Detection and Prevention of Denial-of-Service in

Cloud-based Smart Grid

Abdul Razaq

, Muhammad Majid Hussain

, Waqas Javed

, Tasmiyah Javed and Zulfiqar A. Memon

School of Design and Informatics, Abertay University, Dundee, U.K.

Department of Electrical & Electronic Engineering, University of South Wales, Cardiff, U.K.

Department of Electrical Engineering, University of Engineering & Technology, Lahore, Rachna campus, Pakistan

Department of Electrical and Computer Engineering, Ajman University, Ajman, U.A.E.

Keywords: Cloud based Smart Grid, Denial-of-Service, IDS/IPS, Cyber-security.

Abstract: Smart Grid (SG), components with historical set of security challenges, becomes more vulnerable because

Information and Communications Technology (ICT) has its own share of problems while Cloud infrastructure

adds yet another unpredicted layer of threats. Scalability and availability, which are strong aspects of the cloud

platform making it attractive to users, also attracts security threats for the same reasons. The malware installed

on single host offers very limited scope compared to attack magnitude that compromised Cloud platform can

offer. Therefore, the strongest aspect of Cloud itself becomes a nightmare in Cloud-Based SG. A breach in

such a delicate system can cause severe consequences including interruption of electricity, equipment damage,

data breach, complete blackouts, or even life-threatening consequences. We mimic Denial-of-Service (DoS)

attacks to demonstrate interruption of electricity in SG with open-source solution to co-simulate power and

communication systems.

1 INTRODUCTION

SG promises reduced energy consumption, lower

production cost and robust transmission with

intelligent distribution. SGs are exposed to a

distinctive set of security threats because two

different systems of Power Electronics and ICT are

integrated to form a system with single core function:

“Uninterruptable and Cost-Effective Energy Supply”.

At the writing of this draft, not a single country has a

true and complete SG setup in place. Beside the

ordinary cost issues of installations or upgrading

existing systems; critical question of reliability is

unanswered. Cyber security for SG is of immense

concern because of emerging cyber-threats and

security incidents targeting smart grids all over the

world. These threats are severe and obvious in SG

systems if deployed without appropriate

measurements. A cyber-attack at Maroochy Shire

resulted in the release of untreated water and attack

on Davis-Besse nuclear plant, USA, disabled the

safety system (Yang, 2011). Stuxnet worm attack at

Iran’s nuclear power station halted the work and a

https://orcid.org/0000-0002-6255-6966

recent bug termed as ‘HeartBleed’ in OpenSSL has

initiated debate in the research community for

dedicated security measures and re-assessment of

user grade software solutions for multibillion national

assets such as power grids.

Existing security measurements are insufficiently

scalable, incompatible, or simply inadequate to

address the challenges posed by highly complex

environments such as smart grid. Below are the

possible security threats originated by DoS attacks

and general aspects of toolsets to emulate such

models in terms of usability, extensibility, and

accuracy

1.1 Security and Privacy in Physical

Grid

The performance of power grid considerably relies on

the actual physical devices and deployed

environment; therefore, devices should be critically

designed to sustain adverse environmental factors

(Stouffer and Falco, 2006) and possible brutal force

attacks. Master terminal units (MTUs) and remote

172

Razaq, A., Hussain, M., Javed, W., Javed, T. and Memon, Z.

Detection and Prevention of Denial-of-Service in Cloud-based Smart Grid.

DOI: 10.5220/0010449901720179

In Proceedings of the 10th International Conference on Smart Cities and Green ICT Systems (SMARTGREENS 2021), pages 172-179

ISBN: 978-989-758-512-8

terminal units (RTUs) controlling programmable

logic controllers (PLCs) from generation to

transmission systems require strict timing to control

the demand and supply of electricity. Automation in

SG is commonly accomplished with Supervisory

Control and Data Acquisition (SCADA) system.

SCADA devices are real-time or non-real-time

(Muhammad and Siddique, 2020) small computer

system that manipulates electrical outputs based on

the condition of electrical input signals and program

logic. In theory, these systems consist of Human

Machine Interface (HMI) situated in operation

facilities which are part of MTU. MTU is used to

monitor RTU which is eventually connected to PLC

for automation (Liu and Xiao, 2012). Data

communication between RTUs and MTU occurs over

wired telephone lines or wireless cellular

technologies.

