Secure Key Management in Embedded Systems: A First Proposal

Gorazd Jank, Silvia Schmidt and Manuel Koschuch

Competence Centre for IT Security, University of Applied Sciences FH Campus Wien, Vienna, Austria

Keywords:

Constrained Devices, Decision-making, Embedded Systems, Internet of Things, Secure Key Management.

Abstract:

The Internet-of-Things (IoT) domain is highly heterogeneous and comprises a multitude of different devices.

Because of this variety, many projects require unique compositions of tools, systems, and use cases. In addi-

tion, embedded devices are highly optimized and due to that are subject to different constraints. The intercon-

nection of such products for data analysis or cooperation simultaneously increases the attack surface, which

leads to requiring efﬁcient cryptographic methods for the protection of data and communication. To enable

this, a secure key management approach is needed. In practice however, there are still difﬁculties regarding

the implementation and associated decision making of said management. All the more so since a generic one-

size-ﬁts-all approach in such a complex heterogeneous environment as the IoT simply does not exist. This

paper aims to provide initial guidelines to argue the choice of a secure key management approach. To do so

the state-of-the-art is presented and beneﬁts as well as limits are evaluated. After that a set of factors and a

ﬁrst taxonomy are presented, which inﬂuence the ﬁnal key management solution.

1 INTRODUCTION

The number of embedded systems continues to grow.

Various summaries of market research suggest that

this trend will continue in the next years (Wadhwani

and Yadav, 2020). By the end of 2019 the market size

exceeded USD 100 Billion and is expected to grow up

to USD 160 billion by 2026.

Despite this widespread usage, a 2018 survey con-

ducted by the Barr Group with over 1,700 partici-

pants concluded that ”About 1 in 6 designers of po-

tentially injurious, Internet-connected embedded sys-

tems are completely ignoring security.” (Barr Group,

2018). This situation is exacerbated by the emer-

gence of malware like Mirai (Kolias et al., 2017),

which was ﬁrst discovered in mid-2016. The worm

compromised thousands of systems because basic se-

curity practices were ignored. The infected devices

fell victim to only 62 default username and password

combinations. Even a year later, not only did Mirai

still infect IoT devices, but a vast amount of similar

worms emerged, infecting even more systems (Ko-

lias et al., 2017). This example and similar attacks

(Nie et al., 2017; Checkpoint, 2018; Rajendran and

Nivash, 2019) highlight the importance of IT/OT –

Security in the IoT.

The goal of this work, based mainly on the results

https://orcid.org/0000-0001-8090-3784

of the primary author’s master’s thesis (Jank, 2020),

is to present a structured way to support the decision-

making process of picking a suitable key management

approach during early development of an embedded

(IoT) system. The challenge for the decision mak-

ers lies within the heterogeneity of embedded devices,

their individual constraints as well as the vast amount

of possible key management compositions and the re-

sulting advantages and limitations for the ﬁnal sys-

tem. Many factors have to be taken into account such

as the architecture of the embedded systems, their se-

curity requirements and special threats. Furthermore,

production, commissioning and maintenance costs as

well as existing in-house know-how and infrastruc-

ture must be considered.

Numerous security measures such as user authen-

tication, secure communication and data encryption

require cryptographically secure keys to work cor-

rectly. In order not to compromise the algorithms and

procedures, keys need to be generated, distributed,

protected and destructed in a secure way. The pro-

cess of performing these steps in a structured fashion

is called key management (Barker, 2020).

Requirements of embedded systems differ from

classic IT-systems such as PC or server systems. They

often have restricted resources, longer product life cy-

cles and a different focus on security goals (Sadeghi

et al., 2015). This and the heterogeneous landscape

Jank, G., Schmidt, S. and Koschuch, M.

Secure Key Management in Embedded Systems: A First Proposal.

DOI: 10.5220/0010475600810091

In Proceedings of the 6th International Conference on Internet of Things, Big Data and Security (IoTBDS 2021), pages 81-91

ISBN: 978-989-758-504-3

make it difﬁcult if not impossible to implement a

generic security solution (Humayed et al., 2017).

Security in embedded systems is often reduced to

an afterthought, while it should be considered start-

ing from the design throughout the entire life cycle

(Mirjalili and Lenstra, 2008). An embedded device

in an industrial plant with an estimated lifetime of 20

years has completely different security requirements

compared to a consumer IoT-Gadget. Considering se-

curity only at the end of the development limits the

amount of suitable options.

The majority of existing research focuses on how

to add to security while in the requirements and de-

sign phase (e.g. (M.K et al., 2016; European Union

and Agency for Network and Information Security,

2017; European Union Agency for Cybersecurity,

2019)). These phases should output necessary secu-

rity requirements and deﬁne processes on how to en-

force them. During implementation, different secu-

rity mechanisms will be needed to safeguard differ-

ent parts of the solution. Those often need secrets,

which in most cases will be realized through crypto-

graphic keys. The assumption that a single key will

remain secure for the entire lifetime of the embed-

ded system typically is not sufﬁcient (Grand View Re-

search, 2014). To account for revocation of compro-

mised keys and generation of new ones, key manage-

ment solutions are required. This has however to be

adapted to the speciﬁc needs of the embedded system

that is using it (Grand View Research, 2014).

Various possibilities exist to implement key man-

agement. These differ by the usage of special hard-

ware or software for calculations, by the utilization of

symmetric or asymmetric keys, by the requirements

on storage space, memory or CPU and other details

(Vai et al., 2015; Whelihan et al., 2016; Obermaier

et al., 2018).

This work aims to present a ﬁrst introduction to

our structured approach to support decision makers in

the process of choosing a suitable, secure key man-

agement solution. The remainder of this paper is now

structured as follows: Section 2 gives a comprehen-

sive overview of existing works dealing with the prob-

lem of key management in constrained devices. From

that, we present our contributions in form of a tax-

onomy to support decision making in Section 3 and

ﬁnally concluding with a brief outlook in Section 4.

2 RELATED WORK

In the ﬁeld of key management for embedded systems

we are not aware of works supporting the decision

making for all key management objectives. However,

there is some work giving advice for classical key

management and a paper presenting a method to pick

a ﬁtting key management protocol for the domain of

Wireless Sensor Networks (WSNs).

