Text Processing Techniques in Approaches for Automated
Composition of Domain Models
Viktorija Gribermane
1a
and Erika Nazaruka
2b
1
Institute of Applied Computer Systems, Riga Technical University, 1 Setas St., Riga, Latvia
2
Department of Applied Computer Science, Riga Technical University, 1 Setas St., Riga, Latvia
Keywords: Natural Text Processing, Knowledge Extraction, Unrestricted Language, Domain Model, Software Model.
Abstract: Text processing techniques are critical for automated analysis of domain documentation. Proper domain
analysis may include analysis of a huge number of documents that may describe business procedures, policies,
organizational structures, regulations, etc., as well as minutes of discussions with domain experts. The results
of analysis are also presented as documents with or without supporting graphics, e.g., domain models.
Automated composition of domain models (including software models) should decrease the time necessary
for analysis and would provide traceability to the original documentation. The goal of this research is to
understand how text processing techniques can be applied for composition of those models and what are the
current trends in this field. The result of analysis of 15 approaches showed that Natural Language Processing
features are just the starting point in document processing. The main difficulty is proper analysis of
dependencies among words in sentences and among sentences themselves. The obtained results indicate two
directions in identification of patterns of those dependencies and a complete diversity in their applications.
1 INTRODUCTION
Domain models are simplified representation of one
or many aspects of the real phenomena (e.g., a
system) which are created with a certain purpose.
Composition of the domain models is a
transformation of experts’ knowledge about existing
phenomena into some human understandable form,
e.g., graphical, mathematical, or textual. Usually, this
transformation is a mental work supported by
guidelines that are aimed to make this work more
systematic. However, the development of natural
language processing (NLP) technologies opened an
opportunity to use them for automated composition of
domain models based on textual and graphical-textual
descriptions of phenomena.
The automated composition of domain models is
based on processing verbal descriptions that origin as
a result of discussions with domain experts, tasks
performed, or that are represented by existing
documents. Besides, some knowledge may remain
implicit. Therefore, validation of the composed
domain models by the human expert is also required.
a
https://orcid.org/0000-0002-8368-9362
b
https://orcid.org/0000-0002-1731-989X
There are many research results on text processing
as such, but the aim of this research is to find out what
techniques are used mostly in the context of
system/software domain model composition and their
further use. For this purpose, we have selected and
analyzed 15 research papers published from 2005 till
2020 and stored in IEEE and ACM publication bases.
The main criterion of selection was the use of NLP
features for processing textual descriptions of the
problem domain structures and functionality that has
finished in automated composition of the domain
model. We skipped approaches those of using manual
processing of text or manual composition of the
domain models.
The following sections contain information on
domain model characteristics that could be got from
the verbal descriptions (section 2) and analysis of
research works that uses NLP features at the
beginning of the problem domain analysis (section 3).
Conclusion summarizes main results obtained and
describes validity of the research done.
Gribermane, V. and Nazaruka, E.
Text Processing Techniques in Approaches for Automated Composition of Domain Models.
DOI: 10.5220/0010533904890500
In Proceedings of the 16th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2021), pages 489-500
ISBN: 978-989-758-508-1
Copyright
c
2021 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
489
2 COMPOSITION OF DOMAIN
MODELS
The domain most often is understood as an
application area or a field for which software is
developed (Prieto-Diaz, 1990). Domains can be
narrow like a user authentication or broad like a
business. A domain analysis is a process of
identification of information that can be used for
software development with the purpose of making it
reusable (Prieto-Diaz, 1990). If this information is
available, then it will be faster and more effective for
software engineer to decide whether to reuse
components in the software system and understand
the beginning idea of this designed component.
The goal of the domain analysis in the software
development is to understand and specify the
functional, behavioral and structural characteristics of
a domain AS-IS (the problem domain: today’s reality
with existing business processes, existing objects,
existing functionality, etc.) and/or a domain TO-BE
(the solution domain: requirements to software to be
built, information system planned, new business
processes, modified functionality etc.) as well as
conformity among them if the both domains are
analyzed.
The structural characteristics of the domain can be
modelled as concepts and their intra- and inter-
relationships. The behavioral characteristics of the
domain are expressed as activities, control flows, data
flows and interactions with users or other systems.
The functional characteristics of the domain are
expressed as causal dependencies among activities or
functional parts of the domain, or states of the
software systems and transitions between them.
The domain models can be informal, semi-formal
and formal. In order to use models as a source for
further code generation, the models must be formal
(Miller and Mukerji, 2001), i.e., readable by
machines. Otherwise, only manual, or partially
automated transformation into code is possible.
Composition of the domain model starts from
gathering information. Usually, the obtained
information is specified in the form of unstructured
text (text in a formal writing style) and structured
descriptions (user stories, use case specifications,
scenarios, and other formats). Generally, descriptions
are represented as a large number of documents,
which consist of text with figures, tables, and multiple
links to other documents. In practice, preparation of
text and manual knowledge obtaining are too
resource-consuming (Elstermann and Heuser, 2016).
Therefore, the common case is to avoid the step of
preparation of text or to automate or semi-automate
this process. Certainly, the automated process may
require composition of a “transitional” model that can
be used for organizing the knowledge gathered from
the documentation and its further analysis.
The automated processing of structured text
(especially if a language is controlled) is easier than
processing of unstructured prose (Nazaruka, 2020).
However, structuring the text also requires additional
manual processing of information.
3 USE OF TEXT PROCESSING
TECHNIQUES
Analysis of unstructured (uncontrolled) text requires
not only application of basic NLP features such as
tokenization, part-of-speech (POS) tagging, chunking
and Name Entity Recognition (NER) but also analysis
of dependencies between clauses, in complex noun
phrases, in predicates and in verb phrases as well as
one of the most difficult tasks, namely, discourse
analysis (Nazaruka and Osis, 2018). The process is
getting complicated with particularities of a natural
language (Nazaruka et al., 2019). Thus, quality of the
processing depends on the presence of needed
knowledge, different structures of sentences and
implicit synonyms.
