Solutions for Monitoring and Anomaly Detection in Dynamic IT

Infrastructure: Literature Review

Jānis Grabis

, Jānis Kampars

, Krišjānis Pinka

, Guntis Mosāns

, Ralfs Matisons

and Artjoms Vindbergs

Information Technology Institute, Riga Technical University, Kalku 1, Riga, Latvia

TET, Dzirnavu 105, Riga, Latvia

Keywords: Infrastructure Monitoring, Network Topology, Streaming, Graph Analytics.

Abstract: Modern information technology infrastructure is highly complex, and its monitoring requires integration of

different monitoring tools and management systems. That is especially important if monitoring data is to be

used for predictive maintenance purposes. This paper identifies methods and technologies suitable for analysis

of the information technology infrastructure. They are identified by means of literature review. The research

questions considered are: 1) What methods are applicable for analysing the virtualized IT infrastructure

related data from a technological point of view? 2) What architectural patterns and group of tools are

appropriate for infrastructure data processing and analysis? and 3) What tools according to the identified

categories in RQ3 can be used for storing and analysing topology graphs and metrics describing virtualized

infrastructure? The research finding will serve as an input for further research activities on architectural design

of the integrated monitoring solution and development of machine learning model for predictive maintenance.

1 INTRODUCTION

Modern cloud-based information technology (IT)

infrastructure provides a large variety of services and

serves many users. A typical large IT infrastructure

generates millions of events per day at rates of about

100 events per second (Harper & Tee, 2019) and

averaged sized cloud has around 1000 tenants and

100,000 users) (Majumdar et al., 2019). Security and

reliability concerns should be addressed on the

massive scale. Errors and faults occur in the complex

IT infrastructure. They result in the potential loss of

service to customers or cause extra work to maintain

the infrastructure. Monitoring tools continuously

track events in IT infrastructure and report the current

and historical situation. They cover such aspects as

performance including response time, availability,

and uptime as well as security and other operating

measures. Measures provided by component vendors

as well as sniffing, scanning and benchmarking tools

are using for monitoring purposes.

Open research issues in the monitoring of

software-defined networks are support of adaptive

measurements, real-time analytics, cyber-security

support, cloud application integration, and quality-of-

experience monitoring (Tsai et al., 2018). The

taxonomy of cloud monitoring solutions describes

various aspects of cloud computing monitoring many

of which are concerned with cloud infrastructure

management (Syed et al., 2017).

In the case of multi-functional data centres

providing a variety of services, new holistic

approaches to monitoring are needed (Natu et al.,

2016). Monitoring context and data should be

gathered from various systems and integrated to

support the analysis of processes in the data centres.

The performance monitoring and analysis system

itself should possess the same degree of flexibility

and adaptability as the virtualized and servitized

infrastructure. Predictive maintenance and machine

learning provide efficient means for managing

security and reliability concerns though they have

been rarely applied in the area of IT infrastructure (Su

& Huang, 2018). Large scale applications of machine

learning have been studied by Pacheco et al. (2019)

in the context of network traffic classification.

The objective of the paper is to review existing

methods and technologies for dynamic analysis of

evolving IT infrastructure. The review reveals the

current research gaps and suggests methods and

technologies suitable for further development. A

224

Grabis, J., Kampars, J., Pinka, K., Mos

ans, G., Matisons, R. and Vindbergs, A.

Solutions for Monitoring and Anomaly Detection in Dynamic IT Infrastructure: Literature Review.

DOI: 10.5220/0010446102240231

In Proceedings of the 11th International Conference on Cloud Computing and Services Science (CLOSER 2021), pages 224-231

ISBN: 978-989-758-510-4

systematic literature study is conducted to achieve the

objective. The research questions are motivated by

the preliminary analysis of the infrastructure

monitoring case, specifically dealing with the

management and monitoring of virtualized storage

infrastructure. This use case is investigated in

collaboration with an industry partner.

The paper has five sections. Section 2 describes

the motivational case. Section 3 establishes the

research method. The detailed literature review is in

Section 4. The findings of the literature review are

summarized in Section 5. Section 6 concludes.

2 BACKGROUND

The existing monitoring systems and diagnostic tools

target specific products and do not analyse the

infrastructure as a whole, therefore, it is difficult to

detect coherence among occurring incidents in

different data centre sub-systems. The reactive IT

infrastructure monitoring is available to limited

extent and an overall analysis of the entire IT

infrastructure with built-in predictive capabilities is

not available.

