AN EVENT PROCESSING SYSTEM FOR RULE-BASED

COMPONENT INTEGRATION

Susan D. Urban, Sunitha Kambhampati, Suzanne W. Dietrich, Ying Jin, Amy Sundermier

Department of Computer Science and Engineering

Arizona State University

Tempe, Arizona USA

Keywords: active rules, event specification, event

processing, component integration

Abstract: The Integration Rules (IRules) project has developed an environment in which active rules, known as

integration

rules, are used together with transactions to provide an event-driven, rule-based approach to the

integration of black-box components. This paper presents the event processing system that supports the use

of integration rules over components. The event processing system is composed of the language framework

for the specification of different types of events, an event generation system for generating event instances,

and an event handler for communicating the occurrence of events to the integration rule processor. The

language framework supports the enhancement of EJB components with events that are generated before

and after the execution of methods on components. Since integration rules support an immediate coupling

mode and execute in the context of nested transactions, a synchronization algorithm has been developed to

coordinate the execution of immediate integration rules with the execution of methods on components. The

synchronization algorithm makes it possible to suspend and resume distributed application transactions to

accommodate the nested execution of integration rules with an immediate coupling mode.

1 INTRODUCTION

Distributed component technology standards address

the need for well-known interfaces and middleware

for discovering and integrating software components

into applications (COM/DCOM, 2003; OMG, 1998;

WSA, 2002; J2EE, 2003). Implementing distributed

applications when components reside on multiple

servers, however, can be a difficult task that often

results in procedural, hard-coded solutions. The

application integrator must not only understand the

semantics for mediating the interactions between the

components, but must also be skilled in the technical

details associated with distributed event and

transaction processing techniques.

The Integration Rules (IRules) project at Arizona

State Uni

versity has responded to the need for more

flexible and declarative middleware technology by

applying active rule processing technology to the

area of software component integration (Urban et al.,

2001). Active database technology enhances

traditional database technology with the ability to

monitor and react to circumstances that are relevant

to an application (Widom and Ceri, 1996). The

IRules project is extending the use of active rules to

distributed components, providing a middle-tier, rule

processing framework for the integration of

distributed black-box software components. The

current prototype implementation supports the

Enterprise JavaBeans (EJB) (EJB, 2001) component

model, with future plans to include support for other

component models.

The IRules project provides an environment in

ich active rules, known as integration rules, are

used together with transactions to provide an event-

driven, rule-based approach to component

integration. When an event is generated in the IRules

environment, an integration rule is triggered to test a

condition expressed as a query over distributed

components. A successful condition evaluation may

invoke additional methods on components in the

action part of an integration rule. Integration rules

therefore provide a declarative and distributed rule

processing mechanism for responding to events in a

distributed environment, thereby separating the logic

associated with reactive behavior from the main

312

D. Urban S., Kambhampati S., W. Dietrich S., Jin Y. and Sundermier A. (2004).

AN EVENT PROCESSING SYSTEM FOR RULE-BASED COMPONENT INTEGRATION.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 312-319

DOI: 10.5220/0002619803120319

 SciTePress

application logic expressed within distributed

transactions.

One of the challenges of developing the IRules

environment has been the design and

implementation of the event processing system that

supports the execution of integration rules

(Kamphampati, 2003). The event processing system

is composed of a language framework for the

specification of several different types of events, an

event generation system for generating instances of

each event type, and an event handler for

communicating events to the integration rule

processor. The IRules language allows for the

definition of events that are detected before and after

the execution of methods on components and the

execution of distributed application transactions.

The language framework also supports the

specification of events that are generated and

published by the internal logic of black-box

components as well as events that are generated by

sources external to IRules.

To coordinate events with transactional behavior

in the IRules environment, we have developed

wrappers that serve as proxies for EJB components

(Patil, 2003). All method calls are routed through the

wrappers. The wrappers are responsible for

generating events before and after method execution.

The wrappers are also capable of suspending

methods to support the nested execution of triggered

rules with an immediate coupling mode. A

synchronization algorithm uses semaphores

implemented with JavaSpaces (Freeman et al., 1999)

operations as a distributed communication

mechanism. The synchronization algorithm

coordinates the execution of application transactions

with the nested execution of integration rules before

and after the execution of methods on EJB

components.

