An Empirical Study on the Impact of Aspect-oriented Model-driven

Code Generation

Andr

e Menolli

1,2 a

, Luan de Souza Melo

3 b

, Maur

ıcio Massaru Arimoto

1 c

and Andreia Malucelli

3 d

University of Northen Paran

a (UENP), Brazil

Postgraduate Program in Computer Science, State University of Londrina (UEL), Brazil

Postgraduate Program in Computer Science, Pontiﬁcia Universidade Cat

olica do Paran

a (PUCPR) , Brazil

Keywords:

Model-driven Development, Aspect-oriented Software Development, Software Quality, Experimentation.

Abstract:

Over the years innovative approaches in software development have been proposed. Among the main ap-

proaches, we can highlight aspect-oriented software development. However, applying aspect-oriented soft-

ware development is not simple, but may be facilitated by the model-driven development, mainly because it

is possible to build models to drive consolidated aspect solutions. In this context, we analyzed the impact

of aspect-oriented solutions created from a model-driven approach. To this end, a model-driven approach

to create aspect-oriented code was proposed and an experiment focusing on data persistence was conducted.

From data gathering, we empirically discuss the impact of the generated solutions compared to oriented-object

solutions. Some code metrics were analyzed using quantitative analysis and the results show that the approach

may help to reuse aspect-oriented solutions and improve the code quality and productivity.

1 INTRODUCTION

The aspect-oriented software development (AOSD) is

a software development paradigm designed to reduce

the effort required to maintain software systems by re-

placing cross-cutting code with aspects. Many stud-

ies (Hoffman and Eugster, 2009; Katic et al., 2013;

Kulesza et al., 2006) have been conducted showing

that AOSD may be effective to improve the sepa-

ration of concerns, and, consequently, improve the

reusability and maintainability. However, recently,

the study of (Przybyłek, 2018) indicates that AOSD

decreases the code understandability while improv-

ing changeability. This explains why previous experi-

ments measuring completion time generally showed

the advantage of object-oriented development over

AOSD (Mehmood, 2013).

Considering this, we believe it is possible to use

model-driven development (MDD) to create aspect

code to have less impact on understandability and,

at the same time, have the advantages that the use

https://orcid.org/0000-0002-4755-8031

https://orcid.org/0000-0002-3085-3819

https://orcid.org/0000-0002-3972-0764

https://orcid.org/0000-0002-0929-1874

of AOSD provides. MDD allows code development

from high-level models and its function is essentially

to transform a software model into executable code

and to vary totally or partially according to needs

(France and Rumpe, 2007).

While MDD allows domain speciﬁc abstraction,

AOSD provides greater support for modularization

concerns throughout the software development life-

cycle (Groher and Voelter, 2009; Pinto et al., 2007).

Thereby, we proposed an MDD-based approach to

assist in semi-automatic coding of aspect-oriented ap-

plications, and through a controlled experiment with

20 students, we evaluated our approach and compared

it with OO development. The experiment was car-

ried out in the context of data persistence. This do-

main was chosen because there are many methods

and tools to implement data access in separate ways.

Our approach aims to allow AOSD to be applied al-

most transparently for the end user. We followed the

Goal-Question-Metric (GQM) approach (Basili et al.,

1994) to deﬁne a measurement system for our re-

search. Figure 1 presents an overview of the goal,

questions, metrics, as well as their interrelations.

Menolli, A., Melo, L., Arimoto, M. and Malucelli, A.

An Empirical Study on the Impact of Aspect-oriented Model-driven Code Generation.

DOI: 10.5220/0010442802750282

In Proceedings of the 23rd International Conference on Enterprise Information Systems (ICEIS 2021) - Volume 2, pages 275-282

ISBN: 978-989-758-509-8

275

Figure 1: GQM Measurement plan.

2 RELATED WORKS

The idea of combining model-driven techniques and

aspect-oriented development is not new. Over the

years, approaches have been proposed to solve dif-

ferent problems in the research. For example, a long-

standing initiative in this direction is the paper (Sim-

monds et al., 2005) that presents an Aspect Oriented

Model Driven Framework (AOMDF) that facilitates

separation of pervasive features and supports their

transformation through different levels of abstraction.

Another work (Singh and Sood, 2009) proposes to in-

corporate the merits of AOSD such as modularization,

reuse and complexity in the Model Driven Architec-

ture (MDA) software development strategy.

