Resolving Confusion of Unknowns in Autonomous Vehicles: Types and

Perspectives

Kaushik Madala and Hyunsook Do

Department of Computer Science and Engineering, University of North Texas, Denton, U.S.A.

Keywords:

Safety Of The Intended Functionality (SOTIF), ISO 21448, UL 4600, Machine Learning Safety, Autonomous

Vehicle Safety, SAE Level 5 of Driving Automation.

Abstract:

Autonomous vehicles are susceptible to unknowns. In particular, vehicles with SAE level 5 of driving au-

tomation, which need to operate in complex operational design domain (ODD) conditions, have a very high

chance to face unknowns. While the industrial standards ISO 21448 and UL 4600 hint at analyzing unknowns

from the analysts and engineers’ perspective, the unknowns from different perspectives such as a autonomous

vehicle or a machine learning model within an autonomous vehicle can differ from those perceived by en-

gineers and analysts. In this paper, we discuss the different types of unknowns considering three different

perspectives: analysts and engineers, autonomous vehicles, and machine learning (ML) models. We also clar-

ify the often confused concepts of unknown knowns and unknowns unknowns for each perspective. Using a

running example, we show how considering unknowns from different perspectives will aid in designing a safe

autonomous vehicle.

1 INTRODUCTION

Autonomous vehicles have gained great attention in

recent years. The eventual goal of autonomous ve-

hicles is to reach driving automation of SAE level

5 (Committee et al., 2018), where the vehicles shall be

able to operate autonomously and safely at any loca-

tion without human feedback/intervention. Operating

anywhere requires engineers of the autonomous vehi-

cles to consider a complex operational design domain

(ODD) (BSI/PAS, 2020). This requires engineers to

explicitly consider the various environmental factors

(e.g., snow, rain), road infrastructural elements (e.g.,

trafﬁc signs, road arrow markings), road types (e.g.,

freeway, straight road), and other road users (e.g.,

skateboarders, pedestrians). Note that every element

of ODD can have various attributes.

For example, a pedestrian can have attributes such

as race, gender, type of clothing, and color of cloth-

ing. Considering all the possible values of these at-

tributes and analyzing their effect on safety of a sys-

tem can be challenging. Further, it is possible to over-

look some of the elements or attributes and to have

certain ODD elements that are not widely known as

these elements are speciﬁc to a few locations. This

makes autonomous vehicles susceptible to unknown

scenarios and situations (Hejase et al., 2020) - both

unknown knowns and unknown unknowns (Pickard

et al., 2010). These unknowns can compromise the

safety of the vehicles. Hence, autonomous vehicles

must be designed taking unknowns into account. In

this paper, we simply refer unknown scenarios and

situations as unknowns.

Finding unknowns can be challenging because un-

knowns are highly perspective dependent. The indus-

trial autonomy safety standards ISO 21448 (ISO/PAS,

2019) and UL 4600 (ANSI/UL, 2020) stress the need

for analyzing unknowns and reducing the hazards

that can be caused by the unknowns. Both the stan-

dards mostly refer to unknowns from the viewpoint

of the engineers and analysts who design and analyze

the safety of the system, respectively. However, un-

knowns can also be considered from the perspective

of autonomous vehicles and machine learning models

used in those autonomous vehicles.

For example, let us consider a trafﬁc sign detec-

tion machine learning model in an autonomous vehi-

cle. If the trafﬁc sign detection model is identifying

trafﬁc signs correctly in one frame but not the subse-

quent frame, then the causes for such behavior can be

unknowns to the engineers and analysts. This can be

due to one of the following reasons: 1) the engineers

and analysts might not be familiar with the factors

affecting the trafﬁc sign detection model’s inference,

and 2) the run-time occurrence of such behaviors by

646

Madala, K. and Do, H.

Resolving Confusion of Unknowns in Autonomous Vehicles: Types and Perspectives.