In order to deal with the uncertainty of a natural
language, machine learning or manual pre-processing
of knowledge can be used (Nazaruka, 2019).
Research on NLP techniques used for discovering
causal dependencies in texts in prose showed two
clear trends (Nazaruka, 2019). The first is increasing
the accuracy of the results using ontology banks,
machine learning and statistical inferring. The second
is decreasing the cost of these activities. In case of
construction of software models using machine
learning or statistical inferring, the main challenge is
a lack of corpuses and statistical datasets for potential
problem domains. Nevertheless, this issue can be
potentially solved by limitation of those source
documents to specifications (requirements, scenario,
etc.) having less variability in expressing causality.
The causal dependencies in text may be expressed
implicitly and explicitly. The explicit representation
means are causal links, causative verbs, resultative
constructions, conditionals as well as causative
adverbs, adjectives, and prepositions (Khoo et al.,
2002). Though, the implicit causality usually is
inferred by a reader associating information in the
text with their background knowledge (Khoo et al.,
2002; Ning et al., 2018; Solstad and Bott, 2017).
MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering
490
Theories attempting to reduce causal reasoning to
a domain-general theory can be grouped as
associative theories, logical theories, and
probabilistic theories (Waldmann and Hagmayer,
2013). Logical theories seem to be more suitable to
software development in processing verbally
expressed information, since they model causal
reasoning as a special case of deductive reasoning.
Logical theories frequently analyze conditionals
(if/when…then constructs) in the text. Although
conditionals do not distinguish between causes and
effects. Temporal priorities can be helpful in
distinguishing them (Pearl, 2019; Solstad and Bott,
2017).
3.1 Domain Model Composition
Approaches
The selected 15 approaches published from 2005 till
2020 and available in IEEE and ACM publication
bases are presented here in brief and are
chronologically ordered from the oldest to the more
recent ones.
Ilieva and Ormandjieva’s Approach (Ilieva &
Ormandjieva, 2006) uses plain text descriptions of
software requirements in unlimited natural language
as a source of knowledge for constructing the domain
TO-BE model with the aim to obtain requirements
engineering models such as a Use Case Path model, a
Hybrid Activity diagram model and a domain model.
Tabular presentation and Semantic Networks are used
as transition models. For extraction, the approach
uses POS recognition and semantic analysis of text.
Relative Extraction Methodology (Krishnan &
Samuel, 2010) uses user requirements or problem
statements as a source of knowledge for constructing
the domain TO-BE model and UML Class diagram as
the target model. A dependency graph is used as the
transition model. For the extraction POS recognition
is used with Breadth First Search (BFS) and Depth
First Search (DFS) algorithms for processing the
graph as well as algorithmic structures for concept,
value and action identification and class diagram
generation. The obtained class diagram lacks
advanced relationships like aggregation and
dependency between classes, as well as multiplicities
between the classes.
DAA4BPM. The Description Analysis Approach for
Business Process Management (DAA4BMP)
presented in (Friedrich et al., 2011) uses informal
textual descriptions of processes (the domain AS-IS
model) for Business Process Model and Notation
(BPMN) models creation as a target model. The
approach uses a dependency graph as a transition
model. The approach uses syntax parsing (factored
model of Stanford Parser, action filtering by example
indicators), semantic and flow analysis as well as a
custom anaphora resolution algorithm.
ReDSeeDS. Requirements Driven Software
Development System (ReDSeeDS) introduced in
2010-2012 by the international researchers’ teams
(Kalnins, 2010; Kalnins et al., 2011; Smialek &
Straszak, 2012) uses domain vocabulary (the class
model with links to WordNet entries) and semi-
formal use case specifications in the Requirements
Specification Language (RSL) as a source of
knowledge. Scenarios are written in Controlled
English. The target model is a platform independent
model based on UML profile, which includes static
structures as classes, components, and interfaces. The
behavior is represented as a sequence diagram.
AnModeler. AnModeler is a tool for generating
domain models from textual specifications (Thakur &
Gupta, 2014). Semi-structured use case specifications
with unrestricted plain text are used for composing
UML Class and Sequence diagrams. The approach
employs NLP, sentence structures and transformation
rules.
Nassar and Khamayseh’s Approach (Nassar &
Khamayseh, 2015) targets the construction of activity
diagrams from Arabic user requirements using NLP
tools. User requirements must follow strict writing
rules (formal short statements SVO and VSO “verb-
subject-object”). The approach uses manually
detected tag patterns to generate UML activity
diagrams as the output model. As the result this
approach allows extracting actions, domain objects
without additional details and actors.
IDM. The Integrated Domain Modeling (IDM)
approach uses semi-formal Use Case specifications as
the domain TO-BE model (Slihte, 2015). The
language is restricted since steps should be in the
form of “subject verb object” (SVO). The approach
produces a topological functioning model (TFM) as
the target model, employing NLP features and
ontology bank for this task. The approach allows
determining actions, objects, actors, preconditions,
and causal dependencies.
Domain Model Extractor (Arora et al., 2016) is
capable of extracting UML Class diagrams as a target
model from software requirements given in
unrestricted natural language form. It uses NLP
features and extraction rules. This approach allows
extracting concepts, associations and generalizations,
cardinalities, and attributes.
DAA4BPM v.2. The modified version of the
DAA4BMP (Leopold et al., 2017). Knowledge is
extracted from business process models given in
Text Processing Techniques in Approaches for Automated Composition of Domain Models
491
BPMN or Event-driven Process Chain (EPC)
notations together with corresponding informal
textual descriptions in plain text. Resource
Description Framework (RDF) triplets are used as the
target model. The approach uses syntax parsing
(Stanford Parser) and semantic analysis (Stanford
Parser, WordNet, and predicates).
