Deployment Service for Scalable Distributed Deep Learning Training on

Multiple Clouds

Javier Jorge

1 a

, Germ

an Molt

1 b

, Damian Segrelles

1 c

, Jo

ao Pedro Fontes

and Miguel Angel Guevara

Instituto de Instrumentaci

on para Imagen Molecular (I3M), Centro Mixto CSIC, Universitat Polit

ecnica de Val

encia,

Camino de Vera s/n, 46022, Valencia, Spain

Computer Graphics Center, University of Minho, Campus de Azur

em, Guimar

aes, Portugal

Keywords:

Cloud Computing, Deep Learning, Multi-cloud.

Abstract:

This paper introduces a platform based on open-source tools to automatically deploy and provision a dis-

tributed set of nodes that conduct the training of a deep learning model. To this end, the deep learning frame-

work TensorFlow will be used, as well as the Infrastructure Manager service to deploy complex infrastructures

programmatically. The provisioned infrastructure addresses: data handling, model training using these data,

and the persistence of the trained model. For this purpose, public Cloud platforms such as Amazon Web

Services (AWS) and General-Purpose Computing on Graphics Processing Units (GPGPU) are employed to

dynamically and efﬁciently perform the workﬂow of tasks related to training deep learning models. This ap-

proach has been applied to real-world use cases to compare local training versus distributed training on the

Cloud. The results indicate that the dynamic provisioning of GPU-enabled distributed virtual clusters in the

Cloud introduces great ﬂexibility to cost-effectively train deep learning models.

1 INTRODUCTION

Artiﬁcial Intelligence (AI), mainly through Deep

Learning (DL) models, is currently dominating the

ﬁeld of classiﬁcation tasks, especially after the disrup-

tive results obtained in 2012 in the most challenging

image classiﬁcation task at that moment (Krizhevsky

et al., 2012), defeating the SVM (Support Vector Ma-

chine) (Vapnik, 1998) approaches that were leading

those contests previously. DL models are trained us-

ing Backpropagation (Rumelhart et al., 1985), an iter-

ative procedure that could take days or weeks depend-

ing on the volume of the data or the complexity of the

model. Among the options to reduce the computa-

tional cost, the most common technique to parallelize

this process is the data parallelism approach (Dean

et al., 2012) as that is the most straightforward and

easy technique to implement.

Big tech companies and relevant research groups

have open-sourced many of their algorithms and

methods as AI frameworks for the community (i.e:

https://orcid.org/0000-0002-9279-6768

https://orcid.org/0000-0002-8049-253X

https://orcid.org/0000-0001-5698-7965

TensorFlow (TF) (Abadi et al., 2016), PyTorch (Py-

Torch, 2018) or MXNet (MXNet, 2018)) enabling a

quicker and easier evaluation of academic DL mod-

els and the deployment in production environments.

These frameworks provide a uniform set of functions,

such as parallelization on multiple nodes, ﬂexibility

to code using different interfaces, automatic differen-

tiation, similar abstractions regarding the structure of

the network, and “model zoos” to deploy an out-of-

the-box model in production quickly.

Considering the interest of the academia and in-

dustry to use DL models in their pipelines, it is of vital

importance to provide easier, faster and better tools to

deploy their algorithms and applications. To this end,

research groups and companies are using Cloud ser-

vices (such as Google’s Cloud AI (Cloud AI, 2018)

or Amazon SageMaker (Amazon SageMaker, 2018))

to develop their DL solutions, as long as they are

computationally (storage and processing) demanding

and require expensive and dedicated hardware such

as General-Purpose Computing on Graphics Process-

ing Units (GPGPUs), as it is the case of the DL tech-

niques. However, these Cloud solutions result in the

user being locked-in to a particular Cloud and, there-

fore, loosing the ability to perform infrastructure de-

Jorge, J., Moltó, G., Segrelles, D., Fontes, J. and Guevara, M.

Deployment Service for Scalable Distributed Deep Learning Training on Multiple Clouds.

DOI: 10.5220/0010359601350142

In Proceedings of the 11th International Conference on Cloud Computing and Services Science (CLOSER 2021), pages 135-142

ISBN: 978-989-758-510-4

135

ployment on different or multiple Cloud providers.

