A Consortied Ledger-based Cloud Computing Provider Users

Reputation Architecture

Gabriel Escobar Vasques and Adriano Fiorese

Graduate Program in Applied Computing (PPGCAP), Department of Computer Science (DCC),

Santa Catarina State University (UDESC), Joinville, Brazil

Keywords:

Blockchain, Cloud Computing, Credibility, Reputation.

Abstract:

Several users and organizations have been attracted by the beneﬁts offered by the cloud computing services.

However, there are still several security issues and challenges in these environments. Controlling access to

providers is an important task and must be carried out safely. In this sense, this paper presents a ledger-based

collaborative user reputation architecture for a cloud providers’ consortium. The reputation is based in two

indicators: objective and subjective ones. The objective data corresponds to the user’s session data. Subjective

data, on the other hand, corresponds to the providers’ feedback about users and data obtained from external

sources. The combination of these two indicators deﬁnes the reputation value. It aims to avoid bias in the

evaluations carried out by the providers and possible conﬂict of interests. In order to evaluate the proposed

architecture, a user cloud providers scenario was developed. Evaluation results show applicability of storing

and providing users reputation values to participating providers.

1 INTRODUCTION

Several users and organizations have been attracted

to Cloud Computing (CC) services in the last years.

Public health questions can result in social isolation

preventing organizations from carrying out their ac-

tivities normally. As main beneﬁts in the adoption

of cloud services we can emphasize its ubiquitous

model of working and the on demand services deliv-

ery. Besides that, the cloud services make possible

cost reduction on hardware acquisition, installation,

and maintenance of the hardware equipment, etc. (Liu

et al., 2012). Despite the beneﬁts offered by the CC

there are several security issues and challenges that

still need attention, offering research opportunity for

development of proposals to solve them.

The NIST (National Institute of Standards and

Technology) in its cloud reference architecture iden-

tiﬁed several issues of security (Liu et al., 2012), and

had made them public through a report. It estab-

lishes necessary recommendations so that the secu-

rity and privacy of services are guaranteed. Among

the issues raised by NIST, the identity management

and access control is an important security issue for

service providers. Malicious users represents men-

ace and are cause for great concerns in cloud envi-

https://orcid.org/0000-0003-1140-0002

ronments (Nkosi et al., 2013). In the literature it is

possible to ﬁnd several techniques and tools focused

on authentication and control access of users. The

Public Key Infrastructure (PKI) and Reputation Sys-

tems (RS) are examples of used techniques to per-

form these tasks. Particularly, reputation systems

are widely used to estimate the credibility of service

providers, e-commerce users, among others. In such

cases, the risks assumed by providers and users in

their relationships on computational systems are pro-

portional to the reputation of the provider/user they

are dealing with. To encourage users good behaviour

in their interactions with the service providers and

help on providers access control it is possible to use

credibility indicators. Such indicators can be deﬁned

by a reputation calculation based in the actions taken

by users in their interactions with providers. Coping

with a scenario in which CC service users utilize ser-

vices of multiple service providers in their activities,

it is possible to utilize a collaborative reputation sys-

tem shared between a consortium of providers aim-

ing the users reputation calculation based on the per-

formed actions on participants providers.

In this sense, this paper aims to present a cloud

provider service users reputation architecture that

uses as basis for the reputation value calculation,

the relations of users with consortium CC service

374

Vasques, G. and Fiorese, A.

A Consortied Ledger-based Cloud Computing Provider Users Reputation Architecture.

DOI: 10.5220/0010527403740381

In Proceedings of the 23rd International Conference on Enterprise Information Systems (ICEIS 2021) - Volume 1, pages 374-381

ISBN: 978-989-758-509-8

providers and their overall behaviour catch by ex-

ternal information sources. This architecture has

the function of providing participating providers with

users’ reputation/credibility value to help them con-

trol access to their services and contribute to the man-

agement of risks and threats that users may repre-

sent. Given the scenario characteristics we intend to

work on, which relies on the distributed collabora-

tion of consortium cloud providers, blockchain tech-

nology will be used to store the values used to cal-

culate the reputation value as well as the reputation

value itself. This technology acts as a Timestamp-

ing Authority (TSA), which is responsible for ensur-

ing the order of chronological transactions and user

behaviour data integrity. Blockchain offers beneﬁts

such as data redundancy, transparency, consensus on

demand, which differs from traditional reputation ar-

chitectures/systems. In addition, it uses the P2P (peer-

to-peer) communication model. That is, blockchain

does not present a single point of failure that is com-

mon in reputation systems that relies on client/server

communication.