Basic key management concepts are already de-

ﬁned in 1997’s Handbook of Applied Cryptography

by Menezes et al. (Menezes et al., 1997). This in-

cludes the key life cycle, the concept of Trusted Third

Parties (TTPs), digital signatures, key protocols as

well as fundamental advantages and disadvantages of

different key management approaches.

The NIST publication “Recommendation for key

management: Part 2” [SP-800-57-2] (Barker and

Barker, 2019) contains a chapter handling the plan-

ning of key management. They start by choosing a ﬁt-

ting key management architecture based on the avail-

able cryptographic mechanism and objectives. After

that a key management speciﬁcation is developed for

each cryptographic product used in the system. This

speciﬁcation has to list, for each contained device, in-

formation about key generation and/or distribution,

key storage, access control, accounting and audit-

ing, recovery from compromise, corruption, or loss of

keying material as well as key recovery from backups

and archives. In the third step a Cryptographic Key

Management System (CKMS) Security Policy is devel-

oped. This is “a set of rules that are established to de-

scribe the goals, responsibilities, and overall require-

ments for the management of cryptographic keying

material throughout the entire key lifecycle” (Barker

and Barker, 2019). Finally, a decision is made if the

CKMS is operated in-house or by another organiza-

tion and a CKMS Practice Statement is developed.

It describes the establishment of a trust root for the

CKMS and a speciﬁcation “how key management pro-

cedures and techniques are used to enforce the CKMS

Security Policy and to conform with the Key Manage-

ment Speciﬁcation” (Barker and Barker, 2019). This

planning procedure does not consider possible limita-

tions which embedded devices can have.

Alcaraz et al. (Alcaraz et al., 2012) present an ap-

proach on how to map WSN requirements to key man-

agement protocol properties. They deﬁned a set of at-

tributes which they claim to be crucial when selecting

a protocol. These attributes can be used to evaluate a

set of candidates and pick one by excluding protocols

not ﬁtting the application requirements.

The authors of (Alohali et al., 2015) surveyed key

management schemes for the Smart Grid. In the ﬁrst

part of their paper they discuss components of the

smart grid and in the second part key management.

They separate the schemes into key management for

AMI, SCADA, V2G as well as WSN. Further ap-

proaches are separated into symmetric and asymmet-

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

ric. The writers conclude that approaches for WSN

“can be effectively implemented for Smart Grid use”,

that each analyzed scheme can be efﬁcient depending

on the setting and that there is no generic solution ﬁt-

ting for each Smart Grid application.

Messai et al. focus their survey on a Multi-Phase

WSN (Messai and Seba, 2016). As WSN devices

mostly work on battery, they have to be replaced from

time to time. When a set of nodes is replaced af-

ter a ﬁxed time this is called a phase. Those phases

generate new challenges as nodes have to frequently

leave and join the network. They analyzed the work

of previous surveys on WSN but only take into ac-

count approaches ﬁtting Multi-Phase WSN require-

ments. They classify them into deterministic and

probabilistic approaches and compare their security

and efﬁciency. Finally, they point out future open is-

sues: the authors believe that addressing sensor node

failure is of importance and for that fault-tolerant key

management is needed. Furthermore they see a need

for research into Mobile Multi-Phase WSN, the IoT as

well as Real-world applications, because as yet there

exist no implementations of the covered schemes.

In (Barskar and Chawla, 2016) the authors sur-

vey efﬁcient group key management schemes in wire-

less networks. They separate the analyzed schemes

into Network Independent Schemes and Network De-

pendent Schemes. They focus on network indepen-

dent schemes which do not consider the underlying

network infrastructure because they can also be used

in wired and wireless settings. They further divide

them into Centralized, Decentralized and Distributed

group key management schemes. They examine each

scheme for security requirements like forward and

backward secrecy, and QoS requirements, e.g. low

bandwidth overhead or minimal delays. They also

summarize advantages and limitations of each sub-

group.

Lavanya et al. surveyed key management in IoT

(Lavanya and Usha, 2017). Ten key management

techniques are covered which according to the au-

thors are suitable for the IoT. The paper focuses on

protocols rather than holistic approaches. They cat-

egorize key management into public key cryptogra-

phy, pre-shared key approaches and link-layer ori-

ented schemes. They conclude that various key man-

agement schemes for end-to-end security in high lay-

ers exist, but key management on network level needs

further research. Further energy cost of establishment

schemes in heterogeneous IoT networks have to be

decreased.

Delay tolerant networks (DTNs) are another sub-

group of embedded systems. Those systems aim to

address technical issues with “intermittent connectiv-

ity, network heterogeneity, and large delays” (Men-

esidou et al., 2017). The authors of (Menesidou et al.,

2017) count deep space, sensor-based and terrestrial

wireless networks among them. They separate key

management schemes into Security Initialization, Key

Establishment and Key Revocation. Plenty of key

management schemes are analyzed and the possible

use of PKI and IBC in DTN is discussed. A con-

clusion of the paper is that “hardware testbeds and

real-life deployments in cryptographic key manage-

ment are still largely missing from the DTN research

area”. In the last part the authors also propose dif-

ferent key management categorization attempts e.g.

if an approach needs a TTP or not. Also open re-

search challenges are presented, highlighting short-

comings in most parts of DTN key management (e.g.

key storage and key revocation) as well as deﬁcien-

cies in DTN network research, for instance naming

and performance issues.

Vasukidevi et al. present a paper reviewing ex-

isting key management and authentication techniques

available in Vehicular Ad-Hoc Metworks (VANETs)

(Vasukidevi and Sethukarasi, 2017). They try to take

into account the difﬁculties of such networks and

present a list of approaches with advantages and per-

formance metrics. They are of the opinion that au-

thentication plays a major role in securing VANET.

The writers of (Huang and Chen, 2018) pub-

lished a survey about key management service in

cloud. They analyzed AWS CloudHSM, Keyless SSL

and STYX and focused on security and performance.

They present the architecture of each approach and

conclude that distributed environments of cloud plat-

forms make key management more complicated.

Manikandan et al. made a survey on various key

management schemes in WSN (Manikandan and Sak-

thi, 2018). They surveyed 13 schemes and sep-

arated them into symmetric, asymmetric and hy-

brid approaches. Furthermore, they analyzed these

schemes with regard to computational complexity,

memory, energy consumption, scalability, communi-

cation overhead, used technique and possible attacks.

Their goal was to “be helpful for researchers in select-

ing the appropriate key management technique spe-

ciﬁc to their application needs.”