1.2 Security and Privacy in Information

and Communications Technology

ICT provided necessary communication means and

protocols for control and data exchange in SG.

Security of interconnected devices and subsystems is

important, but it should not result in a degraded and

unreliable system. Efficiency and reliability should be

achieved with only secure and completive open

solutions (Hahn and Member, 2013). The (Bou-Harb,

2013) investigated communication in distributed

networks and smart meters. They suggest that

distributed devices and applications should follow

design objectives including device authentication,

data confidentiality, message integrity, prevention

mechanism for cyber-attacks and facilitating

communication overhead.

Historically (Galloway and Hancke, 2013),

control in industrial automation was done

mechanically with hydraulic controllers or manually.

These mechanical components were upgraded once

electronics such as transducers, relays and hard-wired

control circuits became available. This changed to

new dimensions when small microcontrollers were

introduced which would allow smaller size and ability

to connect over wire or wireless. Electronics based

digital systems are able to remotely control and

monitor various power grid components with various

connectivity means and communication protocols.

These communications protocols are commonly

referred to as fieldbus protocols. Various protocols

and technologies are being used in traditional power

grids for networking purpose such as ModBus,

ModBus+, ProfiBus, ICCP, DNP3, PROFINET,

INTERBUS, WorldFIP, etc. It is important to note

that all these were designed without considering

cyber security. Existing deployed communication

protocols were developed under the umbrella of

IEEE, IEC and DNP3. IEC 60870-5 and DNP3 are

considered most widely used protocols in the

automation industry. IEC is typically used in

European countries and recognized by IEEE 1379

standard which is used in Asia and North America

(Liu and Xiao, 2012).

1.3 Security and Privacy in

Cloud-based Smart Grid

Cloud virtualization presents a logical view of

resources while encapsulating heterogeneity,

complexity, and distributed characteristics with

unified interface. Cloud computing provides virtually

aggregation of dispersed resources beside remote

accessibility. The emerging technologies in Cloud

based platforms present feasible solution for

processing and storage thriving domains such as SG.

Cloud-Based capability will allow ordinary resource

limited devices in SG with low power CPU and

limited memory to execute resource intensive

security protocols. It is also important to note that

Cloud platforms are prone to open access and

anonymous attacks

Data and software in cloud resides on network

which poses a unique set of security and privacy

challenges to the system. A survey conducted by

(Bera, 2015) provides comprehensive discussion on

Cloud applications for SG in contrast to conventional

solutions that exist without Cloud. Traditional

solutions need point to point physical connection

whereas cloud can provide virtual control of any node

without any real physical connection or media.

Similar (Genge and Beres, 2014) survey on existing

cloud–based solutions for SG without any details on

security criteria concludes that security in cloud

storage, communication paths between Cloud with

Grid and security within SG are basic system

requirements.

The (Markovic, 2013) provided comprehensive

survey on cloud in SG. An interesting comparison is

provided between conventional and smart grids and

how cloud solutions can effectively apply in

integration, reduced control latency, virtualized

energy sources and load management. Study

conducted on Los Angeles SG to address S&P in this

development investigates software layers on various

levels in cloud settings. The similar work is

investigated by (Simmhan, 2011)and emphasis on

data mining and aggregation of 1.4 million power

customers in municipality of United States of

America. Reporting, transporting, and storing huge

Detection and Prevention of Denial-of-Service in Cloud-based Smart Grid

173

data (Bigdata) without native support of encryption

can result in poor performance on Cloud platform. SG

user applications should address privacy threats while

utilizing datasets obtained continuously which

represent user behaviour.

A comprehensive report published by (Akyol,

2012) under the umbrella of Department of Defence,

United States concluded that power grids will

eventually deploy cloud computing and this shift will

be gradual only if the cyber security challenges are

addressed. Report further recommends that utility

providers must comply with NIST 2010 and NIST

2011 cyber security requirements analysis and design

methodologies. A mechanism implemented on

Eucalyptus open-source platform by (Baek, 2014)

based on ID, encryption and proxy validation

provides an ideal solution. However, cascading of

trust layers can prove to be dangerous if cooperating

layer is compromised. Proposed Smart-Framework is

interesting as far as it fulfils the trust criteria.