This work is organized as follows: Section 2

presents the concepts related to cloud computing, rep-

utation and blockchain technology. Section 3 exhibits

works related to this research. Section 4 presents the

users reputation architecture proposal. Section 5 dis-

cusses the scenario and experiments preformed, as

well as results obtained. Lastly, Section 6 present the

ﬁnal consideration and future work.

2 BACKGROUND

This section presents characteristics and descriptions

of the related technologies to the content covered by

this work.

2.1 Cloud Computing

Cloud computing is a paradigm for more efﬁcient use

of computational infrastructure, being deﬁned as a

technologically ubiquitous model. Cloud computing

service models are deﬁned according to how the con-

ﬁgurable set of computational resources can be deliv-

ered to end users. In this work, we adopted the NIST

nomenclature, which is used by several researchers

and organizations.

According to the NIST reference model, an im-

portant feature in computational clouds regardless of

their classiﬁcation and deployment model is security.

NIST has developed a security guide, which provides

an overview of the security and privacy challenges in-

volved in CC (Jansen and Grance, 2011). Among the

security issues pointed out by NIST, access control

is an important task and requires care by providers.

This work presents a cloud providers’ users reputa-

tion architecture that aims to assist the addressment of

issues raised by the security guide prepared by NIST.

Among these issues, the proposed architecture aims to

assist service providers at managing identity and ac-

cess. In addition, the architecture reputation value can

indirectly assist the management of cloud providers

internal risks and threats.

2.2 Reputation

Reputation is a well-known concept and applied in

several areas. A widely used deﬁnition of reputation

to describe its use in computer systems was devel-

oped by (Mui et al., 2002). There, the authors deﬁne

reputation as: “the perception that an agent creates

through past actions on his or her huge intentions”.

Typically, reputation values are deﬁned according to

the feedback provided by users and/or comprising the

results of the transactions. However, applications that

use only feedback in their calculations, which are sub-

jective in nature, can present loopholes for malicious

users and common reputation system attacks such as

self-promotion or defamation (collusion) (Hendrikx

et al., 2014). So, in fact, the ﬁnal reputation values

are not affected only by feedback to prevent malicious

behavior, it is possible to use other information to-

gether with them to compose the calculations. In this

sense, it is possible to use objective information about

users to compose the reputation calculation, such as:

behavior classiﬁcation, use of resources, etc. In addi-

tion, information related to the payment of monthly

fees/annuities regarding the used computational re-

sources, can also be part of the ﬁnal reputation value.

This way, the ﬁnal reputation values will be less sus-

ceptible to malicious feedback provided by dishonest

users.

2.3 Blockchain

Blockchain is a disruptive technology for conducting

transactions between two entities without the need for

a responsible third party to establish trust (Nakamoto,

2009). The blockchain concept consists of six main

characteristics: decentralization, transparency, open

source, autonomy, immutability and anonymity (Lin

and Liao, 2017). In general, applications developed

with blockchain can be implemented following three

main models: public, private and consortium (Lin and

Liao, 2017). In public blockchains, the entry of new

participants in the network happens in a simple way.

Users can choose to participate in the consensus pro-

A Consortied Ledger-based Cloud Computing Provider Users Reputation Architecture

375

cess and consequently to the addition of new blocks

where all participants in the blockchain can check the

transactions. A blockchain network is a technical in-

frastructure that provides ledger and smart contracts

services to applications.

In implementations that follow the private model,

the control of the blockchain network is performed

by a single organization which is responsible for al-

lowing or not allowing the entry of new participants,

in addition to deﬁning the actions that each partici-

pant can perform. The consortium model works in

a similar way to the private one. However, two or

more organizations have control of the network. In

these models, the mechanisms used to obtain consen-

sus and to add new blocks tend to be less computa-

tionally costly, and consequently consumes less en-

ergy. Furthermore, in these models, participants are

usually well identiﬁed and only participants deﬁned

by the organization(s) can verify transactions and add

new blocks (Greve et al., 2018).

