Efﬁcient Secure Communication for Distributed Multi-Agent Systems

Davide Costa

, Daniel Garrido

and Daniel Castro Silva

LIACC, Artiﬁcial Intelligence and Computer Science Laboratory, FEUP, Faculty of Engineering, University of Porto,

Rua Dr. Roberto Frias s/n, 4200-465 Porto, Portugal

Keywords:

Multi-Agent, Middleware, Security, Distributed, Architecture.

Abstract:

The use of multi-agent systems has been increasing and with it the need to improve communication perfor-

mance and to make it secure. In a system with hundreds of agents, in which their reaction must be fast, it is

essential to ensure low latency and high message throughput. These agents can work in a cooperative or com-

petitive environment and, especially in the last, the absence of secure communications opens the possibility

for malicious agents to intercept and/or change the content of the messages. This paper explores alternatives to

the Message Transport Service as described in the Foundation for Intelligent Physical Agents architecture for

multi-agent systems, namely using message-oriented middleware. It also introduces a new component to the

typical multi-agent system architecture, the certiﬁcation authority service. This component is responsible for

creating certiﬁcates that platform agents can use to ensure their identity and communicate safely. This archi-

tecture also manages external agents distribution across several machines, similar to a federated environment,

making the system more suitable for computationally demanding scenarios. The architecture was tested on an

existing simulation platform, showing very good results.

1 INTRODUCTION

The increased use of multi-agent systems (MAS) for

several applications, such as energy systems and in-

dustry 4.0, has led to the need for better perfor-

mant communication middleware and the use of se-

cure message exchange (Pires et al., 2018) (Xie and

Liu, 2017). A system with a high number of agents

in simultaneous communication and with the need

to ensure (near) real-time communication requires

a middleware that can ensure both low latency and

high throughput (Calvaresi et al., 2017) (Leit

ao et al.,

2013). Moreover, these agents can work in a com-

petitive environment, in which secure communica-

tion stops malicious agents from intercepting and/or

changing the contents of the messages being ex-

changed. This way, secure communications in MAS

has been referenced in (Briones et al., 2016), (Tangod

and Kulkarni, 2018), (Hedin and Moradian, 2015),

(Subburaj and Urban, 2018) and other works as an

important feature for current MAS.

The possibility of improving legacy applications

by introducing MAS features has been referenced as

https://orcid.org/0000-0002-2190-5453

https://orcid.org/0000-0002-7421-3119

https://orcid.org/0000-0001-9293-0341

a great advantage of MAS (Oprea, 2004). This can

be done with the concept of external agents. External

agents act like external applications not speciﬁcally

developed for a MAS platform but that can connect

to it and act as an agent. These agents have access to

normal MAS functionalities like message exchange,

yellow and white pages, allowing them to communi-

cate and locate each other using a well-known stan-

dard promoted by FIPA

(Foundation for Intelligent

Physical Agents).

In this paper we present an architecture that aims

to introduce a new component in the FIPA architec-

ture for MAS, the CA service. This service should

create certiﬁcates that ensure agents’ identities and

allow them to communicate securely. We also study

the integration of a communication middleware that

can be used on a MAS. This middleware must provide

the desired messaging performance (both in terms of

latency and throughput) and implement security on

message delivery ensuring conﬁdentiality, integrity

and authenticity.

To achieve that, some related work regarding

multi-agent platforms, communication middleware

and communication security will be explored in Sec-

tion 2. A comparative analysis and some performance

More information available at http://ﬁpa.org/

Costa, D., Garrido, D. and Silva, D.

Efﬁcient Secure Communication for Distributed Multi-Agent Systems.

DOI: 10.5220/0010375605430552

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 1, pages 543-552

ISBN: 978-989-758-484-8

543

tests will be conducted to show performance dif-

ferences between message-oriented middleware and

multi-agent platforms in Section 3, acting as state of

the art regarding current MAS communication perfor-

mance. The architectural solution, proposed in Sec-

tion 4, should be generic, so it can be applied to

any multi-agent system, endowing it with high per-

formance and security on message delivery, while

maintaining important features like compliance with a

standard agent communication language and support

for external agents. This is showcased in Section 5,

with a case study. Section 6 presents some ﬁnal con-

clusions on the developed solution and its abilities.

2 RELATED WORK

Some related works on multi-agent platforms, com-

munication middleware and communication security

are shown in the following sections.

2.1 Multi-Agent Platforms

Several studies on multi-agent platforms have been

conducted, and detailed information can be found in

(Kravari and Bassiliades, 2015) or (Leon et al., 2015).

We focus on those platforms that are more referenced

and adopted by the community, with current active

development, support for secure communication (at

least authenticity, conﬁdentiality and integrity), fol-

lowing FIPA standards and with the possibility of run-

ning agents in different networked computers.

JIAC (Java-based Intelligent Agent Compo-

nentware): is an open-source framework and multi-

agent architecture, developed in Java and distributed

by DAI-Labor. JIAC uses, since version 5, Apache

ActiveMQ as communication middleware. ActiveMQ

(detailed below) is a message-oriented middleware

that should provide JIAC with good performance

utzenberger et al., 2015). JIAC has been used in

several projects such as Energy Efﬁciency Controlling

in the Automotive Industry (EnEffCo) (K

uster et al.,

2013), Intelligent Solutions for Protecting Interdepen-

dent Critical Infrastructures (ILIas) (Konnerth et al.,

2012), Service Centric Home (SerCHo) (Hirsch et al.,

2006) and others.

JADE (Java Agent DEvelopment Framework):

is an open-source framework for multi-agent systems

developed in Java and distributed by Telecom Italia

(Telecom IT, 2017) (Kravari and Bassiliades, 2015).

JADE uses a proprietary protocol for communication,

the Internal Message Transport Protocol (IMTP). This

protocol uses Java event-based communication within

the same container and Remote Method Invocation

(RMI) between containers (Soklabi et al., 2013) (Bel-

lifemine et al., 2007). In JADE, a container represents

a set of agents, and it is possible to have multiple con-

tainers distributed across the network. JADE has been

widely referenced and used in several projects, such

as Agreement Negotiation in Normative and Trust-

enabled Environments (ANTE) (Lopes Cardoso et al.,

2016) and a system that simulates dispatching and

scheduling of transport and production tasks with au-

tomated guided vehicles in manufacturing systems

(Braga et al., 2008).

SPADE (Smart Python Agent Development En-

vironment): is an open-source platform for devel-

oping multi-agent systems in Python. Communica-

tion between two SPADE agents is based on instant

messaging with Extensible Messaging and Presence

Protocol (XMPP). This is a communication protocol

for XML-based middleware (Gregori et al., 2006).