A data centre analysed in the case study is

complex and consists of physical and virtual

components at multiple levels of abstractions, each

with its own dynamically evolving topology. Physical

infrastructure components such as computing nodes,

power supply units, routers, switches, firewalls need

to be considered. The virtual environment consists of

software defined networks, software defined storage,

hypervisor, virtual machines and containers. The

topology of the data centre physical part is mostly

static and evolves slowly, but the topology of the

virtual environment changes dynamically.

An automatic and unified infrastructure

monitoring system (Figure 1) that would provide

automated incident root cause analysis and reduce the

manual work is envisioned. This system observes the

status of physical and virtual resources, records

measurements, detects topology changes, provides

incident root cause analysis and predictive

maintenance. Data from monitoring tools can be

divided into two groups – component related metrics

and topologies. Both data sets need to be ingested into

the data analysis component, which merges

topologies on different levels of abstraction with the

component related metrics. The result is a data centre

level graph containing the corresponding metrics for

each of the components and information about

relations among the components. A database is used

to store graphs, metrics and perform aggregations

over historical values. The envisioned system

provides stream processing capabilities for near-real

time incident analysis. The results from the batch and

stream processing can be observed in the monitoring

user interface by the administrators of the data centre.

Figure 1: A proposal of integrated monitoring system.

3 METHOD

In order to identify methods and tools to implement

the envisioned systems, a systematic review of the

literature is performed. The literature review was

done following the principles of a structured literature

review (Kofod-Petersen, 2014). The process includes

three stages – planning, conducting, and analysis of

the literature reviews. To identify suitable sources,

the choice of the literature used was determined by

its: 1) relevance of the article, 2) the information

contained in the citation, 3) the date of publishing.

The main goal of this review is to gather information

about the current situation in infrastructure

monitoring, which is driven by the analysis of

evolving topology infrastructure metrics. Research

questions are specified to help achieve the goal of this

research, which are shown in the Table 1.

Table 1: Overview of research questions.

RQ1

What methods are applicable for analysing the

virtualized IT infrastructure related topologies

and metrics?

RQ2

What architectural patterns are appropriate for

the design of a horizontally scalable platform

capable of analysing infrastructure topologies

and metrics?

RQ3

What types of tools are appropriate for

infrastructure data

rocessin

and anal

sis?

3.1 RQ1: Methods

Within the scope of this research two types of

infrastructure related data are considered: 1) topology

graphs – contains the topology of physical and virtual

infrastructure components (e.g., disk arrays, software

defined networks, virtual machines), and 2) numeric

metrics – contains measurable properties describing

Solutions for Monitoring and Anomaly Detection in Dynamic IT Infrastructure: Literature Review

225

the status of a certain infrastructure component.

Existing research papers mostly concentrate on one of

the aspects – either topology or numeric metrics-

based infrastructure analysis. A small group of

researchers try to address both challenges within a

single solution.

3.1.1 Topology Driven Infrastructure

Analysis

The complexity of a modern cloud infrastructure

topology is emphasized in a number of scientific

articles. An IT infrastructure graph containing four

levels of abstraction – application layer, container

layer, virtual machine layer and hardware layer is

mentioned in (Podolskiy et al., 2017). The authors

propose an architecture that is aimed at dynamically

adapting cloud application deployments on different

infrastructure levels to meet quality of service (QoS)

requirements. Dedicated tuning agents are used for

each of the abstraction layers.

Each of the mentioned layers of abstraction can

have its own graph with a significant level of

complexity. Niwa et al., 2017 present a framework

for identifying anomalies in software services of

OpenStack cloud computing platform. Graph

generator and statistics monitoring agents are

installed and executed in each server. The framework

is mostly implemented in Python, while Neo4J is used

to store the topology graph data. The anomaly

detection component uses K-means and MeanShift

clustering algorithms.

Root cause analysis of an IT infrastructure failure

is also addressed by Schoenfisch et al. (2018), who

propose a Markov Logic Networks and abductive

reasoning based solution. With the support of

background knowledge expressed as ontologies the

system enables users without any specific knowledge

of a concrete infrastructure to gain viable insights in

the case of an observed IT infrastructure incident. The

proposed approach was implemented in RoCA, a tool

providing a graphical user interface for modelling the

infrastructure and conducting the root cause analysis.

