An Integrated Dependability Analysis and Design Method for

Distributed Systems Engineering

Claus Pahl

Free University of Bozen-Bolzano, Bolzano, Italy

Keywords:

Dependability Engineering, Reliability, Availability, Safety, Security, Requirements Analysis, Design,

Architecture, Software Quality.

Abstract:

Dependability Engineering is a critical importance for the now huge number of software systems that are

directly linked to people (and can damage them – be that physically or through security and data protection

issues) and that operate in open and distributed environments that expose them to reliability problems. We

present here an integrated dependability analysis and design methods for reliability, safety and security that

targets beginners and that can be applied without speciﬁc tools support. We introduce this analysis and design

method here in a concrete educational setting that is made up of beginners and works without tools. We will

look at this speciﬁcally in the context of Internet-of-Things data with realistic application cases.

1 INTRODUCTION

Dependability quantiﬁes several dimensions to pre-

dict how well and how long a system will operate.

These dimensions typically safety, security, reliabil-

ity and availability (ISO/IEC, 2011). Environments

such as the Internet-of-Things (IoT), edge and cloud

systems are particularly reliant on dependability.

While these aspects have been investigated, a

comprehensive method that provides, ﬁrstly, an inte-

grated view across all concerns, secondly, is based on

a joined architecture perspective, and, thirdly, uses a

uniform mechanism for the dependability analysis de-

spite differences in the metrics and assessments being

involved. We introduce here an analysis and design

method for dependable systems in open distributed

systems such as cloud, edge and IoT environments.

Furthermore, we target a beginners setting not sup-

ported by speciﬁc tools to allow the methods to be

brought to non-experts. We report this here in a teach-

ing context, presenting our experience for a Master-

level course on dependable systems analysis and de-

sign. This setting demonstrates the need for a uni-

form methods that can be used within the constraints

of graduate computer scientists without deep experi-

ence and speciﬁc tools.

Reliability is one of the central dependability

properties, largely capturing that a system performs as

requested. Reliability starts with a non-functional re-

liability requirements analysis that then extracts func-

tional reliability requirements and a design build on

suitable reliability architecture patterns. Safety ad-

dress the impact of a system onto its environment

in terms of damages that can be caused. A haz-

ard/accident analysis is the ﬁrst step, followed by a

corresponding risk analysis and a functional require-

ments and architecture steps. Security is concerned

with the impact of the environments on the system,

be that malicious or unintentional intrusions and their

negative consequences. Again, a non-functional re-

quirements analysis is following by a functional per-

spective and architectural design.

We present a method for dependable systems anal-

ysis and design for the three selected aspects. This has

been evaluated for a number of application systems in

the IoT and edge space. Key properties are the use of

a table format to have a uniform structure and repre-

sentation approach that does not rely on speciﬁc tools

and also a joint architecture approach based on com-

mon architecture patterns.

The methods takes into account the needs of a

non-expert setting. Here, the table-based analysis

approach allows a uniform approach that is easy to

convey. Also, architecture patterns as a common ap-

proach to address quality in software architectures is

a key ingredient. Thus, the aim is not to support fully

safety- or security-critical application development,

but to create a wider awareness of dependability needs

for less critical applications.

The remainder is organised as follows. Section 2

Pahl, C.

An Integrated Dependability Analysis and Design Method for Distributed Systems Engineering.

DOI: 10.5220/0010433102310238

In Proceedings of the 16th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2021), pages 231-238

ISBN: 978-989-758-508-1

231

reviews the background on dependability concerns. In

Section 3, we review the state-of the-art, both from an

educational and technical perspective. The analysis

and design method is introduced in Section 4 and the

subsequently evaluated in Section 5. We conclude in

Section 6.

2 BACKGROUND

Reliability, safety and security are well explored con-

cepts (Mellor, 1992; Avizienis et al., 2004; Al-

Kuwaiti et al., 2009; Walter and Suri, 2003), which

is partly reﬂected in standards.

• Security: ISO 27005:2018 (ISO/IEC, 2018) fo-

cuses on security requirements.

• Reliability: IEEE Standard 1044-1993 (IEEE,

2010) is the IEEE Classiﬁcation for Software

Anomalies that covers the reliability concepts

fault, error and failure.

