ENTERPRISE ANTI-SPAM SOLUTION

BASED ON MACHINE LEARNING APPROACH

Igor Mashechkin, Mikhail Petrovskiy, Andrey Rozinkin

Computer Science Department, Lomonosov Moscow State University,

Building 2, MSU, Vorobjovy Gory, 119992, Moscow, Russia

Keywords: Spam, Junk E-mail, Machine Learning, Text Classification, Multi-agent Architecture

Abstract: Spam-detection systems based on traditional methods have sev

eral obvious disadvantages like low detection

rate, necessity of regular knowledge bases’ updates, impersonal filtering rules. New intelligent methods for

spam detection, which use statistical and machine learning algorithms, solve these problems successfully.

But these methods are not widespread in spam filtering for enterprise-level mail servers, because of their

high resources consumption and insufficient accuracy regarding false-positive errors. The developed

solution offers precise and fast algorithm. Its classification quality is better than the quality of Naïve-Bayes

method that is the most widespread machine learning method now. The problem of time efficiency that is

typical for all learning based methods for spam filtering is solved using multi-agent architecture. It allows

easy system scaling and building unified corporate spam detection system based on heterogeneous

enterprise mail systems. Pilot program implementation and its experimental evaluation for standard data sets

and for real mail flows have demonstrated that our approach outperforms existing learning and traditional

spam filtering methods. That allows considering it as a promising platform for constructing enterprise spam

filtering systems.

1 INTRODUCTION

It is well known that from 40% up to 80% of all

electronic messages in the Internet is spam. Spam,

by definition, is unsolicited bulk e-mails. In other

words spam is electronic messages posted blindly to

thousands of recipients. Obviously, unauthorized e-

mails mean real expenses for companies and

personal users.

Nowadays various spam-preventing techniques

have

been developed. They can be divided into two

major categories. The first one includes

administrative and technical methods, which try to

stop spam distribution. They are laws, which restrict

sending of spam messages, new protocols for e-mail

services based on authorized confirmation of the

mail transfer like Sender ID standard (Microsoft

Corp., 2004), payments for each sent message,

blocking of mail servers, which are used to send

spam and so on.

The other category includes methods that

pre

vent spam receiving by users, so called spam

filtering. These methods can be also divided into two

groups: traditional, which use fixed set of rules or

signatures for spam filtering; and adaptive, which

are based on statistical methods and artificial

intelligence. Many traditional methods use different

types of black lists of spam senders’ addresses

(ORDB.org, 2004). Traditional methods also use

knowledge bases of keywords, rules and signatures

of spam messages. These knowledge bases are

prepared manually by experts and require regular

updates. The systems based on such methods usually

have low spam detection rate (60-70%). Besides, it

is necessary to upgrade knowledge bases regularly to

keep them up-to-date. So, these systems depend on

efficiency of the updates’ provider and they are

unprotected during the period between new spam

appearing and knowledge base updating. Moreover,

traditional methods are not personalized, so they do

not take into account peculiarities of the

correspondence of a particular user. All this also

decrease the accuracy. Nevertheless, the systems

using black lists are widespread because of

simplicity of their installation and maintenance.

However, recently they are strongly criticized for the

high false-positive error rate. The reason is that

some providers use very simple and inconsequent

rules to update and maintain their black lists.

188

Mashechkin I., Petrovskiy M. and Rozinkin A. (2005).

ENTERPRISE ANTI-SPAM SOLUTION BASED ON MACHINE LEARNING APPROACH.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 188-193

DOI: 10.5220/0002521801880193

 SciTePress

Intelligent methods are a relatively new trend in

spam detection. They may eliminate disadvantages

of the traditional methods. Intelligent methods use

statistical and machine learning algorithms. The

algorithms are capable to classify mail into several

categories using a statistical or machine learning

models constructed beforehand on the basis of the

precedent information (Yang, 1999).

To make such system work properly, it is

necessary to train it on a set of e-mails that have

been already classified as spam or legal messages.

