Experiments with Auto-generated Socratic Dialogue for Source Code

Understanding

Zeyad Alshaikh, Lasang Tamang and Vasile Rus

University of Memphis, Memphis, U.S.A.

Keywords:

Intelligent Tutoring System, Computer Science Education, Socratic Method of Teaching, Dialogue

Generation, Programming Comprehension.

Abstract:

Intelligent Tutoring Systems have been proven to generate excellent learning outcomes in many domains such

as physics, mathematics and computer programming. However, they have seen relatively little use in training

and school classrooms due to the time and cost of designing and authoring. We developed an authoring tool

for dialogue-based intelligent tutoring system for programming called Auto-author to reduce the time and

cost. The tool allows teachers to create fully functional Socratic tutoring dialogue for learning programming

from Java code. First, we conducted a controlled experiment on 45 introductory to programming students to

assess auto-authored tutoring dialogues’ learning outcomes. The result shows that the auto-authored dialogues

improved students’ programming knowledge by 43% in terms of learning gain. Secondly, we conducted

a survey of auto-authored tutoring dialogues by introductory to programming course instructors to evaluate

the dialogues’ quality. The result shows that the instructors rated the questions as agree or strongly agree.

However, the instructors suggested that more improvement is required to help students develop a robust under-

standing of programming concepts.

1 INTRODUCTION

Tutoring is one of the most effective forms of in-

struction. Students in human tutoring conditions

show mean learning gains of 0.4–0.9 (non-expert) to

0.8–2.3 standard deviations (expert tutors) compared

to students in traditional classroom instruction and

other suitable controls (Bloom, 1984; Cohen et al.,

1982; Graesser et al., 2009; Person et al., 2007; Van-

Lehn et al., 2007). Therefore, Intelligent Tutoring

Systems (ITS) that mimic human tutors have been

built, hoping that a computer tutor could be pro-

vided to every student with access to a computer.

As a result, the ITSs have been shown to be effec-

tive for one-to-one tutoring in many domains such as

mathematics, physics and programming (Pillay, 2003;

Freedman et al., 2000; Corbett et al., 1999; Alshaikh

et al., 2020) and can generate impressive learning out-

comes.

Despite many successful ITSs examples, they

have seen relatively little use in training and school

classrooms. In examining the barriers to ITS’s

widespread use, the time and cost for designing and

authoring ITS have been widely cited as the primary

obstacles (Sottilare and Holden, 2013). The costs are

high because authoring content and other needed el-

ements for ITSs is tedious, error-prone (Heffernan

et al., 2006), and time-consuming (Blessing, 1997).

Furthermore, the authoring process usually involves

domain experts, pedagogical experts, cognitive scien-

tists, linguistic experts in the case of dialogue-based

ITSs, and software development expertise (Blessing,

1997). It is estimated that creating one hour of ITS

instruction can take up to 200 hours (Woolf & Cun-

ningham, 1987; Murray, 1999)

To overcome the challenge of authoring high-

quality tutors is to automate the entire authoring

process or as many parts of the process as possi-

ble (Aroyo et al., 2004). Therefore, authoring tools

can reduce time, effort, cost and enable reuse and

customization of content and lower the skill barrier

(Ainsworth et al., 2003; Halff et al., 2003). Conse-

quently, authoring systems were developed in many

domains such as physics, mathematics, and public

policy to increase both the accessibility and the af-

fordability of ITSs (Heffernan et al., 2006). For in-

stance, a successful example of an ITS authoring sys-

tem was developed by Jordan and his colleagues (Jor-

dan et al., 2001) in which they were able to build

knowledge sources for their dialogue system in only

Alshaikh, Z., Tamang, L. and Rus, V.

Experiments with Auto-generated Socratic Dialogue for Source Code Understanding.

DOI: 10.5220/0010398100350044

In Proceedings of the 13th International Conference on Computer Supported Education (CSEDU 2021) - Volume 2, pages 35-44

ISBN: 978-989-758-502-9

3 man-months. The system uses a graphical inter-

face for teachers to construct tutoring dialogues for

physics. Another example of such a system was in-

troduced by Aleven and his colleagues (Aleven et al.,

2009) where they developed a graphical user interface

to speed up the development of instructional compo-

nents such as hints and just-in-time messages.

Intelligent tutoring systems with conversational

dialogue form is a special category of educational

technologies. These conversational ITSs are based on

explanation-based constructivist theories of learning

and the collaborative constructive activities that oc-

cur during human tutoring. They have been proven

to promote student learning gains up to an impressive

effect of 1.64 sigma when compared to students learn-

ing the same content in a canned text remediation con-

dition that focuses on the desired content (VanLehn

et al., 2007).