Blockchain technology is used in the development

of the reputation architecture proposed in this work.

In turn, the architecture suits a scenario where CC ser-

vice providers and their users integrate a blockchain

network at the consortium model.

3 RELATED WORK

Some works such as (Xu et al., 2019) are aimed at

assisting the selection of personalized CC services,

based on Quality of Service (QoS) assessments car-

ried out by users. To encourage users to provide re-

liable QoS assessments, the authors propose a mech-

anism for calculating users’ reputation and reliability

based on the assessments provided by them and com-

paring it with other assessments on the same service

provided by other users. In (Zheng et al., 2018) the

authors present an approach to improve the speed of

classifying users’ normal behavior in a cloud environ-

ment. For this, those authors present a reputation clas-

siﬁer, which is responsible for calculating the reputa-

tion values based on the user behavior and service use

classiﬁcations obtained by means of machine learn-

ing.

The work of (Thakur and Breslin, 2019) proposes

a mechanism for managing the reputation of IaaS-

type service providers in a federated/hybrid cloud.

The proposal aims to encourage providers to clas-

sify their users’ behavior correctly, differentiating

them between good and malicious users. The reputa-

tion of providers is estimated through feedback from

providers about other providers, feedback from users

about providers and feedback from providers about

users.

The work developed by (Wu et al., 2015) in-

troduces a reputation mechanism and designs a

reputation-based identity management model for CC.

The authors developed a model, in which users re-

ceive pseudonyms generated from a reputation sig-

nature in order to guarantee the non-traceability of

pseudonyms and proposes a reputation calculation

mechanism to help identify malicious users. The

work of (Du et al., 2019) proposes an online repu-

tation calculation method to efﬁciently provide a per-

sonalized reputation for each user, within the context

of cloud applications based on service-oriented archi-

tectures. The work (Donghong et al., 2016) presents

a dynamic access control framework based on repu-

tation and attributes for privacy protection in the CC

environment.

These works analysis shows that there is a gap for

works that present approaches related to the reputa-

tion of users of cloud providers. Moreover, it is also

noticeable a lack of works where providers’ users rep-

utation is shared with other providers, allowing them

to assess the risks that eventually malicious users can

to offer.

4 PROPOSAL

This paper models and proposes a reputation archi-

tecture for users of cloud providers, as a collaborative

tool between them.

4.1 Reputation Architecture

The proposed architecture is presented in Figure 1. It

is composed of several modules that perform the func-

tions related to the calculation of the reputation value.

For the implementation, blockchain technology was

used as a mechanism for data persistence, taking ad-

vantage of its beneﬁts as immutability to protect data

against attacks on the reputation system, as well as

ensuring the traceability and auditing of any conﬂicts.

The reputation architecture has three main compo-

nents: the reputation system (RS), the cloud provider

and external data sources. The RS consists of the rep-

utation calculation module and the blockchain itself.

The data is validated and stored in a distributed and

redundant way using a blockchain in the consortium

model through distributed consensus. The blockchain

has the important role of acting as a distributed TSA,

being responsible for ensuring the temporal ordering

of the records inserted in the chain of blocks.

The proposed architecture usage and behaviour is

given by the following interactions between its mod-

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

376

ules. Upon receiving the request, the access control

module of the cloud provider can perform a query to

the reputation calculation module to obtain the user

reputation value. Upon receiving the user’s reputa-

tion value, the provider may or may not allow the

user access to its services, applying access and secu-

rity policies according that value. If access is allowed,

user uses the provider’s services and at the end of his

session provider makes available the data from that

session to the reputation system so that they can be

used in the proper credibility indicator calculations.

After receiving the session data from the user, the RS

performs consultations with external sources to obtain

information from public databases that are also used

in the calculations. After receiving all the previously

mentioned data, they are saved in the ledger and cal-

culations of the objective and subjective credibility in-

dicators are performed. The values that compose the

objective credibility indicator come from resources

utilization offered by the providers to the users like

RAM memory, processors, the user connection sta-

bility and payments. Thus, the higher these values,

which indicates an active, stable and well payer user,

the higher the objective credibility indicator and con-

sequently the reputation value. The contrary is also

directly related. The values that make up the sub-

jective credibility indicator come from the external

sources and user evaluation given by the providers

feedback. The ﬁnal reputation value is calculated by

combining these two indicators.

