METAPOLICIES AND CONTEXT-BASED ACCESS CONTROL

Ronda R. Henning

Harris Corporation, 1025 W. NASA Blvd, Melbourne, FL, 32904, US

Keywords: Access Control, Context-Based Access Control, Security Policy

Abstract: An access control policy mediates access between authorized users of a computer system and system

resources.

Access control policies are defined at a given level of abstraction, such as the file, directory,

system, or network, and can be instantiated in layers of increasing (or decreasing) abstraction. In this paper,

the concept of a metapolicy, or policy that governs execution of subordinate security policies, is introduced.

The metapolicy provides a method to communicate updated higher level policy information to all

components of a system; it minimizes the overhead associated with access control decisions by making

access decisions at the highest level possible in the policy hierarchy. This paper discusses how metapolicies

are defined and how they relate to other access control mechanisms. The rationale for revisiting

metapolicies as an access control option for federated enterprise architectures is presented, and a framework

for further research in metapolicy use as a context based access control representation is described.

1 INTRODUCTION

The phrase security policy has been used to address

the protection mechanisms employed to protect an

organization’s assets from potential misuse. In

reality, a security policy is composed of several sub-

policies: accountability, authentication,

contingency, and access control. The access control

policy defines how system users interact with the

data stored within the system. In most access

control models, access control is defined as a triple

consisting of the <subject, object, privileges>

associated with a given data container, for example,

a file or a row in a database. In the early days of

computing, much discussion surrounded how access

control models should be represented in computer

systems. (Schell, 1979) developed the notion of

multilevel mode of operations, stating:

In multilevel mode, the computer must

ternally distinguish multiple levels of information

sensitivity and user authorization. Internal Controls

of hardware and programs must assure that each user

has acces

s to only authorized information.

The concept of Role-based access control

(RBAC) was introduced by (Ferraiolo, 1995; Schell,

1979) and (Sandhu,et al 1996) to more accurately

model the workings of a commercial enterprise. In

RBAC, access control is based on a four-element set

(user, group, object, privileges). A user may belong

to many groups, each with a different privilege set.

In the worst case model, every user has their own

group, and there are as many groups to administer as

there are users. In (Ferraiolo, 1995) a role is defined

and centrally administered within an organization.

However, with the flexibility of RBAC, there are

some limitations. In a distributed network centric

enterprise, it may take several hours to confirm the

update of an application’s access control roles.

Because several applications may use their own

security services instead of the centralized security

services of the operating system, it may be difficult

to determine whether an access control policy has

been completely administered. In fact, it may well

be that RBAC in a distributed enterprise can violate

the three primary engineering principals of security

reference monitors:

1. Co

mpleteness – that the policy is invoked on

every access to data

2. Isolation

– the security mechanism is protected

from unauthorized modification

3. Verifiab

ility – the policy must be small and

simple for complete test and verification.

There are times when an e

vent may occur that

requires comprehensive pre-emption or revocation

of an RBAC policy. (Hosmer, 1991) presented the

notion of a metapolicy to address instances of

arbitration among diverse domains implementing

355

R. Henning R. (2005).

METAPOLICIES AND CONTEXT-BASED ACCESS CONTROL.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 355-359

DOI: 10.5220/0002579203550359

 SciTePress

disparate security policies. In this paper, the use of a

metapolicy to address immediate access control

policy changes for an enterprise is presented. .

2 RELEVANCE AND

SIGNIFICANCE OF TOPIC

This section discusses the various research and

standards about access control policies, with an

emphasis on relevancy to the concept of metapolicy

formulation and implementation.

2.1 Related Work

In (Hosmer, 1991) the concept of a metapolicy was

introduced. A metapolicy is a policy about other

policies, the rules and assumptions about the

policies, and explicitly states the coordination of

interaction among policies rather than implicitly

leaving such coordination to the administrators

Hosmer’s interpretation was that a metapolicy would

address how diverse policies would interact across

domain boundaries, how data could be updated

across domains, and how precedence could be

determined and ambiguity removed. As a way to

address multiple security goals or the needs of

different organizations with their own policy

intentions, the provision was made for multiple

policies. The constraints on support for multiple

metapolicies were that each metapolicy had its own:

• Source or owner,

• Enforcement authorities, which could be

different from the source, and

• Evolutionary timeframe

Metapolicies were envisioned as being flexible,

potentially layered, tamperproof, and providing a

controlling representation of the organization,

system, or security policy it represented. In

(Hosmer, 1993), the concept of a multipolicy

paradigm was presented

. A key use of

multipolicies was for changing circumstances, for

example when a country moves from peace to war.

