REQUIREMENTS ELICITATION FOR DECISION SUPPORT

SYSTEMS: A DATA QUALITY APPROACH

Alejandro Vaisman

Universidad de Buenos Aires

Keywords: OLAP, Data Warehousing, Requirements, Decision Support System.

Abstract: Today, information and timely decisions are crucial for an organization’s success. A Decision Support

System is a software tool that provides information allowing its users to take decisions timely and cost-

effectively. This is highly conditioned by the quality of the data involved. In this paper we show that

conventional techniques for requirement elicitation cannot be used in Decision Support Systems, and

propose DSS-METRIQ, a methodology aimed at providing a single data quality-based procedure for

complete and consistent elicitation of functional (queries) and non functional (data quality) requirements.

In addition, we present a method based on QFD (Quality Function Deployment), that, using the information

collected during requirements elicitation, ranks the operational data sources from which data is obtained,

according to their degree of satisfaction of user information requirements.

1 INTRODUCTION

Among the phases of the software development

process, requirement analysis and specification of

functional and non-functional requirements is a

crucial one. The lack of good requirement

specification is a major cause of failure in software

development. The Software Engineering community

has developed many useful tools for requirement

analysis in transactional systems. These kinds of

systems deal with the day-to-day operation of an

organization. Decision Support Systems (hereafter

DSS) are of a complete different kind: they are

focused on integrating data and models in order to

improve the decision-making process. The software

development cycle of DSS has particularities that

require applying methodologies different than the

ones used for operational systems because: (a)

traditional methodologies have been thought and

designed with transactional systems in mind; (b)

specific methodologies applicable to DSS aroused as

ad-hoc answers to practical needs, and most of them

are just mere enumerations of activities that must

take place during system implementation, focusing

on populating the data repository while ignoring

important issues like the impact of changes in the

operational data sources, or, worse, if these data

sources satisfy the users’ information requirements.

Based on the above, we propose a methodology

called DSS-METRIQ, that integrates concepts of

requirements engineering and data quality, in order

to provide a comprehensive solution to the

requirements elicitation process specifically oriented

to data warehousing, OLAP and Decision Support

Systems. DSS-METRIQ is a methodology aimed at

providing an integrated and consistent analysis of

functional (queries) and non-functional (data

quality) requirements. DSS-METRIQ also addresses

completeness of the operational data sources (i.e.

what is the set of queries the system will be able to

answer in a reliable way using the available data),

and data quality issues. The methodology also

accounts for conflicting requirements and provides

tools for their resolution. A relevant contribution of

DSS–METRIQ is a method which, using the

information collected during requirements

elicitation, ranks the operational data sources

according to their degree of satisfaction of user

information requirements.

In Section 2 we review related work and study

the differences between DSS and operational

systems with respect to requirements elicitation.

Section 3 discusses Data Quality. Section 4

introduces DSS-METRIQ, and Section 5 gives a

more detailed description. We conclude in Section 6.

2 RELATED WORK

The concept of Decision Support refers to a

methodology (or collection of methodologies)

designed to extract information from a database (or

316

Vaisman A. (2006).

REQUIREMENTS ELICITATION FOR DECISION SUPPORT SYSTEMS: A DATA QUALITY APPROACH.

In Proceedings of the Eighth International Conference on Enterprise Information Systems - ISAS, pages 316-321

DOI: 10.5220/0002444603160321

 SciTePress

data warehouse) and use it to support the decision

making process. In spite of the popularity gained by

DSSs in the last decade, a methodology for software

development has not been agreed. System

development involves (roughly speaking) three

clearly defined phases: design, implementation and

maintenance. However, in the development cycle of

traditional software systems, activities are carried

out sequentially, while in a DSS they follow a

heuristic process (Cippico, 1997). Thus,

methodologies for developing operational and DSS

systems are different. Most contributions on

requirements analysis for DSS came from consulting

companies and software vendors. On the academic

side, Winter and Strauch (2003, 2004) introduced a

demand-driven methodology for data warehousing

requirement analysis. They define four-steps where

they identify users and application type, assign

priorities, and match information requirements with

actual information supply (i.e. data in the data

sources). There are several differences with the

methodology we present here. The main one resides

in that our approach is based on data quality, which

is not considered in the mentioned paper. Moreover,

although the authors mention the problem of

matching required and supplied information, they do

not provide a way of quantifying the difference

between them. On the contrary, we give a method

for determining which is the data source that better

matches the information needs for each query

defined by the user. Paim and Castro (2003)