The sources of external information are used in

the reputation calculation together with the providers’

feedback to compose the subjective credibility indi-

cator. These kind of external sources should provide

info that can be used to marginally infer a particular

portion of the user social behavior. Queries to these

external (to the architecture) databases return the re-

spective number of issue items that user has. Origi-

nally, as proposed by default, it should be four exter-

nal data sources and each one of them represents 25%

of the external issues indicator.

However, providers can assign agreed weights to

external data sources at their own discretion.

Figure 1: Reputation Architecture.

Thus, the reputation (R) of users is given by the

combination of two historical indicators of credibil-

ity: the objective and subjective ones, as observed in

Equation 1.

According to the deﬁnition adopted for reputation,

obj

is the historical and current objective credibility

indicator (if any) for user s, I

sub

is the historical sub-

jective credibility indicator and ω

obj

, ω

sub

are weights

deﬁned for the respective indicators.

Equation 2 represents the user’s objective cred-

ibility indicator, which is composed of the average

percentage of computational resources use (upr) in n

sessions, the connection stability (EoC) calculated by

the n sessions latency (ping) value average and the ra-

tio calculated between the number of payments made

on time and the total number of monthly/annuity pay-

ments (pay), for each user. These indicators corre-

spond respectively to 35%, 25% and 40% of the ob-

jective credibility indicator value.

The upr variable corresponds to the percentage of

resource use, which is calculated by means of the

arithmetic average between the percentage averages

of CPU usage (mpcp) and corresponding RAM mem-

ory usage (mmr) in the last n user sessions. Equa-

tion 6 is responsible for calculating the percentage

value of resource usage according to the user’s history

(upr). The percentage of use of each CPU (process-

ing core) (pcp(s)) is captured during the user’s session

and through it the average percentage of CPU usage

of that session is calculated. Thus, the mpcp vari-

able, which corresponds to the average percentage of

CPU usage, is obtained by adding the percentages of

use of each CPU (pcp) used, from the ﬁrst core (i =

1) to the last one (npc), and dividing that sum by the

total number of cores (npc). Equation 3 is responsi-

ble for calculating the user’s CPU usage percentage

(mpcp(s)).

The mmr variable corresponds to the average

RAM memory usage in MB, which is calculated as

the ratio between the sum of the memory usage value

every second during the user session, and the total du-

ration of the session tf, in seconds. Equation 4 is re-

sponsible for calculating the average RAM memory

usage for that session. The pur variable corresponds

to the percentage of RAM memory usage, calculated

by the ratio between the average RAM memory used

(mmr - Equation 4) and the amount of RAM memory

allocated (amr). The amount of allocated RAM (amr)

is the amount originally purchased by the user. Equa-

tion 5 is responsible for determining the percentage of

RAM memory usage.

In turn, variable (EoC) present in Equation 2 cor-

responds to the historical average of the user’s con-

nection latency. To obtain its value, the user’s connec-

A Consortied Ledger-based Cloud Computing Provider Users Reputation Architecture

377

tion latency value should be initially obtained from

each user’s sessions. In this case, the ping appli-

cation is used for polling, by means of the Internet

Control Message Protocol (ICMP), between the cloud

provider and a host on the user’s network, making it

possible to obtain the latency value in the communica-

tion between provider and user. Thus, every ping op-

eration during the user’s session at the provider adds

value 1 for the latency accumulator, if its value is less

than or equal to 150 ms. At the end of the session, this

accumulated value is divided by the number of times

that the latency value was recovered (n), according to

Equation 7. This is the user connection latency when

he is using a cloud provider. The user s historical av-

erage latency (EoC(s)), used in the composition of the

objective indicator, according to Equation 2, is cal-

culated using the p last (therefore historical) values

of the user’s connection latency (EoC), as shown in

Equation 8.

In turn, variable (pay), also Equation 2, corre-

sponds to the user’s punctuality in paying the monthly

fee for the cloud provider’s services. Variable (pay)

corresponds to the ratio between the number of pay-

ments up to on time (npd) and the total of payments

made (ntp), as described by Equation 9.

On the other hand, Equation 10 is responsible for

calculating the subjective credibility indicator value.