We focus on conversational ITSs that implement a

Socratic tutoring style that relies on prompting stu-

dents to think and provide information in the form

of answers. The questions are designed to follow

a directed, predeﬁned line of reasoning (Ros

e et al.,

2001). Based on static analysis and dynamic simula-

tions of code examples that learners are prompted to

understand, we propose an automated method to gen-

erate a Socratic line of reasoning and corresponding

questions necessary to implement a Socratic tutorial

dialogue for code comprehension.

For instance, for each target concept in the abstract

syntax tree (AST), we generate a question that the cor-

rect answer is the target information. For example,

the static analysis of the statement “int num = 10;”

results in the following benchmark answer declar-

ing an integer variable num and initializing it to 10

. When students are prompted to answer the ques-

tion, what does the statement at line 1 do?, the stu-

dent response is automatically compared to the corre-

sponding benchmark answer using semantic similar-

ity. If the two match, positive feedback is provided

to the students, e.g., Great job! Otherwise, the stu-

dents receive negative feedback followed by an asser-

tion indicating the correct answer. The students may

also receive neutral feedback depending on how se-

mantically close their answer is to the benchmark an-

swer. In sum, we adopt the following Socratic Tutor-

ing Framework for our automatically generated So-

cratic ITSs (see Figure 1).

The Socratic ITS Framework just presented can

be implemented adaptively. In other words, not all

students will receive all the prompts/questions. Some

students, e.g., students who show mastery of certain

concepts, e.g., conditions, will be asked fewer ques-

tions about it than students who have yet to master the

conditions. Thus, this adaptive Socratic ITS uses in-

struction tailored to each learner should result in bet-

ter learning outcomes for all learners.

It should be noted that the above framework cov-

ers the inner loop or within-task interaction of an ITS.

We assume an instructional task has been selected for

the learner to work on, e.g., a particular Java code ex-

ample has been chosen for the learner to read to com-

prehend. Therefore, our task is to automate the inter-

action with the learner within such a task. The outer

loop responsible for selecting an appropriate instruc-

tional task for a given learner is not described here

(see VanLehn’s two-loop ITS framework (Vanlehn,

2006)). How to automatically select the appropriate

next instructional tasks in adaptive ITSs is a topic we

plan to explore in the future.

It is important to add that our Socratic line of

reasoning for a target code example only targets the

program level or program model aspects of compre-

hension. Indeed, comprehension theories distinguish

between the program model, the domain model, and

the situation model (Pennington, 1987; Schulte et al.,

2010).

This paper investigates and proposes an approach

to generate Socratic dialogue for programming com-

prehension automatically. This work’s research hy-

pothesis is that auto-generated dialogues will help in-

troductory to programming students learn program-

ming and produce learning gain. The proposed ap-

proach was implemented and evaluated throughout a

controlled experiment and survey.

2 SYSTEM DESCRIPTION

Socratic Author was designed and developed as a

stand-alone tool that can be used by ITS developers.

The authoring tool requires only source code exam-

ples as input to produce a full dialogue framework

that can simply be played. The current implemen-

tation was developed for the Java language to help

students understand Java code examples. The tool

was developed in Python and the output dialogue is

a JSON object (JavaScript Object Notation, or JSON,

is a lightweight data-interchange format that is easy

for machines to parse and generate). When porting

to a new target language, e.g., Python, the only com-

ponents that need to be changed are the static code

analyzer and the underlying dynamic simulator of the

code, which are typically available as off-the-shelf

components.

The architecture of the authoring tool consists of

ﬁve major components: question generation, bench-

mark answer generation, feedback generation, run

CSEDU 2021 - 13th International Conference on Computer Supported Education

WHILE t h e r e a r e i t e m s t o ask a b o u t i n t h e AST {

Prom pt t h e s t u d e n t t o a n swer a q u e s t i o n f o r a t a r g e t i n f o r m a t i o n

i n t h e AST o r fro m t h e dynamic c ode s i m u l a t i o n

A u t o m a t i c a l l y a s s e s s t h e c o r r e c t n e s s o f t h e s t u d e n t an s w e r .

P r o v i d e s h o r t f e e d b a c k f o l l o w e d by t h e a s s e r t i o n o f t h e c o r r e c t

an swer , i f ne e d ed

}

Figure 1: The Socratic ITS Framework.

Figure 2: Architecture of Socratic Author.

time information, and dialogue generation (see Fig-

ure 2). The dialogue generation module takes as in-

put the output of the other four components or mod-

ules (question generation, answer generation, feed-

back generation, run time information) to generate a

complete segment of dialogue. As already noted, the

generated dialogue can be adaptively played by con-

versational ITSs. That is, all learners need not be

asked all questions; questions can be chosen adap-

tively depending on learners’ knowledge and other

characteristics, such as their emotional state.

