ConfIs: A Tool for Privacy and Security Analysis and Conflict
Resolution for Supporting GDPR Compliance through
Duaa Alkubaisy
, Luca Piras
, Mohammed Ghazi Al-Obeidallah
, Karl Cox
and Haralambos Mouratidis
Centre for Secure, Intelligent and Usable Systems, University of Brighton, U.K.
Imam Abdurrahman Bin Faisal University, Dammam, Saudi Arabia
School of Computing, Robert Gordon University, Aberdeen, U.K.
School of Computer Sciences and Informatics, Amman Arab University, Jordan
Keywords: Security Requirements, Privacy Requirements, Requirements Conflicts, General Data Protection Regulation
(GDPR), Requirements Modelling, Privacy by Design.
Abstract: Privacy and security requirements, and their potential conflicts, are increasingly having more and more
importance. It is becoming a necessary part to be considered, starting from the very early stages of
requirements engineering, and in the entire software engineering cycle, for the design of any software system.
In the last few years, this has been even more emphasized and required by the law. A relevant example is the
case of the General Data Protection Regulation (GDPR), which requires organizations, and their software
engineers, to enforce and guarantee privacy-by-design to make their platforms compliant with the regulation.
In this context, complex activities related to privacy and security requirements elicitation, analysis, mapping
and identification of potential conflicts, and the individuation of their resolution, become crucial. In the
literature, there is not available a comprehensive requirement engineering oriented tool for supporting the
requirements analyst. In this paper, we propose ConfIs, a tool for supporting the analyst in performing a
process covering these phases in a systematic and interactive way. We present ConfIs and its process with a
realistic example from DEFeND, an EU project aiming at supporting organizations in achieving GDPR
compliance. In this context, we evaluated ConfIs by involving privacy/security requirements experts, which
recognized our tool and method as supportive, concerning these complex activities.
Conflicts arising between different requirements,
such as privacy and security, are a common problem
in engineering software systems (Kim et al., 2007).
Conflicts in software requirements are inevitable
because of the nature of software development for
realistic systems, and conflicts, therefore, are the
most common cause of inconsistencies during the
software development process (Egyed and Boehm,
1998). Every case of conflict based on requirements
is surrounded by complex issues, and these issues
should be taken into consideration when resolving the
conflicts (Lamsweerde, et al., 1998). Security and
privacy requirements should be considered essential
for every software system. Privacy has become a
mainstream topic, and especially problematic for
software development companies. Problems around
misuse of presumed personal data by organizations,
especially social media companies, has led to moves
to ‘guarantee’ privacy at legislative levels, as
envisioned in the EU’s General Data Protection
Regulation (GDPR) (Albrecht, 2016). However, from
the developer’s point of view, certain issues crop up
when adhering to security requirements, while others
appear when adhering to privacy requirements. This
can lead to conflict when trying to meet these
requirements, and it is now necessary for developers
to manage these conflicts in order to be compliant
with GDPR. However, there is a degree of complexity
within these conflicting requirements that makes
resolution less immediately obvious. Recourse to the
business objective is one way to determine whether a
Alkubaisy, D., Piras, L., Al-Obeidallah, M., Cox, K. and Mouratidis, H.
ConfIs: A Tool for Privacy and Security Analysis and Conflict Resolution for Supporting GDPR Compliance through Privacy-by-Design.
DOI: 10.5220/0010406100800091
In Proceedings of the 16th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2021), pages 80-91
ISBN: 978-989-758-508-1
2021 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
security requirement outweighs its privacy conflict in
aiming to achieve compliance with GDPR. The first
step in this type of conflict resolution is to be able to
identify the conflict in the first place: this paper
outlines an approach for doing so.
In the context of software development, a conflict
is defined as a clash of interests in the development
environment between privacy and security
requirements (Schar et al., 2015). Such a conflict
could arise at any point in the Systems Development
Life Cycle (SDLC), irrespective of whether an agile,
traditional or hybrid approach is used. Regardless of
the approach, it is less costly to identify incorrect
requirements – and here we can add privacy and
security requirements (Liu et al., 2003) in the
requirements phase than to do so later (Egyed and
Boehm, 1998). For example, pseudonymization
(privacy requirement) may conflict with the need for
authentication (security requirement) to avoid a data
breach. While such conflicts are common, the
challenge is to balance them without creating the
opportunity for an easier breach of privacy or
security. Conflicts arising from incompatible
requirements can negatively affect information
systems, even if controls are put in place (Kim et al.,
2007; Egyed and Boehm, 1998; Lamsweerde et al.,
1998). Consequently, it is preferable to manage
conflicts that are identified early in the lifecycle,
before they derail the entire project. However, a
requirement conflict can still affect the development
of information systems and their successful
deployment, even after controls have been put in
place to manage conflict or resolve it (Schar et al.,
Data breaches are a key concern for businesses
with large amounts of personal data, such as banks
and governmental departments, as such systems are
the most frequently targeted, accounting for nearly
80% of all incidents disclosed (Botha et al., 2017).