AGER. The Automated E-R diagram Generation
System (AGER) presented in (Ghosh et al., 2018) can
generate E-R diagrams from plain text. User
statements are given in VSO form. It employs NLP
features to detect entities, attributes and relations.
Kashmira and Sumathipala’s Approach
(Kashmira & Sumathipala, 2018) is targeted at
generation of Entity Relationship (E-R) diagrams
from requirements specification using NLP. The
source model is semi-structured use case
specifications. The approach uses NLP, machine
learning, ontology, and web-mining to achieve its
goals. As the result this approach identifies entities,
attributes, and relationships between entities/sub
entities-attributes, entities-entities (association),
entities-sub entities (generalization), attributes-
attributes, cardinalities (One to One, One to Many,
Many to Many).
Shweta, Sanyal and Ghoshal’s Approach (Shweta
et al., 2018) uses Use Case specifications in a semi-
structured plain text form with keywords specified.
The target model is UML Class diagrams. The
approach uses NLP features and rules for extraction
of classes, attributes, and methods. This approach
allows extracting actions, domain objects and
attributes and relationships between objects without
additional information.
AR2AA. Automated Requirements to Assertions
Analyzer (AR2AA) uses plain text Requirement
specifications as a source of knowledge for
constructing the domain TO-BE model (Anwar et al.,
2020). The target model for the approach is a triplet
<Requirements, Actions, Conditions>. The approach
employs NLP for identification of nouns, verbs and
adjectives, and rules to identify actions and
conditions.
DoMoRe. Domain Modeling Recommender
(DoMoRe) introduced in (Agt-Rickauer, 2020) is
author’s own implementation of the DoMoRe system
that “generates context-sensitive modeling
suggestions using SemNet Nad OntoConnector”. The
approach uses a large text corpus in plain text as input
and Semantic Term Network as the target model. N-
Grams constructs are used as an intermediate model.
It employs Stanford NLP toolkit, syntactic POS
patterns for 5-Grams, and statistics of term
occurrence.
Mirończuk’s Approach or Fire Report Analysis
(Mirończuk, 2020) uses fire service reports as a
source that is the combination of structured data and
unrestricted text. The target model is a database with
structured data as the records in it. The author
employed classification by using supervised machine
learning, creation of terms DB, manually created
taxonomy, and extraction rules based on manually
created patterns. As the result the author extracts
concept values from text using predefined extraction
patterns.
3.2 Characteristics to Compare
In order to determine what of these techniques and
principles are used for composition of domain models
which should be applied for software development
the following characteristics are analyzed:
Source model is a description of a domain,
which is used as a source of knowledge about
the domain’s characteristics at the very
beginning of analysis. It can be considered
from two viewpoints:
o Domain AS-IS model represents the
problem domain that describes existing
processes in the domain,
o Domain TO-BE model represents the
solution domain that that describes
demanding processes as system or
software requirements and improvements.
Mapping indicates whether an approach has a
support of providing formal conformity
between domains AS-IS and TO-BE.
Source model type indicates in which form of
specification a source model is presented.
Source model format indicates in which
format (e.g., plain text, formatted text,
hyperlink text, PDF, WORD, etc.) of
specification a source model is presented.
Target model represents the target
specifications after knowledge extraction and
transformation.
Transition model is the transitional
knowledge representation (specification)
during transformation to the target model.
Knowledge extraction techniques are
methods or approaches used for getting
knowledge from the source model.
Techniques for extraction of relationships
between elements are methods or approaches
used for discovering relationships between
elements of the source model.
MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering
492
Declarative knowledge extraction indicates
whether an approach analyzes the structural
characteristics of the domain.
Procedural knowledge extraction indicates
whether an approach analyzes the functional
and behavioral characteristics of the domain.
Synonym processing indicates whether an
approach processes anaphors, synonyms, and
homonyms.
3.3 Comparison of Approaches
Domains and Mappings Between Them. Most of
the 15 approaches are focused on analysis of
specifications of the required solution, i.e.,
composing the model of the domain TO BE. Three
of them DAA4BPM (Friedrich et al., 2011), its
modification DAA4BPM v.2 (Leopold et al., 2017)
and the Fire Report Analysis are dedicated for the
domain AS IS analysis and do not consider the
domain TO BE at all. The DoMoRe approach is a
universal and can be applied for analysis of both the
domains. Therefore, none of these approaches
provides conformity between models of the domains
just because none of them considers both domains.
Source Model Formats. Most of the considered
approaches proceed the source documents in the plain
text format (Table 1). Just two exceptions are
presented, namely, the ReDSeeDS where hyperlinks
are also acceptable and the DAA4BPM v.2 where the
text is an informal textual description of processes
that supplements BPMN (Business Process Model
and Notation) or EPC (Event Process Chain)
diagrams.
Source documents in approaches that analyze the
domain AS IS – the DAA4BPM, its modification
DAA4BPM v.2 and the Fire Report Analysis are
textual descriptions of processes such as policies,
reports, forms, manuals, e-mail messages, etc.
Reports may combine structured and unstructured
data and text in the unrestricted language.
Source Model Types. Source documents on the
domain TO BE are requirement specifications of
different types: unstructured text and semi- or
completely structured text in the form of use cases
like in the IDM approach, AnModeler, and
ReDSeeDS as well as domain vocabularies with
hyperlinks to the ontology bank entries in the
ReDSeeDS.
Table 1: Source documents type and format. Denotation: SVO – subject verb object, VSO – verb subject object.
Approaches Source model type Source model
format
Ilieva and Ormandjieva SR descriptions Plain text
Relative Extraction
Methodology
A large collection of sentences Plain text
DAA4BPM Informal textual descriptions:
policies, reports, forms, manuals, e-mail messages etc.