Majumdar et al. (2019) audit cloud-based IT

infrastructure for security purposes and propose a

solution that is able to identify topology

inconsistencies that might occur between multiple

control layers in the cloud. The system gathers data

from cloud management systems, cloud infrastructure

system, data centre infrastructure components. The

data collection is performed in batch mode. Authors

use a Constraint Satisfaction Problem solver, namely

Sugar (Tamura & Banbara, 2008) for validating the

compliance of the cloud infrastructure.

The security threats caused by cloud platform

misconfiguration or insider attacks are addressed by

Bleikertz et al. (2015). The authors establish a

security system, called Weatherman, which

proactively analyses the intended cloud infrastructure

configuration changes and risks associated with them

and then either approves or rejects them, thus

enforcing a variety of security and operational

policies during run-time. The graph is constantly

updated whenever changes in infrastructure

configuration occur according to the approach

presented in Bleikertz et al. (2014). The authors also

define a threat model to identify possible

misconfigurations and vulnerabilities in the graph and

identify 95 methods which modified the topology or

configuration in a way that can cause potential

security threats.

A method to construct cloud-based IT

infrastructure connectivity graph is presented by

Mensah et al. (2017). The proposed solution retrieves

the infrastructure topology and connectivity

information in real-time from Cloud Management

System and Software Defined Network controller.

Logs from both systems are scanned to detect events

that alter the infrastructure topology graph. The

proposed system is validated by using OpenStack

cloud computing platform.

3.1.2 Numeric Metrics-driven

Infrastructure Analysis

A fault localization method for detecting failures of

individual infrastructure elements can be based on the

received operational status data and alerts (Harper &

Tee, 2019). The authors state that a typical enterprise

IT infrastructure might generate around 100 events

per second. The work concentrates on the type of

alerts that cause cascading errors in related

infrastructure components. The cascading errors are

detected without any knowledge of the infrastructure

topology. In order to correlate groups of alerts and

determine the root cause of cascading errors

optimization techniques are employed for

establishing a temporal similarity graph for the alerts.

MAYOR is a solution for processing

communication system alarms (Mijumbi et al., 2019).

The proposed system contains machine learning

models for determining the persistence time of the

alert dynamically and allowed to reduce the

persistence time by 80% for 20% of all previously

statically set alarm persistence times. The system was

built using Apache Kafka, MongoDB and python data

science tools such as sklearn, pandas, numpy.

Another paper presents a mechanism for collecting

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

226

virtualized service communication metrics in a

service agnostic way, which are then usable for

detecting anomalies (Wallschläger et al., 2017). The

proposed method, namely Deep Packet Inspection,

concentrates on analysing communication protocol

metrics. Anomaly detection and root cause analysis is

also addressed by Lin et al. (2016). The paper

proposes a method for virtualized cloud data centres.

To address the scalability challenges the authors use

Apache Spark. The anomaly detection is based on K-

means clustering due to its simplicity and support for

scalability requirements. The anomaly detection and

root cause analysis functions are implemented in a

Apache Spark based system, namely MonArch (Lin

et al., 2015).

Another clustering-based anomaly detection

solution is proposed by Cucinotta et al. (2020). The

authors perform analysis of system-level metrics,

mostly related to resource consumption patterns of

virtual machines by using self-organizing maps

(SOM) based approach. Miyazawa et al. (2015) use

SOMs for supervised learning-based anomaly

detection in IT infrastructure. Analysis of

infrastructure can be used for cybersecurity threat

identification (Farooq & Otaibi, 2018). Applicable

machine learning algorithms are categorized as: data

rate analytics; anomaly detection in process

executions; and predicting user behaviour.

3.1.3 Topology and Numeric Metric-driven

Infrastructure Analysis

A modular platform is able to process numeric

metrics originating from entities such as

infrastructure components while considering the

topological relationships between the mentioned

entities (Kampars & Grabis, 2018). Authors reference

the original metrics as measurable properties and next

level aggregates as context elements. Context

elements can then be used to trigger various

infrastructure related adjustments such as scaling

virtual machines or triggering data replication. The

topology information is entered manually in a web-

based user interface as opposed to reading it from

originating systems such as hypervisors as shown in

other typology-driven infrastructure analysis

research. Only basic aggregations such as average or

max values withing a chosen time window are

supported and more advanced use cases relying on

machine learning are not reviewed as part of the

paper. The system is based on Apache Kafka, Apache

Spark and Apache Cassandra. Topology related

information is stored in Cassandra together with

numeric metrics and necessary metadata to generate

Apache Spark jobs.