This Cloud approach is known as “Infrastructure As

Code” (IaC) (Wittig and Wittig, 2016) and it arises

to overcome these gaps and deﬁne instead the cus-

tomized computational environment required with-

out interaction with the Cloud provider’s interfaces

and enabling non-expert users to deﬁne, in a Cloud-

agnostic way, the virtual infrastructure as well as the

process of managing and provisioning the computa-

tional resources from multiple Clouds for different

trainings. Notice that a single training is performed

within the boundaries of a single cloud to achieve re-

duced latency.

This paper introduces a Cloud Service that pro-

vides an automated DL pipeline, from the deployment

and provision of the required infrastructure on Cloud

providers, through an IaC approach, to its execution

in production. It is based on open-source tools to de-

ploy a customised computational environment based

on TF, to perform the distributed DL model training

based on data parallelism, on Cloud infrastructures

involving accelerated hardware (GPUs) for increased

efﬁciency. As use case to validate the service, it is

presented the deployment, conﬁguration and execu-

tion of a distributed cluster for training deep neural

networks, on a public Cloud provider. This uses re-

sources that the user may not be able to afford oth-

erwise, such as several nodes connected using one or

more expensive GPUs. This approach will be con-

veniently assessed by means of training several DL

models on distributed clusters provisioned on Ama-

zon Web Services (AWS). In addition, an actual re-

search problem has been used to validate the proposed

service in order to test the system in a real use case

documented in the work by Brito at al. (Brito et al.,

2018).

2 RELATED WORK

Recently, approaches for efﬁcient DL have been de-

veloped ad-hoc for speciﬁc use cases, such as Deep-

Cell (Bannon et al., 2018), a tool used to perform

large-scale cellular image analysis, tuned for these

particular problems. For a general purpose, the al-

ternative is using proprietary tools that the Cloud

providers offer, tailored for a speciﬁc framework that

usually depends on the provider, or a high-level API

to access these services easily. A thorough review of

this can be found in (Luckow et al., 2016), where the

authors studied distributed DL tools to use in the au-

tomotive industry.

There are other approaches related to the use of

multi-GPUs beyond using different nodes or more

than one GPU per node. For instance, GPU virtual-

ization provides the interface to use a variable number

of GPUs, intercepting local calls and sending them to

a GPU server farm to be processed, with thousands

of GPUs working in parallel. An example of these

proposals is shown in rCUDA (Rea

no et al., 2015).

However, these approaches are either experimental or

more expensive than public Clouds, and they do not

provide additional services required for this kind of

problems such as storage resources.

The topic of distributed DL has been addressed in

the past, as it is the case of the work by Lee et al.

(Lee et al., 2018) where a framework for DL across

multiple machines using Apache Spark is introduced.

There are also approaches that try to speed up this

distributed computation providing another layer of

abstraction over TF, such as Horovod (Sergeev and

Del Balso, 2018), using MPI

, the commonly used

(M)essage (P)assing (I)nterface to intercommunicate

nodes.

As opposed to previous works, we introduce

an approach for distributed learning that relies ex-

clusively on the capabilities of TF, thus minimiz-

ing external dependencies. Also, these distributed

clusters can be dynamically deployed on different

Cloud back-ends through an Infrastructure-as-Code

approach thus fostering reproducibility of the dis-

tributed learning platform and the ability to easily

proﬁt from GPU resources provided by public Cloud

platforms to accelerate training.

3 DEPLOYMENT SERVICE FOR

DISTRIBUTED TensorFlow

This section identiﬁes the components to design and

implement the proposed service. The goal is to train

a deep neural network in a distributed way, fostering

data parallelism, and considering that the training pro-

cess can be split according to different shards of data.

This scales very easily, and this is how some of the

big companies such as Google achieved the amazing

breakthroughs these last years, such as AlphaGO (Sil-

ver et al., 2017). Among different approaches for do-

ing this, we have followed the scheme from (Dean

et al., 2012), that is reproduced in Figure 1. This ar-

chitecture shows different nodes that can be identiﬁed

as follows:

• Parameter server (PS): Node(s) that initializes pa-

rameters, distributes them to the workers, gathers

the modiﬁcations of the model’s parameters and

https://www.mpi-forum.org/docs/

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

136

then applies them, and scatters them back to the

workers.

