SEMANTIC E-LEARNING AGENTS

Supporting E-Learning By Semantic Web and Agents Technologies

Jürgen Dunkel, Ralf Bruns

Department of Computer Science, University of Applied Sciences and Arts Hannover,

Ricklinger Stadtweg 120, D-30459 Hannover, Germany

Sascha Ossowski

AI Group, E.S.C.E.T.,Universidad Rey Juan Carlos Madrid,

Campus de Mostoles, Calle Tulipan s/n, E-28933 Madrid, Spain

Keywords: Semantic Web, Ontology, Software Agents, E-learning

Abstract: E-learning is starting to play a major role in th

e learning and teaching activities at institutions of higher

education worldwide. The students perform significant parts of their study activities decentralized and

access the necessary information sources via the Internet. Several tools have been developed

providing basic infrastructures that enable individual and collaborative work in a location-independent and

time-independent fashion. Still, systems that adequately provide personalized and permanent support for

using these tools are still to come.

This paper reports on the advances of the Semantic E-learning Agent (SEA) project, whose objective is to

develop virtual student advisors, that render support to university students in order to successfully organize

und perform their studies. The E-learning agents are developed with novel concepts of the Semantic Web

and agents technology. The key concept is the semantic modeling of the E-learning domain by means of

XML-based applied ontology languages such as DAML+OIL and OWL. Software agents apply ontological

and domain knowledge in order to assist human users in their decision making processes. For this task, the

inference engine JESS is applied in conjunction with the agent framework JADE.

1 INTRODUCTION

E-learning has established itself as a significant part

of learning and teaching at institutions of higher

education worldwide. The students perform

significant parts of their study activities

decentralized and access the necessary information

sources via the Internet. The emerged individual

means of work are location-independent and time-

independent, consequently requiring a permanent

available and direct support that can only be

provided by a software system.

The main focus of current E-learning systems is to

provide a

n appropriate technical infrastructure for

the information exchange between all user groups

involved in the E-learning process. A recent

comparison of modern E-learning environments

(CCTT, 2002) revealed, that intelligent advisory

agents are not applied so far in E-learning systems.

However, the necessity of an intelligent support is

unquestioned due to the individual and decentralized

means of study (Cuena et al., 1999, Ossowski et al.

2002).

The objective of the semantic E-learning agent

oject is to develop virtual student advisors, that

render support to university students, assisting them

to successfully organize und perform their studies.

These advisors are to behave both reactive and

proactive: setting out from a knowledge base

consisting of E-learning and user ontologies, their

recommendations must be tailored to the personal

needs of a particular student. For example, they

should be able to answer questions regarding the

regulations of study (e.g.: does a student possess all

requirements to participate in an examination or a

course?, is a student allowed to register for his/her

271

Dunkel J., Bruns R. and Ossowski S. (2004).

SEMANTIC E-LEARNING AGENTS - Supporting E-Learning By Semantic Web and Agents Technologies.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 271-278

DOI: 10.5220/0002613602710278

 SciTePress

thesis?, etc). In addition, advisors should be capable

of announcing new opportunities for students that

are looking for suitable practical training jobs or

thesis subjects.

To achieve these goals, we propose a software

architecture (Dunkel et al., 2003) where virtual

student advisors are developed with novel concepts

from Semantic Web (Berners-Lee et al., 2001) and

Intelligent Agent (Wooldbridge et al. 1995)

technology. The basic idea is to model the structure

of our E-learning domain by means of ontologies,

and to represent it by means of XML-based applied

ontology languages such as DAML+OIL and OWL.

Due to the standardization of these technologies,

knowledge models can easily be shared und reused

via the Internet. Software agents apply the

knowledge represented in the ontologies during their

intelligent decision making process. Again, the use

of widespread inference engines, such as JESS

(Friedman-Hill, 2000a), and of agent frameworks

that comply with the FIPA standard (FIPA, 2003) as

JADE (Bellifemine et al., 2002), which facilitates

maintenance and fosters interoperability with our

system. We claim that this is quite a promising

approach because − although first concrete practical

application scenarios with Semantic Web

technologies have been published, e.g. (Horrocks et

al. 2002) − E-learning systems that successfully

combine these techniques in order to render support

to users are still to come.