introduced DWARF, a methodology that, like DSS-

METRIQ, deals with functional and non-functional

requirements. They adapt requirements engineering

techniques and propose a methodology for

requirements definition for data warehouses. For

non-functional requirements, they use the Extended-

Data Warehousing NFR Framework (Paim &

Castro, 2002). Although DWARF and the extended

NFR framework are close to the rationale of DSS-

METRIQ, the main differences are: (a) we give a

more detailed and concrete set of tools for non-

functional requirements elicitation; (b) we provide a

QFD-based method for data source ranking; (c) we

give a comprehensive detail of all the processes and

documents involved. Prakash and Gosain (2003)

also emphasize the need for a requirements

engineering phase in data warehousing development,

and propose the GDI (Goal-Decision-Information)

model. The methodology is not described at a level

of detail that may allow a more in-depth analysis.

3 QUALITY CONCEPTS

Many techniques have been developed in order to

measure quality, each one of them associated to a

specific metric. In what follows, we comment on the

ones we are going to use in our proposal.

GQM (Goal Question Metric) is a framework for

metric definition (Basili, Caldiera & Rombach,

1992). It describes a top-down procedure allowing to

specify what is going to be measured, and to trace

how measuring is being performed, providing a

framework for result interpretation. The outcome of

the process is the specification of a system of

measurements that consists of a set of results and a

set of rules for the interpretation of the collected

data. The model defines three levels of analysis: (a)

conceptual (Goal), where a goal for a product,

process or resource is defined; (b) operational

(Question): at this level, a set of questions is used

for describing the way an specific goal will be

reached; (c) quantitative (Metric): the metric

associated with each question.

Quality Function Deployment (QFD) (Akao,

1997), proposed in the 60's by Yoji Akao, was first

conceived as a method for the development of new

products under the framework of Total Quality

Control. QFD aims at assuring design quality while

the product is still in its design stage. It defines an

organizational behavior based on the conception of a

multifunctional team that intends to reach consensus

on the needs of the users and what they expect from

the product. The central instrument of the

methodology is the "house of quality" matrix.

Data Quality. Efforts made in order to improve data

quality are generally focused on data accuracy,

ignoring many other attributes and important quality

dimensions. Wang et al identified four data quality

categories after evaluating 118 variables (Wang &

Strong, 1996): (1) intrinsic data quality; (2)

contextual data quality; (3) data quality for data

representation; (4) accessible data quality. There is

a substantial amount of academic research on the

multiple dimensions applicable to quality of

information. For the sake of space we do not

comment on them in this work. The interested reader

should take a look to the work of Hoxmeier

(Hoxmeier, 2000), Jarke et al (Jarke & Vassiliou,

1997), and many other ones.

4 DSS-METRIQ OVERVIEW

We now introduce DSS-METRIQ, a methodology

specifically devised for requirements elicitation for

DSSs. The methodology consists of five phases:

scenario, information gathering, requirements

integration, data source selection, and document

generation. The rationale of the methodology is

REQUIREMENTS ELICITATION FOR DECISION SUPPORT SYSTEMS: A DATA QUALITY APPROACH

317

the following: on the one hand, the data consumer’s

functional requirements are analyzed, unified and

documented. On the other hand, the quality of data

in the data sources is collected from the data

producer users. This information is then analyzed as

a whole, and a set of documents are produced, that

will allow matching requirements with available

data. In the remainder of this section we will

introduce the methodology, and discuss the

conceptual basis over which it is built. A detailed

description can be found in (Vaisman, 2006).