SPADE is used in several projects such as a platform

called SimFleet, a simulator for the use of car ﬂeets

in a more decentralized way (Carrascosa et al., 2019)

and a recommendation system that analyzes user be-

haviour when visiting historical and cultural museum

collections (Gelvez Garc

ıa et al., 2019).

2.2 Message Oriented Middleware

Platforms

Several studies on message-oriented middleware plat-

forms have been conducted, and detailed information

can be found in (Celar et al., 2016) or (Yongguo et al.,

2019). A survey on message oriented middleware

was made in order to understand their characteristics,

features, advantages and disadvantages. We focused

on platforms that are more referenced in the litera-

ture, are free to use, have active development, and

support for secure communication. Middleware plat-

forms normally present an architecture with a broker.

We can think of a broker as a post ofﬁce: a message is

sent to the broker and it then sends the message to the

destination. However, some platforms use a broker-

less architecture, using connections directly between

sender and receiver, in a peer-to-peer (P2P) style.

ActiveMQ: is an open-source communication li-

brary developed by the Apache Software Founda-

tion under the Apache License 2.0 (Apache Software

Foundation, 2019d). There are currently two versions

of this library: ActiveMQ 5 and ActiveMQ Artemis.

We focus on Artemis as it will be the successor to

ActiveMQ 5 as ActiveMQ 6 (Apache Software Foun-

dation, 2019b). ActiveMQ Artemis uses a broker

architecture in which the association to a queue or

set of queues is made using the concept of address.

The messages have an address that indicates where

SDMIS 2021 - Special Session on Super Distributed and Multi-agent Intelligent Systems

544

they should be sent. Thus, sending a message to a

given address may correspond to a send, by the bro-

ker, of the message to one or more queues associ-

ated with that address. There are two types of rout-

ing for a message: multicast, where each message is

sent to all queues associated with that address; and

anycast

, where the message is only sent to one

queue (Apache Software Foundation, 2019a). Ac-

tiveMQ has been used as communication middleware

for several projects related to MAS such as in Decen-

tralized Coordination Framework for Various Multi-

Agent Systems (DeCoF) (Preisler et al., 2016) and

also in the JIAC system, presented above.

Apache Kafka: is an open-source communica-

tion platform developed by LinkedIn for the Apache

Software Foundation, under an Apache License 2.0

(Wang et al., 2015). Apache Kafka uses a broker ar-

chitecture using the concept of topics. A topic serves

as an address where records are published by produc-

ers. A record corresponds to a key, a value and a

timestamp. A topic has several partitions and each

partition consists of records that have been published

there. A producer is responsible for choosing the

partition where the record he produced will be pub-

lished. The partition keeps the records in an orderly

fashion, using a unique sequential identiﬁer for each

record (Apache Software Foundation, 2019c). A con-

sumer can read a record by specifying the identi-

ﬁer of the record it wants to read from the partition.

Apache Kafka has been used as communication mid-

dleware for several projects related to MAS such as

a distributed data analysis framework for Industry 4.0

(Peres et al., 2016) and a distributed multi-agent ap-

plication for continuous and integrated big data pro-

cessing (Shashaj et al., 2019).

RabbitMQ: is an open-source communication

platform developed by Pivotal Software under the

Mozilla Public License (Pivotal, 2019). In Rab-

bitMQ, sending messages from a producer to a con-

sumer must always go through a broker, called

Exchange. There are four types of exchanges

(CloudAMQP, 2015): direct, fanout, topic and head-

ers. RabbitMQ has been used as communication mid-

dleware for several projects related to MAS such as

an ontology-based approach to scheduling jobs (Khe-

gai et al., 2015) and a system to test multi-agent sys-

tems using a publish-subscribe architecture (Nasci-

mento et al., 2017).

ZeroMQ: is an open-source communication li-

brary developed by iMatix Corporation under an

LGPLv3 license (Lauener and Sliwinski, 2017). It

has a brokerless architecture (Marcos, 2016), which

More information available at https://www.cloudﬂare

.com/learning/cdn/glossary/anycast-network/

brings, in theory, two advantages: i) a greater

throughput, since the bottleneck for sending a larger

number of messages is, in most cases, the lack of ca-

pacity of the broker; ii) lower latency, since the mes-

sage is sent directly from producer to consumer, in-

stead of sending it to the broker, who would process

it and only then send it to the ﬁnal recipient. Ze-

roMQ has been used as communication middleware

in several projects related to MAS such as a system

architecture for data and multimedia transmission for

multi-UAV systems (Uk et al., 2018) and a system

that allows to automate mission-level decision mak-

ing for unmanned systems (Unmanned Systems Au-

tonomy Services) (Li et al., 2018).

2.3 Communication Security

To mitigate security risks on communication, there

are some requirements that a MAS must ensure

(Borselius, 2002): integrity, ensuring there was no

change in message content between send and arrival;

conﬁdentiality, ensuring the message content can only

be perceived by authorized agents (i.e., those who

have the key); authenticity, ensuring the message was

in fact sent by whoever claims to be the author; and

non-repudiation, ensuring that an agent cannot deny

having sent a message it actually sent.

These requirements were covered in several MAS

works such as (Poggi et al., 2001) and (Xu et al.,

2010), with the use of public key cryptography

(Mollin, 2002). Public key cryptography uses two

keys: one public, known to everyone, and one private,

that should be kept secret. The two keys are gener-

ated using some mathematical properties in a way that

they are different but one can revert the effect of the

other. Typical algorithms are elliptic curve and RSA,

but elliptic curve manages to maintain the same level

of security with much smaller keys when compared to

RSA, making it more efﬁcient and faster to compute

(Sullivan, 2013).

As mentioned, the public key is known to every-

one, but the association of a public key to an entity

poses a problem: how to ensure a given public key

actually belongs to that entity. The solution found to

this vulnerability is the existence of trusted central-

ized authorities, who certify that a given public key

really belongs to an entity by issuing a certiﬁcate

This certiﬁcate, usually called digital certiﬁcate, cor-

responds to the entity’s public key signed by the cen-

tralized authority with its private key, associated with

an entity identiﬁer. This certiﬁcate then allows ev-

eryone to verify, using the public key of the authority

More information available at https://www.venaﬁ.com/

education-center/pki/how-does-pki-work

Efﬁcient Secure Communication for Distributed Multi-Agent Systems

545

(which is known to everyone), that a given public key

really belongs to an entity (Henmi, 2006).

Another type of cryptography is private key cryp-

tography, in which the same key is used to both en-

crypt and decrypt the content of a message. This type

of encryption is much faster than public key encryp-

tion (according to (Haque et al., 2018), 1000 times

faster) and also more secure (Mollin, 2002). How-

ever, it does not consider key exchange.