A paper surveying key management for beyond 5G

Mobile Small Cells was published by De Ree et al.

(De Ree et al., 2019). They discuss key management

schemes for Mobile Ad-Hoc Networks (MANETs),

as well as ad hoc D2D networks. The paper solely

focuses on self-organized key management schemes.

These schemes do not rely on an online centralized

TTP. The authors classify approaches into Public Key

Cryptography and Symmetric Key Cryptography. Fur-

Secure Key Management in Embedded Systems: A First Proposal

ther they subclassify Public Key Cryptography into

Certiﬁcate-based, Identity-based and Certiﬁcateless

approaches. They also deﬁned some requirements of

self-organized key management for networks of mo-

bile small cells: security, connectivity, overhead, scal-

ability, sustainability, fairness and secure routing in-

dependence. These requirements were then used to

analyze the 17 approaches they looked into. The writ-

ers argue that there are two open research challenges.

Firstly, key management schemes relying on a par-

tially distributed TTP require a rigorous procedure for

selecting the most suitable network nodes to act as the

distributed TTP. Thereby it can happen that nodes act

selﬁshly due to the overhead burden. This selﬁshness,

as well as the many considerations needed in the se-

lection process, need further attention. Secondly, the

MANET schemes taken into account rely on physical

contact to instantiate trust and distribute keys. The

reason for that is the lack of network infrastructure.

Such an approach is not ﬁtting for mobile small cells,

and for that network nodes must use online network

infrastructure. There have been proposed schemes to

secure D2D communication but they always assume

that the network infrastructure is secure against com-

promise. Because of that the authors propose fur-

ther research for authentication schemes which pre-

vent distribution of sensitive and private data over in-

secure channels.

From all these works it can be seen that still no

structured approach for supporting decision makers

with the question, which approach or combination of

solutions is best suited for their product, exists. The

purpose of this paper is to propose a ﬁrst attempt at

such an approach.

3 KEY MANAGEMENT: A

TAXONOMY

Commonly key management is classiﬁed by the em-

ployed underlying cryptographic primitive into sym-

metric and asymmetric (Wan et al., 2016; Manikan-

dan and Sakthi, 2018; Payment Security Support

Group, 2018; Barker, 2020; Malik et al., 2019) or

by the resulting architecture into centralized, decen-

tralized and distributed (Rafaeli and Hutchison, 2003;

Challal and Seba, 2005; Mapoka, 2013; Abouhogail,

2014; Sharma and Krishna, 2015; Liu et al., 2020)

approaches. Less common grouping criteria are sep-

aration by organization type (self-, TTP-organized)

(De Ree et al., 2019), utilized communication patterns

(peer-to-peer, group, mixed) (Kandi et al., 2020),

key establishment approach (probabilistic, determin-

istic) (Messai and Seba, 2016), inclusion of biomet-

ric data (biometric, non-biometric) (Masdari et al.,

2017), network topology (hierarchical, ﬂat), network

dependability (network dependent, network indepen-

dent) (Mapoka, 2013) etc. An overview can be found

in Figure 1.

These classiﬁcations may be used to characterize

speciﬁc approaches. The approach in (Naﬁ et al.,

2020) can for example be outlined as hybrid, de-

centralized, network independent, self-organized and

non-biometric approach. Each class itself has advan-

tages and disadvantages depending on the use case.

This section introduces and analyzes those classes and

highlights beneﬁts and limitations when used with

embedded systems.

3.1 Cryptographic Primitive

Approaches can be differentiated by the used cryp-

tographic primitives (Barker, 2020). They can rely

on symmetric or asymmetric cryptography, or utilize

both primitives in which case they are called hybrid

(Manikandan and Sakthi, 2018). In the context of this

work hybrid approaches are those that combine the

management of symmetric and asymmetric keys e.g.

(Balasubramanian et al., 2005; Dawson et al., 2006).

In (Balasubramanian et al., 2005) a decentralized ap-

proach is implemented using clusters. Within each

cluster, symmetric keys are used. Inter-cluster com-

munication is secured using asymmetric keys.

Not counting as hybrid approaches are those uti-

lizing symmetric keys exclusively on protocol level.

Asymmetric approaches often use protocols which

use asymmetric cryptography to establish a secure

symmetric session key with a communication partner.

Trafﬁc is then encrypted with symmetric algorithms

to boost computational and energy efﬁciency (Sara-

vanan et al., 2011). A common effective way to es-

tablish symmetric session keys is the ECDH protocol

(Abusukhon et al., 2019). The key is exclusively used

for one or a part of a session and is only saved on

volatile storage.

To assure the same amount of security, asymmet-

ric approaches need longer keys than symmetric ap-

proaches. A symmetric AES-128 key has a length of

128 bits while asymmetric RSA keys with a compa-

rable security strength need 3,072 bits (Barker, 2020).

As a consequence more computing power and storage

is required (Haque et al., 2018). This effect can be

reduced when using an ECC algorithm. To achieve

same security strength as AES-128, the asymmet-

ric ECDSA algorithm needs about 283 bits (Barker,

2020), which is only a fraction of RSA. A detailed

comparison of ECC and RSA can be found in (Jansma

and Arrendondo, 2004).

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

Figure 1: Classiﬁcation of key management approaches (Jank, 2020).

Asymmetrical approaches perform better in point-to-

point communication with multiple individual enti-

ties. If a unique symmetric key is used for every

connection, (n − 1) keys must be stored in a secure

way per node or a total of (n(n − 1)/2) keys system-

wide (Haque et al., 2018). As asymmetric encryption

utilizes the public key of the communication partner

which can be freely published, in an minimal setup

only the own private key needs to be protected. Public

keys of communication partners can be veriﬁed using

a TTP.

Different approaches exist to minimize the sym-

metric keys needed, like matrix-based (Naﬁ et al.,

2020) or key pool-based approaches (Ahlawat and

Dave, 2018). Furthermore, asymmetric protocols can

be adapted to ﬁt embedded system constrains e.g.

(Liu and Ning, 2008; Raza and Mar Magnusson,

2019).

Asymmetric secret keys used for authentication

can be generated directly on embedded devices, al-

though depending on the employed trust model they

might still need to be certiﬁed by a trusted third party.

This ensures that as long as the key is not com-

promised, strong non-repudiation can be guaranteed.