Many papers focus on the integration of these

two technologies, proposing high-level solutions us-

ing model-driven engineering (MDE) or MDA. For

example, (Tekinerdogan et al., 2007) considers MDA

and the aspect-oriented approach as complementary

techniques for the separation of concerns and devel-

ops a systematic analysis of cross-cutting concerns in

the MDA context. Another study on the same line of

work (Groher and Voelter, 2009) presents an approach

that facilitates variability implementation, manage-

ment, and tracing by integrating model-driven and

aspect-oriented software development, where features

are separated into models and composed of aspect-

oriented composition techniques at model level.

However, the combination of these technologies

is not limited for the aforementioned areas. Differ-

ent approaches may be proposed for several areas

to address speciﬁc problems. For example, (P

erez

et al., 2013) propose a methodology that should al-

low code generation from models that specify func-

tional and non-functional requirements. In addition,

the work of (Mehmood, 2013) presents a system-

atic mapping study of aspect-oriented model-driven

code generation. They conclude that aspect-oriented

model-driven code generation is indicated as a rela-

tively immature area.

The papers presented works focus on generating

the ﬁnal AO code, and unlike the other presented, this

work focus on generating the ﬁnal aspect code in a

transparent way for developers, for very speciﬁc con-

solidated solutions, such as patterns and to empiri-

cally compare the generated code with the OO code

produced for the same solution.

3 PROPOSAL APPROACH

The proposed approach tries to help developers to

apply the AOSD paradigm, helping them to deﬁne

where and how to use the AOSD, using a model-

driven approach. Figure 2 shows how our approach

works. The proposed approach presents two roles: (a)

the Framework Developer - responsible for creating

PIM and Model Transformations (Class and Aspect

Transformations); and (b) the Application Developer

- responsible for creating a PSM based on PIM.

Figure 2: The proposed approach.

The ﬁrst step (1) is the creation of the PIM. In our ap-

proach, PIM is a metamodel, that is, a generic model

that describes a reusable solution to a problem that

usually occurs within a given context and can be used

in different situations. Thus, the PIM is a generic

model that describes a domain solution to guide the

creation of applications and is created by the Frame-

work Developer.

Therefore, any application developed by the Ap-

plication Developer must be created from a PIM.

Specifying the aspect and where (which classes) it

may act on the PIM is the critical point of the ap-

proach. The Framework Developer is responsible for

deﬁning the aspects that a model should contain, help-

ing to create an organizational standard, since any ap-

plication in a given domain will share the same as-

pects and implementation.

The second step (2) is to create the transforma-

tions, which is also the responsibility of the Frame-

work Developer, and will be used to generate low-

level source code. We have chosen to use Ac-

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

276

celeo to deﬁne the Model Transformations (Koch,

2007). Acceleo (https://www.eclipse.org/acceleo/) is

an implementation of the Object Management Group

(OMG) Model to Text Language (MTL). This choice

is due to the possibility of automatically transform-

ing platform-independent models (PIMs) to low-level

source code (Mtsweni, 2012).

In the third step (3), the Application Developer

chooses a PIM to start developing an application, and

in the fourth step (4) he/she creates the PSM. In this

step, the Application Developer must create a model

based on the PIM deﬁned by the Framework Devel-

oper. In addition, Application Developer must de-

ﬁne all parameters to conﬁgure the classes and as-

pects being generated. PSM, along with the transfor-

mations, comprises the Application Core, from which

the source code may be generated (5).

4 RESEARCH STRUCTURE

To evaluate our approach, we deﬁned the research

structure following the research decision-making

structure presented by (Wohlin and Aurum, 2015),

which shows decision points that are grouped into

three phases: strategic, tactical and operational. Once

the research questions issues had been deﬁned, the de-

cision points were selected.

4.1 Deﬁnition of Hypotheses

To guide our experiment, two hypotheses were for-

mally stated:

• Ha µT < µA: where, the approach based on MDD

and AOSD is superior in productivity compared

to an OO implementation produced manually by

programmers.

• Hb µT < µA: where, the approach based on

MDD and AOSD generates a higher code qual-

ity than an OO implementation produced manu-

ally by programmers.

The next step in the planning activity was to de-

termine variables (independent variables (persistence

technology, the approach used) and the dependent

variables (development time and code quality)).