• Model replicas (MR): Node(s) that stores the

model and that carries out the backpropagation’s

forward and backward steps, and ﬁnally sends

back the updates to the PS. There will be a mas-

ter among them in charge of persisting the model.

These nodes are the ones that require more com-

putational power, i.e: GPU units.

• Data shards: Nodes that provide data for MRs.

Figure 1: Distributed training scheme: Parameter server and

model replicas, in a master-slave setup (Dean et al., 2012).

This scheme could work either synchronously or

asynchronously, meaning that the MR nodes could

wait for the rest of the MR nodes to ﬁnish their itera-

tion to move to the next one (training synchronously

with others) or the node could continue with the

next batch of data when it completes the forward-

backward step (training asynchronously).

Regarding the data shards, we propose the use of

a distributed ﬁle system among nodes, in order to

share data and model checkpoints as well. In particu-

lar, we have chosen the Hadoop Distributed File Sys-

tem (HDFS) (Shvachko et al., 2010), a distributed and

scalable ﬁle system that is focused on storing massive

amounts of data. It has been used mainly on Java’s

framework Hadoop (Hadoop, 2018) to implement the

MapReduce paradigm (Dean and Ghemawat, 2008).

The proposed service deploys the Hadoop cluster

in charge of data storage (HDFS) and the TF cluster

in charge of processing data, in the same resources

and nodes, coexisting along with each other. Con-

cerning training, each node will run a TF script that

implements the aforementioned training scheme. As

a summary, Figure 2 shows the proposed steps to pre-

pare the architecture required to perform the training.

3.1 Infrastructure Manager

The Cloud service, in order to deploy the nodes

commented above on Cloud uses an IaC approach

relying on the Infrastructure Manager (IM) (Infras-

tructure Manager, 2018; Caballer et al., 2015)

. It

IM - https://www.grycap.upv.es/im

PS WN1 WN2 WN3

Bucket

y = f(x; w)

Figure 2: Step 1: Getting the data and uploading it to the

HDFS storage. Step 2: Training starts, the PS node and

MR nodes collaborate to train the model, using TF and the

HDFS ﬁle system. Step 3: Once training is completed, a PS

node stores the model in a persistent Cloud storage, such as

an S3 bucket.

is an open-source tool to deploy on-demand cus-

tomized virtual computing infrastructures. It allows

the user to deploy complex infrastructures choos-

ing among multiple Cloud providers, such as AWS,

Microsoft Azure or Google Cloud Platform. The

IM is the orchestration tool adopted by the Euro-

pean Grid Infrastructure (EGI) (European Grid Infras-

tructure, 2018) in order to deploy Virtual Machines

through the VMOps Dashboard on the EGI Feder-

ated Cloud that spans across Europe. This paves

the way for easy adoption of the approach described

in this work by the European scientiﬁc community.

It uses “Resource and Application Description Lan-

guage” (RADL)(Infrastructure Manager, 2018; Ca-

baller et al., 2015), a high-level language to deﬁne

virtual infrastructures and VM requirements.

The IM processes the RADL ﬁle and interacts

with the Cloud providers to launch the Master VM

that will orchestrate the deployment and conﬁgura-

tion. A speciﬁc module called Conﬁguration Man-

ager conﬁgures this Master node using Ansible (An-

sible, 2018), providing the contextualization and con-

ﬁguration ﬁles and installing the Contextualization

Agent. This module will deploy, conﬁgure and pro-

vision main roles, in our case, the PS and MR Nodes,

including TF and the Hadoop cluster.

The following subsections present the tools em-

ployed by the proposed service, in order to prepare

the infrastructure required to support the architecture

shown in Figure 2. After that, it presents how dis-

tributed TF training is achieved through the service.

3.2 Resources’ and Operations’

Deﬁnition

The RADL ﬁle and the Ansible roles to deploy the

whole infrastructure’s speciﬁcs required to achieve

distributed training of a deep neural network describe

Deployment Service for Scalable Distributed Deep Learning Training on Multiple Clouds

137

the node’s characteristics, the operations to perform

upon them and the system architecture.

The execution of the RADL through the IM pre-

pares the whole environment (PS and MR nodes) to

execute the training script. The complete version of

the resource allocation conﬁguration ﬁles and code

are available on GitHub

, and thoroughly described

in (Jorge Cano, 2019). We have relied on an An-

sible role to deploy the Hadoop cluster in order to

use HDFS as a shared data storage among the nodes.