In order to illustrate, but also to validate the proposed

solution, we refer to the following use cases:

• Road Mobility and Automotive: here we con-

sider connected cooperative autonomous mobil-

ity (CCAM), speciﬁcally focusing in examples

on cars and other vehicles in a motorway setting

(Barzegar et al., 2020b; Barzegar et al., 2020a;

Gand et al., 2020; Le et al., 2019). This a techni-

cal setting that involves IoT infrastructure through

sensors and actuators in cars and road-side, but

also edge capabilities for local car coordination as

well as remote cloud processing. Since cars with

passengers are involved, reliability, safety and se-

curity are of highest importance.

• Industry 4.0: automated production scenarios

equally require local coordination and processing,

e.g., for sensor-guided robots in production lines,

but also remote centralised processing of larger

volumes of data in clouds (von Leon et al., 2019;

Scolati et al., 2019; El Ioini and Pahl, 2018). As

business-critical activities, reliability and security

are important, as is safety of the operators and ma-

chines in the production process.

3 RELATED WORK

The importance of dependability and the need to con-

sider this in non-expert settings has been recognised

(Schoitsch and Skavhaug, ; Pahl et al., 2019). In this

paper, however, only a broad strategic perspective is

given. A concrete approach is lacking. In the wider

context of distributed systems, approach to teaching

and learning exist (Pop and Cristea, 2019). Here, the

need to cover IoT, cloud and edge scenarios through

architecture and also operations management is high-

lighted. Some works, such as (Michael et al., 2019),

go deeper on speciﬁc technologies. Here, model

checking is proposed a speciﬁc tool. However, we

are looking at a broader analysis and design process

coverage.

There is somewhat more technical progress. Some

attempts have recently tried to integrate dependability

concepts. (Shan et al., ) survey the current literature

on all dependability aspects. In (Verma et al., 2019),

the authors address a combined safety and security

perspective. (Dobaj et al., 2019), speciﬁcally look at

risk assessment in these two aspects.

In general, the need for a joint treatment is recog-

nised (Serpanos, 2019), but not may integrated ap-

proach exist. The need for an integrated perspective

is recognised for speciﬁc domains such as the auto-

motive and mobility domain that we also focus on

(Much, 2016).

This is where we aim to present an integrated ap-

proach that (i) integrates reliability, safety and secu-

rity, but also (ii) requirements analysis with architec-

tural design. However, it should be understood that

our aim is to provide a method that covers all ma-

jor aspects, but might not include deeper details that

would be required for a professional industrial setting

(but are not feasible in an educational setting).

4 DEPENDABILITY

FRAMEWORK

The presentation of the dependability analysis and de-

sign framework is presented in two parts: ﬁrstly, a

conceptual summary of the quality concerns, metric

and their meaning, followed by, secondly, a process

for analysis and design based on the common table

structure.

4.1 Conceptual Framework

For each of the three aspects reliability (including

availability), safety and security, we now present a

conceptual map deﬁning the key concepts and the rel-

evant metrics.

4.1.1 Reliability

A basic conceptual map of the reliability aspect is pre-

sented in Figure 1 that follows (IEEE, 2010).

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

232

Figure 1: Reliability - Conceptual Map.

Often, availability, which in itself is an important

concerns, is captured as part of the reliability concern.

We reﬂect this and cover availability as part of the

metrics:

AVAIL = 1 −

downtime

uptime

POFOD =

number o f f ailures

number o f requests

ROCOF =

number o f f ailures

total − elapsedtime

MT T F =

ROCOF

total − elapsedtime

number o f f ailures

(1)

Note that these are numerical dimensions. Later

on in the security and safety aspects, we will also con-

sider categorical aspects. These metrics need to be

better explained in order to clarify the meaning and

when they should be used. For instance, POFOD is

suitable for rarely used functions such as emergency

systems, while ROCOF is suitable for regulary and

frequently used functions that are short in duration.

For functions with a long duration, the MTTF metric

is more suitable.

For availability, it needs to be noted that systems

with the same availability might have different outage

behaviours, see Figure 2. In many cases, many shorter

outages (below some threshold) are less critical than

one long one.

