WesterParse: A Transition-based Dependency Parser for Tonal Species

Counterpoint

Robert Snarrenberg

Department of Music, Washington University in St. Louis, One Brookings Drive, St. Louis, MO, U.S.A.

Keywords:

Music Analysis, Melodic Parsing, Tonal Syntax, Algorithmic Analysis, Westergaard.

Abstract:

This article describes the syntax parser that is a principal component of WesterParse, a software program

designed to evaluate tonal species counterpoint in the version developed by Peter Westergaard (1975). The

parser produces interpretations of the pitch-syntactic structure of simple tonal lines. The parser is written

in Python and relies on the

music21

toolkit. Given a simple tonal line of the sort found in Westergaardian

counterpoint, the parser can evaluate its structure and report whether the line is valid. To do so, the parser

compiles a set of possible syntactic interpretations. If asked, the program can display the interpretations in

a notation program such as MuseScore. (A separate component of WesterParse is a voice-leading evaluator

that can test the counterpoint of both simple and combined species for compliance with Westergaard’s rules

of voice leading.) After providing a synopsis of Westergaard’s deﬁnition of simple tonal lines, the article

describes the architecture of the software parser, the scanning process, and the central concept of dependency

relations. The parsing operation is then illustrated using Fux’s Dorian cantus ﬁrmus, and a closer look is taken

at the process for parsing transitions.

1 INTRODUCTION

I have been teaching Peter Westergaard’s species

counterpoint in a class on tonal theory for 25 years.

As in traditional lessons, students compose exercises

and bring them to class for evaluation and feedback.

There is often a time lag of several days between the

act of composition and the reception of feedback, and

days or even weeks may elapse between receipt of

feedback and work on revising the composition. To

give students more frequent and more timely feed-

back, I thought it would be useful if evaluation and

feedback could be built into a software program and

made available at the click of a button, while students

are still in the ﬂow of composing. So I decided to cre-

ate a web-based application to supplement the in-class

experience.

The application consists of a web page where stu-

dent users can compose species counterpoint exer-

cises and a server-based backend that can interpret

data sent from the web page. Stephen Pentecost, from

the Humanities Digital Workshop at Washington Uni-

versity, created the web interface. I wrote the backend

in Python.

https://orcid.org/0000-0001-6705-188X

The user begins by deciding how many measures

of counterpoint to write, how many parts, and what

key signature to use. The webpage then presents the

user with a blank set of staves. The user enters notes

as desired, and a separate edit mode allows the user

to go back and change notes and add or delete mea-

sures. When the exercise is complete, the user can ask

the machine to evaluate the lines or evaluate the voice

leading. Clicking “Evaluate Lines” sends a represen-

tation of the line in MusicXML to a parser, which then

evaluates the construction of the lines and returns a

report that is displayed on the web page. The report

indicates whether the lines are generable according to

Westergaard’s rules and, if not, where errors were en-

countered. A similar report is issued when the user

clicks “Evaluate Voice Leading.”

This article describes the backend software

component that evaluates individual lines, the

so-called parser. Readers interested in testing

the parser and counterpoint evaluator may visit

talus.artsci.wustl.edu/westerparse/. The full code for

WesterParse is freely available on github.com/snar-

renberg/westerparse. Documentation of the software

is available at westerparse.readthedocs.io.

Snarrenberg, R.

WesterParse: A Transition-based Dependency Parser for Tonal Species Counterpoint.

DOI: 10.5220/0010482606690679

In Proceedings of the 13th International Conference on Computer Supported Education (CSEDU 2021) - Volume 1, pages 669-679

ISBN: 978-989-758-502-9

669

2 WESTERGAARDIAN LINES

In the early 1970s Westergaard developed an ap-

proach to teaching tonal music theory centered on

the cognition of linear syntax and counterpoint rather

than chords and harmony. The goal was to give the

student “the ability to understand the complex and

varied voice-leading patterns of actual eighteenth-

and nineteenth-century music in terms of the simpler

patterns available under the artiﬁcial constraints of

species counterpoint” (Westergaard, 1975, vii).

One thing that distinguishes Westergaard’s ap-

proach to species counterpoint from traditional forms

is the rigorous fashion in which the individual line is

regarded as (and constructed to be) “an entity with

its own structure, unfolding in time” (Westergaard,

1975, 29). In Westergaard’s formulation, the simple

tonal lines of species counterpoint are constructed by

applying rules that generate notes with certain order-

dependent functions (see Appendix). These genera-

tive rules constitute a syntax for simple tonal lines.