Our research provides an original approach to

enhancing black-box components with event

generation techniques, addressing issues for control

of transactional scope, event handling, and

suspension and resumption of activities in

component-based integration architectures. These

issues are described as future directions within the

Business Process Execution Language specification

(BPEL4WS, 2002), a standard choreography

language for integrating Web Services. The

techniques described within this paper, although

currently implemented using Java technology, are

applicable to other component models and

integration languages as well.

The remainder of this paper is structured as

follows. Section 2 provides an overview of the

IRules environment. Section 3 presents the

language framework for the specification of IRules

events. The event handling component of the IRules

environment is presented in Section 4. Section 5

provides an overview of the synchronization

algorithm for coordinating method execution with

rule execution. Our work is discussed in the context

of related work in Section 6. The paper concludes

with a summary in Section 7.

2 OVERVIEW OF IRULES

Figure 1 provides a high-level view of the

functionality of the IRules environment. As shown

in Figure 1, EJB components are organized into

distributed containers, where each component was

purchased or created independently of components

in other containers. This specific example illustrates

an Investment application from (Urban et al., 2001),

consisting of four different containers with

purchased software components: a Portfolio

container, a Pending Order container, a Stock

container, and an Account container.

Although the containers in Figure 1 are

independent black-box containers that know nothing

about the existence of the other containers, the

IRules semantic framework supports the definition

of externalized relationships (Rumbaugh, 1987)

between such containers. These relationships are

shown in Figure 1 by lines between components in

different containers. For example, the externalized

relationship between Stock and Pending Order

represents the type of stock that is associated with a

pending buy or sell order. Externalized relationships

are managed by IRules wrappers around existing

EJB components. In addition to externalized

relationships, IRules wrappers add other

functionality to EJB components, such as extents,

derived attributes, stored attributes, and events

(Dietrich et al. 2001).

Application logic is captured through the use of

application transactions together with integration

rules. Integration rules have been derived from

active rules in active database technology (Widom

and Ceri, 1996), providing an Event-Condition-

Action (ECA) rule form as well as an Event-Action

(EA) rule form for responding to events. As shown

in Figure 1, when an application transaction

executes a method such as Operation k on an EJB

component, an event can be generated that triggers

the execution of integration rules. These events are

referred to as method events and can be generated

before or after the execution of a method on a

component. Integration rules may also be triggered

by internal events, application transaction events, or

external events. Internal events are events that were

defined within a black-box component before the

component joined the IRules environment.

AN EVENT PROCESSING SYSTEM FOR RULE-BASED COMPONENT INTEGRATION

313

Application transaction events are events that can be

generated before or after the execution of an

application transaction. External events are events

that are generated from sources outside of the IRules

environment.

The structure of an integration rule is also shown

in Figure 1. When an integration rule is triggered by

an event, the rule may execute a when condition that

is expressed as a simple query over the event object

and its parameters. If the condition evaluation is

true, then an OQL-based (Cattell and Barry, 2000)

define statement allows for the named specification

of bindings using a query over the distributed

components of the environment. The action of the

rule may refer to these bindings when invoking a

method of a component or an application

transaction.

The rule-based approach to component

integration within the IRules environment is

expressed using the IRules Definition Language

(IRDL) (Dietrich et al., 2001; Urban et al. 2001).

IRDL consists of four sub-languages: the

Component Definition Language (CDL) for

describing components and defining the method and

internal events associated with that component, the

IRules Scripting Language (ISL) for describing

application transactions, the Event Definition

Language (EDL) for defining external and

application transaction events, and the Integration

Rule Language (IRL) for defining integration rules

that respond to events. In the current version of

IRDL, ISL is based on the JACL (DeJong and Laird,

2003) scripting language, which is a Java

implementation of the Tool Command Language

(TCL) (Ousterhout, 1994).