Framework.

The methodology defines the

following roles and participants in the team that will

carry out the project: (a) Project leader; (b) Training

leader; (c) Requirements engineer; (d) Query and

Data manager: analyzes the queries; (e) Information

administrator. A User is any person participating in

the project. Users to be interviewed are: (a) data

producers; (b) data consumers; (c) referent users

(users with a higher hierarchy in the organization

than the ones defined in (a) and (b)).

Data Sources. DSS-METRIQ defines two kinds of

data sources: physical and logical. The former are

sources where data is actually stored. The latter are

sets of data sources producing a data element.

Supporting Elements. DSS-METRIQ provides

elements for supporting the management of the

information collected throughout the process. These

elements are forms, matrices, a data dictionary and

an aggregations dictionary. Forms are elements

that register the collected information, and can be

updated during the process. Matrices are equipped

with certain intelligence that allows giving weight to

the information contained in the forms, in order to

qualify and prioritize requirements. A data

dictionary is a catalogue of data that contains names,

alias and detailed descriptions of the atomic

elements that compose the user queries, data

sources, and the data warehouse. Its purpose is the

definition of a common meaning for each one of

these elements, allowing formulating user’s

requirements on the basis of a unique terminology. It

can also be updated throughout the process. The

aggregations dictionary is a catalogue containing

information on dimensions and aggregations.

Data Quality Requirements. We work with the

following quality dimensions: accuracy,

consistency, completeness, timeliness, query

frequency, source availability and accepted response

time. Associated

to timeliness we also add: currency, and volatility.

Accuracy. Measures how close to the value in the

real world is the data under consideration. The

accuracy of a data warehouse is influenced by two

main factors: (a) accuracy of the data sources; (b)

the error factor that the ETL process can introduce.

Consistency. We adopt the ontological point of view,

which describes consistency as the “logical

consistency” of information. The underlying idea is

that given two instances of representation for the

same data, the value of the data must be the same.

Completeness. Is the ability of an information

system of representing every significant state of the

real world. For instance, if there are 250 employees

in the organization, we expect at least one record for

each one of them to be in the database.

Timeliness. Measures the delay between a change in

the state of the real world and the resulting

modification of the state in the data warehouse. This

dimension is tightly associated with other two ones:

currency and volatility. Currency measures the age

of the data. It is computed as the difference between

the present time, and the instant when the data

element was created (Wang, 1992). Volatlity

measures the interval in which the data is valid in

the real world (Wang, 1992). Finally, Timeliness is

defined as:

Timeliness(d)=MAX[1–currency(d)/ volatility(d),0]

where s = sensitivity, s >0. Timeliness ranges

between 0 (worst case) and 1 (desirable value).

Data source availability. Given a time interval, is

the time during which the data source is available

(Jarke, Lenzerini, Vassiliou & Vassiliadis, 2003).

Expected query response time. It is the maximum

accepted time for getting the answer to a query.

Query Frequency. Minimum time between two

successive queries.

Measuring Quality It is necessary to define a

unique way of specifying user needs, and measuring

whether the DSS or the data warehouse will be able

to fulfill the minimum levels of quality required. To

this end, our methodology applies GQM to each one

of the dimensions defined above. This technique is

used both for specifying user requirements, and for

measuring the actual values for data quality in the

available data sources. Due to space constraints,

below we only show how the technique is applied to

the accuracy as follows:

a) Specification of user requirements.

Goal: Specify the level of accuracy required for

each data element in a query.

Question: What is the maximum acceptable

difference between the answered obtained, and the

actual value of the data element in the real world?

Metric: The user must specify the maximum

accepted difference between the value of a data

element in the data warehouse and its value in the

real world.

b)Measuring accuracy in the data sources.

ICEIS 2006 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

318

Goal: Determine the accuracy value of the data in

each source.

Question: ¿What is the divergence between the

value of the data in the source and in the real world?

Metric: Accuracy of the data source for a certain

attribute.