The forms of simple linear structure are based on

those that Schenker posited as the components of the

Ursatz: a primary upper line and a bass line. The ker-

nel structure of a primary upper line consists of three

functions: a tonic pitch that acts as the ﬁnal element of

the structure (rule A1); a tonic-triad pitch that lies in

the register above the tonic pitch and acts as the initial

structural element (A2); and pitches in the scale that

ﬁll the span between the initial and ﬁnal elements with

a complete stepwise motion (A3). Bass lines have a

kernel structure consisting of an arpeggiation from the

tonic degree (A2) to the dominant (A3) and on to an-

other tonic degree (A1). (Westergaard adds a third,

less constrained type of line that begins and ends on a

tonic-triad pitch; I call this a generic line.)

The kernel structures may be elaborated by the

addition of syntactically dependent elements: tonic-

triad pitches may be repeated (B1), new tonic triad

pitches may be inserted (B3), and stepwise transi-

tions may be created between consecutions of iden-

tical pitches (neighboring motions, B2) or different

pitches (passing motions, B4).

Figure 1 shows howa melody familiar to countless

generations of species counterpoint students might be

constructed as a bass line using Westergaard’s rules,

starting with the A-rules at the top and proceeding

level by level until all the notes of the line have been

generated.

Simple lines are rhythmically uniform and relatively

brief. The syntactic system for complex, rhythmically dif-

ferentiated lines involves rhythmically and contrapuntally

sensitive rules. Parsing the syntax of such lines lies outside

the scope of this project.

"# $

¯ ¯

Figure 1: Constructing Fux’s Dorian cantus ﬁrmus as a

Westergaardian bass line.

3 THE PARSER

The interpretation of Fux’s Dorian cantus ﬁrmus

shown in Figure 1 builds the line, as it were, note by

note, from the root node at the end of the line to the

most deeply embedded, dependent notes in the mid-

dle. The top-down structure resembles a syntax tree.

To arrive at such an interpretation, however, the soft-

ware parser (or the human interpreter) has to begin

with the given line of notes (the utterance) and then

derivean interpretation, determining what rule is used

to generate each note. And if there is more than one

way to parse the syntax of the line, the parser ought

to generate multiple interpretations.

The parser is designed to model the cognitive pro-

cess of auditive interpretation, which occurs in time

as the melody unfolds note by note. It is not a simple

process. In fact, a listener cannot begin to attribute

syntactic structure reliably to a melody without also

determining what triad and scale to use as frames of

reference. In the case of Fux’s melody, it takes a few

notes before a listener can grasp the mode and triad.

The process might run something like this. A listener

CSME 2021 - 2nd International Special Session on Computer Supported Music Education

670

assumes that the ﬁrst note at the very least belongs

to the tonic triad, unless evidence accumulates to the

contrary. But which scale degree is it?

3, or

5? Af-

ter hearing the second note, the number of possibili-

ties is reduced, for the only plausible interpretations

of the two notes are

3 and

5. And after hearing the

third note, there is no doubt: this is a line in the mi-

nor mode that starts with

2. A preliminary stage

of parsing, then, involves the selection of such frames

of reference as a plausible context for the syntactic

interpretation.

The parser must also keep track of notes and

all their contextually derived properties and syntac-

tic functions. From a software standpoint, this re-

quires an object-oriented programming language. I

built the parser in Python in order to take advantage

of the

music21

toolkit developed at MIT by Michael

Cuthbert and his colleagues.

A signiﬁcant advan-

tage of

music21

is that its already robust collection

of musical objects and relations is easily extensible.

The parser accepts input in the form of a MusicXML

source ﬁle, which is then converted by the

music21

toolkit. After conversion, the program can access the

content in the source ﬁle in a variety of ways: parts,

measures, notes, simultaneities, and so forth. Thanks

to the design of

music21

, it is a relatively simple mat-

ter to extract the line of notes in each part of a contra-

puntal exercise for parsing.

The basic architecture of the parser is borrowed

from computational linguistics. It is modeled on soft-

ware that processes a sentence word by word and out-

puts a syntactic model, a so-called “transition-based

dependency parser.” In simple terms, this kind of

parser examines the transitions from word to word in

a sentence and decides at each point whether two ad-

jacent words are syntactically related as head and de-

pendent (or, vice versa, as dependent and head), or

whether to keep looking for such connections. Since

dependency relations are rather different in music, I

wrote all the interpretive routines from scratch

Figure 2 shows the basic architecture of the parser.

The process begins with an input buffer, loaded with

all of the notes in the line, and a stack, which is

empty. A simple scanning function shifts notes from

the buffer onto the stack, one at a time, until the buffer

is exhausted. At each step, the transition parser exam-

ines the top element of the stack and the next element

in the buffer and selects an action based on examina-

(Cuthbert and Ariza, 2010); see http://web.mit.edu

/music21/doc/index.html.