The (Alcaraz, 2011) investigated this in very

details of SCADA and how a virtual secure blanket

can efficiently execute console to hardware

commands with cryptic and efficiently. This virtual

control not only provides access to resources but also

guarantees scalability and availability with re-routing

solutions for communication infrastructure.

However, introducing virtual control layer over

critical physical instalments would introduce latency

which can result in fatal consequences. Recently,

(Armando, 2014) investigated smart metering data in

cloud with attribute-based control model. They have

used open-source Energy Home platform for

proposed security framework. Solution partially

addresses the security access problem assuming that

data transportation and storage is secured.

1.4 Denial-of-Service Threats in Smart

Grid

(He and Chan, 2014 ) proposed a mechanism based

on MicaZ and TelosB motes to resist DoS attacks

against adversaries and legitimate insiders. They

suggest that public key infrastructure (PKI) is valid

solution for uninterruptible service; however,

deployment of PKI is directly proportional with cost

for large scale networks such as SG. Different

security protocols have been suggested depending

upon the applications’ scalability and resources on

board. (Lu and Wang, 2010) reviewed the security

threats of DoS in DNP3 and classified these into three

types: network availability, data integrity and

information privacy, and evaluated their feasibility

and impact on the smart grid.

(Liu, 2013) investigated DoS attacks on load

frequency control (LFC) in SG while analysing

dynamic performance of communication channels

connected to RTUs in power systems. Case-studies of

simulated DoS attacks were modelled as a switched

(on/off) power system and two-area LFC theoretical

model was built for different attack-launching

instants. It has been concluded that adversaries can

make power system unstable via DoS attacks if

communication channels of RTUs are jammed.

Similar work by (Liu and Chen, 2013) also

investigated jamming threat but for wireless networks

in the power systems. They suggested that traditional

anti-jamming techniques can serve the purpose with

additional measurements. A local controller with

channel hoping is proposed to reduce possible DoS

threats.

In (Manandhar, 2014) investigated theory of false

data injection (DoS) attacks in power systems and

proposed Kalman Filter (KF). They suggest that DoS

attacks can be averted with linear quadratic

estimation (KF) detectors for sensors in SG such as

PMUs which measure current phase and amplitude in

power systems. The projected values by KF and

incoming instant values can be compared to detect an

anomaly in the system.

Recently, (Sgouras, 2014) presented qualitative

assessment of DoS attacks with simulation in

OMNeT++ and INET framework. They examined

performance of AMIs, routers and utility servers

under such situation. An attack on AMI would result

in minor consequences connected to single entity

whereas similar scenarios for utility server would

cause drastic effects during peak hours. Similar work

was conducted by (Yi, Zhu, 2014) to demonstrate the

impact of DoS in ICT without involving power grid

simulation. They termed DoS attack as puppet attack

which would penetrate in the system like warm and

continue to congest the communication channels with

false data until the network is exhausted.

1.5 Cloud based Intrusion Detection

System and Intrusion Prevention

System in Smart Grid

Intrusion Detection System (IDS) with Intrusion

Prevention System (IPS) or combined Intrusion

Detection and Prevention System (IDPS) is a system

which is meant to detect and prevent the unwanted

activity. In a cloud environment where infrastructure

and resources are in the form of services, a system of

IDPS should also adopt service-oriented design.

(Patel, 2013) presented a systematic review of

existing IDPS techniques and how they are

SMARTGREENS 2021 - 10th International Conference on Smart Cities and Green ICT Systems

174

insufficient for Cloud platform. Classic IDPSs are

unable to address security challenges that are

presented in mix-network-topology, multi-user, and

mixture of software layers in Cloud platforms.

(Mohamed and Adil, 2013) adopted to monitor

system calls generated by virtual machine's programs

to the hypervisor. This approach is limited to and

false alarm would be huge problem if legitimate, but

not-document application is executed. This technique

also suffers with typical system overloading and

lower throughput problem as monitoring all the

systems calls and their call sequence.