Commercial organizations are also at risk. For
example, TalkTalk, a telecoms provider, was hit with
a record £400K fine for a data breach in 2015 that
exposed the private details of more than 150,000
customers (Farrell, 2015).
GDPR forces organizations to implement changes
that relate to the use of personal data as well as its
protection. GDPR empowers citizens to take greater
control of their personal data by having a say in the
use of their data. Organizations are required to keep
track of the use of user data, which allows the relevant
authorities (such as individuals) to give consent with
ease. Despite the advantages of GDPR, it can be hard
to apply for several reasons, including complexities
involved in measures put in place by companies to
enhance security. These complexities can lead to
conflicts in addition to the complexity involved in
covering various aspects of data protection. Most of
the existing approaches in the literature (Aldekhail et
al., 2016; Mairiza and Zowghi, 2010; Mairiza et al.,
2013) do not provide adequate solutions to identify
and resolve conflicts between security and privacy
requirements. Identifying and resolving such
conflicts are essential to mitigate threats to software
systems, as unresolved conflicts could make a system
vulnerable to threats.
This paper is based on our previous work
Alkubaisy (2017, 2019), and here we present the final
framework. This paper provides a novel structured
framework that fulfils the gap of the current state of
the art. Above all, this paper addresses the following
Research Questions (RQs):
RQ1: How to design a framework supporting the
analyst to identify and resolve conflicts between
privacy and security requirements?
RQ2: How to support the analyst in the identification
and resolution of conflicts between requirements in a
systematic and tool-supported way in real cases?
RQ1 will be addressed by extending SecTro, a
requirement modelling tool (Pavlidis and Islam,
2011). The proposed framework offers the analyst a
process or guide to help him in identifying and
resolving conflicts. The presented framework will be
validated using one part of the DEFeND project
(Mouratidis, 2011) to ensure that this framework is
GDPR compliant.
RQ2 will be addressed by reviewing the current
methods to identify conflicts between requirements,
and by introducing ConfIS framework phases to help
the analyst to locate conflicts between requirements.
The rest of the paper is organized as follows.
Section 2 presents the baseline from which we started
and based our work. These parts are phases of the
theoretical framework, DEFeND project where the
framework has been applied, and answers to RQ1.
Section 3 addresses RQ2 by proposing Tool-
Supported Conflict Identification, Resolution and
application of these within DEFeND, showing and
discussing our Case Study. Section 4 evaluates the
proposed ConfIS framework. Related work and
conclusion are presented respectively in Sections 5
and 6.
ConfIs: A Tool for Privacy and Security Analysis and Conflict Resolution for Supporting GDPR Compliance through Privacy-by-Design
This section presents an overview of the key parts
presented in this paper. This paper is based on our
previous work Alkubaisy (2017, 2019), and here we
present the final framework based on the previous
work. The first part presents our proposed theoretical
framework, enhanced with an explanation of each
phase. We then explain more about the DEFeND
project (Piras et al., 2019; Piras et al., 2020), an
ongoing live project aiming to determine needs
related to identifying conflicts and conflict resolution.
An overview of the SecTro tool, which has been
extended to fulfil the requirements of our proposed
framework, is presented at the end of this section.
2.1 Theoretical Framework Phases
Our proposed framework has a sequence of phases to
achieve conflict detection and resolution, presented in
Figure. 1:
Figure 1: The phases of the proposed theoretical
As Fig. 1 illustrates, some of the steps are semi-
automated, while the others are manual steps, based
on the analyst’s point of view.
The partners might have a special perspective on
requirements. First, the conflicts between
requirements are identified, based on a matrix
presented by a previous study (Piras et al., 2019).
Hence, we sort the requirements that could lead to a
potential conflict. After identifying the requirements
that are in conflicts, the analyst must decide whether
this kind of conflict would affect the system, based on
the presented scenarios. Therefore, the first phase of
the framework is performed manually by the software
requirements analyst. Phase Two identifies the
potential conflicts between requirements that were
detected in the previous phase. The final phase
proposes conflict resolution patterns by matching the
problem to a resolution pattern for each conflict that
the analyst might face. Those patterns act as a
reference for the analyst to resolve conflicts between
requirements. The final phase of our framework is
automated by using the SecTro tool (by importing a
privacy pattern library).
