Embedded Features for 1D CNN-based Action Recognition

on Depth Maps

Jacek Trelinski and Bogdan Kwolek

AGH University of Science and Technology, 30 Mickiewicza, 30-059 Krakow, Poland

Keywords:

Action Recognition on Depth Maps, Convolutional Neural Networks, Feature Embedding.

Abstract:

In this paper we present an algorithm for human action recognition using only depth maps. A convolutional

autoencoder and Siamese neural network are trained to learn embedded features, encapsulating the content

of single depth maps. Afterwards, statistical features and multichannel 1D CNN features are extracted on

multivariate time-series of such embedded features to represent actions on depth map sequences. The action

recognition is achieved by voting in an ensemble of one-vs-all weak classiﬁers. We demonstrate experimentally

that the proposed algorithm achieves competitive results on UTD-MHAD dataset and outperforms by a large

margin the best algorithms on 3D Human-Object Interaction Set (SYSU 3DHOI).

1 INTRODUCTION

Human action recognition (HAR) can be deﬁned as

capability of determining whether a given action oc-

curred in image or depth sequence. It has been inten-

sively studied in the last decade, especially because

this is a challenging problem, but also due to possible

applications that can beneﬁt from it. However, due to

several difﬁculties, including non-rigid shape of the

humans, intra-class variations, viewpoint variations,

occlusions and plenty another challenges and environ-

mental complexities, the current algorithms have poor

performance in comparison to human ability to rec-

ognize and to understand human motions and actions

(Liang and Zheng, 2015; Wang et al., 2020).

Prior to the release of low-cost depth cameras, such

as Microsoft Kinect, research has concentrated on

learning and recognizing actions using RGB datasets

and video repositories. Having on regard that Kinect

motion sensor is capable of extracting the depth maps

in poor illumination conditions or even in darkness,

considerable attention is devoted to algorithms oper-

ating on depth maps. When action performers are

captured using 2D cameras then one dimension is lost

during the acquisition, which causes the loss of im-

portant information. For the same reason, 3D-based

approaches provide higher accuracy than 2D-based

approaches. Most of the current approaches to action

recognition on depth maps are based on the skeleton

(Ren et al., 2020). The number of approaches, rely-

ing on depth maps only, particularly deep learning-

based is very limited (Wang et al., 2020). Despite

that skeleton-based methods usually achieve better re-

sults in comparison to algorithms using only depth

maps, they can fail in many scenarios due to skeleton

extraction failure.

In order to stimulate the research as well as to

facilitate development and evaluation of new algo-

rithms, several RGB-D benchmark datasets have been

acquired in the last decades (Li et al., 2010; Chen et al.,

2015; Hu et al., 2015). Currently available datasets

for 3D action recognition usually have 10, 20, 27 or

a little more categories of actions, which were per-

formed by a dozen or several dozen performers, and

each action has been repeated a few times. The MSR

Action 3D dataset (Li et al., 2010), is one of the most

frequently used benchmarks in the research as well

as in evaluation of the algorithms. The recently intro-

duced UTD-MHAD dataset (Chen et al., 2015) has

four types of data modalities: RGB, depth, skeleton

joint positions, and the inertial sensor signals and it is

considered as a valuable benchmark data. In SYSU 3D

Human-Object Interaction (3DHOI) dataset (Hu et al.,

2015) each action involves a kind of human-object

interactions. Deep learning-based methods for human

action recognition require a huge amount of image or

depth map sequences for training. Collecting and an-

notating huge amounts of data is immensely laborious

and necessitates appropriate equipment and computa-

tional resources. Due to limited number of depth se-

quences in currently available RGB-D datasets, which

is typically smaller than one thousand, the recogni-

536

Trelinski, J. and Kwolek, B.

Embedded Features for 1D CNN-based Action Recognition on Depth Maps.

DOI: 10.5220/0010340105360543

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 4: VISAPP, pages

536-543

ISBN: 978-989-758-488-6

tion of actions on the basis of 3D depth maps is very

challenging.