Figure 2: Graph Availability.

ROCOF captures the number of failures for fre-

quently occurring events.

MTTF captures the likely time until the next fail-

ure, which should ideally not happen during the func-

tion execution of a long-lasting function.

These graphs help to clarify the semantics of the

metrics. In addition, we provide information to the

users on measurements and requirements values. At

Figure 3: Graph ROCOF.

Figure 4: Graph MTTF.

least in generic terms, we explained the difference be-

tween orders of magnitude, e.g., between 0.9 and 0.99

for availability and how those translate into time peri-

ods (such as a day or a year).

4.1.2 Safety

We start again with a conceptual map, shown in Fig-

ure 5. The central concepts are hazards, which might

turn into accidents. Accidents if they happen cause

damage. The important task is to assess the risk that

a hazard becomes an actual accident. The risk is de-

ﬁned through the severity and probability of the acci-

dent.

Figure 5: Safety - Conceptual Map.

In order to assess the safety criticality, the follow-

ing metrics severity level, probability level and risk

level with their respective value ranges are proposed

• Risk: tolerable, ALARP (as low as reasonably

possible), intolerable)

• Severity: low, medium, high

• Probability: low, medium, high

Rather than being numerical, we assess these as a

classiﬁed metric. The concrete values are common

ones, but could be altered if needed.

4.1.3 Security

The conceptual map for security reﬂects threats and

how they could be exploited by an intruder, as shown

An Integrated Dependability Analysis and Design Method for Distributed Systems Engineering

233

in Figure 8. Starting with the assets to be pro-

tected, the individual security concerns such a expo-

sure, threat and vulnerability can causally linked. A

vulnerability can then be exploited by an attacker, but

countered with a control mechanism.

Figure 6: Security - Conceptual Map.

The relevant metric is here the security level,

which like in the safety example uses classiﬁed, or-

dered labels: low, medium, high.

4.1.4 Discussion

While for reliability we have used quantitative met-

rics, for security and safety quantitative metrics are

proposed. Reliability metrics are generally easy to

monitor and measure. The others however are inﬂu-

enced by a multitude of factors that are more difﬁcult

to quantify. For instance, security is the summary of

aspects such as integrity and conﬁdentiality. Thus, la-

bels as broader categories have been suggested.

4.2 Analysis and Design Process

4.2.1 Non-functional Requirements Analysis

All three dependability aspects start with a non-

functional requirements perspective.

For Reliability, we propose a 2-step approach

consisting of a fault-failure analysis and a mapping

to corresponding metrics. The Fault-Failure Analy-

sis associates faults and possibly resulting failures to

each component:

Component | Fault | Failure

A concrete example of this for the automotive road

mobility use case is presented in Table 1. The ex-

ample focuses on hardware components as the more

likely sources of failures.

Table 1: Fault-Failure Analysis.

Component Fault Failure

sensor broken no data

camera dust incorrect data

5G antenna broker no data up/down

GPS no signal no position

The Dependability Mapping associates metrics

and their concrete values to the components and the

relevant dependability concern.

Component | Dep Concern | Metric | Value

In Table 2, the values reﬂect assumed realistic require-

ments.

Table 2: Reliability Analysis.

Component Dep Concern Metric Value

sensor reliability AVAIL 0.99

camera reliability POFOD 0.9

5G antenna reliability AVAIL 0.999

5G antenna reliability ROCOF 0.9999

GPS reliability AVAIL 0.999

For the next concern, Safety, we propose a 3-step

approach consisting of a hazard-accident analysis, a

risk analysis and a fault-tree based root cause analy-

sis. The Hazard-Accident Analysis identiﬁes the rele-

vant hazards and possibly resulting accident. A con-

crete application of the analysis is given in Table 3.

Component | Hazard | Accident

Table 3: Safety Analysis.

Component Hazard Accident

external object on road crash (car/people)

antenna fail to communicate crash/system

stops

edge overload car crash

external security attack car crash

The seconds step is the Risk Analysis, which asso-

ciates accident probability and severity, from which

an overall risk can be derived. A concrete example is

given in Table 4.

Hazard | Probability | Severity | Risk

Table 4: Safety Risk Analysis.