2.2 DEFeND Project
The DEFeND project was designed as an EU project
to support organizations by defining essential tools
and methods that enable organizations and authorities
to monitor their actions so that they can be GDPR-
compliant (Mouratidis, 2011). DEFeND stands for
Data govErnance For supportiNg gDpr. DEFeND
aims at improving existing frameworks and software
tools and developing and designing new integration
software based on market needs. This is with the aim
of delivering a unique data platform for privacy
In order to achieve GDPR compliance and raise
awareness of the diverse features of GDPR, DEFeND
will deliver a platform which empowers
organizations in various sectors to assess their
compliance status. The DEFeND platform allows for
designing and analysing models following a Privacy-
by-Design approach. The DEFeND platform provides
five main services to organizations and relevant
stakeholders: Data Scope Management Service, Data
Process Management Service, Data Breach
Management Service, GDPR Planning Service and
GDPR Reporting Service. Each of these services
assists organizations in collecting, analysing and
operationalizing different aspects and articles of
GDPR, and providing appropriate reporting
The DEFeND platform will be in a live laboratory
pilot studies in four different areas: healthcare,
finance (or banking), energy and local public
administration. The DEFeND platform will be tested
in an effective environment in three scenarios through
two different types. The first type focuses on the
GDPR compliance process for end users, while the
second addresses GDPR implications for external
stakeholders. Our proposed framework will identify
and resolve conflicts between requirements by
applying a scenario from the healthcare sector of the
DEFeND project.
2.3 SecTro
SecTro tool has been used to aid in the modelling of
conflicts resolution (Alkubaisy et al., 2019). It
implements the Secure Tropos Methodology which
consists of an engineering approach for security and
privacy requirements, starting from early-stage
requirements of the IS (Information System)
development process. Secure Tropos must be
specified in the early phases of an IS development, as
it is an organized approach for goal-oriented security
and privacy requirement modelling. The Secure
ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering
Tropos methodology supports a modelling language,
security aware processes and automated processes.
The Secure Tropos methodology enhances our
framework by translating conflicts between
requirements in a goal model. SecTro presents
models that contain security and privacy
requirements (Piras et al., 2020). It involves
modelling views which are used to facilitate system
design and elicitation of security and privacy
To solve the conflicts between requirements, we
explored critical conflicts from literature review,
research studies and European Projects. The needs
come also from a discussion with stakeholders from
different domains, such as banking, healthcare, public
administration, and smart energy; all of which need to
achieve GDPR compliance. In addition, we found that
conducting a requirement analysis on Privacy-by-
Design, found potential conflicts that could not be
solved. Hence, on behalf of DEFeND a European
Project - we have interviewed those stakeholders in
relation to how to create platforms to address such
Achieving GDPR compliance is very complex. To
do so, requirements analysis must be conducted, in
which many conflicts arise, and stakeholders may
have great difficulty in understanding how to manage
and solve them. Moreover, we found that performing
requirements analysis on Privacy-by-Design in real
cases is essential, according to the stakeholders. We
recognize that stakeholders need to achieve GDPR
compliance via Privacy-by-Design, and they consider
this as a problem. In addition, as mentioned above,
there is a lack of recent studies which addresses this
issue. Stakeholders need a tool to resolve the
identified conflicts more quickly by reducing their
effort and having a ready-to-use solution of any of the
conflicts that could arise.
3.1 Motivation Scenario
As we discussed earlier, within the DEFeND project
section, it comprises several services. The Centre for
Secure, Intelligent and Usable Systems at the
University of Brighton works on one of DEFeND’s
services; Data Scope Management (DSM) which
supports Privacy by Design (PbD). DSM developed a
case study which has been used as a storyline, to
regard highly valuable PbD activities of DSM. In
Mouratidis and Giorgini, (207), the DSM service has
been widely discussed by describing its flow phase by
phase, and by using the storyline. In this paper, we
will illustrate one example from the storyline and
apply the ConfIS framework phase by phase to
identify and resolve the conflicts between security
and privacy requirements. The example being
applied in the ConfIS framework is as follows:
One of the most critical aspects is to manage
patients’ medical record, have verification from
a supervisor for any changes happening to it, and
establish a retention period for the data.
In section 3.4 we will analyse this example and
find out the related security and privacy requirements.
Therefore, we will apply the ConfIS framework phase
by phase to resolve conflicts.