Traditional approaches to activity recognition on

depth maps rely on the handcrafted feature-based rep-

resentations (Yang et al., 2012; Xia and Aggarwal,

2013). In contrast to handcrafted representation-based

approaches, in which actions are represented by engi-

neered features, learning-based algorithms are capable

of discovering the most informative features automat-

ically from the raw data. Such deep learning-based

methods permit processing images/videos in their raw

forms and thus they are capable of automating the

process of feature extraction and classiﬁcation. These

methods employ trainable feature extractors and com-

putational models with multiple layers for action rep-

resentation and recognition.

In this work we demonstrate experimentally that

despite the limited amount of training data, i.e. action

sequences in currently available datasets, it is possi-

ble to learn features with highly discriminative power.

A convolutional autoencoder and Siamese neural net-

work have been trained to extract features on single

depth maps. Afterwards, statistical features and multi-

channel 1D CNN features were extracted on multivari-

ate time-series of features to represent actions on depth

map sequences. As far as we know, the multi-channel

1D convolutional neural networks (Zheng et al., 2014;

Zheng et al., 2016) have not been utlized in human

action recognition. The recognition of the actions is

done by a voting-based ensemble operating on one-hot

encodings of one-vs-all weak classiﬁers.

2 THE ALGORITHM

A characteristic feature of the proposed approach is

that it does not require skeleton. Thanks to using depth

maps only, our algorithm can be employed on depth

data provided by stereo cameras, which can deliver the

depth data for persons being at larger distances to the

sensors. It is well known that the Kinect sensor fails to

estimate the skeleton in several scenarios. In the next

Section, we demonstrate experimentally that despite

no use of the skeleton, our algorithm achieves better

accuracies than several skeleton-based algorithms. In

the proposed approach, various features are learned in

different domains, like single depth map, time-series

of embedded features, and ﬁnal decision is taken on

the basis of voting of one-vs-all weak classiﬁers.

The algorithm has been evaluated on MSR Action

3D, UTD-MHAD and SYSU 3DHOI datasets. Since

in SYSU 3DHOI dataset the performers are not ex-

tracted from depth maps, we extracted the subjects.

For each depth map we determined a window sur-

rounding the person, which has then been scaled to the

required input shape.

In Subsection 2.1 we present features describing

the person’s shape in single depth maps. Afterwards,

in Subsection 2.2 we present features representing

multivariate time-series. In Subsection 2.3 we discuss

multi-class classiﬁers to construct ensemble. Finally,

in Subsection 2.4 we describe the ensemble.

2.1 Embedded Frame-features

Since current datasets for depth-based action recogni-

tion have insufﬁcient number of sequences to learn

deep models with adequate generalization capabil-

ities, we propose CNNs operating on single depth

maps or pairs of depth maps to extract informative

frame-features. Because the number of frames in the

current benchmark datasets for RGBD-based action

recognition is pretty large, deep feature representations

can be learned. Given an input depth map sequence

x = {x

, x

, . . . , x

}

, we encode each depth map

us-

ing a CNN backbone

into a feature

f (x

)

, which

results in a sequence of embedded feature vectors

f (x) = { f (x

), f (x

), . . . , f (x

)}

. The dimension of

such embedding for a depth map sequence is

T × D

where

is size of the embedded vector. In the next

subsection we detail how frame-features were embed-

ded without supervision using a convolutional autoen-

coder. Afterwards, we explain how frame-features

were calculated using a Siamese neural network.