In Cloud computing IDS has its applicability on

Virtual machine level. The (Alina, 2013) proposed a

multilevel protection mechanism , the system

consists of front-end control and IDS on virtual

machines. Authors claim to reduce number of false

alarms with efficient detection of real threats. This

approach short falls if trust system is compromised, a

similar attack reported but with different weigh will

be undetected. Recently, (Li and Sun, 2012) proposed

anomaly-based solution with neural settings for

artificially sensing the activity. Neural configuration

helps to distribute the workload of IDS to spread

algorithm across Cloud rather chocking a single

machine. This technique of load balancing is natural

as far as all entities share the same interest and

participate with resources and time. The (Vaid and

Verma, 2014) proposed IDPS based on user

behaviour to detect malicious activities, the proposed

system is meant to be implemented as SaaS layer of

cloud. In (Maiti and Sivanesan, 2012) presented

simple but practical implementation of Cloud based

intrusion detection system. The presented idea

provides a simple yet robust example how cloud-

based security service can leverage on vast resources

for resource limited system.

A researcher (Tupakula, 2011) elaborated design

suggestions for virtual machine based IDPS targeted

for IaaS. Proposed design will require continuous

monitoring of operating systems calls and application

logging , this method is not ideal for systems with

strict timing needs and limited resources untilled data

mining techniques are adopted. Researchers

(Mehmood and Habiba, 2011) presented a

comprehensive discussion on different solutions for

Cloud security. Authors have suggested that IDS

should utilize multiple or hybrid solutions for

effective detection in Cloud security challenges.

Recently, (Prajapati, 2014) critically investigated

classical solutions and concluded that databases of

incident used to detect anomaly have low reliability.

This approach drastically increases the database size

and can introduce latency in monitor and detector

functionality. (Sathya and Vasanthraj, 2013) also

investigated Cloud based pattern matching IDPS and

have introduced multilevel detection system. Their

solution can suffer from overloading as auditing and

logging will require ample resources and monitoring

each activity will reduce overall system throughput.

In section 1 evaluate existing work in literature

review that encircles challenges presented in SG

system from power systems to communication

technologies and cloud. Section 1 also describes

possible security threats originated by DoS attacks

and general aspects of toolsets to emulate such

models in terms of usability, extensibility, and

accuracy. Section 2 represents a proposed technique.

Finally, work in progress is presented in section 3

with simulation of DoS in SG system for protected

and insecure settings before concluding with

discussion and future directions.

2 PROPOSED TECHNIQUES

In this section, we propose techniques to simulate

DoS attack and methodologies adopted to address this

attack (Abdul and Huaglory , 2016). Power and

network architecture is presented with specifications

of physical components and link layouts with

functional configurations. Several solutions were

evaluated as described in the literature review section.

Most of these solutions simulate SG with a

combination of network and power simulators (PS)

based on commercial and open-source tools.

Our proposed simulation uses NeSSi2 due to its

open-source license and ability to simulate power and

IP networks as a single application. NeSSi2 is a

scenario and profile-based simulation tool. Each

network in NeSSi2 consists of at least one scenario

which is eventually profiled depending upon required

simulation. A scenario defines type of profiles that

can be deployed on each node of the network.

Multiple profiles can be deployed on a single node

within a single scenario. A profile is a component to

provide a specific set of functionalities incorporating

single or various features relevant to power and IP

network simulation, which can be deployed onto SG

nodes. Finally, profiled scenario requires a simulation

component which allows the mapping of power and

network domains while linking the corresponding

entities. NeSSi2 is capable to generate various attack

scenarios and traffic analysis.

Figure 1 presents the high-level topology of

proposed SG simulation for both networks. Power

network is represented on the left side with the

corresponding IP network presented on the right side.

Detection and Prevention of Denial-of-Service in Cloud-based Smart Grid

175

Power network consists of one generator and two

consumption subnets representing insecure and

secure gird configurations. Parallel IP network also

consists of similar topology with server as a main

subnet connected to insecure and secure subnets.

Mapping between power and IP network is

configurable on node level within the simulation.

Figure 1: Proposed SG network topology.

Detailed configuration of proposed power

network based on is shown in figure 2. The power

grid consists of green generation based on solar panel

with output of 5147W. Two step-down transformers

with varying current of 380kV to 220kV are in place

between generation and consumption which depict

transmission and distribution. These swing bus

profiled transformers are eventually connected to two

consumption local grids: “Secure” and “Protected.”