While many linguistics parsers now use machine learn-

ing methods and a set of training data, WesterParse takes an

algorithmic approach, based on a set of rules for generating

lines and a set of preferences for interpreting lines.

b0 b1 b2 …

transition

parser

parse

input bufferstack

open heads

open transitions

dynamic lists

… s2 s1 s0

dependency

relations

Figure 2: The architecture of WesterParse’s line parser.

tion of the current interpretive state.

In addition to the stack and the input buffer, the

parser maintains a set of dynamic lists (open heads,

open transitions) and a partial parse of the line. The

dynamic lists keep track of open syntactic relations.

They change in content during the course of interpret-

ing the line. On the list of open heads are all the notes

that can currently initiate a new step motion or get

repeated. The list of open transitions contains notes

that are in yet-to-be-completed step motions. Think

of the opening notes of Fux’s cantus ﬁrmus, D F E.

At this point, the parser has placed D and F on the list

of notes of available heads and has decided that E is

an open transition, on its way somewhere. The parser

has also decided that E is stepping awayfrom F, which

is to say, E depends on F. As the line transitions from

one note to the next, the parser is beginning to ﬁgure

out dependency relations among the notes, hence the

name of transition-based dependency parser.

The dependency relations make up the content of

the interpretation, the so-called parse. So, what is

meant by dependency relations? Take a consecutive

pair of notes, X and Y. We will say that Y is syntacti-

cally dependent upon X if X is mentioned in the syn-

tactic description of Y. We will also say that X stands

“to the left” of Y. If we ﬁnd that Y repeats X, then Y is

dependent on X. Repetitions are always dependent on

a lefthand note, a so-called lefthead. Passing tones,

by contrast, are dependent upon notes to the left and

the right. They have a lefthead and a righthead.

Take

the succession [F E D]. One possible syntactic inter-

By contrast, the linguistics parsers described in (Juraf-

sky and Martin, 2008, Chapter 13, “Syntactic Parsing”) ex-

amine the top two elements of the stack. In the linguistics

parsers, the syntactic category of each element has already

been assigned prior to parsing, whereas WesterParse assigns

and revises syntactic classiﬁcations during the parsing pro-

cess itself.

This is a signiﬁcant point of difference between lan-

guage and music. In language, each word other than the

root note has but a single head, and so linguistic dependency

can be represented in strictly binary trees or graphs. In mu-

WesterParse: A Transition-based Dependency Parser for Tonal Species Counterpoint

671

lefthead righthead

dependents

simple passing and

neighboring motions

longer passing motions

repetitions

incomplete neighbors

and anticipations

Figure 3: Four types of arc.

pretation of the succession is this: “E passes between

F and D.” Under this interpretation, F and D are men-

tioned in the description of E. F is the lefthead of E.

D is the righthead of E. And E is a dependent of both

F and D.

A set of notes interconnected by dependency re-

lations forms an arc. Arcs are of several types (see

Fig. 3): some arcs, like passing and neighboring mo-

tions, have heads to the left and the right with depen-

dents in between. Others have only a lefthead (e.g.,

repetition), and some notes (e.g., insertions) do not

have a head, per se. In more complex tonal lines, it is

possible that an arc might have only a righthead (e.g.,

incomplete neighbor or anticipation). As the parser

works its way through the line, then, it sets depen-

dency attributes for each note, storing the informa-

tion in a custom Dependency object that is attached

to each note in the parse. As completed arcs accumu-

late, they are stored in a Parse object.

The parser also needs to keep track of other vari-

ables and properties of notes (see Fig. 1). At the out-

set, it needs to set some global variables: the name of

the keynote and the mode, from which the tonic triad

and scale can be inferred. This is currently handled

by a separate software component that infers the key

of the source input using a set of custom algorithms.

(The web application also allows the user to input a

key and thus override the keyﬁnding algorithm.)

Keyﬁnding is a crucial ﬁrst step, since the parser

also needs to know the scale degree function of each

pitch. This is stored in another custom object called

Concrete Scale Degree (CSD). We are used to think-

ing of scale degrees as scale-degree classes, assigning

all tonic degrees to the class “scale degree one,” but

it has proven helpful to have a more concrete scale

degree function, one that distinguishes between, say,

sic, however, some notes are clearly transitional between an

earlier and a later note. Restricting theory to binary rela-

tions leads to false dependency choices, as can be seen, for

example, in Lerdahl and Jackendoff’s account of neighbor-

ing motions (see (Lerdahl and Jackendoff, 1983, 113–14,

185–87)).

Table 1: A partial ontology of WesterParse.

Object Classes Attributes Values

Context parts Part

key Key

Key keynote Pitch

mode major, minor

Part notes Note

id 0, ..., n

Note pitch A, .. ., G

index 0, .. ., n

Concrete value . .., –1, 0, 1, . ..

Scale degree .. .,

2, .. .