The IRules execution environment is a Jini-based

architecture that supports the execution of events,

rules, and application transactions over distributed

EJB components (Jin et al., 2002). Architectural

components include the rule manager for controlling

the execution of rules, the transaction manager for

the management of transactions, the object manager

for providing abstract access to the underlying

components of the system, the metadata manager for

storing the integration semantics as extracted from

the compilation of an IRDL schema, and the event

handler for processing events. The Java Messaging

Service (JMS) (JMS, 1999) provides asynchronous

event notification.

Account

IRulesAccount

Portfolio

IRulesPortfolio

Stock

IRulesStock

PendingOrder

IRulesPendingOrder

Account Container Stock Container

Portfolio Container

PendingOrder Container

Method Event

Internal Event

Application Transaction

Begin

Operation1

...

Operation k

...

Operation n

End

Application Transaction

Event

Integration Rule

triggers

generate

Execute operation

on EJB

Integration Rule:

create rule ruleName

event eventName(event Parameters)

[on componentName componentVariable]

condition [eaCoupling]

when conditionSpecification

[define bindingsName as

select <>

from <>

[where <>]]

action [caCoupling]

[from <>

[where <>]]

do action

External Event

Integration Rule

Execute Operation

on EJB

triggers

Externalized Relationships

Figure 1: Purchased Components

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

314

3 IRULES EVENT DEFINITION

The subsections that follow illustrate the

specification of each type of event supported in the

IRules environment.

3.1 Event Specification in CDL

Method and internal events are expressed using CDL

since they are associated with component

definitions. The syntax of CDL is based on the

syntax of the ODMG Object Definition Language

(ODL) (Cattell and Barry, 2000). Using the

Investment example introduced in Section 2, Figure

2 shows an example of describing a portion of the

Stock component to the IRules environment, which

includes the definition of a method event. The event

specification is composed of an event name and a

list of parameters, followed by curly braces that

enclose the definition of the details of the event. The

method keyword defines the type of the event, while

the before keyword is an event modifier, indicating

that the event is raised before the execution of the

method. The keyword after can be used to define an

event raised after the execution of a method. The

name and type of the method parameters are also

specified. The names of the method parameters in

CDL allow for naming the attributes that are to be

propagated as parameters to the IRules event.

component Stock implements EntityBean

(extent stocks)

{ ………

event beforeSetPrice(newPrice)

{method before setPrice(double newPrice);}}

Figure 2. Example of a Method Event

Figure 3 presents the stockBuy rule as an example

of an integration rule that is triggered in response to

the beforeSetPrice method event. The condition part of

the rule includes an OQL-like query expressed over

the distributed components of the environment. The

when condition checks whether the new price of the

stock is less than the current stock price. The action

part of the rule does a buy transaction for the stocks

that are currently pending.

When an EJB component joins the IRules

environment, it is possible that the black-box

component is capable of generating and publishing

events as part of its internal logic. The IRules

environment refers to these events as internal events

and allows the use of internal events in the

integration process. Since internal events are

associated with components, these events are

defined as part of CDL.

create rule stockBuy

event beforeSetPrice(NewPrice)

on stock S

condition immediate

when NewPrice > S.price

action immediate

from Pn in S.pendingTrades

where S.price<=Pn.desiredPrice and

Pn.pnaction="buy"

do buyStock(S,Pn)

Figure 3. Example of an Integration Rule Triggered by a

Method Event

As an example of an internal event, Figure 4

presents the specification of the afterUpdateCash

event within the StockBroker_PastHolding component

of the Portfolio container. This is an event that is

generated as a result of the execution of an update

operation on the cash value of a portfolio. Internal

events are always after events, since the IRules

environment has no control over the execution of the

internal logic of a black-box component. As a result,

an event modifier is never specified for internal

events. The event handler currently supports internal

events published by EJB components using the JMS

system. Internal events must specify the proprietary

name and message type of the event that

accompanies the JMS message. In Figure 4, the

updateCashEvent token is the name of the event that

is sent to the appropriate JMS topic (i.e., a data

structure for collecting JMS messages) by the black-

box component. The map token represents the JMS

map message type with its corresponding

parameters.

component StockBroker_PastHolding implements

EntityBean

(extent pastHoldings)

{relationship Stock pastStock

inverse Stock::soldBy;

event afterUpdateCash (portfolioID, cashValue)

