A MULTILINGUAL DIALOGUE SYSTEM FOR ACCESSING

THE WEB

Marta Gatius, Meritxell González and Elisabet Comelles

Technical University of Catalonia, Software Department, Campus Nord UPC, Jordi Girona, 1-3 08034 Barcelona, Spain

Keywords: Web dialogue systems, portability, dialogue management, multilinguality.

Abstract: In this paper we propose the use of multilingual multichannel dialogue systems to improve the usability of

web contents. In order to improve both the communication and the portability of those dialogue systems we

propose the separation of the general components from the application-specific, language-specific and

channel-specific aspects. This paper describes the multilingual dialogue system for accessing web contents

we develop following this proposal. It is particularly focused two main components of the system: the

dialogue manager and the natural language generator.

1 INTRODUCTION

The large amount of services and documents in

different languages available in Internet has

increased the need for multilingual and multichannel

systems guiding the user when accessing the web

contents. Web interfaces need to be more interactive

and adaptable to different types of users,

applications and channels.

The main advantage of language modes of

interaction (text and speech) is that they are friendly

and easy to use. Furthermore, spoken interfaces are

necessary in applications where no other mode of

communication is possible, such as applications for

telephones and vehicles. Additionally, the voice

mode improves web usability, especially for

handicapped people, such as elderly adults, who face

specific challenges when accessing the web.

The language modes become more useful as new

uses of the web are invented and more new channels

are available. For example, the spreading of personal

digital assistants and other mobile communication

devices results in an increasing prevalence of voice

interfaces.

This article describes the multilingual dialogue

system (henceforth, DS) we developed to enhance

the usability and accessibility of online public

contents in the context of the European project

HOPS (http://www.hops-fp6.org). Section 2 gives an

overview of the existing DSs accessing the web.

Section 3 presents the multilingual web DS we have

developed. Section 4, describes the dialogue

manager (henceforth, DM) component of the

system. Section 5 explains how the system messages

needed for each new service are generated for each

language. And finally, the last section draws some

conclusions.

2 WEB DIALOGUE SYSTEMS

Even though the first language systems were

developed during the seventies, its importance has

increased throughout the last two decades. The main

cause of this increasing importance was the technical

improvements in speech recognition technologies.

2.1 The Evolution

DSs have evolved towards improvements both in the

functionality and in the engineering features of the

development process. Several lines have been

followed in this evolution. One of the most

significant of these consists in separating the

application and the presentation components.

Important improvements in the friendliness of the

interaction have been achieved by expanding

linguistic and conceptual coverage as well as by

integrating different modes and languages.

Examples of systems supporting multimodality and

multilinguality are described in (Herzog et al, 2004)

and (Gatius, 2001).

184

Gatius M., González M. and Comelles E. (2007).

A MULTILINGUAL DIALOGUE SYSTEM FOR ACCESSING THE WEB.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Web Interfaces and Applications, pages 184-189

DOI: 10.5220/0001272001840189

 SciTePress

Speech recognition in open domain has still

performance problems. For this reason, the speech

mode is basically used in restricted domain systems.

However, application-restricted DSs are expensive

to develop and difficult to reuse. For this reason, an

important aspect of the DS development is

portability, the ability to facilitate the adaptation of

the DSs to different applications, languages and

channels. The most relevant of those works propose

a separated representation of different types of

knowledge involved in the dialogue: task

knowledge, dialogue knowledge and modality and

language-specific knowledge. The next subsections

give several examples of these works.

2.2 Languages Based on XML

The definition of standard languages based on XML

has favoured the development of DSs for accessing

web content. Several of those languages are

explicitly aimed to the development of internet-

powered telephone applications. The use of standard

XML-based mark-up language reduces the cost of

training, facilitates technology integration and

improves flexibility.

The most well-known of these languages is

VoiceXML. One of the main advantages of

VoiceXML is that it separates the logic of dialogues

from the low level details of the voice components.

Two complementary standard languages are used in

VoiceXML systems: the Speech Recognition

Grammar Specification (SRGS), and the Speech

Synthesis Mark-up Language (SSML). The SRGS

defines the standard formalism for the words and

sentences which can be recognized by a VoiceXML

application. The SSML is the new standard way of

producing content to be spoken by a speech

synthesis system.

The dialogue management model in VoiceXML

presents several advantages to the finite state model

used in previous commercial systems. It facilitates

the description of the slots representing the various

kinds of information the user would be asked to fill.