Symmetric keys are always shared between at least

two entities, not providing non-repudiation (Barker,

2020). This also impacts key storage, as asymmetric

keys only need to be protected on one device, while

symmetric keys must be protected on all communica-

tion partners.

Another advantage of asymmetric keys is that

when generated directly on the device, the private

key never needs to be transported to another device

(Barker, 2020). Symmetric keys always have to be

transmitted which can affect conﬁdentiality and in-

tegrity of the key.

3.2 Architecture

In centralized approaches there exists a designated en-

tity exclusively responsible for speciﬁc tasks e.g. cre-

ation and distribution of keys (Devaraju and Ganap-

athi, 2010; Sharma and Krishna, 2015; Vasukidevi

and Sethukarasi, 2017). Examples for a designated

entity are the group leader of a clustered approach, a

KDC in a symmetric approach or a CA in an asym-

metric approach. When a set of devices need a com-

mon key to securely encrypt communication between

each other, only one entity is responsible to distribute

that group key (Devaraju and Ganapathi, 2010).

Decentralized approaches share the responsibili-

ties between multiple entities. In cluster based ap-

Secure Key Management in Embedded Systems: A First Proposal

proaches for example, there exists a designated device

in each sub-group, called LC, which is responsible for

handling certain key management tasks (Devaraju and

Ganapathi, 2010; Vasukidevi and Sethukarasi, 2017).

This device often is less constrained than other mem-

bers of the cluster. When sticking to the example used

before, each group leader would be responsible to dis-

tribute the group key to its groups members (Devaraju

and Ganapathi, 2010). The resulting system will be

decentralized but each group for itself would be cen-

tralized.

In distributed approaches group members cooper-

ate to fulﬁll certain key management objectives. No

exclusively responsible entity exists. To stick to the

previous example, in distributed approaches devices

work together to agree upon a group key (Devaraju

and Ganapathi, 2010; Vasukidevi and Sethukarasi,

2017).

Centralized approaches are the most widely used

and researched (Guoyu Xu et al., 2012; Menesidou

et al., 2017; Harn et al., 2018). Their main advantages

are the efﬁciency in both transmission and computa-

tion. Common problems in centralized approaches

are that they induce a single-point of failure (Liu et al.,

2020) and can be a bottleneck in big networks (De-

varaju and Ganapathi, 2010). Purely centralized ap-

proaches require trust into the entity generating and

distributing secret keys (Harn et al., 2018). Central-

ized approaches do not enforce a mutual TTP (Harn

et al., 2018). This can be an advantage if the mem-

bers of a group want to communicate in a secure way

and cannot trust the centralized key provider e.g. in

an internet chat (Dowsley et al., 2016). In such an

attempt a centralized entity can establish keys for a

secure connection between the participants but is not

involved in further group key establishment. A prop-

erty and possible limitation is that the dedicated entity

providing a service (e.g. key distribution) can only be

used by devices if the service is reachable (Menesidou

et al., 2017). This can for example become a prob-

lem if an otherwise ofﬂine systems relies on a cloud

KDC. Centralized approaches are prone to infrastruc-

ture failures (Menesidou et al., 2017) and ”may suf-

fer from low availability and poor scalability due to

the low reliability and poor connectivity of networks”

(Saravanan et al., 2011).

To reduce the key management overhead of large-

scale centralized networks, decentralized approaches

can be used (Guoyu Xu et al., 2012). The overhead

is shared between the LC (Menesidou et al., 2017). If

one controller fails this will not affect other groups

/ clusters (Liu et al., 2020), reducing the effect of

the single-point of failure problem (Challal and Seba,

2005). Communication between the groups can lead

to delays, as data needs to be transmitted via the LC

(Liu et al., 2020). As there is no global group key,

multiple encryption and decryption operations are re-

quired. This can be a system bottleneck (Guoyu Xu

et al., 2012) and increase CPU workload and subse-

quent energy consumption.

Distributed approaches solve the single-point of

failure problem (Liu et al., 2020). They improve the

reliability of the overall system, reduce the bottle-

necks in networks (Devaraju and Ganapathi, 2010)

and are more tolerant to infrastructure failure (Men-

esidou et al., 2017). Challenges exist regarding pri-

vacy (Menesidou et al., 2017), storage and commu-

nication overhead (Guoyu Xu et al., 2012; Liu et al.,

2020) when e.g. establishing group keys. This can af-

fect battery lifetime as well as transmission time.

The classiﬁcation into centralized, decentralized

and distributed is most commonly used in group com-

munication (Rafaeli and Hutchison, 2003; Challal and

Seba, 2005; Mapoka, 2013; Sharma and Krishna,

2015; Liu et al., 2020).

3.3 Organization Type

Approaches are self-organized if devices “do not have

to rely on an online centralized TTP to provide key

management services during network deployment”

(De Ree et al., 2019). Certiﬁcate chaining (Cap-

kun et al., 2003) or self-certiﬁcation-based (van der

Merwe et al., 2005) key management can be taken as

examples (De Ree et al., 2019). Those approaches

rely on a partially distributed TTP. The advantage is

that they can handle ofﬂine authorization. Disadvan-

tages are that nodes may act selﬁshly if TTP nodes

leave the group, due to the overhead if being selected

as new TTP. Further such approaches rely on phys-

ical contact to “instantiate trust and distribute keys”

(De Ree et al., 2019).

When using TTP organized approaches different

options exist in what quantity and for which tasks the

third party is needed. In e.g. identity-based encryp-

tion systems, such approaches the public key is re-

placed by one or a set of unique public identiﬁcation

parameters (IDs) (Drias et al., 2017). To generate

a private key, devices transmit their public IDs to a

TTP called PKG. To encrypt a message for a speciﬁc

device D the public key of the PKG and the public

identiﬁcation parameters of D are needed. The TTP

is solely needed for initial key generation. After that

the system can work in a decentralized mode. Sim-

ilar to other centralized approaches the PKG knows

all keys which may be a violation of the privacy and

conﬁdentiality property (key escrow problem) (Drias

et al., 2017). To mitigate this problem the PKG can

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

be taken ofﬂine as soon as system setup is ﬁnished

(Drias et al., 2017). An advantage of identity-based

approaches and at the same time and open issue is the

revocation of keys. The advantage is that there is no

need of CRL. If an entity is no longer in the system

or unreachable, its identity can’t be used to encrypt

messages. The issue lies with compromised private

keys. In this case outgoing and incoming messages

can be manipulated. A solution is to add timestamps

to the public identiﬁers to shorten the cryptoperiod

(Boneh and Franklin, 2001). This increases the times

the PKG is needed as private keys have to be issued

more frequently. Another method is to add a second

TTP called Identity Revocation Server (IRS). Prior to

communication each entity requests a revocation sta-

tus for itself and gets it signed. After that the enti-

ties can send and receive encrypted messages. This

approach to solve the key revocation problem reintro-

duces the need for a reachable TTP.