DOI: 10.5220/0010482106460653

In Proceedings of the 7th International Conference on Vehicle Technology and Intelligent Transport Systems (VEHITS 2021), pages 646-653

ISBN: 978-989-758-513-5

the trafﬁc sign detection model might not have been

exposed to engineers and analysts. On the other hand,

if the machine learning model is not trained to detect

pedestrians, then pedestrians are unknowns to the traf-

ﬁc sign detection model. However, this does not im-

ply pedestrians are unknowns to the autonomous ve-

hicle as it can have another machine learning model

which can detect pedestrians. In this example, we

can observe that identifying unknowns of a machine

learning model helps us to understand what additional

machine learning models we will need to ensure that

we can identify objects that are part of ODD and

can compromise safety. Exposing unknowns to au-

tonomous vehicles will aid in making better design

decisions. Similarly, exposing unknowns to engineers

and analysts helps to make better safety solutions,

gather better data, and revise ODD. These observa-

tions lead to our central research question: “Should

we consider unknowns from different perspectives

to ensure safety of an autonomous vehicle?”. We

address this central research question by answering

the following research questions:

RQ1. What are unknowns from the perspective of

machine learning models, autonomous vehicles, and

engineers and analysts, respectively?

RQ2. What are similarities and dissimilarities

among the unknowns from the three perspectives?

In this paper, we address these research questions

by comparing the unknowns from each perspective

with others using a running example. We discuss

unknowns and their sub-categories (i.e., unknown

knowns and unknown unknowns) from the perspec-

tives of engineers and analysts, autonomous vehi-

cles, and machine learning models in an autonomous

vehicles. We discuss similarities and dissimilari-

ties among the unknowns from the three perspectives

and provide the details on how sub-categories of un-

knowns from one perspective can relate and differ to

sub-categories of unknowns from other perspectives.

The rest of the paper is organized as follows. Sec-

tion 2 discusses about the classiﬁcation of knowns and

unknowns. Section 3 details about the importance of

unknowns with respect to ISO 21448 and UL 4600.

Section 4 discusses the types of unknowns with re-

spect to the three perspectives mentioned earlier with

an example. Section 5 provides insights and observa-

tions, and we ﬁnally conclude in Section 6.

2 KNOWNS AND UNKNOWNS

We can classify knowns and unknowns based on the

knowledge possessed by an intelligent agent/person

(or a group of intelligent agents/persons) such as an

engineer, analyst, autonomous system or organiza-

tion. We can consider a set U which represents an

entire universal knowledge. Considering each intelli-

gent agent, we can divide U into two subsets: a set K

denoting the knowledge possessed by the agent and

a set N denoting the rest of universal knowledge not

possessed by the agent. We can represent this mathe-

matically in Equation 1, where K ⊂ U and N ⊂ U.

U = K ∪ N (1)

We can further divide a set K into subsets. There

are many classiﬁcations of K proposed by the existing

literature (Smith, 2001; McCormick, 1997; De Jong

and Ferguson-Hessler, 1996) (e.g., explicit and tacit

knowledge (Smith, 2001); factual, procedural, con-

ceptual and meta-cognitive knowledge (McCormick,

1997)). In this paper, to focus on knowns and un-

knowns, we classify K into following subsets: 1) a set

D representing the direct knowledge, i.e., knowledge

which an intelligent agent can comprehend and/or an-

alyze easily after seeing an object, action or event,

and 2) a set I representing the indirect knowledge, i.e.,

knowledge inferred using the knowledge from D. We

can represent the relation between K, D, and I using

Equation 2.

K = D ∪ I (2)

To understand the relation between sets D and I,

let us consider ‘P (D)’ which is the power set of D

and a set V = {valid, invalid}. We can deﬁne a set

I as shown in Equation 3, where f(x) is a function

which provides the inference that can be generated

based on input x, g(f(x)) is a function which tells if

the inference output given from f(x) is a valid or in-

valid inference. Each element in I must have a map-

ping to only one of the elements in V, i.e., the intelli-

gent agent shall be able to derive valid or invalid in-

ferences from D. We mentioned element ‘x’ belongs

to P (D) because I cannot exist without D, i.e., with-

out the knowledge from a set D, we cannot infer the

corresponding knowledge in I.

I = { f (x) | x ∈ P (D) and g( f (x)) ∈ V } (3)

Based on the knowledge possessed and informa-

tion recognized by an intelligent agent, we can clas-

sify the knowns and unknowns similar to ones clas-

siﬁed by the existing literature (Pickard et al., 2010;

Collins and Cruickshank, 2014; Jensen et al., 2017)

as shown in Figure 1. We also illustrate the relation

between these classiﬁcations and sets U, K, N, D and I

in Figure 2. The ﬁgure shows four widely recognized

classiﬁcations as follows.