This value results from the difference between the

feedback from the providers and the results of con-

sultations with external sources.

The second component of the subjective credibil-

ity indicator comprises the results from consultation

with external sources, and it is called external issues

indicator (I

Pex

(s)). Equation 11 is responsible for cal-

culating that indicator. For the calculation of the ex-

ternal issues indicator, normalization is carried out in-

volving the sum of the values obtained from external

sources (Fe

) weighted by the cloud providers (default

weight is 0.25 each external source), and the sum of

weighted maximum values from each external source,

according each user s. Equation 12, on the other hand,

is responsible for calculating the average of n values

of the external issues indicator for each user, making

the ﬁnal external issues indicator a historical indica-

tor. The n value, representing the historical period

(how many external issue indicator values are used),

should be agreed among the cloud providers belong-

ing to the consortium.

Cloud providers send feedback values, regarding

their users, to allow the user behaviour assessment

by the reputation architecture. These feedback val-

ues comprise different activities users perform at the

cloud provider. Each of these activities is represented

by an indicator, for instance (I

, I

, ..., I

), where k is

the total number of activities/indicators. This work

proposes three so called feedback indicators. First

indicator (I

) corresponds to the provider’s feedback

due to the user’s login attempts. Second indicator

) corresponds to the provider’s feedback due to

the login path, in which the IP address and the user

agent are veriﬁed. According to (Yu et al., 0108)

and (Berrached and Korvin, 2006) these two indica-

tors represent factors that inﬂuence the user’s login

behavior and credibility. Third indicator (I

), on the

other hand, corresponds to the provider’s feedback

due to the attempts of users to access improper data.

Providers assign values from 0 to 10 for each of these

indicators according the user attempts to execute the

corresponding activities. All providers must be in line

with the feedback evaluation model in order to avoid

indicator value bias. Thus, a user feedback provided

by all nfp providers, in a time period, corresponds

to the ratio between feedback indicators’ sum from

all providers [1..nfp], and the sum of maximum val-

ues for each of these indicators, from all providers

[1..nfp]. Equation 13 shows user feedback (Fp(s))

calculation.

In turn, Equation 14 transforms the single period

of time user feedback indicator (Fp(s)) into a histor-

ical (average) user feedback (Fp(s) ). To accomplish

that, it performs the ratio between the sum of np single

user feedback indicators and the number of already

(past) calculated single user feedback indicators for

that historical period (np). This np value also must be

agreed among providers’ consortium participants. It

is important to note that the historical user feedback is

one of the subjective credibility indicator components

(Equation 10).

= ω

ob j

∗ I

ob j

(s) + ω

sub

∗ I

sub

(s). (1)

ob j

(s) = (upr ∗ 0.35 +EoC ∗ 0.25 + pay ∗ 0, 40). (2)

mpcp(s) =

∑

npc

i=1

pcp(s)

npc

(3)

mmr(s) =

∑

t f

i=1

umr(s)

t f

(4)

pur(s) =

mmr(s)

amr(s)

(5)

upr(s) =

∑

i=1

pur(s)

∑

i=1

mpcp(s)

(6)

EoC(s) =

∑

i=1

1[ping

≤ 150ms]

(7)

EoC(s) =

∑

i=1

EoC(s)

(8)

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

378

pay(s) =

npd

nt p

(9)

Isub(s) = F p − I

Pex

(10)

Pex(s)

∑

N f e

i=1

∗ ωi

∑

N f e

j=1

max(Fe

∗ ω j)

(11)

Pex(s)

∑

n f

i=1

Pex(s)

n f

(12)

F p(s) =

∑

n f p

i=1

1,i

+ I

2,i

+ I

3,i

n f p

∑

j=1

max

) + max

)

(13)

F p(s) =

∑

i=1

F p

(14)

5 SCENARIO & EXPERIMENTS

The performed experiments are based on a sce-

nario, in which 15 users use the services of 3 dif-

ferent cloud providers. These cloud providers com-

pose a blockchain network coping with the consor-

tium model, and they use the proposed reputation

architecture. The experiments were carried out us-

ing Hyperledger Fabric version 2.2 framework de-

veloped by the Linux Foundation. To create and

conﬁgure the blockchain network, Docker contain-

ers and the container orchestrator Docker-Compose

were used. The blockchain network reaches consen-

sus by means of the Byzantine Fault Tolerance (BFT)

mechanism, which allows the consensus process to

be carried out even if some nodes fail or act ma-

liciously. To develop chaincodes (smart contracts),

JavaScript programming language was used. Node.js

framework runs JavaScript code. To manage pack-

ages for JavaScript language, the Node Package Man-

ager was used, which is already included in Node.js

framework. In addition, cURL (Client URL) software

that provides a library and a command line tool for

transferring data, providing support for various proto-

cols, was used.