3.2 RQ2: Patterns

The event-driven architecture (Richards & Ford,

2020) is based on asynchronous communication and

its main components are event processing nodes and

queues or topics in which the results of event

processing are written. Broker and mediator

topologies are used for designing systems which are

based on the event-driven architecture pattern. The

advantage of this approach is that architecture does

not have a central component for storing the business

logic. The disadvantage is that it is difficult to

implement a complex event orchestration logic, as it

is scattered across services. In the mediator topology

there is a central node ensuring implementation of

complex orchestration logic what also makes the

mediator a single point of failure and complicates

horizontal scalability of the system.

Lambda (Persico et al., 2018) is a software

architecture pattern associated with horizontally

scalable big data processing platforms. A serving

layer is responsible for indexing batch views,

allowing to query them in a low-latency ad-hoc way.

A single query can be run against results from both

batch and real-time view. Big data platforms like

Apache Spark and Apache Flink provide both batch

and real-time data processing capabilities and the

need for separate speed and batch layers was

questioned. As a result, the Kappa architecture

(Kreps, 2014) was proposed, containing only the real-

time layer and no dedicated batch-processing layer.

The architecture also employs a serving layer with

querying capabilities for the streaming layer.

An experimental review of both competing

architectural patterns was done by Sanla &

Numnonda (2019). It was concluded that due to the

dedicated batch layer Lambda contributes to higher

resource consumption and cost. The advantages of

Lambda are better resistance to data changes and

reliability.

3.3 RQ3: Tools

This section reviews the following potentially useful

tool groups and their corresponding characteristics -

general-purpose stream processing platforms,

message brokers, graph databases, graph streaming

frameworks, time-series databases.

3.3.1 Stream Processing Platforms

Stream processing platforms are systems which ope-

Solutions for Monitoring and Anomaly Detection in Dynamic IT Infrastructure: Literature Review

227

rate on continuous data (Kambatla et al., 2014). In

regard to IT infrastructure analysis examples of

continuous data are metrics gathered from IT

infrastructure components. The stream is not

persisted before executing a query or data aggregation

(Clemente & Lozano-Tello, 2018). Stream

processing platform queries are run constantly based

on a time interval or the amount of newly received

data tuples (Hesse & Lorenz, 2016). Windowing

algorithms are used to determine which data tuples

should be processed together as part of a single query

run (Lal & Suman, 2020). The stream process is made

horizontally scalable by describing it as a directed

acyclic graph, where separate processing tasks can be

delegated to worker nodes in a stream processing

cluster. An equal load distribution between worker

nodes is an open research challenge (Nasir et al.,

2015). Another issue is related to the order and time

at which the data tuples arrive at the stream

processing platform, which cannot be controlled by

the stream processing platform (Hesse & Lorenz,

2016). Stream processing platforms address this

challenge by introducing watermarks. Determining

the right watermark time is an open research

challenge (Onishi et al., 2020).

General-purpose stream processing platforms are

potentially useful for infrastructure analysis due to

their ability to process real-time metrics and late

arriving data. The platforms also have limited graph

processing capabilities.

3.3.2 Graph Databases

Graph processing is widely used in various areas of

computer science such as machine learning,

computational sciences, medical applications, social

network analysis and corresponding graphs can

contain up to several trillions of edges (Besta, Peter,

et al., 2019). Although topology data can also be

stored in regular databases this would lead to lost

query optimization potential. Graph databases are

superior since they support complex and rich graph

models like Labelled Property Graph (Angles et al.,

2017). Some of the graph databases also provide

support for ACID compliant transactions (Besta,

Peter, et al., 2019; Malewicz et al., 2010).

Unfortunately, there is no common query standard,

and a wide range of different query languages exist -

SPARQL (Pérez et al., 2006), Gremlin (Rodriguez,

2015), Cypher (Francis et al., 2018). Two types of

queries are usually supported – pattern matching

queries (Zámečníková & Kreslíková, 2016) and

business intelligence queries (Szárnyas et al., 2018).

A subset of graph databases that could be particularly

interesting for infrastructure analysis are platforms

which support temporal or time-evolving graph

analysis (Hartmann et al., 2017; Then et al., 2017;

Vora et al., 2016).

