USING LINGUISTIC TECHNIQUES FOR SCHEMA MATCHING

Ozgul Unal, Hamideh Afsarmanesh

Informatics Institutes, University of Amsterdam, Kruislaan 403, Amsterdam, The Netherlands

Keywords: Schema Matching, Linguistic Matching, Collaborative Networks, Biodiversity.

Abstract: In order to deal with the problem of semantic and schematic heterogene

ity in collaborative networks,

matching components among database schemas need to be identified and heterogeneity needs to be

resolved, by creating the corresponding mappings in a process called schema matching. One important step

in this process is the identification of the syntactic and semantic similarity among elements from different

schemas, usually referred to as Linguistic Matching. The Linguistic Matching component of a schema

matching and integration system, called SASMINT, is the focus of this paper. Unlike other systems, which

typically utilize only a limited number of similarity metrics, SASMINT makes an effective use of NLP

techniques for the Linguistic Matching and proposes a weighted usage of several syntactic and semantic

similarity metrics. Since it is not easy for the user to determine the weights, SASMINT provides a

component called Sampler as another novelty, to support automatic generation of weights.

1 INTRODUCTION

Collaboration has drawn considerable attention in

recent years and as a result, a large variety of

collaborative networks have emerged, such as virtual

organizations, supply chains, collaborative virtual

laboratories, etc. (Camarinha-Matos and

Afsarmanesh, 2005). As identified in the ENBI

project (ENBI (2005)), need for collaboration as

well as the mechanisms and infrastructures

supporting advanced collaborations among pre-

existing, heterogeneous, and autonomous

organizations have been established in biodiversity

domain also. One prominent requirement in a

collaborative network is to share data with other

organizations. Advances in the Internet technologies

have made it possible to set up a high-speed

infrastructure for sharing large amounts of data over

long distances. However, it is still a big challenge to

automatically resolve syntactic, semantic, and

structural heterogeneity for providing integrated

access to and data sharing among heterogeneous,

autonomous, and distributed databases in

biodiversity or in any other domains.

Therefore, an infrastructure supporting

collab

orative networks needs to consider this

challenge to provide interoperability. In most

previous approaches aiming to enable

interoperability among databases, schema matching

is performed manually, which is an error-prone and

time consuming task. However, the SASMINT

(Semi-Automatic Schema Matching and

INTegration) system (Unal and Afsarmanesh, 2006),

introduced as a part of the Collaborative Information

Management System (CIMS) proposed in the ENBI

project for the biodiversity domain, identifies the

syntactic, semantic, and structural similarities

automatically, and expects the user to accept,

change, or reject the results. Furthermore, if there is

a need to produce an integrated schema of the

domain, it automatically generates the integrated

schema using the results of schema matching.

The main processing steps of the SASMINT are

shown in Figure 1. Th

e steps, which are the subject

of this paper are shown in bold. Since the focus of

this paper is the Linguistic Matching, we will not go

into the details of other steps. However, to give a

general overview of the whole system, SASMINT

consists of Schema Matching and Schema

Integration components. Schema Matching involves

the following main steps: 1) Preparation, which

translates database schemas into the common

Directed Acyclic Graph (DAG) format, 2)

Comparison, which identifies the correspondences

between the two schemas represented as DAGs,

resolves the conflicts, and finds out the matches,

using both Linguistic and Structure Matching, 3)

Result Generation and Validation, in which matches

are displayed to the end-user in order to make any

necessary modifications and to save or reject the

final result.

115

Unal O. and Afsarmanesh H. (2006).

USING LINGUISTIC TECHNIQUES FOR SCHEMA MATCHING.

In Proceedings of the First International Conference on Software and Data Technologies, pages 115-120

 SciTePress

SASMINT

The rest of the paper is organized as follows.

Section 2 is dedicated to the review of related work.

Section 3 presents the details of similarity metrics

used in the linguistic matching as well as the results

of tests that we performed for the evaluation of the

metrics. Section 4 briefly explains the Sampler

component. Finally, Section 5 summarizes the main

conclusions of this paper.

2 RELATED WORK

Schema matching has been the subject of a large

number of efforts in the database research domain.

However, these efforts usually require a large

amount of manual work and are limited in their

provided solutions. Furthermore, they provide

insufficient functionalities for normalization of

strings, referred to as pre-processing. Regarding the

linguistic matching, they do not use the linguistic

techniques effectively, but rather they typically use

only one string similarity metric. Using a single

similarity metric is not enough especially

considering the fact that schemas usually contain

element names with different characteristics and

some metrics give more accurate results for certain

types of strings.