2.1.1 Unsupervised Extraction of

Frame-features using Convolutional

Autoencoder

An autoencoder is a type of artiﬁcial neural network

that projects a high-dimensional input into a latent

low-dimensional code (encoder), and then carries out

a reconstruction of the input using such a latent code

(the decoder) (Hinton and Salakhutdinov, 2006). To

achieve this the autoencoder learns a hidden represen-

tation for a set of input data, typically through com-

pression (dimensionality reduction), by learning to

ignore less informative information. This means that

the autoencoder tries to generate from such a reduced

encoding an output representation that is close as pos-

sible to its input. When the hidden representation uses

fewer dimensions than the input, the encoder carries

out dimensionality reduction. An autoencoder consists

of an internal (hidden) layer that stores a compressed

representation of the input, as well as an encoder that

maps the input into the code, and a decoder that maps

the code to a reconstruction of the original input. The

encoder compresses the input and produces the code,

whereas the decoder reconstructs the input using only

Embedded Features for 1D CNN-based Action Recognition on Depth Maps

537

this code. Learning to replicate its input at its output is

achieved by learning a reduction side and a reconstruct-

ing side. Autoencoders are considered as unsupervised

learning technique since no explicit labels are needed

to train them. Once such a representation with reduced

dimensionality is learned, it can then be taken as input

to a supervised algorithm that can then be trained on

the basis of a smaller labeled data subset.

We extracted frame-features using encoder/decoder

paradigm proposed in (Masci et al., 2011). We imple-

mented a convolutional autoencoder (CAE) in which

the input depth map is ﬁrst transformed into a lower

dimensional representation through successive con-

volution operations and rectiﬁed linear unit (ReLU)

activations and afterwards expanded back to its orig-

inal size using deconvolution operations. The mean

squared error, which measures how close the recon-

structed input is to the original input has been used

as the loss function in the unsupervised learning. The

network has been trained using Adam optimizer with

learning rate set to 0.001. After training, the decoding

layers of the network were excluded from the convo-

lutional autoencoder. The network trained in such a

way has been used to extract low dimensional frame-

features. The depth maps acquired by the sensor were

projected two 2D orthogonal Cartesian planes to rep-

resent top and side view of the maps. On training

subsets we trained a single CAE for all classes. The

convolutional autoencoder has been trained on depth

maps of size 3 × 64 × 64.

The CAE network architecture is shown in Fig. 1.

The network consists of two encoding layers and two

associated decoding layers. The size of depth map

embedding is equal to 100.

Figure 1: Architecture of convolutional autoencoder.

2.1.2 Semi-supervised Learning of Frame

Similarity

Siamese Neural Networks (SNNs) are a class of neu-

ral networks that contain multiple instances of the

same model and share same architecture and weights

(Chopra et al., 2005). In contrast to MLPs that utilize

loss functions calculating errors between outputs and

target values, the SNNs use objectives that compare

the feature vectors of pairs of the exemplars. They

have been used for dimensionality reduction (Hadsell

et al., 2006) as well for one-shot image classiﬁcation

(Koch et al., 2015), i.e. recognition on the basis of one

training example per class. They are trained with a

collection of sample pairs with the same or different

categories. Sharing weights across the sub-networks

results in smaller number of learned parameters. Thus,

this architecture shows its strength when it has to learn

on the basis of limited data.

In the proposed approach a separate Siamese neural

network is trained for each action class to extract fea-

tures distinguishing a given class from all remaining

classes, same as in one-vs-all multi-class classiﬁcation.

In other words, each Siamese neural network is trained

to decide whether the considered depth map belongs

to the class for which the network had been trained or

to one of the remaining classes.

The central idea behind SNNs is to learn an em-

bedding, where similar image pairs are close to each

other and dissimilar image pairs are separated by a

distance that depends on a parameter called margin.

Let us assume that our aim is to learn a SNN on a

training set

, y

}

i=1

, where

∈ R

and

are class

labels. The Siamese network produces a feature em-

bedding

f (x, θ

)

that is deﬁned as

f : R

× R

→ R

where

∈ R

stands for parameters of the network.

The aim of the learning is to seek for the parameter

vector

such that the embedding produced through

has desirable properties, and particularly it places

similar examples nearby. The SNN can extract infor-

mation from the available data and determine such

an embedding without requiring speciﬁc information

about the categories. Thus, learning the Siamese net-

work is achieved in a weakly-supervised scheme using

only pairs of data instances labeled as matching or

non-matching.