Once this step is completed, the Hadoop cluster is

completely deployed, and then we can proceed with

data handling, as well as conﬁguring and installing

TF. Amazon S3 is used as the initial storage for the

data, and the dataset is retrieved from S3 and staged

into HDFS upon deployment of the Hadoop cluster,

but the data can come from any external source. Af-

ter deploying the Hadoop cluster, the distributed TF

script is prepared, installed and executed using an-

other Ansible role. The set of parameters for the PS

node is similar to the MR nodes, with some changes

accordingly to their function, such as the node type

or whether a GPU is used or not. The role involves

four parts: ﬁrst, some environment preparation with

paths and additional variables. Second, the condi-

tional installation of a speciﬁc TF version depending

on whether the node has a GPU or not. Third, cloning

the actual training scripts and running them, depend-

ing on the role of the node in the cluster. Finally, we

have included the code to upload the resulting model

to an S3 bucket to persist it beyond the lifecycle of

the dynamically provisioned Hadoop cluster, but we

can select any external platform or service to store the

model.

3.3 Distributed TensorFlow Training

This section shows how we performed the adaptation

of the distributed TF code to be used in our pipeline.

TF distributed training implements a scheme where

one or more nodes act as PS nodes and the rest as MR

nodes. The code is available in Github

This work uses the Estimator API in TF, which

provides high-level functions that encapsulate the dif-

ferent parts of the machine learning pipeline: model,

input, training, validation and evaluation. Provid-

ing common headers for these steps they can manage

training and inference better, as the whole pipeline

is decomposed into isolated functions. By deﬁning

the pipeline in these terms, it is entirely managed by

https://github.com/JJorgeDSIC/Master-Thesis-

Scalable-Distributed-Deep-Learning/

https://github.com/JJorgeDSIC/

DistributedTensorFlowCodeForIM

TF, without worrying about running iterations, evalu-

ation steps, logs or saving the model manually. An-

other signiﬁcant advantage is to have a program that

can run in a single node with CPU or GPU, with

multiple GPUs or in a distributed way, just indicat-

ing these variations as an environment variable called

TF CONFIG.

4 EXPERIMENTATION

In this section, we will use the conﬁguration ﬁles,

codes and scripts that we have presented in previous

sections in order to evaluate our deployment and ex-

ecution in terms of ﬂexibility and timing. For do-

ing this, we have selected a public Cloud provider

to deploy our infrastructure and perform the evalua-

tion. First, we consider executing the training using

single nodes, in physical and virtual machines, to get

the baseline that we can achieve with the resources at

reach. Second, we study the use of a Cloud provider

to deploy Virtual Machines with and without special-

ized hardware, to compare the results to both single

and multiple node conﬁgurations.

To perform the local experimentation, we used a

physical node with Ubuntu 16.04, NVIDIA CUDA 9

- CUDNN 7, TF r1.10. Regarding the hardware, the

node includes an Intel(R) Xeon(R) CPU E5-1620 v3

4 cores @ 3.50GHz with 128 GB of RAM along with

the GPU GeForce GTX 1080Ti (11GB, 3.5K cores @

1.6Ghz).

We selected AWS as the public Cloud provider

to use during the evaluation. An analysis of the in-

stance types and pricing was carried out, in terms

of choosing cost-effective computing resources. To

reduce costs, we have selected an Amazon Machine

Image (AMI) to accelerate the deployment and avoid

some time-consuming tasks such as update packages

when we use a fresh Ubuntu 16.04 VM. The AMI

used is called Deep Learning Base AMI (Ubuntu)

Version 10.0 AMI

, and it is available in most AWS

regions. This AMI comes with NVIDIA CUDA 9 and

NVIDIA cuDNN 7 and can be used with several in-

stance types, from a small CPU-only instance to the

latest high-powered multi-GPU instances. The infor-

mation of these instances’ families is available on the

AWS website

. We have selected p2 instances, the

p2.xlarge in particular, that are composed of an In-

tel Xeon E5-2686 v4 (Broadwell) CPU and NVIDIA

K80 GPUs (12GiB, 2.5K cores). It is important to

remark the years of development between the vir-

https://aws.amazon.com/marketplace/pp/

B077GCZ4GR

https://aws.amazon.com/ec2/instance-types/

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

138

tualized GPU (K80, year 2014) the physical GPU

(RTX1080, year 2017), as the performance is not di-

rectly comparable.