Plain text
ReDSeeDS Semi-formal equivalent of the domain class model with
links to WordNet entries, use cases for scenarios in
controlled language
Plain text with
hyperlinks
Nassar and Khamayseh Formal short statements SVO, VSO Plain text
IDM Use case specifications with steps in the form of SVO Plain text
Domain Model Extractor Unrestricted NL requirements Plain text
AnModeler Semi-structure unrestricted software requirement
specification
Plain text
DAA4BPM v.2 BPMN or EPC diagram and its informal textual description Plain text and
BPMN / EPC
AGER User statements SVO Plain text
Kashmira and Sumathipala Requirement specifications Plain text
Shweta, Sanyal and
Ghoshal
Semi-structured software requirement specification with
keywords
Plain text
AR2AA Textual Design Requirements Plain text
DoMoRe A large text corpus Plain text
Mirończuk (Fire Report
Analysis)
The combinations of structured data and unrestricted text Plain text
Text Processing Techniques in Approaches for Automated Composition of Domain Models
493
Target Models. The target domain models are also
quite diverse (Table 2) and can be grouped to UML
or UML like models presented in 7 approaches, E-R
diagrams presented in 2 approaches, BPMN models
(just in one approach), Topological Functioning
Models (in one approach) and others in 4 approaches.
Transitional Models. The transition models are
required in 4 approaches Ilieva and Ormandjieva’s
approach, Relative Extraction Methodology,
DAA4BPM, DoMoRe mainly for analysis of the
semantical relationships between concepts (Table 2).
Knowledge Extracting Techniques. Let us look at
the knowledge extracting techniques used in the
provided approaches (Table 3). The first step in the
most approaches is parsing of sentences using
standards NLP techniques. Thus, tokenization,
chunking, POS recognition and dependencies
identification are applied. The exception is
ReDSeeDS that uses Keyword Based Analysis for the
domain TO-BE model (RSL) since the language of
the source model is Controlled English.
After syntax analysis, the semantic analysis is
performed using dependencies between word pairs in
the parsed sentences. In most of the approaches these
dependencies are described in the form of lexical
syntactical patterns. Their implementation differs in
the approaches:
Algorithmic structure for processing
dependency graph as in the Relative Extraction
Methodology as well as BFS and DFS
traversals;
Semantic analysis algorithm that uses
ontologies and some predefined lists of
“keywords”:
o FrameNet and WordNet, lists of order
indicators such as ConditionIndicators,
ParallelIndicators, ExceptionIndicators,
SequenceIndicators, as well as anaphora
resolution algorithm in the DAA4BPM;
o WordNet in the ReDSeeDS for domain
vocabulary and in the Kashmira and
Sumathipala’s approach, as well as
together with predicates in the
DAA4BPM v.2;
Rules for detecting and extracting separate
elements: in the “Domain Model Extractor”
AnModeler, AGER (for entities, attributes, and
relations), Shweta Sanyal and Ghoshal’s
approach (for classes, attributes, relations, and
methods), AR2AA (for actions and
conditions), and Fire Report Analysis (for
values for terms used in the database).
Table 2: Target model and transition model representation.
Approaches Target model Transition model
Ilieva and Ormandjieva Use Case Path model,
Hybrid Activity Diagram model,
Domain model
Tabular
presentation,
Semantic Network
Relative Extraction Methodology UML class diagram Dependency graph
DAA4BPM BPMN model World Model
ReDSeeDS PIM model based on UML profile:
-Static structure as classes, components, and
interfaces,
-Draft behavior as sequence diagram.
N/U
Nassar and Khamayseh UML Activity diagram N/U
IDM TFM N/U
Domain Model Extractor UML class diagram N/U
AnModeler UML class diagram, UML sequence diagram N/U
DAA4BPM v.2 RDF triplets N/U
AGER E-R Diagram N/U
Kashmira and Sumathipala E-R Diagram N/U
Shweta, Sanyal and Ghoshal UML class diagram N/U
AR2AA Triplet <R, A, C> N/U
DoMoRe Semantic Term Network N-Grams constructs
Mirończuk (Fire Report Analysis) Database record with structured data N/U
* Donotation used: N/U – not used; TFM – Topological Functioning Model; UML – Unified Modeling Language; BPMN –
B
usiness Process Modeling and Notation; PIM – Platform Independent Model; E-R – Entity Relationships; R –
r
equirements; A – actions; C – conditions; RDF – Resource Description Framework.
MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering
494
Classification of sentences according to the
lexical syntactical patterns can be performed either
manually as it is done in most of the approaches, or
by using machine learning as in the Kashmira and
Sumathipala’s approach and the Fire Report Analysis.
Techniques for Extraction of Relationships. The
extraction of relationships implements the part of the
techniques discussed above and is quite diverse in the
approaches.
The triads, heuristics and mappings are used
sequentially in the Ilieva and Ormandjieva’s
approach for automated extraction of relationships
between elements:
from text to tabular presentation using POS
tagger and their own labeling;
from tabular presentation to semantic network
using relations (triads) and heuristic;
from semantic network to three target models
using mappings between semantic network and
models.
The analysis of dependencies in the dependency
graph is used in the Relative Extraction Methodology:
from text to dependency graph using BFS
traversal on the syntactic tree for concept and
value identification and DFS traversal on the
Verb Phrase (VP) sub-tree of the syntactic tree
for action identification;
from the dependency graph to UML class
diagram using BFS traversal on the
dependency graph by searching a link between
concept and its corresponding elements (value
and action) for identification of classes with
their attributes and methods.
The syntax parsing and semantic analysis are
applied in the DAA4BPM (Friedrich et al., 2011) in
the following way:
Syntax parsing applies the factored model of
Stanford Parser as well as action filtering by
example indicators;
Semantic analysis investigates meanings of
words and phrases (synonyms, homonyms,
etc.) searching the ontologies FrameNet and
WordNet as well as lists of indicators of
conditions (ConditionIndicators), parallel
execution (ParallelIndicators), possible
exceptions (ExceptionIndicators), and the
sequential order (SequenceIndicators);
Table 3: Knowledge Extraction Techniques.