Let us consider a pair of images

, I

)

that con-

tains person performing the same action, and a pair of

images

, I

)

, which belong to different action cate-

gories. The Siamese neural network maps such image

pairs into embedded space

, x

)

such

and

are close, whereas

and

are further apart. Such

an embedding can be achieved on the basis of a con-

trastive loss function

, which expresses how well the

function

is capable of placing similar image repre-

sentations in the close proximity and keep dissimilar

image representations distant. The contrastive loss

function L(θ) can be expressed as follows:

L(θ) =

∑

)

, x

)

| {z }

penalty term

for similar images

∑

)

, x

)

| {z }

penalty term

for dissimilar images

(1)

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

538

where

, x

) =



− x



, x

) = max (0, m −

− x

)

(2)

The penalty term

penalizes the pair

, x

)

that is

too apart, whereas

penalizes the pair

, x

)

that

is closer than a margin

. Thus, dissimilar image

pairs contribute to the loss function if their distances

are within the margin

. Given the label

indicating

whether the images are similar or dissimilar the margin-

based loss function can be expressed as follows:

L(θ, x

, x

) = y



f (x

) − f (x

)



+ (1 − y)max(0, m −



f (x

) − f (x

)



)

(3)

where function

performs a forward propagation

through the Siamese sub-network. The loss function

penalizes positive pairs by the squared Euclidean dis-

tances and negative pairs by the squared difference

between the margin

and Euclidean distance for pairs

having distance less than the margin

. Figure 2 con-

tains diagram of the utilized Siamese neural network.

The network has been trained using Adam optimizer

with learning rate set to 0.00006.

Figure 2: Architecture of Siamese neural network.

2.2 Features of Time-series

On the basis of depth map sequences representing hu-

man actions the neural networks that were discussed

above produce multivariate time-series. Having on

regard that depth map sequences differ in length, such

variable length time-series were interpolated to a com-

mon length. In the next two Subsections we explain

how features for multivariate time-series are deter-

mined.

2.2.1 Statistical Features of Time-series

For each multivariate time-series of features, which

were extracted by the convolutional autoencoder, we

calculate statistical features. Such statistical features

represent actions. For each time-series feature we cal-

culate four features: average, standard deviation, skew-

ness and correlation of the time-series with time. The

motivation of using skewness was to include a param-

eter describing asymmetry in random variable’s proba-

bility distribution with respect to normal distribution.

The multivariate time-series are of size

4 × 100 = 400

2.2.2 Multi-channel, Temporal 1D CNN

In multi-channel, temporal CNNs (MC CNNs) the

1D convolutions are applied in the temporal domain.

In this work, the time-series (TS) of frame-features

that were extracted by the Siamese neural network

have been used to train multi-channels 1D CNNs. The

number of channels is equal to 64, see Fig. 2. The

multivariate time-series were interpolated to the length

equal to 100. Cubic-spline algorithm has been utilized

to interpolate the TS to such a common length.

The ﬁrst layer of the MC CNN is a ﬁlter (feature

detector) operating in time domain. Having on regard

that the amount of the training data in current datasets

for depth-based action recognition is quite small, the

neural network consists of two convolutional layers,

each with

8 × 1

ﬁlter,

4 × 1

and

2 × 1

max pools, re-

spectively, see Fig. 3. The number of neurons in the

dense layer is equal to 100. For each Siamese time-

series of features a separate multichannel 1D CNN has

been trained. Such approach is due to redundant depth

maps, i.e. the same human poses in different actions.

The number of output neurons is equal to number of

the classes. Nesterov Accelerated Gradient (Nesterov-

Momentum) has been used to train the network, in

1000 iterations, with momentum set to 0.9, dropout

equal to 0.5, learning rate equal to 0.001, L1 parameter

set to 0.001. After the training, the output of the dense

layer has been used to extract the features.

2.3 Multi-class Classiﬁers to Construct

Ensemble

The features described in Subsections 2.2.1 and 2.2.2

were used to train multi-class classiﬁers with softmax

encoding, see Fig. 4. Having on regard that for each

class an action-speciﬁc classiﬁer to extract depth map

features has been trained, the number of such classi-

ﬁers is equal to the number of actions to be recognized.