Graph databases can be used for infrastructure

topology analysis. Horizontal scalability and ability

to store time-evolving graphs should be considered

while choosing the appropriate system.

3.3.3 Graph Streaming Frameworks

The graph streaming frameworks perform processing

of temporal, time-evolving, online, and dynamic

graphs (Besta, Fischer, et al., 2019). While general-

purpose stream processing platforms are concerned

with processing continuous flow of data and have

basic graph processing capabilities, graph streaming

frameworks are tailored for near real-time analysis of

dynamically evolving graphs where changes arrive in

form of a continuous data flow. These tools differ

from traditional graph processing platforms and

databases like Pregel (Malewicz et al., 2010) and

GraphX (Xin et al., 2014) which mostly consider

static graphs. The graph streaming frameworks can be

seen as hybrids between general purpose stream

processing platforms and graph databases. Such

systems need to deal with unique challenges like

effective modelling and storage of dynamic datasets,

efficient ingestion of a stream of graph updates in

parallel with continuous graph queries (Besta,

Fischer, et al., 2019). These systems usually do not

track the historical state of the graph and concentrate

on enabling low-latency graph updates and queries.

Since IT infrastructure topology is a dynamically

evolving graph and anomalies should ideally be

detected in near-real time, graph streaming

frameworks could be beneficial for IT infrastructure

analysis scenarios.

3.3.4 Time Series Databases

Time series are a finite or unbounded sequences of

data points in increasing order by time (Jensen et al.,

2017). Although traditional relational databases can

be used to store time series data and various SQL

extensions have been proposed for this purpose, they

are not able to cope with high velocity and volume of

data originating from sensor networks or large data

centre infrastructure monitoring systems (Palpanas,

2016). NoSQL databases provide a solution which is

based on better horizontal scalability, weakened

relations and consistencies (Grolinger et al., 2013).

As a result, a new generation of NoSQL-based

databases which are particularly optimized towards

storing and analysing large amounts of temporal data

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

228

have been proposed. These systems provide improved

scalability to store large amounts of rapidly ingested

time series data together with a capability of

performing SCAN queries (Dunning & Ellen

Friedman, 2014). It is hard to establish boundaries

between NoSQL database management systems and

time-series databases since both can provide similar

functionality (Bader et al., 2017).

4 ANALYSIS

Scientific papers addressing IT infrastructure analysis

were reviewed as part of RQ1 and led to a number of

conclusions. There is almost no research done on

combining topology analysis with analysing IT

infrastructure characterizing metrics, although it is

apparent that awareness of the topology would

improve the accuracy of root cause analysis and

identifying cascading events. Virtualization has

introduced several new challenges for IT

infrastructure analysis. Multiple layers of abstraction

have greatly increased the number of entities that

need to be monitored. The IT infrastructure

components on different levels of abstraction might

also have different ownership, which complicates the

monitoring. Due to the large number of components

and differential ownership, monitoring agents should

be installed in a non-intrusive way and with little

computing overhead. The monitoring data analysis

platform needs to be highly scalable. The subject of

IT infrastructure analysis for large cloud-based

environments is not studied enough, since a

significant amount of the existing researches propose

solutions which are not appropriate due to scalability.

Unsupervised and semi-supervised machine learning

algorithms are more appropriate for cloud-based IT

infrastructure analysis scenarios.

It was concluded that event-driven architecture

patterns can be used in both Kappa and Lambda

architecture. Kappa architecture is more lightweight

and could provide lower latency and resource

consumption. Lambda is more appropriate for use

cases where complex machine learning algorithms

and data pre-processing need to be used – such as in

IT infrastructure analysis.

The review of the appropriate tool groups has led

to the following conclusions: 1) to select a message

broker, the priorities for latency, throughput,

reliability and horizontal scalability as well as the

supported messaging models need to be defined; 2)

Watermarks are used to address the issue of late-

arriving data tuples in stream processing platforms,

however determining the right watermark size is

challenging; 3) Although stream processing

platforms have some graph processing capabilities,

more specialized graph streaming frameworks can be

used to analyse dynamically evolving graphs; 4)

Traditional graph databases provide advanced means

for graph-based analytics; however, they fail to

support low latency queries for dynamically evolving

graphs; and 5) time series querying functionality

varies greatly among the tools, therefore, the set of

required type of queries for analytic purposes needs

to be identified prior to choosing the most appropriate

database management system.