However, VoiceXML presents also limitations to

support complex telephonic calls and other modes

than voice (and touch-tone DTMF). In order to solve

those limitations, other languages were developed.

The CCXML and the CallXML languages were

developed to deal with control management in

complex telephonic calls not supported by

VoiceXML systems (calls including

multiconference, transfers, etc.).

Standard languages to support multichannel and

multimodal communication have also been defined.

Examples of these languages are the Speech

Application Language Tags (SALT), the Extensible

MultiModal Annotation (EMMA) language and the

Synchronized Multimedia Integration Language

(SMIL). Standard architectures facilitating the

development of web DSs have also been designed,

such as the MultiModal Architecture.

The standard languages mentioned favour the

development and portability of DSs. However, the

dialogues and language resources (grammars and

system’s messages) have to be defined for each new

service. A step can be taken towards portability of

DSs by isolating the application task knowledge and

the dialogue strategies. In this line, there have been

several proposals, such as the GEMINI platform

(Hamerich et al, 2004) and the MIML language

(Araki and Tachibana, 2006).

2.3 Web Interaction Management

Web interaction management is another related area

of research focused on improving web usability and

accessibility. There are different works on

facilitating the web access through different modes,

such as that for adapting web contents to different

impairments (Richards and Hanson, 2004), the

transformation rules for creating mixed-initiative

dialogues (Narayan et al, 2004) and the framework

for incorporating multimodal interfaces to already

existing web applications (Ito, 2005).

The main difference between the works on DSs

and those in the web interaction management area is

that DSs are more concerned with achieving a

friendly and robust communication in different

languages, adapted to the user’s needs, whereas the

interaction management research is typically

concerned with building simple dialogues

automatically from web pages.

2.4 Large-Scale Dialogue Systems

There is also a lot of interest in the development of

large-scale DSs supporting rich interactions to

different applications in several languages and

channels. Examples of those systems are TRIPS

(Allen et al, 2001), STAPLE (Kumar, Cohen and

Huber, 2002) and COLLLAGEN (Rich, Sidner and

Lesh, 2001). Those systems are rather complex.

They require a flexible and modular architecture

model and appropriate software for the integration of

modules.

As mentioned in (Herzog et al, 2004), for such

large DSs a distributed organization constitutes the

natural choice to develop a flexible and scalable

A MULTILINGUAL DIALOGUE SYSTEM FOR ACCESSING THE WEB

185

software architecture, able to integrate

heterogeneous modules. Different approaches have

been followed when developing a distributed DS.

The Galaxy Communicator Software

Infrastructure (Seneff, Lau and Polifroni, 1999) is a

distributed, message-based architecture for

developing spoken DSs. A central hub mediates the

interaction among the dialog components (although

peer-to-peer connections are also supported).

The Open Agent Architecture (Martin, Cheyer

and Moran, 1999) is a framework supporting

multimodal interaction. It integrates several

heterogeneous agents controlled by a central unit

which communicate between themselves via

messages.

The MULTIPLATFORM (Herzog et al, 2004) is

based on a distributed architecture which employs

asynchronous message-passing to connect modules

and does not rely on centralized control. This

platform has been used to develop several DSs.

3 OVERVIEW OF THE SYSTEM

Figure 1: The architecture of the dialogue system.

The system we developed for guiding the user to

access the web supports text and speech (through the

telephone) in several languages: English, Spanish,

Catalan and Italian. The current implementation of

the DS has been adapted to two different types of

services: a transactional service for large objects

collection and an informational service giving

information about the cultural events. The system

has been deployed in the public administration of

three different cities.

The architecture of the system is shown in Figure 1.

One of the goals of the system design has been to

facilitate the incorporation of new services,

languages and channels. For this purpose, the

channel-specific, language-specific and service-

specific aspects of the system have been separated

from the general components.

3.1 The Components of the System

As many existing web DSs our system is composed

of three layers: Presentation (or front-end), Dialogue

Management and Data. As can be seen in Figure 1

the components of the presentation layer are the

following: The Voice Gateway and the Audio Web

Server for speech mode, the Text Client and the Text

Server, for text mode and the Natural Language

Parser and Processor (NLPP) performing a deep

syntactic and semantic analysis, used for both, voice

and textual interaction.