The convolutional Autoencoder (Subsect. 2.1.1) oper-

ating on sequences of depth maps delivers time-series

Embedded Features for 1D CNN-based Action Recognition on Depth Maps

539

Figure 3: Flowchart of the multi-channel CNN for multivariate time-series modeling.

of AE-based frame-features, on which we determine

statistical temporal features (Subsect. 2.2.1). The base

networks of the Siamese (Subsect. 2.1.2) operating on

sequences of depth maps deliver time-series of fea-

tures (one feature vector per frame), which are further

processed by the multi-channel, temporal neural net-

work (Subsect. 2.2.2). It delivers feature vectors of

size 100, see Fig. 4, which are then concatenated with

statistical features of size 400. The multi-class clas-

siﬁers delivering at the outputs the softmax-encoded

class probability distributions are ﬁnally used in an

ensemble responsible for classiﬁcation of actions.

2.4 Ensemble of Classiﬁers

Figure 4 depicts the ensemble for action classiﬁcation.

The ﬁnal decision is calculated on the basis of voting

of the classiﬁers. As we can see, the statistical features

that are common for all actions are concatenated with

class-speciﬁc features, and then used to train multi-

class classiﬁers.

3 EXPERIMENTAL RESULTS

The proposed algorithm has been evaluated on three

publicly available benchmark datasets: MSR Ac-

tion 3D dataset (Li et al., 2010), UTD-MHAD dataset

(Chen et al., 2015) and SYSU 3D Human-Object In-

teraction Set (SYSU 3DHOI) (Hu et al., 2015). The

datasets were selected having on regard their frequent

use by action recognition community in the evalua-

tions and algorithm comparisons.

In experiments and evaluations with MSR Ac-

tion 3D dataset, 557 sequences were investigated. In

the evaluation of the algorithm, half of the subjects

were utilized for the training, and the rest for the test-

ing, which is dissimilar to evaluation protocols based

on AS1, AS2 and AS3 data splits and averaging the

classiﬁcation accuracies over such data splits. It is also

worth mentioning that the classiﬁcation performances

Figure 4: Ensemble operating on features extracted by con-

volutional autoencoder, concatenated with class-speciﬁc fea-

tures that were extracted by Siamese neural networks.

achieved in the selected setting are lower in compari-

son to classiﬁcation performances, which are achieved

on AS1, AS2, AS3 setting due to bigger variations

across the same actions performed by different per-

formers. The evaluations were performed according to

the cross-subject evaluation protocol (Xia and Aggar-

wal, 2013; Wang et al., 2016) The discussed evaluation

scheme is different from the procedure employed in

(Xia et al., 2012), in which more performers were in

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

540

the training subset.

The UTD-MHAD dataset contains 27 different ac-

tions performed by eight subjects (four females and

four males). All actions were performed in an indoor

environment with a ﬁxed background. Each performer

repeated each action four times. The dataset consists

of 861 data sequences and it was acquired using the

Kinect sensor and a wearable inertial sensor.

The SYSU 3D Human-Object Interaction (3DHOI)

dataset was recorded by the Kinect sensor and com-

prises 480 RGBD sequences from 12 action categories,

including calling with cell phone, playing with a cell

phone, pouring, drinking, wearing backpack, packing

a backpack, sitting on a chair, moving a chair, taking

something from a wallet, taking out a wallet, mop-

ping and sweeping. Actions were performed by 40

subjects. Each action involves a kind of human-object

interactions. Some motions actions are quite similar

at the beginning since the subjects operate or interact

with the same objects, or actions start with the same

sub-action, such as standing still. The above men-

tioned issues make this dataset challenging following

the evaluation setting in (Hu et al., 2019), in which

depth map sequences with the ﬁrst 20 subjects were

used for training and the rest for testing.

Table 1 presents experimental results that were

achieved on the MSR Action 3D dataset. As we can

notice, the best results were achieved using logistic

regression classiﬁers and hard voting in the ensemble.