Being the most similar system to ours, the

COMA system (Do and Rahm, 2002) provides a

library of matchers. However, it does not support the

pre-processing of elements’ names. Cupid

(Madhavan, Bernstein et al., 2001) on the other

hand, involves a normalization step. However, for

the linguistic matching, Cupid exploits only a simple

name matcher to identify syntactic similarities and

nothing for determining semantic similarity.

Similarity Flooding (Melnik, Garcia-Molina et al.,

2002) identifies the matching between elements of

two schemas represented as graphs using a simple

string matcher and again no semantic similarity

metric is used. The ONION (Mitra, Wiederhold et

al., 2001) system uses a number of heuristic

matchers in the matching process. However, it does

not employ any combination of syntactic and

semantic similarity metrics. GLUE (Doan,

Madhavan et al., 2002) provides a name matcher and

several instance-level matchers. However, compared

to SASMINT, it requires a large amount of manual

effort because ontologies need to be first mapped

manually to train learners. Clio (Miller, Haas et al.,

2000) requires the user to define the value

correspondences, thus there is no use of any

linguistic matching techniques and a lot of manual

work is required.

In summary, the linguistic matching step of the

schema matching process has not gained as much

importance as the structural matching step.

However, since the results of linguistic matching are

used by the structure matching of schema matching,

in our opinion it is imperative to obtain as accurate

results as possible at this step. Therefore, using a

combination of several syntactic and semantic

similarity metrics has become one of the main goals

of SASMINT.

3 LINGUISTIC MATCHING

The Linguistic Matching in SASMINT has two main

goals: identifying both the syntactic and semantic

similarity between element pairs. A combination of

string similarity metrics are utilized to determine

syntactic similarity, while semantic similarity

algorithm uses the WordNet and considers a variety

of relationships between the terms, such as

synonymy and hyponymy, as well as the gloss

information as explained in Section 3.3. Among

different alternatives, a number of metrics, widely

used in NLP and suitable for different string types,

Figure 1: Processing Steps of SASMINT.

Schema

Matching

Preparation

Comparison

Result Generation

and Validation

Linguistic Matching

Structure Matching

Pre-Processing

Syntactic

Semantic

Tokenization and Word Separation,

Elimination of stop words & special characters ,

Abbreviation expansion, Lemmatization

(combination of string

similarity metrics)

(combination of Path-based & Gloss-based

semantic similarity metrics )

Schema

Integration

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

116

are implemented in Java for the Linguistic

Matching.

Before applying any linguistic matching

algorithm, element names from two schemas need to

be pre-processed to bring them into a common

representation. Below, the main processes of the pre-

processing step are introduced:

1. Tokenization and Word Separation: Strings

containing multiple words are split into lists of

words or tokens.

2. Elimination of stop words: Stop words are

common words such as prepositions, adjectives,

and adverbs, e.g. ‘of’, ‘the’, etc., that occur

frequently but do not have much effect on the

meaning of strings.

3. Elimination of special characters and De-

hyphenation: The characters such as ‘/’, ‘-‘, etc.,

are considered to be useless and removed from

the names.

4. Abbreviation expansion: Since the abbreviations

are mostly used in names, they need to be

identified and expanded. For this purpose, a

dictionary of well-known abbreviations is used.

5. Normalizing terms to a standard form using

Lemmatization: Multiple forms of the same word

need to be brought into a common base form. By

means of lemmatization, verb forms are reduced

to the infinitive and plural nouns are converted to

their singular forms.

After pre-processing element names, a variety of

algorithms (metrics) are applied to identify syntactic

and semantic similarities, as detailed below.

3.1 Syntactic Similarity

There has been a lot of past research work in Natural

Language Processing (NLP) on comparing two

character strings syntactically. SASMINT uses a

combination of several main syntactic similarity

metrics. Since each of these metrics is best suited for

a different type of strings, we find it more

appropriate for SASMINT to use several of them

together, to make it a more generic tool to be used

for matching schemas with different types of

element names. These metrics are briefly explained

below:

1. Levenshtein Distance (Edit Distance):

Levenshtein Distance (Levenshtein, 1966), also

known as Edit Distance, is based on the idea of

minimum number of modifications required to

change a string into another. The modification

can be of type changing, deleting, or inserting a

character. Levenshtein distance is a string-based

distance metric, meaning that it does not consider

the multi-word string as a combination of tokens

but rather as a single string.