Degree direction ascending,

descending,

bidirectional

Dependency lefthead None, or Note index

righthead None, or Note index

dependents None, or Note inidices

Rule name A1, .. ., B1, ...

level 0, .. ., n

Parse linetype primary, bass, generic

arcs lists of Note indices

open heads Note indices

open transitions Note indices

1 and

8; this distinction allows the parser to hear

as adjacent to

8 but not to

1. The CSD stores a value

representing the distance of a particular pitch from the

core tonic degree. Scale degrees also have have direc-

tionality: in the minor mode, some degrees are bidi-

rectional, some are ascending, and some descending.

The parser will need to know, for example, that raised

6 is bidirectional but diatonic

6 is strictly descending.

When the parse is ﬁnished, the parser assigns a

Rule object to each note in the line. This object stores

the name of the note’s syntactic function and its struc-

tural level.

4 THE PARSING PROCEDURE

Let us look at how the parser works its way through

Fux’s Dorian cantus ﬁrmus. The ﬁrst half of the pro-

cess is illustrated in Figure 4. To initialize the parser,

the ﬁrst note D is moved onto the stack and is also

added to the list of open heads; at this stage there

are no open transitions and no completed arcs. From

this initial state, the parser scans forward, listens to F

(state 1), and adds F to the list of open heads. The

parser scans forward again (state 2), listens to E, and

adds it to the list of open transitions.

Several things happen after the parser hears the

fourth note, D (state 3). The parser connects E to this

D as a righthead and then listens back through the list

of open heads, searching for a lefthead. The parser

is biased toward ﬁnding a lefthead in proximity, so it

looks no further than F. The parser then creates an arc,

CSME 2021 - 2nd International Special Session on Computer Supported Music Education

672

‰

”

Figure 4: Parsing Fux’s Dorian cantus ﬁrmus, states 0–5.

[F E D], which is added to the parse.

Meanwhile, E

is removed from the list of open transitions and the

most recent D is added to the list of open heads.

The parser listens to G (state 4). Realizing that

the only available precursor to G is the F, it removes

the intervening D from the list of open heads. The

list is pruned, we might say. The parser also adds G

to the open transitions. When it listens to F (state 5),

it makes an arc [F G F], adds this arc to the parse,

and then prunes back the list of open transitions. In

general, when the parser ﬁnds an arc, it prunes interior

elements from the list of open transitions and prunes

embedded heads from the list of open heads.

In subsequent stages, shownin Figure 5, the parser

hears A and adds it to the list of open heads, then hears

G and adds it to the list of open transitions. Upon

hearing F (state 8), the parser uses it as the righthead

of a new arc, [A G F], adding F to the open heads, and

In the musical representations of the parses, notes of

the basic structure are identiﬁed by rule number, ties con-

nect repetitions to their heads, slurs connect the notes of a

stepwise motion, and parentheses enclose insertions.

removing G from the list of open transitions. Upon

hearing E (state 9), the parser adds it to the list of

open transitions. When the parser hears the ﬁnal D

(state 10), it creates an arc, [F E D], adds the ﬁnal D

to the open heads, and removes E from the list of open

transitions.

The parse, at this stage, is nevertheless incom-

plete. The parser has compiled a list of line segments

(arcs), but at least one note (the ﬁrst) does not be-

long to any arc, and the arcs are not yet integrated into

an overarching structure. To integrate the arcs into a

complete interpretation, the parser has to decide what

type of line it wants to hear.

Suppose that the parser is told to see whether the

line makes sense as a bass line. If so, the line will

have to end and begin on a tonic pitch, and in be-

tween the beginning and the end it will have to touch

5. The rules imply that these three notes are con-

ceptually prior to all other notes in the line. Which is

to say, they are not dependent upon any other notes.

In the way that the rules are framed, A1 is something

like a root node. A2 is partially dependent on A1 (at

least in terms of order), and A3 is dependentupon A1.

WesterParse: A Transition-based Dependency Parser for Tonal Species Counterpoint

673

‰

”

‰

¯ ¯

‰

”

‰

Figure 5: Parsing Fux’s Dorian cantus ﬁrmus, states 6–10.

Ideally, the parser would look for this structure as

it proceeds through the notes of the line. And a fu-

ture version of the parser may incorporate simultane-

ous parsing of basic structure, but for now the proce-

dure has been relegated to what we might think of as

a retroauditive parse.

Once the buffer is empty, the parser scans the line

again, looking for notes that could function in a basic

structure, assuming that the line is of a certain type

(bass, primary, generic). The parser is somewhat in-

telligent. It knows that it only needs to look at notes

that are not dependents of others, so at this stage it

uses just the list of open heads that remained in play

at the end of the initial parse. The parser examines

these open heads and assembles lists of candidates for

each of the structural components (A1, A2, A3) and

then tries to generate an interpretation for each list.