Measuring methodology: Given a representative

sample of the data in the real world, we define the

accuracy of the data source as:

Accuracy = [ MAX ] * 100

We proceed analogously for the other quality

dimensions. This allows determining which data

sources can be considered apt for developing the

DSS, meaning that if a data source does not fulfill

the minimum bound for a quality dimension, a data

cleaning procedure can be applied in order to

improve data quality. Otherwise, the data source

must be discarded (or a quality lower than the

desired one would be obtained).

Integrated Requirement Analysis. After finishing

the interview phase, and when all functional and

quality requirements have been obtained,

information is consolidated, yielding a single

requirements document that will be input for the

later phases of design. In this unification and

integration process we need to establish priorities

and solve conflicting requirements. Thus, we define

a set of priorities for each functional and non-

functional requirement. Conceptually, this priority

indicates the level of importance of the requirement.

Priorities are defined by a number between 1 and 5

as follows: optional requirement = 1; low

importance importance requirement = 2;

intermediate importance requirement = 3; high

importance requirement = 4; mandatory requirement

= 5. Conflicts between requirements are solved

using priorities. When two conflicting requirements

have the same priority, a high-level user must decide

which one will be considered. Once conflicts are

solved, Requirements validation is performed.

5 DSS-METRIQ IN DETAIL

In this section we describe the phases of the

methodology, giving details of the processes within

each phase. Each phase groups together tasks that

are conceptually related. In what follows we

describe the key aspects of each one.

Phase I – Scenario The goal of this phase is to

introduce the project to the different levels of the

company, building a consensus about the scope and

boundaries of the project (v.g., users, domains),

priorities, and the initial configuration of the

information. The input of this phase consists of: (1)

details of the project; (2) initial list of domains

involved; (3) scope and list of participants of the

introductory meetings. The output of the phase is a

set of documents containing: (1) domains, and

domain hierarchy; (2) users, and user hierarchy; (3)

quality dimensions; (4) data dictionary; (5)

aggregation dictionary.

Phase II – Information Gathering The goal is to

capture and document functional (queries) and non-

functional (quality) requirements, taking into

account the scope defined in Phase I. The output of

the phase includes: (1) list of the queries expected to

be posed to the system; (2) a data form, consistent

with the data dictionary; (3) data quality

requirements form, one for each data element; (4)

quality hierarchy. The steps of the phase are: (1)

interviews with users and referent people; (2) query

analysis; (3) query reformulation; (4) validation

interviews; (5) quality survey interviews; (6)

prioritizing of quality factors.

Phase III – Requirements Integration In this

phase requirements from all users and domains are

unified, using a criteria based on QFD (Akao, 1997).

In the input of the phase we have: (1) a query list;

(2) a hierarchy of quality dimensions; (3) a data

quality requirements form; (4) data and aggregation

dictionaries; (5) a hierarchy of domains; (6) a

hierarchy of users. The output of the phase is a set of

documents containing the unified data model, the

query priorities, and the data requirements

matrix. After the analysis of query redundancy,

unified query prioritizing is carried out, by means of

a scale of priorities. First, we need to unify

requirements from the different domains, defining

priorities between them. DSS-METRIQ proposes the

following order:

Priorities between domains ►

Priorities between users ► Priorities between queries of

the same user.

Intuitively, the idea is that the

requirement with the least priority in a domain

prevails over the requirement in the domain

immediately following (in importance) the previous

one. The following formula defines the global

priority computation for a query “Q” (

PriorityG(Q)):

PriorityG(Q) = PriorityD (D) * X

+ PriorityU (U) * X +

PriorityQ(Q);

where PriorityD(D), PriorityU(U) and

PriorityQ(Q) are the domain, users and query

priorities.

As a result of this step we obtain a query set, with

priorities defining an order for satisfying data and

quality requirements. Finally, a Data Requirements

Matrix is built, integrating all requirements.

