Mobile Service Provisioning as SOA-Integration Problem
Michael Decker and Rebecca Bulander
Institute AIFB, University of Karlsruhe, Englerstr. 11, 76128 Karlsruhe, Germany
Keywords: Mobile and wireless Computing/Services, Service Oriented Architecture, Enterprise Service Bus.
Abstract: A middleware platform especially designed for the provisioning of data services for handheld computers
using wireless data communication (e.g. smartphones, PDAs) has to offer a variety of different features.
Some of these features have to be provided by external parties, e.g. billing or content syndication. The inte-
gration of all these features while satisfying mobile-specific challenges is a demanding task. In the article at
hand we thus describe a middleware platform for mobile services which follows the idea of an Enterprise
Service Bus (ESB). An ESB is a communication backbone for a Service Oriented Architecture (SOA) based
on asynchronous communication with integration capabilities like transformation or intelligent routing. Be-
cause of its specific characteristics an ESB is an appropriate fundament for mobile service provisioning.
In the last ten years we witnessed the extraordinary
success of the wired internet. So far this success
couldn’t be repeated in the wireless world despite
the high penetration rates of mobile devices and the
availability of wireless data communication pro-
vided by cellular networks (e.g. GPRS, EDGE,
One of the reasons for the lack of success of mo-
bile data services is that the large variety of services
which drove the wired internet to success isn’t avail-
able in the wireless world. This originates from the
fact that offering a data service for mobile devices is
much more difficult than offering a service in the
wired internet: there is a much bigger heterogeneity
with regard to mobile devices’ capabilities, e.g. what
kind of data formats they can process or the quality
of the displays. Due to the limited size of mobile
devices they have only small displays and data input
is cumbersome; that’s why it is necessary to make
use of context information like current location, time
or profile information to support the user when in-
teracting with the mobile device. Features like de-
tecting the device's position, sending push messages
(SMS/MMS), identifying the user or the kind of de-
vice used and charging fees (billing) can only be
supplied by the respective mobile network operators
(MNO). But MNOs won't grant access to these func-
tions to everyone. Because of these hurdles only
large firms with telecommunication know-how are
able to offer mobile data services nowadays.
In literature many descriptions of technical solu-
tions like frameworks or middleware for making it
easier to develop and operate mobile services can be
found. The novel approach of the middleware pre-
sented in the paper at hand is that the provisioning of
mobile services will be considered as integration
problem within a Service Oriented Architecture
(SOA). The basic idea of SOA is to loosely couple
the components of a distributed system (Keen et al.,
2004; 37ff; Kaye, 2003): some components of the
system provide functionalities called “services” and
other components consume these services. The ser-
vice provider publishes an interface description for
each service offered. The most prominent approach
for the realization of SOA is the use of web services.
But SOA is also a management concept which pos-
tulates not to try to build monolithic business appli-
cations but a distributed system whose components
offer reusable services which can be easily plugged
together to implement the IT-support for business
To integrate all the services required for the pro-
visioning of mobile services we resort to the concept
of a so called Enterprise Service Bus (ESB). An
ESB is a special middleware for SOA that is based
Decker M. and Bulander R. (2007).
SOA-Integration Problem.
In Proceedings of the Second International Conference on e-Business, pages 122-129
DOI: 10.5220/0002112501220129
on asynchronous messaging. We argue that the fea-
tures provided by an ESB help to fulfil essential re-
quirements for a “mobile middleware”. Afterwards
we describe an ESB-based architecture for mobile
service provisioning which we are currently realiz-
This article mainly deals with architectural con-
siderations and does not address the problem of ser-
vice discovery, namely how end users can find ap-
propriate services based on contextual information
or semantic techniques. There are other groups
working on these subjects (e.g. Chakraborty, 2001;
Hamdy & König-Ries, 2006).