2.1 The Question Generation Module

The question generation module uses a Java parser

to identify programming concepts and sub-concepts

in an abstract syntax tree as well as program run

time information from the dynamic program simula-

tion model to generate two types of questions. The

ﬁrst question type is based on the dynamic behavior

of the code, e.g., how many times a loop is executed

and what are the values of the counter i during the

execution of the loop. The second type of questions

are generated based on the static code analysis of the

code, such as What is the name of the integer variable

declared in line 1? These questions were generated

from the code shown in Figure 3.

Based on the static analysis of the code, this sys-

tem generated three types of questions. Deﬁnition

questions check students’ knowledge of basic pro-

gramming concepts (e.g., What is a variable? or What

is an assignment statement about?). Second are ques-

tions targeting syntactic knowledge of the target pro-

gramming language (e.g., Can you indicate the con-

dition of the for loop in line 2?). Third are complex

questions or sequences of related questions targeting

all aspects of statements. For instance, for a line of

code declaring an integer variable and initializing it

to 0, a generic question is generated (e.g., What does

the statement in line 1 do?) and a sequence of two re-

lated questions (e.g., What is the main purpose of the

statement in line 1? and What value, if any, are the

variables in the declaration statement in line 1 initial-

ized to?). That is, the sequence of questions targets

the declaration and initialization aspects of a declara-

tion statement. For more complex statements, e.g., for

loops, a sequence of questions promoting deep under-

standing of this more complex statement is generated.

Each question in the sequence targets an important as-

pect of the loop concept, such as the loop variable

i, the initialization of the loop variable, the terminal

condition, and the increment of the loop variable. For

instance, the following questions are generated for the

for loop, as shown in Figure 3: (1) What is the initial-

ization statement of the for loop? (2) What is the stop

condition of the loop? (3) What is the inc/decrement

statement?

Finally, the question generation module generates

questions for a block of statements as well. For a

block, i.e., a group of statements between balanced

braces, questions are generated to ask the learner

to summarize the goal of the block, e.g., functions,

loops, and if-else. For instance, a block question gen-

erated for the code in Figure 3 is What does the code

on the block from line 24 do?

Figure 3: Java for loop.

There is one challenge with these block-level ques-

tions. Generating a higher level benchmark response

summarizing the function of the block in order to au-

tomatically assess student responses was beyond the

scope of the current method, which focused on the

program model as opposed to the domain model. Fur-

thermore, automatically generating functional bench-

mark responses for a given block of code is a chal-

Experiments with Auto-generated Socratic Dialogue for Source Code Understanding

lenging task the researcher plans to tackle in the fu-

ture. For this reason, the current solution to gener-

ate the benchmark responses for a given block is to

concatenate the benchmark responses of the individ-

ual statements in the block, as detailed later.

Figure 4: Auto-generated questions from Figure 2 program.

2.2 The Benchmark Answer Generation

Module

To generate a meaningful answer, the answer genera-

tion model starts with the abstract syntax tree of the

input Java program obtained from Java parser. The

model generates block- and statement-level answers

by traversing the syntax tree. A complete pass of

the tree statement nodes generates a complete sen-

tence, where each type of node is associated with

a predeﬁned template. That is, this study followed

a template-based text generation approach, which is

Figure 5: Abstract syntax tree for static ﬁnal int x = 10.

widely used in natural language generation (Jurafsky

and Martin, 2008). For instance, a complete pass over

the tree of the statement ﬁnal static int = 10 produces

the following benchmark answer Declare a ﬁnal static

integer x and initialize it to 10. For block-level an-

swers, the answer generation module ﬁrst identiﬁes

the block by matching the node type with a prede-

ﬁned list of types, e.g., function, loop, and if-else,

then analyzes the sub-tree to generate an answer for

each statement in the block. Next, the module com-

bines the answers for each individual statement in the

block into a single paragraph. For example, the block-

level answer for the for loop presented in Figure 3 is

“The for loop in line 2 iterates over the counter i from

0 to 9, increasing the counter by 1 in each iteration.

In each iteration, the value of sum is incremented to

its current value plus the value of i.”

2.3 The Code Simulation Module

Generating answers from abstract syntax trees is not

enough because the trees do not represent any run-

time information. This is critical for code examples

that require user input, in which case the behavior

of the code will change depending on the user input.