The parser now has something to say about the

function of the ﬁrst note in Fux’s cantus ﬁrmus: it

functions as “the initial pitch of the bass arpeggia-

tion,” rule A2. Looking for A1 in a bass line is only

a matter of conﬁrming that the last note is a tonic de-

gree. The only remaining question is whether there

are any candidates for A3. What the parser discovers

in this particular case is that there is only one candi-

date: the A in the middle of the line. Hence the parser

generates a single parse of the cantus ﬁrmus as a bass

line (see Fig. 6).

What if we ask the parser to see whether the can-

tus ﬁrmus makes sense as an upper line? Like bass

˜¯

‰

”

¨¯

Ś´ 5

Figure 6: Parsing Fux’s Dorian cantus ﬁrmus as a bass line.

lines, primary upper lines must end on the tonic de-

gree. But while bass lines must start on the tonic

degree, primary upper lines can begin on other tonic

triad pitches. And the initial note of the line need not

be the note that functions as A2. The rule speciﬁes

that at some point, the upper line has to reach a tonic-

triad pitch (

5, or

8) that lies above A1. Rule A3

speciﬁes that A2 has to then be connected to A1 via

a continuous, descending step motion. In effect, there

are three options, corresponding to the three forms of

the Urlinie posited by Schenker. As with the bass line,

the notes that function as A2, A3, and A1 must be

conceptually prior to all other notes in the line.

The task for our parser, then, is to ﬁgure out

whether there are any candidates for A2 and then to

ﬁnd out which of these candidates, if any, can be con-

nected to A1 via a step motion. It turns out that Fux’s

Dorian cantus ﬁrmus is structurally ambiguous when

taken as a primary upper line. There are several can-

didates for A2: any of the Fs and also the A. Our

parser considers it more plausible to take the ﬁrst of

the Fs as a candidate. Which is to say, our parser has

a preference for interpreting later instances of a pitch

as repetitions, operating on the principle that it is eas-

ier to interpret the future in terms of the past than vice

CSME 2021 - 2nd International Special Session on Computer Supported Music Education

674

versa. Figure 7 shows the parse that results when F is

the candidate for A2.

˜¨¯

‰

”

‰

Figure 7: Parsing Fux’s Dorian cantus ﬁrmus as a primary

upper line from

Our parser has other preferences built into it. The

reader may have noticed in the initial run of the parser

that the span after the high A was interpreted as an arc

from A down to F followed by an arc from F down to

D. Our parser, however, considers it simpler to hear

this span not as two arcs but as a single arc, a single

step motion from A down to D, and will do so if it

can. Of course, if F is functioning as A2, then it has

priority, and our parser hears the line as returning to

F instead of passing through it. But if the parser tries

out the A as a candidate for A2, it will fuse that span

into a single arc, as shown in Figure 8.

˜¨¯

˜¯

‰

”

¨¯

"# $

Figure 8: Parsing Fux’s Dorian cantus ﬁrmus as a primary

upper line from

5 PARSING TRANSITIONS

The parser is principally concerned with evaluating

transitions from one note to the next. So let us look

a little closer at how the parser goes about this work.

Let us call the notes I and J. The parser asks a series

of questions having to do with I and J: their relation

to the tonic triad, their intervallic relation, and the dy-

namic lists of open heads and transitions. Based on

the answers, the parser assigns dependency relations,

creates arcs where warranted, or returns error mes-

sages if the line is syntactically malformed.

The ﬁrst questions asked of I and J are simple: Is

I a tonic-triad pitch? Is J a tonic-triad pitch? If both

are triad pitches, then the parser looks to see whether

J can be the terminus of any open transitions; if I and

J are identical in pitch, then J is interpreted as a repe-

tition of I, else J is added to the list of open heads.

If either I or J is not a triad pitch, the parser

looks to see whether the interval between I and J is

a diatonic step or a consonant skip. (The parser is

trained to think that simple tonal lines have no dis-

sonant skips, so if it encounters a dissonant skip be-

tween I and J, it decides that the line is syntactically

malformed and returns an error message to that ef-

fect.) The parser then considers whether there are any

open transitions or open heads.

If neither I nor J is a triad pitch, the parser looks

at their intervallic relation. If they form a skip of any

kind or a repetition, the parser rejects the line as syn-

tactically malformed, since the rules do not permit a

skip or repetition between non-triad pitches.

If they

form a step, the parser tries to interpret them as part

of a single step motion.

In melodic minor, the parser has to pay special

attention to the directionality of scale degrees. The

parser is designed to hear raised

7 as either the lower

neighbor to

8 or an ascending passing tone, so when it

listens to the line in Figure 9a, it resists thinking that

the F♯ is part of a descending passing motion. The

parser instead honors the upward directionality of F♯

by keeping it on the list of open transitions until G

returns. But it must decide how to interpret the E♮.