The remainder of this article is structured as fol-
lows: in the second chapter we introduce our com-
prehension of some basic concepts required for the
understanding of this article; afterwards we discuss
the advantages of messaging oriented middleware
for gluing together the infrastructure required for
mobile services. In chapter three we describe fea-
tures that should be provided by a middleware plat-
form for mobile services. Chapter four describes a
mobile-specific ESB which is exemplified by an
example given in chapter five. We conclude with a
brief discussion of related work in chapter six and
give a summary and outlook in chapter seven.
2.1 Platforms for Mobile Services
In figure 1 we depict a simple reference model for
mobile service platforms: we make the assumption
that there is some kind of client software on the mo-
bile device, e.g. thin client (only rendering function,
e.g. web-browser for XHTML/WML/
cHTML-based services), rich client (browser capa-
ble of some business logic like validation of user
entries), medium client (major part of business logic
but only data caching) or fat client (autonomous data
management). This assumption is a weak one since
even the reception of SMS messages requires some
kind of client software embedded in the mobile de-
vice’s firmware. The other three parties involved in
the provisioning of mobile services are stationary:
Service providers: They use the middleware to
offer the actual services (end-user services), e.g. a
location-aware newsticker.
Third party providers: Their services may be
required by the end-user service providers. Third
party services are “raw” and are not intended to be
directly accessed by end users, e.g. a service to
query weather data in machine-readable form.
Middleware: Middleware is software that medi-
ates between the different software-components in a
distributed system. The paper at hand deals mainly
with architectural considerations of this component
and which features it should provide and integrate.
Client on
Air interface &
MNO core network
Figure 1: Reference model for mobile service provision-
Services provided by the middleware itself are called
internal services; services provided by third parties
or services for end-users are external services. All
communication between the mobile device and the
service provider is routed over the middleware.
2.2 Messaging Oriented Middleware
One can distinguish two fundamental paradigms to
implement interaction with a remote service: syn-
chronous and asynchronous communication. Using
synchronous communication a request is sent to the
remote service which tries to send back a response
as soon as possible. This might be a convenient way
from a developer’s point of view since it mimics the
way local methods/functions/procedures are invoked
in a programming language but is not always ade-
quate for the realization of a SOA: The caller has to
wait (block) till the response arrives. If the server
fails to deliver a response within a certain time span
(e.g. temporary failure of wireless communication,
high load of requests) this may even impair the call-
ing process.
The asynchronous approach of messaging ori-
ented middleware (MOM) is different: using this
communication model a producer formulates a so
called message which is a self-containing collection
of arbitrary data and passes it to the MOM along
with a specification of a queue (point-to-point mes-
saging) or a topic (publish-subscribe messaging).
For point-to-point-messaging each message can only
be read by exactly one consumer, for publish-
Mobile Service Provisioning as SOA-Integration Problem
subscribe each message can be consumed by an arbi-
trary number of consumers.
Asynchronous messaging is an adequate fundament
for a middleware for mobile services because it has
the following features:
Push capability: A service can proactively de-
liver information to a consumer without being di-
rectly requested (polled) to do so. This enables the
implementation of push services at user level, that
means services that can proactively delivery (maybe
time critical) information.
Scalability: By looking at the current penetration
rates of mobile devices it is obvious to conclude that
the market for mobile services is a mass market. A
middleware for mobile services thus should be able
to handle large amounts of service requests. MOM
makes it easy to fulfil this requirement: for services
with high load levels one can simply add another
service provider that helps to process the messages
in the respective queue.
Information syndication: The publish-subscribe
mechanism is well suited for the distribution of one
piece of information (message) to a lot of different
consumers; this problem with regard to mobile mid-
dleware has to be solved for the syndication of con-
tent or public context information. The content pro-
vider’s server hasn’t to be a strong machine because
the MOM takes the burden of distributing the infor-
mation to a potentially big number of consumers.
Reliability: Asynchronous communication helps
to make the system more reliable: if a service pro-
vider or a (wireless) network connection fails the
MOM stores the messages and retries to deliver
them some time later.
Loose coupling: MOM constitutes a way to
loosely couple the different parties involved in a
SOA. This is important because the participating
service providers will often change.