2. Monge-Elkan Distance: Monge and Elkan

(Monge and Elkan, 1996) proposed another

string-based distance function using an affine gap

model. Monge-Elkan Distance allows for gaps of

unmatched characters. Affine gap costs are

specified in two ways: one with a cost for starting

a gap and a second for the cost of continuation of

the gap.

3. Jaro (Jaro, 1995), a string-based metric well

known in the record linkage community, is

intended for short strings and considers

insertions, deletions, and transpositions. It also

takes into account typical spelling deviations.

4. TF*IDF (Term Frequency*Inverse Document

Frequency) (Salton and Yang, 1973) is a vector-

based approach from the information retrieval

literature that assigns weights to terms. For each

of the documents to be compared, first a weighted

term vector is composed. Then, the similarity

between the documents is computed as the cosine

between their weighted term vectors.

5. Jaccard Similarity (Jaccard, 1912) is a token-

based similarity measure yielding a similarity

value between 0 and 1. The Jaccard similarity

between two strings A and B consisting of one or

more words is defined as the ratio of the number

of shared words of A and B to the number owned

by A or B.

6. Longest Common Substring (LCS): is a special

case of edit distance. The longest common

substring of A and B is the longest run of

characters that appear in order inside both A and

Syntactic Similarity Metrics Used in SASMINT

All the metrics described above are used in the

Linguistic Matching component of our system.

Considering that schemas usually consist of mixed

set of element names (strings) with different

characteristics and each metric might be suitable for

different types of strings, we propose to use a

weighted sum of the metrics as defined below,

which yields better results.

(a,b)

(a,b) + w

(a,b)

*sm

(a,b) +w

*sm

(a,b) + w

*sm

(a,b)

where ‘lv’ stands for Levenstein, ‘me’ for Monge-

Elkan, ‘jr’ for Jaro, ‘jc’ for Jaccard, ‘tf’ for TF-IDF,

and ‘lc’ for Longest Common Sub-string.

Using a weighted sum of several metrics is one

key innovation of our system, as depending on the

characteristics of the element names, some metrics

can be assigned higher weights. In addition to being

USING LINGUISTIC TECHNIQUES FOR SCHEMA MATCHING

117

applicable for different string types, SASMINT

system also proposes a recursive weighted metric as

an alternative to the weighted metric, which is a

modified version of Monge-Elkan's hybrid metric

(Monge and Elkan, 1996) and better supports the

matching of schema names when they contain more

than one token. Our metric is different from that of

Monge-Elkan in that ours applies more than one

similarity metric to string pairs, while Monge-Elkan

uses only one metric. Furthermore, unlike Monge-

Elkan, it is symmetric generating the same result for

sim(a,b) and sim(b,a), and thus making our pair

matching associative. Given two strings a and b that

are tokenized into

a = s

,..s

and

the recursive weighted metric is as follows:

= t

,...t

sim(a,b) =

max

j = 1

sim

)

i = 1

∑

max

i = 1

sim

)

j = 1

∑

3.2 Evaluation of Syntactic

Similarity

In order to determine the accuracy of our syntactical

similarity step, we carried out a number of tests.

Since our aim was to evaluate only the accuracy, we

did not consider any performance issues. We

borrowed the test data from Similarity Flooding

(Melnik, Garcia-Molina et al., 2002) and Clio

(Miller, Haas et al., 2000). In our tests, similarities

were calculated in three ways: 1) Using the metrics

individually, 2) using the SASMINT’s weighted sum

of the individual metrics, and 3) using the

SASMINT’s modified recursive weighted metric.

For calculating the weighted sum, we used the same

weight for all similarity metrics.

All possible pairs of element names from the two

schemas were compared using the metrics and each

pair was assigned a similarity score between 0 and 1.

If the similarity score was above the threshold, then

the match was accepted. We performed the tests

with the threshold value of 0.5. In the evaluation

process, we used the concepts of precision and recall

from the information retrieval field (Cleverdon and

Keen, 1966). Precision (P) and Recall (R) are

computed as follows:

P =

and

R =

x + y

where x is the number of correctly identified similar

strings, z is the number of strings found as similar,

which are actually not similar (called as false

positives), and y is the number of similar strings,

which could not be identified by the system (called

as false negatives).