Therefore, a Java Debugger Interface (JDI) was used

to simulate the execution of Java programs and record

variable values. This information answers questions

such as what the value of the variable sum is in line

3 when i is 4 or what the values of the counter i are

during the execution of the for loop. Therefore, the

simulation module offers the ability to trace the exe-

cution of Java code and generate questions based on

the results of this dynamic execution of the code.

2.4 The Scaffolding Module

The scaffolding module uses the information from the

answer generation module and a set of short prede-

ﬁned phrases expressing positive (Good job), neutral

(Good try), or negative (Not quite so) feedback to gen-

erate a more complete feedback utterance, which con-

sists of short feedback (e.g., Good job) followed by

an assertion of the correct answer or a more informa-

tive follow-up hint. The system can generate three

levels of Socratic hints, as shown in Figure 6. At the

ﬁrst level, the tutor may ask deﬁnition questions about

the targeted programming concept, e.g., “What is the

int keyword used for in line 1?” For level 2 ques-

tions, the tutor may ask a concept completion ques-

tion in the form of a ﬁll-in-the-blank question, e.g.,

“The int keyword is used to a that can

hold a 32-bit signed .” The expected keywords

are declare, variable, and integer. Finally, at Level

CSEDU 2021 - 13th International Conference on Computer Supported Education

3, the tutor asks a veriﬁcation question in the form

of a yes/no question, e.g., “The int keyword is used

to declare a variable that can hold a 32-bit signed in-

teger? Please answer the following question by typ-

ing yes or no.” Using yes/no questions allows the sys-

tem to verify common misconceptions students may

have and correct them. However, at this moment, no

misconception information has been incorporated into

the method to account for and correct misconceptions,

but this feature will be added in the future.

Figure 6: Tutoring session.

2.5 The Dialogue Module

Once the questions, answers, feedback, and run-time

simulations are produced, the dialogue module gen-

erates a complete segment dialogue in the form of

a sequence of questions and corresponding expected

benchmark answers, which are used to automatically

assess whether student responses are correct using a

semantic similarity approach (Khayi and Rus, 2019).

Technically speaking, the dialogue is speciﬁed as an

JSON object.

2.6 Enacting the Dialogue Model

The dialogue generated for a given code example

needs to be played by a dialogue manager as part of a

dialogue-based ITS. The role of the dialogue manager

is to present the learner with questions in a particular

order. Typically, the dialogue manager presents the

questions in a sequence corresponding to the lines of

code the questions are about. For blocks, the Socratic

dialogue starts with questions about each statement

within the code block. When all the statements in a

block are covered, the ITS asks the students to sum-

marize the block. Other orders of presenting the ques-

tions can be envisioned, such as the execution order of

the lines of code for a given input.

Besides the questions generated from the abstract

syntax trees and the dynamic execution of the code,

there are two general types of questions or statements:

a question or statement to elicit self-explanation (Can

you read the code and explain in your own words what

the code does and what it means to you while you

read the code?) and a prediction question or state-

ment (Please read the code and predict its output).

Each generated question is labeled internally ac-

cording to its type and a list of concepts in order

to track students’ mastery of key programming con-

cepts. Therefore, this labeling mechanism gives the

dialogue manager freedom to choose what questions

to present. Various ITS developers may choose dif-

ferent question sequencing strategies. For instance,

the following is a potential sequencing: the dialogue

manager starts by asking the students to explain the

code in detail and predict its output. The Socratic line

of questioning is only triggered if the student’s expla-

nation and prediction are incorrect or incomplete. For

instance, for incomplete explanations, the sequencing

strategy may be implemented to ask questions only

about the parts of the code that were not explained in

sufﬁcient detail.

2.7 User Interface

The user interface is simple, easy to use, and consists

of a text area to write or paste Java code and three

buttons (see Figure 7). The interface offers authors

two options: (1) generate a Socratic dialogue and save

it as a JSON script or (2) start a tutoring session for

testing purposes. Furthermore, the interface provides

the ability to choose what concepts the author prefers

to generate a dialogue for. For example, if an author

wants to encourage students to practice for loops, they

can select the for loop concept only.

The authoring tool also offers an interface for ITSs

by using REST API technology. This allows ITSs

to easily integrate the tool by requesting a dialogue

script for a given Java code and getting as a response

the corresponding Socratic dialogue as a JSON ob-

ject.

3 EVALUATION

3.1 Method

We carried out two evaluations to assess the qual-

ity of auto-generated dialogue and its effect on pro-

gramming comprehension. The ﬁrst evaluation was

Experiments with Auto-generated Socratic Dialogue for Source Code Understanding

Table 1: Mean and Stander Deviation of pre-test, post-test, and learning gain.