Approaches Knowledge extraction techniques
Ilieva and Ormandjieva NLP(POS), Semantic analysis of text
Relative Extraction
Methodology
NLP(POS), BFS traversal, DFS traversal, algorithmic structures for
processing the dependency graph
DAA4BPM NLP: Syntax parsing (factored model of Stanford Parser, action filtering by
example indicators), Semantic analysis (FrameNet and WordNet; lists of
indicators ConditionIndicators, ParallelIndicators, ExceptionIndicators,
SequenceIndicators), authors’ original anaphora resolution algorithm
ReDSeeDS Keyword Based Analysis for RSL; WordNet for domain vocabulary;
Nassar and Khamayseh Manually detected tags patterns
IDM NLP, ontology bank
Domain Model Extractor NLP, extraction rules
AnModeler NLP, sentence structure and transformation rules
DAA4BPM v.2 NLP: Syntax parsing (Stanford Parser), Semantic analysis (Stanford Parser,
WordNet, and predicates)
AGER NLP, Detection rules for Entities, Attributes and Relations
Kashmira and Sumathipala NLP, machine learning, ontology, and web-mining
Shweta, Sanyal and Ghoshal NLP, rules for extraction of classes, attributes, relation, and operations
AR2AA NLP; Identification of Noun, Verb and Adjectives; Rules to identify Actions
and Conditions
DoMoRe Stanford NLP toolkit, Syntactic POS patterns for 5-Grams; Statistics of term
occurrence
Mirończuk (Fire Report
Analysis)
Classification by using supervised machine learning; creation of terms of the
database; Manually created taxonomy; Extraction rules based on manually
created patterns
Text Processing Techniques in Approaches for Automated Composition of Domain Models
495
Anaphora resolution algorithm, i.e.,
identification of a grammatical substitute (such
as pronouns “we”, “he”, it”, certain articles
“this”, “that” or a pro-verb) to refer to the
denotation of a preceding word or group of
words.
In the ReDSeeDS project (Kalnins, 2010; Kalnins
et al., 2011; Smialek and Straszak, 2012) the authors
use analysis of basic dependencies between words
and keywords as well as synsets analysis by using
ontology WordNet. The analysis is done in the step of
transforming the model of the domain TO BE – RSL-
into the platform independent one:
each step of a use case in the Subject-Verb-
Object (SVO) format;
analysis of the SVO sentence type;
analysis of keywords in SVO sentences;
lexicographic term matching;
WordNet-based similarity measures for
comparing synsets (groups of synonyms that
express the same concept).
The analysis of the SVO sentence type determines
the direction of behavior described in the sentence by
using the following rules:
Actor system sentence. An actor is the
subject, and a system is the recipient of the
SVO sentence;
System actor sentence. A system is the
subject, and an actor is the recipient of the SVO
sentence;
System – system sentence. A system is the
subject and the recipient of the SVO sentence.
The Nassar and Khamayseh’s approach
transforms text in Arabic (Nassar and Khamayseh,
2015) as a sample is free to apply the algorithm which
uses tags patterns and heuristic in order to create the
UML activity diagrams
In the IDM approach (Slihte, 2015) the classic
NLP features are used and for the outcome other
techniques are applied: extraction rules for entities,
descriptions of and dependencies between functional
features based on the sequence of steps in certain
scenario.
The approach using “Domain Model Extractor”
(Arora et al., 2016) in order to extract relationships
required for the UML class diagram apply the
standard NLP features, extraction rules, which use
determined dependencies for concepts, associations,
generalization, cardinalities, and attributes.
The AnModeler approach (Thakur and Gupta,
2014, 2016a, 2016b) that uses the tool with the same
name uses the Stanford NL Parser API to obtain type
dependencies (TDs) and parts of speech tags (POS-
tags) of each sentence in the specification. The
identified sentence structure and the semantic
relationships between the words in the sentence
obtained from the TDs and POS-tags are used by the
tool to identify domain elements with domain objects,
their attributes, operations, and interactions between
the objects.
Analysis of individual sentences and extracted
RSF triples are used in the modified DAA4BPM
approach that we refer as DAA4BPM v.2 (Leopold et
al., 2017). First, RDF specification is obtained from
the informal textual specification in the following
way:
Stanford Parser is used to automatically
transform a text into a list of individual
sentences, identify the grammatical entities
(the subject, object, predicate, and adverbial)
and the relations between them;
WordNet is used in conversion of all words into
their base form;
Then, RDF triples are used for specifying the
obtained information;
The RDF specification is obtained from process
models in the following way:
Using extraction, linguistic analysis,
normalization, and transformation of activity
labels with its components (action, business
object, additional information) into RDF;
By extracting the inter-relations between
activity records.
The inter-relations between activity records in the
DAA4BPM v.2 are extracted in the following way:
pair-wise relations are identified;
relations are propagated;
behavioral relations are transformed into RDF
In the AGER (Ghosh et al., 2018) the algorithm
for detecting entities, attributes and relations is
performed by using the entity, attribute and relation
synonyms tables. However, to generate the E-R
diagram the BFS algorithm is used.
In the Kashmira and Sumathipala’s approach
(Kashmira and Sumathipala, 2018) supervised
machine learning module (the “Weka” model), as
well ontology and web-mining are used to identify
entities, attributes, and relationships from the given
text as well as to filter out the relevant attributes into
extracted entities. In order to train the “Weka” model,
the authors considered four classifier algorithms
namely Random Forest, Naive Bayes, Decision
Table, and SMO.
MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering
496
In the Shweta Sanyal and Ghoshals approach
(Shweta et al., 2018) Implementation Rules based on
the universal dependencies between words (provided
by the NLP tools) and authors’ keywords are used for
the sequential extraction of classes, attributes,
methods, and relations.
In the AR2AA (Anwar et al., 2020) the rules are
developed to identify actions and conditions in the
textual requirements to the design. These rules
analyze the POS tagging in the sentences and extracts
all actions (verbs) and the corresponding conditions
(nouns and adjectives) based on them.