3.4 Communication Pattern

Key management approaches may differ by the type

of secure communication needed within the managed

systems. Communication may happen in peer-to-

peer fashion (Kandi et al., 2020) (also called uni-

cast or point-to-point (ISO, 2018)) with other nodes

or TTP, within groups (Murugesan and Saminathan,

2018) (also called multicast (Abirami and Padma-

vathy, 2017)) or a combination of those. Key man-

agement faces different challenges depending on the

utilized communication patterns.

Unicast (Point-To-Point) communication needs

unique keys between two entities, which is usually

called pairwise key (Kandi et al., 2020). Messages

can only be read by these two entities. Those should

be agreed on each session anew and be only used

once. Challenges are in establishing the ﬁrst trust

as well as authentication between nodes. Further-

more, key storage can become an issue when numer-

ous point-to-point connections are needed. Unicast

communication suffers from poor scalability and ﬂex-

ibility. Different approaches exist to mitigate this lim-

itations (Kandi et al., 2020).

In group communication a set of entities commu-

nicates with each other. The exchanged messages are

readable by the entire group. A common key must be

known exclusively by current members (Kandi et al.,

2020). Challenges are within group key establishment

and rekeying if an entity leaves or enters the group.

Entities leaving the group should not be able to read

future messages (forward secrecy) and new members

should not be able to decipher old messages (back-

ward secrecy) (Kandi et al., 2020). Another chal-

lenge is communication between groups as separate

keys are needed. Furthermore, group joining, group

leaving and compromise of a group member add ad-

ditional complexity.

Existing solutions still have problems with the het-

erogeneity of embedded systems (Kandi et al., 2020).

Additionally, the same parameters are used indepen-

dently of the submitted data and load is not balanced

fairly between powerful and weak nodes (Kandi et al.,

2020).

All communication patterns are vulnerable to so-

called node capture attacks. The less communication

can be deciphered if a node is compromised the more

resilient this node is against capture (Zhen Yu and

Yong Guan, 2005). To maximize resilience a distinct

key is needed for each pair of devices (Kandi et al.,

2020). As described in Section 3.2 this would have

negative effects for embedded systems.

3.5 Key Establishment Approach

This classiﬁcation focuses on key establishment

methods and divides them into deterministic and

probabilistic (Messai and Seba, 2016; Mesmoudi

et al., 2019). A probabilistic approach was ﬁrst pro-

posed by Eschenauer and Gligor in (Eschenauer and

Gligor, 2002). In such approaches for each member

of a network, a set of keys is chosen, in a random or

semi random way (Abu Al-Haija, 2011). The pool of

keys can be generated by an external server or directly

on the devices (Leshem et al., 2018). After each entity

is equipped with a set of keys, commonly called key

ring (Abu Al-Haija, 2011), two nodes in the network

share the same key with a predeﬁned probability. This

probability is depending on the method used. If two

nodes share any common keys, they can establish a

secure connection between each other.Otherwise they

can try to establish a connection by using other de-

vices as proxies. In the worst case two nodes cannot

establish a connection between each other.

Conversely in deterministic approaches nodes

have a probability of 1 (sure event) to share a com-

mon key with all nodes (Messai and Seba, 2016).

They have less communication overhead as they do

not need to route communication via other devices

(Mesmoudi et al., 2019).

Probabilistic approaches try to improve efﬁciency

and security by minimizing the keys saved per de-

vice. This has a positive effect on storage capacity

and improves resilience against node capture attacks

(Eschenauer and Gligor, 2002). However Xu et al.

argue that these advantages do not have such a great

impact as presumed and have to be opposed to the

increasing complexity and low network connectivity

Secure Key Management in Embedded Systems: A First Proposal

(Xu et al., 2007).

If the amount of nodes in a system increases, stor-

age capacity can becomes a bottleneck for constrained

devices. Probabilistic approaches can reduce the bur-

den but have an impact on communication perfor-

mance.

3.6 Biometric Data

Biometric approaches extract various biometric fea-

tures to create biometric keys (Masdari et al., 2017).

Biometric data can be physiological or behavioral.

The former are measurements of the human body e.g.

ﬁngerprint, iris, retina, hand geometry or face and the

latter are measurements based on human actions e.g.

signatures, keystrokes or voice (Masdari et al., 2017).

As such approaches need physical presence, their use-

cases are limited as they need at least one sensor ex-

tracting some biometric feature. WBAN are one sec-

tor which can use biometric data at no cost as their

sensors mostly already extract those.

Biometrically generated keys can not be used for

conventional cryptographic schemes as those by de-

sign do not tolerate even a single-bit error (Bui and

Hatzinakos, 2007). The challenge in such approaches

is to generate constant and repeatable keys from vari-

ant biometric samples (Chen et al., 2007). A method

to circumvent this problem is to divide biometric

identiﬁers into a set of separate elements. When recal-

culating the key not all measurements have to be cor-

rect to be able to successfully retrieve the key. More-

over, biometric data comes with privacy and security

concerns (Cavoukian, 2007). Storage and misuse for

surveillance, proﬁling etc. is still an issue.

Advantages are that biometric approaches can

generate keys from sensor data. Approaches exist

needing live biometric samples for veriﬁcation and

through that prevents dictionary and brute-force at-

tacks (Chen et al., 2007).

If exterior features such as face, ﬁngerprint or

retina are used they can be stolen and bypassed by

e.g. taking a picture of the victims face or directly

exploiting latent ﬁngerprints remaining on a smart-

phones ﬁngerprint reader (scrap attack) (Kim et al.,

2017).

3.7 Network Topology

Systems can be classiﬁed into ﬂat and hierarchical

(Mesmoudi et al., 2019). In ﬂat systems, all nodes

have the same capabilities in the sense of computa-

tional power, battery life, storage, memory size, etc.

