-ﬂood attack. In our experi-

ment the overall transmission rate was 33 Kbps (1,048

SYN packets per second) and with short bursts of 480

Kbps.

Figure 1 presents the statistical results. Out of

all the tests, 31 outliers were removed from the data.

Out of these, 6 of the outliers were actually the real

random value. One can see in the graph that as the

number of packets sent per burst increases, the high

SECRYPT 2007 - International Conference on Security and Cryptography

122

0.2

0.4

0.6

0.8

1500 1350 1200 1000 900 750 600 500 200

Fraction of times

Number of Packets Sent for each Random Value

HIGHEST

TOP 5

TOP 10

Figure 1: Fraction of times in which the correct secret value

caused the highest RTT, was in the top-5 RTTs, or the top-

10 RTTs, as a function of the number of Class A packets

sent. The secret value is of 13 bits.

RTT values are the result of ﬁnding the actual ran-

dom value. However, even sending 200 packets per

burst gives a success rate of 20% for having the high-

est RTT value belong to the actual secret value. For

a burst of 750 packets per candidate secret value, the

correct value’s average RTT was one of the ten high-

est RTT values on more than half of the tests. The

drops in the graph for the top-5 and top-10 highest

values were caused by the removal of the outliers as

presented above, i.e., by poor transient network con-

ditions. The graph shows that with a burst size of

1000, the attacker guessed the true secret value al-

most always. According to these results, it can be

safely said that 1000 packets are enough to detect the

correct secret value during the information gathering

stage, when the secret value is 13 bits long. These re-

sults closely match those we previously calculated in

Section 3.3.2. Figure 2 shows the differences in RTT

values for each candidate value taken in a single run

with a burst size of 500. The ﬁgure on the top shows

that the highest RTT is the one calculated for the ac-

tual secret value (which is set to be 5766). However,

the bottom ﬁgure is also a single run with a burst size

of 500. In this case, the RTT of the true secret value

was not even one of the top-10 highest received RTTs.

4.2.2 14-bit Secret Values

For the experiment when the secret value is 14 bits

long, the ofﬂine pre-processing time and space is mul-

tiplied by a factor of 2: the tuple generation lasted

about 104 hours on the same computer and produced

700MB of space. The number of combinations to cre-

ate tuples that fall into the same bucket, both when

forging and not forging the source IP address are sim-

ilar to the results received when the random value is

13 bits long: on average over all the random values,

100

150

200

0 1000 2000 3000 4000 5000 6000 7000 8000

RTT

Secret Value

"rtt_500_4"

100

120

140

160

0 1000 2000 3000 4000 5000 6000 7000 8000

RTT

Secret Value

"rtt_500_7"

Figure 2: Comparison when the highest RTT belongs to

the actual random value (5766) (top), and when the RTT of

the random value was not even in the top 10 highest RTTs

when the network was generally slower (bottom). A burst

of 500 was sent for both these tests. RTTs are speciﬁed in

microseconds.

83,000 combinations were tried to create 40 Class

B tuples, and 12,000,000 combinations were tried to

create 1500 Class A tuples that all fall into the same

bucket. The experiment for the 14 bit random value

length lasted about 31 days.

0.2

0.4

0.6

0.8

1500 1350 1200 1000 900 750 600 500 200

Fraction of times

Number of Packets Sent for each Random Value

HIGHEST

TOP 5

TOP 10

Figure 3: Fraction of times in which the correct secret value

caused the highest RTT, was in the top-5 RTTs, or the top-

10 RTTs, as a function of the number of Class A packets

sent. The secret value is of 14 bits.

REMOTE ALGORITHMIC COMPLEXITY ATTACKS AGAINST RANDOMIZED HASH TABLES

123

The experiment results are shown in Figure 3.

The number of outliers in this experiment was higher,

where 58 results were removed. Out of these values, 6

outliers were caused by the extremely high RTT val-

ues received for the real random value. The drop in

the top-5 and top-10 success rate in the ﬁgure for the

burst size of 1350 is due to the outlier being the actual

secret value. The ﬁgure is very similar to Figure 1: as

the burst size grows, a slowdown in the RTT values is

almost always due to ﬁnding the correct secret value.

The ﬁgure shows that as few as 500 packets sufﬁce

to recognize the correct secret value in the top-5 with

≈ 50% success.