For the CPU-based resources, we chose instance

types t2.micro and t2.small, These are very low-

cost computing instances that support burstable CPU

performance. Concerning software, we have used the

same versions as the aforementioned physical equip-

ment in all the VM.

4.1 Datasets

To perform the experiments we selected two tasks:

a well-known benchmark and a real research prob-

lem. As benchmark dataset, we selected the CIFAR-

10 (Krizhevsky, 2009) dataset that comprises 60k

32x32 colour images, with 10 different categories (6k

images per category). The ofﬁcial split deﬁnes 50k

samples to train the model and 10K to evaluate its ac-

curacy predicting the correct category among the 10

possible. Figure 3 shows some examples from this

dataset with their categories.

Figure 3: Images from CIFAR-10 with their cate-

gories (Krizhevsky, 2009).

We have selected this dataset since it is handy

and complicated enough to require a non-trivial neu-

ral network model. As this is a dataset of images, we

can use a convolutional neural network where GPUs,

with their specialized hardware to process graphics,

can take full advantage of the accelerated hardware.

Along with this well-known dataset, we have

used an internal dataset provided by the “Centro de

Computac¸

ao Gr

aﬁca (CCG)”

from Portugal, in or-

der to evaluate our software approach with an ac-

tual research problem. Our proposed deployment

service was tested in a real use case documented

in (Brito et al., 2018). This work is part of the

AGATHA project

that consists of a solution pro-

viding image/video analysis for crime control and

surveillance. For this collaboration, we have used a

proprietary dataset provided by CCG, composed of

pictures of faces, labelled with child, young, adult or

http://www.ccg.pt

http://www.agatha-osi.com/

elder classes, aiming to identify this features in a se-

curity surveillance system. Regarding the dataset, it

is composed of around 65k RGB images with a res-

olution of 224x224. We train the model to predict

the label among the set {child, young, adult, elder}.

Some examples of these pictures are shown in Fig-

ure 4. It is composed of different sources, the subset

that is shown was extracted from the website Internet

Movie Database (IMDB)

. The 4.5GB dataset takes

an average of 13 minutes to be retrieved from S3 to

HDFS inside the Hadoop cluster.

Figure 4: Images from the provided dataset.

4.2 TensorFlow Code

We chosen an implementation provided in the TF of-

ﬁcial repository

, using the version r1.10. We exe-

cuted it without any change thanks to the Estimator

API, introduced in the previous section, to illustrate

that the code that follows this scheme can be trained

inside this infrastructure with ease. For the same rea-

son, we only included the required changes, just mod-

ifying the input pipeline, to adapt the age recogni-

tion model to be trained under this API. The model

that these codes use is the convolutional neural net-

work model known as Inception-Resnet-V1 (He et al.,

2016). This model has 44 layers, millions of parame-

ters, and it is based on one of the ﬁrst huge deep learn-

ing models called Inception (Szegedy et al., 2015).

4.3 Results with CIFAR-10

First, we evaluated to decide whether to conduct asyn-

chronous or synchronous training. Using a conﬁgura-

tion with three GPU nodes, one parameter server and

three worker nodes. We carried out both experiments

and we show the results in Table 1, evaluating several

iterations of the process. Regarding measuring, for

these and the following experiments we have evalu-

ated the number of global steps per second, that is, the

number of batches processed per second and the av-

erage examples per second: number of instances that

the model can process per second.

https://www.imdb.com

https://github.com/tensorﬂow/models/tree/master/

tutorials/image/cifar10\ estimator

Deployment Service for Scalable Distributed Deep Learning Training on Multiple Clouds

139

Table 1: Comparison of both training schemes: syn-

chronous and asynchronous.

Training G.step/sec Avg.ex/sec

Synchronous 3,26±1,14 485±67

Asynchronous 10,04±5,59 2755±765

After getting better results with the asynchronous

training, we have chosen it for the following exper-

iments. We have performed 60k steps globally over

the training partition, with batches of 128 images to

carry out a fair comparison among different architec-

tures. With this training on a physical machine with

one GPU, we have obtained a classiﬁcation accuracy

of 92,27%, that we used to measure the convergence

of the other models. Therefore, we will use this value

to compare timing measures during 60k or the equiv-

alent in a distributed conﬁguration, that is, 30-30 if

there are two worker nodes or 20-20-20 if there are

three.