3.2 Integrating the Theoretical
Framework in SecTro
The SecTro tool has been extended with new
concepts to support the analyst in identifying and
resolving conflicts. The theoretical framework was
completely integrated and implemented in the top of
SecTro, with its analysis supporting all phases. Here,
the case study shows in more details, diagrams from
the tool that are integrated with the theoretical
Moreover, the new concepts are added to the
privacy by design view of SecTro to support the
modelling of requirements conflicts. Phase two
involves identifying conflicts between requirements
according to the output from phase one. At This Point,
the analyst needs to make conflict decisions based on
each scenario and the relevant requirements. Next, in
phase three, new concepts are added to identify
conflicts; based on the out-come of phase two, the
analyst will locate these conflicts. The next section
describes the case study in further depth and applies
the theoretical framework to achieve conflict
3.3 Tool Description in a Case Study
Based on the motivation example, we will illustrate
the security and privacy requirements, following the
phases of the ConfIS framework to resolve conflicts,
using the extended supported tool. The first phase
aims to map the security and privacy requirements
Alkubaisy, 2017). This assumes the existence of a
matrix to find out the potential conflicts between
security and privacy requirements, based on our
ConfIs: A Tool for Privacy and Security Analysis and Conflict Resolution for Supporting GDPR Compliance through Privacy-by-Design
recent study Piras et al., 2019). The next sections
show the application of our proposed framework
phases in identifying and resolving conflicts,
discusses the application of the motivation example
in SecTro, and presents the theoretical framework to
identify and resolve conflicts (3.4-3.6).
3.4 Phase 1: Mapping Security and
Privacy Requirements
Based on the motivation scenario presented in section
3.1, we find that there are security and privacy
requirements involved. Therefore, to determine
which requirements are in conflict, we model the
scenario using the organizational view of SecTro as
presented in Figure 2. Each bubble represents an actor
(i.e. Supervisor, Doctor, and Employee). We break
the scenario into several tasks to assign a related
requirement for it, and assign each task to a related
requirement, to find out which task has a potential
conflict. The Doctor needs to acquire patient medical
results from an Employee, while sending this sort of
information needs to be confidential and treated with
integrity. When the Doctor runs a patient examination
or updates patient medical records, this task must
remain Anonymous. On the other hand, the same data
needs to be validated by a Supervisor; hence, this task
requires some Accountability. Any updates on patient
medical records by the Doctor also needs to be
Accountable based on GDPR Principles. As a result,
each task has its own security and privacy
requirements, which helps in identifying the
conflicting requirements. For instance, anonymity as
a privacy requirement conflicts with accountability as
a security requirement. In Fig. 2, we model the
motivation example in SecTro to pinpoint these
3.5 Phase 2: Identify Conflicts between
Requirements and Conflict
To identify conflicts, we next divide each scenario
task to address the possible conflicts. Therefore, for
each case, we assign the involved requirements.
Based on the “Managing Patient Records” scenario
presented, we will address the security and privacy
requirements for each activity. For instance: The lab
must perform a medical examination, then send the
results to the doctor (security requirements:
confidentiality and integrity). Furthermore, medical
results will be sent to the doctor to update the patient’s
medical record; this action must be compatible with
the GDPR accountability principle. Furthermore,
while the doctor is updating the patient’s medical
Figure 2: Organization View of Managing Patient Records.
ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering
Figure 3: Privacy by Design View of Managing Patient Records.
record, this action should be anonymous. This
therefore could lead to conflicts between
requirements- accountability and anonymity. To
process the updated results, they should be verified by
a supervisor; therefore, this requirement involves
accountability as a security requirement. In addition,
updating the patients’ medical record involves
anonymity, to keep the patients’ record private,
according to Privacy-by-Design principles. On the
other hand, this update must be accountable to the
supervisor to keep the system secure and accurate; the
supervisor must be aware of every and final updates
being made and by whom. At this point conflicts is
likely to occur between anonymity as a privacy
requirement and accountability as a security
requirement. This task can require more than one
requirement involved which will have potential
conflicts arising between requirements, especially
based on privacy and security requirements. It is
therefore difficult to fulfil both requirements.
Accountability is the requirement that holds entities
responsible for their actions, while anonymity allows
entities to use resources or services without having to
reveal their identity. In Figure 3, we provide an
overview of the Privacy-by-Design view of
Managing Patient Records. In this view, we allocate
security and privacy requirements for each soft goal.
As discussed above, we have already identified a
conflict between accountability related to the
supervisor and anonymity related to the doctor. In this
phase, we only highlight the conflict issue.
3.6 Phase 3: Conflict Resolution
In this phase, for each type of conflicts, we model a
pattern to link two conflicting requirements, and a
suitable supporting tool.