Reducing N-grams to terms and counting their
frequency of occurrence in text are techniques for
extraction of relationships between elements in
DoMoRe (Agt-Rickauer, 2020):
N-Grams are a sequence of n consecutive
words. It is used for derivation of semantic
relationships between co-occurring words and
terms.
Redundancy and Paraphrases. The authors
focus on identification of relationships on a
conceptual level and use mentions of concepts
that occur redundantly and paraphrased as well.
Word Co-occurrences and Distributions. The
authors derive the latent semantic relationship
between domain-specific terms from
frequently co-occurring words and phrases, as
well as identify technical terms with the help of
collocations.
Mind maps and formal concept analysis (FCA)
are used for manual extraction of the relationships in
the Fire Report Analysis approach (Mirończuk,
2020).
Declarative Knowledge Extraction (Table 4).
Since, all the target models include the concept of an
object or a group of objects (a class) all the analyzed
approaches support extraction of the declarative
knowledge, i.e., identification of classes/objects,
attributes and relations in pairs class-attribute, object-
attribute, class-class, and object-object.
Procedural Knowledge Extraction (Table 4). The
elements describing the dynamic characteristics of
the domain are also extracted in all the considered
approaches. The approaches, where the target model
is an E-R diagram, express the procedural knowledge
as an element Relation between entities the AGER
and the Kashmira and Sumathipala’s approach. In
their turn, in the Relative Extraction Methodology
and the Shweta Sanyal and Ghoshal’s approach –
where the target model is just an UML Class
diagram – the procedural knowledge is expressed as
class operations.
Synonym Processing (Table 4). Most of the
approaches provides automated processing of
synonyms by using corresponding ontology banks.
Table 4: Extraction of the certain knowledge type and processing synonyms.
Approaches Knowledge Type Synonyms Processing
Declarative Procedural
Ilieva and Ormandjieva Y Y Y, belonging
Relative Extraction Methodology Y Y, class operations N/I
DAA4BPM Y Y Y
ReDSeeDS Y Y Y
Nassar and Khamayseh Y Y N/I
IDM Y Y Y, theoretically
Domain Model Extractor Y Y Y
AnModeler Y Y Y
DAA4BPM v.2 Y Y Y
AGER Y Y, relations Y
Kashmira and Sumathipala Y Y, relations Y
Shweta, Sanyal and Ghoshal Y Y, class operations N/I
AR2AA Y Y N/I
DoMoRe Y N Y, link to ontology bank
Mirończuk (Fire Report Analysis) Y Y Y, manually
*“Y”-yes; “N” – no; N/I – not indicated.
Text Processing Techniques in Approaches for Automated Composition of Domain Models
497
The exceptions are the Fire Report Analysis
where the processing is done manually by the author,
and the IDM approach where the authors described
such an option theoretically. In the descriptions of
four approaches the Nassar and Khamayseh’s
approach, the Relative Extraction Methodology, the
Shweta Sanyal and Ghoshal’s approach and the
Shweta Sanyal and Ghoshal’s approach this
question is not even discussed.
3.4 Discussion on Findings
As mentioned in the beginning of section 3, to
minimize the uncertainty of natural languages manual
pre-processing of text can be applied. The result of
the review approves the same fact, just 6 of 15
considered approaches take as input unrestricted
texts. Other approaches either use predefined
structures of the sentences (SVO and VSO), or
organize the content within some structure
supplemented by pre-defined keywords. Most of
approaches compose the domain model based on
requirements specifications thus assuming further
generation of application code or database schemes.
Another way how to deal with the semantical
uncertainty is application of ontology banks, machine
learning and statistical inferring. The presented
approaches demonstrated this fact. Six of them use
machine learning, ontology banks WordNet and
FrameNet, statistics of term occurrence and even
web-mining like in the Kashmira and Sumathipala’s
approach. However, if the ontology banks were
applied even in research published in 2011, then
machine learning is the new thing: among the
observed approaches the first mention is in 2018.
Ontology banks are also applied for automated
synsets analysis.
The target models are quite diverse. They are
represented by such “traditional notations” of the
domain models as UML (behavioral and structural
diagrams), BPMN, E-R and such rare used as RDF
triplets, semantic networks, database schemes and
TFMs. Thus, this diversity approves that knowledge
in all the dimensions of domain models could be
automatically extracted and modeled. Besides that, it
illustrates that both procedural and declarative
knowledge can be processed in the automated way.
The applied knowledge extraction techniques are
mostly algorithmic solutions that implements
knowledge extracting rules based on keyword
analysis, determined word dependencies and lexical
semantic patterns. As an input these algorithmic
solutions use outcomes of NLP of texts or a
transitional model and as an output produce a target
model or a transitional model. A part of rules may
share the same patterns. In this activity, machine
learning models are used for the sentence
classification task.
All the approaches have been validated by their
authors. Most of them manually. The main
measurements were the accuracy and the
completeness of the extracted knowledge. The results
evaluated can be considered as satisfactory, and in a
large degree depends on the quality of the patterns
and extracting rules.
4 CONCLUSIONS
The research has provided the short overview of 15
approaches for automated domain model composition
those of using automated knowledge extraction. The
compared characteristics have been selected to
understand the trends in application of the knowledge
extraction techniques for analysis of documentation
needed for composing the software domain model.
Main findings are the following:
Still there is a small number of works that
investigate processing of text in unrestricted
languages;
Approaches deal with behavioral, functional
and structural dimensions of the problem
domain that is approved by the target models
used;
It is not enough just to apply NLP feature for
text: analysis of the NLP outcomes is required;
The analysis of the NLP outcomes mostly is
algorithmic and assumes a use of lexical
semantic patterns based on dependencies and
POS tags of words as well as keyword analysis
for structures text and synsets analysis.
Application of machine learning models is a
new thing in the field.
The main manageable issues in the presented
approaches relate to the quality of lexical semantic
patterns and algorithmic processing of NLP
outcomes. However, natural languages uncertainty
remains and may affect the results in an unexpected
way.
