An Overview of Cryptographic Accumulators

Ilker Ozcelik

1,3 a

, Sai Medury

1,2 b

, Justin Broaddus

1,2 c

and Anthony Skjellum

1,2 d

1

SimCenter, University of Tennessee at Chattanooga, Chattanooga, U.S.A.

2

Department of Computer Science and Engineering, University of Tennessee at Chattanooga,

Chattanooga, Tennessee, U.S.A.

3

Department of Computer Engineering, Recep Tayyip Erdogan University, Turkey

Keywords:

Cryptographic Accumulator, Membership Test, RSA, Merkle Tree.

Abstract:

This paper contributes a primer on cryptographic accumulators and how to apply them practically. A cryp-

tographic accumulator is a space- and time-efﬁcient data structure used for set membership tests. Since it is

possible to represent any computational problem where the answer is yes or no as a set-membership problem,

cryptographic accumulators are invaluable data structures in computer science and engineering. But, to the

best of our knowledge, there is neither a concise survey comparing and contrasting various types of accumu-

lators nor a guide for how to apply the most appropriate one for a given application. Therefore, we address

that gap by describing cryptographic accumulators while presenting their fundamental and so-called optional

properties. We discuss the effects of each property on the given accumulator’s performance in terms of space

and time complexity, as well as communication overhead.

1 INTRODUCTION

There are many use cases where one might need to

maintain a list of elements with the purpose of deter-

mining whether an element being presented is part of

this list or not. A common example is a list of cre-

dentials that have been authorized and granted certain

privileges like an Access-Control List (ACL). During

Authentication, an account management system will

check to see whether the credentials entered are a part

of the ACL or not and grant/deny privileges accord-

ingly. If this list were small with only a few hundreds

of elements at any given time, it would not take long

to load the entire list into memory, compare each cre-

dential, and search for a match. The time complexity

of this algorithm scales linearly (O(n)) with the size

(n) of the list; therefore, it will perform poorly if the

list grows to a number in the hundreds of thousands

(and the performance is controlled by I/O speed, not

main memory speed if the list is sufﬁciently large).

We can reduce this complexity to sublinear (O(log n))

by doing certain pre-computations on the list, such as

by ordering it, then performing a binary search. Sub-

a

https://orcid.org/0000-0002-2032-1640

b

https://orcid.org/0000-0002-2349-8783

c

https://orcid.org/0000-0001-8540-997X

d

https://orcid.org/0000-0001-5252-6600

linear time complexity is an acceptable computational

complexity by Industry standards but there is substan-

tial overhead of sorting the elements that has the av-

erage computational complexity of O(n log n), which

increases the total computational complexity of the al-

gorithm to O(nlogn).

We can further reduce computation complexity

by trading off memory space by constructing auxil-

iary data structures like hashmaps with constant time

lookup complexity. This could be a great alternative

to pre-computation overhead and facilitates constant

time lookup, which is literally the best possible speed

up. However, this approach comes with an overhead

of having to store extra data in memory that will also

scale linearly (O(n)) with the size of the list. De-

pending on the memory size of the processing unit,

a SHA256 hashmap representing a list that contains

10 million elements may not ﬁt in the memory of a

low-energy and resource constrained devices.

A cryptographic accumulator can be used as an al-

ternative to search-based approaches. Cryptographic

accumulators are space-efﬁcient data structures that

rely on cryptographic primitives to achieve sublin-

ear time complexity for set membership operations.

They were ﬁrst proposed to solve document time-

stamping and membership testing purposes (Benaloh

and De Mare, 1993) Later, they were employed to im-

plement authenticated data structures (Ghosh et al.,

Ozcelik, I., Medury, S., Broaddus, J. and Skjellum, A.

An Overview of Cryptographic Accumulators.

DOI: 10.5220/0010337806610669

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 661-669

ISBN: 978-989-758-491-6

Copyright

c

2021 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved

661

2014; Goodrich et al., 2002) privacy-preserving (Sla-

manig, 2012) and anonymity-conscious (Camenisch

and Lysyanskaya, 2002; Miers et al., 2013; Sudarsono

et al., 2011) applications. Also, with the advent of

blockchain technology, demand for data to be stored

in a decentralized manner is rising rapidly and crypto-

graphic accumulators are well suited to support quick

constant-time set-membership testing on such data.

Cryptographic accumulators use novel probabilis-

tic data structures for set-membership that minimize

space complexity by compressing the hashmap using

a set of cryptographic functions into a constant size

bit-based data structures like the Bloom ﬁlter (Bloom,

1970), or its more recently proposed alternative called

the cuckoo ﬁlter (Fan et al., 2014). This compression

is lossy, inevitably giving rise to false positives from

possible collisions.