The two voice components had been adapted

from those in the Loquendo platform

(http://www.loquendocafe.com). VoiceXML is used

to define the voice interaction with the user. The

automatic speech recognizer uses grammars

following the SRGS standard formalism to model

the user’s interventions. Once the sequence of words

have been recognized they are passed to the NLPP.

The speech synthesis system transforms the content

of the system’s answer into voice following the

standard SSML.

The components of the dialogue management

layer control the interaction with the user. These

components are the Application Manager,

responsible for the session management and the DM

determining the dialogue flow. The DM includes

two submodules: the Output Generator and the

Natural Language Generator.

The data layer components are the Action &

Query Manager, accessing the back-end, and the

Ontology Manager using the ontologies which

model the domain-specific knowledge. These

ontologies are used by the NLPP to perform the

semantic analysis. The ontologies are represented in

the standard language OWL.

In our system the different components are

integrated following a service-oriented architecture

(SOA). Although asynchronous message-passing is

more flexible than component-specific remote APIs

(used in SOA) we found that synchronous

communication between components was more

appropriate for efficiency reasons. We use FADA

technology (Federated Advanced Directory

Architecture, http://sourceforge.net/projects/fada) to

WEBIST 2007 - International Conference on Web Information Systems and Technologies

186

support the SOA principles. It is an implementation

of the Jini Network Technology for working in

WAN environments.

4 DIALOGUE MANAGEMENT

The dialogue management is concerned mainly with

conversational control and guidance: who can speak

at each state of the communication and what they

can speak about. A proper design of the DM

component reduces the cost of adapting the system

to a new service. Dialogue management models

have evolved from simple finite state automata,

representing all possible interactions, to more

complex models using plans to recognize the user’s

intention.

4.1 System-Driven Communication

The main goal in commercial DSs is robustness. For

this reason, most of the DMs only support system-

driven dialogues asking the user the information

needed to accomplish the task. Following this

approach, for the first prototype of the system we

developed a DM supporting only system-driven

dialogues. In the resulting system, once the user

selects a specific service task, the system asks the

information about the corresponding input

parameters and finally, gives the results.

The DM we developed for the first prototype

followed a structural dialogue state, as most of the

DMs in commercial systems. For each service, a

specific dialogue flow was defined in which there

was an explicit description of the relation between

states and actions.

The resulting application-driven dialogues have

proved efficient for transactional web services but

not for the informational web service. When seeking

for specific information, the user usually can give

different types of information, thus restricting the

system search. Most existing DSs guide the user to

introduce this information by asking very specific

questions, that, in many cases, may look unnatural.

See for example, the web service on cultural

events shown in Figure 2. When accessing the

service the user can search an event giving different

types of information: The particular event name, the

event type, the location, the data or a combination of

any of the above type of information.

In the first prototype, the DM tried to restrict the

search on cultural events by asking a sentence such

as: “If you are looking for events, please say LIST

OF EVENTS. If you know the event, and you are

looking for information about it, please say SINGLE

EVENT.” In most cases, the users did not answer the

question but instead they asked for specific

information, such as “I am looking for classical

music concerts”.

Figure 2: The web service on cultural events.

When seeking information, users may not have a

well defined goal, and for this reason user’s

interventions can switch from one aspect of the topic

to another. The specification of such types of

interactions through a finite-state controller is

difficult and can not be changed easily.

In order to improve both the communication and

the engineering process of adapting the system to a

new service, we decided to use an explicit dialogue

model, defining general strategies to decide the next

action. In particular, we followed the Information

State (IS) approach, explained in the next section.

4.2 The Information State Approach

The main reason for following the IS approach is

that it covers dialogue phenomena useful in practical

dialogues, such as feedback strategies related to

grounding and addressing not raised issues. The IS

theories support mixed and user-initiative dialogues,

including confirmation and clarification dialogues,

which can be initiated by the system or the user.

Besides, those theories have been successfully

applied in many projects and applications.

The main difference between the IS approach

and the structural dialogue state approaches is that

IS theories are based in a much richer representation

of the dialogue context, including more mentalistic

notions such as beliefs, intentions and plans. As

defined in (Traum et al, 1999) an IS theory consists

of the following components: The description of the

A MULTILINGUAL DIALOGUE SYSTEM FOR ACCESSING THE WEB

187

information state (e.g., participants, beliefs, common

ground, intentions, etc.), a set of dialogue moves, a

set of rules updating the information state and a

control strategy to select next rule.