Construct Validity: Since various methods for
extraction of domain models from text exist, the
question about the format of the input information is
open should it be unrestricted or controlled
language and what means do we have to process text
in it. Thus, this research reviews existing results of
other authors’ works that have been published from
2005 till 2020 by IEEE and ACM.
MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering
498
In order to evaluate the current state in the field,
the characteristics of the source models, transition
models and target models were evaluated, as well as
methods or approaches used for procedural and
declarative knowledge extraction including synonym
analysis. The quality of extraction of knowledge is
not analyzed since the diversity of input models and
output models as well as a lack of precise information
on implementation of extracting rules and algorithms
do not allow to make objective conclusions about the
degree of validity of the presented approaches.
Internal Validity: The presented research works
are limited by publication period (15 years) and
publication databases (IEEE and ACM). The search
of related works has been done using a limited
number of keywords: “Knowledge Extraction,”
“Domain model extraction,” “Natural Language
Processing.” The result of the search was filtered by
relevance to the research question and the target
model as well as manual processing and composing
approaches have been ignored. Multiple publications
of the same authors were reviewed, and the most
complete publications were taken for the analysis.
External Validity: The presented results
illustrate that despite having quite advanced NLP
features, the main difficulty is processing of NLP
outcomes. Language ambiguity, multiple possible
constructs for expressing one and the same
statements, multiple possible interpretations of a
statement require huge work on processing text and
does not guarantee that the results of application of
any method will be the same or at least will have
similar quality for all cases.
Future research directions can be related to
investigation on how to obtain more complete set of
lexical semantic patterns and extraction rules as well
as to techniques used for discourse understanding in
specifications written in unrestricted languages and
having informal structure. Besides that, the important
question is how one can discover the fact that some
knowledge is missed and what this knowledge is.
REFERENCES
Agt-Rickauer, H. 2020. Supporting Domain Modeling with
Automated Knowledge Acquisition and Modeling
Recommendation, Technischen Universitat Berlin.
Anwar, M. W., Ahsan, I., Azam, F., Butt, W. H., and Rashid,
M. 2020. A Natural Language Processing (NLP)
Framework for Embedded Systems to Automatically
Extract Verification Aspects from Textual Design
Requirements. In Proceedings of the 2020 12th
International Conference on Computer and Automation
Engineering, 7–12. ACM. https://doi.org/10.1145/
3384613.3384619
Arora, C., Sabetzadeh, M., Briand, L., and Zimmer, F. 2016.
Extracting domain models from natural-language
requirements: Approach and Industrial Evaluation. In
Proceedings of the ACM/IEEE 19th International
Conference on Model Driven Engineering Languages
and Systems - MODELS ’16, 250–260. ACM/IEEE.
https://doi.org/10.1145/2976767.2976769
Asnina, E. 2006a. Formalization of Problem Domain
Modeling within Model Driven Architecture, Riga
Technical University.
Asnina, E. 2006b. The Computation Independent Viewpoint:
a Formal Method of Topological Functioning Model
Constructing. In Applied Computer Systems, 26, 21–32.
RTU Press.
Donins, U. 2012. Doctoral thesis “Topological Unified
Modeling Language: Development and Application,”
Riga Technical University.
Elstermann, M., and Heuser, T. 2016. Automatic Tool
Support Possibilities for the Text-Based S-BPM Process
Modelling Methodology. In Proceedings of the 8th
International Conference on Subject-Oriented Business
Process Management - S-BPM ’16, 1–8. ACM.
https://doi.org/10.1145/2882879.2882882
Friedrich, F., Mendling, J., and Puhlmann, F. 2011. Process
Model Generation from Natural Language Text. In
Proceedings of the 23rd International Conference on
Advanced Information Systems Engineering (CAiSE
2011), 482–496. Springer-VerlagBerlin, Heidelberg.
https://doi.org/10.1007/978-3-642-21640-4_36
Ghosh, S., Mukherjee, P., Chakraborty, B., and Bashar, R.
2018. Automated Generation of E-R Diagram from a
Given Text in Natural Language. In 2018 International
Conference on Machine Learning and Data Engineering
(ICMLDE), 91–96. IEEE.
https://doi.org/10.1109/iCMLDE.2018.00026
Ilieva, M. G., and Ormandjieva, O. 2006. Models Derived
from Automatically Analyzed Textual User
Requirements. In Fourth International Conference on
Software Engineering Research, Management and
Applications (SERA’06), 13–21. IEEE.
https://doi.org/10.1109/SERA.2006.51
Kalnins, A. 2010. A Model-Driven Path from Requirements
to Code. Computer Science and Information
Technologies, 756, 33–57. Horizon Research Publishing.
Kalnins, A., Smialek, M., Kalnina, E., Celms, E.,
Nowakowski, W., and Straszak, T. 2011. Domain-
Driven Reuse of Software Design Models. In J. Osis and
E. Asnina (Eds.), Model-Driven Domain Analysis and
Software Development, 177–200. IGI Global.
https://doi.org/10.4018/978-1-61692-874-2.ch009
Kashmira, P. G. T. H., and Sumathipala, S. 2018. Generating
Entity Relationship Diagram from Requirement
Specification based on NLP. In 2018 3rd International
Conference on Information Technology Research
(ICITR), 1–4. IEEE. https://doi.org/
10.1109/ICITR.2018.8736146
Khoo, C., Chan, S., and Niu, Y. 2002. The Many Facets of
the Cause-Effect Relation. In R. Green, C. A. Bean, and
Text Processing Techniques in Approaches for Automated Composition of Domain Models
499
S. H. Myaeng (Eds.), In The Semantics of Relationships:
An Interdisciplinary Perspective (pp. 51–70). Springer
Netherlands. https://doi.org/10.1007/ 978-94-017-0073-
3_4
Krishnan, H., and Samuel, P. 2010. Relative Extraction
Methodology for class diagram generation using
dependency graph. In 2010 International conference on
communication control and computing technologies,
815–820. IEEE. https://doi.org/10.1109/
ICCCCT.2010.5670730
Leopold, H., van der Aa, H., Pittke, F., Raffel, M., Mendling,
J., and Reijers, H. A. 2017. Searching textual and model-
based process descriptions based on a unified data
format. Software & Systems Modeling, 18(2), 1179–
1194. https://doi.org/10.1007/s10270-017-0649-y
Miller, J., and Mukerji, J. 2001. Model Driven Architecture
(MDA). In Architecture Board ORMSC.