Pre-test Post-test Learning gain

Section n Mean SD Mean SD Mean SD

Group-1 14 58 21 86 13 51% 21

Group-2 15 56 16 70 11 43% 19

Group-3 15 57 35 61.3 33 12% 9.1

Table 2: Mean and Stander Deviation of turns, words, sentences and content-words.

Section Turns Words Sentences Content-words

Mean SD Mean SD Mean SD Mean SD

Group-1 123 13 402 217 45 8 191 164

Group-2 115 28 334 183 35 18 154 106

Figure 7: Socratic Authoring Tool Interface.

to let a group of programming instructors evaluate the

auto-generated dialogues to explore if this approach

is educationally useful. The second evaluation was

conducted as a control experiment by letting intro-

ductory to programming course’s students use either

auto-authored, expert-authored Socratic dialogue or

output only. The goal of the second evaluation is to

analyze the learning outcomes to see how easy, efﬁ-

cient, and friendly the system is.

3.2 Participants

In the ﬁrst evaluation, participants (n=13) were in-

structors teaching Java programming courses. More-

over, the second study participants were undergrad-

uate students (n=45) who enrolled in the introduc-

tory to programming course at a major 4-year Asian

university. The participants were divided into three

groups of 15 students. The ﬁrst group (Group-1) was

assigned to a tutoring session where experts generated

the tutoring dialogues. The second group (Group-2)

was assigned to a condition in which they used auto-

generated tutoring dialogues. And ﬁnally, the last

group (Group-3) was assigned to a scaled-down ver-

sion of the system. The scaled-down version presents

Java code examples and asks about the output without

providing any feedback.

3.3 Materials

Materials for the ﬁrst evaluation study included ﬁfteen

auto-generated dialogues from Java code examples

covering the following concepts: variables, if and if-

else conditionals, for loop, while loop and array. The

dialogues were formatted in a human readable form

and then shown one by one to each rater. At the end

of each dialogue, a survey consists of 10 questions

using a 5-point Likert scale presented (see Table 4)

where 1 is strongly disagree and 5 is strongly agree.

Materials for the controlled experiment included

a pre- and post-test measuring participants’ knowl-

edge on a number of key computer programming con-

cepts and a survey that contains 7 questions to eval-

uate the authored dialogues. The pre- and post-test

have similar difﬁculty levels and contain 6 Java pro-

grams where each question assessed students’ under-

standing of a particular programming concept. For

each question in the pre- and post-test, the participants

were asked to predict the code example’s output.

3.4 Procedure

For the ﬁrst evaluation, we emailed the survey link

to introductory to programming courses instructors.

The instructors were given ﬁve days to complete the

survey.

On the other hand, the controlled experiment was

conducted in a computer lab under supervision. First,

participants were debriefed about the purpose of the

experiment and were given a consent form. Those

who consented started by taking a pre-test. Once

they have ﬁnished the pre-test, an approximately 60-

minute tutoring session started. Finally, participants

took the post-test and an evaluation survey. For

group-3, there was no survey at the end of the experi-

ment since they did not interact with the dialogue ITS.

CSEDU 2021 - 13th International Conference on Computer Supported Education

Table 3: Mean and Stander Deviation of scaffolding questions and success rate.

Section Feedback First Second Third

Mean SD Mean SD Mean SD Mean SD

Group-1 28 4 55% 16 70% 23 61% 37

Group-2 31 7.5 41% 21 47% 13 73% 24

Table 4: Mean and Stander Deviation of survey questions for evaluating tutoring dialogues by students.

Question Group-1 Group-2

Mean SD Mean SD

I think the questions were clear and easy to understand. 3.6 0.9 3.4 0.8

I think the system was able to understand my answers and response accordingly 4.6 1.2 4.3 0.9

I think the scaffolding questions from the system helped me produce the correct

answer.

4.4 0.5 4.2 0.4

I think the system was effective at helping me understand the code examples. 4.6 0.5 4.4 0.7

I think the system was effective at helping me understand core programming

concepts.

3.6 1.1 3.7 1.2

I think the system helped me to understand Java programming. 4 0.8 4.3 1.2

I think the system provides a useful learning experience. 4.5 0.5 3.4 1.3

3.5 Assessment

The pre and post-test questions were scored 1 when

the student answer was correct and 0 otherwise. The

learning gain score (LG) was calculated for each par-

ticipant as follows (Marx and Cummings, 2007).