4.2 Participants

The participants who collaborated in this experi-

ment were undergraduate and graduate students of the

Computer Science course. The participants were spe-

cially selected individuals from the population of in-

terest for the experiment, since the experiment wants

to simulate the behavior of individuals within a soft-

ware development company. We applied a placement

test to select participants who had the same level of

coding skills and knowledge about all the technolo-

gies involved in the experiment (in general partic-

ipants have little knowledge about AOSD), so that

they can perform the proposed functions at a simi-

lar time. Therefore, a non-probabilistic sampling was

used in the selection of participants, considering a

convenience sample, which the closest and most con-

venient people are selected. Furthermore, the exper-

iment was complex, requiring knowledge of design

patterns, and distinct technologies (such as Hibernate,

JDBC and JPA), in addition to AOSD. Thus, the pop-

ulation had been limited by these restrictions.

4.3 Description of the Experiment and

Procedure

In this experiment, the participants were invited to

perform a software implementation in library loan

management software, developed in the Java plat-

form. The proposed implementation was based on

the Data Access Object (DAO) pattern using Generic-

DAO. Each participant implemented the data persis-

tence code for a given functionality (borrow book),

using one of the technologies: JPA, Hibernate or

JDBC.

The experiment was divided into two parts: A –

using the approach and B – not using the approach.

The tasks requested to be implemented in the experi-

ment were: 1A – JPA using the approach; 1B – JPA

not using the approach (OO implementation); 2A –

Hibernate using the approach; 2B – Hibernate not us-

ing the approach (OO implementation); 3A – JDBC

using the approach; 3B – JDBC not using the ap-

proach (OO implementation).

For A implementations, the participants followed

the ﬂow presented in Figure 3, which includes four

steps: (1) Access the documentation and source code

of the lending functionality (domain layer). The par-

ticipants, in this step, had access to the requirement

and project artifacts (Book Borrow Requirements -

Use Case; Class Diagram; Sequence Diagram; Code

of domain layer (.java ﬁles) and Script to generate the

database). (2) Create the PSM (based on the PIM)

for the requested technology. (3) Generate the initial

source code, according to the PSM created and (4) Fi-

nalize and test the source code.

On the other hand, for B implementations, partic-

ipants followed two steps: (1) Access the documenta-

tion and source code of the borrow functionality (do-

main layer) and (2) Create OO source code using the

requested technology.

An Empirical Study on the Impact of Aspect-oriented Model-driven Code Generation

277

Figure 3: Flow of experiment to implement solution using

the proposed approach.

In this experiment, a quantitative analysis was used.

The analysis was performed using productivity met-

rics and a set of separation, coupling, cohesion, and

size metrics (Sant’Anna et al., 2003). Moreover, an

expert analysed the solutions created by participants

in order to understand whether the solutions corre-

sponded to what was required, and whether the so-

lutions were acceptable for the proposed problem.

5 THE FRAMEWORK

To implement a framework using the proposed ap-

proach, we chose the data persistence domain for

two main reasons: previous studies, such as (Oliveira

et al., 2008), conﬁrm that the use of AOSP in this type

of problem could be a good strategy and data persis-

tence is common to several types of applications, thus

facilitating data reuse.

The framework was built to help create data per-

sistence applications using DAO and AOSD. More-

over, it supports the following technologies: Java

Database Connectivity (JDBC), Java Persistence API

(JPA) or Hibernate. The following subsections de-

scribe how each step of the proposed approach was

implemented.

5.1 The PIM

In order to support the creation of data persistence

applications using three different technologies, the

Framework Developer deﬁned two PIMs (Hibernate

and JPA use the same PIM). They were created

through the Eclipse Modeling Framework (EMF), and

deﬁne the essential elements of the submitted domain.

The EMF is a modeling framework and code genera-

tion facility for the development of applications based

on a structured data model. We used the EMF, since it

has become undoubtedly has become standard in the

MDE community, as well as in the most MDE tools.