5 CONCLUSION

This literature review has identified the current

research gaps and state-of-the-art in IT infrastructure

analysis. The findings of the review will be used to

design an integrated platform for IT infrastructure

monitoring and predictive maintenance. Concrete

tools belonging to the identified groups of tools are to

be tested and selected for their inclusion in the

solution. That will serve as an input for architecture

development and implementation of the monitoring

and prediction platform.

ACKNOWLEDGEMENT

This research is funded by European Regional

Development Fund Project Nr. 1.1.1.1/19/A/003

“Development of integrated monitoring and

predictive maintenance solution for dynamically

evolving IT infrastructure” Specific Objective 1.1.1

“Improve research and innovation capacity and the

ability of Latvian research institutions to attract

external funding, by investing in human capital and

infrastructure” 1.1.1.1. measure “Support for applied

research” (round No.3).

REFERENCES

Angles, R., Arenas, M., Hogan, A., & Reutter, J. (2017).

Foundations of Modern Query Languages for Graph.

50(5).

Bader, A., Kopp, O., & Falkenthal, M. (2017). Survey and

comparison of open source time series databases.

Lecture Notes in Informatics (LNI), Proceedings -

Series of the Gesellschaft Fur Informatik (GI).

Besta, M., Fischer, M., Kalavri, V., Kapralov, M., &

Hoefler, T. (2019). Practice of streaming and dynamic

graphs: Concepts, models, systems, and parallelism.

Solutions for Monitoring and Anomaly Detection in Dynamic IT Infrastructure: Literature Review

229

ArXiv, 1–16.

Besta, M., Peter, E., Gerstenberger, R., Fischer, M.,

Podstawski, M., Barthels, C., Alonso, G., & Hoefler, T.

(2019). Demystifying Graph Databases: Analysis and

Taxonomy of Data Organization, System Designs, and

Graph Queries. CoRR, abs/1910.0.

Bleikertz, S., Vogel, C., & Groß, T. (2014). Cloud radar:

Near real-time detection of security failures in dynamic

virtualized infrastructures. ACM International

Conference Proceeding Series, 2014, 26–35.

Bleikertz, S., Vogel, C., Gross, T., & Mödersheim, S.

(2015). Proactive security analysis of changes in

virtualized infrastructures. ACM International

Conference Proceeding Series, 7-11 Dec, 51–60.

Clemente, P. J., & Lozano-Tello, A. (2018). Model Driven

Development Applied to Complex Event Processing for

Near Real-Time Open Data. Sensors, 18(12).

Cucinotta, T., Lanciano, G., Ritacco, A., Vannucci, M.,

Artale, A., Barata, J., Sposato, E., & Basili, L. (2020).

Behavioral analysis for virtualized network functions:

A som-based approach. CLOSER 2020 - Proceedings

of the 10th International Conference on Cloud

Computing and Services Science, Closer, 150–160.

Dunning, T., & Ellen Friedman. (2014). Time Series

Databases: New Ways to Store and Access Data.

O’Reilly Media, Inc.

Farooq, H. M., & Otaibi, N. M. (2018). Optimal machine

learning algorithms for cyber threat detection.

Proceedings - 2018 UKSim-AMSS 20th International

Conference on Modelling and Simulation, UKSim

2018, 32–37.

Francis, N., Green, A., Guagliardo, P., Libkin, L.,

Lindaaker, T., Marsault, V., Plantikow, S., Selmer, P.,

& Taylor, A. (2018.). Cypher : An Evolving Query

Language for Property Graphs. SIGMOD '18:

Proceedings of the 2018 International Conference on

Management of Data, 1433–1445.

Grolinger, K., Higashino, W. A., Tiwari, A., & Capretz, M.

A. M. (2013). Data management in cloud

environments: NoSQL and NewSQL data stores.

Journal of Cloud Computing, 2(1).

Harper, R., & Tee, P. (2019). A method for temporal event

correlation. 2019 IFIP/IEEE Symposium on Integrated

Network and Service Management, IM 2019, 13–18.

Hartmann, T., Fouquet, F., Jimenez, M., Rouvoy, R., & Le

Traon, Y. (2017). Analyzing Complex Data in Motion

at Scale with Temporal Graphs. The 29th International

Conference on Software Engineering & Knowledge

Engineering (SEKE’17), Jul 2017, Pittsburgh, US, pp.