Learning gain =











post-test−pre-test

100−pre-test

post-test > pre-test

post-test−pre-test

pre-test

post-test < pre-test

drop pretest = posttest = 100 or 0

0 post-test = pretest

(1)

4 RESULT

To understand each type of tutoring method’s over-

all effectiveness on students’ knowledge, we report

the knowledge change in terms of learning for each

group. Table 1 shows the average scores of the pre-

test for each group 1, 2, and 3 are 58%, 56% and 57%,

respectively, in which they are in the range of 2% dif-

ference. Thus, the pre-test scores indicate that par-

ticipants in both groups have, to some extent, similar

knowledge—however, the post-test scores improved

by 28% in group-1, 14% in group-2 and 4% in group-

1. Therefore, the difference between pre- and post-

test scores result in learning gain of 51%, 34% and

12% for group 1,2 and 3, respectively. Thus, the result

indicates that the auto-authoring dialogues improved

students’ knowledge by 34% and outperformed the

output only group by 22%.

Despite the difference in learning gain between

group-1 and 2, the result from a two-tailed t-test

showed that there is no statistically signiﬁcant differ-

ence (t=0.83, df=19, p>0.05). Furthermore, the re-

sults from the two-tailed t-test also showed that there

is a statistically signiﬁcant difference between group-

3 and other groups (t=3.1, df=52, p<0.05) in terms of

learning gain.

To evaluate dialogue efﬁciency, we analyzed the

students’ responses from dialogue logs in terms of

turns, word, sentence and content-word for each

group (see Table 2). For group-1, the results show

that, on average, each tutoring session consist of 123

turns and participants produced 402 words, 45 sen-

tences, and 191 content-words. On the other hand,

group-2 students produced 334 words, 35 sentences,

and 154 content-words within 115 turns. Therefore,

students assigned to expert-written dialogues interact

more with the tutor and produce more words, sen-

tences, and content-words. However, the result from

a two-tailed t-test showed that there is only a statisti-

cally signiﬁcant difference (t=6.13, df=19, p<0.05)

in terms of sentences.

We further analyzed the scaffolding questions to

understand the difference between expert- and auto-

generated help. Table 3 shows the average number

of help received by students and the success rate.

The question would be considered a success if the

student was able to provide the correct answer. Ta-

ble 3 shows that students in group-1 received more

questions and have a higher success rate in the ﬁrst

and second levels. Furthermore, the result shows that

the auto-generated third level has a 12% higher suc-

cess rate. However, the result from a two-tailed t-

test showed only a statistically signiﬁcant difference

in ﬁrst (t=3.6, df=25, p>0.05) and second (t=-4.1,

Experiments with Auto-generated Socratic Dialogue for Source Code Understanding

df=25, p<0.05) level.

To understand how efﬁcient and user-friendly the

system was to the students, we analyzed the result

from after session survey, as shown in Table 4. The

survey contains 7 questions using a 5-point Likert

scale where 5 is strongly agree and 1 is strongly dis-

agree. Students in group-1 gave a higher rate in all

questions except the answer to the question “the sys-

tem was effective at helping me understand core pro-

gramming concepts” and “the system helped me to

understand Java programming.” We further calculated

Fleiss’ kappa for inter-rater reliability, and the result

shows that (Fleiss’ Kappa = 0.52) for group-1 and

(Fleiss’ kappa = 0.43) for group-2. Therefore, the

Fleiss’ kappa score suggests that the agreement be-

tween subjects in group-1 is higher than the subjects

in group-2.

Table 5 shows the result in terms of average and

standard deviation for 10 questions using a 5-point

Likert scale where 5 is strongly agree and 1 is strongly

disagree. Questions 1 and 2 target the quality of the

auto-generated questions, feedback, and model an-

swers regarding their syntactic and semantic quality.

Moreover, the third question asks about the coherence

and consistency of the dialogue. The rest of the ques-

tions focus on educational goals and the raters’ overall

likelihood of using the system in their teaching in the

future.

The result shows an average score above 4 for

all questions except the ﬁfth question that asking

if the generated dialogue would help students de-

velop a robust understanding of programming con-

cepts. Furthermore, the instructors agreed that the

auto-generated dialogues would help students under-

stand Java programs better and learn programming

concepts (Fleiss’ Kappa = 0.51). We also allowed

the raters to provide voluntary feedback at the end of

the survey, and the voluntary feedback was positive.

For instance, one of the raters stated that “the system

looks promising and the dialogue looks coherent to

the point you feel it is not auto-generated.”

5 DISCUSSION

The controlled experiment results show that the auto-

generated Socratic dialogue for programming com-

prehension can improve students’ knowledge. The

average learning gain of group-2 students is 43%

comparing with 12% group-3 students. However,

group-1 students outperform both group-2 and group-

3 in which we expected; however, it was not statisti-

cally signiﬁcant.