As an example of PIM, Figure 4 presents a dia-

gram containing the entities of the Hibernate and JPA

PIM as well as their relationships. The PIM is com-

posed of the following entities:

Init: has the role of starting point when building

the PSM. Therefore, it is possible to create Aspect-

DAO, Control and Persistence entities. Control: as-

sociates the Object to DaoClass. In addition, Con-

trol contains a set of interfaces equivalent to the set

of interfaces brought by DaoClass, which may be

used by Init to trigger the data persistence function-

ality. GenericDAO: A skeleton of DaoClass. Gener-

icDAO is an abstract entity that contains declarations

of the required interfaces of a DaoClass. Further-

more, it contains the functionality that the Aspect-

DAO will use as a pointcut. DaoClass: an exten-

sion of the GenericDao class. As DaoClass is as-

sociated with Object, it may contain speciﬁc queries

performed on it. Object: a POJO which determines

an entity of the domain as to its attributes and behav-

iors. In other words, in the data persistence domain,

the Object could also be described as an element of

the model layer. Attribute: responsible for deﬁning

the Object class attributes. Persistence: responsible

for the information needed to connect to the database.

textbfAspectDAO: deﬁnes a pointcut and an advice

that is triggered when data persistence functions from

GenericDAO are executed or called.

Figure 4: JPA and Hibernate PIM.

5.2 The Model Transformation

As previously described, the model transformations

performed on our framework run on Acceleo. In Ac-

celeo, the model transformation is designed through

standard templates, which are able to load model data

and manipulate it in order to build the resulting arti-

facts, namely, low-level source code.

The transformations were built upon the entities

present in the PIMs. Therefore, every entity will

present a distinct data treatment and all of them will

be supported in the model transformation process.

The creation of model transformation is responsi-

bility of the Framework Developer (the Framework

Developer has created seven transformation classes

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

278

and one aspect transformation for each technology

JPA, Hibernate and JDBC). These transformations

are templates, which will be used to generate low-

level source code. The approach supports two types

of transformations: class and aspect transformations.

Class transformations contain the Acceleo content to

create the class structure and the main constraints.

Aspect transformations contain the Acceleo content

to deﬁne the whole aspect.

5.3 The PSM

Once the PIMs and Transformation are created, the

Framework Developer is able to generate a plugin

containing all metadata of the PIMs, namely, an

Eclipse build that supports the creation of the PSM

based on the entities of a PIM. To create the PSM,

the Application Developer creates a model based on

a PIM, using a tree-view feature to build the hierar-

chy and attribute entities’ values. Then, the Applica-

tion Developer must deﬁne the attributes of the enti-

ties. Once the PSM is built, the Application Devel-

oper must run the Acceleo, so the low-level source

code is generated from the PSM and Transformations

(which act on the PSM).

6 DATA ANALYSIS

To evaluate our approach and compare it with the OO

implementation produced manually by the program-

mers, we used the Framework presented. The exper-

iment was conducted as described in Section 4, and

once all participants had executed the requested tasks,

the data were collected and analyzed. To analyze the

code metrics we used 10 software metrics frequently

used in software projects presentd in (Varela et al.,

2017) .

6.1 Productivity

To deﬁne whether the productivity to generate code is

higher using our approach than manually by program-

mers, we used two types of statistical analysis. The

ﬁrst analysis sought to understand: given an imple-

mentation using the approach, what is the probability

that the time to complete this implementation will be

less than an OO implementation produced manually

by programmers?

In our experiment, we believe that the time to de-

velop a solution using the proposed approach is lesser

than to develop manually the solution OO. Thus, from

the hypothesis Ha, we proposed a null Ha

hypoth-

esis, which states that there is no difference in the

time of development using the approach or not using

it. That is, the null hypothesis can be formulated as:

: µT = µA; where, there is no productivity dif-

ference in relation to the use of the approach based on

MDD and AOSD with respect to the OO implementa-

tion produced manually by programmers.

In order to reject the null hypothesis, we used a

non-parametric test (binomial test). In the experi-

ment, twelve solutions were produced to compare the

two types of development. In 11 times, the time to de-

velop was shorter using the proposed approach. Only

once was the time the same or shorter not using the

approach. To calculate the binomial test, we deﬁned

that α should be less than 0.05 (the critical area, C

is α ≥ 0.05). To verify the hypothesis we used the

binomial formula:

(1)

In this case, we rejected Ha

because 0.003 < 0.05.

As a result, the Ha hypothesis is discussed. We al-

ready knew that this is the probability of developing

a solution using the proposed approach in a shorter

time. However, we want to analyze this difference.

We compared if there is a statistically signiﬁcant

difference in the development time between the two

categories (using the approach and developing manu-

ally using OOP). First, we checked whether the sam-

ple is normally distributed using Shapiro–Wilk test,

which presents a null hypothesis that a sample comes

from a normally distributed population if p-value ≥

x (for all tests we considered p-value as 0.05). The

result showed that the sample is normally distributed.