Although precision and recall measures are

widely used for variety of evaluation purposes,

neither of them can accurately assess the match

quality alone. Therefore, a measure combining

precision and recall is needed. F-measure

(Rijsbergen, 1979) is one such a measure, combining

recall and precision as follows:

F =

F-measure forms the base of our evaluation

process. Although in Figures 2-7, the values of

precision and recall are also shown, for the purpose

of the assessment of the similarity metrics, values of

F-measure are considered. The figures below

demonstrate that while one metric among the six

may perform well on one data set, it may not on

another. This is due to the fact that different schema

test sets from different domains contain elements

with different characteristics, while at the same time

each of the six metrics is usually suitable for specific

type(s) of strings. However, SASMINT’s approach

is more generic, and in all our similarity evaluation

tests we observed that the weighted sum of metrics

consistently performed almost as good as the best

metric among the six. For different types of

schemas, SASMINT yields better results than other

systems, as it uses a combination of metrics suitable

for different element names.

3.3 Semantic Similarity

Semantic similarity algorithms used in SASMINT

can be categorized into two, using the names of

groups mentioned in (Pedersen, Banerjee et al.,

2003): 1) path based measures and 2) gloss-based

measures, which are briefly explained below.

1. Path-based Measures: Path-based measures are

based on the idea of calculating the shortest path

between the concepts in a IS-A hierarchy, such as

the WordNet (Fellbaum, 1998), which is a lexical

dictionary mostly used by similarity measures.

Among different alternatives in this category, we use

the measure of Wu and Palmer (Wu and Palmer,

1994). This measure focuses on verbs, though it is

applicable for nouns also, and takes into account the

lowest common subsumer of the concepts.

2. Gloss-based Measures: In this category of

semantic similarity measures, gloss overlaps are

used. Gloss refers to a brief description of a word.

Lesk (Lesk, 1986) uses gloss overlaps for word

sense disambiguation. We convert the algorithm of

Lesk to compute the semantic similarity of two

concepts and as follows: for each of the senses

, we compute the number of common words

between its glosses and the glosses of each of the

senses of

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

118

0.00

0.20

0.40

0.60

0.80

1.00

Lev

Mon

e-E

Jaro

TFID

LCS

Wei

P R F

0.00

0.20

0.40

0.60

0.80

1.00

Levens

ein

nge-El

Jaro

card

TFI

LCS

Weight

P R F

Semantic Similarity Metrics Used in SASMINT

Both of the semantic similarity measures mentioned

above are used in the SASMINT system for

identifying the semantic similarity of element

names. These measures utilize the WordNet.

Resulting semantic similarity is the weighted sum of

path-based and gloss-based measures.

4 IDENTIFYING THE WEIGHTS

AUTOMATICALLY

For schema matching among heterogeneous and

autonomous sources of information, a variety of

techniques can be applied. Nevertheless, the

conclusion of our studies shows that depending on

the characteristics of the strings in the domain, some

metrics are more suitable for matching certain types

of strings. Therefore, to produce more accurate

results, we suggest assigning weights to the metrics

and giving higher weights to those metrics that are

more suitable. Although using a weighted sum of

different metrics gives more accurate results in

syntactic and semantic matching steps, it is not

always easy to manually determine the weights.

Furthermore, for some cases, it might not be

appropriate to use equal weights for each of the

metrics.

As another contribution of the system,

SASMINT proposes a component called ‘Sampler’

to help the user with identifying the most suitable

weights. The Sampler component discovers the

weights through the following steps: 1) The user is

asked to choose between syntactic or semantic

matching and then to provide up to ten known

sample “similar pairs” (syntactically or semantically

similar, depending on which type of matching he

Figure 2: Test Data #1.

Figure 3: Test Data #2.

0.00

0.20

0.40

0.60

0.80

1.00

1.20

Levenstein

Monge-El

card

Weight

Rec

rsive

P R F

0.00

0.20

0.40

0.60

0.80

1.00

1.20

Levenstein

-El

aro

Jac

ard

IDF

eig

hte

urs

ive

P R F

Figure 4: Test Data #3.

Figure 5: Test Data #4.

0.00

0.20

0.40

0.60

0.80

1.00

1.20

Levenstein

nge-El

Jar

Jaccard

TFID

Weighte

ecu

siv

P R F

Figure 6: Test Data #5.

0.00

0.20

0.40

0.60

0.80

1.00

1.20

Levens

ein

onge-

lkan

Jaro

Jacc

TFID

eigh

ursive

P R F

Figure 7: Test Data #6.