Hazard Probability Severity Risk

animal low high ALARP

truck medium high intolerable

antenna high high intolerable

The third step is the Fault Tree, which is a Root

Cause Analysis, presented in Figure 7.

The ﬁnal dependability concern is Security. A

concrete example is shown in Figure 5. This starts

with a Security Risk analysis:

Control

Then, a Security Policy needs to be speciﬁed, for

which a concrete example is given in Table 6.

Asset | Level of Protection | responsibilities |

Procedures and Techniques

The analysis and design process shall now be sum-

marised, see Fig. 1

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

234

Table 5: Security Risk Analysis.

Asset Exposure Threat Vulnerability Attack Control

DB data loss

(integrity)

accidental deletion

OR unauthorised user

no proper ac-

cess control

unauthorised user

accesses DB

authentication

software

sensor data manip-

ulation

unauthorised use no encryption packet spooﬁng

and manipulation

encryption

sensor data manip-

ulation

noise redundancy accidental encryption,

access control

sensor data leak-

age

unauthorised use no encryption packet spooﬁng

and manipulation

encryption

Figure 7: Safety - Fault Tree.

Table 6: Security Policy.

Asset Level of

Protec-

tion

Responsi-

bilities

Procedures

and Tech-

niques

car po-

sition

data

high in transit: com-

munication in-

frastructure

encryption

DB /

edge

cloud

high DB manager access con-

trol and re-

dundancy

4.2.2 Functional Dependability Requirements

and Architecture

Now, we change the perspective from non-functional

dependability requirements to functional dependabil-

ity requirements, i.e., requirements for system com-

ponents that help to prevent, detect or remedy (heal)

the dependability requirements identiﬁed. The gen-

eral objectives are avoidance, identiﬁcation, reme-

diation. We outline here some sample architec-

tural strategies. In the context of this dependabil-

ity design, we need an architectural style. We spec-

ify the key principles and patterns of this architec-

tural style as follows: (i) Principles: redundancy,

diversity; (ii) Patterns: MAPE-K, Protection Sys-

tem, Multichannel Architecture. Figure 9 illustrates

the MAPE-K pattern. In the MAPE-K, K rep-

resents knowledge, for example rules of the form

if T > 20 then CloseValve else OpenValve for

T of type temperature and T = 20 for a self-adaptive

heating system. Figure 10 shows the protection sys-

tem pattern. Figure 11 shows the multi-channel ar-

chitecture, which proposes to carry out the same task

Figure 8: Analysis and Design Process.

using different mechanism, and let a selector decide

on the correctness of the result.

Figure 9: Layered ML Quality Management Architecture.

Figure 10: Protection System.

The patterns allow to select a concrete architec-

ture that realises the principles of redundancy and di-

versity (Barrett et al., 2006; Pahl et al., 2018), which

are known to aid dependability engineering. In order

to avoid, identify or remedy dependability risks, these

patterns can be utilised. For Reliability, the following

components could be suitable:

• Reliability: a multichannel architecture to in-

crease reliability.

• Availability: MAPE-K with with analysis and

planning components for instance to utilise

HADR (high availability and desaster recovery)

An Integrated Dependability Analysis and Design Method for Distributed Systems Engineering

235

Figure 11: Multi Channel Architecture.

functions as actions.

For Safety, the following architectural components

could be suitable: MAPE-K with monitoring to mea-

sure the relevant safety concerns such whether objects

in the vicinity are still intact and react with an emer-

gency shutdown in an accident situation (or even as

a prevention measure before the actual accident hap-

pens). For Security, a protection system against ex-

ternal attacks is a solution.

We now illustrate this stage. Examples are pre-

sented in Table 7. The concerns of this architectural

analysis and design step for security are as follows:

Layer of risk | Control | architectural solution type

Table 7: Architectural Design.

Layer of Risk Control Architectural

Solution Type

technology /

platform

architecture /

application

partitioning distribution

asset / data / ob-

ject / record

encryption protection

Concrete functional components are ﬁrewall, en-

cryption or access control.

5 EVALUATION

The methods targets a non-expert developer that

might not have access to dedicated tools. A sample

setting that matches these requirements is education.