The emphasis was on explicit statements of

interaction, such that multiple policies could be

formally specifiable and subject to verification of

tamper-resistance, the very characteristics Schell

presented as desirable for a security kernel’s

architecture.

In (Bell, 1994), the author discussed modeling

an instance of a “Multipolicy Machine” and

described 4 levels of abstraction associated with a

given security policy:

1. an organization abstraction, written as a narrative,

for people to read;

2. a conceptual abstraction, discussing an

organizational policy at the concept level;

3. an abstract level, describing the design and

tracing the conceptual requirements; and

4. an implementation level, describing the design as

developed.

(Baskerville, 2002) addressed the concept of an

information security meta-policy for an

organization, and the characteristics of such a meta-

policy. Security is considered a facilitating

capability, not a hindrance, and there is recognition

that access control policies change over time.

Metapolicies, in this discussion, must possess the

attribute of political simplicity, and be criterion-

oriented: that is, they must be comprehensible and

produce a measurable result

. In essence, these

metapolicies require an explicit statement of the

subjects’ capabilities for accessing data objects, and

the rules for granting access that will be enforced

with the metapolicy.

3 BARRIERS AND ISSUES

3.1 Definition of Context

The dictionary definition of the word “context” is

the circumstances or events that form the

environment within which something exists or takes

place (Press, 2004). Describing the general context

of an application would be an infinite problem, as

there are always new observations or attributes to

incorporate into the context. In (Covington, 2002)

the environmental roles are defined as the security

relevant aspects of the environment. Covington

further emphasizes that environmental roles are used

to maintain uniformity across a diverse environment.

Further, the sensors, those devices that monitor the

environmental conditions, must be authenticated and

the integrity of the sensor data guaranteed, or the

environmental policy components could be

compromised

(Strembeck, 2004) states that “every goal and

obstacle can be used to define a context condition

and can map to a concrete access control service.” It

becomes necessary, then, to have an environmental

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

356

model in mind prior to exploring a context-based

security policy

3.2 Conflicting Policies

(Wang, 2004) discusses the issue of policy

reconciliation in heterogeneous environments

The notion of a reconciliation algorithm is

introduced to find a security policy that consistently

adheres to the security policies of all participating

domains. Wang’s model applies acyclic graph

theory to model the security mechanisms employed

by various environments to provide a framework for

policy an analysis. Further, the use of acyclic graph

theory exposes commonalities in policy and

countermeasures to provide an efficient

reconciliation method (linear in size v. N-P-

complete).

3.3 The existence of supporting

modeling tools and concepts

(Jaeger, 2001) and (Jaeger, 2003) discuss the

concept of safety in access control models. A safe

access control model is one in which a given access

control will not inadvertently leak access rights to

unauthorized persons

. Safe models require

restrictive security policies, namely policies that

apply constant values as constraints, because

variable constraint-based policies are difficult to

administer. Jaeger also applies graph theory to

design comprehensible security policies.

(Bertino, 2001) presents a framework for

logical reasoning about access control models. In

this framework, access control models are modeled

in the C-datalog language to develop a common

basis for comparison.

3.4 The existence of more robust

security models

The last 10 years have brought the concepts of

Usage-controlled models (UCON)

, Type

Enforcement, and other security models that provide

a more granular model of access control interactions.

In the past, access decisions were binary, validated

on an as-needed basis, with the access maintained

for the life of the session. The UCON model allows

access rights to change during the life of a session,

treating access as a consumable, specifiable event

that can exist for a single object access or all

attempted object access instances within a session.

4 SYNTHESIS & METHODOLOGY

The basic research and technology experimentation

required for defining and applying the security

context of an application and its information was not

available. As (Brézillon, 2004) states, context was

very rarely used explicitly for a security

specification. Since the security metapolicy concept

was first presented, both security modelling and the

analysis tools to support replicable mathematical

results have matured considerably. The fundamental

computing models in place when metapolicies were

first proposed evolved into the distributed and

federated “systems of systems” architectures of

today. In distributed and federated computing

models, the use of an overarching policy for queue

management or asset allocation is a more accepted

concept.

4.1 Characterization of User Data

In FIPS Publication 800-73 (Draft) (U.S.

Government, 2005), the requirements for user access

information associated with user security credentials

are defined. These credentials govern all Federal

physical and logical access systems, and were

mandated by Presidential Homeland Security

Directive 12.