There are various vendors offering MOM products
based on proprietary standards. In the Java-World
the Java Messaging Service (JMS) defines a stan-
dardized API for MOM and several implementations
are available, e.g. OpenJMS or JORAM.
2.3 Enterprise Service Bus
The term “Enterprise Service Bus” (ESB) was origi-
nally introduced by a consulting firm but meanwhile
it is used for a certain kind of integration software
based on MOM (Chappel, 2004; Keen et al., 2004;
74ff). With the Java Business Integration specifica-
tion (JBI, see Java Specification Request No. 208)
there is a standardization attempt for ESBs in the
Java world.
In first generation SOA implementations con-
sumer and providers of services communicate in a
peer-to-peer fashion but this leads to a “brittle” sys-
tem, because when one provider fails or has to be
replaced all other components depending on him
have to be altered. In second generation SOA ap-
proaches an ESB is used as hub between service
consumers and providers. The ESB is not just a hub
but it also provides features necessary for integration
of different services in the sense of a SOA. The
minimum functions an ESB has to provide are trans-
formation of messages, intelligent routing (e.g.
based on its contents a message is sent to a certain
service provider) and adapters to connect services
via different protocols like web services, Corba,
RMI, SMTP/POP3, FTP or even proprietary proto-
cols. Additional features are authentication or or-
chestration of services.
Technically an ESB consists of federated MOM-
servers which share configuration and control. There
are internal services (e.g. transformation, routing,
and authentication) and the external services of the
SOA which are connected using the adapters. From
the MOM’s point of view internal as well as external
services are so called endpoints.
It is also possible to incrementally extend an
ESB by adding segments. For the case of an ESB as
“mobile middleware” this might be interesting if a
company wants to operate mobile services that are
only accessible by employees, e.g. access to group-
ware or ERP for mobile sales force.
2.4 Document-Style versus RPC-Style
Synchronous middleware communication typically
(but not necessarily) employs R
emote Procedure
alls (RPC): the caller’s request is targeted at a cer-
tain address/procedure name and contains optional
parameters; the response may contain return values.
RPC-style might be sufficient for simple communi-
cation between a service consumer and a service
provider but has the following drawbacks:
If the required communication pattern in a dis-
tributed system can not be mapped to simple
“request-response” RPC-style is not appropri-
ate; this is the case when three or more entities
have to collaborate.
ICE-B 2007 - International Conference on e-Business
When an entity receives a RPC request it has to
find out to which session the request belongs to.
One cannot use the full versatility of XML
while using RPC.
Therefore asynchronous middleware typically makes
use of document-style messaging (Kaye, 2003): in
this mode the data is passed in form of self-
contained messages between the collaborating enti-
ties. Each entity only looks at the parts of the mes-
sage that it needs for its duty and has only to under-
stand these.
In this chapter we describe the features that a mid-
dleware for mobile services should provide and
sketch how they are supported by the ESB. Not all
of these features are required for each service. We
categorize these features into two main groups (fig-
ure 2): those which can be provided by the middle-
ware itself (internal services, operated in the same
administrative domain like the ESB) and those
which have to be provided by external parties (ex-
ternal services). The internal services can be further
divided into security-related and non-security re-
lated; for the external services we can distinguish
end-user services and third-party services.
3.1 External Services
The most important type of external services to be
integrated by the ESB are the actual end-user ser-
vices of course, e.g. a firm that wants to offer a loca-
tion-based information service. For the provisioning
of these services it might be necessary to resort to
external services provided by 3
-parties. These 3
party services aren’t directly used by the end users
but are needed as “building-blocks” for the actual
end-user services. One group of such 3
-party ser-
vices are services that have to do with functionalities
controlled by the MNO. We call these services
“MNO services”. Examples are:
Billing means to pay for a telecommunication-
related service over a telephone bill.
Remote Locating: When mobile devices are not
equipped with a self locating module (e.g. GPS-
receiver) it may be necessary to resort to remote
locating techniques (e.g. CellID, TDOA
) offered by
external providers. These techniques offer sufficient
precision for many (but not all) thinkable services,
e.g. localized news or weather forecast.