Phase IV – Data Source Selection In this step, data

sources are studied in order to determine if they

fulfill the information requirements. The output of

((X - Xreal)^2/Xreal)

REQUIREMENTS ELICITATION FOR DECISION SUPPORT SYSTEMS: A DATA QUALITY APPROACH

319

the phase is a qualification for each data source with

respect to each data element. The first step of the

phase is the analysis of data sources. Meetings with

data producers are carried out, where the set of data

sources, their availability, and the quality of their

data are documented. The following actions are

taken: (a) the data producer determines the priority

criteria for data source usage. Priority ranges

between 1 and 5. (b) the analyst finds out if a

physical source contains the required data; (c) if a

combination of fields yields some of the required

data, this combination is considered a logical data

source. Then, the quality of the data source for each

data-source combination is determined. The data

provider informs quality characteristics of the data

source, and a mapping for the required fields (i.e.,

where is the required data located, and under which

name). The data source quality assessment step

integrates, in a single data source assessment matrix,

the three essential components of the methodology:

(a) data requirements; (b) quality requirements; and

assessment matrix (see Figure 1) is built. This

procedure is an adaptation of the QFD methodology.

Example 1. Through different interviews we

obtained the following information. For User 1 and

Query 101 – Quality priorities: accuracy: 1,

consistency: 3, completeness: 5, timeliness: 2;

Global priority of the query: 130 (obtained as a

function of the user’s and domain’s priorities);

Aggregations required: day and month. For User 2,

and Query 92 - Quality priorities: accuracy: 4,

consistency:5, completeness: 1, timeliness: 3;

Global priority of the query: 31; Aggregations

required: country, province, city, neighborhood.

Each matrix block is composed as follows: (1)

Consumer users’ requirements: data (h), query ID,

quality dimensions (i), aggregations (j), global query

priority (from Phase II), and quality dimension

priorities given by the users in Phase III (v.g.

consistency has a priority of “3” for Q101). (2) Data

producer users’ information: a sub-matrix indicating

requirements fulfillment for each available data

source. According to the degree of fulfillment, a

value is given (1, 3, or 9, (d) in Figure 1), using the

following criteria: “1” is given if the condition is

not fulfilled, “3” if the condition is not fulfilled, but

can be computed from the data in the source; and

“9” if the condition is fulfilled. (3) Data source

performance for each query ((e) in Figure 1). (4)

Global data source performance ((f) in Figure 1).

The local data source performance is:

PerfLocal (S,Q,D)

= ∑ pri

i *

rel

, where pri

=Data,

quality and aggregations priorities, for data D in

query Q ; rel

=Degree of fulfillment of data source S

for query Q and data element D;

The global data source performance is given by :

PerfGlobal (F,D)

= ∑ HierGlobal (Q

) * PerfLocal

(S,Q

,D), for all queres Qj involving data element

HierGlobal(Q

): Global priority of query Q

j .

Example 2. For the matrix in Figure 1, the local

performance for data source A and query Q101 is

computed as: 5 * 9 + 5 * 9 + 5 * 9 + 1 * 9 + 3 * 9 +

5 * 9 + 2 * 9 + 5 * 9 + 5 * 9 = 324. The global

performance for source A is computed as: 130 *

324 + 31 * 144 = 46584.

Data source selection. A document with a ranking of

data sources for each data is generated. It will be

used in the final data source selection process.

Phase V – Document Generation With the

information collected in Phases I to IV, a set of

documents is generated, which are reviewed by the

different users in order to get a final agreement for

closing the requirements elicitation phase. These

documents are: (1) Query requirements document.

Contains all the queries obtained in phases I to IV,

ordered by global priority. Each query is qualified

with a value ranging from “1” to “3” (“1” means that

the query can be answered with the information

contained in the data sources); (2) DSS requirements

document, containing details of each query obtained

in the process; (3) DW Requirements documents. (4)

Preliminary data model: a preliminary version of the

star-schema model for the data warehouse. (5) Data

source requirements document. Contains the

information obtained in Phase IV.