We have implemented these components

following the issue-based approach described in

(Larsson, 2002). In this approach, system actions

were defined in plans which contain information

about the action the system should perform to

achieve a specific goal.

4.3 Plans

In plan-based dialogue management, plans are

usually generated dynamically during the

communication using AI plan recognition techniques

to recognize the user’s intention and templates to

performe actions. When knowing the goal, the

system can optimize the plan to achieve it,

considering the dialogue history. Although this

technique is powerful, it is not the most efficient for

all types of dialogues. For simple dialogues on web

services, such as those supported by our system,

plans can be defined and stored in a library when a

new service is incorporated, they do not need to be

generated dynamically. The DM we develop does

not need general reasoning capabilities for planning

and plan recognition because it is designed for

guiding the user to access the web services, which

usually are not very complex.

Each task a service can perform is considered a

possible user goal. For this reason, for each task

service we define a communication plan that has to

be followed in order to perform the task. A task plan

can be descomposed into actions and subtasks.

Preconditions governing in which context a

particular action must be done are also included.

Three types of actions can appear in the plans used

by our system: Ask, the system asks the user the

information needed, Answer, the system gives

information to the user and Back-end access.

Using these plans the system can address issues

introduced by the user which had not been

previously raised. For instance, if the user initially

says “I want information about classical music

concerts” the system can search for a plan in which

classical music concerts could be the answer to an

Ask action. Then, it would continue executing the

other actions in the plan.

In order to facilitate the generation of plans for a

new service, we have defined general templates for

the two types of web services the system has to

support: informational and transactional services. In

transactional services the system has to ask the user

all the information corresponding to the mandatory

input parameters that have not been previously

given. In informational services the system has to

ask the user information to constrain the search.

5 THE SYSTEM MESSAGES

Generating the most appropriate system messages

for each service is time consuming, especially in

systems supporting several languages. This cost can

be reduced when representing appropriately the

relations between the different types of knowledge

involved in communication: dialogue knowledge,

conceptual knowledge and linguistic knowledge.

One of the most relevant works in this area is the

Generalized Upper Model (Bateman, Magnini and

Rinaldi, 1994), a general syntactico-semantic model

used to generate text in several languages for

different types of applications.

Our work differs from previous works in that

area because it is focused in dialogues guiding the

user to access transactional and informational web

services. By representing appropriately the linguistic

structures involved in the communication in these

web services we can limit the language that has to be

generated at run-time. Several of these linguistic

structures can be reused across services. Others will

have to be generated when incorporating a new

service to the system.

Several system messages appear in all services.

Most of them correspond to the dialogue acts

common to all services, such as, formal opening,

closing and thanking. There are some system

messages which appear only in a specific type of

service, either transactional or informational, but can

also be reused through them. For example, in

information services, several sentences presenting

the results to the users can be needed. Some of them

are independent of the particular service and can be

applied to all informational services.

The system messages related to the parameters

appearing in more than one service (such as name,

address, telephone, date and price) are also reused.

However, there are also many system messages that

differ for each particular service. Basically, these

messages are related to the dialogue acts the system

can perform: Asking the user for specific data (the

task to perform, the information to search and the

value of the input task parameters), asking for

confirmation and presenting the results.

We have defined general patterns to represent the

several forms in which these dialogue acts can be

expressed. These patterns are adapted to each

WEBIST 2007 - International Conference on Web Information Systems and Technologies

188

specific service. In order to perform automatically

this process we have adapted the syntactico-

semantic taxonomy described in (Gatius, 2001). This

taxonomy is reused in the four languages we are

working with. For each language, each taxonomy

class has been associated with the linguistic

structures involved in the following dialogue acts:

asking the parameter’s value, giving its value,

checking its value and confirming it.

When adapting the system to a new service, the

task parameters have to be classified according to

the syntactico-semantic taxonomy and linked to the

corresponding lexical entries (in each language).

Then, the system messages can be automatically

generated in each language by adapting the general

patterns associated with each taxonomy class to the

particular lexical entries.

6 CONCLUSIONS

In this paper we propose the use of multilingual

multichannel DSs to improve the usability of web

contents. In order to improve the portability of those

DSs we propose the separation of the general

components from the application-specific, language-

specific and channel-specific aspects.