Transport Layer Security (TLS

) is a commonly

used protocol for secure communication, using a hy-

brid approach of public and private encryption. For

a given session between two parties, this protocol

uses public key encryption for authentication and ex-

change of a secure symmetric key; then, for the rest

of the session, that symmetric key is used for private

key encryption, as it is more efﬁcient and secure.

3 EXPERIMENTAL

PERFORMANCE EVALUATION

To better understand if a more efﬁcient and secure

solution could be found with the use of a message-

oriented middleware, we performed some experi-

ments to compare the performance of the studied

message-oriented middleware and MAS. These ex-

periments were done both without and with the use

of security (TLS), also providing us with insights on

the performance penalty it entails.

The experiments were performed for three typical

agent communication scenarios (Paletta, 2012): one-

to-one; broadcast; and many-to-one. The tests were

carried out with 10, 50 and 100 pairs of agents com-

municating simultaneously in the one-to-one commu-

nication scenario; 10 producers with 10, 50 and 100

consumers and 50 producers with 10, 50 consumers

in the broadcast communication; and 10, 50 and 100

producers sending to only one consumer in many-to-

one communication.

The content of each message is its own times-

tamp. A group with 500 messages was sent by each

producer, iteratively with an interval of 1ms between

each message. The use of this interval makes the test

case closer to the real one and has a great impact on

the performance values of the middleware.

The tests on communication middleware were

performed using ActiveMQ Artemis 2.10.1, Rab-

bitMQ 3.8.2 and Apache Kafka 2.4.0 server versions,

and Apache.NMS.ActiveMQ 1.7.2, RabbitMQ.Client

5.1.2, Conﬂuent.Kafka 1.3.0, NetMQ 3.3.3.4 and

More information available at https://www.cloudﬂare

.com/learning/ssl/transport-layer-security-tls/

clrzmq4 4.1.0.31 C# .Net clients. The use of C#

clients is related to compatibility with the case study

presented in section 5. The tests on MAS were per-

formed using JIAC 5.2.4, JADE 4.5.0 with JADE-S

3.10 and SPADE 3.1.4. All tests were performed on a

computer with an Intel 4720HQ@2.6Ghz CPU, with

16GB of RAM @1600MHz, 500GB SSD and Win-

dows 10 operating system.

In one-to-one communication, results on Table 1

show ZeroMQ as the best in terms of latency (re-

sults in the format Latency / Throughput). In terms

of throughput, ZeroMQ when using security suffers a

very signiﬁcant impact and RabbitMQ takes the lead.

Regarding ZeroMQ, it is also necessary to refer the

use of two C# clients, NetMQ in the insecure version

and clrzmq in the secure one. Despite being the rec-

ommended client, and having recently received sup-

port for the use of elliptic curve encryption, NetMQ

does not yet support the use of certiﬁcates for client

authentication.

Table 1: One-to-One Performance Tests. Values represent

latency (ms) and throughput (msg/s).

Secure

Platform 10 Pairs 50 Pairs 100 Pairs

ActiveMQ 11 / 1830 23 / 2004 26 / 3358

A. Kafka 574 / 9763 747 / 6512 1475 / 7525

ZeroMQ 0 / 4771 1 / 20342 4 / 23321

RabbitMQ 1 / 4980 11 / 12742 27 / 12791

JADE 3 / 2393 14 / 7319 104 / 12376

JIAC 1317 / 763 9223 / 1512 17437 / 2125

SPADE 468 / 3771 1302 / 7542 2706 / 14321

Yes

ActiveMQ 18 / 1905 181 / 1968 429 / 1981

A. Kafka 565 / 4244 618 / 1901 1166 / 2871

ZeroMQ 3 / 2657 13 / 2360 23 / 3282

RabbitMQ 1 / 4789 19 / 8951 33 / 11529

JADE 33 / 1679 125 / 2811 1016 / 5792

JIAC 1583 / 744 14224 / 1301 18567 / 1871

SPADE 553 / 2649 1978 / 4360 3978 / 9282

Some other platforms also presented good results:

RabbitMQ has good latencies and good throughput;

ActiveMQ has good latencies but a low throughput

when compared to other middleware; JADE is the

only MAS with good overall results (but still far from

most middleware in most cases). Apache Kafka,

SPADE and JIAC present worse results, a situation

that repeats itself in other communication scenarios.

Apache Kafka presents unexpectedly bad results,

much higher than all other middleware. The overall

cost of using security was an increase of 21.38% in

latency and a decrease of 51.3% on throughput.

In broadcast communication, results on Table 2

show RabbitMQ as the best. ZeroMQ’s latency has

increased a lot with the need of using a broker for

broadcast – its documentation recommends the use of

SDMIS 2021 - Special Session on Super Distributed and Multi-agent Intelligent Systems

546

a broker to solve the ”Dynamic Discovery Problem”

In terms of throughput, ZeroMQ is now superior in

both insecure and secure communication, by a large

margin. Regarding other platforms, we refer to the

overall good results of JADE but mainly for the sce-

nario of 50 publishers and 50 subscribers, in which

results are very close to those of RabbitMQ. The over-

all cost of using security was an increase of 13.33%

in latency and a decrease of 52.7% on throughput.

Table 2: Broadcast Latency Performance Tests. Values rep-

resent latency (ms) and throughput (msg/s).

Secure Platform

10 Pubs 10 Pubs 10 Pubs 50 Pubs 50 Pubs

10 Subs 50 Subs 100 Subs 50 Subs 50 Subs

ActiveMQ 5216/31 7095/64 7259/70 10305/192 9583/896

A. Kafka 50000/604 18154/3211 13488/3977 11640/3901 6894/9557

ZeroMQ 181159/3 454546/237 372024/425 146456/904 441889/1473

RabbitMQ 40683/2 63516/11 75896/32 39494/41 76108/279

JADE 13466/14 16159/32 12634/381 34699/207 34882/271

JIAC 870/1267 1004/6096 1269/18656 981/9156 1866/18943

SPADE 2791/1065 2802/3370 3398/6685 3058/3768 3262/9529

Yes

ActiveMQ 3659/300 2927/82 2458/273 2504/130 2552/921

A. Kafka 4163/1115 12303/2898 13488/4265 10493/4294 3699/11042

ZeroMQ 47755/4 166778/340 190986/831 76617/1429 167515/3658

RabbitMQ 34435/5 50648/17 45741/103 48049/33 48005/293

JADE 6154/123 10940/126 11121/1603 21988/350 18207/375

JIAC 884/1502 954/7433 1155/19674 1060/9355 1484/21365

SPADE 2760/1115 2880/3898 3135/7265 2992/4294 3269/11042

In many-to-one communication, results on Table 3

show JADE as the overall best in terms of latency

without the use of security (results in the format La-

tency / Throughput), followed by RabbitMQ. When

using security, RabbitMQ has better latencies. Ze-

roMQ and JADE, with very similar performance be-

tween them, are the ones that follow RabbitMQ but

with signiﬁcantly higher values. The other middle-

ware and MAS have much higher results. In terms

of throughput, ZeroMQ is superior in all scenarios.