So, as the samples are independent, we use t-test to

compare them. The t-test null hypothesis is that the

two samples are equivalent. The results of these tests

are presented in Table 1. Comparing all solutions

(ﬁrst line) there is a difference. However, looking for

each solution, there is a difference in time only for

the ﬁrst solution (JPA implementation). So, we ap-

plied the t-test (greater) to identify if the side A is

greater than B, in cases where there was a difference.

In both cases, the implementation time when the ap-

proach was used was statistically better.

6.2 Code Quality

To evaluate the code quality, we used the metrics sum-

marized in Table 2. First, we used the binomial test to

see if there is a higher probability of having a better-

quality code if the proposed approach is used instead

of implementing it manually using OOP. From the Hb

hypothesis, we proposed a null H

hypothesis, which

states that there is no difference in the code quality

An Empirical Study on the Impact of Aspect-oriented Model-driven Code Generation

279

Table 1: Statistical difference between development time.

Comparison

(tasks)

t-test

(p-value)

t-test (greater)

(p-value)

A-B (total) 0.0206 0.989

1A-1B 0.0237 0.988

2A-2B 0.1338 –

3A-3B 0.4024 –

A - Task executed using the approach

B - Task executed manually by programmers

using the approach or not using it. That is, the null hy-

pothesis can be formulated as: Hb

µTl = µA; where,

there is no quality difference in relation to the use of

the approach based on MDD and AOSD with respect

to the OO implementation produced manually by pro-

grammers.

We compared ten metrics, considering the twelve

solutions of two kinds of development. Thus, there

are 120 metrics to compare. At 70 times the metric

was higher using the approach. At 50 times the metric

was the same or higher not using the approach.

We deﬁned that α should be below 0.05 (the criti-

cal area, C is α ≥ 0.05). Hence, to verify the hypoth-

esis, we used the formula (2):

(2)

In this case, we rejected Hb

because 0.041 < 0.05.

As a result, the Hb hypothesis is discussed. We al-

ready know that there is a higher probability of hav-

ing a better-quality code using the proposed approach

if compared to not using the approach. However, we

want to analyze each metric and apply statistical tech-

niques. Table 2 presents the median and standard de-

viation for each technology used. Moreover, we com-

pare with which metrics there are statistically signiﬁ-

cant differences between the two categories of imple-

mentation.

The results are presented in Table 3 that presents

the general evaluation (comparing all implementa-

tions using the approach with the implementations

that do not use it) and in Table 4 that compares each

task.

The results based on metrics was superior when

using the proposed approach. Other studies have al-

ready shown that aspects support the improvement

of the separation of concern, such as (Garcia et al.,

2005), and (Oliveira et al., 2008), which explores

the separation of concerns speciﬁcally for data per-

sistence applications. Therefore, as shown in Table 2,

the Concern Diffusion over Components (CDC) was

improved by 83%. The Concern Diffusion over Op-

Table 2: Metrics and their statics.

Table 3: Statistical difference between Metrics in general.

Table 4: Statistical difference between Metrics in each task.

erations (CDO) was improved by 86%. The last met-

ric, Concern Diffusions over LOC (CDLOC), was im-

proved by 92%. Besides the superior results when the

approach was used, it is important to realize that none

of the metrics presented a difference in the standard

deviation when the approach was used.

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

280

Considering coupling metrics,the metric epth In-

heritance Tree (DIT) showed no difference from the

two approaches. However, the results obtained in the

Coupling Efferent (CE) and Coupling Afferent (CA)

metrics show that the implementations using the pro-

posed approach had a reduction in coupling of 9% and

3% respectively. Regarding Lack of Cohesion in Op-

erations (LCOO), it was the only metric that in gen-

eral presented a worse result using the proposed ap-

proach, although the difference was small, only 4%.

In the last metrics, regarding code size, the follow-

ing data are analyzed: Lines of Code (LOC), Num-

ber of Attributes (NOA) and Weighted Operations per

Component (WOC). Regarding LOC metric, the pro-

posed approach was 4% more efﬁcient, while in the

NOA metric it was 2% better. In the last WOC metric

the proposed approach was 3% more efﬁcient. More-

over, observing Table 2, it is possible to see that in

general the size metrics presented a lower standard

deviation when the approach was used.