Hesse, G., & Lorenz, M. (2016). Conceptual survey on data

stream processing systems. Proceedings of the

International Conference on Parallel and Distributed

Systems - ICPADS, 2016, 797–802.

Jensen, S. K., Pedersen, T. B., & Thomsen, C. (2017). Time

Series Management Systems: A Survey. IEEE

Transactions on Knowledge and Data Engineering,

29(11), 2581–2600. 2.

Kambatla, K., Kollias, G., Kumar, V., & Grama, A. (2014).

Trends in big data analytics . Journal of Parallel and

Distributed Computing, 74(7), 2561–2573

Kampars, J., & Grabis, J. (2018). Near Real-time Big-data

Processing for Data Driven Applications. Proceedings

- 2017 International Conference on Big Data

Innovations and Applications, Innovate-Data 2017, 35–

42.

Kofod-petersen, A. (2014). How to do a structured

literature review in computer science. Researchgate,

May 2015, 1–7.

Kreps, J. (2014). Questioning the Lambda Architecture.

The Lambda Architecture has its merits, but

alternatives are worth exploring. O’Reilly Media on

line, July.

Lal, D. K., & Suman, U. (2020). A Survey of Real-Time

Big Data Processing Algorithms. Lecture Notes in

Mechanical Engineering, 3–10.

Lin, J., Ravichandiran, R., Bannazadeh, H., & Leon-Garcia,

A. (2015). Monitoring and measurement in software-

defined infrastructure. Proceedings of the 2015

IFIP/IEEE International Symposium on Integrated

Network Management, IM 2015, 742–745.

Lin, J., Zhang, Q., Bannazadeh, H., & Leon-Garcia, A.

(2016). Automated anomaly detection and root cause

analysis in virtualized cloud infrastructures.

Proceedings of the NOMS 2016 - 2016 IEEE/IFIP

Network Operations and Management Symposium,

Noms, 550–556.

Majumdar, S., Madi, T., Wang, Y., Tabiban, A., Oqaily, M.,

Alimohammadifar, A., Jarraya, Y., Pourzandi, M.,

Wang, L., & Debbabi, M. (2019). Cloud security

auditing. In Advances in Information Security (Vol. 76).

Malewicz, G., Austern, M. H., Bik, A. J. C., Dehnert, J. C.,

Horn, I., Leiser, N., & Czajkowski, G. (2010). Pregel :

A System for Large-Scale Graph Processing. 135–145.

Mensah, P., Dubus, S., Kanoun, W., Morin, C., Piolle, G.,

& Totel, E. (2017). Connectivity graph reconstruction

for networking cloud infrastructures. 2017 IEEE 16th

International Symposium on Network Computing and

Applications, 1–9.

Mijumbi, R., Asthana, A., Bernal, C., & Castejon, M.

(2019). MAYOR: machine learning and analytics for

automated operations and recovery. Proceedings -

International Conference on Computer

Communications and Networks, ICCCN, 2019-July.

Miyazawa, M., Hayashi, M., & Stadler, R. (2015). VNMF:

Distributed fault detection using clustering approach

for network function virtualization. Proceedings of the

2015 IFIP/IEEE International Symposium on

Integrated Network Management, IM 2015, 640–645.

Nasir, M. A. U., De Francisci Morales, G., García-Soriano,

D., Kourtellis, N., & Serafini, M. (2015). The power of

both choices: Practical load balancing for distributed

stream processing engines. Proceedings - International

Conference on Data Engineering, 2015-May, 137–148.

Natu, M., Ghosh, R. K., Shyamsundar, R. K., & Ranjan, R.

(2016). Holistic Performance Monitoring of Hybrid

Clouds: Complexities and Future Directions. IEEE

Cloud Computing, 3(1), 72–81.

Niwa, T., Kasuya, Y., & Kitahara, T. (2017). Anomaly

detection for openstack services with process-related

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

230

topological analysis. 2017 13th International

Conference on Network and Service Management,

CNSM 2017, 1–5.

Onishi, T., Michaelis, J., & Kanemasa, Y. (2020).

Recovery-conscious adaptive watermark generation for

time-order event stream processing. Proceedings - 5th

ACM/IEEE Conference on Internet of Things Design

and Implementation, IoTDI 2020, 66–78.

Pacheco, F., Exposito, E., Gineste, M., Baudoin, C., &

Aguilar, J. (2019). Towards the Deployment of

Machine Learning Solutions in Network Traffic

Classification: A Systematic Survey. IEEE

Communications Surveys and Tutorials, 21(2), 1988–

2014. 7

Palpanas, T. (2016). Big Sequence Management: A glimpse

of the Past, the Present, and the Future. In R. M.