As solar generation is considered unreliable, depends

on surrounding environment, a swing bus is used

between the links from solar panel to transmission

transformer. Swing bus accommodates system losses

by emitting or absorbing active/reactive power

to/from the system. The transformer connected to

insecure subnet is profiled with line failure profile to

simulate the unviability of load during power

interruption. Line failure profile of NeSSi2 allows

simulating the load unavailability in target power line

between required time intervals. This line failure

profile only accepts a single power link and can be

mapped to one instance of application. Consumption

subnets further consists of one transformer and two

smart houses. These smart houses are capable to

simulate load consumption and are mapped to

corresponding IP nodes in IP network for

communication simulation. Smart houses are capable

to emulate load usage depending upon time, weather,

and number of persons.

Configuration of proposed 100Mbps IP network

is presented in Figure 3. Main subnet or Server subnet

is connected to two subnets labelled as Insecure

Subnet and Secure Subnet. Server node with Server

subnet is profiled as Echo server application serving

both connected subnets.

Server subnet is connected to insecure subnet

without any protection mechanism in place, whereas,

secured subnet is connected via front-end firewall.

Moreover, secured subnet deploys additional firewall

at client's interface level in case router has been

compromised by malicious activity. DoS attacks

simulated via BOT component are presented in both

insecure and secure subnets. The firewall alone is not

a sufficient solution; an Intrusion Prevention System

(IPS) along with Intrusion Detection System (IDS)

must be carefully designed and deployed side-by-side

for complete protection. NeSSi2's firewall and packet

sniffer profiles are very limited which results in

restricted functionality.

Figure 2: Power network layout.

Figure 3: IP network layout.

SMARTGREENS 2021 - 10th International Conference on Smart Cities and Green ICT Systems

176

3 SIMULATIONS OF

DENIAL-OF-SERVICE

ATTACKS AND DETECTIONS

IN SMART GRID

All nodes of IP network are configured with default

load (echo client/server) at the beginning of

simulation, but the packet flow is increased to

demonstrate the packet loss which is turn depicts the

DoS. DoS or inability to serve the legitimate

incoming requests is a phenomenon where system’s

capacity has reached its maximum throughput and

prompts to unavailability of given service. Ability to

handle DoS attacks is crucial due to the power electric

grid’s strict availability requirements. Botnet attack is

emulated in both secure and insecure networks for

DoS attack. The BOT profile of NeSSi2 is limited to

only specify the attack start time and can only target

single IP node. All these IP nodes are mapped to

smart houses in a power network with a one-to-one

relationship, which means that a house in a power

grid has a counterpart IP client in an IP network.

This simulation is executed for 1000 ticks and

failure or interruption of electricity and

communication is simulated between 105-350, 500-

600 and 800-900 ticks (time intervals). A tick is the

smallest possible time interval (event) in NeSSi2. The

actual time length depends on the simulation,

simulation mode and underlying hardware platform.

The solar panel model is set to produce 5147W peak

production whereas smart houses are simulated for 5

Figure 4: Server communication - secure and insecure

subnets.

Figure 5: Secure IP client.

persons each with 0.90% consumption of received

load.

Figure 4 provides simulation statistics of 1000

tick of server’s echo response to secure and insecure

subnet nodes. The communication packets are

presented along vertical axis whereas horizontal axis

present numbers of ticks or simulation time itself.

Interruption of insecure subnet is visible between

failed intervals with less density of packets compared

to tick intervals for secure subnet. The successful or

uninterrupted communication between server and

secure subnet can be verified in figure 5 which

demonstrated the continuous request sent by a secure

client.

Communication of insecure client is presented in

Figure 6. Packet drop statistics marked with cyan

colour simulates the failure scenario when client was

under attack from BOT and failed to process the echo

packets. Successful echo request is marked in yellow

colour whereas packets in magenta colour represent

forwarded packets. The successful and drop packets

can be compared with server’s statistics which

illustrates the fewer number of packets during failed

communication of insecure client. These failed

intervals can also be cross-checked in figure 7 which

presents the load statistic of insecure smart house.

The mapping between insecure client and smart house

is done prior to simulation and smart house is profiled

with smart house consumption profile along line

failure profile on transformer link level. The

corresponding IP client is profiled with echo client

and device failure.

Figure 6: Insecure IP client.

Figure 7: Power interruption of insecure house.