Resolving Confusion of Unknowns in Autonomous Vehicles: Types and Perspectives

647

Known knowns Unknown knowns

Known unknowns Unknown unknowns

Within the

knowledge

of intelligent

agent

Outside the

knowledge

of intelligent

agent

Identified by the

intelligent agent

Not identified by the

intelligent agent

Need knowledge from intelligent

agents who have a different expertise

Unknowns

Figure 1: Classiﬁcation of knowns and unknowns for an

intelligent agent.

Known

knowns

Known

unknowns

Unknown

unknowns

Known

knowns

Unknown

knowns

K = D ? I

U = K ? N

Figure 2: Venn diagram showing the different types of

knowns and unknowns and their relation with sets U, K, N,

D and I.

1. Known Knowns: These refer to the concepts and

information that are present within the scope of

the knowledge possessed by an intelligent agent.

In the knowledge classiﬁcation, we discussed

prior, known knowns are a subset of the set K. An

example of known known is the object correctly

recognized by an individual agent.

2. Known Unknowns: These refer to the concepts

and information that are identiﬁed by an intelli-

gent agent but not within the scope of their knowl-

edge. For an intelligent agent to identify a concept

or information that is out of scope their knowl-

edge, the agent should have a basic knowledge

about the existence of the concepts, but does not

need to have expertise enough to make observa-

tions or inferences from it. Known unknowns are

sets which have few elements in the set D and no

elements in the set I. Since only few elements in

D help us in recognizing the unknown concepts,

the knowledge that can be inferred from these el-

ements is mostly part of the set N as we will need

more knowledge to make a meaningful inference.

An example of known unknown is a runtime mon-

itor identifying that the machine learning model is

uncertain of its input (Weiss and Tonella, 2021).

3. Unknown Knowns: These refer to concepts and

information which are within the scope of knowl-

edge possessed by an intelligent agent but are not

identiﬁed. Unknown knowns mostly belong to the

set I as they mostly represent the overlooked in-

formation by an intelligent agent either due to the

insufﬁcient analysis, a lack of awareness about

presuppositions we have, a lack of proper infer-

ence, or due to the effect from mental factors such

as stress, anxiety, and others. An example of un-

known known is the misprediction of an object by

a machine learning model which was recognized

in the previous frame. In this case, the model

knows the object and has knowledge to identify

it, but was unable to identify it. An unknown

known when exposed and analyzed will change

into a known known.

4. Unknown Unknowns: These are concepts and

information which are not in the scope of knowl-

edge of an intelligent agent and not identiﬁed by

the agent. For the misprediction example we used

for unknown known, the cause that resulted in a

misprediction of an object, which was correctly

recognized in the previous frame, can be an un-

known unknown to engineers until the frame is

exposed and analyzed. All unknown unknowns

belong to the set N. When exposed, unknown

unknowns change mostly into known unknowns.

However, with sufﬁcient knowledge and exper-

tise (potentially with the help from other experts),

unknown unknowns when exposed can change to

known knowns.

Related Work. To date many researchers (Pickard

et al., 2010; Collins and Cruickshank, 2014; Jensen

et al., 2017) have discussed the need for ﬁnding

unknowns and proposed approaches to identify or

expose unknowns. The application domains for

such approaches mostly include biomedical applica-

tions (Collins and Cruickshank, 2014; Hoskisson and

Seipke, 2020), software security (Al-Zewairi et al.,

2020; Rashid et al., 2016), system design (Jensen

et al., 2017), complex systems (Pickard et al., 2010),

and autonomous vehicles (Wong et al., 2020; He-

jase et al., 2020; Zhu et al., 2020). For example,

Zhu et al. (Zhu et al., 2020) proposed a weakly-

hard paradigm framework to model as well as mit-

igate time-based uncertainties for autonomous soft-

ware. Even though all these current approaches dis-

cuss identiﬁcation of unknowns or their mitigations,

they do not consider different perspectives, which are

the main concerns when we identify unknowns and

understand reasons why such consideration is impor-

tant.