Analyzing tutoring logs shows that group-1 stu-

dents produced more words, sentences and content-

words and were more interactive in terms of turns.

Furthermore, group-1 students received more scaf-

folding questions and have higher success rates in

providing the correct answer to the ﬁrst and second

levels. However, group-2 students achieved a higher

success rate on the third level; however, the difference

was not statistically signiﬁcant.

Post tutoring survey shows that on average group-

2 students rated the evaluation questions of auto-

authored dialogues as agree or strongly agree. How-

ever, the rating dropped to neither agree nor disagree

for questions 1, 5 and 7 (see Table 4). On the other

hand, group-1 students rated questions 1 and 5 as nei-

ther agree nor disagree. The overall result suggests

that students preferred to interact with expert-written

dialogues. On the other hand, the evaluation by pro-

gramming instructors shows that they chose to agree

or strongly agree to every question except question

5 (see Table 5) suggesting that more improvement is

required to help students developing a robust under-

standing of programming concepts.

To conclude, expert-written tutoring dialogues

outperformed auto-generated dialogues in many as-

pects. However, auto-generated dialogue can be cre-

ated from java code examples in less than a minute

and requires no technical or educational knowledge.

We believe that considering the cost, skills and time

required to generate expertly written dialogues, the

tool offers a great opportunity to students and teach-

ers.

6 CONCLUSION

Intelligent Tutoring Systems can generate impressive

learning outcomes in many domains such as physics,

mathematics and computer programming. However,

they have seen relatively little use in training and

school classrooms due to the time and cost of de-

signing and authoring ITS. We developed an author-

ing tool for programming dialogue intelligent tutoring

system called Auto-author to reduce the time and cost.

The tool allows instructors to create fully functional

Socratic tutoring dialogue for teaching programming

from Java code examples.

A controlled experiment on 45 introductory to

programming students was carried out to evaluate

auto-authored tutoring dialogues’ learning outcomes.

The result shows that the auto-authored dialogues im-

proved students’ programming knowledge by 43% in

terms of learning gain. Furthermore, we conducted

a survey of auto-authored tutoring dialogues by pro-

gramming instructors to evaluate the dialogues’ qual-

CSEDU 2021 - 13th International Conference on Computer Supported Education

Table 5: Mean and Stander Deviation of survey questions for evaluating auto-generated tutoring dialogues by instructors.

Question Mean SD

I think the generated questions, feedback, and answers are syntactically correct. 4.2 0.55

I think the generated questions, feedback, and answers are semantically correct. 4.5 0.84

I think the generated dialogue is coherent and consistent. 4.4 0.45

I think the generated dialogue (questions, feedback) would help students understand Java

code.

4.2 0.84

I think the generated dialogue (questions, feedback) would help students develop a robust

understanding of programming concepts.

3.8 0.55

I think the generated scaffolding questions would help students learn and understand the

corresponding Java code.

4.6 0.55

I think the generated dialogue covers all important programming concepts presented in

the code.

4.8 0.45

I think I may use this system in the classroom. 4.2 0.84

I think the system is effective at helping students understand Java code. 4.2 0.45

I think the system is effective at helping students understand programming concepts. 4.2 0.84

ity. The result shows that the teachers believe the di-

alogues as good. However, the instructors believed

that more improvement is required to help students

developing a robust understanding of programming

concepts.

ACKNOWLEDGEMENTS

This work as partially funded by the National Science

Foundation under the award #1822816 (Collaborative

Research: CSEdPad: Investigating and Scaffolding

Students’ Mental Models during Computer Program-

ming Tasks to Improve Learning, Engagement, and

Retention) to Dr. Vasile Rus. All opinions stated or

implied are solely the authors’ and do not reﬂect the

opinions of the funding agency.

REFERENCES

Ainsworth, S., Major, N., Grimshaw, S., Hayes, M., Un-

derwood, J., Williams, B., and Wood, D. (2003). Re-

deem: Simple intelligent tutoring systems from usable

tools. In Authoring Tools for Advanced Technology

Learning Environments, pages 205–232. Springer.

Aleven, V., Mclaren, B. M., Sewall, J., and Koedinger, K. R.

(2009). A new paradigm for intelligent tutoring sys-

tems: Example-tracing tutors. International Journal

of Artiﬁcial Intelligence in Education, 19(2):105–154.

Alshaikh, Z., Tamang, L. J., and Rus, V. (2020). Exper-

iments with a socratic intelligent tutoring system for

source code understanding. In The Thirty-Third Inter-

national Florida Artiﬁcial Intelligence Research Soci-

ety Conference (FLAIRS-32).

Aroyo, L., Inaba, A., Soldatova, L., and Mizoguchi, R.