This paper reports on the lessons learnt from the

construction of a real-world application in the E-

learning domain that draws upon an effective

integration of both, Semantic Web and Intelligent

Agent technology. It is organized as follows: In the

next section the employed knowledge representation

techniques and the developed knowledge models are

presented in detail. The third section shows how

automated inference can be carried out on base of

the knowledge models, and how agents can provide

reasoning capabilities using this ontology. In the

following section the software architecture of the

agent system is outlined. Finally, the last section

summarizes the most significant features of the

project and provides a brief outlook to the direction

of future research.

2 ONTOLOGIES

The key concept of a semantic advisory system for

university students is the semantic modeling of the

E-learning domain knowledge (e.g. university

regulations, course descriptions, admission

regulations) as well as an individual user model,

which reflects the current situation of study (e.g.

passed exams, current courses). In these models the

fundamental structures of the available domain

knowledge as well as the basic facts (e.g. offered

courses) are defined.

In our system, the structural part of this E-

learning knowledge is modeled by means of

ontologies which formally define domain entities

and the relations among them. For this purpose, we

use Semantic Web technology based on XML and

RDF/ RDF Schema (WWW-RDF, 2003),

respectively. Software agents use this information as

the basis for their reasoning and, due to the

standardization of these technologies, they are able

to access distributed information sources from

different universities. Thus the developed ontologies

can serve as standardized and open interfaces for the

interoperability of E-learning systems.

The ontology language DAML+OIL is an attempt

to address the shortcomings of the RDF/ RDF

Schema specification by incorporating additional

features (DAML, 2003). DAML+OIL includes

support for classification, property restriction and

facilities for type definitions. In the last years,

ontology languages have converged to the new W3C

standard OWL (Web Ontology Language) (WWW-

OWL, 2003), which is currently under development.

In a first step, we have chosen the DAML+OIL

language to model the E-learning knowledge. The

main reason was the availability of different tools

for the development of the knowledge base. As soon

as possible, the knowledge base will be migrated to

the new W3C standard language OWL.

Two different ontologies have been developed for

our E-learning agents: on the one hand, an ontology

describing the organization structure of a university

department, on the other hand, an ontology holding

the knowledge about a specific user of the system.

2.1 Department Ontology

The department ontology models the essential parts

of the organizational structure of a university. The

emphasis lies on the individual departments, the

different roles of persons in a department and the

courses.

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

272

Figure 1: Department Ontology – person branch

It is modeled as follows. Every organizational unit is

defined as a subclass of organization. For this super

class a transitive property is defined, thus a

hierarchy of instances can easily be modeled. In

DAML this transitivity is modeled as follows:

<daml:TransitiveProperty

rdf:ID="subOrg">

<rdfs:label>subOrg of</rdfs:label>

<rdfs:domain

rdf:resource="#Organization"/>

<rdfs:range

rdf:resource="#Organization"/>

</daml:TransitiveProperty>

The transitivity is used in the instance files to model

a concrete hierarchy. For example, a student project

is a sub-organization of a department and the

computer science department is a sub-organization

of the university FH Hannover.

<fbi:department rdf:ID="CS">

<fbi:subOrg>

<fbi:FH rdf:about="#FHHannover"/>

</fbi:subOrg>

</fbi:department>

<fbi:project rdf:ID="Project1">

<fbi:subOrg>

<fbi:department

rdf:about="#CS"/>

</fbi:subOrg>

</fbi:project>

All further parts of the ontology belong to an

organization. This is modeled by the property

<daml:ObjectProperty

rdf:ID=”isPartOf”/>

, which is restricted to a

concrete subclass of organization.

The part of the ontology that models a person is

shown in figure 1. The semantic of inheritance in

this taxonomy is slightly different compared to

object-oriented programming. In object-oriented

programming it expresses a specialization of an “is-

a”-relation, while in the context of ontologies, it

serves mainly as a categorization of knowledge.

For the sake of clarity, the graphical

representation does not show all information of the

relations. In particular, is not shown which class or

property of another branch of the ontology is

referred to. One example is the property

offersCourse of the class Lecturer. In the XML

notation it is defined as follows:

<daml:ObjectProperty

rdf:ID="offersCourse">

<rdfs:label> offers course

</rdfs:label>

<rdfs:domain

rdf:resource="#Lecturer"/>

<rdfs:range

rdf:resource="#Course"/>

<daml:minCardinality>1

</daml:minCardinality>

</daml:ObjectProperty>

A lecturer teaches one or more courses and it is

possible to navigate from a lecturer to a specific

Person

Student

Employ

Lecturer

Research

Assist.