Regarding the single node experiment, we exe-

cuted the training with different hardware conﬁgura-

tions. We refer to the physical machines with the pre-

ﬁx phys, and virt to the virtual ones, while denoting

the use of CPU/GPU adding the sufﬁx cpu or gpu,

respectively. In addition to global steps and average

samples per second, we evaluated also the total time,

that is, how long the training takes to converge. This

is not always plausible considering that CPU based

nodes can take a considerable amount of time. Ta-

ble 2 shows the results for the comparison among sin-

gle nodes. The * means that training did not fully con-

verge and then an estimation of time to convergence is

provided. We noticed the obvious performance boost

that GPU provides with this kind of data. These prob-

lems are extremely resource-consuming for CPUs,

discouraging any possible training using this hard-

ware. It is important to remark again the difference

between the physical GPU and the virtual one. In the

next experiment we explore the options to parallelize

the problem.

Next experiments involve the use of a distributed

conﬁguration. For doing this, we have deployed the

infrastructure in AWS and run the experiments, taking

the same measures than before. Table 3 summarizes

the results. We divided accordingly the number of

Table 2: Single node results with different hardware (G =

G.step/sec, A = Avg.ex/sec., T = T.time (min)).

Machine G A T

phys cpu 0,44±0,02 54,94±2,78 2200 (*)

virt cpu 0,18±0,02 25,12±0,92 4860 (*)

phys gpu 22±1 2804±22 ˜45

virt gpu 7±0,56 850±15 ˜142

Table 3: Multiple node results with different hardware (G =

G.step/sec, A = Avg.ex/sec., T = T.time (min)).

Machine G A T

virt cpu +

virt gpu x 2

(1 PS - 2 WN)

7,68±2,95 1259±395 ˜92

virt gpu x 3

(1 PS - 2 WN)

13,04±0,48 1687±80 ˜41

virt cpu +

virt gpu x 3

(1 PS - 3 WN)

10,04±5,59 2755±965 ˜43

steps among the workers to add up to 60k, and values

shown are related to the architecture as a whole.

Some results show very high variance, this was the

side-effect of using a lower-end instance type for the

PS, such as t2.small. During the experiments with

this kind of node, the global steps per second were

decreasing gradually along iterations until they reach

lower values than in the virt gpu single training.

Even if it seems counter-intuitive, using this fourth

node as PS caused a bottleneck in the system. Fig-

ure 5 illustrates this fact, that we discovered after sus-

pecting and discarding that HDFS latency to access

to the data or the model was the cause. It seems that

at a certain point, the resources of the CPU-based PS

were exhausted, and then the performance got worse.

Changing the type of instance solved the problem, as

it can be seen in the improvement in the results us-

ing virt gpu x 3, providing a stable global step/sec

rate, at the expense of losing a GPU node to do the

computationally intensive work.

Steps

Figure 5: TensorBoard screenshot, showing the bottleneck

in the middle of the training due to the use of low CPU-

based instance.

Regarding ﬂexibility, we performed the previous

experiments again with the distributed conﬁguration,

using our deployment system with the IM and Ansi-

ble, changing parameters easily and interacting just

with the RADL ﬁle, that deﬁne the architecture. Con-

sidering this, we found that the best combination is

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

140

the use of three nodes (a PS and two WNs) that are

GPU-based. In the following section we explore some

of these setups with the computer vision research

problem provided by the CCG.

4.4 Results with Age Recognition Task

Table 4 shows the results of the best systems after the

evaluation considering phys gpu, virt gpu x 3 and

virt cpu + virt gpu x 3, the setups that provided

the best result among virtualization systems.

Table 4: Single physical node and multiple node results on

the Age dataset, with different hardware.