This training’s result is a model that is then used for

a new mail classification. Nowadays the most

popular intelligent method for spam detection is

Naïve-Bayes method. (Sahami et al., 1998). Naïve-

Bayes method is being implemented and is

successfully used in several spam-detection systems

(Apache, 2004a; Farmer, 2004).

Intelligent methods have several advantages in

comparison with the traditional ones. They do not

depend on external knowledge databases and do not

need regular updates. They do not use specific

features of particular language, so they are

multilingual. They are able to adjust the models

using new samples of spam without the

administrator’s assistance and they can build

personal filtering models.

Nevertheless, despite their efficiency and

intelligence these methods are not widely used in

spam-detection systems at the enterprise level for

several reasons. First of all, most intelligent methods

are not stable enough when detecting legal mails and

have a rather high level of false-positive errors.

Intelligent methods have higher hardware

requirements because they are based on

computationally expensive algorithms.

The aim of our research is to offer a

comprehensive e-mail-classifying solution for

enterprise-level system that will be based on the

intelligent analysis of messages. The solution should

have the advantages of intelligent methods such as

personification and high spam detection rate at low

quantity of false-positive errors. At the same time

the system should provide necessary efficiency to be

used on enterprise-level mail servers.

2 OUR SOLUTION

Our solution is based on the intelligent classification

algorithm that allows reaching necessary quality on

the one hand, and on a multi-agent architecture that

provides necessary efficiency, on the other.

For solving the classification problem we are

using a statistical method based on support vector

machines (SVM) (Scholkopf & Smola, 2000;

Vapnik, 1998). This method was applied to text

categorization task earlier (Joachims, 1998). It is

necessary to solve two problems to apply SVM for

spam detection task: select proper kernel-function

and find appropriate representation of e-mails as

feature vectors.

We have selected the following representation

for electronic messages: a feature set is defined as a

set of all words that appeared in all analyzed

messages more than the predetermined number of

times. Furthermore, feature set is reduced by

eliminating a set of predefined stop-words.

Additionally, the feature set is expanded with

features defined for all file extensions of files

attached to the analyzed messages (Yang &

Pedersen, 1997).

So, each message is represented as a subset of

feature set. Each element of the set is a number of

appearances of a particular feature in a message

normalized by quantity of message’s features.

We have carried out several experiments with

various standard kernel-functions and have

discovered that RBF kernel-function shows quite

good results. It provides a high level of accuracy and

comprehensible efficiency of the algorithm.

Besides, the solution should meet the following

basic requirements: high efficiency; enterprise level;

the ability to take into account personal features of

each user’s correspondence; platform independence;

scalability; safety and privacy. These requirements

lead us to a multi-agent architecture for the system.

The general architecture of the system is shown on

the figure 1.

The central communication node of the system is

presented by one or several web-servers. It provides

communication environment for training and

classifying agents, supports shared vocabulary,

converts messages to feature sets and provides GUI

for users. The communication node stores shared

vocabulary, temporary feature vectors and some

additional user’s information in the database. All

time-consumptive operations like preprocessing and

downloading messages, training user models and

classification are moved to corresponding agents.

The training agent is a process that analyses

user’s messages and builds user’s personal model on

the basis of this analysis. The training agent allows

customization for different message storages.

In current version it is located at the centralized

mail server and accesses personal data using IMAP

protocol. Another solution might be the personal

agent on a user’s workstation that uses local mail

storage from the personal folders. The common

training workflow is the following.

A user initializes training procedure using web-

based interface.