To resolve a conflict via supported tools, we
identified a relevant tool that could satisfy both types
of privacy and security requirements. By applying
this scenario in SecTro, we must add the tool to the
Privacy Pattern Library. In this case, we identify two
supporting tools, but determine that the IDEMIX tool
is more appropriate (Camenisch & Lysyanskaya,
2001). Figure4 shows how we add the supporting tool
into the framework. Consequently, Figure.5 shows
the Privacy-by-Design view after adding the new
concepts to identify conflict between requirements
and imports a suitable mechanism to satisfy the
There is a need to fulfil the anonymity requirement
for the Update Patient Medical Record process,
making sure that nobody knows which doctor has
made the change on a record. This is fulfilled by the
mechanism, which IDEMIX fulfils our solution
requirement. In addition, the accountability constraint
is related to the validate aspect of the Add Medical
Exam process, i.e., a supervisor needs to validate the
change. However, for this, the supervisor needs to
ConfIs: A Tool for Privacy and Security Analysis and Conflict Resolution for Supporting GDPR Compliance through Privacy-by-Design
know which doctor made the change; thus, there is a
conflict between accountability and anonymity,
because the supervisor cannot know, due to the
anonymity requirement, who the doctor is, so
accountability cannot be fulfilled. We solve this by
introducing the IDEMIX mechanism, which will be
used by the supervisor, so that accountability can be
IDEMIX is a solution for minimizing the release of
personal information and can be based on one of
many proposed techniques for anonymizing the
transport medium used between users and service
providers. IDEMIX is an optimizing cryptographic
compiler that achieves an unprecedented level of
assurance, without sacrificing the practicality for a
comprehensive class of cryptographic protocols. This
protocol satisfies the conditions for anonymous,
authenticated, and accountable transactions between
users and service providers. On the lab side, the
employee should fulfil confidentiality and integrity
while sending medical results; we fulfil this with the
cryptographic mechanism. In addition, the last point
is related to fulfilling GDPR principles, and an
example is accountability, where it is necessary to
record which doctor did the change. We fulfil this by
the Record Data Action mechanism.
Figure 4: Conflict Resolution.
Figure 5: Integrating conflict resolution in Privacy-by-Design view of Managing Patient Records.
ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering
In this section, we describe the preliminary evaluation
we carried out within the DEFeND project, for the
tool and method described in this paper. Here we
report the evaluation strategy and results. The
framework is Human Oriented, which supports the
investigation to conduct this kind of analysis based on
the importance of usable systems and promotes the
process of human centered design as a way to achieve
them (Maguire, 2001). Human Oriented is useful to
design the evaluation in a human centered way, to
obtain feedback from experts of security and privacy
engineering. We have fifteen participants, who are
researchers of privacy and security engineering. They
work within different universities from various
countries including the United Kingdom, Italy,
Greece, Germany, Saudi Arabia, and China; this
gives scope for a variety of perspectives (achieving
Evaluation Strategy. To have a comprehensive
evaluation, we use qualitative and quantitative
analyses. For the qualitative aspect, we design a focus
group session, having participants who are both
experts and researchers. Before we began the
evaluation, we constructed a pilot focus group
evaluation with three participant groups, namely-
PhD student, Doctor and Research Fellow. This
revealed to us the possibilities of improving the focus
group evaluation according to the participants’
feedback. Moving forward, we could perform the
full-scale focus group evaluation. The rational of the
problem, is to allow the participants to interact with a
task in order to find out how the researcher can
identify conflicts between requirements. Therefore,
we describe the ConfIS framework with an example
provided (as discussed in this paper) and provide the
participants a useful handout containing a description
of the focus group sessions, and what the input and
outputs for each phase of the framework are. In
addition, each part has full content. After the
participants have grasped the full idea and learned
how to use the framework, we asked them to apply
ConfIS to the same task that we started the
presentation with it. This comparison method gave us
some insight into using the framework and without
using it. By the end of the session, participants are
required to complete a survey, evaluating the
framework in general- phase by phase.
This evaluation strategy covered the qualitative
evaluation. By having the focus group and during
discussions in this session, we observe how the
participants understand the framework. Additionally,
answering the survey thereafter gave a quantitative
evaluation of the framework.
Evaluation Results. The survey consisted of fifteen
participants, of which 100% are respondents.
Encouraging responses of its design, revealed it
showed huge efforts, with a well and confident
presentation, interesting field and helpful work,
utilizing real cases within EU projects. Its clarity in
understanding the research objective, deemed a
supportive method which could be used in an iterative
way, and for each phase there is good support for the
analyst. Additionally, it brought revelations of much
more alternatives that could arise for the designer.