In the next sections, we will discuss why we need

to perform unknown analysis for autonomous vehi-

VEHITS 2021 - 7th International Conference on Vehicle Technology and Intelligent Transport Systems

648

Known hazardous

scenarios

(Area 2)

Known and not

hazardous scenarios

(Area 1)

Unknown hazardous

scenarios

(Area 3)

Unknown and not

hazardous scenarios

(Area 4)

Known

Unknown

Hazardous

Not Hazardous

Figure 3: Scenario categories described in ISO 21448 stan-

dard.

cles and different perspectives we need to consider for

performing such an analysis.

3 INDUSTRIAL STANDARDS AND

UNKNOWNS

Industrial standards for safety of autonomy such as

ISO 21448 (ISO/PAS, 2019) and UL 4600 (ANSI/UL,

2020) stress the need for analyzing unknowns to re-

duce the risks for autonomous vehicles. As au-

tonomous vehicles with SAE level 5 of driving au-

tomation operate in a complex and changing ODD, it

is possible to overlook some characteristics of ODD,

which might be uncovered over time or when an un-

safe situation is exposed.

ISO 21448 (ISO/PAS, 2019) is an industrial stan-

dard that details steps to analyze the safety of the in-

tended functionality (SOTIF) of autonomous vehicles

and thereby achieve compliance with respect to SO-

TIF. The standard focuses on identifying the gaps in

nominal requirements and in reducing the safety is-

sues for a system when exposed to unknown condi-

tions. The standard illustrates a four quadrant struc-

ture for scenario categories as shown in Figure 3. We

can observe that the categories are based on whether

the scenarios are known or unknown and if they are

hazardous or not. Each quadrant in Figure 3 repre-

sents a category and the corresponding area number

that is assigned. For example, Area 1 implies scenar-

ios which are known and non-hazardous. The goal of

SOTIF is to increase Area 1 and reduce Areas 2 and

3. This illustrates the importance the ISO 21448 has

given in need for analyzingunknown scenarios and

proposing mechanisms to ensure autonomous vehi-

cles operate safely in such scenarios.

Similarly, UL 4600 (ANSI/UL, 2020) which de-

tails a process of creating a safety case for au-

tonomous vehicles also stresses the need for consid-

ering unknowns as a part of assuring safety of an au-

tonomous vehicle. The standard mentions unknowns

when discussing the safety case and arguments, au-

tonomy function and support, dependability, lifecycle

concerns, metrics and safety performance indicators,

and assessment. The standard suggests to use feed-

back loops to keep track of unknowns. By doing so,

we can accumulate knowledge of unknowns overtime

and thus change design as needed. Hence, we can

conclude analyzing unknowns for autonomous vehi-

cles plays a vital role in assuring its safety for its op-

eration in a complex ODD.

Note that it is not possible to identify all un-

knowns, and it might be very difﬁcult to replicate

some of the unknowns that are exposed in the real

world. Hence, the standards focus more on proving

that the occurrence of unknowns is rare and that we

have mechanisms to accumulate the knowledge of un-

knowns over time as they occur. In addition to these

standards, there is a functional safety standard ISO

26262 (ISO, 2018) for automotive, which deals only

with malfunctions of electrical and electronic systems

used in the vehicles but not unknowns.

4 UNKNOWN TYPES AND

DIFFERENT PERSPECTIVES

Although both ISO 21448 and UL 4600 stress the

need for analyzing unknowns, the focus of these stan-

dards is often interpreted as analyzing unknowns from

the engineers and analysts’ perspective. This inter-

pretation comes from the assumption that unknowns

perceived by engineers and analysts are not different

from the ones by autonomous vehicles or machine

learning models’ perspective. However, this is not al-

ways true. Machine learning algorithms, which are

intended for effective generalization based on data on

which they are trained, could produce correct out-

puts for instances that might be unknowns to engi-

neers and analysts. Hence, it is possible for unknowns

to differ from different perspectives such as machine

learning models used in autonomous vehicles, au-

tonomous vehicles (i.e., vehicle-level unknowns), and

engineers and analysts. This leads to our central re-

search question stated in Section 1: Should we con-

sider unknowns from different perspectives to en-

sure safety of an autonomous vehicle?

To answer our central research question, we

speciﬁcally investigate the following two research

questions:

RQ1. What are unknowns from the perspective of

machine learning models, autonomous vehicles, and

engineers and analysts, respectively?

RQ2. What are similarities and dissimilarities

Resolving Confusion of Unknowns in Autonomous Vehicles: Types and Perspectives

649

among the unknowns from these three perspectives?