Alternatively, one can use a cryptographic accu-

mulator, a hash representative generated from the el-

ements in the list, that is of constant size and pro-

vides constant time lookup complexity without po-

tential false positives (Benaloh and De Mare, 1993).

These types of cryptographic accumulators are bet-

ter suited for distributed applications where a trusted

authority is responsible for continuously maintaining

the accumulator (hash representative); the trusted au-

thority keeps the accumulator up to date with addi-

tions and deletions of elements from the list. Partici-

pants other than this authority could be clients them-

selves that are part of the list or else be veriﬁers that

are trying to determine whether an element being pre-

sented is part of the list. Such cryptographic accumu-

lators, also called asymmetric cryptographic accumu-

lators (Kumar et al., 2014), additionally require the

generation of witnesses (Kumar et al., 2014) for each

element.

The witness is the value corresponding to an el-

ement that is required to verify an element’s mem-

bership in the accumulator (Kumar et al., 2014); it is

unique to each element and needs to be updated each

time an element is added or deleted to the accumula-

tor. This witness can also be communicated to the

client for storage and later presentation on-demand

to a veriﬁer. The trusted authority, often known as

the Accumulator Manager (AM) (Akkaya and Cebe,

2018), needs to perform O(n) operations to update the

witnesses of n elements for each new addition (resp,

deletion) of an element to (resp, from) the list; this

is the tradeoff for having virtually constant size com-

putation complexity and communication overhead be-

tween the veriﬁer, client, and AM for determining set-

membership. Most studies thus far regarding crypto-

graphic accumulators have been theoretical and focus

on their underlying theories. By carefully combing

through these studies and presenting a guide with a

gentler learning curve, this paper provides an accessi-

ble discussion for those who are interested in learning,

developing, and utilizing cryptographic accumulators

in their applications.

The remainder of this paper is organized as fol-

lows: Section 2 introduces the set membership prob-

lem and cryptographic accumulators. Different archi-

tectures of cryptographic accumulators and their clas-

siﬁcation are also presented in this section. Effects

of these optional features on accumulator operations

are discussed in Section 3, in terms of memory usage,

computational- and communicational-complexity. Fi-

nally, Section 4 concludes with a discussion of current

and potential applications.

2 CRYPTO-ACCUMULATORS

In computer science and engineering, set membership

tests (yes/no) tests) are used in many applications in-

cluding database, authentication, and validation sys-

tems.

Testing set membership can be performed by run-

ning a search on the set but this method can be a

resource intensive task as the set size increases. To

address these limitations, researchers proposed cryp-

tographic accumulators (Fan et al., 2014; Baldimtsi

et al., 2017; Tremel, 2013; Reyzin and Yakoubov,

2016). The fundamental idea behind the accumula-

tor is being able to accumulate values of a set A into

a small value z in such a way that it is possible to

prove only the elements of set A have been accumu-

lated (Fazio and Nicolosi, 2002).

2.1 Classiﬁcation

Cryptograph accumulators can be categorized as sym-

metric or asymmetric. Symmetric Accumulators (Ku-

mar et al., 2014) are designed using symmetric cryp-

tographic primitives and can verify membership of el-

ements without the need of a corresponding witness.

The Bloom ﬁlter (Bloom, 1970)—a type of array data

structure—is a symmetric cryptographic accumulator

that uses k-number of hash functions that set a unique

combination of indices in the array based on the in-

put element; it provides a limited representation of

set-membership with a false positive rate that grows

as the number of elements in the list approaches the

max capacity of the list (Bloom, 1970). Equation 1

provides the estimate of the false positive rate of a

simple Bloom ﬁlter construction:

FPR = (1 − [1 −

1

m

]

kn

)

k

≈ (1 − e

−kn

m

)

k

(1)

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

662

with m being the size of the array, k being the num-

ber of hash functions, and n being the number of ac-

cumulated elements. Variations of the Bloom ﬁlter

(Fan et al., 2014) have sought to minimize this false

positive rate but are unable to eliminate it entirely.