The tables are a valuable form of presentation, but
models could be a better way to visualize potential
analysis of elements and solutions, speeding up the
process. The evaluation was in general a positive
experience, and the evaluator clearly presented the
framework and its main objectives. Furthermore,
suggested areas for improvement included,
considering additional features/phases such as
prioritization and the conflicts involved with this. The
material and tools used to resolve conflicts could be
more informative especially for those without much
knowledge of the field, which could mean including
more examples. Furthermore, specifying the basis of
any choice of solution; when the participant identifies
conflicts, and then chooses a possible solution,
specifying how to choose one if there is more than
one option is not supported. Moreover, creating a
more structured evaluation that guides the subjects in
their evaluation should be noted. Participants were a
bit unsure of the utility (or the ordering) of the conflict
identification phase. The identification of the
enforcement technologies that "resolve" the identified
conflicts, eliminated the conflict and some
participants did not see the reason identifying them,
if there were no more conflicts to search.
The majority’s share, well over 70% of research
fellows agree with the general framework. They
approve that the relevant phases are clear, well defined,
sequentially in order, can have a fast development
process, is easier for identifying conflict, reducing it
and its relevant costs, and maintaining the value of
each requirement. The same can be said for doctors,
with the exception of 50% indicating a neutral response
to the framework phases having a fast development
process, being easier for detecting/identifying and
reducing conflict, and for maintaining the value of each
requirement. Additionally, more than 80% of PhD
students agree with the design of the general
framework, and its phases Figure 6.
ConfIs: A Tool for Privacy and Security Analysis and Conflict Resolution for Supporting GDPR Compliance through Privacy-by-Design
Figure 6: General Framework Per Respondent Group.
A summary analysis of the evaluation survey
reveals most respondents were research fellows
(40%), followed by PhD students (33%) and doctors
(27%). They all found the research design questions
to be appropriate, useful, well presented (87%) and
the research field quite interesting (93%) in gaining
their feedback. On the other hand, just 54% agreed
that the results were clearly presented; this leaves
room for improvement Additionally, the general
framework was also well received by the majority,
proving to be sequentially in order (87%), clear and
well defined (80%), easier for analysis (80%) and for
making feasible decisions such as reducing cost,
conflict, and faster development processing (73%)
(Figure 7). Among the three phases, to Phase 1 (74-
80%) agreed that Mapping between security and
privacy to identify conflict was clear. Phase 2 was
well received with the majority (80-86%) agreeing
that the researcher adequately addressed conflicts
between requirements and decisions.
Additionally, feedback on Phase 3 showed
varying responses (67-87%), yet the participants still
agreeing that there was an ease to understanding
conflict resolutions patterns and its supporting tools.
(Table 1).
ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering
Table 1: Phases.
Phase 1: Mapping Security and Privacy
Phase 2: Identify Conflicts between
Requirements and Conflict Decisions
Phase 3: Conflict Resolution Patterns
Figure 7: General Framework.
Studies have been conducted regarding conflicts in
requirement engineering approaches. Aldekhail et al
(2016) provide a comparative review on the conflict
analysis approach, which was conducted with 20
studies from 2001 to 2014. Moreover, approaches in
the literature are focused only on considering the
following important aspects separately:
identification, analysis, and resolution of conflicts. In
fact, most of them focus only on identifying conflicts
between requirements, especially NFR (non-
functional requirements), without considering an
overall, systematic approach for identifying,
analysing and, above all, resolving them. This paper
aims exactly to fulfil such gap, by supporting the
analyst in all three phases, in a tool-supported, semi-
automatic, interactive way, with the systematic
approach we propose.
A recent study conducted by Ramadan et al., (2018
and 2020) examine- detecting conflicts between data-
minimization and security requirements. They
investigate how conflicts between security and
privacy requirements gather into the systems, in
business process models.
Salnitri et al. (2020) in their work, propose a novel
method named SePTA (Security, Privacy and Trust
Approach). This method supports a unified
specification of security, privacy and trust
requirements, under one framework. It, more so,
enables software designers and security experts to
enforce such requirements, and is designed for
sociotechnical systems. They focus on how security,
privacy and trust requirements can be specified in the
early requirement phase, using a goal-based
modelling language, and how such requirements can
be correctly enforced in the late requirement phase,
using goal-based modelling languages and a
modelling language for business processes. Horkoff
et al., (2019) examined the top-cited 246 papers over
the past 20 years, as per Scopus. They make several
observations about the Goal-oriented requirements
engineering (GORE) field, where goals are used as a
useful conceptualization to elicit, model, and analyse
requirements, capturing alternatives and conflicts.