This is different in hierarchical systems. In these sys-

tems, some devices can be more constrained then oth-

ers. This fact can be utilized by key management

approaches to increase performance by distributing

tasks depending on device capabilities (Albakri et al.,

2019). Those approaches are called hierarchical ap-

proaches. For instance in cluster based systems it can

be of advantage if the LC (see section 3.2) is less con-

strained. That enables it to take over computationally

heavy tasks. This can improve the overall efﬁciency

of the system.

3.8 Network Dependability

To operate efﬁciently, network dependent approaches

rely on the features of the underlying network infras-

tructure (Mapoka, 2013). Conversely, network inde-

pendent approaches can be used in different architec-

ture setting (Mapoka, 2013).

4 CONCLUSIONS AND

OUTLOOK

In this work we brieﬂy summarized our ﬁrst steps to-

wards creating a unifying taxnonomy for supporting

developers in the IoT context with the selection of ap-

propriate key management approaches.

We provided a ﬁrst glance at our classiﬁcation,

albeit still omitting important aspects; due to space

constraints we were for example unable to detail the

factors inﬂuencing the actual decision for a speciﬁc

approach, be they internal (like existing know-how

and infrastructure, policies, or strategies), external

(like legislation, customers, competitors), or product-

driven (like environmental conditions, process needs,

project size and of course actual security require-

ments).

So there is still a lot of work ahead in order to

close this existing gap, establishing a generic decision

supporting mechanism to enhance security aspects in

the Internet of Things and embedded systems, respec-

tively.

ACKNOWLEDGEMENTS

Parts of this work were supported by the Embedded

Lab Vienna for IoT & Security, funded by the City of

Vienna.

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

REFERENCES

Abirami, E. and Padmavathy, T. (2017). Proﬁcient key

management scheme for multicast groups using group

key agreement and broadcast encryption. In 2017 In-

ternational Conference on Information Communica-

tion and Embedded Systems (ICICES), Chennai, In-

dia. IEEE.

Abouhogail, R. A. (2014). Security Assessment for Key

Management in Mobile Ad Hoc Networks. Inter-

national Journal of Security and Its Applications,

8(1):169–182.

Abu Al-Haija, Q. (2011). Toward Secure Non-

Deterministic Distributed Wireless Sensor Network

Using Probabilistic Key Management Approaches

Qasem Abu Al-Haija. Journal of Information Assur-

ance and Security, 6.

Abusukhon, A., Mohammad, Z., and Al-Thaher, A. (2019).

Efﬁcient and Secure Key Exchange Protocol Based on

Elliptic Curve and Security Models. In 2019 IEEE

Jordan International Joint Conference on Electrical

Engineering and Information Technology (JEEIT),

pages 73–78, Amman, Jordan. IEEE.

Ahlawat, P. and Dave, M. (2018). Deployment Based At-

tack Resistant Key Distribution with Non Overlapping

Key Pools in WSN. Wireless Personal Communica-

tions, 99(4):1541–1568.

Albakri, A., Harn, L., and Song, S. (2019). Hierarchical

Key Management Scheme with Probabilistic Security

in a Wireless Sensor Network (WSN). Security and

Communication Networks, 2019:1–11.

Alcaraz, C., Lopez, J., Roman, R., and Chen, H.-H. (2012).

Selecting key management schemes for WSN appli-

cations. Computers & Security, 31(8):956–966.

Alohali, B., Kifayat, K., Shi, Q., and Hurst, W. (2015). A

Survey on Cryptography Key Management Schemes

for Smart Grid. Journal of Computer Sciences and

Applications, 3(3A):27–39.

Balasubramanian, A., Mishra, S., and Sridhar, R. (2005).

Analysis of a hybrid key management solution for ad

hoc networks. In IEEE Wireless Communications and

Networking Conference, 2005, volume 4, pages 2082–

2087, New Orleans, LA, USA. IEEE.

Barker, E. (2020). Recommendation for Key Management:

Part 1 - General. Technical report.

Barker, E. and Barker, W. C. (2019). Recommendation for

key management: Part 2 – best practices for key man-

agement organizations. Technical Report NIST SP

800-57pt2r1, Gaithersburg, MD.

Barr Group (2018). 2018 Embedded Systems Safety & Se-

curity Survey Report.

Barskar, R. and Chawla, M. (2016). A Survey on Efﬁ-

cient Group Key Management Schemes in Wireless

Networks. Indian Journal of Science and Technology,

9(14).

Boneh, D. and Franklin, M. (2001). Identity-Based Encryp-

tion from the Weil Pairing. In Goos, G., Hartmanis,

J., van Leeuwen, J., and Kilian, J., editors, Advances

in Cryptology — CRYPTO 2001, volume 2139, pages

213–229. Springer Berlin Heidelberg, Berlin, Heidel-

berg.

Bui, F. M. and Hatzinakos, D. (2007). Biometric Meth-

ods for Secure Communications in Body Sensor

Networks: Resource-Efﬁcient Key Management and

Signal-Level Data Scrambling. EURASIP Journal on

Advances in Signal Processing, 2008(1).

Capkun, S., Buttyan, L., and Hubaux, J. (2003). Self-

organized public-key management for mobile ad hoc

networks. IEEE Transactions on Mobile Computing,

2(1):52–64.

Cavoukian, A. (2007). Biometric Encryption : A Positive-

Sum Technology that Achieves Strong Authentication

, Security AND Privacy.

Challal, Y. and Seba, H. (2005). Group Key Management

Protocols: A Novel Taxonomy. Information Technol-

ogy - IT, 2.

Checkpoint (2018). Faxploit HP Printer Fax Exploit.

Chen, H., Sun, H., and Lam, K.-Y. (2007). Key Manage-

ment Using Biometrics. In The First International

Symposium on Data, Privacy, and E-Commerce (IS-

DPE 2007), pages 321–326, Chengdu, China. IEEE.

Dawson, R., Boyd, C., Dawson, E., and Nieto, J. (2006).

SKMA: a key management architecture for SCADA

systems. In Conferences in Research and Practice

in Information Technology Series, volume 54, pages

183–192.

De Ree, M., Mantas, G., Radwan, A., Mumtaz, S., Ro-

driguez, J., and Otung, I. E. (2019). Key Management

for Beyond 5G Mobile Small Cells: A Survey. IEEE

Access, 7:59200–59236.