(2004). Ease: Evolutional authoring support environ-

ment. In International Conference on Intelligent Tu-

toring Systems, pages 140–149. Springer.

Blessing, S. B. (1997). A programming by demonstra-

tion authoring tool for model-tracing tutors. Interna-

tional Journal of Artiﬁcial Intelligence in Education

(IJAIED), 8:233–261.

Bloom, B. S. (1984). The 2 sigma problem: The search

for methods of group instruction as effective as one-

to-one tutoring. Educational researcher, 13(6):4–16.

Cohen, P. A., Kulik, J. A., and Kulik, C.-L. C. (1982).

Educational outcomes of tutoring: A meta-analysis

of ﬁndings. American educational research journal,

19(2):237–248.

Corbett, A., Anderson, J., Graesser, A., Koedinger, K., and

VanLehn, K. (1999). Third generation computer tu-

tors: learn from or ignore human tutors? In CHI’99

Extended Abstracts on Human Factors in Computing

Systems, pages 85–86, New York, NY, USA. Associa-

tion for Computing Machinery.

Freedman, R., Ros

e, C. P., Ringenberg, M. A., and Van-

Lehn, K. (2000). Its tools for natural language dia-

logue: A domain-independent parser and planner. In

International Conference on Intelligent Tutoring Sys-

tems, pages 433–442. Springer.

Graesser, A. C., D’Mello, S., and Person, N. (2009). 19

meta-knowledge in tutoring. Handbook of metacogni-

tion in education, page 361.

Halff, H. M., Hsieh, P. Y., Wenzel, B. M., Chudanov, T. J.,

Dirnberger, M. T., Gibson, E. G., and Redﬁeld, C. L.

(2003). Requiem for a development system: reﬂec-

tions on knowledge-based, generative instruction. In

Authoring tools for advanced technology learning en-

vironments, pages 33–59. Springer.

Heffernan, N. T., Turner, T. E., Lourenco, A. L., Macasek,

M. A., Nuzzo-Jones, G., and Koedinger, K. R. (2006).

The assistment builder: Towards an analysis of cost

effectiveness of its creation. In Flairs Conference,

pages 515–520.

Jordan, P., Ros

e, C. P., and VanLehn, K. (2001). Tools for

authoring tutorial dialogue knowledge. In Proceed-

ings of AI in Education 2001 Conference.

Experiments with Auto-generated Socratic Dialogue for Source Code Understanding

Jurafsky, D. and Martin, J. H. (2008). Speech and lan-

guage processing: An introduction to speech recog-

nition, computational linguistics and natural language

processing. Upper Saddle River, NJ: Prentice Hall.

Khayi, N. A. and Rus, V. (2019). Bi-gru capsule networks

for student answers assessment. In 2019 KDD Work-

shop on Deep Learning for Education (DL4Ed).

Marx, J. D. and Cummings, K. (2007). Normalized change.

American Journal of Physics, 75(1):87–91.

Pennington, N. (1987). Stimulus structures and mental

representations in expert comprehension of computer

programs. Cognitive psychology, 19(3):295–341.

Person, N., Lehman, B., and Ozbun, R. (2007). Pedagog-

ical and motivational dialogue moves used by expert

tutors. In 17th Annual Meeting of the Society for Text

and Discourse. Glasgow, Scotland.

Pillay, N. (2003). Developing intelligent programming tu-

tors for novice programmers. ACM SIGCSE Bulletin,

35(2):78–82.

Ros

e, C. P., Moore, J. D., VanLehn, K., and Allbritton, D.

(2001). A comparative evaluation of socratic versus

didactic tutoring. In Proceedings of the Annual Meet-

ing of the Cognitive Science Society, volume 23.

Schulte, C., Clear, T., Taherkhani, A., Busjahn, T., and Pa-

terson, J. H. (2010). An introduction to program com-

prehension for computer science educators. In Pro-

ceedings of the 2010 ITiCSE working group reports,

pages 65–86.

Sottilare, R. A. and Holden, H. K. (2013). Motivations for

a generalized intelligent framework for tutoring (gift)

for authoring, instruction and analysis. In AIED 2013

Workshops Proceedings, volume 7, page 1.

Vanlehn, K. (2006). The behavior of tutoring systems. In-

ternational journal of artiﬁcial intelligence in educa-

tion, 16(3):227–265.

VanLehn, K., Graesser, A. C., Jackson, G. T., Jordan, P.,

Olney, A., and Ros

e, C. P. (2007). When are tutorial

dialogues more effective than reading? Cognitive sci-

ence, 31(1):3–62.

CSEDU 2021 - 13th International Conference on Computer Supported Education