Stud.Asssist

Techical

ExtLect Profs

Stu

-ID

Pers-No

Office

Semeste

assedExa

offersCourse

isAuthorOf

Name

Literal

ektPro

ert

Class

ObjectProperty

subClassOf

Legend

SEMANTIC E-LEARNING AGENTS - SUPPORTING ELEARNING BY SEMANTIC WEB AND AGENTs

TECHNOLOGIES

273

Figure 2: Department Ontology – course branch

Course

Exercise

Lecture

hasDate

hasRoom

Exam

hasLecturer

Participants

has Document

name

course. In the course branch of the ontology one can

find a property

hasLecturer with a similar

semantics with inverse direction of navigation. This

can be defined as an inverse property in DAML.

<daml:ObjectProperty

rdf:ID="hasLecturer">

<daml:label>is offered by

</daml:label>

<daml:inverseOf

rdf:resource="#offersCourse"/>

</daml:ObjectProperty>

Figure 2 displays the course branch of the E-learning

ontology. Not visualized by the graphical notation

are further characteristics of subclasses. For example

a course is a disjunctive union of its subclasses. In

DAML this is modeled as follows.

<daml:Class

rdf:about="#Course">

<daml:disjointUnionOf rdf:parseType=

"http://www.daml.org/2001/

03/daml+oil#collection">

<daml:Class rdf:about="#Lecture"/>

<daml:Class rdf:about="#Exercise"/>

<daml:Class rdf:about="#Exam"/>

</daml:disjointUnionOf>

</daml:Class>

This construct ensures that a course is either a

lecture, an exercise or an examination.

2.2 User Ontology

The user ontology serves as the knowledge model of

a specific user, e.g. a student or a faculty member.

The core class of the ontology is

User. A user is a

person with respect to the department ontology. This

is modeled by the object property

sameClassAs,

which is the DAML element to model inter-

ontological equivalence.

<daml:Class rdf:about=“#User“>

<daml:sameClassAs rdf:resource=

"http://localhost:8080/Agents/

FB_Onto.daml#Person"/>

</daml:Class>

The additional properties model all relevant data of a

person, e.g. login name, student ID, current

semester, passed/failed courses, last login date, skills

etc.

3 AGENTS AND INFERENCE

The semantic E-learning agents should act like a

human advisor according to the knowledge modeled

in the ontology. This is achieved by using a rule-

based inference engine to carry out the automated

inferences entailed by the semantics of DAML.

3.1 Inference

To provide the semantic E-learning agents with

reasoning capabilities, the rule-based Expert System

Shell JESS (Java Expert System Shell) (Friedmann-

Hill, 2000] is employed. JESS was initially

developed as a Java version of CLIPS (C Language

Integrated Productions System) and provides a

convenient way to integrate reasoning capabilities

into Java programs. With the JESS language

complex rules, facts and queries can be specified.

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

274

3.2 Ontology Reasoning

To make use of the knowledge modeled in the

ontology, the DAML semantics must be mapped

into facts and rules of a production system, like

JESS.

Because JESS does not provide any interface to

import a DAML ontology in its knowledge base, we

choose DAMLJessKB (Kopena et al., 2003), a

reasoning tool for DAML that uses JESS as

inference engine. In some more detail

DAMLJessKB processes the following steps.

First DAMLJessKB loads and parses RDF docu-

ments using the RDF-Parser ARP of the Jena toolkit

(Hewlett Packard Labs, 2003). ARP generates RDF

triples. DAMLJessKB reorders the triples from

subject-predicate-object form into predicate-subject-

object form. Each RDF triple represents an

unordered fact in JESS.

To assert triples in JESS minor transformations

are necessary. DAMLJessKB translates URIs

(Uniform Resource Identifiers) into JESS symbols

by removing invalid characters (e.g. ~), and inserts

the dummy predicate

PropertyValue in front of

each triple. The following example shows a

generated fact for JESS, which means, that

Professor is a subclass of Lecturer.