Because Bloom ﬁlters are static accumulators, they

cannot accommodate growing list sizes, so they must

be regenerated after reaching full capacity during the

transaction discovery process

The recently proposed cuckoo ﬁlter is a dynamic

data structure that functions similarly to the simple

Bloom ﬁlter but with additional capabilities such as

the ability to delete elements. A cuckoo ﬁlter im-

plements a cuckoo hash table (Fan et al., 2014) to

save ﬁngerprint representations of the elements in

an accumulated set. A cuckoo hash table is an ar-

ray of buckets in which each stored element is as-

sociated with two indices in the array. Two associ-

ated indices allow for the dynamic rearrangement of

the elements stored in the cuckoo hash table, provid-

ing optimized space efﬁciency and low false-positive

rates. For a given number of elements, a cuckoo ﬁlter

outperforms a space-optimized Bloom ﬁlter in terms

of false-positive rate and space overhead (Fan et al.,

2014).

Asymmetric Accumulators (Kumar et al., 2014)

require witness creation and update for dynamic ver-

iﬁcation of set membership (Baldimtsi et al., 2017).

They are built on asymmetric cryptographic primi-

tives (Baldimtsi et al., 2017) and require the underly-

ing hash algorithm to exhibit the quasi-commutative

property (Benaloh and De Mare, 1993). The RSA ac-

cumulator (Benaloh and De Mare, 1993) is one exam-

ple of asymmetric accumulator that uses RSA modu-

lar exponentiation to achieve the quasi-commutative

property. A simple RSA accumulator construction

consists of the following expression for addition:

acc

n

= acc

x

n−1

mod N where acc

n

is the new accu-

mulator value after addition, acc

n−1

is the old accu-

mulator value before addition, x is the element be-

ing added, and N = pq where p and q are considered

to be strong prime numbers whose Sophie Germain

prime numbers p

0

=

p−1

2

and q

0

=

q−1

2

are the accu-

mulator trapdoor. One drawback of an RSA accumu-

lator is that it is collision-free only when accumulat-

ing prime numbers. A prime representative generator

is required to accumulate composite numbers without

collision . The implementation of an RSA accumu-

lator by (Tremel, 2013) a random oracle prime repre-

sentative generator provided by (Bari

´

c and Pﬁtzmann,

1997) was used. Asymmetric accumulators can be

further classiﬁed based on operations supported and

the type of membership proofs provided. This classi-

ﬁcation will be further explained and analyzed in the

following sections.

A Merkle hash tree can also be implemented as an

asymmetric accumulator to prove Set Membership of

elements (Baldimtsi et al., 2017). It is classiﬁed as

an asymmetric accumulator because a member of its

set requires a witness to prove membership (or non-

membership). But, it does not use asymmetric cryp-

tographic primitives nor does it need the underlying

hash function to exhibit quasi-commutative property.

The root node of the Merkle Tree is called the Merkle

root and its value is the pairwise accumulated hash

of all of the non-root nodes in the tree. The Merkle

root value must be recalculated when there is an ad-

dition/deletion of a member in the set. Checking for

set membership can be done with a portion of the tree

(Merkle, 1989), making it unnecessary to download

the full data structure.

2.2 Architectures

There are two well known cryptographic accumula-

tor architectures: the one-way and the collision-free

accumulator.

2.2.1 One-way Accumulator

(Benaloh and De Mare, 1993) proposed the ﬁrst-

ever accumulator construction, known as the One-way

Accumulator, characterized as a family of one-way

hash functions with the additional quasi-commutative

property. A one-way hash function H is a function

that can accept an arbitrarily large message M and re-

turns a constant size output that is also called a mes-

sage digest MD. For H to be a one-way hash, it must

satisfy the following properties (Weisstein, a; Weis-

stein, b):

• The description of function H should be public

and should work without needing to know secret

information.

• For a message M, it must be easy to calculate its

message digest, MD = H(M).

• Given an MD, it must be difﬁcult to determine M

for a range where H is valid.

• For any M, the probability of ﬁnding an M

0

6= M

such that H

0

(M) = H(M) is negligible.

The quasi-commutative property is a generalization

of the commutative property. A function h deﬁned as

h : X ?Y ⇒ X holds the quasi-commutative (Benaloh

and De Mare, 1993) if ∀x ∈ X and ∀y

1

,y

2

∈ Y ,

h(h(x,y

1

),y

2

) = h(h(x, y

2

),y

1

). (2)

Despite using a strong one-way hash function (Fazio

and Nicolosi, 2002), Benaloh and de Mare’s accumu-

lator can be compromised if an attacker can choose a

An Overview of Cryptographic Accumulators

663

subset of the values being accumulated (Fazio and Ni-

colosi, 2002). (Bari

´

c and Pﬁtzmann, 1997) proposed

“Collision-free accumulators” to address this issue.