USING LINGUISTIC TECHNIQUES FOR SCHEMA MATCHING

119

wants to determine the weights for) from his schema

domain. 2) Sampler runs each metric over these

pairs and determines the similarity for each pair

between 0 and 1. 3) It calculates the accuracy of

each metric using the F-measure as explained in

Section 3.2. 4) Sampler assigns weights for each

metric, based on the following formula, where

∑

represents the sum of F-measure values resulted for

all metrics used, and represents the F-measure

value calculated for metric ‘m’:

∑

* F

5) Finally, weights are presented to the user who can

accept or modify them. If the user does not run the

sampler, then he either will define them, or

averaging the metrics (equal weights for all) is the

only mechanism that SASMINT can use, although it

may not produce desirable results.

5 CONCLUSION

In this paper, we introduce a semi-automatic schema

matching and integration tool called SASMINT and

explain how it uses linguistic techniques to

automatically resolve syntactical and semantic

heterogeneities between database schemas. In order

to identify the syntactic and semantic similarity

between the elements’ names from two schemas,

unlike other schema matching efforts, the SASMINT

system utilizes a combination of different types of

string similarity and semantic similarity metrics

from NLP. The use of a weighted and recursive

weighted sum of these metrics are proposed, giving

more accurate results. Furthermore, the Sampler

component of SASMINT helps users to influence

the weights for applying these metrics. A number of

tests were carried out to measure the correctness of

the metrics and the results are provided in this paper.

Other tests are being planned to compare SASMINT

with other similar systems.

REFERENCES

ENBI (2005). European Network for Biodiversity

Information (IST 2001-00618).

http://www.enbi.info.

Camarinha-Matos, L. M. and H. Afsarmanesh (2005).

Collaborative networks: A new scientific discipline.

Journal of Intelligent Manufacturing 16(4-5): 439-

452.

Cleverdon, C. W. and E. M. Keen (1966). Factors

determining the performance of indexing systems, vol

2: Test results, Aslib Cranfield Research Project.

Cranfield Institute of Technology.

Do, H. H. and E. Rahm (2002). COMA - A System for

Flexible Combination of Schema Matching

Approaches. In 28th International Conference on Very

Large Databases (VLDB).

Doan, A., J. Madhavan, et al. (2002). Learning to Map

between Ontologies on the Semantic Web. In World-

Wide Web Conf. (WWW-2002).

Fellbaum, C. (1998). An Electronic Lexical Database.,

Cambridge: MIT press.

Jaccard, P. (1912). The distribution of flora in the alpine

zone. The New Phytologist 11(2): 37-50.

Jaro, M. A. (1995). Probabilistic linkage of large public

health. Statistics in Medicine: 14:491-498.

Lesk, M. (1986). Automatic sense disambiguation using

machine readable dictionaries: how to tell a pine code

from an ice cream cone. In 5th SIGDOC Conference.

Levenshtein, V. I. (1966). Binary codes capable of

correcting deletions, insertions, and reversals.

Cybernetics and Control Theory 10(8): 707-710.

Madhavan, J., P. A. Bernstein, et al. (2001). Generic

Schema Matching with Cupid. In 27th International

Conference on Very Large Databases (VLDB).

Melnik, S., H. Garcia-Molina, et al. (2002). Similarity

Flooding: A Versatile Graph Matching Algorithm and

its Application to Schema Matching. In 18th

International Conference on Data Engineering (ICDE).

Miller, R. J., L. M. Haas, et al. (2000). Schema Mapping

as Query Discovery. In 26th International Conference

on Very Large Databases (VLDB).

Mitra, P., G. Wiederhold, et al. (2001). A scalable

framework for the interoperation of information

sources. International Semantic Web Working

Symposium.

Monge, A. E. and C. Elkan (1996). The Field Matching

Problem: Algorithms and Applications. In 2nd

International Conference on Knowledge Discovery

and Data Mining.

Pedersen, T., S. Banerjee, et al. (2003). Maximizing

Semantic Relatedness to Perform Word Sense

Disambiguation. Supercomputing Institute, University

of Minnesota.

Rijsbergen, C. J. v. (1979). Information Retrieval,

Butterworths, London.

Salton, G. and C. S. Yang (1973). On the specification of

term values in automatic indexing. Journal of

Documentation(29): 351-372.

Unal, O. and H. Afsarmanesh (2006). Interoperability in

Collaborative Network of Biodiversity Organizations.

In Proc. of PRO-VE'06 - Virtual Enterprises and

Collaborative Networks, Accepted for Publication.

Wu, Z. and M. Palmer (1994). Verb Semantics and

Lexical Selection. 32nd Annual Meeting of the

Association for Computational Linguistics.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

120