The overall cost of using security was an increase

of 21.39% in latency and a decrease of 91.41% on

throughput.

Table 3: Many-to-One Performance Tests. Values represent

latency (ms) and throughput (msg/s).

Secure Platform 10 Pubs 50 Pubs 100 Pubs

ActiveMQ 11 / 808 28 / 2365 381 / 3897

A. Kafka 617 / 64103 768 / 27503 1628 / 12034

ZeroMQ 13 / 454546 58 / 446429 186 / 310559

RabbitMQ 1 / 5005 13 / 18382 28 / 25013

JADE 4 / 2589 7 / 10549 14 / 13763

JIAC 1574 / 1072 11747 / 1917 19475 / 2555

SPADE 133 / 1771 741 / 10342 2079 / 11321

Yes

ActiveMQ 9 / 931 67 / 1466 3787 / 1764

A. Kafka 448 / 4382 782 / 5569 1319 / 5105

ZeroMQ 16 / 4916 65 / 14501 201 / 16955

RabbitMQ 1 / 4921 17 / 10233 47 / 16361

JADE 11 / 2152 57 / 4428 176 / 7409

JIAC 1818 / 856 17361 / 1659 21096 / 2176

SPADE 140 / 2109 830 / 6192 1907 / 8437

More information available at http://zguide.zeromq

.org/page:all#header-39

Table 4 shows an overall comparison of all tested

platforms. The ﬁrst two lines show the number of

times a platform has been the best in all scenarios

for insecure and secure versions, respectively. Re-

sults are presented as Latency / Throughput. The third

and fourth lines show the number of times a platform

reached the top 3 in a scenario, allowing for a bet-

ter understanding of which platforms perform the best

overall. The last two lines show the percentage differ-

ence of the secure version when compared to the in-

secure one (the ﬁfth line shows latency and the sixth

throughput), providing a clearer picture of the perfor-

mance impact in each platform.

These results show RabbitMQ as the most consis-

tent in all scenarios, and also to have better perfor-

mance than all tested MAS platforms. Considering

these results, the quality of its documentation and the

fact that the second best choice (ZeroMQ) would im-

ply using two C# clients, RabbitMQ was chosen.

Table 4: Overall Comparison (Ins. for Insecure and Sec. for

Secure).

Metric ActiveMQ A. Kafka ZeroMQ RabbitMQ JADE JIAC SPADE

1st Ins. 0 / 0 0 / 1 3 / 10 5 / 0 3 / 0 0 / 0 0 / 0

1st Sec. 0 / 0 0 / 0 3 / 7 8 / 4 0 / 0 0 / 0 0 / 0

Top 3 Ins. 7 / 0 0 / 6 5 / 11 11 / 11 10 / 3 0 / 0 0 / 2

Top 3 Sec. 7 / 0 0 / 5 7 / 11 11 / 11 8 / 2 0 / 0 0 / 4

Latency 603% -7% 235% 39% 632% 18% 19%

Throughput -41% -68% -80% -25% -47% -11% -22%

4 PROPOSED ARCHITECTURE

We propose a multi-agent system in which RabbitMQ

acts as the Message Transport Service (MTS

) of the

FIPA architecture for MAS, being responsible for all

message transfers between agents. In order to se-

cure yellow and white pages operations, RabbitMQ

will also transport messages regarding these opera-

tions, but the operation itself continues to be pro-

vided by the original MAS. This works as a wrapper

around operations’ messages, with conﬁdentiality and

integrity assurance for all operations and also sender

identity veriﬁcation when registering, modifying and

de-registering a service. In this architecture, all agents

are connected as publishers, subscribers or both, al-

lowing them to send messages to each other. When

starting an agent, the system will create a queue for

the agent, which other agents can use to send mes-

sages to it. A channel is also created that can be used

by the agent to send messages. Two main communi-

cation scenarios are presented, for individual messag-

ing and broadcast.

More information available at http://www.ﬁpa.org/

specs/ﬁpa00067/SC00067F.html# Toc26669817

Efﬁcient Secure Communication for Distributed Multi-Agent Systems

547

The individual scenario is the most simple case

of communication, messaging from one agent to an-

other. In this scenario, we use a direct exchange in

which a message arriving at the exchange is sent to

the queues whose routing key is the same as the rout-

ing key of the message (Marcos, 2016). Each agent

has a unique routing key (its AID, or Agent Identi-

ﬁer), so any agent just needs to know the recipient’s

AID (which can be learned using the yellow or white

pages) to communicate with it.

The broadcast scenario uses broadcast to send

messages to all agents interested in a topic. This

scenario uses a fanout exchange in which a message

reaching an exchange is sent to all queues linked to it

(Marcos, 2016). An agent only needs to send a mes-

sage to the correct exchange (different exchange per

topic) using a routing pattern for the topic. In our case

we want a message sent to an exchange to be sent to

all subscribers, so we need to have n queues bound to

the exchange, one per subscriber agent.

In order to fulﬁll our objectives we needed to add

to this base FIPA architecture support for secure com-

munication. RabbitMQ supports the use of security

between sender and broker and between broker and

receiver. However, it is necessary to provide each

agent with a certiﬁcate in which the RabbitMQ broker

trusts because it was signed by a certiﬁcate authority

(CA) it knows and trusts. The certiﬁcate also needs

to contain agent-speciﬁc information such as AID. To

allow this, our architecture introduces a new compo-

nent, a CA service, that will sign a certiﬁcate for each

valid agent.

Multi-agent systems were designed with a dis-

tributed architecture in mind, allowing to distribute

agents across several machines. Typically, multi-

agent platforms allow to do that with internal agents

by default. However, when using external agents this

is not assured. In order to allow distribution for ex-

ternal agents, while considering the secure certiﬁca-

tion architecture already presented, we also developed

a distribution architecture. We have called Remote

Node to a node/computer where agents can be placed

to run. This solution is similar to the distribution of

the load on a MAS platform using a federation with

multiple MAS platform instances (Wang and Zhang,

2012). This mechanism works with multiple Remote

Nodes to allow high demanding scenarios, but also

works with the simple case of just one Remote Node

with all agents. This Remote Node can even be on

the same machine as the Master node with the sys-

tem working as a package, like a big single compo-

nent. In this distributed architecture, an agent’s cer-

tiﬁcate needs to contain the IP address of the machine

where the agent is running (the machine from which

the agent will connect to the RabbitMQ broker). If an

agent migrates to another Remote Node it will have

its certiﬁcate regenerated for the new IP address. We

considered that a multi-agent platform with support

for distribution needs to have at least two roles: a

Master node, the central entity of the system respon-

sible for launching the agents; and the agents them-

selves.