After ﬁnding answers from these two research ques-

tions, we will conclude by answering our central

question.

Running Example: To better illustrate unknowns from

different perspectives, let us consider a running exam-

ple of a level 5 autonomous vehicle which has cam-

eras and a LIDAR and travels in city roads that have

high density of pedestrians. Let us also assume that

the pedestrians are multicultural and diverse in nature.

4.1 RQ1: Unknowns from the Three

Perspectives

4.1.1 Unknowns with Respect to Machine

Learning Models

Machine learning models play a vital role for per-

ception and motion planning in autonomous vehicles.

Tasks for which machine learning models are used

include road object detection (Ashraf et al., 2016),

pedestrian detection (Yang et al., 2020), trafﬁc sign

detection (Ayachi et al., 2020), unknown object de-

tection (Wong et al., 2020) and trajectory estima-

tion (Rozumnyi et al., 2020). The results of a ma-

chine learning model are highly dependent on its data,

algorithm, and the training process followed. An un-

known with respect to a machine learning algorithm

is something which it cannot identify or detect. A ma-

chine learning model is susceptible to both unknown

knowns and unknown unknowns.

Unknown Knowns for Machine Learning Models:

Unknowns knowns for a machine learning model im-

plies that the predictions regarding an object or an ac-

tion are correct for the previous inputs or subsequent

inputs, but are not correct for the current input. To

better understand unknown knowns, let us consider

the running example in which the autonomous vehi-

cle detects pedestrians on city roads. If we assume

the vehicle relies on cameras for pedestrian detection,

then the input to the machine learning model that de-

tects pedestrians will be a sequence of frames. If a

pedestrian is identiﬁed in one frame but not identi-

ﬁed in the subsequent frame, then we can refer to the

latter case as an unknown known with respect to the

machine learning model. This is because the machine

learning model has knowledge to identify the pedes-

trian, but it might not always be able to correctly infer

it.

Unknown Unknowns for Machine Learning Mod-

els: A machine learning model cannot detect or per-

form something that is never trained for. For exam-

ple, if the training data of pedestrians for our running

example is missing data on pedestrians belonging to

a certain race and/or gender or pedestrians wearing

a certain type of clothing, then the model might not

be able to identify such pedestrians because it never

knows such pedestrians would exist in the ﬁrst place.

Such instances for which machine models are never

trained for are considered as unknown unknowns for

machine learning models.

4.1.2 Unknowns with Respect to Autonomous

Vehicles

When we consider unknowns with respect to au-

tonomous vehicles, we refer to situations or events

that an autonomous vehicle might not be familiar with

or might have misinterpreted the situations or events

as something else. Unknowns with respect to an au-

tonomous vehicle are highly dependent on the archi-

tecture and the nature of sensor fusion. Similar to

machine learning models, an autonomous vehicle also

has a possibility of facing unknown knowns and un-

known unknowns.

Unknown Knowns for Autonomous Vehicles: An

autonomous vehicle takes a decision based on infor-

mation it gathers from different sensors. If the au-

tonomous vehicle’s algorithm prioritizes one sensor

over the other and the least prioritized sensor (not the

highly prioritized one) provides correct information

for a potential collision, then we can refer to such

a situation as unknown knowns to autonomous ve-

hicles. In our running example, if we consider the

autonomous vehicle to have cameras and a LIDAR,

and the cameras are prioritized over a LIDAR, then

a pedestrian not detected by the machine models in

the cameras but correctly detected by a LIDAR might

be ignored by the vehicle. In this situation, the vehicle

has the knowledge of the presence of a pedestrian, but

the priority of sensors in the algorithm made it to ig-

nore the pedestrian detected by the LIDAR. Since the

motion planner takes action based on the output from

camera models, the occurrence of the pedestrian will

be an unknown known to the autonomous vehicle.

Unknown Unknowns for Autonomous Vehicles:

An autonomous vehicle can face situations or ODD

conditions which it never faced before. Such situa-

tions and ODD conditions, which autonomous vehi-

cles are completely unfamiliar with and either can-

not process the corresponding information or ignore

them, are considered as unknown unknowns to au-

tonomous vehicles. For example, let us assume the

autonomous vehicle is never trained to operate it in

snowy weather due to the low probability of snow in

that region. If such a vehicle faces an unexpected

snowfall in the region of its operation, then it is an

VEHITS 2021 - 7th International Conference on Vehicle Technology and Intelligent Transport Systems

650

unknown unknown condition with respect to the au-

tonomous vehicle.