7 DISCUSSIONS

To answer the question a “Is it possible to pro-

ductively generate semi-automatically quality AOSD

code based on MDD?”, we analyzed the experiment

and its results. Based on the experiment, we conclude

that our approach generates semi-automatic quality

AOSD productivity. In the experiment, all partici-

pants were able to develop three different persistence

AOSD codes. Thus, based on experiment, the ap-

proach helps to create different solutions for a generic

domain semi-automatically. Yet considering the ex-

periments, analyzing the development time, and the

code quality metrics that are considered to generate

quality code productivity. Thus, we consider that the

ﬁrst main question is true, and that it is possible an ap-

proach, based on MDD, productively generates semi-

automatically quality AOSD code.

However, to analyze productivity and quality

compared to a OO code developed manually, it is

necessary to analyze question b: “Can the quality

of the code and productivity be as good, or better

than the OO code produced manually by the program-

mers?”. Based on the results of the experiment, we

may state that, using the proposed approach, there is

a greater probability of having a shorter development

time compared to OO manual development. Further-

more, the development time was statistically signiﬁ-

cantly shorter compared to manual OO development.

Regarding code quality, using the proposed ap-

proach there is a greater probability of having higher

quality code compared to the manual OO develop-

ment. Statistically, we may state that development

using the approach helps to improve the Separation of

Concerns and Coupling. Therefore, we consider that

the second question is also true, since the productiv-

ity and code quality produced using the approach was

superior to the OO code produced manually.

Based on the experiments, there are other aspects

that may be discussed, considering the expert’s per-

ception. In the approach, the use of aspects should be

as transparent as possible, i.e., the developer only cre-

ates an aspect in the model, and sets some parameters

for it works properly. Therefore, the developers do

not need to understand this concept, and one advan-

tage is that all implementations are equals, helping the

maintenance and reuse.

7.1 Threats to Validity

The main threats to the validity of this study were

identiﬁed as its limitations are discussed below. Con-

struct validity. Participants in the experiments were

only students. Data were collected from a single data

source. We tried to mitigate this threat by applying a

placement test to ensure all students have had similar

knowledge levels and all were able to perform the re-

quested tasks. Design Threats. The use of poorly

designed experimental artifacts may be a threat. To

mitigate this issue, we designed our experiment to

work as software maintenance. Inappropriate se-

lection of subjects. The scope of domain (database)

is a threat since for other domains could present dif-

ferent results. However, we believe the application

of the approach to other domains has a great chance

of success, since the domain enables aspect solutions,

and a well-deﬁned PIM is created. Conclusion va-

lidity. The use of inappropriate measure occurring

the wrong understanding of the results. We deﬁned

clear hypotheses and chose the appropriate statistical

tests for each hypothesis. Furthermore, we tested all

data, verifying the data characteristics to use the cor-

rect statistical test and we applied the power test.

8 CONCLUSIONS

We have carried out an experiment to report an em-

pirical evaluation of our approach and to compare the

AO code generated by using the approach with the

OO code generated. The ﬁnal code produced by the

framework based on the proposed approach, consid-

ering all the data obtained in the analysis, was con-

sidered of better quality than that OO code produced

manually by programmers. This corroborates with

other studies that have already presented comparisons

An Empirical Study on the Impact of Aspect-oriented Model-driven Code Generation

281

between AO and OO code, as instance (Hoffman and

Eugster, 2009);(Katic et al., 2013);(Kulesza et al.,

2006). However, although AOSD is effective in im-

proving the separation of concerns, (Przybyłek, 2018)

pointed out that AOSD decreases understandability,

and this explains why object-oriented development is

advantageous over AOSD at completion time. How-

ever, using our approach, the completion time to pro-

duce AO code was shorter than the time to produce

the OO code manually.

As main advantage, we can highlight that our ap-

proach brought the beneﬁts already discussed in the

literature by the use of ASOD, and on the other hand

avoid the problems pointed out by (Przybyłek, 2018),

since the approach may help to improve the software

development (both quality and productivity).

Finally, the AOSD appeared more than two

decades, and so far its use remains a challenge in

the industry. Therefore, a fundamental novelty of our

research is that the application of AOSD should be

rethought, given the difﬁculty of its use in practice;

however this study shows that there are alternatives,

such as the use of higher-level solutions.

ACKNOWLEDGEMENTS

This study was ﬁnanced in part by the Fundac¸

Arauc

aria and Conselho Nacional de Desenvolvi-

mento Cient

ıﬁco e Tecnol

ogico (CNPq), protocol n.