Beyond the specifications of the

access information; there is a requirement in FIPS

800-73 to apply X.509v3

digital certificates for

user attribute information. This digital certificate

information establishes an individual’s unique

digital identity, and is normally maintained in an

X.500

directory for rapid application access. The

user attributes as defined in X.509v3

certificates

and in FIPS Pub 800-73 define the user data

available to support this research.

4.2 Characterization of System Data

The Government Information Security Reform Act

(GISRA) (Government, 2001) mandates the

existence of an enterprise architecture document for

any critical infrastructure system in the U.S.

Government. The enterprise architecture document

enumerates the security attributes associated with an

infrastructure system. For a representative critical

infrastructure, these attributes will be used to

provide the system security data available for use to

a metapolicy mechanism.

4.3 Definition of the System Context

Using the system data derived from the enterprise

architecture, and the user data derived from the

METAPOLICIES AND CONTEXT-BASED ACCESS CONTROL

357

X.509v3 certificate and access card specifications,

define the information that is used to define the

security context. This data becomes the formal

definition of the security context for the purposes of

this research and for use by the metapolicy in access

decisions.

4.4 Definition of a Metapolicy

structure

With the system security context defined, an

information structure for the metapolicy must be

created. In (Abadi, 1993), a calculus for access

control in distributed systems is defined. To be

effective a metapolicy must be created,

administered, and enforced. This phase of the

research defines a narrative notation for the

metapolicy, addressing the definition of:

• subjects, or users of the system;

• objects, or items upon which the policy will

act; and

• operations, or privileges associated with the

policy.

The result of this phase is a structured set of

defined actions that describe the behavior of the

metapolicy, written for a human audience. The goal

is to express the model in comprehensible terms to

obtain understanding of the mechanisms of the

metapolicy.

4.5 Modeling of the Metapolicy

Using the modelling techniques developed in

(Abadi, 1993) and (Bell, 1994), a logical

mathematical model of the narrative metapolicy will

be defined. This will allow analysis of the

metapolicy for safety, and logical soundness. Set

theory and mathematics will be employed to provide

a logical basis for metapolicy interaction.

During this phase of the study, a taxonomy of

environmental factors that may impact a metapolicy

will be defined. This taxonomy will be extended

and modified to create a modified taxonomy

appropriate for the metapolicy. Once this taxonomy

is in place, Bayesian belief networks will be used to

model the impact to the metapolicy that could be

anticipated in the event a given node would be

defined as being in a vulnerable state. Finally,

decision tree analysis will be applied to determine

combinations of metapolicy states that could result

in unsafe conditions.

4.6 Determine a Delivery Protocol

The metapolicy needs to be propagated to the nodes

within a network. An analogous model would be the

use of Certificate Revocation Lists (CRLS) in X.509

Public Key Infrastructures (PKI). This task will

examine the feasibility of developing a similar

model for metapolicy propagation. The CRL

processing model is used because it does not require

immediate propagation to all nodes in a network, but

is propagated as nodes/users join the system. That

is, the nodes receive the updated metapolicy when

they join the network and validate that the policy in

force is valid.

5 SUMMARY AND FUTURE

WORK

This paper has presented the concept of

metapolicies, and their potential contribution to

access control in distributed and federated system

architectures. The relationship of this technique to

existing access control models has been explored, as

have the barriers to implementation that existed

when the concept of metapolicies were first

introduced. As security models have matured, so

have computer architectures and artificial

intelligence-based analysis techniques. The next

steps in the research are to explore the logical basis

of metapolicies and determine an appropriate

protocol design for establishment, administration,

and propagation of these policies in a network-

centric environment.

FOOTNOTES

(Schell, 1979) p.20.

Ibid, p. 29.

(Hosmer, 1991) p. 2.

Ibid. pp. 4-5.

(Hosmer, 1993) p. 1

(Bell, 1994) p. 2.

(Baskerville, 2002) p.341

(Strembeck, 2004) p.p. 395-396.

(Covington, 2002) pp.12.

(Strembeck, 2004) p. 400.

(Wang, 2004) p. 1

(Jaeger, 2001) p. 158.

(Sandhu, 2004)p . 1.

ICEIS 2005 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

358

Homeland Security Presidential Directive 12 (HSPD-

12), 27 August 2004.

ITU-T X.509 (formerly CCITT X.509) or ISO/IEC/ITU

9594-8,X.509v3, 1996.

ISO/IEC 9594-1:1993, X. 500, 1991.

REFERENCES

Abadi, M. B., et al (1993). A calculus for access control in

distributed systems. ACM Transactions on

Programming Languages and Systems, Vol. 15(No. 4),

706-734.