Table 1: Recognition performance on MSR Action 3D

dataset (LR - logistic regression, SVM - Support Vector

Machine, H - hard voting, S - soft voting).

class. vot. Accuracy

Preci-

sion

Recall

F1-

score

LR S 0.8836 0.8865 0.8836 0.8716

LR H 0.9018 0.9076 0.9018 0.8903

SVM S 0.8909 0.8889 0.8909 0.8833

SVM H 0.8691 0.8704 0.8691 0.8621

Table 2 illustrates the classiﬁcation performance of

the proposed method in comparison to previous depth-

based methods on the MSR Action 3D dataset. The

classiﬁcation performance of the proposed framework

has been determined using the cross-subject evaluation

(Wu, 2012), where subjects 1, 3, 5, 7, and 9 were em-

ployed for training and subjects 2, 4, 6, 8, and 10 were

utilized for testing. As we can notice, the proposed

method achieves better classiﬁcation accuracy than

recently proposed method (Wang et al., 2018), and

it has worse performance in comparison to recently

proposed method (Bulbul et al., 2019) (Split I). One

of the main reasons that our method achieves worse

results than (Bulbul et al., 2019) is limited amount of

training samples in the MSR Action 3D dataset. In

our methods features extracted by CAE and Siamese

neural networks are employed, whereas the method

mentioned above is based on handcrafted features.

Table 2: Comparative recognition performance of the pro-

posed method with recent algorithms on MSR Action 3D

dataset.

Method Split

Modality

Acc.

[%]

3DCNN (Wang et al., 2018) Split II depth

84.07

GLAC (Bulbul et al., 2019) Split I depth

94.50

Proposed Method Split I depth

90.18

Table 3 presents experimental results that were

achieved on the UTD-MHAD dataset. As we can

observe, the best results were achieved using logistic

regression classiﬁers and hard voting in the ensemble.

Figure 5 depicts the confusion matrix.

Table 3: Recognition performance on UTD-MHAD dataset

(LR - logistic regression, SVM - Support Vector Machine, H

- hard voting, S - soft voting).

class. vot. Accuracy

Preci-

sion

Recall

F1-

score

LR S 0.8767 0.8912 0.8767 0.8720

LR H 0.8791 0.8902 0.8791 0.8760

SVM S 0.8744 0.8921 0.8744 0.8724

SVM H 0.8628 0.8801 0.8628 0.8621

Figure 5: Confusion matrix on UTD-MHAD dataset.

Table 4 presents the recognition performance of

the proposed method compared with previous meth-

ods. Most of current methods for action recognition

on UTD-MHAD dataset are based on skeleton data.

Methods based on skeleton modality usually achieve

better results in comparison to methods relying on

depth data only. Despite the fact that our method

is based on depth modality, we evoked the recent

Embedded Features for 1D CNN-based Action Recognition on Depth Maps

541

Table 4: Comparative recognition performance of the proposed method with recent algorithms on MHAD dataset.

Method Modality Accuracy [%]

JTM (Wang et al., 2018) skeleton 85.81

SOS (Hou et al., 2018) skeleton 86.97

Kinect & inertial (Chen et al., 2015) skeleton 79.10

Struct. joint (Wang et al., 2017) skeleton 86.81

Struct. SzDDI (Wang et al., 2017) skeleton 89.04

WHDMMs+ConvNets (Wang et al., 2016)(Wang et al., 2017) depth 73.95

Proposed Method depth 87.91

skeleton-based methods to show that it outperforms

many of them. Our method is considerably better

than the WHDMM+3DConvNets method that employs

weighted hierarchical depth motion maps (WHDMMs)

and three 3D ConvNets. The WHDMMs are employed

at several temporal scales to encode spatiotemporal

motion patterns of actions into 2D spatial structures.

In order to provide sufﬁcient amount of training data,

the 3D points are rotated and then used to synthesize

new exemplars. In contrast, our algorithm extracts

deep features on single frames, and determines fea-

tures from time-series of such deep features, which

are concatenated with handcrafted features. The im-

proved performance of our method may suggest that

the proposed method has better viewpoint tolerance

in comparison to depth-based algorithms, including

(Wang et al., 2016).