5 CONCLUSIONS AND FUTURE

WORK

We have demonstrated that a remote algorithmic com-

plexity attack, against randomized hash tables, is pos-

sible if the secret value is chosen from a small enough

space. More secret bits cause more effort, time and

space to be consumed in the information gathering

stage. Thus, it seems that a random value of 32

bits would render this attack impractical with today’s

technology. Note though that in this paper the at-

tacker iterates over all possible random values in a

brute-force manner, searching for bucket collisions.

However, the search space may be limited to a smaller

subset of random numbers by taking advantage of the

vulnerabilities in the Linux Random Number Gener-

ator as suggested in (Gutterman et al., 2006). This

might lead to a feasible attack against a server with a

longer secret value.

The Linux Routing Table cache which uses a hash

table, has also updated its hash function as a counter-

measure against the algorithmic complexity attack

with Linux version 2.4.2. In this patch, the routing

table cache also uses a random value as a parameter

to the hash function, but in order to increase the secu-

rity, this key is changed every 10 minutes. Since our

experiments show that when the random value is 13

bits long, testing all 8192 possibilities with 500 packet

bursts takes about 1 hour, this additional measure is

indeed helpful. However, changing the secret value is

not always easy: Doing so on a ﬁrewall like Netﬁlter

will potentially break existing connections since fu-

ture packets will be hashed to a different bucket and

not ﬁnd the connection’s state.

REFERENCES

Boneh, D. and Brumley, D. (2003). Remote timing attacks

are practical. In Proceedings of the 12th USENIX Se-

curity Symposium.

Bounds, D. (2003). packit v1.0.

http://www.obtuse.

net/software/packit/

Crosby, S. and Wallach, D. (August 2003). Denial ofservice

via algorithmic complexity attacks. In Proceedings of

the 12th USENIX Security Symposium, pages 29–44.

Dean, D. and Stubbleﬁeld, A. (Aug. 2001). Using client

puzzles to protect TLS. In Annual USENIX Security

Symposium, page 178, Washington, D.C., USA.

Filter. Linux netﬁlter.

http://www.netfilter.org/

Gal, A., Probst, C., and Franz, M. (2004). Complexity-

based denial of service attacks on mobile-code sys-

tems. Technical Report 04-09, School of Informa-

tion and Computer Science, University of California,

Irvine.

Gal, A., Probst, C., and Franz, M. (2005). Average case vs.

worst case margins of safety in system design. In Pro-

ceedings of the 2005 New Security Paradigms Work-

shop (NSPW 2005), Lake Arrowhead, CA, USA.

Garﬁnkel, S. (1996). Script for a king. HotWired Packet.

Gutterman, Z., Pinkas, B., and Reinman, T. (2006). Anal-

ysis of the linux random number generator. In

IEEE Symposium on Security and Privacy, Berke-

ley/Oakland, CA, USA.

Jenkins, B. (1997). Jenkins’ hash.

http://

burtleburtle.net/bob/hash/doobs.html

Kohno, T., Broido, A., and Claffy, K. (2005). Remote phys-

ical device ﬁngerprinting. In IEEE Symposium on Se-

curity and Privacy, Oakland, CA, USA.

Kuzmanovic, A. and Knightly, E. (2003). Low-rate TCP-

targeted denial of service attacks (the shrew vs. the

mice and elephants). In Proc. Sigcomm.

McCanne, S. and Floyd, S. ns network simulator.

http:

//www.isi.edu/nsnam/ns/

McIlroy, M. D. (1999). A killer adversary for quicksort.

Softw., Pract. Exper., 29(4):341–344.

Needham, R. M. (1993). Denial of service. In Proceedings

of the 1st ACM conference on Computer and commu-

nications security, pages 151–153, FairFax, VA, USA.

Paxson, V. (1999). Bro: a system for detecting network in-

truders in real-time. Computer Networks (Amsterdam,

Netherlands: 1999), 31(23–24):2435–2463.

RFC4418. Umac: Message authentication code using

universal hashing.

http://www.rfc-archive.org/

getrfc.php?rfc=4418

Shacham, H., Page, M., Pfaff, B., Goh, E.-J., Modadugu,

N., and Boneh., D. (2004). On the effectiveness of ad-

dress space randomization. In ACM Conf. Computer

and Communications Security (CCS), pages 298–307.

SYN ﬂood (1996). SYN-ﬂooding attacks.

http://www.

cert.org/advisories/CA-1996-21.html

SECRYPT 2007 - International Conference on Security and Cryptography

124