Querying Device’s Profile: The MNO knows
about some of the characteristics of the mobile de-
vice, e.g. display size and supported data formats.
Call control: The article at hand is about data
services but some data services might need the abil-
ity to initiate voice telephony sessions (e.g. “call that
hotel”-button in a location-aware hotel-finder ser-
There are standardized gateways and APIs (e.g.
OSA Parlay(X), see www.parlay.org) which are in-
tended to enable MNOs to offer access to such func-
tionalities to independent service providers but
CellID: the location of the mobile device is determined by the
coordinates of the base station used; TDOA: T
ime Difference
f Arrival, location of device is determined by runtime differ-
ence of radio signal between several base stations.
Figure 2: Features required for mobile services provisioning.
Features of mobile Middleware
Security Non-Security
Integration of
End User Services
(Remote locating,
Billing, etc.)
MNO services
for syndication
LBS related Transport
Store &
Non LBS related Non-Transport
Data format
Mix Zones
Mobile Service Provisioning as SOA-Integration Problem
MNOs can’t or don’t want to negotiate with the
large number of service providers interested in offer-
ing mobile services.
Content/Context syndication: The ESB also in-
tegrates third party services that offer content for
syndication; this content is used by the client ser-
vices to enrich their services, e.g. news or weather
data. If the content is machine-understandable (e.g.
temperature in a certain city) it can be used to realize
context-aware services. According to our compre-
hension Context (in the sense of mobile computing)
is information that can be used to support the user
when interacting with a mobile device or service.
One way to support a user in this sense is to display
only data deemed as relevant by evaluating context
information, e.g. a location-aware tourist guide
shouldn’t recommend a visit to the nearest swim-
ming pool when it is raining all day long.
3.2 Security Related Features
We first discuss the following security features that
are not mobile specific:
Authentication: The ESB has to ensure that
every message it transports originates indeed from
the party that is stated inside the message. To realize
this each endpoint connecting to an external service
has to require authentication from the service pro-
vider before accepting or delivering messages
to/from that endpoint.
Anonymization/Pseudonymization: For many
services it isn’t necessary that the service provider
knows the identity of the end user or can correlate
different request, e.g. for general information ser-
vices. To implement this feature the transformation
capability of the ESB can be used: the ID-token in
the request-message is encrypted before forwarding
the message to external parties and decrypted just
before the ESB has to find out to whom he has to
dispatch the message. In contrast to anonymization
for pseudonymization the ciphertext of a given ID
has to be the same between several requests so the
service provider can recognize users by the pseudo-
Spam prevention: “Spam” denotes unsolicited
push-messages. Because users carry their mobile
device with them most of the day we can realize
many useful proactive services dealing with time-
critical information like reminders or alerts (e.g.
stock quotes, new messages, failure of a technical
facility, inventory level) using push messages. But
an unsolicited push-message would be much more
annoying on a mobile device than on an ordinary
desktop computer. So there is the great fear that the
spam wave known from the email-system spills over
to mobile services. Therefore the ESB should help to
avoid spam: it could provide a spam filter like those
for emails (e.g. Bayesian filtering) and check a push-
message before delivery; if the message indicates
evidence of being unsolicited (e.g. by looking for
ominous words) it would be blocked. Since filters
are an essential component of ESBs the integration
of such a feature is trivial but these kinds of filters
are prone to produce false positives and thus rele-
vant messages could get lost. Therefore it’s prefer-
able that the ESB adds a special token to a request
message before forwarding it to the service provider.
The service provider has to include this token if he
wants to publish a push message to the end user over
the ESB. The ESB will only dispatch a push mes-
sage to an end user if a valid spam token is included.