The presented method has been used over 4 years in

the course Requirements and Design for Dependable

Systems as part of an M.Sc. in Software Engineering

where participants had a least a degree in computing,

partly with industrial development experience. Dur-

ing this period, around 15 students in average have

participated. Since this course is also catering for

part-time students, the proportion of students with in-

dustrial experience, either prior to enrolling or con-

currently experiencing, is more than 50 %.

For this context, the key evaluation criteria we

have chosen are: (i) relevance of the method, i.e., how

realistic and ﬁt for purpose the proposed method is in

industrial practice, (ii) non-expert suitability, i.e., how

well the method is suitable for untrained developers

without dedicated tools.

5.1 Relevance

The relevance criterion assesses the technical ade-

quacy of the method, i.e., whether it reﬂects industrial

practice and aligns with common conceptualisations.

For the latter point, we already presented the align-

ment with standards regarding the conceptual scope

in the Background section earlier on. A more detailed

investigation of the criteria shows:

• Concepts: validity (complete and necessary) is

given, 1) based on using standards and referring to

relevant literature on dependability concepts, and,

2) is veriﬁed in concrete experiments (application

scenarios) that we document below.

• Process: effectiveness (i.e., is usable and achieves

the goals) has been demonstrated experimentally

by applying the method over 4 years in 4 different

application settings by more than 25 teams.

A number of domains have been selected, that vary in

terms of the distribution of the setting, the number and

form of people being involved, and the type of cyber-

physical system in terms of hardware/embedded sys-

tem components utilised. This is summarised in Table

Table 8: Application Scenarios in IoT Settings.

Application

Domain

Properties Source

Road mobility Safety, Re-

liability

EU H2020 Project

5G-CARMEN

Industry 4.0 Reliability Microtec Scanning

Devices – Wood

Production

Health Safety Insulin Pump Case

Study

Tourism Safety Dolomites Skiing

5.2 Suitability

While the previous section looked at the technical ad-

equacy of the method (in terms of relevance for indus-

trial practice), we now consider the suitability for the

non-expert setting. The requirements here were:

• Comprehensibility, i.e., the the method is easy to

learn within a given time frame (e.g., that of the

course in question).

• Tool support, i.e., the feasibility of applying the

method in a constrained setting without dedicated

analysis tools.

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

236

For comprehensibility, we created a uniform table-

based format for all dependability aspects that refers

to metrics and measurements of common types for

the analysis part. Equally, for the architecture part,

the starting point were architecture patterns, which as

industry practice are commonly used in software en-

gineering and software architecture teaching. Thus,

basing the method on common structures and mecha-

nism aided the learnability.

For tool support, here no speciﬁc software tools

were requires as only tables and block diagrams had

to be created. Here, the simple presentation allowed

open discussions and the use of blackboard in the val-

idation setting of classroom-based teaching.

In terms of acceptance and usability of the

method, from the student side, the high topicality of

the problem context as well as the chosen application

domains were appreciated. The method itself with

is presentation elements and its proposed process has

not caused problems. The difﬁculty here was more in

understanding domain knowledge.

6 CONCLUSIONS

The dependability of modern software systems is

due to their deep involvement not only in industrial

production or organisational administration, but also

in our everyday life of critical importance. Conse-

quently this needs to be taught to students as well.

For the classroom, we need a dependability engineer-

ing that takes on-board the critical concerns reliabil-

ity, safety and security, but also does so in in a for-

mat suitable for the constraints of teaching. We use a

table-based structure for analysis and integrated im-

portant metrics into it. The architectural design is

based on architectural patterns to steer the system de-

sign towards important quality criteria.

Overall, the method does not aim at support fully

safety or security-critical applications, but to provide

improved dependability and in particular an improved

awareness of the concerns for a wider range of appli-

cations. This is of particular importance for the de-

scribed training context. Here, the uniformity of the

modelling means should aid online presentation needs

(Kenny and Pahl, 2005; Pahl et al., 2004; Murray

et al., 2003; Lei et al., 2003; Melia and Pahl, 2009;

Fronza et al., 2019). We have taken a ﬁrst step to-

wards a semantic model in the form of an ontology for

dependability analysis with the table structure (Fang

et al., 2016; Javed et al., 2013; Pahl, 2005), although a

full formalisation would enhance analysis quality. A

remaining challenge is the difﬁculty of providing do-

main knowledge is a suitable form. While a generic

method can provide for instance metrics and can give

guidance on what differentiates different measure-

ments in terms of orders of magnitude (e.g., 0.99 vs.