Despite extensive efforts in this field, the
requirements engineering (RE) community lacked a
recent, general systematic literature review of the
An expressive goal-based modelling language for
requirements that supports the representation of nice-
to-have requirements, preferences, optimization
requirements, constraints and more, have been
proposed by Nguyen et al. (2018). They exploited
automated reasoning solvers in order to develop a tool
that supports sound and complete reasoning, with
respect to goal models, and scales well to goal models
with thousands of elements. Their proposal advances
the state-of-the-art on goal modelling and reasoning.
Additionally, for future work they propose an
empirical validation of the CGM-Tool with modelers
and domain experts, currently working in this
direction with PhD students and post-docs. While
their work is in the preliminary stages, our framework
has already been applied to a real case study named
DEFeND, which has been validated, and is now in the
evaluation process.
Bhavsar et al., (2019) presented a survey paper
comparing recent studies of conflict between
requirements in the early stage of development. In
their survey, they summarize case studies related to
different domains of software engineering, with
respect to requirement gathering techniques, and how
conflicts could be resolved, that arise at the RE phase,
using the Agile software development method. This
model includes a continuous iteration of development
and testing phases, so that it could deliver the product
in the early stage, which makes Agile software
development used widely by companies. While this is
so, it also increases the complexity of the system. The
authors have also cited the work of Alkubaisy et al.,
(2019) who investigates conflicts between security
and privacy requirements.
ConfIs: A Tool for Privacy and Security Analysis and Conflict Resolution for Supporting GDPR Compliance through Privacy-by-Design
Maxwell et al., (2011) also conducts a cross-
reference approach for identifying conflicting
software requirements. Their work revealed that rules
and laws are easier to handle, and the reputation of
the company depends on the rules and regulation
which are followed. On the other hand, this can lead
to an increase in costs, because system laws have
Furthermore, Schon et al., (2017) investigates
agile software development, and discovers that rapid
changing in requirements can be easy to handle,
whilst on the other hand, there are more complexities
because a hybrid development model is used.
In this paper, we outline the need to identify conflicts
between requirements and to have a suitable tool to
resolve such conflicts. The ConfIS framework has
been presented for identifying conflicts between
security and privacy requirements. ConfIS allows the
analyst to deal with the potential conflicts that may be
discovered later and has been applied to a case study
from the DEFeND project. Lastly, we demonstrate
the phases of ConfIS step-by-step, to investigate how
it helps the analyst to identify and resolve conflicts
via a supporting tool.
The DEFeND project received funding from the
European Union’s Horizon 2020 research and
innovation programme under grant agreement No.
Albrecht, J. P. (2016). How the GDPR will change the
world. Eur. Data Prot. L. Rev., 2, 287.
Aldekhail, M., Chikh, A., & Ziani, D. (2016). Software
requirements conflict identification: review and
recommendations. Int J Adv Comput Sci Appl
(IJACSA), 7(10), 326.
Alkubaisy, D. (2017, May). A framework managing
conflicts between security and privacy requirements. In
2017 11th international conference on research
challenges in information science (RCIS) (pp. 427-
432). IEEE.
Alkubaisy, D., Cox, K., & Mouratidis, H. (2019, May).
Towards Detecting and Mitigating Conflicts for
Privacy and Security Requirements. In 2019 13th
International Conference on Research Challenges in
Information Science (RCIS) (pp. 1-6). IEEE.
Bhavsar, R., Thakkar, A., Sanghavi, P., & Tanwar, S.
(2019). Resolving conflicts in requirement engineering
through agile software development: A comparative
case study. In International Conference on Innovative
Computing and Communications (pp. 349-357).
Springer, Singapore.
Botha, J., Grobler, M., & Eloff, M. (2017, June). Global
Data Breaches Responsible for the Disclosure of
Personal Information: 2015 & 2016. In European
Conference on Cyber Warfare and Security (pp. 63-72).
Academic Conferences International Limited.
Camenisch, J., & Lysyanskaya, A. (2001, May). An
efficient system for non-transferable anonymous
credentials with optional anonymity revocation. In
International conference on the theory and applications
of cryptographic techniques (pp. 93-118). Springer,
Berlin, Heidelberg.
Egyed, A., & Boehm, B. (1998, July). 4.5. 3 A Comparison
Study in Software Requirements Negotiation. In
INCOSE International Symposium (Vol. 8, No. 1, pp.