Detection and Prevention of Denial-of-Service in Cloud-based Smart Grid

177

4 DISCUSSION AND

CONCLUSIONS

Virtualization technologies in SG focus on

availability, aggregation and accessibility of

computing, storage, and network resources; without

consideration of security. A shift to cloud-based SG

is focused on the deliverability of services with

respect to cost and throughput. However, security

threats within these architectures not only remain the

same but it is even more severe when deployed in a

critical system of SG. Security in Cloud-based SG is

complex because of its multi-layered nature. Which

entity should be responsible for threat handling? Is it

applications, devices, services, or infrastructure

providers?

DoS is an instinctive security threat which include

hardware failure to service interruption. Efficiency to

revert DoS without considerable change in QoS is

important both during under-attack and afterwards.

Detection and prevention are a set of a single security

function divided into two conceptual sub-functions:

IDS and IPS. These two distinguishable methods

offer first line of defence in the event of DoS attack.

DoS and IDPS are also directly proportional in terms

of resources. The more intense the DoS attack, the

greater the resources of processing and data mining

techniques are required for IDPS. Cloud based

security-as-a-service technique for IDPS overcomes

this classic limitation.

We examined the importance of SG for future

energy requirements followed by detailed security

challenges that are presented in Cloud Based SG

systems. We demonstrated DoS attack and how this

can cause the interruption of electricity while

simulating the power and IP networks in parallel. We

also simulated ICT configuration for SG security that

can withstand DoS attack while ensuring the

uninterruptible communication and power. Finally,

we suggested that simulators for critical systems such

as SG should be able to simulate defence techniques,

including firewalls and IPS/IDS practices to avert

possible attacks.

REFERENCES

Akyol, B. A., 2012. Cyber security challenges in using

cloud computing in the electric utility industry. Pacific

Northwest National Laboratory.

Alcaraz, C., Agudo, I., Nunez, D., Lopez, J., .2011.

Managing incidents in smart grids a la cloud. IEEE 3rd

International Conference on Cloud Computing

Technology and Science. pp. 527-531.

Armando, A., Carbone, R., Chekole, E. G., Petrazzuolo, C.,

Ranalli, A., Ranise, S., 2014. Selective Release of Smart

Metering Data in Multi-domain Smart Grids. Intl.

Workshop on Smart Grid Security. pp. 48-62.

Baek, J., Vu, Q., Liu, J., Huang, X., Xiang, Y., 2014. A

secure cloud computing-based framework for big data

information management of smart grid. IEEE

Transactions on Cloud Computing. pp.233-344.

Bera, S., Misra, S., Rodrigues, J. J., 2015. Cloud Computing

Applications for Smart Grid: A Survey. IEEE

Transactions on Parallel and Distributed Systems. pp.

1477-1494.

Bou-Harb, E., Fachkha, C., Pourzandi, M., Debbabi, M.,

Assi, C., 2013. Communication security for smart grid

distribution networks. IEEE Communications

Magazine. pp. 42-49.

Galloway, B., Hancke, G. P., 2013. Introduction to

Industrial Control Networks. IEEE Communications

Surveys & Tutorials. pp.860-880.

Genge, B., Beres, A., Haller, P., 2014. A survey on cloud-

based software platforms to implement secure smart

grids. 49

International Universities Power

Engineering Conference. pp. 1-6.

Hahn, A., Member, S., Ashok, A., 2013. Cyber-Physical

Security Testbeds: Architecture, Application and

Evaluation for Smart Grid. IEEE Transactions on

Smart Grid. pp. 847.855.

He, D., Chan, S., Zhang, Y., Guizani, M., Chen, C., Bu, J.,

2014. An enhanced public key infrastructure to secure

smart grid wireless communication networks. IEEE

Network. pp. 10-16.

Hussain, M. M., Siddique, M., Raees, A., Nouman, M.,

Javed, W., Razaq, A., 2020. Power management through

smart grids and advance metering infrastructure. 6

IEEE

International Energy Conf. pp.767-772.

Liu, J., Xiao, Y., Li, S., Liang, W., Chen, C. L. P., 2012.

Cyber Security and Privacy Issues in Smart Grids. IEEE

Communications Surveys & Tutorials. pp.981-997.

Liu, S., Liu, X. P., Saddik, A. E., 2013. Denial-of-Service

(dos) attacks on load frequency control in smart grids.

IEEE PES Innovative Smart Grid Technologies

Conference. pp. 1-6.

Liu, H., Chen, Y., Chuah, M. C., Yang, J., 2013. Towards

self-healing smart grid via intelligent local controller

switching under jamming. IEEE Conference on

Communications and Network Security. pp. 127-225.