Table 5 illustrates results that were achieved on

the 3DHOI dataset. As we can observe, the best re-

sults were achieved using SVM and hard voting in the

ensemble. Figure 6 illustrates the confusion matrix.

Table 5: Recognition performance on SYSU 3DHOI dataset

(LR - logistic regression, SVM - Support Vector Machine, H

- hard voting, S - soft voting).

class. vot. Accuracy

Preci-

sion

Recall

F1-

score

LR S 0.8289 0.8294 0.8289 0.8273

LR H 0.8640 0.8643 0.8640 0.8621

SVM S 0.9035 0.9077 0.9035 0.9039

SVM H 0.9254 0.9295 0.9254 0.9251

Table 6 presents results achieved by recent algo-

rithms on 3DHOI dataset in comparison to results

achieved by our algorithm. As we can observe, our

algorithm achieves the best results on this challenging

dataset. It is worth noting that method (Wang et al.,

2019) relies on depth and skeleton modalities, whereas

(Hu et al., 2019) additionally utilizes RGB images

jointly with the skeleton data.

We also performed evaluations of a modiﬁed algo-

rithm in which instead of statistical features of time

series we employed features extracted by a multi chan-

nel 1D CNN. As we can notice in Tab. 7 slightly worse

results have been achieved by such an algorithm on the

3DHOI dataset. The results on two remaining datasets

were also not better.

Figure 6: Confusion matrix on 3DHOI dataset.

Table 6: Comparative recognition performance of the pro-

posed method with recent algorithms on 3DHOI dataset.

Method Modality Acc.

[%]

MSRNN (Hu et al., 2019) depth+RGB+skel.

79.58

PTS (Wang et al., 2019) depth+skeleton

87.92

Proposed Method depth 92.54

Table 7: Recognition performance on SYSU 3DHOI dataset

achieved by algorithm with 1D CNN-based features instead

of statistical features (LR - logistic regression, SVM - Sup-

port Vector Machine, H - hard voting, S - soft voting).

class. vot. Accuracy

Preci-

sion

Recall

F1-

score

LR S 0.8684 0.8687 0.8684 0.8678

LR H 0.8509 0.8568 0.8509 0.8488

SVM S 0.9035 0.9091 0.9035 0.9039

SVM H 0.8026 0.8104 0.8026 0.8023

4 CONCLUSIONS

In this paper we presented a novel algorithm for hu-

man action recognition on depth maps. The novelty

comprises the use of convolutional autoencoder and

Siamese network to learn frame-features and then

multi-channel 1D CNNs to extract informative features

for depth map sequences. In order to cope with depth

map sequences with redundant depth maps, in which

the human pose are the same in some sub-sequences

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

542

for different classes we trained class-speciﬁc Siamese

neural networks and corresponding multichannel 1D

CNNs. The ﬁnal decision is taken on the basis of the

voting. The presented algorithm achieves promising

results in comparison to recent algorithms. It achieves

considerable gain in recognition accuracy on challeng-

ing SYSU 3DHOI dataset. We demonstrated experi-

mentally that our algorithm outperforms several recent

skeleton-based methods.

ACKNOWLEDGEMENTS

This work was supported by Polish National

Science Center (NCN) under a research grant

2017/27/B/ST6/01743.

REFERENCES

Bulbul, M., Islam, S., and Ali, H. (2019). 3D human action

analysis and recognition through GLAC descriptor on

2D motion and static posture images. Multim. Tools

Appl., 78(15).

Chen, C., Jafari, R., and Kehtarnavaz, N. (2015). UTD-

MHAD: A multimodal dataset for human action recog-

nition utilizing a depth camera and a wearable inertial

sensor. In IEEE ICIP, pages 168–172.

Chopra, S., Hadsell, R., and LeCun, Y. (2005). Learning a

similarity metric discriminatively, with application to

face veriﬁcation. In CVPR, pages 539–546.

Hadsell, R., Chopra, S., and LeCun, Y. (2006). Dimension-

ality reduction by learning an invariant mapping. In

CVPR, pages 1735–1742. IEEE Comp. Society.