Farrell, S. "Nearly 157,000 had data breached in TalkTalk
cyber-attack." (2015). Available at: https://www.the
had-data-breached-in-talktalk-cyber-attack [Accessed:
15 May 2017].
Horkoff, J., Aydemir, F. B., Cardoso, E., Li, T., Maté, A.,
Paja, E., & Giorgini, P. (2019). Goal-oriented
requirements engineering: an extended systematic
mapping study. Requirements Engineering, 24(2), 133-
Kim, M., Park, S., Sugumaran, V., & Yang, H. (2007).
Managing requirements conflicts in software product
lines: A goal and scenario based approach. Data &
Knowledge Engineering, 61(3), 417-432.
Van Lamsweerde, A., Darimont, R., & Letier, E. (1998).
Managing conflicts in goal-driven requirements
engineering. IEEE transactions on Software
engineering, 24(11), 908-926.
Liu, L., Yu, E., & Mylopoulos, J. (2003, September).
Security and privacy requirements analysis within a
social setting. In Proceedings. 11th IEEE International
Requirements Engineering Conference, 2003. (pp. 151-
161). IEEE.
Maguire, M. (2001). Methods to support human-centred
design. International journal of human-computer
studies, 55(4), 587-634.
Mairiza, D., Zowghi, D., & Nurmuliani, N. (2010).
Towards a Catalogue of Conflicts Among Non-
functional Requirements. ENASE, 2010, 20-29.
Mairiza, Dewi, et al. (2013). "Conflict characterization and
analysis of non-functional requirements: An
experimental approach." Intelligent Software
Methodologies, Tools and Techniques (SoMeT), 2013
IEEE 12th International Conference on. IEEE.
Maxwell, J. C., Antón, A. I., & Swire, P. (2011, August). A
legal cross-references taxonomy for identifying
conflicting software requirements. In 2011 IEEE 19th
ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering
international requirements engineering conference (pp.
197-206). IEEE.
Mouratidis, H. (2011). Secure software systems
engineering: the secure tropos approach. JSW, 6(3),
Mouratidis, H., & Giorgini, P. (2007). Secure tropos: a
security-oriented extension of the tropos methodology.
International Journal of Software Engineering and
Knowledge Engineering, 17(02), 285-309.
Nguyen, C. M., Sebastiani, R., Giorgini, P., & Mylopoulos,
J. (2018). Multi-objective reasoning with constrained
goal models. Requirements Engineering, 23(2), 189-
Pavlidis, M., & Islam, S. (2011, June). SecTro: A CASE
Tool for Modelling Security in Requirements
Engineering using Secure Tropos. In CAiSE Forum
(pp. 89-96).
Piras, L., Al-Obeidallah, M. G., Praitano, A., Tsohou, A.,
Mouratidis, H., Crespo, B. G. N., ... & Zorzino, G. G.
(2019, August). DEFeND architecture: a privacy by
design platform for GDPR compliance. In International
Conference on Trust and Privacy in Digital Business
(pp. 78-93). Springer, Cham.
Piras, L., Al-Obeidallah, M. G., Pavlidis, M., Mouratidis,
H., Tsohou, A., Magkos, E., ... & Crespo, B. G. N.
(2020, September). DEFeND DSM: a data scope
management service for model-based privacy by design
GDPR compliance. In International Conference on
Trust and Privacy in Digital Business (pp. 186-201).
Springer, Cham.
Ramadan, Q., Strüber, D., Salnitri, M., Riediger, V., &
Jürjens, J. (2018, June). Detecting conflicts between
data-minimization and security requirements in
business process models. In European Conference on
Modelling Foundations and Applications (pp. 179-
198). Springer, Cham.
Ramadan, Q., Strüber, D., Salnitri, M., Jürjens, J., Riediger,
V., & Staab, S. (2020). A semi-automated BPMN-
based framework for detecting conflicts between
security, data-minimization, and fairness requirements.
Software and Systems Modeling, 1-37.
Salnitri, M., Angelopoulos, K., Pavlidis, M.,
Diamantopoulou, V., Mouratidis, H., & Giorgini, P.
(2020). Modelling the interplay of security, privacy and
trust in sociotechnical systems: A computer-aided
design approach. Software and Systems Modeling,
19(2), 467-491.
Schär, B., Jüngling, S., & Thönssen, B. (2015, October).
Towards an Agile Requirements Engineering Process
Combining HERMES 5 and SCRUM. In 2015
International Conference on Enterprise Systems (ES)
(pp. 98-109). IEEE.
Schön, E. M., Thomaschewski, J., & Escalona, M. J.
(2017). Agile Requirements Engineering: A systematic
literature review. Computer Standards & Interfaces, 49,
ConfIs: A Tool for Privacy and Security Analysis and Conflict Resolution for Supporting GDPR Compliance through Privacy-by-Design