To allow all agents to have valid certiﬁcates we

had to create an integrated architecture that allows an

agent to ask for certiﬁcation. It is also necessary that

the CA only issues certiﬁcates to trusted agents. The

process adopted to achieve this is depicted in Fig. 1.

Master Node

1 2

Remote Node

Agent

Private Key

Public Key

CA Certiﬁcation

Service

Figure 1: Agent Certiﬁcation Architecture.

In step 1, the Master node distributes the agents by all

available Remote Nodes in order to achieve load bal-

ance. The communication between the Master node

and each Remote node can be carried out securely

through the use of certiﬁcates with RabbitMQ. The

Master node as well as the Remote nodes previously

had digital certiﬁcates generated on their behalf and

signed by the system’s CA. In terms of scalability, as

there is only one Master node and the Remote nodes

growth is controlled by it, this is an easily practiced

precondition.

In step 2, each Remote node will start the execu-

tion of the received agents.

In step 3, each agent, at the time of its creation, is

responsible for the generation of a pair of keys, used

later to ensure its identity. This pair consists in a pub-

lic key and a private key.

In step 4, each agent sends its public key to the

system CA to create a valid certiﬁcate through a new

component that works as a service. For this com-

munication to happen safely, the created agents will,

only for this request and since an agent is a Remote

node’s child, send its public key to be signed on be-

half of the Remote node. The goal is to ensure that

only agents that have been created by system Remote

nodes (and that way considered trusted) have their

certiﬁcates signed and further access to the platform.

In step 5, the system’s CA generates a certiﬁcate

for each received request, verifying they came from a

trusted Remote node.

In step 6, each certiﬁcate is sent to the agent, who

SDMIS 2021 - Special Session on Super Distributed and Multi-agent Intelligent Systems

548

can use it in future communications with other agents.

These agents of the platform trust these certiﬁcates

because they trust in the identity that issued it (the

system’s CA). This sending operation is carried out

securely through RabbitMQ using certiﬁcates from

the system CA and the agent’s Remote node (as the

signed certiﬁcate is public, and anyone can see it, this

is only a security measure to prevent integrity issues).

After these steps, it is now possible to guaran-

tee that messages are exchanged with conﬁdentiality

and integrity. However, in terms of authenticity we

only ensure that who sends the message is an agent

with a certiﬁcate trusted by the RabbitMQ broker. As

RabbitMQ uses a broker, the ﬁnal message receiver

doesn’t have access to the certiﬁcate used by the orig-

inal sender and so it can’t validate its identity. How-

ever, this can be solved using a RabbitMQ property,

user-id

, that can be sent together with the message.

This property can be set by the sender to indicate its

identity but a message is only successfully sent if the

logged in user has in fact logged in with a username

equal to user-id. Thus, the use of this property implies

that every agent registers itself in the broker.

RabbitMQ offers a plugin that helps in user man-

agement, allowing to register a user just using a user-

name and no password. To login, a user has to use

a certiﬁcate in which the broker trusts and that has

a Distinguished Name (DN) equal to the username

used. The DN

is an identiﬁer that uniquely identiﬁes

an entity in a certiﬁcate. This identiﬁer is built us-

ing other ﬁelds of the certiﬁcate like CommonName

(CN), UserId (UID) and others.

The registration imposes two challenges: having

certiﬁcates to all the platform agents with DN equal to

the username registered; and secure communication

with the RabbitMQ management plugin for registra-

tion. The certiﬁcates architecture presented before al-

ready solves the ﬁrst, as long as the generated certiﬁ-

cates have the correct DN. A good DN format could

be ”UID=<AgentId>,CN=<AgentIpAddress>” and

so this needs to be the username with which the agent

is registered. The use of the agent’s IP address as the

CN is necessary because RabbitMQ checks if the IP

from which it is receiving the request matches that

value. The UID ﬁeld of a certiﬁcate can be used for

storing the agent id (AID), allowing the receiver to

check it. The registration of an agent in RabbitMQ

can be done securely using the available HTTPS API,

by the Master node before launching the agent.

RabbitMQ allows setting permissions regarding

More information available at https://

www.rabbitmq.com/validated-user-id.html

More information available at https://tools.ietf.org/

html/rfc4514

access to queues and exchanges, which are divided

in three: conﬁgure (related to declaring operations),

read and write (Pivotal, 2020). When registering a

user we used these permissions to only allow the nec-

essary operations to that agent, improving security by

using authorisation. Only an agent with ID equal to

X should be able to declare a queue in some standard

format, like ”Agent-X-MessageQueue”, to read mes-

sages. However, all agents should be able to write to

it, to communicate with others.

Since the beginning we knew that using security

would have a performance penalty that the previous

performance tests shown. So, we have planned to

make possible the use of different security assurance

levels to balance between security and performance as

needed. The idea is that the Master node can choose

between different types of security on a given execu-

tion. The levels of security available are: authentica-

tion + SSL, just SSL and no security.

5 CASE STUDY

To test the proposed solution we used a simula-

tion platform (SimPlatform) previously developed

by this research group for simulation of coopera-

tive missions using heterogeneous autonomous ve-

hicles (Silva, 2011). This platform uses a FIPA-

compliant multi-agent system, AgentService

, with

no security in message exchange. We made a compar-

ison between the performance of SimPlatform with

AgentService and now with RabbitMQ (both insecure

and secure versions). The tests were divided in three

scenarios as before: one-to-one and many-to-one at

Table 5 and broadcast at Table 6.

Table 5: One-to-One and Many-to-One Before and After

Comparison. Values represent latency (ms) and throughput

(msg/s).

Test Platform 10 pairs 50 pairs 100 pairs

One-To-One

AgentService 2216 / 466 14416 / 422 31922 / 388

RabbitMQ Ins. 2 / 4916 15 / 6342 36 / 4884

RabbitMQ Sec. 5 / 4344 26 / 5421 46 / 3732

Many-To-One

AgentService 7428 / 338 115677 / 117 685647 / 39

RabbitMQ Ins. 2 / 4995 13 / 11611 35 / 8258

RabbitMQ Sec. 4 / 4985 36 / 10365 61 / 7365

The tests show a tremendous improvement both in

latency and throughput, even when using security,

which was not used before. AgentService’s values are

much worse than all other MAS tested before (JADE,

JIAC and SPADE). However, it needs to be consid-

ered that AgentService was used with external agents

Archived image available at https://web.archive.org/

web/20170703015137/http://www.agentservice.it/

Efﬁcient Secure Communication for Distributed Multi-Agent Systems

549

Table 6: Broadcast Before and After Comparison. Latency

in ms and Throughput in msg/s.