9908272120340724

REFERENCES

Basili, V. R., Caldiera, G., and Rombach, H. D. (1994).

Goal Question Metric Approach”. In: Encyclopedia

of Software Engineering. Wiley.

France, R. and Rumpe, B. (2007). Model-driven Devel-

opment of Complex Software: A Research Roadmap.

In FOSE ’07: 2007 Future of Software Engineering,

pages 37–54, Washington, DC, United States. IEEE

Computer Society.

Garcia, A., Sant’anna, C., Figueiredo, E., and Kulesza, U.

(2005). Modularizing design patterns with aspects:

A quantitative study. In International Conference on

Aspect-Oriented Software Development.

Groher, I. and Voelter, M. (2009). Aspect-oriented model-

driven software product line engineerings. Trans. Asp.

Softw. Dev, 5560:111–152.

Hoffman, K. and Eugster, P. (2009). Cooperative

aspect-oriented programming. Sci Comput Program,

74(5–6):333–354.

Katic, M., Boticki, I., and Fertalj, K. (2013). Impact

of aspect-oriented programming on the quality of

novices’ programs: A comparative study. Journal of

Information and Organizational Sciences, 37(1).

Koch, N. (2007). Classiﬁcation of model transformation

techniques used in uml-based web engineering. Soft-

ware, IET, 1:98 – 111.

Kulesza, U., Sant’Anna, C., Garcia, A., Coelho, R., von

Staa, A., and Lucena, C. (2006). Quantifying the ef-

fects of aspect oriented programming: A maintenance

study. In 22nd IEEE Intl. Conf. on Software Mainte-

nance.

Mehmood, A. (2013). Aspect-oriented model-driven code

generation: A systematic mapping study. Information

and Software Technology, 55(2):395 – 411.

Mtsweni, J. (2012). Exploiting uml and acceleo for de-

veloping semantic web service. In The 7th Inter-

national Conference for Internet Technology and Se-

cured Transactions (ICITST-2012).

Oliveira, A. L., Menolli, A., and Coelho, R. (2008). Sepa-

rating data access crosscuting concerns using aspectj,

a quantitative assessment. In International Confer-

ence on Software Engineering.

erez, J., Ramos, I., Cars

ı, J. A., and Costa-Soria, C. (2013).

Model-driven development of aspect-oriented soft-

ware architectures. J. Univers. Comput. Sci., 19:1433–

1473.

Pinto, M., Fuentes, L., Fern

andez, L., and Valenzuela, J.

(2007). Using aosd and mdd to enhance the archi-

tectural design phase. Springer-Verlag, 5872:360 –

369. Second International Workshop on Aspect-Based

and Model-Based Separation of Concerns in Software

Systems.

Przybyłek, A. (2018). An empirical study on the impact

of aspectj on software evolvability. Empir. Software

Eng., 23:2018–2050.

Sant’Anna, C., Garcia, A., Chavez, C., Chavez, G., Lucena,

C., and von Staa, A. (2003). On the reuse and main-

tenance of aspect-oriented software: An assessment

framework. Brazilian S. on Software Engineering.

Simmonds, D. M., Reddy, Y., France, R., Ghosh, S., and

Solberg, A. (2005). An aspect oriented model driven

framework. Ninth IEEE International EDOC Enter-

prise Computing Conference (EDOC’05), pages 119–

130.

Singh, Y. and Sood, M. (2009). Models and transformations

in mda. In 2009 First International Conference on

Computational Intelligence, Communication Systems

and Networks, pages 253–258.

Tekinerdogan, B., Aksit, M., and Henninger, F. (2007). Im-

pact of evolution of concerns in the model-driven ar-

chitecture design approach. Electronic Notes in The-

oretical Computer Science, 163(2):45 – 64. Second

International Workshop on Aspect-Based and Model-

Based Separation of Concerns in Software Systems.

Varela, A., P

erez-Gonz

alez, H., Mart

ınez-P

erez, F. E., and

Soubervielle-Montalvo, C. (2017). Source code met-

rics: A systematic mapping study. J. Syst. Softw.,

128:164–197.

Wohlin, C. and Aurum, A. (2015). Towards a decision-

making structure for selecting a research design in em-

pirical software engineering. Empirical Software En-

gineering, 20:1427–1455.

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

282