4¯

6¯

Ś´ 2

4¯

6¯

”

Figure 9: Some special cases in melodic minor.

Consider ﬁrst how the parser would handle the

line if the notes were F♮ and E♭ (Fig. 9b). In this case,

the line steps down twice, and those descents match

the directionality of the two scale degrees. F was al-

ready interpreted as a dependent of G and has G as its

lefthead, so when the parser hears E♭, it connects it to

F, because it has the same directionality, and adds all

of F’s dependencies to E♭; it also adds E♭ to F’s list of

dependents and vice versa. The parser then removesF

from the list of open transitions. F has been displaced.

When it hears D, it makes D the righthead of E♭ and,

by extension, F, as shown in Figure 9c.

In the original case, the descending step from F♯

to E♮ contradicts the directionality of F♯. So the parser

makes E♮ dependent on F♯, but that is as far as it goes;

F♯ is assigned as the lefthead of E but remains on the

list of open transitions. In other words, E♮ is not in-

tegrated into a step motion with F♯ because the line

is not going in the right direction for that: F♯’s arc

must go up by step. The resulting parse is shown in

In the version of third species that I teach, consonant

skips between non-tonic-triad pitches are permitted within

the measure, so the parser has been built to allow for this

possibility.

WesterParse: A Transition-based Dependency Parser for Tonal Species Counterpoint

675

Figure 9d.

A version of the line shown in Figure 10a was sub-

mitted by a student, and the parser initially rejected

it, saying that the A was not generable in the key of

C major (Fig. 10b). This is because the parser has a

built-in bias for resolving transitions as soon as possi-

ble. So when the parser heard the second C, it de-

cided that B was a lower neighbor and removed B

from the list of open transitions. And then, when it

subsequently heard A, it did not know what to make

of it: there was no B on the list of open transitions

that could link to A, and there was no G on the list of

open heads that could link to A.

˜¨¯

Ś´ 4

Figure 10: A case of retrospective reinterpretation.

The parsing algorithm thus had to be revised. Now,

upon hearing A, the parser takes an extra moment

to forget the partial parse it has constructed. First it

clears the dependency relations. Then it selectively

forgets the second C and starts over, loading all of

the notes back into the buffer, with the exception of

C, and listening again. Now it can hear the step con-

nection between B and A. Later on it ﬁgures out that

the intervening C was an independent insertion, an in-

terjection, as it were, resulting in the parse shown in

Figure 10c. In this respect, the parser’s activity mim-

ics the phenomenology of acts of listening, in which

interpretations are developed and then revised as new

information becomes available in audition.

As already mentioned, the parser is biased toward

simpler interpretations. So one of the things it will

do is look to see whether there are two passing mo-

tions that share an inner node and direction. If so, it

will merge them into a single arc and revise the de-

pendency relations accordingly (Fig. 11a).

Likewise, if a neighbor motion is linked to a passing

motion, the parser will embed the neighbor structure

within the passing, making them both share the same

lefthead (Fig. 11b).

Finally, consider the line fragment shown in Fig-

ure 12a. If this sequence of notes is embedded in a

line that is in the key of D major, the parser needs

to know how to handle the change of direction af-

ter B, which implies that there are two transitions in

‰

ąF



Śˆ D

Figure 11: Two examples of bias toward simplicity.

progress, one of which attaches the B to an A, either

as a left head or right head.

˜¯

‰

ąD

‰

¨¯

Ä!

Figure 12: Handling a change of direction in mid-transition.

The parser therefore needs to consider whether there

is an A already on the list of open heads, in which

case it will interpret the B as a passing tone rising up

to the second D (Fig. 12b); failing that, it will need to

wait and see whether there is an A later in the line that

can serve as a right head, making the B a descending

passing tone from the ﬁrst D (Fig. 12c). In each case,

the B also serves as the head of a subordinate transi-

tion to or from an inserted D.

6 IMPLEMENTATIONS OF

WESTERPARSE

The main implementation of WesterParse is the web-

based pedagogical application for composing and

evaluating exercises in species counterpoint. This ap-

plication provides the student user with reports on the

syntactic validity of the individual lines and on con-

formity with the voice leading rules. If the parser

ﬁnds that a line is syntactically invalid, it reports that

fact and gives a few hints as to the nature of the syn-

tactic problem, which the student must then solve on

their own. If it ﬁnds a line is valid, it simply re-

CSME 2021 - 2nd International Special Session on Computer Supported Music Education

676

ports that fact without providing any details on how

the line can be constructed using Westergaard’s rules;

the student must then download the composition as

a MusicXML ﬁle, open it in a music notation edi-

tor, and add annotations to indicate how the line is

constructed; this ensures that the student has internal-

ized the syntax rules. Voice leading reports detail all

infractions, but it is left to the student to ﬁgure out

how rectify matters. The student can also compose

ofﬂine in music notation editor and then upload a Mu-

sicXML ﬁle to the WesterParse site for testing.