{internal map(int portfolioID, float

cashValue) updatecashEvent};};

Figure 4. Example of an Internal Event

3.2 Event Specification in EDL

Application transaction events and external events

are defined using EDL. Since application

transactions in IRules are defined using ISL, Figure

5 provides an example of the sellStockOnNewPO ISL

transaction for selling stock. The code in the body of

the transaction uses JACL syntax. The newinstance

AN EVENT PROCESSING SYSTEM FOR RULE-BASED COMPONENT INTEGRATION

315

command is a JACL extension command used to

create a new instance of a PortfolioSessionBean. The

sellStock method is then executed on

PortfolioSessionBean and the PendingOrderComponent

status is set to 'executed'. The last step in the body

does the task of printing the status of the pending

order by executing printSellInfo extension command.

application transaction

sellStockOnNewPO(string stockId, float price, string

portfolioId, int numOfShares, PendingOrder pn)

tcl newInstance,printSellInfo

{ set session [newInstance PortfolioSessionBean]

$session sellStock $stockId $price $portfolioId

$numOfShares

$pn setStatus "executed"

printSellInfo $pn}

Figure 5. Example of an Application Transaction in ISL

Figure 6 illustrates the specification of an

application transaction event, named

afterSellStockOnNewPO, that is generated after the

execution of the sellStockOnNewPO application

transaction specified in Figure 5.

event afterSellStockOnNewPO(stockId, price, portfolioId,

numOfShares, pn)

{ appTrans after sellStockOnNewPO(String stockId, float

price, String portfolioId, int numOfShares,

PendingOrder pn);}

Figure 6. Example of an Application Transaction Event

Since it is likely that the application integration

process may need to monitor events from external

sources, the IRules environment supports the

definition and use of external events. We assume

that external events are generated using JMS.

External events are defined in the same manner as

internal events and must therefore specify the

proprietary name and message type of the event that

accompanies the JMS message. There is no modifier

explicitly stated with external events since they are

inherently after events.

Figure 7 gives an example of an external event in

the context of the Investment application that

monitors changes in stock prices from the stock

market. The afterStockMarketQuote event is defined as

a JMS map message type with an originating event

name of TickerEvent. Within the Investment

application, the occurrence of this event can be used

to update local information about stock prices.

event afterStockMarketQuote(stockId, newPrice)

{external map(String stockId, double newPrice)

TickerEvent;}

Figure 7. Example of an External Event

4 THE EVENT HANDLER

The IRules framework uses the publish-subscribe

approach of JMS to support asynchronous message

passing during rule execution. Method and

application transaction events are sent to a pre-

defined IRules Event Topic. Internal and external

events are sent to a proprietary JMS topic that must

be made known to the IRules environment. The

IRules Event Handler listens to the relevant topics

and communicates event information to the rule

processor using a push strategy.

As shown in the Figure 8, method events are

generated by IRules wrappers. The execution of an

application transaction or the action part of a rule

can invoke method calls to the black-box

components. The wrapper intercepts any call to the

EJB instance of the black-box component. The

wrapper is responsible for generating method events

and for invoking the method on the component

instance. Event parameters for a given method event

are packaged into a generic IRules data structure

called EventMsg. The EventMsg object is then

published to the IRules Event Topic. The transaction

manager is responsible for generating application

transaction events. Similar to method events,

application transaction events are also packaged into

the IRules EventMsg data structure and published to

the IRules Event Topic.

For external and internal events, since the

messages are in their proprietary JMS format, the

message has to be extracted, interpreted, and

translated into the IRules EventMsg format. The

event handler initiates the necessary listeners or

subscribers for all of the topics to which internal and

external events are being published. When an

internal or an external event is received, the JMS

message is extracted and the necessary parameters

are interpreted from the information available in the

IRules metadata repository. The interpretation and

extraction process depends on the type of the

message that is received at the event handler.

After the interpretation and extraction process,

the EventMsg instance is propagated to the rule

manager. As a result, all of the different types of

events ultimately share the same event structure. The

rule processor then executes the triggered rules for a

newly detected event depending on the semantics of

the coupling modes associated with the rules.