Test Platform

10 Pubs 10 Pubs 10 Pubs 50 Pubs 50 Pubs

10 Subs 50 Subs 100 Subs 10 Subs 50 Subs

Latency

AgentService 24992 128926 308930 428928 1652217

RabbitMQ Ins. 12 30 96 43 274

RabbitMQ Sec. 19 63 289 59 383

Throughput

AgentService 965 944 744 339 436

RabbitMQ Ins. 27762 33607 20055 24512 25849

RabbitMQ Sec. 14885 21404 14550 23558 19879

and the other MAS with normal in-platform agents.

The values presented by RabbitMQ, when compared

to the tests made with RabbitMQ alone, suffered some

performance penalty related to the use of larger mes-

sages and the cost of message serialization. However,

RabbitMQ continues to present the best overall results

when compared to all other middleware and MAS.

With these changes, and the new middleware, Sim-

Platform is now capable of providing real-time simu-

lations with many more agents and in a secure way.

6 CONCLUSIONS

This paper presents the integration of a message-

oriented middleware in a multi-agent system to im-

prove communication efﬁciency, and also to provide

support for secure message exchange with the in-

troduction of CA certiﬁcation service on FIPA stan-

dard architecture for MAS. The middleware choice

was done after performance tests on a selected group

of MAS and communication middleware platforms.

JADE, the studied MAS with best results, presented

on average 7 times higher latencies and half the

throughput when compared to RabbitMQ. To the best

of our knowledge, this is the ﬁrst solution that uses

RabbitMQ to replace a multi-agent system middle-

ware. We believe this solution could be implemented

in other multi-agent systems with very good results,

as was the case of our case study, SimPlatform. We

also describe how a simulation platform with exter-

nal agents, i.e., external applications with MAS func-

tionalities, can have its performance improved using

agents distribution over several machines and how it

can be done securely.

Future improvements could be made to this ar-

chitecture mostly regarding availability and security.

Regarding fault tolerance, this architecture presents

three potential points of failure: RabbitMQ broker

failure; Master node failure; CA certiﬁcation service

failure. RabbitMQ broker failure can be solved with

the use of a broker cluster, which also improves per-

formance, as described in (Jack Vanlightly, 2018).

Both Master node failure and CA certiﬁcation ser-

vice failure can be solved with the use of multiple

instances/nodes of each one working with a mecha-

nism called ”Role Exchange” between a set of mas-

ter and slave nodes, as described in (Gankevich et al.,

2016). This mechanism allows one slave node to take

over the master’s role/position when it fails. This way

it becomes possible to have better performance and

availability.

Regarding security, the developed system allows

receiving agents to verify the AID and IP address of

the agent who sent the message. Although safe, this

system does not include the agent’s decision process

on whether or not to trust the sender of a given mes-

sage. One approach to this would be a mechanism ref-

erenced in the literature as distributed trust, in which

agent A adjusts the level of trust in another agent B

based on the veracity of the information it has been

receiving from B (Dorri et al., 2018).

REFERENCES

Apache Software Foundation (2019a). Core. Available

at https://activemq.apache.org/components/artemis/

documentation/latest/core.html (accessed Nov. 2019).

Apache Software Foundation (2019b). How does

ActiveMQ compare to Artemis. Available at

https://activemq.apache.org/how-does-activemq-

compare-to-artemis (accessed Nov. 2019).

Apache Software Foundation (2019c). Introduction. Avail-

able at https://kafka.apache.org/intro (accessed Nov.

2019).

Apache Software Foundation (2019d). Legal Notice.

Available at https://activemq.apache.org/components/

artemis/documentation/1.5.0/notice.html (accessed

Nov. 2019).

Bellifemine, F. L., Caire, G., and Greenwood, D. (2007).

Developing Multi-Agent Systems with JADE (Wiley

Series in Agent Technology). John Wiley & Sons, Inc.,

Hoboken, NJ, USA.

Borselius, N. (2002). Security in multi-agent systems. In

Proceedings of the 2002 International Conference on

Security and Management (SAM’02), June, Las Vegas,

Nevada, 2002, pages 31–36.

Braga, R., Rossetti, R., Reis, L. P., and Oliveira, E. (2008).

Applying multi-agent systems to simulate dynamic

control in ﬂexible manufacturing scenarios. In Pro-

ceedings of 19th European Meeting on Cybernetics

and Systems Research (EMCSR 2008). Mar. 25-28, Vi-

enna, Austria, 2008, pages 488–493.

Briones, A. G., Chamoso, P., and Barriuso, A. (2016). Re-

view of the Main Security Problems with Multi-Agent

Systems used in E-commerce Applications. Advances

in Distributed Computing and Artiﬁcial Intelligence

Journal, 5(3):55–61.

Calvaresi, D., Marinoni, M., Sturm, A., Schumacher, M.,

and Buttazzo, G. (2017). The Challenge of Real-Time

Multi-Agent Systems for Enabling IoT and CPS. In

Proceedings of the 2017 International Conference on

SDMIS 2021 - Special Session on Super Distributed and Multi-agent Intelligent Systems

550

Web Intelligence (WI’17), Aug. 23-26, Leipzig, Ger-

many, 2017, pages 356—-364.

Carrascosa, C., Terrasa, A., Palanca, J., and Juli

an, V.

(2019). SimFleet: A New Transport Fleet Simula-

tor Based on MAS. In De La Prieta, F., Gonz

alez-

Briones, A., Pawleski, P., Calvaresi, D., Del Val,

E., Lopes, F., Julian, V., Osaba, E., and S

anchez-

Iborra, R., editors, Proceedings of International Work-

shops of Practical Applications of Survivable Agents

and Multi-Agent Systems (PAAMS 2019), June 26-28,

Avila, Spain, 2019, pages 257–264.

Celar, S., Mudnic, E., and Seremet, Z. (2016). State-of-

the-art of messaging for distributed computing sys-

tems. In Proceedings of 27th International Sympo-

sium on Intelligent Manufacturing and Automation

(DAAAM’16), 26-29 Oct., Mostar, Bosnia and Herze-

govina, 2016, volume 27, pages 298–307.