WesterParse can also be deployed ofﬂine in a

Python environment. In this implementation, in-

tended for music theorists, the user inputs a Music-

XML ﬁle and has the option of sending the full set

of legitimate parses to be displayed in a notation pro-

gram. (I use the freeware program MuseScore, but

just about any program that accepts MusicXML ﬁles

could be used.) Having the option to display the full

set of ﬁnal-state interpretations allows the user to as-

sess the reliability of the algorithms. The parser in

this implementation also logs every step of the pro-

cess, thus allowing the user to access all of the inter-

mediate states, like those shown in Figures 4 and 5.

7 THE WESTERPARSE CORPUS

A corpus of examples drawn from Westergaard’s text

was compiled in order to test the validity of the

WesterParse algorithms: 48 single lines and 29 com-

plete examples of species counterpoint. WesterParse

produces some minor deviations from Westergaard’s

analyses, attributable to minor differences in handling

ambiguity. Westergaard, for example, allows rule A1

to attach to a nonﬁnal pitch, whereas WesterParse

does not. On the whole, however, WesterParse re-

produces Westergaard’s analyses, where they are pro-

vided. The corpus also includes an additional col-

lection of 27 lines and 41 counterpoint compositions,

some of my own invention and others written by stu-

dents. Further testing was performed by a group of 11

students in my Fall 2020 music theory class.

Three samples from the corpus are shown in Fig-

ure 13. The ﬁrst of these is taken from Westergaard’s

text, where it is intended to illustrate various issues

involving similar motion to a perfect ﬁfth. The upper

line is interesting for the way in which the arrival of

B♭ in bar 7 requires the parser to reinterpret the arcs;

having previously decided that the E in bar 2 passed

to the F in bar 6, it must then reject that arc in order

to connect B♭ to the A in bar 3, effectively postponing

the resolution of E until the line arrives on F in bar 11.

The bass line is notable for the long descent from D to

A, interrupted by a number of secondary structures.

The bass line of the second example also requires

the parser to revise its interpretation in midstream.

The B in bar 4 initially seems to resolve the pass-

ing C in bar 2, but the low D♯ puts that into ques-

tion, requiring that the preceding B be demoted to an

insertion, and restoring the C to the list of open transi-

tions where it will remain until the arrival of B in bar

6. Shown here is one of the two interpretations that

WesterParse generates for the upper line; the other

takes the initial G as A2.

The upper line of the third example illustrates

some of the complexities of third species, where the

rules allow for the elaboration of local harmonies, as

can be seen in bars 5 and 7.

8 EXTENDING WESTERPARSE

Plans for further development of the WesterParse ped-

agogical environment include allowing the student

user to add a syntax interpretation to a line and having

the parser determine whether it is legitimate.

A longer-range goal is to incorporate Wester-

gaard’s analysis of the rhythm of linear elaborations

(chapters 3 and 7), and thus give the parser the abil-

ity to analyze rhythmically differentiated lines. In

order to handle longer lines, the contextualizer will

need to incorporate some form of grouping structure

constraints. Some of the computational challenges of

implementing this sort of analysis are addressed in

(Marsden, 2010).

Developing WesterParse into a program that can

parse more complex lines that unfold in a contrapun-

tal texture will require additional components. One

such component must be a stream segregator that is

able to sort simultaneous notes into different lines. If

the input source is a MusicXML ﬁle that is already

divided into single-line parts, as it is in the web ap-

plication, stream segregation is relatively simple. For

more complex contexts, the segregator needs to have

additional abilities. It needs to be able to split simulta-

neously sounding notes into separate streams.

It may

also need to monitor the texture, deciding when an ad-

ditional simultaneous note is supplemental and when

it is the inauguration of an additional stream. The seg-

regator also needs to be able to determine whether a

stream is a compound line; if so, it will need to ex-

tract the pitches of the compound line and re-assign

For a review of relevant literature on computational

stream segregation and a discussion of a neural network

model for automatic voice separation, see (Weyde and

de Valk, 2015). Also see (Temperley, 2009).

WesterParse: A Transition-based Dependency Parser for Tonal Species Counterpoint

677

4¯

˜¯

˜¨¯

˜¯

şĄ ”

¨¯

˜¨¯

ﬂ

¨¯

Ś´ 3

˜¨¯

áŤ s

ôŽ a

˜¯

˜¨˘

Ác

¨¯

ŚĄ E

¨˘

áˆ t

4˘

ò¸ r

’

ÃĄ ”

Ś˜ 2

˜¨

ﬀ

¨4

Figure 13: WesterParse’s ﬁnal-state interpretation of three sample exercises.

them to new notes with new timespans. The segre-

gated streams are then sent on to individual parsers.