Experiments were carried out on a computer with

an Intel Core-i5-7200U 2.50 GHz processor, 8 GB of

RAM memory with Linux Mint 19.2 operating sys-

tem. A simulation of a hypothetical case was con-

ducted, in which each user performs 10 sessions at

one of the participating providers. In addition, ﬁve

different users are assigned to each provider. The val-

ues used to compute the objective and subjective indi-

cators like memory use, processors use, user latency,

external issues values, and providers feedback were

generated randomly, following a normal probability

distribution function using the Math.random ﬂoating

point random number generation function available

in the JavaScript programming language. All values

were generated 10 times to enable averages to be cal-

culated. Values between 35 and 95 were used for the

CPU and RAM memory percentage indicators.

Average of 10 values between 20 and 200ms is

used for the connection stability indicator (user la-

tency). Values between 0 to 10 were generated for

each feedback indicator from the providers. These

values were generated 10 times and added, then these

values were normalized to obtain values between 0

and 1, according Equation 13. In this case, nfp equals

to 10. Comprising data from each external sources,

values between 0 and 10 were generated taken into

account one external data request per session and a

historical period of ten sessions (n in Equation 11 is

10). The payment amounts correspond to the pay-

ments on time divided by the total number of total

payments (historical period) resulting in a value be-

tween 0 and 1. The values were generated for a pe-

riod of 10 months, where the value 1 corresponds to

the payment on time and 0 for late payment. When

the payment was made the value 1 is added, otherwise

the value 0 is added. The values of the indicators that

make up the objective and subjective indicators are

obtained through the summation and subsequent cal-

culation of averages of data of 10 last sessions. To

calculate the averages of the indicators, values corre-

sponding to 10 session of each user were generated.

These values were used to calculate the historical av-

erage values of the I

pex

, F p and EoC indicators.

5.1 Results

Tables 1, 2, 3 show results from simulation. In all

tables, user identiﬁers (1 to 15) and provider iden-

tiﬁers (1 to 3) are present in the ﬁrst two columns.

Table 1 presents the information about the CPU use

percentage averages, RAM memory use average, re-

source usage percentage average, ratio between the

number of payments on time and total number of

payments, and connection stability indicator histori-

cal value, i.e., user session latencies average. Table 2

presents average (historical) user feedback, and the

average values returned by the external data sources

(F1, F2, F3 and F4) presented in Section 4.1. These

values represent the historical average obtained by the

summation of the 10 simulations data to each external

data source.

Table 3 presents Objective and Subjective credi-

bility indicator values, according data from previous

A Consortied Ledger-based Cloud Computing Provider Users Reputation Architecture

379

Table 1: User session data provided by cloud providers.

User ID Provider ID CPU aver-

age

RAM aver-

age

Resources use average Payment Connection stability

U1 P1 66% 64% 65% 1 0,92

U2 P3 74% 70% 72% 0,83 0,87

U3 P3 71% 66% 68,2% 0,75 0,64

U4 P1 60% 53% 56,5% 1 0,98

U5 P2 79% 71% 75% 0,9 0,86

U6 P2 58% 50% 54% 0,6 0,90

U7 P3 64% 58% 61% 0,87 0,69

U8 P1 70% 64% 67% 1 0,79

U9 P2 78% 73% 75,5% 0,9 0,93

U10 P1 59% 50% 54,5% 0,83 0,99

U11 P1 62% 57% 59,5% 0,8 0,99

U12 P3 40% 30% 35% 0,5 0,99

U13 P2 53% 44% 48,5% 0,85 0,97

U14 P3 80% 78% 79% 0,88 0,87

U15 P2 73% 70% 71,5% 1 0,923

Table 2: Data obtained from external sources.