Machine G.step/sec Avg.ex/sec

phys gpu 18,53±1,82 2217±190

virt gpu x 3

(1 PS - 2 WN)

10,06±0,78 1353±47

virt cpu +

virt gpu x 3

(1 PS - 3 WN)

12,45±2,78 1498±317

Concerning the storage, we did not perceive any

important latency caused by the HDFS system nei-

ther in CIFAR-10 nor in the faces dataset. Once the

dataset is uploaded, we have performed experiments

with and without distributing data and model and not

noticing any remarkable difference. This may happen

with massive datasets since they require more com-

plicated management. In terms of the introduced la-

tency, the dynamic deployment’s latency of the virtual

infrastructure, although unavoidable, will be absorbed

by the training when a real time-consuming task is

carried out, that could imply hours or days of train-

ing. The advantages of performing all the steps with-

out human intervention represent a signiﬁcant step

forward. It usually took between 15-20 minutes to

deploy the conﬁguration with a t2.small and three

p2.xlarge. In summary, the results indicate that us-

ing automated deployment on the Cloud to take ad-

vantage of GPU-based nodes is a convenient approach

for cost-effective training, as you can easily match

your needs with your budget, enabling the access to

both basic units and high performance GPUs.

4.5 Discussion

Increasing the throughput of the training of deep neu-

ral networks have become mandatory to solve the

challenging tasks nowadays. Parallelizing training us-

ing GPUs seems the way to go, since the proposal in

(Krizhevsky et al., 2012), where the process of shar-

ing a model between GPUs in order to accelerate the

training was done manually with a lot of human effort.

This has changed and now it is very easy, as shown in

this work, to code the training using TF to distribute

the training effort among different distributed GPUs.

Regarding this, we have shown how to deploy the re-

quired infrastructure in a public Cloud provider to get

the most out of the functionality that this framework

provides.

The parallel training scheme suits well in several

problems, as it is shown in (Dean et al., 2012), but

there are more approaches, such as Elastic Averag-

ing SGD (Zhang et al., 2015). This work proposes

a distributed optimization scheme designed to reduce

communication overhead with the parameter server.

Ideas in that direction are concerned with the func-

tion that the parameter server computes in order to

favour the convergence of the training. This work

aimed to develop the architecture and the deployment,

as well as implementing a generic distributed training,

so these kind of evaluations regarding training conver-

gence are out of the scope of this work.

We have decided to focus on data parallelism as

our motivation was to provide the DL pipeline for

problems that leverage this kind of scheme, i.e.: sev-

eral instances that are distributed in a data cluster, but

there are tasks where this is not enough. Among these

tasks, we can consider machine translation where

models, or the composition of them, are huge. This

is the problem that authors faced in (Wu et al., 2016),

where they used model parallelism as well as data par-

allelism. For these kinds of models, there is no alter-

native for training them in a reasonable time.

5 CONCLUSIONS

In this work we provided and evaluated a deploy-

ment system to provision, conﬁgure and execute a

distributed TF training pipeline in an unattended way,

based on cluster computing in the Cloud. Using the

IM and Ansible, we can modify our architecture and

train easily just by modifying a conﬁguration ﬁle and

being able to deploy on different Cloud providers.

Regarding software, we have used the state-of-

the-art tools, such as TF and CUDA, performing ex-

periments with two different problems, CIFAR-10

and the Age recognition problem. We have shown

that TF scripts can be adapted easily if they are us-

ing the Estimator API, a high-level API that eases the

development of deep learning models.

Concerning the results, we are close to the base-

line with the physical GPU, even considering that it

is two generations ahead of the virtual GPUs that we

used. However, we achieved a good performance ac-

cording to the price of these instances. The present

Deployment Service for Scalable Distributed Deep Learning Training on Multiple Clouds

141

approach democratizes the access to cost-effective

distributed computing based on TF on the Cloud to

perform training of deep learning models.

Future work includes using massive datasets to

identify the bottlenecks of the proposed approach.

Also, more performant instance types were not used

due to budget constraints. This goes inline with using

the p3 family of instances types that feature more than

one GPU per node, to evaluate in-node parallelization

and between-nodes parallelization jointly.

ACKNOWLEDGEMENTS

The authors would like to thank the Spanish “Ministe-

rio de Econom

ıa, Industria y Competitividad” for the

project “BigCLOE” with reference number TIN2016-

79951-R. The development of this work has been par-

tially supported by the project “AGATHA: Intelligent

Analysis System for surveillance/crime control on

open information sources” (project No. 010822), ﬁ-

nanced by the European Regional Development Fund

(ERDF) through COMPETE 2020 - Operational Pro-

gram for Competitiveness and Internationalisation

and Lisbon 2020 - Lisbon Regional Operational Pro-

gram 2014-2020.