ENTERPRISE ANTI-SPAM SOLUTION BASED ON MACHINE LEARNING APPROACH

189

Incoming

Mail

Mail Server

Classifying

Agent

File

Storage

Mail Storage

Spam

Inbox

Training

Agent

Communication

Node

Database

(shared vocabulary

+ datasets)

Local Delivery

Agent

Unclassified

Message

Decoded and

parsed message

Classification

Result

Feature

Vector

User

Model

Feature

Vector

Training Set

Classified

Message

Classification Data Flow

Training Data Flow

Unclassified

Message

User

Model

Decoded and

parsed message

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(1)

(2)

(3)

(4)

Figure 1: Architecture of Enterprise Spam Detection System

The central communication node starts training

agent and initializes downloading the subset of

user’s messages using IMAP protocol. The training

agent decodes each message, parses it into terms and

then passes vector representation of each message to

the central communication node using https

protocol. The central node creates the feature vector

for the message, saves it to the database temporarily

and updates shared vocabulary located in the

database. Have all messages been downloaded, the

central node creates a training set from feature

vectors stored in the database, saves it to the server’s

file system and starts training procedure using the

created training set. The result of training is the

personal user’s model that is saved to the file

system.

The classifying agent intercepts messages from

the mail server and classifies them. The common

classifying workflow is the following. When a new

message arrives, it falls to the local mail delivery

agent. This agent transfers the body of the message

to the classifying agent. Then it decodes and parses

the message and passes it’s vector representation to

the central communication node. The central node

forms the feature vector from the message on the

basis of the shared vocabulary and returns the

feature vector back to the classifying agent. The

classifying agent evaluates message’s score using

saved user’s model and created feature vector of the

message. The resulting score retuned to the local

mail delivery agent that adds a status (spam / not

spam) to the header of the message and then moves

it to the appropriate user’s mail folder. So, if a user

reads mail using IMAP protocol he or she sees only

legal messages in Inbox folder. Spam messages are

not deleted, and are saved in a separate folder, that is

also accessible for a user through IMAP. By default,

IMAP Inbox and Spam folders are used as sources

of legitimate and spam training sets for training user

models. Once the system has been trained, a user

may clear his/her spam storage to save disk space.

Adding new mail servers or new mail clients can

extend the system functionality. To support them it

is necessary to implement a new training or

classifying agents. It allows creating uniform and

well-scaled corporate system of spam filtration that

unites heterogeneous company’s infrastructure

including different mail clients and mail servers.

The presented architecture was tested on the

enterprise spam-detection system. The current

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

190

version of the system has been tested with the

following configuration: RedHat Linux 9.0

operating system, mail server Sendmail 8.2 or Exim

4.34, local mail delivery agent Procmail 3.22.

Current versions of classification and training agents

are written as C++ executables. We used mySQL

database engine for the pilot system. The current

version of the central communication node is

implemented on PHP and based on Apache web-

server.

We propose a solution that solves one of the

main problems of learning algorithms – the

resources consumption. This goal was achieved due

to the multi-agent architecture that allows scaling the

system according to real needs and unites

heterogeneous infrastructure of an enterprise with

different mail servers and clients.

3 EXPERIMENTS

The purpose of our experiments is to compare

efficiency of the proposed algorithm to other up-to-

date methods and algorithms. The framework of the

experiment includes two different tests that estimate

classification accuracy.

The first test was carried out with the

commercial product Kaspersky Anti-Spam

Enterprise Edition (Kaspersky Labs, 2004). This

product uses traditional filtering methods based on

the heuristic analysis of the text and headers of

messages, and regularly updates knowledge bases.

The experiment was carried out in the real-world

situation, using the real dataflow from existing mail

accounts. The experiment should show the

superiority of the system based on intelligent

methods of mail analysis, and it also estimates the

performance and reliability of our solution in the

real-world conditions.

The second test was carried out with the

implementation of Naïve-Bayes method on standard

test corpuses of messages. We used implementation

of Naïve-Bayes method from freeware anti-spam

solution SpamAssassin (Apache, 2004a).

SpamAssassin has been customized so that Naïve-

Bayes method took part in classification only. The

experiment was carried out with several public test

corpuses of messages. The purpose of the given

experiment was to compare our algorithm with the

most popular learning method.