4.1.3 Unknowns with Respect to Engineers and

Analysts

Since level 5 autonomous vehicles need to be able

to travel everywhere without human intervention, the

engineers and analysts of the autonomous vehicle will

need to consider complex ODD conditions. How-

ever, it is not possible for the engineers and ana-

lysts to know all possible conditions that occur in the

world and the ones which might affect the behavior

of the autonomous vehicle. Hence, there might be

some aspects that are overlooked or unknown to engi-

neers and analysts. While considering engineers and

analysts from diverse backgrounds and experiences

across various regions can reduce the total number of

unknowns, it is possible that we can have new poten-

tial unknowns. Also, as environments change, new

unknowns can occur over time, which the engineers

and analysts might not be familiar with unless such

conditions or situations are exposed to them. This can

result in a lack of consideration of such scenarios or

situations while verifying the system as well as a lack

of presence of such environments in simulation tools.

Similar to machine learning models and autonomous

vehicles, there can be unknown knowns and unknown

unknowns with respect to engineers and analysts of

an autonomous vehicle.

Unknown Knowns for Engineers and Analysts:

It is possible for engineers and analysts to over-

look some aspects when designing an intelligent au-

tonomous vehicle. The reason behind overlooking the

aspects can be intentional (e.g., to reduce complex-

ity/scope) or unintentional. We refer to such aspects

as unknown knowns. For our running example, if the

engineers and analysts did not consider pedestrians’

race when training the pedestrian detection machine

learning model or analyzing the model, and the model

did not predict people of a certain race properly, then

it is an unknown known to the engineers and analysts.

The engineers despite having knowledge of different

races of people could have assumed that the machine

learning model will be effective in identifying pedes-

trians of all races, thereby making the missing pre-

dictions of pedestrians belonging to a speciﬁc race as

unknown knowns to engineers and analysts.

Unknown Unknowns for Engineers and Analysts:

The unknown unknowns for engineers and analysts

can occur mostly either due to a lack of knowledge

about some ODD elements and conditions or due to

a lack of appropriate understanding/analysis of ma-

chine learning models used in autonomous vehicles.

For example, in our running example, if a pedestrian

wore a reﬂective costume which resulted in a col-

lision, such an occurrence can be an unknown un-

known to the engineers and analysts. This is because

the engineers and analysts have never seen such an

occurrence before and hence did not take into ac-

count pedestrians with reﬂective costumes when de-

signing the autonomous vehicle. Another example

of unknown unknowns for engineers and analysts is

the root causes for the non-deterministic behavior of

a machine learning model, which identiﬁed an object

in one frame but did not identify the same object in

the subsequent frame for multiple inputs. This im-

plies the machine learning model has knowledge to

recognize the object, but the engineers and analysts

do not know why it produces the correct output for

one frame and the incorrect one for the other despite

having knowledge about recognizing objects.

As mentioned earlier, once exposed unknown

unknowns translate to known unknowns or known

knowns depending on knowledge gained by the en-

gineers and analysts.

4.2 RQ2: Comparing the Unknowns

from Different Perspectives

So far, we have discussed unknowns with respect to

machine learning models, autonomous vehicles, and

engineers and analysts. However, are all these un-

knowns same or different? If they are different, how

do they differ from each other? We shall now com-

pare these unknowns from different perspectives.

An unknown for a machine learning model in an

autonomous vehicle need not to be unknown to other

machine learning models or algorithms that rely on a

sensor different from the sensor being used by the cur-

rent machine learning model. This implies unknowns

of a machine learning model and unknowns of an au-

tonomous vehicle are not necessarily the same. The

unknowns of one machine learning model can be

knowns to other machine learning models or can be

exposed using sensors that are different from the in-

put sensor to the machine learning model. The causes

of unknown knowns for a machine learning model can

be unknown unknowns to engineers and analysts. For

example, if a machine learning model is able to de-

tect an object in the previous frame but not the current

frame, then we consider it to be an unknown known

for the machine learning model. However, the en-

gineers and analysts might not be familiar with such

behavior of the machine learning model until it is ex-

posed to them. Hence, it becomes unknown unknown

for engineers and analysts.