0.999), these need to be linked to concretely accept-

able ﬁgures that are often domain-speciﬁc. Here, we

still aim to improve the method using an industrial

trial.

REFERENCES

Al-Kuwaiti, M., Kyriakopoulos, N., and Hussein, S. (2009).

A comparative analysis of network dependability,

fault-tolerance, reliability, security, and survivabil-

ity. IEEE Communications Surveys & Tutorials,

11(2):106–124.

Avizienis, A., Laprie, J. ., Randell, B., and Landwehr, C.

(2004). Basic concepts and taxonomy of dependable

and secure computing. IEEE Transactions on Depend-

able and Secure Computing, 1(1):11–33.

Barrett, R., Patcas, L. M., Pahl, C., and Murphy, J. (2006).

Model driven distribution pattern design for dynamic

web service compositions. In Proceedings of the 6th

International Conference on Web Engineering, ICWE

’06, page 129–136, New York, NY, USA. Association

for Computing Machinery.

Barzegar, H. R., El Ioini, N., Le, V. T., and Pahl, C. (2020a).

Wireless network evolution towards service continuity

in 5g enabled mobile edge computing. In 2020 Fifth

International Conference on Fog and Mobile Edge

Computing (FMEC), pages 78–85.

Barzegar, H. R., Le, V. T., El Ioini, N., and Pahl, C. (2020b).

Service continuity for ccam platform in 5g-carmen.

In 2020 International Wireless Communications and

Mobile Computing (IWCMC), pages 1764–1769.

Dobaj, J., Schmittner, C., Krisper, M., and Macher, G.

(2019). Towards integrated quantitative security and

safety risk assessment. In Intl Conf on Computer

Safety, Reliability, and Security, pages 102–116.

El Ioini, N. and Pahl, C. (2018). Trustworthy orchestra-

tion of container based edge computing using permis-

sioned blockchain. In 2018 Fifth International Con-

ference on Internet of Things: Systems, Management

and Security, pages 147–154.

Fang, D., Liu, X., Romdhani, I., Jamshidi, P., and Pahl, C.

(2016). An agility-oriented and fuzziness-embedded

semantic model for collaborative cloud service search,

retrieval and recommendation. Future Generation

Computer Systems, 56:11–26.

Fronza, I., El Ioini, N., Pahl, C., and Corral, L. (2019).

Bringing the Beneﬁts of Agile Techniques Inside

the Classroom: A Practical Guide, pages 133–152.

Springer Singapore, Singapore.

Gand, F., Fronza, I., El Ioini, N., Barzegar, H. R., Le, V. T.,

and Pahl, C. (2020). A lightweight virtualisation plat-

form for cooperative, connected and automated mo-

bility. In Proceedings of the 6th International Confer-

ence on Vehicle Technology and Intelligent Transport

An Integrated Dependability Analysis and Design Method for Distributed Systems Engineering

237

Systems - Volume 1: VEHITS,, pages 211–220. IN-

STICC, SciTePress.

IEEE (2010). Ieee standard classiﬁcation for software

anomalies. IEEE Std 1044-2009 (Revision of IEEE

Std 1044-1993), pages 1–23.

ISO/IEC (2011). Iso/iec 25010:2011 – systems and soft-

ware engineering — systems and software quality

requirements and evaluation (square) — system and

software quality models.

ISO/IEC (2018). Iso/iec 27005:2018 – information tech-

nology — security techniques — information security

risk management.

Javed, M., Abgaz, Y. M., and Pahl, C. (2013). Ontology

change management and identiﬁcation of change pat-

terns. Journal on Data Semantics, 2(2):119–143.

Kenny, C. and Pahl, C. (2005). Automated tutoring for a

database skills training environment. SIGCSE Bull.,

37(1):58–62.

Le, V. T., Pahl, C., and El Ioini, N. (2019). Blockchain

based service continuity in mobile edge comput-

ing. In 2019 Sixth International Conference on In-

ternet of Things: Systems, Management and Security

(IOTSMS), pages 136–141.