3.1 Experiment #1: Kaspersky Anti-

Spam Enterprise Edition

Kaspersky Anti-Spam Enterprise Edition (Kaspersky

Labs, 2004) is a spam-filtering system for a mail

server. It is based on several levels of spam

identification such as linguistic analysis, spam

signatures, RBL-services and so on. The support

team prepares updates of the knowledge base every

two hours.

The experiment was carried out on a real mail

dataflow that had been gathered from several mail

accounts. The flow of messages was copied to

several mail accounts, which were processed by

anti-spam filters. In total, 2700 messages were

processed (2598 – spam /102 – legal mail). Four

mail accounts were created, one - for Kaspersky

Anti-Spam filter, and the three others - for the anti-

spam filter based on our algorithm.

All parameters of Kaspersky Anti-Spam filter,

except RBL-lists, remained as default. We

considered that it was more correctly to switch off

RBL-lists. One of the goals of this test was to

discover the influence of size and structure of initial

training set on the classification quality. Therefore,

three different accounts were created for the

experimental anti-spam filter. The initial training

sets were:

Account #1: 200 legal / 200 spam

Account #2: 200 legal / 2000 spam

Account #3: 2000 legal / 2000 spam

Messages for initial training sets were randomly

collected from previously received messages for

those accounts. The additional training using newly

arrived mail was not performed.

After finishing the experiment we processed the

results and selected two different optimal thresholds

Table 1: Results for Kaspersky Anti-Spam Experiment

Detection Rate optimization False Positive optimization

Account

Initial training

corpuses

(spam / legal)

Detection

Rate %

False Positive

Rate %

Detection

Rate %

False Positive

Rate %

Experimental #1 200 / 200 100 7,8 88,6 0

Experimental #1 200 / 2000 100 9,8 99,9 0

Experimental #1 2000 / 2000 100 0 100 0

Kaspersky Anti-Spam - 72,5 0 72,5 0

ENTERPRISE ANTI-SPAM SOLUTION BASED ON MACHINE LEARNING APPROACH

191

for each mail account. One of them is for a

minimized number of the false-positive errors and

the other is for a maximized accuracy of detection.

The results are presented in the Table 1. The results

for Kaspersky Anti-Spam Enterprise Edition were

more or less typical for today’s traditional anti-spam

filters. Its detection level is about 70%. The analysis

of the results shows that it is possible to set

parameters of our algorithm to achieve zero quantity

of false-positive errors. Thus, the corresponding

detection rate will depend on the size and quality of

initial training set. Our anti-spam filter achieved

better results than traditional methods system even

with a smaller initial training set. The absolute

accuracy was reached on a mail account with the

maximal initial training set. There were no errors at

all during two weeks of testing.

3.2 Experiment #2: Naïve-Bayes

method

Two public mail corpuses were used for comparing

our algorithm with Naïve-Bayes method from

SpamAssassin anti-spam filter.

LingSpam Corpus (Androutsopoulos et al.,

2000)

Initially there are four versions of LingSpam

corpus. We used ‘bare’ as the most general version

of the set. A corpus’s message contains body and

subject only, but there is no header. The size of the

set is 2893 messages.

The set was randomly divided into 10 equal

parts, each of which contained about 290 messages

(240 normal and 50 spam). We held ten different

iteration of the test and then combined the results.

Nine parts of the test corpus were used for the

training and one for testing during each iteration.

SpamAssassin Corpus (Apache, 2004b).

Corpus messages are presented in full and all

headers have been saved. The set consists of three

parts: ‘spam’ (500 messages with spam);

‘easy_ham’ (2500 normal messages, which are

easily detected as normal by anti-spam filters);

‘hard_ham’ (250 normal, but very similar to spam

messages).

These three parts were split into five equal parts.

Accordingly, each part contains 100 messages of

spam, 500 easily detected normal messages and 50

hardly detected normal messages.

Four parts of the set were used for training and

one part was used for testing. So, five iterations were

made with this test corpus.