CloudAMQP (2015). Part 4: RabbitMQ Exchanges,

routing keys and bindings. Available at

https://www.cloudamqp.com/blog/2015-09-03-

part4-rabbitmq-for-beginners-exchanges-routing-

keys-bindings.html (accessed Nov. 2019).

Dorri, A., Kanhere, S. S., and Jurdak, R. (2018). Multi-

Agent Systems: A Survey. IEEE Access, 6:28573–

28593. DOI: 10.1109/ACCESS.2018.2831228.

Gankevich, I., Tipikin, Y., Korkhov, V., Gaiduchok, V.,

Degtyarev, A., and Bogdanov, A. (2016). Factory:

Master Node High-Availability for Big Data Appli-

cations and Beyond. In Gervasi, O., Murgante, B.,

Misra, S., Rocha, A. M. A., Torre, C. M., Taniar,

D., Apduhan, B. O., Stankova, E., and Wang, S., edi-

tors, Proceedings of 16th International Conference on

Computational Science and Its Applications (ICCSA

2016), July 4–7, Beijing, China, 2016, pages 379–389.

Gelvez Garc

ıa, N. Y., Ball

en Duarte, A. D., and Espi-

tia Cuchango, H. E. (2019). Multi-Agent System Used

for Recommendation of Historical and Cultural Mem-

ories. Tecciencia, 14:43–52.

Gregori, M. E., C

amara, J. P., and Bada, G. A. (2006). A

Jabber-Based Multi-Agent System Platform. In Pro-

ceedings of the Fifth International Joint Conference

on Autonomous Agents and Multiagent Systems (AA-

MAS ’06), May 8-12, Hakodate, Japan, 2006, page

1282–1284. DOI: 10.1145/1160633.1160866.

Haque, M. E., Zobaed, S., Islam, M. U., and Areef,

F. M. (2018). Performance Analysis of Cryptographic

Algorithms for Selecting Better Utilization on Re-

source Constraint Devices. In Proceedings of 2018

21st International Conference of Computer and Infor-

mation Technology (ICCIT’18), 21-23 Dec., Dhaka,

Bangladesh, 2018.

Hedin, Y. and Moradian, E. (2015). Security in Multi-Agent

Systems. In Proceedings of 19th Annual Conference

on Knowledge-Based and Intelligent Information &

Engineering Systems (KES 2015), Sept. 7-9, Singa-

pore, 2015, volume 60, pages 1604–1612.

Henmi, A. (2006). Firewall Policies and VPN Conﬁgura-

tions, chapter Chapter 5 - Deﬁning a VPN, pages 211–

265. Syngress, Burlington.

Hirsch, B., Konnerth, T., Heler, A., and Albayrak, S.

(2006). A Serviceware Framework for Designing

Ambient Services. In Proceedings of the First In-

ternational Conference on Ambient Intelligence De-

velopments (AmID’06), Sept. 20-22, Sophia Antipolis,

France, 2006, pages 124–136. Springer, Paris.

Jack Vanlightly (2018). RabbitMQ vs Kafka Part 5 - Fault

Tolerance and High Availability with RabbitMQ Clus-

tering. Available at https://jack-vanlightly.com/blog/

2018/8/31/rabbitmq-vs-kafka-part-5-fault-tolerance-

and-high-availability-with-rabbitmq (accessed May

2020).

Khegai, M., Zubok, D., and Maiatin, A. (2015). Ontology-

Based Approach to Scheduling of Jobs Processed

by Applications Running in Virtual Environments.

In Proceedings of 6th International Conference on

Knowledge Engineering and Semantic Web (KESW

2015), Sept. 30 - Oct. 2, Moscow, Russia, 2015, pages

273–282.

Konnerth, T., Chinnow, J., Kaiser, S., Grunewald, D.,

Bsufka, K., and Albayrak, S. (2012). Integration of

Simulations and MAS for Smart Grid Management

Systems. In Proceedings of the 3rd International

Workshop on Agent Technologies for Energy Systems

(ATES 2012), June 5, Valencia, Spain, 2012, pages

51–58.

Kravari, K. and Bassiliades, N. (2015). A Survey of Agent

Platforms. Journal of Artiﬁcial Societies and Social

Simulation, 18(1):18. DOI: 10.18564/jasss.2661.

uster, T., L

utzenberger, M., and Freund, D. (2013).

Distributed Evolutionary Optimisation for Electricity

Price Responsive Manufacturing using Multi-Agent

System Technology. International Journal On Ad-

vances in Intelligent Systems, 6(1&2):27–40.

Lauener, J. and Sliwinski, W. (2017). How to design

& implement a modern communication middleware

based on ZeroMQ. In Proceedings of International

Conference on Accelerator and Large Experimental

Physics Control Systems (ICALEPCS’17), Oct. 8-13,

Barcelona, Spain, 2017.

Leit

ao, P., Inden, U., and Ruckemann, C.-P. (2013). Par-

allelising Multi-agent Systems for High Performance

Computing. In Proceedings of Third International

Conference on Advanced Communications and Com-

putation (INFOCOMP’13), Nov. 17-22, Lisbon, Por-

tugal, 2013, pages 1–6.

Leon, F., Paprzycki, M., and Ganzha, M. (2015). A Re-

view of Agent Platforms. Technical report, CT COST

Action IC1404, Multi-Paradigm Modelling for Cyber-

Physical Systems (MPM4CPS).

Li, Y., Frasure, I., Ikusan, A. A., Zhang, J., and Dai, R.

(2018). Vulnerability Assessment for Unmanned Sys-

tems Autonomy Services Architecture. In Au, M. H.,

Yiu, S. M., Li, J., Luo, X., Wang, C., Castiglione, A.,

and Kluczniak, K., editors, Proceedings of 12th In-

ternational Conference on Network and System Secu-

rity (NSS 2018), Aug. 27-29, Hong Kong, China, 2018,

pages 266–276.

Lopes Cardoso, H., Urbano, J., Rocha, A. P., Castro, A.

J. M., and Oliveira, E. (2016). ANTE: A Framework

Integrating Negotiation, Norms and Trust, pages 27–

45.

utzenberger, M., Konnerth, T., and K

uster, T. (2015). In-

dustrial Agents, chapter 21 - Programming of Multia-

Efﬁcient Secure Communication for Distributed Multi-Agent Systems

551

gent Applications with JIAC, pages 381–398. Morgan

Kaufmann, Boston.

Marcos, P. B. (2016). Resources Management Monitoriza-

tion Platform on a Message Oriented Middleware Sys-

tem. Master’s thesis, University of Porto.

Mollin, R. A. (2002). RSA and Public-Key Cryptogra-

phy. Discrete Mathematics and Its Applications. CRC

Press, Inc., USA.