5 SYNCHRONIZATION ISSUES

Integration rules are processed based on coupling

modes as defined in traditional active database

systems. Coupling modes define transactional

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

316

behavior for rule execution. The IRules system

supports four coupling modes (Jin et al., 2002):

immediate synchronous (the condition of a rule must

be executed as a nested transaction immediately

after an event is raised), immediate asynchronous

(same as immediate synchronous except that the rule

and triggering transaction are processed

concurrently), deferred (condition evaluation occurs

at the end of the outermost transaction in which a

rule is triggered), and decoupled (a new top-level

transaction is created for processing a rule). The

coupling mode of interest in this paper is the

immediate synchronous coupling mode, which

results in a nested execution structure where the

triggering transaction suspends while the triggered

rule executes as a sub-transaction. IRules must

suspend the transaction that executes the triggering

event and release the suspended transaction when

rule execution completes.

Consider the case of method events. An IRules

wrapper wraps each black-box instance and acts as a

proxy to the black-box. Since the EJB component

model does not allow threading and does not support

primitives for a blocking mechanism, there is no

built-in mechanism for suspending method

execution to allow for rule execution. A

synchronization process has been implemented as

part of this research to coordinate the execution of

methods on components with the execution of rules

by the rule processor. Since any method of a

component executes in the context of a transaction

within IRules, the transaction identifier that

represents the IRules transactional context is used to

help generate a semaphore for the synchronization

process. The transaction identifier alone, however, is

not sufficient for the creation of a semaphore since

the JACL interpreter for executing ISL transactions

allows multi-threading. As a result, two or more

methods on components within one transaction can

be called concurrently by the JACL interpreter.

We associate a counter, initialized to zero, with

the transaction identifier to create a

ResourceSemaphore object as a pair (t

, c

), where t

is the transaction identifier and c

is a counter for the

execution of methods within t

. The

ResourceSemaphore (t

, c

) is used to provide a

unique event identifier, known as the EventId, across

all of the distributed components that execute within

the IRules environment. The EventId is used to

coordinate the suspension of a wrapper for a specific

method execution with the execution of immediate

rules in response to before and after events.

JavaSpaces has been used to implement the

synchronization process. A take operation provides

a way to remove an object from the JavaSpaces

persistent store. The take operation is a blocking

operation that will wait until an object matching a

template is found. A ResourceSemaphore with a

Rule Manager

Metadata Manager

Event Handler

IRules Event

Topic

ISL Interpreter

Object Manager

Black-Box Specific

JMS Topic

Internal Events

Application Transaction

Events

Method Events

IRules Propagated

Internal Events

Application

Transaction

Processor

IRules Environment

External

Events

Enterprise System s

events

Enterprise System s

Specific JMS Topic

IRules W rapper for Black-Box

Component

Black-Box Component

( Session/Entity EJB)

IRules Events

Figure 8: Events in the IRules Environment

AN EVENT PROCESSING SYSTEM FOR RULE-BASED COMPONENT INTEGRATION

317

transaction identifier and a counter initialized to

zero is placed into JavaSpaces at the start of a

transaction. The wrapper generating the before event

must use a take operation to access the

ResourceSemaphore and to create a unique EventId

object. When the ResourceSemaphore object is

retrieved, the counter of the object is incremented

and the modified ResourceSemaphore is written back

to the JavaSpace to prevent unnecessary waiting for

the concurrent execution of multiple methods within

the same transaction. Since the ResourceSemaphore

object is unique for each transaction and method

within a transaction, deadlock cannot occur.

The EventId object is used as the synchronization

object for the suspension and release of the wrapper

execution. The EventId is packaged along with an

EventMsg and sent to the IRules Event Topic. The

event handler detects the event and propagates the

information to the rule processor. The rule processor

executes the immediate rules for the particular

event. When the rule execution is completed, the

rule processor notifies the wrapper that it can

continue by writing the EventId back into the

JavaSpace. The wrapper, which has been waiting

during the rule execution by executing a take

operation on the EventId, succeeds in retrieving the

EventId and returns from the blocking operation. The

synchronization process for after events is similar to

before event processing, with the full details of the

algorithm in (Kambhampati, 2003).