User ID Provider ID Feedback F1 F2 F3 F4

U1 P1 0,7 0 0 0 0

U2 P3 0,8 1 3 2 5

U3 P3 0,7 2 0 3 0

U4 P1 0,6 1 1 1 1

U5 P2 0,6 0 2 0 1

U6 P2 0,3 0 3 2 1

U7 P3 0,7 2 1 2 3

U8 P1 0,4 1 1 2 0

U9 P2 0,8 3 2 3 3

U10 P1 0,7 1 2 2 5

U11 P1 0,8 6 1 1 3

U12 P3 0,2 0 1 2 2

U13 P2 0,3 2 9 2 3

U14 P3 0,9 3 2 0 0

U15 P2 0,7 5 3 4 0

Table 3: Indicator results and reputation.

User ID provider ID Objetive Subjective Reputation

U1 P1 0,85 0,7 0,810

U2 P3 0,8 0,7 0,775

U3 P3 0,7 0,71 0,706

U4 P1 0,84 0,84 0,843

U5 P2 0,83 0,57 0,758

U6 P2 0,65 0,525 0,615

U7 P3 0,73 0,62 0,702

U8 P1 0,83 0,44 0,715

U9 P2 0,85 0,72 0,819

U10 P1 0,77 0,61 0,726

U11 P1 0,77 0,7 0,755

U12 P3 0,57 0,74 0,624

U13 P2 0,76 0,50 0,683

U14 P3 0,87 0,82 0,860

U15 P2 0,77 0,6 0,728

tables. In addition, Table 3 also shows the reputation

values for each user.

Summing up, Figure 2 shows the users reputation

values. The x axis of Figure 2 shows distribution of

users at the providers, through the users’ identiﬁers

(U1 to U15) associated with the providers’ identi-

ﬁers (P1 to P3). The y axis presents reputation values

calculated for each user, ranging from 0 to 1, where

value 1 represents the best reputation. By observing

values presented, it is possible to notice that user 14

(U14) who used the services of provider 3, obtained

the highest reputation value among all users, whose

value is close to 85%.

This value is related to the historic average use

of computational resources, since U14 presents the

highest resources use average (Equation 6 when com-

pared to the other users, according Table 1. More-

over, it performs most of the monthly/annuity pay-

ments on time and presents good connection stability,

as it is possible to see in Table 1. In addition, user

14 obtained high average comprising providers’ feed-

back values, despite having a total of 5 pending is-

sues at external sources, as shown in Table 2. Thus,

for this user, objective credibility indicator is 0.87 and

subjective credibility indicator is 0.82, demonstrating

balancing between objective and subjective behavior.

Values shown by Figure 2 for user 12 (U12), who also

used services of provider 3, obtained the lowest repu-

tation value among all users. User 12 reputation value

is close to 62%.

Figure 2: Reputation results.

This value is related to the use of computational

resources, which obtained the lowest average when

compared to the other users, with the accomplishment

of half of the monthly/annuity payments on time, but

with a high value for the connection stability indica-

tor, as can be seen in Table 1. In addition, user 12

obtained a low average of the provider’s evaluation

feedback values, and has a total of 5 pending issues

with external sources, as shown in Table 2. Thus, for

this user, the objective credibility indicators obtained

a value of 0.57 and the subjective credibility indicator

obtained a value of 0.74 Thus, the reputation value

R(s) for this user is 0.444. Weight of each of these

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

380

indicators was deﬁned as 0.7 and 0.3 respectively for

all participating providers.

Results show that it is possible to evaluate the

users reputation based on the use of computational re-

sources.

6 FINAL CONSIDERATIONS

This work proposed a reputation architecture for

cloud providers’ users reputation architecture based

on blockchain consortium model. The proposed ar-

chitecture aims to help cloud providers to prevent re-

source access to malicious users i.e., those whose rep-

utation value is low enough to be considered mali-

cious according to providers security policy deﬁni-

tions. However, it is not restricted to this context and

it can be adapted and used by other computer sys-

tems. Users have their reputations calculated by com-

bining objective and subjective credibility indicators.