(PropertyValue

http://www.w3.org/2000/01/rdf-

schema#subClassOf

file:///C:/FB_Onto.daml#Professor

file:///C:/FB_Onto.daml#Lecturer )

Because in our DAML ontology

Lecturer is

defined as a subclass of P

erson, it follows that

Professor is also a subclass of Person.

To support reasoning, DAMLJessKB includes

some built-in rules of the DAML semantics, which

are asserted into JESS, e.g. that an instance of a

subclass is also an instance of the super class:

(defrule subclassInstances

(PropertyValue daml:subClassOf

?child ?parent)

(PropertyValue rdf:type

?instance ?child)

(assert

(PropertyValue rdf:type

?instance ?parent)

)

The semantics of a JESS rule is similar to an if-then-

statement in a programming language. Whenever the

if part (the left-hand-side) which consists of several

patterns is satisfied, the rule is executed, i.e. in our

example a new fact is asserted into JESS. Details

about the JESS language can be found in (Friedman-

Hill, 2000).

Beside the DAML rules, which are directly

supplied by DAMLJessKB, it is necessary to

develop own domain-specific rules to model the

complete expert knowledge. These rules make it

possible to cope with complex queries related to a

domain.

First, all facts are produced; then, the DAML

rules are added; and finally the domain-specific rules

are asserted into JESS. The reasoning process is

performed by JESS applying all rules to deduce new

facts which are successively added to the knowledge

base.

DAMLJessKB can be considered as an interface

to JESS, which is capable of translating DAML

documents in accordance with their formal

semantics. We are aware of several other tools with

similar functionality, for example DAML API

(DAML API, 2003), or the SWI Prolog distribution

(SWI-Prolog 2003), which includes a package to

parse RDF and assert as Prolog facts, but none of

them fully meet the integration requirements of our

E-learning system

3.3 Agent access to the knowledge

base

In order to cope with their specific tasks, semantic

E-learning agents can pose queries to access the

JESS knowledge base. These queries are special

rules with no right-hand sides. The results of a query

are those facts, which satisfy all patterns. For

example, if a personal agent for a lecturer

tom is

interested in all courses he has to give, it can use the

query:

(defquery getCourses

"find IDs of all my courses"

(declare (variables ?lecturerID)

(PropertyValue lecture:givesCourse

?lectureID ?course)

)

where

lecturerID is the identifier of the lecturer,

which serves as parameter of the query, and

?course is an internal variable. All elements in a

SEMANTIC E-LEARNING AGENTS - SUPPORTING ELEARNING BY SEMANTIC WEB AND AGENTs

TECHNOLOGIES

275

query must be fully qualified with their namespace,

as they are used in the knowledge base. Executing

the query yields all facts that satisfy all patterns

specified in the query. E.g. a fact that fits the query

could be:

(PropertyValue

file://C:/FB_User.daml#givesCourse

file://C:/FB_User.daml#tom

file://C:/FB_Onto.daml#Math1)

In this case the lecturer

tom gives the Math1 course.

The following example shows a more complex

query that yields all documents of a course that are

more recent than a certain time. It has two

parameters: the time

mydate and the identifier of a

course, e.g.

file://C:/FB_Onto.daml#Math1.

(defquery getNewerDocs

(declare (variables ?mydate ?course))

(PropertyValue rdf:type

?course fb:course)

(PropertyValue fb:hasDocument

?course ?doc)

(PropertyValue fb:changeDate

?doc ?doc_modified)

(PropertyValue date:longDate

?doc_modified? long_date)

(PropertyValue rdf:value

?long_date

?doc_date&:(>= ?doc_date ?mydate))

)

The last pattern contains the condition that the last

time the document was modified is greater than

mydate.

4 JADE-AGENTS

In the previous sections we have modeled the

knowledge of the E-learning system in two different

ontologies: the department and the user ontology.

The two knowledge bases are related to different

domain concepts: to a department advisor and to a

specific user. A human advisor and a human user

communicate and exchange information to find a

solution for an individual problem.

To implement a software system reflecting this

situation we chose agent technology. Software

agents provide a direct way to implement

conversations or negotiations. The FIPA

(Foundation of Intelligent Physical Agents)

organization (FIPA, 2003) has defined several

standards for agent communication, e.g. ACL

(Agent Communication Language). Agent

technology provides natural means of

communication and information exchange, which is

on a high abstraction level and independent of

certain technologies, e.g. protocols or inter-process

communication mechanisms.