Any ODD elements which are not considered by

Resolving Confusion of Unknowns in Autonomous Vehicles: Types and Perspectives

651

engineers and analysts because they do not know

about their occurrence in the location considered are

unknown unknowns, and remain unknown unknowns

with respect to both an autonomous vehicle and ma-

chine learning model. This is because if the engi-

neers and analysts do not know about the existence

of an ODD element or condition in the ﬁrst place,

the corresponding design criterion might never have

been taken into account. With respect to unknowns

for an autonomous vehicle, however, they are not nec-

essarily the same as unknowns for engineers and an-

alysts. This is because the machine learning mod-

els used in autonomous vehicles are meant to support

generalization to some extent. The process of gener-

alization involves a machine learning model provid-

ing the expected output for an input which it has not

been trained on or validated on. Hence, it is possible

for machine learning models to work for some cases,

even if they are not part of training data. Hence, un-

knowns for the autonomous vehicles need not to be

the same as unknowns for engineers and analysts.

From the analysis of RQ1 and RQ2, we can con-

clude that,in the case of level 5 autonomous vehicles,

unknowns for engineers and analysts, unknowns for

autonomous vehicles, and unknowns for a machine

learning model used in the autonomous vehicle are

not necessarily the same.

5 DISCUSSION

Our comparison among the unknowns considering

three different perspectives (autonomous vehicles,

machine learning models within autonomous vehi-

cles, and engineers and analysts) has shown that the

unknowns perceived by these different perspectives

can differ. This difference among these perspectives

tells us the need to analyze unknowns considering

all three, rather than following the typical practices,

which tend to focus on unknowns identiﬁed by the

engineers and analysts. If we use algorithms that

are robust and not stochastic in the autonomous ve-

hicle software, the unknowns identiﬁed from the au-

tonomous vehicle’s perspective will be the same as

ones from the engineers and analysts’ perspective.

However, all autonomous vehicle heavily rely on ma-

chine learning models which are stochastic and not

very robust in nature. Hence, for the central research

question which aims to clarify if we need to consider

unknowns from different perspectives to ensure safety

of the autonomous vehicle, we can conclude that we

will need to consider unknowns from all three differ-

ent perspectives.

We believe that by exposing unknowns from the

three perspectives, we can design the system better to

handle unknown circumstances, as well as make the

probability of facing unknown situations extremely

rare. Further, by analyzing unknowns for machine

learning models, we can understand if we need to add

examples with certain elements into data and retrain

a machine learning model or if we need to use other

machine learning models and other sensor modalities

to ensure safe operation of the system. Analyzing un-

knowns from the three perspectives also help the sim-

ulation engineers in enhancing existing simulation en-

vironments as well as building environments for eval-

uating new scenarios and situations.

6 CONCLUSION

In this research, we discussed how unknowns in an

autonomous vehicle can be considered from differ-

ent perspectives and their differences. In this paper,

we focused on level 5 autonomous vehicles without

considering vehicle-to-everything (V2X) connectiv-

ity (Hobert et al., 2015). We also used only a small

running example as a proof of concept for the pro-

posed idea. As a part of future work, we plan to ana-

lyze unknowns comprehensively by considering V2X

communication. We also plan to conduct an extensive

analysis to better understand how unknowns differ for

the three different perspectives and how identifying

them will play a major role in assuring safety of the

system, even when operating in a complex ODD.

ACKNOWLEDGEMENTS

We would like to thank kVA by UL for their feedback

on the topic.

REFERENCES

Al-Zewairi, M., Almajali, S., and Ayyash, M. (2020). Un-

known security attack detection using shallow and

deep ann classiﬁers. Electronics, 9(12):2006.

ANSI/UL (2020). 4600. Standard for Evaluation of Au-

tonomous Products.

Ashraf, K., Wu, B., Iandola, F. N., Moskewicz, M. W.,

and Keutzer, K. (2016). Shallow networks for

high-accuracy road object-detection. arXiv preprint

arXiv:1606.01561.

Ayachi, R., Aﬁf, M., Said, Y., and Atri, M. (2020). Traf-

ﬁc signs detection for real-world application of an ad-

vanced driving assisting system using deep learning.