The objective credibility indicator is calculated with

the user resources utilization like memory, process-

ing, connection stability and payment. The subjec-

tive credibility indicator is calculated with the data

obtained in external data sources and the providers

feedback regarding user’s activities performed on the

provider. These two indicators make up the reputa-

tion value assigned to each user. Thus, reputation

value can be used by participating providers to as-

sist in their access control decisions. Results were

obtained through simulations performed with hypo-

thetical scenarios. In this way, participating providers

have access to user’s reputation values based on in-

teractions with themselves and with other participat-

ing providers through a shared and collaboratively

maintained reputation architecture. As future work,

tests are being developed with a greater number of

providers and users to assess architecture scalability

and performance.

REFERENCES

Berrached, A. and Korvin, A. (2006). Reinforcing access

control using fuzzy relation equations. In Security and

Management.

Donghong, S., Wu, L., Ping, R., and Ke, L. (2016). Reputa-

tion and attribute based dynamic access control frame-

work in cloud computing environment for privacy pro-

tection. In 2016 12th International Conference on

Natural Computation, Fuzzy Systems and Knowledge

Discovery (ICNC-FSKD), pages 1239–1245.

Du, X., Xu, J., Cai, W., Zhu, C., and Chen, Y. (2019). Oprc:

An online personalized reputation calculation model

in service-oriented computing environments. IEEE

Access, 7:87760–87768.

Greve, F., Sampaio, L., Abijaude, J., Coutinho, A. A.,

Valcy, I., and Queiroz, S. (2018). Blockchain e a

revoluc¸

ao do consenso sob demanda. In Simp

osio

Brasileiro de Redes de Computadores e Sistemas Dis-

tribu

ıdos (SBRC) - Minicursos, chapter 5, page 30. So-

ciedade Brasileira de Computac¸

ao - SBC.

Hendrikx, F., Bubendorfer, K., and Chard, R. (2014). Rep-

utation systems: A survey and taxonomy. Journal of

Parallel and Distributed Computing, 75.

Jansen, W. and Grance, T. (2011). Sp 800-144. guide-

lines on security and privacy in public cloud comput-

ing. Technical report, U.S Departament of Commerce,

Gaithersburg, MD, USA.

Lin, I.-C. and Liao, T.-C. (2017). A survey of blockchain

security issues and challenges. I. J. Network Security,

19:653–659.

Liu, F., Tong, J., Mao, J., Bohn, R., Messina, J., Badger, L.,

and Leaf, D. (2012). NIST Cloud Computing Refer-

ence Architecture: Recommendations of the National

Institute of Standards and Technology (Special Publi-

cation 500-292). CreateSpace Independent Publishing

Platform, USA.

Mui, L., Mohtashemi, M., and Halberstadt, A. (2002).

A computational model of trust and reputation. In

Proceedings of the 35th Annual Hawaii International

Conference on System Sciences, pages 2431–2439,

Big Island, HI, USA. IEEE.

Nakamoto, S. (2009). Bitcoin: A peer-to-peer electronic

cash system,” http://bitcoin.org/bitcoin.pdf.

Nkosi, L., Tarwireyi, P., and Adigun, M. O. (2013). Detect-

ing a malicious insider in the cloud environment using

sequential rule mining. In 2013 International Confer-

ence on Adaptive Science and Technology, pages 1–

10, Pretoria, South Africa. IEEE.

Thakur, S. and Breslin, J. G. (2019). A robust reputation

management mechanism in the federated cloud. IEEE

Transactions on Cloud Computing, 7(3):625–637.

Wu, L., Zhou, S., Zhou, Z., Hong, Z., and Huang, K. (2015).

A reputation-based identity management model for

cloud computing. Mathematical Problems in Engi-

neering, 2015:1–15.

Xu, J., Du, X., Cai, W., Zhu, C., and Chen, Y. (2019).

Meurep: A novel user reputation calculation approach

in personalized cloud services. PLOS ONE, 14(6):1–

15.

Yu, X., Gao, N., and Jang, W. (2010(8)). Research on the

identity authentication technology in cloud comput-

ing. In Information Network Security, pages 71–74.

Zheng, R., Chen, J., Zhang, M., Wu, Q., Zhu, J., and

Wang, H. (2018). A collaborative analysis method

of user abnormal behavior based on reputation voting

in cloud environment. Future Gener. Comput. Syst.,

83(C):60–74.

A Consortied Ledger-based Cloud Computing Provider Users Reputation Architecture

381