2.2.2 Collision-free Accumulator

The One-Way accumulators are elementary and ideal

for Set Membership, whereas collision-free accumu-

lators are more general (Bari

´

c and Pﬁtzmann, 1997),

and are better suited for designing Fail-Stop signature

schemes and Group Signatures. Collision-free accu-

mulators consist of an accumulator scheme that is de-

ﬁned together by 4 polynomial-time algorithms: Gen,

Eval, Wit and Ver.

The key generation algorithm Gen is used to gen-

erate the necessary key for a desired size accumulator,

which accepts a security parameter 1

λ

and accumula-

tor threshold value N. The threshold value deﬁnes the

maximum number of elements that can be accumu-

lated securely. Gen returns a key k from key space

K

λN

. The evaluation algorithm Eval is used to accu-

mulate elements of set A = y

1

,· ·· ,y

N

0

where N

0

≤ N.

It accepts the accumulator key k and values to be ac-

cumulated, y

1

,· ·· ,y

N

0

, as input. Eval returns the ac-

cumulated value z and an auxiliary information, aux

that will be used by other algorithms. It is important

to note that the Eval algorithm must return the same

z value for the same input, but it may generate dif-

ferent auxiliary information. The witness extraction

algorithm Wit generates the witness for a given in-

put. It accepts the accumulator key k, the input value

y

i

∈ Y

k

and the previous auxiliary and accumulator

value z generated by Eval. Wit returns a witness value

w

i

∈ W

k

to show input y

i

was accumulated. Otherwise

it returns the symbol ⊥. The veriﬁcation algorithm

Ver is used to test the existence of an element in an

accumulator; it accepts the accumulator key k, accu-

mulator z, input value y

i

, and its corresponding wit-

ness w

i

. Ver returns the value TRUE or FALSE.

The accumulator scheme is paired with the prop-

erty of collision freeness. Collision freeness ensures

that an adversary bounded by polynomial-time cannot

generate a set of values Y = y

1

,y

2

,· ·· ,y

N

that pro-

duces an accumulator value z that allows for a value

y /∈ Y and a witness w that allows for y to be proven

as a member accumulated in z.

(Bari

´

c and Pﬁtzmann, 1997) propose two theoret-

ical constructions of collision-free accumulators for

building Fail-Stop Signature schemes. There also ex-

ists a dynamic accumulator implementation by (Ca-

menisch and Lysyanskaya, 2002) that was inspired by

the Collision-Free accumulator architecture but meant

for set-membership testing.

2.3 Properties

Cryptographic accumulator properties are discussed

next.

2.3.1 Security Properties

There are four prominent security properties of asym-

metric cryptographic accumulators: soundness, com-

pleteness, undeniability and indistinguishability.

Soundness (aka Collision-Freeness) is deﬁned as

the probability of computing a membership witness

for an element that is not part of the accumulated

set or non-membership witness for an element part

of the accumulated set is negligible (Derler et al.,

2015). Completeness, (aka Correctness), property re-

quires that all honestly accumulated values be veriﬁed

as true with their respective witnesses with a negligi-

ble probability of error (Derler et al., 2015). An accu-

mulator is called undeniable if the probability of com-

puting a membership and non-membership witnesses

together, of the same input, is negligible. Undeni-

ability implies the collision-freenes property but not

all collision-free accumulators have the undeniability

property (Derler et al., 2015). Indistinguishability is

both a security- and privacy-related property. An ac-

cumulator is indistinguishable if no information about

the accumulated set is leaked by either the accumula-

tor or its witnesses. This can be achieved by either

accumulating a random value from the accumulation

domain or using a non-deterministic Eval Algorithm

(Derler et al., 2015).

2.3.2 Optional Crypto-Accumulator Features

Constructions can be optimized by selecting a subset

of available features. Each available feature comes

with a cost that can signiﬁcantly impact the system

design and implementation. Notable features are dis-

cussed next.

The set of accumulated elements is not always

static; new elements may be added to or removed

from this set over time. This is a common case for

applications requiring to grant / revoke the privilege

of a credential If an accumulator only supports addi-

tions, it is termed additive. Similarly, an accumula-

tor that only supports deletions is termed subtractive.

Addition and subtraction can be performed by redo-

ing the accumulation process after updating the set.

But, this approach is generally not practical, since re-

calculation takes polynomial time and depends on the

size of the accumulated set (Baldimtsi et al., 2017).

Dynamic accumulators are those that can efﬁciently

(in sublinear or constant time complexity) update the

accumulator and the respective witness values when a

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

664

new element is added to (resp, removed from) the ac-

cumulated set (Au et al., 2009). Accumulators that do

not support additions or deletions are termed static.