Hinton, G. and Salakhutdinov, R. (2006). Reducing the

dimensionality of data with neural networks. Science,

313(5786):504 – 507.

Hou, Y., Li, Z., Wang, P., and Li, W. (2018). Skeleton optical

spectra-based action recognition using convolutional

neural networks. IEEE Trans. CSVT, 28(3):807–811.

Hu, J., Zheng, W., Lai, J., and Zhang, J. (2015). Jointly

learning heterogeneous features for RGB-D activity

recognition. In CVPR, pages 5344–5352.

Hu, J., Zheng, W., Ma, L., Wang, G., Lai, J., and Zhang,

J. (2019). Early action prediction by soft regression.

IEEE Trans. PAMI, 41(11):2568–2583.

Koch, G., Zemel, R., and Salakhutdinov, R. (2015). Siamese

neural networks for one-shot image recognition. In

ICML Deep Learning Workshop. vol. 2.

Li, W., Zhang, Z., and Liu, Z. (2010). Action recognition

based on a bag of 3D points. In CVPR Workshops,

pages 9–14.

Liang, B. and Zheng, L. (2015). A survey on human ac-

tion recognition using depth sensors. In Int. Conf. on

Digital Image Comp.: Techn. and Appl., pages 1–8.

Masci, J., Meier, U., Cire

s¸

an, D., and Schmidhuber, J. (2011).

Stacked convolutional auto-encoders for hierarchical

feature extraction. In ICANN, vol. I, pages 52–59.

Ren, B., Liu, M., Ding, R., and Liu, H. (2020). A survey on

3D skeleton-based action recognition using learning

method. arXiv, 2002.05907.

Wang, L., Huynh, D. Q., and Koniusz, P. (2020). A compar-

ative review of recent Kinect-based action recognition

algorithms. IEEE Trans. Image Process., 29:15–28.

Wang, P., Li, W., Gao, Z., Zhang, J., Tang, C., and Ogunbona,

P. (2016). Action recognition from depth maps using

deep convolutional neural networks. IEEE Trans. on

Human-Machine Systems, 46(4):498–509.

Wang, P., Li, W., Li, C., and Hou, Y. (2018). Action recogni-

tion based on joint trajectory maps with convolutional

neural networks. Knowledge-Based Syst., 158:43 – 53.

Wang, P., Wang, S., Gao, Z., Hou, Y., and Li, W. (2017).

Structured images for RGB-D action recognition. In

ICCV Workshops, pages 1005–1014.

Wang, X., Hu, J.-F., Lai, J.-H., Zhang, J., and Zheng, W.-S.

(2019). Progressive teacher-student learning for early

action prediction. In CVPR, pages 3551–3560.

Wu, Y. (2012). Mining actionlet ensemble for action recogni-

tion with depth cameras. In CVPR, pages 1290–1297.

Xia, L. and Aggarwal, J. (2013). Spatio-temporal depth

cuboid similarity feature for activity recognition using

depth camera. In CVPR, pages 2834–2841.

Xia, L., Chen, C.-C., and Aggarwal, J. (2012). View invari-

ant human action recognition using histograms of 3D

joints. In CVPR Workshops, pages 20–27.

Yang, X., Zhang, C., and Tian, Y. L. (2012). Recognizing

actions using depth motion maps-based histograms of

oriented gradients. In Proc. of the 20th ACM Int. Conf.

on Multimedia, pages 1057–1060. ACM.

Zheng, Y., Liu, Q., Chen, E., Ge, Y., and Zhao, J. L. (2014).

Time series classiﬁcation using multi-channels deep

convolutional neural networks. In Web-Age Informa-

tion Management, pages 298–310. Springer.

Zheng, Y., Liu, Q., Chen, E., Ge, Y., and Zhao, J. L. (2016).

Exploiting multi-channels deep convolutional neural

networks for multivariate time series classiﬁcation.

Frontiers of Computer Science, 10(1):96–112.

Embedded Features for 1D CNN-based Action Recognition on Depth Maps

543