Malware filter: The term “malware” subsumes
software that is intended to cause harm to a com-
puter system, e.g. viruses, worms, Trojan horses or
spy ware. Meanwhile malware targeted especially at
mobile devices was discovered, e.g. Cabir,
Pbstealer.A or Brador. Therefore we use the ESB’s
filtering capability to check messages for such mali-
cious content before they are delivered to the end
There are also security requirements that are specific
to mobile services that make use of location aware-
ness. An external service provider receiving a re-
quest could find out about the identity of the origina-
tor by analysing the included location information:
e.g. it might be the location of a private estate so he
could infer that the requestor is the owner of that
estate; it might also be possible to correlate requests
from different sessions that came from the same
place or involved the same spatial-temporal se-
quence (Bettini et al., 2005). In many countries there
are a lot of cameras to supervise public places (and
some of them are even equipped with face recogni-
tion capability); if we learned that Alice was at a
certain place and at the same time a service request
containing the coordinates of that place was received
by a service provider we can uncover the pseudo-
nym used by Alice (observation attack). In literature
several approaches to ensure location privacy can be
found and these can be integrated by the ESB:
Cloaking means to deliberately reduce the preci-
sion of the location information. (Gedik & Liu,
Mix zone: If a user is within a defined mix zone
the ESB won’t forward any location information and
will assign a new pseudonym so a service provider
ICE-B 2007 - International Conference on e-Business
will lose the user’s trace (Beresford & Stajano,
Dummy request: There is also the idea of gen-
erating dummy requests with changing locations to
confuse a potential attacker (Kido et al., 2005).
3.3 Non-security Related Internal
We identified the following features an ESB can
provide by itself that don’t have to do with security
issues. The first group of such features has to do
with the transportation of messages to or from an
Adapter/Gateways: The external parties to be
integrated may use different protocols and data for-
mats. ESBs are an advancement of integration bro-
kers and therefore the endpoints can host adapters or
gateways to communicate with external parties using
various protocols and data formats.
Load-Balancing: The ESB can use its routing
capability to realize some kind of load balancing if
for a certain service there are a lot of requests and
there are several physical external service providers.
Since the market for mobile consumer services is a
mass market (more than one billion cellular phones
worldwide) this is an essential feature.
Store & Forward: A typical problem of mobile
services is that one has to assume temporary connec-
tion dropouts or switched off devices. This require-
ment is covered by the underlying MOM’s store &
forward capability.
Context aware routing: Depending on the
user’s current context it might be reasonable to route
a service request to a different service provider. One
example is a user interested in special offers for
clothes: if he is in city X the ESB can forward the
request to a service provider offering such a service
for city X. Another example of context aware rout-
ing are service providers offering event guides tar-
geting at different age groups; the ESB can forward
the request to the most appropriate service provider
based on knowledge of profile information.
The non-transportation related features are the fol-
Orchestration: For each service request the ESB
has to know which internal and external services in
which order he has to invoke. Example: the first
request in a session might require the message
routed through a remote locating service for obtain-
ing the requestor’s location. Therefore the ESB
should possess a simple workflow module as inter-
nal service which can decide to which endpoint a
given message has to be routed next; this workflow
module should be stateless (all state information is
included in the message) so we can easily operate
more than one instance if a lot of requests have to be
Transcoding: Because of the great heterogeneity
of mobile devices it might be necessary to transcode
the content of a message before delivering it to the
end user, e.g. to reduce size and/or colour depth of
images or to transcode documents formulated in
generic markup languages to specific formats like
cHTML or XHTML-MP. This transcoding can be
easily realized as filter feature within an ESB.
Coordinate conversion: there are many differ-
ent ways to express the location of a user’s device,
e.g. Cell-ID, latitude/longitude with Bessel or
WGS84 ellipsoid, Cartesian or ellipsoidal coordinate
systems. Therefore services for coordinate conver-
sion are required.
As argued in chapter two an ESB has many charac-
teristics that make it a good choice as communica-
tion backbone for a mobile service infrastructure and
all the features mentioned in chapter three can be
easily integrated. In this chapter we therefore sketch
an ESB-based infrastructure for the provisioning of
mobile services (see figure 3).
To connect internal or external services with the
ESB one has to make use of a logical endpoint. A
logical endpoint may contain a service container
with an internal service like pseudonymization or a
connector to communicate with an external service.