Freivalds, G. Engels, & B. Catania (Eds.), SOFSEM

2016: Theory and Practice of Computer Science (pp.

63–80). Springer, Berlin.

Pérez, J., Arenas, M., & Gutierrez, C. (2006). Semantics

and Complexity of SPARQL. In I. Cruz, S. Decker, D.

Allemang, C. Preist, D. Schwabe, P. Mika, M. Uschold,

& L. M. Aroyo (Eds.), The Semantic Web - ISWC 2006

(pp. 30–43). Springer, Berlin.

Persico, V., Pescapé, A., Picariello, A., & Sperlí, G. (2018).

Benchmarking big data architectures for social

networks data processing using public cloud platforms.

Future Generation Computer Systems, 89, 98–109.

Podolskiy, V., Gerndt, H. M., & Benedict, S. (2017). QoS-

based cloud application management: Approach and

architecture. CrossCloud 2017 - 4th Workshop on

CrossCloud Infrastructures and Platforms, Colocated

with EuroSys 2017.

Richards, M., & Ford, N. (2020). Fundamentals of Software

Architecture. O’Reilly Media, Inc.

Rodriguez, M. A. (2015). The Gremlin Graph Traversal

Machine and Language.

Sanla, A., & Numnonda, T. (2019). A comparative

performance of real-time big data analytic

architectures. ICEIEC 2019 - Proceedings of 2019

IEEE 9th International Conference on Electronics

Information and Emergency Communication, 674–678.

Schoenfisch, J., Meilicke, C., Stülpnagel, J. von, Ortmann,

J., & Stuckenschmidt, H. (2018). Root cause analysis in

IT infrastructures using ontologies and abduction in

Markov Logic Networks. Information Systems, 74,

103–116.

Su, C. J., & Huang, S. F. (2018). Real-time big data

analytics for hard disk drive predictive maintenance.

Computers and Electrical Engineering, 71, 93–101.

Syed, H. J., Gani, A., Ahmad, R. W., Khan, M. K., &

Ahmed, A. I. A. (2017). Cloud monitoring: A review,

taxonomy, and open research issues. In Journal of

Network and Computer Applications (Vol. 98, pp. 11–

26). Academic Press.

Szárnyas, G., Prat-pérez, A., Averbuch, A., Marton, J.,

Paradies, M., Kaufmann, M., et al. (2018). An early

look at the LDBC Social Network Benchmark’ s

Business Intelligence workload. Proceedings of the 1st

ACM SIGMOD Joint International Workshop on Graph

Data Management Experiences & Systems and

Network Data Analytics, No. 9, 1–11

Tamura, N., & Banbara, M. (2008). {Sugar}: A {CSP} to

{SAT} Translator Based on Order Encoding, 65–69.

Then, M., Stephan, G., Neumann, T., & Kemper, A. (2017).

Automatic Algorithm Transformation for Efficient

Multi-Snapshot Analytics on Temporal Graphs. 10(8),

877–888.

Tsai, P. W., Tsai, C. W., Hsu, C. W., & Yang, C. S. (2018).

Network Monitoring in Software-Defined Networking:

A Review. IEEE Systems Journal, 12(4), 3958–3969.

Vora, K., Gupta, R., & Xu, G. (2016). Synergistic Analysis

of Evolving Graphs. ACM Trans. Archit. Code Optim.,

13(4).

Wallschläger, M., Gulenko, A., Schmidt, F., Kao, O., &

Liu, F. (2017). Automated Anomaly Detection in

Virtualized Services Using Deep Packet Inspection.

Procedia Computer Science, 110, 510–515.

Xin, R. S., Crankshaw, D., Dave, A., Gonzalez, J. E.,

Franklin, M. J., & Stoica, I. (2014). GraphX: Unifying

Data-Parallel and Graph-Parallel Analytics.

http://arxiv.org/abs/1402.2394

Zámečníková, E., & Kreslíková, J. (2016). Comparison of

platforms for high frequency data processing. 2015

IEEE 13th International Scientific Conference on

Informatics, INFORMATICS 2015 - Proceedings, 296–

301.

Solutions for Monitoring and Anomaly Detection in Dynamic IT Infrastructure: Literature Review

231