Lei, X., Pahl, C., and Donnellan, D. (2003). An evaluation

technique for content interaction in web-based teach-

ing and learning environments. In Proceedings 3rd

IEEE International Conference on Advanced Tech-

nologies, pages 294–295.

Melia, M. and Pahl, C. (2009). Constraint-based validation

of adaptive e-learning courseware. IEEE Transactions

on Learning Technologies, 2(1):37–49.

Mellor, P. (1992). Failures, faults and changes in depend-

ability measurement. Information and Software Tech-

nology, 34(10):640 – 654.

Michael, E., Woos, D., Anderson, T., Ernst, M. D., and Tat-

lock, Z. (2019). Teaching rigorous distributed systems

with efﬁcient model checking. In EuroSys Confer-

ence, pages 1–15.

Much, A. (2016). Automotive security: challenges, stan-

dards and solutions. Softw. Qual. Prof, 18(4):4–12.

Murray, S., Ryan, J., and Pahl, C. (2003). A tool-mediated

cognitive apprenticeship approach for a computer en-

gineering course. In Proceedings 3rd IEEE Interna-

tional Conference on Advanced Technologies, pages

2–6.

Pahl, C. (2005). Layered ontological modelling for web

service-oriented model-driven architecture. In Hart-

man, A. and Kreische, D., editors, Model Driven Ar-

chitecture – Foundations and Applications, pages 88–

102, Berlin, Heidelberg. Springer Berlin Heidelberg.

Pahl, C., Barrett, R., and Kenny, C. (2004). Supporting ac-

tive database learning and training through interactive

multimedia. In Proceedings of the 9th Annual SIGCSE

Conference on Innovation and Technology in Com-

puter Science Education, ITiCSE ’04, page 27–31,

New York, NY, USA. Association for Computing Ma-

chinery.

Pahl, C., El Ioini, N., Helmer, S., and Lee, B. (2018). An ar-

chitecture pattern for trusted orchestration in iot edge

clouds. In 2018 Third International Conference on

Fog and Mobile Edge Computing (FMEC), pages 63–

70.

Pahl, C., Fronza, I., El Ioini, N., and Barzegar, H. R. (2019).

A review of architectural principles and patterns for

distributed mobile information systems. In Intl Conf

on Web Information Systems and Technologies.

Pop, F. and Cristea, V. (2019). Distributed systems educa-

tion: From traditional models to new paths of learn-

ing. In Intl Conf on Control Systems and Computer

Science, pages 383–386.

Schoitsch, E. and Skavhaug, A. European perspectives on

teaching, education and training for dependable em-

bedded and cyber-physical systems. In Euromicro

Conference on Software Engineering and Advanced

Applications.

Scolati, R., Fronza, I., El Ioini, N., Samir, A., and Pahl,

C. (2019). A containerized big data streaming archi-

tecture for edge cloud computing on clustered single-

board devices. In Proceedings of the 9th International

Conference on Cloud Computing and Services Sci-

ence - Volume 1: CLOSER,, pages 68–80. INSTICC,

SciTePress.

Serpanos, D. (2019). There is no safety without security

and dependability. Computer, 52(6):78–81.

Shan, L., Sangchoolie, B., Folkesson, P., Vinter, J.,

Schoitsch, E., and Loiseaux, C. A survey on the ap-

plicability of safety, security and privacy standards in

developing dependable systems. In Intl Conf on Com-

puter Safety, Reliability, and Security.

Verma, S., Gruber, T., Schmittner, C., and Puschner, P.

(2019). Combined approach for safety and security.

In International Conference on Computer Safety, Re-

liability, and Security, pages 87–101. Springer.

von Leon, D., Miori, L., Sanin, J., El Ioini, N., Helmer, S.,

and Pahl, C. (2019). A Lightweight Container Middle-

ware for Edge Cloud Architectures, chapter 7, pages

145–170. John Wiley & Sons, Ltd.

Walter, C. J. and Suri, N. (2003). The customizable

fault/error model for dependable distributed systems.

Theoretical Computer Science, 290(2):1223–1251.

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

238