The client component on the mobile devices in-
teracts over gateway endpoints with the ESB: this
might be an endpoint for a medium or fat client ap-
plication using web services or another way of
communication with the ESB. For thin client ser-
vices the gateway has to act as web server receiving
requests from a mobile browser application and
sending responses in form of markup documents
(e.g. XHTML-MP, WML). There are also gateways
to send push messages, e.g. SMS/MMS or TCP/IP
push channel.
An ESB uses MOM with document-style mes-
saging as communication backbone: for each logical
endpoint there is one queue for incoming messages.
When a service component has to send a message to
another logical endpoint or finished the processing
of a messaging it puts the result message in the
Mobile Service Provisioning as SOA-Integration Problem
queue for the workflow module which will decide to
which abstract endpoint the message has to be for-
warded. If there is information that has to be distrib-
uted to a lot of endpoints (e.g. content syndication) a
public/subscribe topic is used. For communication
between internal services the messages shouldn’t be
serialized to XML since serializing and de-
serializing is an expensive operation.
To exemplify the concept of the ESB-based infra-
structure we consider “location based news deliv-
ery” as example service: we assume a client compo-
nent on the mobile devices that sends an SOAP-
message to the ESB’s gateway to start a subscription
concerning bargain offers. Before the ESB can for-
ward this request to the respective service provider it
has to be routed through several other internal ser-
The message has to be validated and authenti-
The user has to be billed.
Relevant information from the user profile (e.g.
age, preferred language) and the position ob-
tained from a remote locating provider have to
be added to the message.
The User-ID has to be replaced by a unique
To prevent spamming an internal service adds
some “spam tokens” to the message.
Now the message can be dispatched to the external
provider which offers the service for the region
where the user currently roams. If this provider some
time later gets aware of an interesting offer matching
the user’s profile he formulates a message including
one of the spam tokens and submits it to the ESB.
The ESB again has to route this message through
some of its services before it can be delivered to the
end user’s device eventually:
The presence of a valid spam token has to be
checked otherwise the message will be dis-
The content of the message has to be transcoded
according to the device’s capabilities, e.g. size
of images.
The pseudonym has to be resolved so that the
ESB can find out to whom the message has to
be dispatched.
For thin client services it might be necessary to
convert the message to an appropriate markup
language, e.g. WML, cHTML or XHTML-MP.
There is some work that deals with SOA in mobile
computing: Duda, Aleksy & Butter (2005) discuss
how discovery, extraction, choice and invocation of
services can be distributed between fixed and mobile
Figure 3: Enterprise Service Bus for mobile services.
Protocol, etc.
Internal services External Services
(3rd Party)
Workflow Service 1
Client on
Service 1
City B
Workflow Service 2
Remote locating
Cloaking, spam-
prevention, data
format conversion,
Service 2
Service 1
City A
Air interface &
Core network
ICE-B 2007 - International Conference on e-Business
components when integrating mobile devices into a
SOA. Others publications address the problem of
how to discover appropriate services in mobile sce-
narios or the peer-to-peer-style collaboration of mo-
bile devices (see the overview article by Hamdy &
König-Ries, 2006). However, as far as we know
there is no work dedicated especially to the backend
integration problem of a “mobile SOA”.
Since the most prominent implementation ap-
proach for SOA is the use of web services there are
articles which propose solutions how to consume
web services with mobile devices despite their lim-
ited resources, e.g. Sanchez-Nielsen et al. (2006).
Adacal & Bener (2006) discuss several approaches
to tackle performance issues that typically occur
when accessing web services with mobile devices
because web services make extensive use of XML
and XML is notorious for being bloated. Their solu-
tion approach is based on the use of software agents;
other approaches include the use of proxies or com-
pressed XML.
The appropriateness of using asynchronous mid-
dleware for mobile services is a well-accepted no-
tion; there is even a JMS-implementation for mobile
devices (see www.jtom.de). But in our approach we
don’t assume that mobile devices necessarily con-
sume/produce the middleware’s asynchronous mes-
sages directly; rather we concentrate on asynchro-
nous message exchange between the backend ser-
vices required for mobile service provisioning.