Baskerville, R., and Siponen, Milo. (2002). An

information security meta-policy for emergent

organizations. Logistics Information Management,

Vol. 15(No. 5/6), 337-346.

Bell, D. E. (1994, February 1994). Modeling the

"multipolicy machine". Paper presented at the New

Security Paradigms Workshop, Little Compton, RI,

US.

Bertino, E. C., et al (2001, 3-4 May, 2001). A logical

framework for reasoning about access control models.

Paper presented at the SACMAT'01, Chantilly, VA,

USA.

Brézillon, P., and Mostéfaoui, Ghita Kouadri. (2004).

Context-based security policies: A new modeling

approach. Paper presented at the Second IEEE Annual

Conference on Pervasive Computing and

Communications Workshops (PERCOMW'04).

Ferraiolo, D. and. Kuhn., D.M. (1995, October 1999).

Role-based access controls. Paper presented at the

Fifteenth Annual National Computer Security

Conference (NCSC), Baltimore, MD.

Gligor, V. (1995). Characteristics of role-based access

control. Paper presented at the Proceedings of the first

ACM Workshop on Role-based access control,

Gaithersburg, MD, USA.

Government, U.S. (2001) Defense Authorization Act,

Government Information Security Reform Act

(GISRA), U.S. Congress, 106 Sess.(2001).

Government, U. S. (2003). The 9/11 commission report,

final report of the National commission on terrorist

attacks upon the United States. New York, NY: W.W.

Norton & Company Inc.

Hafmann, U.; and Kuhnhauser, Winfried. (1999).

Embedding security policies into a distributed

computing environment. SIGOPS Operating System

Review, Vol. 33(No. 2), pp. 51-64.

Han, Y. F., Liu; Hong, Zhang. (2000). An object-oriented

model of access control based on role. ACM SIGSOFT

Software Engineering Notes, Vol. 25(No.2), 64-68.

Hosmer, H. H. (1991, 3 December 1991). Metapolicies I.

Paper presented at the ACM SIGSAC Special

Workshop on Data Management Security and Privacy

Standards, San Antonio, TX.

Hosmer, H. H. (1993). The multipolicy paradigm for

trusted systems. Paper presented at the New Security

Paradigms Workshop, Little Compton, RI, US.

Jaeger Trent, et al (2003). Policy management using

access control spaces. ACM Transactions on

Information and System Security (TISSEC), Vol. 6(No.

3), 327-364.

Jaeger, Trent. Treadwell., Jonathon. (2001). Practical

safety in flexible access control models. ACM

Transactions on Information and System Security, Vol.

4(No. 2), pp. 158-190.

International Committee for IT Standards/ANSI. (2004).

Information technology -- role based access control:

ANSI/INCITS.

Park, J. S.; et al (2004, 2-4 June). A composite RBAC

approach for large, complex organizations. Paper

presented at the SACMAT'04, Yorktown Heights, NY,

U.S.

Press, Microsoft. (2004). Microsoft Encarta dictionary for

Office 2003, Windows XP edition.

Sandhu, R. (2004).

A logical specification for usage

control. Paper presented at the Proceedings of the

ninth ACM symposium on Access control models and

technologies, Yorktown Heights, New York, USA.

Sandhu, R. et al (1996). Role-based access control models.

IEEE Computer, Vol. 29(No. 2), pp. 38-47.

Sandhu, R.;et al (2000, 26-27 July 2000). The NISTt model

for role-based access control: Towards a united

standard. Paper presented at the Fifth ACM Workshop

on Role-based Access Control, Berlin, Germany.

Schell, R. R. (1979). Computer security -- the Achilles'

heel of the electronic air force. Air University Review,

Vol. XXX(No. 2), pp. 16-33.

Strembeck, M. &. N., Gustaf. (2004). An integrated

approach to engineer and enforce context constraints

in RBAC environments. ACM Transactions on

Information and System Security, Vol. 7(No. 3), 392-

427.

U.S. Government, National Institute of Standards and

Technology. (2005). NIST special publication 800-73,

interfaces for personal identity verification (Draft

Standard), 31 January 2005 Washington, DC:

Department of Commerce.

Wang, H. J.,et al (2004). Security policy reconciliation in

distributed computing environments. Paper presented

at the Fifth IEEE International Workshop on Policies

for Distributed Systems and Networks (Policy'04).

METAPOLICIES AND CONTEXT-BASED ACCESS CONTROL

359