A contextualizer needs to gather information from

the parsers, store relevant information about the con-

text, and then share that information among the

parsers. For example, the parsers need to provide in-

formation that can be used to determine the tonality

of the passage. The contextualizer collects and ana-

lyzes information at the outset to determine a likely

candidate for the tonic triad and the mode of the pas-

sage. This is information that belongs to the global

context. Each parser uses this information to deter-

mine the structure of its line.

If the input is a musical passage of harmonically

rich counterpoint, the contextualizer also needs to

maintain a list of local contexts. We might know that

a particular span, for example, unfolds within a tonic

triad, while the next span unfolds within a dominant

triad, and so forth. The parsers need to know this in

order to determine whether a pitch is to be generated

as triad pitch (rules B1 and B3) or as a transition (rules

B2 and B4). The same pitch might be generated by

one or the other category of rule, depending upon the

context. The parsers will also have to maintain local

lists. As long as a parser is interpreting a line solely in

terms of the global tonic triad, it only needs to main-

tain one list of open heads and one list of open tran-

sitions. But if local contexts are engaged, it needs to

maintain similar lists for each context, in addition to

the global lists. It needs to be able to tell, for exam-

ple, whether a note during the dominant span is part

of a local transition or whether it belongs to a global

transition.

The contextualizer should also handle negotia-

tions among parsers in cases where one or more lines

is structurally ambiguous (as is the case with the Fux’s

Dorian cantus ﬁrmus). The contextualizer would also

be responsible for deciding when a passage modulates

into a new key, gathering input from the individual

parsers as they encounter interpretive anomalies in the

current key and then negotiating a new state of agree-

ment. And the contextualizer must be responsible for

inferring the meter and any changes to the metrical

system.

REFERENCES

Cuthbert, M. S. and Ariza, C. (2010).

music21

: A toolkit

for computer-aided musicology and symbolic music

data. In Downie, J. S. and Veltkamp, R. C., editors,

11th International Society for Music Information Re-

trieval Conference (ISMIR 2010), pages 637–42.

Jurafsky, D. and Martin, J. H. (2008). Speech and Language

Processing. Pearson Prentice Hall, 2nd ed. edition.

Lerdahl, F. and Jackendoff, R. (1983). A Generative Theory

of Tonal Music. MIT Press.

See (Temperley, 2007) for a review of literature on

parsing meter and modulations as well as proposed solu-

tions.

CSME 2021 - 2nd International Special Session on Computer Supported Music Education

678

Marsden, A. (2010). Schenkerian analysis by computer: A

proof of concept. Journal of New Music Research,

39(3):269–89.

Temperley, D. (2007). Music and Probability. MIT Press.

Temperley, D. (2009). A uniﬁed probabilistic model for

polyphonic music analysis. Journal of New Music Re-

search, 38(1):3–18.

Westergaard, P. (1975). An Introduction to Tonal Theory.

Norton.

Weyde, T. and de Valk, R. (2015). Chord- and note-based

approaches to voice separation. In Meredith, D., ed-

itor, Computational Music Analysis, pages 137–54.

Springer.

APPENDIX

Westergaard’s rules for the construction of simple,

monotriadic lines. A-rules construct the basic struc-

ture. B-rules add secondary structures.

Primary upper lines: the basic step motion

A1. The ﬁnal pitch in the basic step motion must be a tonic.

A2. The ﬁrst pitch in the basic step motion must be a tonic

triad member a third, ﬁfth, or an octaveabove the ﬁnal pitch.

A3 These two pitches must be joined by inserting the

pitches of intervening diatonic degrees to form a descending

step motion.

Bass lines: the basic arpeggiation

A1. The ﬁnal pitch of the basic arpeggiation must be a tonic.

A2. The ﬁrst pitch of the basic step arpeggiation must be a

tonic.

A3. The middle pitch of the basic step arpeggiation must be

a dominant either a ﬁfth above or a fourth below the ﬁnal

tonic.

Secondary structures

B1. Any triad pitch may be repeated.

B2. A neighbor may be inserted between consecutive notes

with the same pitch.

B3. Any triad pitch may precede the ﬁrst pitch [of the basic

step motion] or may be inserted between any two consecu-

tive pitches so long as no dissonant skip and no skip larger

than an octave is created.

B4. Any two consecutive notes forming a skip may be

joined by a step motion.

WesterParse: A Transition-based Dependency Parser for Tonal Species Counterpoint

679