We have tested the event service and rule

execution modules using the synchronization

process for the investment example. We have also

evaluated the performance of event detection for the

four different types of IRules events. Detection time

for application transaction and method events is

measured as the duration from event occurrence to

the time that the rule manager receives the event.

Method event detection is more time consuming

than application transaction event detection. Both

types of event detection must query the metadata to

determine the need to generate before and after

events. Metadata access from component wrappers,

which are also implemented as EJB components, is

more time consuming than Java method calls to the

metadata in the detection of application transaction

events. The detection of internal and external events

is measured differently from that of method and

transaction events. The detection time of internal

and external events is the duration required to wrap

an event and push the event to the rule manager once

the event handler gets events from JMS. The

detection of internal and external events varies

according to the data type of the message. Detection

for the map type, for example, is slower than the

stream data type.

6 RELATED WORK

Several event processing/distributed rule systems are

related to our research. In (Carzaniga, 2001), the

authors describe a general-purpose, Internet-scale

notification service called SIENA. Unlike SIENA,

the IRules project concentrates on integration of

transactional context along with events to develop

distributed applications. JEDI (Cugola et al., 2001)

supports an object-oriented infrastructure for the

development and operation of event-based systems,

also based on active rules. IRules differs from JEDI

by coordinating the generated events with

application transactions, thus allowing for seamless

integration instead of intermixing reactions to events

with application logic.

In (Collett et al., 1998), the authors introduce

dimensions to characterize event definition,

detection, production, and notification for event

services in active database systems, where the

producers and consumers communicate via the

CORBA push and pull protocols. There is no

mention of a rule execution service for active rules

as in the work presented in this paper.

In (Liebzig et al., 2000), the authors present a

CORBA-based transaction and notification service

TS as part of a larger project for unbundling the

concepts of active object systems. In (Cilia et al.,

2001), the authors propose an architecture to move

active functionality from centralized to open

distributed heterogeneous environments using the

results of X

TS to allow for different coupling

modes. Unlike IRules, X

TS requires event-

consuming active objects to pre-register as a group

with the triggering transaction so that a call-back

mechanism can be invoked by consumers to release

the event producer in support of an immediate

coupling mode. The authors state the desire to

explore a declarative means to introduce the concept

of active objects into the CORBA object model.

The research in (Benatallah et al., 2002) has

developed an approach known as SELF-SERV

(composing wEb accessible information & business

sERVices) for declarative composition of dynamic

web services in a peer-to-peer architecture. ECA

rules are used in SELF-SERV to control state

transitions. In IRules, integration rules play a more

direct role in the design of the application

integration logic.

7 SUMMARY

This paper has presented an original approach to

enhancing black-box components with the

specification and generation of events, including a

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

318

synchronization algorithm for coordinating method

execution with the nested execution of integration

rules. In addition to the implementation of the event

processing system, we have implemented a query

processor for IRules based on the monoid algebra of

(Fegaras and Maier, 1995), and a rule processor that

uses the flexible transaction model for the nested

execution of rules (Jin et al., 2002). Full

development of compensating transactions for

dealing with failure in the rule execution process is

an area for future research. Other directions for

future research include extending the environment to

include different component models, different

messaging services, and composite events. We have

already developed a prototype implementation of the

IRules environment using Web Services (WSA,

2002) together with the synchronization algorithm

described in this paper. We are also redesigning the

environment for use with Grid services (Foster,

2002).

REFERENCES

Benatallah, B, Dumas, M., Sheng, Q., and Ngu, A., 2002.

Declarative Composition and Peer-to-Peer

Provisioning of Dynamic Web Services, Proc. of the

Inl. Conf. on Data Eng., San Jose, CA, 297-308.

BPEL4WS, 2002. Business Process Execution Language

for Web Services. Version 1.0.

http://www-

106.ibm.com/developerworks/webservices/library/ws-

bpel/

Carzaniga, A., Rosenblum, D S., and Wolf, A L., 2001.

Design and Evaluation of Wide-Area Event

Notification Service. ACM Trans. on Computer Sys.

19(3), 332 -383.