The semantic E-learning agents are developed

with JADE (Java Agent Development Framework)

(Bellifemine et al., 2002), which complies with the

FIPA standards. JADE is completely written in Java

and includes two main components: a FIPA-

compliant agent platform and a framework to

develop Java agents.

4.1 Agent structure

Figure 3 outlines the structure of the E-Learning

system with two different types of agents: a user and

a department agent.

User Agent

The user agent is implemented in a class

UserAgent and contains the user ontology with all

relevant information about personal data, courses,

skills, etc. When the user agent is started, it reads in

the user ontology with its personal data using

DAMLJessKB. Then the user agent-specific rules

and queries are loaded and asserted in JESS.

void setUP(){

damljesskb = new DAMLJessKB();

damljesskb.loadDAMLResource(

userOntology);

...

loadRules(userRules);

...

Corresponding to each JESS query the agent

includes a dedicated method like

getCourses(),

which execute the query via DAMLJessKB, and

receives an iterator object containing the query

result.

String[] getCourses(){

...

Iterator e = damljesskb.query (

"getCourses", new String[] {""});

Department Agent

The department agent has all knowledge about the

department, e.g. the curriculum and the examination

regulations, which are modeled in its own DAML

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

276

ontology. The corresponding class

Department-

Agent

has a similar structure as UserAgent: In its

setup()-Method DAMLJessKB is used to load the

department ontology, specific rules and the

necessary Jess queries. Each query can be executed

in a corresponding agent method. One example is

getNewerDocs(), which yields all documents

related to a course which are newer than a specified

date.

4.2 Agent Behavior and

Communication

An agent must be able to execute several parallel

tasks in response to different external events. In

JADE all agent tasks are modeled as objects of the

Behavior subclass, which determine the reactions

of an agent: e.g. when it receives a message, and

how it reacts on requests from another agent.

The JADE-method

addBehavior() adds a

behavior to the task queue of a specific agent.

Behaviors a registered in an agent’s

setup()-

method or on response to an user event.

In a round-robin policy a scheduler executes the

action()-method of each behavior in the task

queue. If the

action()-method is finished, the

done()-method is invoked. If it returns true, the

task is removed from the event queue. To model

cyclic tasks

done() returns always false. Details

about behaviors can be found in (Bellifemine et al.,

2002).

For example, the following behaviors are

defined in the E-learning system.

The user and the department agent use the

RegisterAtDF behavior, which registers an agent

with its name and type at the agent platform.

The user agent uses the

UA_SearchDepartment-

Agent

-behavior to ask the name service of the

platform, the Directory Facilitator (DF) for all

department agents, and to establish a connection to

them.

The

UA_SendRequest-behavior requests

information from the department agent. This

behavior object is created by an event on the agent

GUI. According to a parameter

content (e.g.

SEND_DOCUMENTS) the user agent collects the

necessary request parameters, e.g. the courses of a

user, and sends them via an ACL message to the

department agent. Furthermore a command string

(here: DOCUMENTS) is set to specify the request.

void action() {

...

if(content== SEND_DOCUMENTS){

...

parameters.setCourses(

this.getCourses());

...

msg.setContentObject(parameters)

;

msg.setLanguage(DOCUMENTS);

...

}

msg.addReceiver(agent);

myAgent.send(msg);

The UA_ReceiveRequests-behavior waits in

an infinite loop for messages from a department

agent. If a message arrives it is analyzed and the

results are sent to the agent’s GUI.

The department agent uses the

DA_SearchUser-

Agent

-behavior to get all user agents, and to

establish a connection to them.

The

DA_ReceiveRequest-behavior analyzes

arriving messages from user agents. It extracts the

command string and the parameters of the message,

to execute the specified query. Then the query

results are packed into a message and returned to the

corresponding user agent.

User

Agent

Department

Agent

Request/Query-If

Inform/Inform-done

user ontology

rulesss

depart. ontology

ruless

queries

behaviors

Figure 3: Agent structure

SEMANTIC E-LEARNING AGENTS - SUPPORTING ELEARNING BY SEMANTIC WEB AND AGENTs

TECHNOLOGIES

277

5 CONCLUSION

In this paper, we have described the use of Semantic

Web languages and agent technology for building an

intelligent advisory system for E-learning

environments. Our goal is to create and deploy

semantic E-learning agents capable of supporting

university students in successfully organizing and

performing their studies. In the project we have

developed a software architecture, which integrates

Semantic Web and Intelligent Agent technologies.