REFERENCES

Abadi, M. et al. (2016). Tensorﬂow: a system for large-

scale machine learning. In Proc. of OSDI, 2016, pages

265–283.

Amazon SageMaker (2018). [online-Feb.2021] https://aws.

amazon.com/sagemaker/.

Ansible (2018). [online-Feb.2021] https://www.ansible.

com/.

Bannon, D. et al. (2018). Deepcell 2.0: Automated cloud

deployment of deep learning models for large-scale

cellular image analysis. bioRxiv, page 505032.

Brito, P. et al. (2018). Agatha: Face benchmarking dataset

for exploring criminal surveillance methods on open

source data. In Proc. of ICGI, 2018, pages 1–8. IEEE.

Caballer, M. et al. (2015). Dynamic management of virtual

infrastructures. Journal of Grid Computing, 13(1):53–

70.

Cloud AI (2018). [online-Feb.2021] https://cloud.google.

com/products/ai/.

Dean, J. et al. (2012). Large scale distributed deep net-

works. In Proc. of NIPS, 2012, pages 1223–1231.

Dean, J. and Ghemawat, S. (2008). Mapreduce: simpliﬁed

data processing on large clusters. Communications of

the ACM, 51(1):107–113.

European Grid Infrastructure (2018). [online-Feb.2021]

https://www.egi.eu.

Hadoop (2018). [online-Feb.2021] http://hadoop.apache.

org.

He, K. et al. (2016). Deep residual learning for image recog-

nition. In Proc. of CVPR, 2016, pages 770–778.

Infrastructure Manager (2018). [online-Feb.2021] http://

www.grycap.upv.es/im/.

Jorge Cano, J. (2019). Entrenamiento escalable de modelos

de deep learning sobre infraestructuras cloud. [online-

Feb.2021] https://riunet.upv.es/handle/10251/115454.

Krizhevsky, A. (2009). Learning multiple layers of features

from tiny images. Technical report, Citeseer.

Krizhevsky, A. et al. (2012). Imagenet classiﬁcation with

deep convolutional neural networks. In Proc. of NIPS,

2012, pages 1097–1105.

Lee, S. et al. (2018). TensorLightning: A Trafﬁc-

Efﬁcient Distributed Deep Learning on Commodity

Spark Clusters. IEEE Access, 6:27671–27680.

Luckow, A. et al. (2016). Deep learning in the automo-

tive industry: Applications and tools. In Proc. of Big

Data2016, 2016, pages 3759–3768. IEEE.

MXNet (2018). [online-Feb.2021] https://mxnet.apache.

org.

PyTorch (2018). [online-Feb.2021] https://pytorch.org.

Rea

no, C. et al. (2015). Local and remote gpus perform

similar with edr 100g inﬁniband. In Proceedings of the

Industrial Track of the 16th International Middleware

Conference, page 4. ACM.

Rumelhart, D. E. et al. (1985). Learning internal representa-

tions by error propagation. Technical report, Institute

for Cognitive Science, California.

Sergeev, A. and Del Balso, M. (2018). Horovod: fast and

easy distributed deep learning in tensorﬂow. arXiv

preprint arXiv:1802.05799.

Shvachko, K. et al. (2010). The hadoop distributed ﬁle sys-

tem. In Proc. of MSST, 2010, pages 1–10. Ieee.

Silver, D. et al. (2017). Mastering the game of go without

human knowledge. Nature, 550(7676):354.

Szegedy, C. et al. (2015). Going deeper with convolutions.

In Proc. of CVPR, 2015, pages 1–9.

Vapnik, V. N. (1998). Statistical learning theory, volume 1.

J. Wiley & Sons.

Wittig, M. and Wittig, A. (2016). Amazon web services in

action. Manning.

Wu, Y. et al. (2016). Google’s neural machine translation

system: Bridging the gap between human and ma-

chine translation. CoRR, abs/1609.08144.

Zhang, S. et al. (2015). Deep learning with elastic averag-

ing sgd. In Cortes, C., Lawrence, N. D., Lee, D. D.,

Sugiyama, M., and Garnett, R., editors, Proc. of NIPS,

2015, pages 685–693. Curran Associates, Inc.

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

142