There are many hosting solutions for mobile ser-
vice provisioning: ASPF (Karlich et al., 2004) and
WASP (Koolwaaij & Strating, 2003) provide many
features but they don’t describe a particular integra-
tion approach.
We argued that building a comprehensive middle-
ware platform for mobile service provisioning leads
to an integration problem: a lot of different external
and internal services have to work together. To
“glue” all these services together in a flexible or
loosely coupled way we proposed a middleware in-
frastructure in the form of an Enterprise Service Bus
(ESB). An ESB is a sophisticated communication
backbone based on asynchronous messaging to con-
nect the participants in a Service Oriented Architec-
ture. It was explained why an ESB is an appropriate
choice for the implementation of a middleware for
mobile services. Afterwards we sketched an infra-
structure for the provisioning of mobile services
based on an ESB.
We are currently engaged in the implementation
of a proof-of-concept prototype of the ESB pre-
sented in this paper using J2EE-technologies.
Adacal, M. & Bener, A., 2006. Mobile Web Services: A
new Agent-Based Framework. IEEE Internet Comput-
ing. 10(3), 58-65.
Beresford, A., & Stajano, F., 2003. Location Privacy in
Pervasive Computing. Pervasive Computing. IEEE,
2(1), 46-55.
Bettini, C., Wang, X.S., & Jojodia, S., 2005. Protecting
Privacy against Location-Based Personal Identifica-
tion. In Proceedings of the Conference on Secure Data
Management (SDM ’05), Trondheim, Norway, 185-
Chakraborty, D., Perich, F., Avancha, S., Joshi, A., 2001.
DReggie: Semantic Service Discovery for M-
Commerce-Applications. In Workshop on Reliable
and Secure Applications in Mobile Environment. New
Orleans, LA, USA.
Chappell, D. A., 2004. Enterprise Service Bus. O’Reilly
Media, Sebastopol, CA, USA.
Duda, I., Aleksy, M. & Butter, T., 2005. Architectures For
Mobile Device Integration into Service-Oriented Ar-
chitectures. In Proceedings of the International Con-
ference on Mobile Business (ICMB '05), IEEE, Syd-
ney, Australia.
Gedik, B., & Liu, L., 2005. A Customizable k-Anonymity
Model for Protecting Location Privacy. In Proceed-
ings of the 25th International IEEE Conference on
Distributed Computing Systems (ICDCS ‘05), Colum-
bus, Ohio, USA, 620-629.
Hamdy, M., & König-Ries, B., 2006. Service-Orientation
in Mobile Computing: An Overview. In Proceedings
of the MDM ’06, IEEE, Washington, D.C., USA.
Karlich, S., et al., 2004. A Self-Adaptive Service Provi-
sioning Framework for 3G+/4G Mobile Applications.
Wireless Communications, IEEE, October 2004, 48-
Kaye, D., 2003. Loosely Coupled — The Missing Pieces of
Web Services. RDS Press, California, USA.
Keen, M. et al., 2004. Implementing an SOA Using an
Enterprise Service Bus. IBM Redbooks, 2004.
Kido, H., Yanagisawa, Y., & Satoh, T., 2005. An Anony-
mous Communication Technique using Dummies for
Location-based Services. In Proceedings of the IEEE
International conference on Pervasive Service 2005
(ICPS ’05), Santorini, Greece, 88-97.
Koolwaaij, J., & Strating, P., 2003. Service Frameworks
for Mobile Context-aware Applications. Proceedings
of the Conference on e-Challenges, Bologna, Italy.
Sanchez-Nielsen, E., Martin-Ruiz, S. & Rodriguez-
Pedrianes, J., 2006. Service-Oriented Architecture to
Mobile Phones. In Proceedings of the International
Conference on E-Business (ICE-B 2006), INSTICC
Press, Setúbal, Portugal, 57-62.
Mobile Service Provisioning as SOA-Integration Problem