Following this proposal we have developed a DS

for accessing web contents in four languages:

English, Spanish, Catalan and Italian. The core of

this system is the DM component which controls the

dialogue flow. The DM supports user-initiative

dialogues, including confirmation and clarification

dialogues. It uses plans describing the actions to

follow in order to perform the specific service tasks.

Informal tests have shown that this DM supports a

friendlier communication than the one used in a

previous prototype. Currently, a more formal

evaluation of the whole system is being performed.

The process of incorporating a new service to the

system implies generating the specific service plans

as well as adapting the linguistic resources. In order

to facilitate the task of generating plans for new

services, we have defined general templates for two

types of web services: informational and

transactional. We have also defined general patterns

to automatically generate the system messages in the

four languages for new web services.

REFERENCES

Allen, J., Byron, D., Dzikovska, M., Ferguson, G.,

Galescu, L . and Stent, A. (2001) ‘Toward

Conversational Human-Computer Interaction’, AI

Magazine, vol. 22, no. 4, Winter, pp. 27-38.

Araki, M. and Tachibana, K. (2006) ‘Multimodal Dialog

Description Language for Rapid System

Development’, Workshop Proceedings, the 7th

SIGdial Workshop on Discourse and Dialogue,

Sidney, Australia, pp 109-116.

Bateman, J.A., Magnini, B. and Rinaldi, F. (1994) ‘The

Generalized {Italian, German, English} Upper

Model’, Workshop Proceedings, ECAI-94 Workshop

on Implemented Ontologies, Amsterdam.

Gatius, M. (2001) ‘Using an ontology for guiding natural

language interaction with knowledge based systems’.

Ph.D. thesis, Technical University of Catalonia.

Available, http://www.lsi.upc.es/~gatius/tesis.html.

Hamerich, W., Schubert, V., Schless, V., Córdoba, R.,

Pardo, J., D’Haro, L., Kladis, B., Kocsis, O. and Igel,

S. (2004) ‘Semi-Automatic Generation of Dialogue

Applications in the GEMINI Project’, Workshop

Proceedings, SIGdial Workshop on Discourse and

Dialogue, Cambridge, USA, pp. 31-34.

Herzog, G., Ndiaye, A., Merten, S., Kirchmann,

H., Becker, T., Poller, P. (2004) ‘Large-scale software

integration for spoken language and multimodal dialog

systems’, Journal of Natural Language Engineering,

vol. 10, no. 3-4, September, pp. 283-305.

Ito, K. (2005) ‘Introducing Multimodal Character Agents

into Existing Web applications’, Conference

Proceedings, the World Wide Web Conference,

Chiba, Japan, pp. 966-967.

Kumar, S., Cohen, P.R. and Huber, M.J. (2002) ‘Direct

Execution of Team Specification in STAPLE,

Conference Proceedings, AAMAS Conference,

Bologna, Italy, pp. 567- 568.

Larsson, S. (2002) ‘Issue-based Dialogue Management’.

PhD Thesis, Goteborg University.

Martin, D. L., Cheyer, A. J. and Moran, D. B. (1999) ‘The

Open Agent Architecture: A Framework for Building

Distributed Software Systems’, Applied Artificial

Intelligence, vol. 13, pp. 91-128.

Narayan, M., Williams, C. Perugini, S. and Ramakrishnan,

N. (2004) ‘Staging Transformations for Multimodal

Web interaction Management’, Conference

Proceedings, World Wide Web Conference, New

York, USA, pp. 212-223.

Seneff, S., Lau, R. and Polifroni, J. (1999), ‘Organization,

communication and control in the Galaxy-II

conversational system’, Conference Proceedings,

Eurospeech, Budapest, Hungary, pp. 1271-1274.

Rich, Ch., Sidner, C. and Lesh, N. (2001) ‘COLLAGEN:

Applying Collaborative Discourse Theory to Human-

Computer Interaction’, AI Magazine,vol. 22,n 4,15-25.

Richards, J. and Hanson, V. (2004), ‘Web accessibility: A

broader view’ Conference Proceedings, World Wide

Web Conference, New York, USA, pp. 72-79.

Traum, D., Bos, J., Cooper, R., Larson S., Lewin, I.,

Mathesson, C. and Poesio, M. (1999), ‘A model of

Dialogue Moves and Information State Revision’.

Trindi Technical Report D2.1, [Online], Available,

http://www.ling.gu.se/projekt/trindi//publications.htm

A MULTILINGUAL DIALOGUE SYSTEM FOR ACCESSING THE WEB

189