Nascimento, N. M., Viana, C. J., von Staa, A., and Lucena,

C. (2017). A Publish-Subscribe based Architecture for

Testing Multiagent Systems. In Proceeding of 29th In-

ternational Conference on Software Engineering and

Knowledge Engineering (SEKE’17), July 5-7, Pitts-

burgh, PA, USA, 2017, pages 521–526.

Oprea, M. (2004). Applications of Multi-Agent Systems.

In Reis, R., editor, Proceedings of International Fed-

eration for Information Processing 18th World Com-

puter Congress (WCC2004), August 22-27, Toulouse,

France, 2004, pages 239–270.

Paletta, M. (2012). Self-Organizing Multi-Agent Systems

by means of Scout Movement. Recent Patents on

Computer Science, 5(3):197–210.

Peres, R. S., Rocha, A. D., Coelho, A., and Barata Oliveira,

J. (2016). A Highly Flexible, Distributed Data Anal-

ysis Framework for Industry 4.0 Manufacturing Sys-

tems. In Proceedings of 6th International Workshop

on Service Orientation in Holonic and Multi-Agent

Manufacturing (SOHOMA 2016), Oct. 6-7, Lisbon,

Portugal, 2016, volume 694, pages 373–381.

Pires, F., Barbosa, J., and Leit

ao, P. (2018). Quo Vadis

Industry 4.0: An Overview Based on Scientiﬁc Pub-

lications Analytics. In Proceedings of 2018 IEEE

27th International Symposium on Industrial Electron-

ics (ISIE 2018), June 13-15, Cairns, QLD, Australia,

2018, pages 663–668.

Pivotal (2019). Mozilla Public License. Available at https:

//www.rabbitmq.com/mpl.html (accessed Jan. 2020).

Pivotal (2020). Authorisation: How Permissions Work.

Available at https://www.rabbitmq.com/access-

control.html#authorisation (accessed May 2020).

Poggi, A., Rimassa, G., and Tomaiuolo, M. (2001). Multi-

User and Security Support for Multi-Agent Systems.

In Proceedings of 2nd Workshop From Objects to

Agents (WOA 2001), Sep. 4-5, Modena, Italy, 2001,

pages 13–18.

Preisler, T., Dethlefs, T., and Renz, W. (2016). DeCoF:

A Decentralized Coordination Framework for Vari-

ous Multi-Agent Systems. In Klusch, M., Unland,

R., Shehory, O., Pokahr, A., and Ahrndt, S., editors,

Proceedings of 4th German Conference on Multiagent

System Technologies (MATES’16), Sept. 27–30, Kla-

genfurt, Austria, 2016, volume 9872, pages 73–88.

Shashaj, A., Mastrorilli, F., Morrelli, M., Pansini, G., Ian-

nucci, E., and Polito, M. (2019). A Distributed Multi-

Agent System (MAS) Application For continuous and

Integrated Big Data Processing. In Chatzigiannakis,

I., De Ruyter, B., and Mavrommati, I., editors, Pro-

ceedings of 15th European Conference on Ambient In-

telligence (AmI 2019), Nov. 13–15, Rome, Italy, 2019,

pages 350–356.

Silva, D. C. (2011). Cooperative Multi-Robot Missions:

Development of a Platform and a Speciﬁcation Lan-

guage. PhD thesis, University of Porto, Porto, Portu-

gal.

Soklabi, A., Bahaj, M., and Cherti, I. (2013). JIAC Systems

and JADE Agents Communication. International

Journal of Engineering and Technology, 5(2):1976–

1984.

Subburaj, V. H. and Urban, J. E. (2018). Specifying Secu-

rity Requirements in Multi-agent Systems Using the

Descartes-Agent Speciﬁcation Language and AUML.

In Proceedings of 15th Conference on Advanced In-

formation Technologies for Management (AITM 2018)

and 13th Conference on Information Systems Man-

agement (ISM 2018), Sept. 9-12, Poznan, Poland,

2018, pages 93–111.

Sullivan, N. (2013). A (Relatively Easy To Understand)

Primer on Elliptic Curve Cryptography. Available

at https://blog.cloudﬂare.com/a-relatively-easy-to-

understand-primer-on-elliptic-curve-cryptography

(accessed Jan. 2020).

Tangod, K. and Kulkarni, G. (2018). Secure Communica-

tion through MultiAgent System-Based Diabetes Di-

agnosing and Classiﬁcation. Journal of Intelligent

Systems, 29(1):703–718.

Telecom IT (2017). JADE. Available at https://

jade.tilab.com/ (accessed Nov. 2019).

Uk, B., Konam, D., Passot, C., Erdelj, M., and Natalizio,

E. (2018). Implementing a System Architecture for

Data and Multimedia Transmission in a Multi-UAV

System. In Chowdhury, K. R., Di Felice, M., Matta,

I., and Sheng, B., editors, Proceedings of 16th Inter-

national Conference on Wired/Wireless Internet Com-

munication (WWIC 2018), June 18–20, Boston, MA,

USA, 2018, pages 246–257.

Wang, G., Koshy, J., Subramanian, S., Paramasivam, K.,

Zadeh, M., Narkhede, N., Rao, J., Kreps, J., and

Stein, J. (2015). Building a Replicated Logging

System with Apache Kafka. Proc. VLDB Endow.,

8(12):1654–1655. DOI: 10.14778/2824032.2824063.

Wang, X. and Zhang, L. (2012). Multi-Agent Systems Sim-

ulation Base on HLA Framework. In Lee, G., edi-

tor, Proceedings of International Conference on Au-

tomation and Robotics (ICAR 2011), Dec. 1-2, Dubai,

United Arab Emirates, 2011, pages 339–346.

Xie, J. and Liu, C.-C. (2017). Multi-agent systems and

their applications. Journal of International Council

on Electrical Engineering, 7(1):188–197.

Xu, X., Xiong, J., and Cheng, C. (2010). The model and the

security mechanism of the information retrieval sys-

tem based on mobile multi-agent. In Proceedings of

2010 IEEE 12th International Conference on Commu-

nication Technology (ICCT’10), Nov. 11-14, Nanjing,

China, 2010, pages 25–28.

Yongguo, J., Qiang, L., Changshuai, Q., Jian, S., and Qian-

qian, L. (2019). Message-oriented Middleware: A Re-

view. In Proceedings of 5th International Conference

on Big Data Computing and Communications (BIG-

COM’19), 9-11 Aug., QingDao, China, 2019, pages

88–97. DOI: 10.1109/BIGCOM.2019.00023.

SDMIS 2021 - Special Session on Super Distributed and Multi-agent Intelligent Systems

552