Devaraju, S. and Ganapathi, P. (2010). Dynamic Clustering

for QoS based Secure Multicast Key Distribution in

Mobile Ad Hoc Networks. IJCSI International Jour-

nal of Computer Science, 7.

Dowsley, R., Gabel, M., Hubsch, G., Schiefer, G., and

Schwichtenberg, A. (2016). A Distributed Key Man-

agement Approach. In 2016 IEEE International Con-

ference on Cloud Computing Technology and Science

(CloudCom), pages 509–514, Luxembourg, Luxem-

bourg. IEEE.

Drias, Z., Serhrouchni, A., and Vogel, O. (2017). Identity-

based cryptography (IBC) based key management

system (KMS) for industrial control systems (ICS).

In 2017 1st Cyber Security in Networking Conference

(CSNet), Rio de Janeiro. IEEE.

Eschenauer, L. and Gligor, V. D. (2002). A key-

management scheme for distributed sensor networks.

In Proceedings of the 9th ACM conference on

Computer and communications security - CCS ’02,

page 41, Washington, DC, USA. ACM Press.

European Union and Agency for Network and Information

Security (2017). Baseline security recommendations

for IoT in the context of critical information infras-

tructures.

European Union Agency for Cybersecurity (2019). Good

practices for security of IoT: secure software develop-

ment lifecycle.

Grand View Research (2014). Embedded System Market

Report Embedded System Market Analysis By Prod-

uct (Hardware, Software), By Application (Automo-

tive, Telecommunication, Healthcare, Industrial, Con-

Secure Key Management in Embedded Systems: A First Proposal

sumer Electronics, Military & Aerospace) And Seg-

ment Forecasts To 2020. Technical report.

Guoyu Xu, Xingyuan Chen, and Xuehui Du (2012). Chi-

nese Remainder Theorem based DTN group key man-

agement. In 2012 IEEE 14th International Confer-

ence on Communication Technology, pages 779–783,

Chengdu, China. IEEE.

Haque, M. E., Zobaed, S., Islam, M. U., and Areef, F. M.

(2018). Performance Analysis of Cryptographic Al-

gorithms for Selecting Better Utilization on Resource

Constraint Devices. In 2018 21st International Con-

ference of Computer and Information Technology (IC-

CIT), pages 1–6, Dhaka, Bangladesh. IEEE.

Harn, L., Hsu, C.-F., and Li, B. (2018). Centralized

Group Key Establishment Protocol without a Mutu-

ally Trusted Third Party. Mobile Networks and Appli-

cations, 23(5):1132–1140.

Huang, X. and Chen, R. (2018). A Survey of Key Man-

agement Service in Cloud. In 2018 IEEE 9th In-

ternational Conference on Software Engineering and

Service Science (ICSESS), pages 916–919, Beijing,

China. IEEE.

Humayed, A., Lin, J., Li, F., and Luo, B. (2017). Cyber-

Physical Systems Security—A Survey. IEEE Internet

of Things Journal, 4(6):1802–1831.

ISO (2018). Information technology - Security techniques

- Key management - Part 2: Mechanisms using sym-

metric techniques. Standard ISO/IEC 11770-2:2018,

Geneva, CH.

Jank, G. (2020). Secure key management in embedded sys-

tems. Master’s thesis, FH Campus Wien - University

of Applied Sciences.

Jansma, N. and Arrendondo, B. (2004). Performance Com-

parison of Elliptic Curve and RSA Digital Signatures.

Kandi, M. A., Lakhlef, H., Bouabdallah, A., and Challal, Y.

(2020). A versatile Key Management protocol for se-

cure Group and Device-to-Device Communication in

the Internet of Things. Journal of Network and Com-

puter Applications, 150.

Kim, S., Lee, H., and Kwon, T. (2017). POSTER: Re-

thinking Fingerprint Identiﬁcation on Smartphones. In

Proceedings of the 2017 ACM SIGSAC Conference

on Computer and Communications Security, pages

2515–2517, Dallas Texas USA. ACM.

Kolias, C., Kambourakis, G., Stavrou, A., and Voas, J.

(2017). DDoS in the IoT: Mirai and Other Botnets.

Computer, 50(7).

Lavanya, S. and Usha, D. (2017). A Survey on Key Man-

agement in Internet of Things. SSRN Electronic Jour-

nal.

Leshem, G., David, E., and Domb, M. (2018). Probability

Based Keys Sharing for IOT Security. In 2018 IEEE

International Conference on the Science of Electrical

Engineering in Israel (ICSEE), pages 1–5, Eilat, Is-

rael. IEEE.

Liu, A. and Ning, P. (2008). TinyECC: A Conﬁgurable

Library for Elliptic Curve Cryptography in Wireless

Sensor Networks. In 2008 International Conference

on Information Processing in Sensor Networks (ipsn

2008), pages 245–256, St. Louis, MO, USA. IEEE.

Liu, J., Tong, X., Wang, Z., Zhang, M., and Ma, J. (2020).

A Centralized Key Management Scheme Based on

McEliece PKC for Space Network. IEEE Access,

8:42708–42719.

Malik, M., Dutta, M., and Granjal, J. (2019). A Survey

of Key Bootstrapping Protocols Based on Public Key

Cryptography in the Internet of Things. IEEE Access,

7:27443–27464.

Manikandan, G. and Sakthi, U. (2018). A Comprehen-

sive Survey on Various key Management Schemes in

WSN. In 2018 2nd International Conference on I-

SMAC (IoT in Social, Mobile, Analytics and Cloud) (I-

SMAC)I-SMAC (IoT in Social, Mobile, Analytics and

Cloud) (I-SMAC), 2018 2nd International Conference

on, pages 378–383, Palladam, India. IEEE.

Mapoka, T. T. (2013). Group Key Management Proto-

cols for Secure Mobile Multicast Communication:

A Comprehensive Survey. International Journal of

Computer Applications, 84(12):28–38.

Masdari, M., Ahmadzadeh, S., and Bidaki, M. (2017). Key

management in wireless Body Area Network: Chal-

lenges and issues. Journal of Network and Computer

Applications, 91:36–51.

Menesidou, S. A., Katos, V., and Kambourakis, G. (2017).

Cryptographic Key Management in Delay Tolerant

Networks: A Survey. Future Internet, 9(3):26.

Menezes, A. J., Van Oorschot, P. C., and Vanstone, S. A.