Due to the use of Semantic Web languages the

developed knowledge models can easily be used in

distributed systems and shared among software

agents via the Internet.

The major difficulty encountered was the

integration of the different concepts – on the one

hand the knowledge base written in RDF and

DAML+OIL, on the other hand the inference engine

JESS and the agent environment JADE. Further

problems emerged from the unsatisfactory tool

support for developing the ontology and the concrete

instances of the ontology. However, after the

mentioned problems were solved we could

implement a prototype system, where the agents

were able to reason upon the knowledge base in the

desired manner. Actually the migration of our

system to the upcoming W3C standard language

OWL is under work.

REFERENCES

Berners-Lee, T., Hendler, J., Lassila, O., 2001. The

Semantic Web. Scientific American.

Bellifemine, F, Giovanni, C., Trucco, T., Rimassa, G.,

2002, JADE Programmers’s Guide,

http://sharon.cs-

elt.it/projects/jade/, retrieved October, 2003.

Dunkel, J. Holitschke, A., Software Architecture (In

German), 2003. Springer Verlag.

Bruns, R., Dunkel, J., von Helden, J., 2003. Secure Smart

Card-Based Access To An eLearning Portal. In

ICEIS’03, 5th International Conference on Enterprise

Information Systems. ICEIS Press.

CCTT - Center for Curriculum, Transfer and Technology,

2002.

http://www.edutools.info/course/compare/all.jsp,

retrieved October, 2003.

Cuena J., Ossowski S., 1999. Distributed Models for

Decision Support. In: Weiß (ed.): Multi-Agent

Systems — A Modern Approach to DAI. MIT Press,

459–504.

DAML-The DARPA Agent Markup Language Home-

page: http://www.daml.org, retrieved October 10,

2003.

DAML API, 2003.

http://codip.grci.com/Tools/Compo-

nents.html, retrieved October, 2003.

Friedman-Hill, E., 2000a. JESS, The rule engine for the

Java platform,.

http://herzberg.ca.sandia.gov/jess/

retrieved October, 2003.

Friedman-Hill, E., 2000b, Jess. The Rete Algorithm,

Sandia National Laboratories,

http://herzberg.ca.sandia.gov/jess/docs/52/rete.html,

retrieved October, 2003.

FIPA - Foundation of Intelligent Physical Agents, 2003.

www.fipa.org, retrieved October, 2003.

Horrocks, I., Hendler, J. (eds.), 2002. The Semantic Web,

First International Semantic Web Conference,

Sardinia, Italy, Springer LNCS 2342.

Hewlett Packard Labs: Jena Semantic Web Toolkit, 2003.

http://www.hpl.hp.vom/semweb, retrieved October,

2003.

Kopena, J. Regli, W., 2003, DAMLJessKB: A Tool for

reasoning with the Semantic Web. IEEE Intelligent

Systems, 18(3).

Ossowski, S., Hernández, J., Iglesias, C.A.; Fernández, A.,

2002. Engineering Agent Systems for Decision

Support. In: Engineering Societies in an Agent World

III (Petta, Tolksdorf & Zambonelli, eds.), Springer-

Verlag.

Ossowski, S., Omicini, A., 2002. Coordination Knowledge

Engineering. Knowledge Engineering Review 17(4),

Cambridge University Press.

SWI-Prolog, 2003.

http://www.swi-prolog.org, retrieved

October, 2003.

WWW – The World Wide Web Consortium, 2003a. RDF

Primer – W3C Working Draft 05 September 2003:

http://www.w3.org/TR/2002/WD-rdf-primer-

20020319/, retrieved October 10, 2003.

WWW – The World Wide Web Consortium, 2003b. OWL

(Web Ontology Language): http://

www.w3.org/TR/-

owl-ref/ , retrieved October 10, 2003.

Wooldridge, M.; Jennings, N., 1995. Intelligent Agents -

Theory and Practice. Knowledge Engineering Review

10 (2), pp. 115–152.

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

278