Neural Processing Letters, 51(1):837–851.

VEHITS 2021 - 7th International Conference on Vehicle Technology and Intelligent Transport Systems

652

BSI/PAS (2020). 1883:2020. Operational Design Do-

main (ODD) taxonomy for an automated driving sys-

tem (ADS) – Speciﬁcation.

Collins, R. A. and Cruickshank, R. H. (2014). Known

knowns, known unknowns, unknown unknowns and

unknown knowns in dna barcoding: a comment on

dowton et al. Systematic biology, 63(6):1005–1009.

Committee, S. O.-R. A. V. S. et al. (2018). Taxonomy and

deﬁnitions for terms related to driving automation sys-

tems for on-road motor vehicles. SAE Standard J,

3016.

De Jong, T. and Ferguson-Hessler, M. G. (1996). Types

and qualities of knowledge. Educational psychologist,

31(2):105–113.

Hejase, M., Barbier, M., Ozguner, U., Ibanez-Guzman, J.,

and Acarman, T. (2020). A validation methodology

for the minimization of unknown unknowns in au-

tonomous vehicle systems. In 2020 IEEE Intelligent

Vehicles Symposium (IV), pages 114–119. IEEE.

Hobert, L., Festag, A., Llatser, I., Altomare, L., Visintainer,

F., and Kovacs, A. (2015). Enhancements of v2x

communication in support of cooperative autonomous

driving. IEEE communications magazine, 53(12):64–

70.

Hoskisson, P. A. and Seipke, R. F. (2020). Cryptic or

silent? the known unknowns, unknown knowns, and

unknown unknowns of secondary metabolism. mBio,

11(5).

ISO (2018). 26262. Road Vehicles – Functional Safety.

ISO/PAS (2019). 21448. Road vehicles - Safety of the in-

tended functionality.

Jensen, M. B., Elverum, C. W., and Steinert, M. (2017).

Eliciting unknown unknowns with prototypes: Intro-

ducing prototrials and prototrial-driven cultures. De-

sign Studies, 49:1–31.

McCormick, R. (1997). Conceptual and procedural knowl-

edge. International journal of technology and design

education, 7(1-2):141–159.

Pickard, A. C., Nolan, A. J., and Beasley, R. (2010). 8.3.

1 certainty, risk and gambling in the development of

complex systems. In INCOSE International Sympo-

sium, volume 20, pages 1051–1061. Wiley Online Li-

brary.

Rashid, A., Naqvi, S. A. A., Ramdhany, R., Edwards, M.,

Chitchyan, R., and Babar, M. A. (2016). Discovering

”unknown known” security requirements. In Proceed-

ings of the 38th International Conference on Software

Engineering, ICSE ’16, page 866–876, New York,

NY, USA. Association for Computing Machinery.

Rozumnyi, D., Matas, J., Sroubek, F., Pollefeys, M., and

Oswald, M. R. (2020). Fmodetect: Robust detection

and trajectory estimation of fast moving objects. arXiv

preprint arXiv:2012.08216.

Smith, E. A. (2001). The role of tacit and explicit knowl-

edge in the workplace. Journal of knowledge Man-

agement.

Weiss, M. and Tonella, P. (2021). Fail-safe execution of

deep learning based systems through uncertainty mon-

itoring. In 2021 IEEE 14th International Confer-

ence on Software Testing, Validation and Veriﬁcation

(ICST). IEEE.

Wong, K., Wang, S., Ren, M., Liang, M., and Urtasun,

R. (2020). Identifying unknown instances for au-

tonomous driving. In Conference on Robot Learning,

pages 384–393. PMLR.

Yang, P., Zhang, G., Wang, L., Xu, L., Deng, Q., and Yang,

M.-H. (2020). A part-aware multi-scale fully convolu-

tional network for pedestrian detection. IEEE Trans-

actions on Intelligent Transportation Systems.

Zhu, Q., Li, W., Kim, H., Xiang, Y., Wardega, K., Wang, Z.,

Wang, Y., Liang, H., Huang, C., Fan, J., et al. (2020).

Know the unknowns: addressing disturbances and un-

certainties in autonomous systems. In Proceedings of

the 39th International Conference on Computer-Aided

Design, pages 1–9.

Resolving Confusion of Unknowns in Autonomous Vehicles: Types and Perspectives

653