Lonea, A. M., Popescu, D. E., Tianfield, H., 2012.

Detecting DDos attacks in cloud computing

environment. International Journal of Computers,

Communications & Control. pp. 70-78.

Li, Z., Sun, W., Wang, L., 2012. A neural network based

distributed intrusion detection system on cloud

platform. IEEE 2nd International Conference on Cloud

Computing and Intelligence Systems. pp. 75-79.

Lu, Z., Lu, X., Wang, W., Wang, C., 2010. Review and

evaluation of security threats on the communication

networks in the smart grid. Milcom Military

Communication Conference. pp. 1830-1835.

Maiti, A., Sivanesan, S., 2012. Cloud controlled intrusion

detection and burglary prevention stratagems in home

SMARTGREENS 2021 - 10th International Conference on Smart Cities and Green ICT Systems

178

automation systems. 2

Baltic Congress on Future

Internet Communications. pp. 182-186.

Manandhar, K., Cao, X., Hu, F., Liu, Y., 2014. Combating

false data injection attacks in smart grid using Kalman

filter. International Conference on Computing,

Networking and Communications. pp. 16-20.

Markovic, D .S., Zivkovic, D., Branovic, I., Popovic, R.,

Cvetkovic, D., 2013. Smart power grid and cloud

computing. Renewable and Sustainable Energy

Reviews. pp. 566-577.

Mehmood, Y., Habiba, U., Shibli, M. A., Masood, R., 2013.

Intrusion detection system in cloud computing:

challenges and opportunities. 2nd National Conference

on Information Assurance. pp. 59-66.

Mohamed, H., Adil, L., Saida, T., Hicham, M., 2013. A

collaborative intrusion detection and Prevention

System in Cloud Computing. AFRICON Conf. pp. 1-5.

Patel, A., Taghavi, M., Bakhtiyari, K., Júnior, J. C., 2013.

An intrusion detection and prevention system in cloud

computing: A systematic review. Journal of Network

and Computer Applications. pp. 25-41.

Prajapati, N. M., Mishra, A., Bhanodia, P., 2014. Literature

survey - IDS for DDoS attacks. Conference on IT in

Business, Industry and Government. pp. 1-3.

Sathya, G., and Vasanthraj, K., 2013. Network activity

classification schema in IDS and log audit for cloud

computing. International Conference on Information

Communication and Embedded Systems. pp. 502-506.

Simmhan, Y., Kumbhare, A. G., Cao, B., Prasanna, V.,

2011. An analysis of security and privacy issues in

smart grid software architectures on clouds. IEEE

International Conf. on Cloud Computing. pp.582-589.

Stouffer, K. K. K., Falco, J., 2006. Guide to Supervisory

Control and Data Acquisition (SCADA) and Other

Industrial Control System Security. NIST Guide to

Industrial Control Systems (ICS) Security.

Sgouras, K. I., Birda, A. D., Labridis, D. P., 2014. Cyber-

attack impact on critical Smart Grid infrastructures.

Innovative Smart Grid Technologies. pp. 1-5.

Tupakula, U., Varadharajan, V., Akku, N., 2011. Intrusion

detection techniques for infrastructure as a service

cloud. IEEE 9

International Conference on

Dependable, Autonomic and Secure. pp. 740-751.

Vaid, C., Verma, H. K., 2014. Anomaly-based IDS

implementation in cloud environment using BOAT

algorithm. Proceedings of 3rd International Conf. on

Reliability, Infocom Technologies and Optimization.

pp. 1-6.

Yang, Y., Littler, T., 2011. Impact of cyber-security issues

on smart grid. IEEE PES Innovative Smart Grid

Technologies Conference Europe. pp. 1-7.

Yi, P., Zhu, T., Zhang, Q., Wu, Y., Li, J., 2014. A denial-

of-service attack in advanced metering infrastructure

network. IEEE International Conference on

Communications. pp. 1029-1034.

Abdul, R., Huaglory, T., Bernardi P., Hong, Y., 2016.

Simulating smart grid cyber security. Taylor and

Francis group: Smart Grid Networking, Data

Management, and Business Models. pp. 97-116.

Detection and Prevention of Denial-of-Service in Cloud-based Smart Grid

179