Cattell, R. and Barry D., 2000. The Object Database

Standard: ODMG 3.0, Morgan Kaufmann.

Cilia, M., Bornhovd, C., and Buchmann, A.. 2001.

Moving Active Functionality from Centralized to

Open Distributed Heterogeneous Environments. Proc.

of the 6

Int. Conf. on Cooperative Information Sys.,

2172 LNCS. Springer.

Collet, C., Vargas-Solar, G., and Grazziotin-Ribeiro, H.,

1998. Towards a Semantic Event Service for

Distributed Active Database Applications. DEXA,

LNCS 1460.

COM/DCOM, 2003. COM/DCOM Specification.

http://www.microsoft.com/com/resources/comdocs.as

Cugola, G., Nitto, E., and Fuggetta, A., 2001. The JEDI

Event-Based Infrastructure and Its Application to the

Development of the OPSS WFMS. IEEE Trans. on

Software Eng., 27, 827-850.

Dietrich, S W., Urban, S D., Sundermier, A., Na, Y., Jin,

Y., and Kambhampati, S., 2001. A Language and

Framework for Supporting an Active Approach to

Component-Based Software Integration. Informatica

25,4 443-454.

DeJong, M., and Laird, C., 2003. TCL+Java = A match

made for scripting.

http://www.tcl.tk/software/java/java.html

EJB, 2001. Enterprise JavaBeans Specification 2.0.

Proposed Final Draft 2.

Fegaras, L., and Maier, D., 1995. Towards an Effective

Calculus for Object Query Languages. ACM SIGMOD

Int. Conf. on Mgmt. of Data, San Jose CA, 47-58.

Foster, I, Kesselman, C., Nick, J., and Tuecke, S. “The

Physiology of the Grid: An Open Grid Services

Architecture for Distributed Systems Integration”,

http://www.globus.org/research/papers/ogsa.pdf

, 2002.

Freeman, E., Hupfer, S., and Arnold, K., 1999. JavaSpace:

Principles, Patterns, and Practice. Addison-Wesley.

JMS, 1999. Java Messaging Service 1.0.2.

http://java.sun.com/products/jms/docs.html

J2EE, 2003. Java TM 2 Platform, Enterprise Edition

(J2EE).

http://java.sun.com/j2ee/

Jin, Y., Urban, S D., Sundermier, A., and Dietrich, S W.,

2002. An Execution and Transaction Model for

Active, Rule-Based Component Integration

Middleware. Proc. of the Eng. and Deployment of

Cooperative Info. Sys.

Kambhampati, S., 2003. An Event Service for a Rule-

Based Approach to Component Integration, M.S,

Thesis, Dept. of Computer Sci. and Eng., Arizona

State University.

Liebig, C., Malva, M., and Buchmann, A., 2000.

Integrating Notifications and Transactions: Concepts

and X2TS Prototype. Proc. of 2

Int. Workshop on

Eng. Distributed Objects.

OMG, 1998. Object Management Group: The common

Object Request Broker, Architecture and

Specification, (December 1998).

Ousterhout, J., 1994. TCL and the TK Toolkit. Addison-

Wesley Publishing.

Patil, R., 2003. The Development of a Framework

Supporting an Active Approach to Component-Based

Software Integration, Arizona State University, Dept.

of Comp. Sci. and Eng., Spring 2003.

Rumbaugh, J., 1987. Relations as Semantic Constructs in

an Object-Oriented Language. Proc. of OOPSLA, 446-

481.

Urban, S D., Dietrich, S W., Na, Y., Jin, Y., Sundermier,

A., and Saxena, A., 2001. The IRules Project: Using

Active Rules for the Integration of Distributed

Software Components. Proc. of the 9

IFIP 2.6

Working Conf. on Database Semantics: Semantic

Issues in E-commerce Sys. Hong Kong, 265-286.

WSA 2002. Web Services Activity,

http://www.w3.org/2002/ws

Widom, J., and Ceri, S., 1996. Active Database Systems.

Morgan Kaufmann publishers, San Francisco CA.

AN EVENT PROCESSING SYSTEM FOR RULE-BASED COMPONENT INTEGRATION

319