6 SUMMARY

We showed that methodologies for operational

systems do not apply in the DSS setting. Thus, we

proposed DSS-METRIQ, a methodology that

provides an integrated, data quality-based process

for functional and non-functional requirements

elicitation. A relevant contribution of this work is

the data source selection method based on matching

information needs, data quality requirements and the

quality offered by the data sources.

Future research includes a web-based

implementation of the framework, and the

development of a data source selection engine that

can deliver different combinations of data sources

fulfilling data quality requirements.

ICEIS 2006 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

320

REFERENCES

Akao, Y. (1997). QFD, Past, present and future. Third

International QFD Symposium (QFD’97), Linköpin.

Basili, V., Caldiera, G. & Rombach, H. (1992). The goal

question metric approach. Computer Science

Technical Report Series. CS-TR-2956. University of

Maryland, College Park, MD.

Cippico, V. (1997). Comparison of the Decision Support

Systems and Transaction Support System

Development Methodologies. Advances in Database

and Information Systems (pp. 416-426), St.

Petersburg: Nevsky Dialect.

Hoxmeier, J.A. (2000) Database Quality Dimensions.

Journal of Business and Management, 7(1).

Jarke, M. & Y. Vassiliou. (1997). Data Warehouse

Quality: A Review of the DWQ Project. Information

Quality (pp. 299-313), Cambridge, MA: MIT Press.

Jarke, M., Lenzerini, M., Vassiliou, Y., & Vassiliadis, P.

(2003). Fundamentals of Data Warehouse. Berlin,

Germany: Springer-Verlag.

Paim, F. & Castro , J. (2002). Enhancing Data Warehouse

Design with the NFR Framework Proceedings of

WER2002, 40-57.

Paim, F. & Castro , J.(2003). DWARF: An Approach for

Requirements Definition and Management of Data

Warehouse Systems. Proceedings of the 11th IEEE

Int. Conference on Requirements Engineering, 75-84.

Prakash, N. & Gosain, A. (2003). Requirements Driven

Data Warehouse Development. Proceedings

CaiSE’03.

Vaisman, A. Data Quality-Based Requirements for

Decision Support Systems. In Data Warehouses and

OLAP: Concepts, Architectures and Solutions.

.PA-USA: Idea Group. To appear.

Wang, R.Y. (1992). Quality Data Objects. Total data

quality Management Research Program.

Wang, R. Y. & Strong, D.M. (1996). Beyond Accuracy:

What Data Quality Means to Data Consumers. Journal

of Management Information Systems, 12(4), 5-34.

Winter, R. & Strauch, B. (2003). A Method for Demand-

Driven Information Requirements Analysis in Data

Warehousing Projects. In HICSS-36 (pp.231-231),

Hawaii, USA: IEEE Press.

Winter, R. & Strauch, B. Information requirements

engineering for data warehouse systems. (2004).

Proceedings of SAC’04 (pp. 1359-1365), Nicosia,

Cyprus: ACM Press.

( a )

1 3 5

uer

ID For

For Item

SOURCE SOURCE SOURCE

exists?

5 9 1 3

SALES

Range

5 9 1 3

Ranking

9 1 3

Accuracy

1 9 1 3

Consistenc

9 1 3

Com

letenes

5 9 1 3

Timeliness

9 1 3

Day

5 9 1 3

Month

9 1 3

324 36 108

Exists?

5 3 1 9

Range

5 3 1 9

Rankin

3 1 9

Accuracy

4 3 1 9

Consistenc

3 1 9

Completenes

1 3 1 9

Timeliness

3 1 9

Country

5 3 1 9

Provinc

3 1 9

City

5 3 1 9

Neighbour’d

3 1 9

144 48 432

46584 6168 27432

1º 3º 2º

Q101

Data

130

uer

Priorities

Item

Q92

Data

ualit

ations

( b )

( d )

( e )

( e

( f )

( c )

( d )

( h )

( i )

( j )

Data source selection ranking

ations

Data ID

Figure 1: Quality Assessment Matrix.

REQUIREMENTS ELICITATION FOR DECISION SUPPORT SYSTEMS: A DATA QUALITY APPROACH

321