http://www.omg.org/cgi-bin/doc?ormsc/2001-07-01
Mirończuk, M. M. 2020. Information Extraction System for
Transforming Unstructured Text Data in Fire Reports
into Structured Forms: A Polish Case Study. Fire
Technology, 56(2), 545–581. Springer.
https://doi.org/10.1007/s10694-019-00891-z
Nassar, I. N., and Khamayseh, F. T. 2015. Constructing
Activity Diagrams from Arabic User Requirements using
Natural Language Processing Tool. In 2015 6th
International Conference on Information and
Communication Systems (ICICS), 50–54. IEEE.
https://doi.org/10.1109/IACS.2015.7103200
Nazaruka, E. 2020. Processing Use Case Scenarios and Text
in a Formal Style as Inputs for TFM-based
Transformations. Baltic J. Modern Computing, 8(1), 48–
68. https://doi.org/10.22364/bjmc.2020.8.1.03
Nazaruka, E. 2019. Identification of Causal Dependencies by
using Natural Language Processing: A Survey. In E.
Damian, G. Spanoudakis, and L. Maciaszek (Eds.), In
Proceedings of the 14th International Conference on
Evaluation of Novel Approaches to Software
Engineering - Volume 1: MDI4SE, 603–613. SciTePress.
https://doi.org/10.5220/0007842706030613
Nazaruka, E., and Osis, J. 2018. Determination of Natural
Language Processing Tasks and Tools for Topological
Functioning Modelling. In Proceedings of the 13th
International Conference on Evaluation of Novel
Approaches to Software Engineering, 501–512.
SciTePress.
Nazaruka, E., Osis, J., and Griberman, V. 2019. Extracting
Core Elements of TFM Functional Characteristics from
Stanford CoreNLP Application Outcomes. In E. Damian,
G. Spanoudakis, and L. Maciaszek (Eds.), Proceedings
of the 14th International Conference on Evaluation of
Novel Approaches to Software Engineering - Volume 1:
MDI4SE, 591–602. SciTePress.
https://doi.org/10.5220/0007831605910602
Ning, Q., Feng, Z., Wu, H., and Roth, D. 2018. Joint
Reasoning for Temporal and Causal Relations. In
Proceedings of the 56th Annual Meeting of the
Association for Computational Linguistics (Long
Papers), 2278–2288. Association for Computational
Linguistics.
Osis, J., Asnina, E., and Grave, A. 2007. Formal computation
independent model of the problem domain within the
MDA. In J. Zendulka (Ed.), Proceedings of the 10th
International Conference on Information System
Implementation and Modeling, Hradec nad Moravicí,
Czech Republic, April 23-25, 2007 (Vol. 252, pp. 47–54).
Jan Stefan MARQ.
Pearl, J. 2019. The Seven Tools of Causal Inference, with
Reflections on Machine Learning. Communications of
Association for Computing Machinery, 62
(3), 54–60.
ACM. https://doi.org/10.1145/3241036
Prieto-Diaz, R. 1990. Domain Analysis: An Introduction.
Software Engineering Notes, 15(2), 47–54. ACM
SIGSOFT.
Shweta, Sanyal, R., and Ghoshal, B. 2018. Automatic
Extraction of Structural Model from Semi Structured
Software Requirement Specification. In 2018 IEEE/ACIS
17th International Conference on Computer and
Information Science (ICIS), 543–558. IEEE.
https://doi.org/10.1109/ICIS.2018.8466406
Slihte, A. 2015. The Integrated Domain Modeling: an
Approach & Toolset for Acquiring a Topological
Functioning Model, Riga Technical University.
Smialek, M., and Straszak, T. 2012. Facilitating transition
from requirements to code with the ReDSeeDS tool. In
2012 20th IEEE International Requirements Engineering
Conference (RE), 321–322. IEEE.
https://doi.org/10.1109/RE.2012.6345825
Solstad, T., and Bott, O. 2017. Causality and causal reasoning
in natural language. In M. R. Waldmann (Ed.), The
Oxford Handbook of Causal Reasoning, Oxford
University Press. http://www.oxfordhandbooks.com/
view/10.1093/oxfordhb/9780199399550.001.0001/oxfo
rdhb-9780199399550-e-32
Thakur, J. S., and Gupta, A. 2014. Automatic generation of
analysis class diagrams from use case specifications. In
ISEC '14: Proceedings of the 7th India Software
Engineering Conference, 1-6. ACM.
https://doi.org/10.1145/2590748.2590768.
Thakur, J. S., and Gupta, A. 2016a. AnModeler: a tool for
generating domain models from textual specifications. In
Proceedings of the 31st IEEE/ACM International
Conference on Automated Software Engineering - ASE
2016, 828–833. ACM/IEEE.
https://doi.org/10.1145/2970276.2970289
Thakur, J. S., and Gupta, A. 2016b. Identifying domain
elements from textual specifications. In Proceedings of
the 31st IEEE/ACM International Conference on
Automated Software Engineering - ASE 2016, 566–577.
ACM/IEEE. https://doi.org/10.1145/2970276.2970323
Waldmann, M. R., and Hagmayer, Y. 2013. Causal
reasoning. In D. Reisberg (Ed.), Oxford Handbook of
Cognitive Psychology. Oxford University Press.
https://doi.org/10.1093/oxfordhb/9780195376746.013.0
046
MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering
500