(1997). Handbook of applied cryptography. CRC

Press series on discrete mathematics and its applica-

tions. CRC Press, Boca Raton.

Mesmoudi, S., Benadda, B., and Mesmoudi, A. (2019).

SKWN: Smart and dynamic key management scheme

for wireless sensor networks. International Journal of

Communication Systems, 32(7).

Messai, M.-L. and Seba, H. (2016). A survey of key man-

agement schemes in multi-phase wireless sensor net-

works. Computer Networks, 105:60–74.

Mirjalili, S. H. and Lenstra, A. K. (2008). Security Obser-

vance throughout the Life-Cycle of Embedded Sys-

tems. In ESA.

M.K, J., Abhiraj, K. S., Bolloju, S., Brukbacher, S., Carullo,

G., Dhungel, R., Donahoe, T., Duddilla, R., Duren,

D. V., Falletta, L., Yeoh, J., Santos, J., Ferrari, L.,

Figuigui, A., Futagi, M., Grimes, M., Guzman, A.,

Hendrickson, H., Khemissa, S., Lanois, P., Kanni-

moola, J. M., Naik, S., Perera, C., Rajapaksha, S., Ru-

pasinghe, L., Sharma, A., Szewczul, M., Tatipamula,

S., Thikkavarapu, S., and White, K. (2016). Future-

prooﬁng the Connected World: 13 Steps to Develop-

ing Secure IoT Products.

Murugesan, A. and Saminathan, B. (2018). Key manage-

ment for secured group communication. International

Journal of Pure and Applied Mathematics, 118:33–37.

Naﬁ, M., Bouzefrane, S., and Omar, M. (2020). Matrix-

based key management scheme for IoT networks. Ad

Hoc Networks, 97.

Nie, S., Liu, L., and Du, Y. (2017). FREE-FALL: HACK-

ING TESLA FROM WIRELESS TO CAN BUS.

Keen Security Lab of Tencent.

Obermaier, J., Hauschild, F., Hiller, M., and Sigl, G. (2018).

An embedded key management system for PUF-based

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

security enclosures. In 2018 7th Mediterranean Con-

ference on Embedded Computing (MECO), pages 1–6,

Budva, Montenegro. IEEE.

Payment Security Support Group (2018). European Pay-

ments Council: Guidelines on Cryptographic Algo-

rithms Usage and Key Management - Version 8.0.

Technical Report EPC342-08.

Rafaeli, S. and Hutchison, D. (2003). A survey of key man-

agement for secure group communication. ACM Com-

puting Surveys, 35(3):309–329.

Rajendran, G. and Nivash, R. (2019). Security in the Em-

bedded System: Attacks and Countermeasures. SSRN

Electronic Journal.

Raza, S. and Mar Magnusson, R. (2019). TinyIKE:

Lightweight IKEv2 for Internet of Things. IEEE In-

ternet of Things Journal, 6(1):856–866.

Sadeghi, A.-R., Wachsmann, C., and Waidner, M. (2015).

Security and privacy challenges in industrial internet

of things. In Proceedings of the 52nd Annual Design

Automation Conference on - DAC ’15, San Francisco,

California. ACM Press.

Saravanan, D., Rajalakshmi, D., and Maheswari, D. (2011).

DYCRASEN: A Dynamic Cryptographic Asymmet-

ric Key Management for Sensor Network using Hash

Function. International Journal of Computer Appli-

cations, 18(8):1–3.

Sharma, S. and Krishna, C. R. (2015). An Efﬁcient Dis-

tributed Group Key Management Using Hierarchical

Approach with Elliptic Curve Cryptography. In 2015

IEEE International Conference on Computational In-

telligence & Communication Technology, pages 687–

693, Ghaziabad, India. IEEE.

Vai, M., Nahill, B., Kramer, J., Geis, M., Utin, D., Whe-

lihan, D., and Khazan, R. (2015). Secure architec-

ture for embedded systems. In 2015 IEEE High Per-

formance Extreme Computing Conference (HPEC),

pages 1–5, Waltham, MA, USA. IEEE.

van der Merwe, J., Dawoud, D., and McDonald, S. (2005).

Fully self-organized peer-to-peer key management for

mobile ad hoc networks. In Proceedings of the

4th ACM workshop on Wireless security - WiSe ’05,

page 21, Cologne, Germany. ACM Press.

Vasukidevi, G. and Sethukarasi, D. R. (2017). A Survey on

Security and Key Management in VANET.

Wadhwani, P. and Yadav, S. (2020). Embedded systems

market size by component (hardware, [asic & assp,

microcontroller, microprocessor, power management

integrated circuit (pmic), ﬁeld programmable gate ar-

ray (fpga), digital signal processor (dsp), memory],

software (os, middleware)], by function (standalone

system, real-time system, network system, mobile

system), by application (automotive, consumer elec-

tronics, manufacturing, retail, media & entertainment,

military & defense, telecom), industry analysis re-

port, regional outlook, application potential, competi-

tive market share & forecast, 2020 – 2026. Technical

report.

Wan, J., Lopez, A. B., and Al Faruque, M. A. (2016).

Exploiting Wireless Channel Randomness to Gener-

ate Keys for Automotive Cyber-Physical System Se-

curity. In Proceedings of the 7th International Con-

ference on Cyber-Physical Systems, ICCPS ’16. IEEE

Press.

Whelihan, D., Vai, M., Utin, D., Khazan, R., Gettings,

K., Anderson, T., Godfrey, A., Govotski, R., Yea-

ger, M., Chetwynd, B., Nahill, B., and Koziel, E.

(2016). SHAMROCK: A Synthesizable High Assur-

ance Cryptography and Key management coprocessor.

In MILCOM 2016 - 2016 IEEE Military Communica-

tions Conference, pages 55–60, Baltimore, MD, USA.

IEEE.

Xu, D., Huang, J., Dwoskin, J., Chiang, M., and Lee, R.

(2007). Re-examining Probabilistic Versus Determin-

istic Key Management. In 2007 IEEE International

Symposium on Information Theory, pages 2586–2590.

IEEE.

Zhen Yu and Yong Guan (2005). A robust group-based key

management scheme for wireless sensor networks. In

IEEE Wireless Communications and Networking Con-

ference, 2005, volume 4, pages 1915–1920, New Or-

leans, LA, USA. IEEE.

Secure Key Management in Embedded Systems: A First Proposal