To evaluate the performance of the algorithms

we used ROC (Receiver Operating Characteristic)

curves. The results of several tests have been

averaged and ROC-curves have been constructed for

each test corpuses. Evidently, ROC-curve for our

algorithm is above a curve for Naïve-Bayes

algorithm for both LingSpam and SpamAssassin

corpuses. That means that our algorithm completely

outperforms Naïve-Bayes method from

SpamAssassin.

4 CONCLUSIONS

The developed solution offers precise and fast SVM

based algorithm with better classification quality

than Naïve-Bayes method’s that is the most

widespread now. It allows achieving high detection

level. The problem of time efficiency that is typical

100

012345

False positive (%)

Detection Rate (%)

Naïve-Bayes

Our Method

100

00,511,522,53

False Positive (%)

Detection Rate (%)

Naïve-Bayes

Our Method

Figure 2: ROC-curves for LingSpam Test Corpus Figure 3: ROC-curves for SpamAssassin Test Corpus

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

192

for learning algorithms is solved by using multi-

agent architecture that allows scaling system easily

and building uniform corporate system for spam

detection based on heterogeneous enterprise mail

system.

Pilot

program implementation and its

exp

REFERENCES

Androutsopoulos, I., Koutsias, J., Chandrinos, K.V.,

Ap 2004a) The Apache

Apache Software Foundation (2004b) The Apache

Far il Classification Program

Joa

Ka ersky Anti-Spam Enterprise

Mi ID technology [WWW]

OR lay Database [WWW]

Sah umais, S., Heckerman, D., and Horvitz, E.

Sch

els: Support Vector Machines, Regularization,

Vap

election in text categorization. Proceedings

Yan

mation Retrieval, 1, 1/2,

erimental evaluation for standard data sets and

for real mail flows have demonstrated that our

approach outperforms existing learning and

traditional spam filtering methods. That allows

considering it as a promising platform for

constructing enterprise spam filtering systems.

Paliouras, G., and Spyropoulos, C.D. (2000). An

evaluation of naïve Bayesian anti-spam filtering. In

Proceedings of the Workshop on Machine Learning in

the New Information Age, 11-the European

Conference on Machine Learning (ECML 2000),

Barcelona, Spain, pp. 9–17 [WWW] Available at

http://www.aueb.gr/users/ion/data/lingspam_public.tar

.gz (retrieved November 2003)

ache Software Foundation (

SpamAssassin Project [WWW] Available at

http://spamassassin.apache.org (accessed December

2004).

SpamAssassin Public Corpus [WWW] Available at

http://spamassassin.apache.org/publiccorpus/

(retrieved November 2003)

mer, J. (2004) SpamPal - Ma

[WWW] Available at http://www.spampal.org

(accessed December 2004).

chims, T. (1998) Text Categorization with Support

Vector Machines: Learning with Many Relevant

Features. Proceedings of {ECML}-98, 10th European

Conference on Machine Learning, Springer Verlag,

Heidelberg, DE, 137-142

spersky Labs (2004), Kasp

Edition [WWW] Available at

http://www.kaspersky.com/antispamenterprise

(accessed December 2004).

crosoft Corp. (2004) Sender

Available at http://www.microsoft.com/senderid

(accessed December 2004).

DB.org (2004) Open Re

Available at http://www.ordb.org (accessed December

2004).

ami, M., D

(1998). A Bayesian approach to filtering junk email.

AAAI Workshop on Learning for Text Categorization,

Madison, Wisconsin. AAAI Technical Report WS-98-

olkopf, B. and Smola, A., J. (2000) Learning with

kern

Optimization and Beyond. The MIT Press Cambridge,

Massachusetss

nik, V., N. (1998) Statistical learning theory, Wiley,

New York

Yang, Y. and Pedersen, J., O. (1997) A comparative study

on feature s

of {ICML}-97, 14th International Conference on

Machine Learning, 412-420

g, Y. (1999) An Evaluation of Statistical Approaches

to Text Categorization. Infor

69-90

ENTERPRISE ANTI-SPAM SOLUTION BASED ON MACHINE LEARNING APPROACH

193