Accumulators are alo termed positive, negative, or

universal based on the type of membership proof(s)

they can support (Baldimtsi et al., 2017). Positive

accumulators only support set membership proof of

inclusion. Thus, for all elements in the accumu-

lated set, there exists an efﬁciently computable wit-

ness w. Negative accumulators can only support a

non-membership proof. For all elements that are con-

sidered non-members in regards to the accumulated

set, there exists an efﬁciently computable witness w

0

.

Lastly, a universal accumulator supports both mem-

bership and non-membership proofs (Li et al., 2007).

Zero Knowledge Proof (ZKP) is a privacy preserv-

ing membership proof used by cryptographic accu-

mulators. It was initially proposed by (Goldwasser

et al., 1989) in 1989. With ZKP, it is possible to show

the accuracy of a statement about a secret without

revealing the secret itself. This is possible because,

if one can compute the same output that the prover

provides by only accessing the input of the veriﬁer;

it should also be possible to compute the output be-

fore such interaction occurs. Therefore, through ZKP

systems, an honest veriﬁer need not interact with the

prover (Morais et al., 2018) to verify the accuracy of

a statement.

A single accumulator data structure alone won’t

be enough to implement ZKPs but two or more cryp-

tographic accumulator schemes can be used to imple-

ment ZKP system. Even with a combination of ac-

cumulators, the interaction mechanisms must be aug-

mented to carry out ZKPs. Additionally, these inter-

actions must be standardized to make all parties aware

of these mechanisms.

The zero knowledge property has been proven to

imply indistinguishability for cryptographic accumu-

lators (Ghosh et al., 2016). But, maintaining the in-

tegrity, zero knowledge property, and the efﬁciency of

the accumulator simultaneously is challenging. This

complexity can be reduced by restricting the accumu-

lator’s design to a trusted setup (Ghosh et al., 2016),

where the accumulator value is always maintained

by a trusted party. But, a trusted user is required to

generate a secret value called a trapdoor to compute

the accumulator and witness values efﬁciently. This

setup raises major security and centralization con-

cerns. But, there is no practical trapdoorless (strong)

accumulator that can produce constant-size proofs.

In trapdoorless accumulators, since the accumulator

manager is also considered untrusted, the witness size

grows at least like logN where N is the number of ac-

cumulated elements (Ghosh et al., 2016).

Applications can be either local, where only a sin-

gle entity / authority is responsible for proving mem-

bership, or distributed where multiple parties in a net-

work interact with each other. In the distributed case,

the communication channel between all relevant par-

ties becomes a bottleneck because membership wit-

ness additions or updates must be broadcasted each

time an element is added to or deleted from the accu-

mulator. To minimize this communication overhead,

asynchronous accumulators were proposed for dis-

tributed applications (Reyzin and Yakoubov, 2016).

The asynchronous accumulator relies on low up-

date frequency and compatibility with old accumula-

tor version (Reyzin and Yakoubov, 2016). An accu-

mulator has a low update frequency property, if the

witness of an element requires less number of updates

than the number of elements added after the element

(Reyzin and Yakoubov, 2016). Low update frequency

can be achieved only if it is additionally possible to

accurately verify membership using an outdated accu-

mulator value, in other words, the accumulator must

be backwards compatible. It is important to note that

the element tested for membership proof must be ac-

cumulated before the outdated accumulator value was

generated (Reyzin and Yakoubov, 2016).

3 COST-BENEFIT ANALYSIS

Security properties of cryptographic accumulators de-

ﬁne the reliability of the accumulator design. It is

expected for an accumulator to satisfy these proper-

ties. However, some of the features presented in Sec-

tion 2.3.2 are design choices rather than a necessity.

We encountered four major design choices in litera-

ture and each choice affects the implementation com-

plexity and overall accumulator performance. In this

section we will present and discuss effects of these de-

sign choices in terms of space complexity, time com-

plexity, and communication overhead.

In an application, the input set that needs to be

accumulated can be static, additive, subtractive or dy-

namic. A static set is a set whose list of elements do

not change through time. In an additive and subtrac-

tive sets, elements can only be added to or deleted

from the set respectively. A dynamic set refers to the

ability to both add and delete elements from the set. In

our discussion, static accumulators will be our base-

line and the system’s initial space, time complexities

and communication overhead will not be considered.

The effects of dynamic input set over system

space, time complexity and communication overhead

is presented in Table 1. This table is compiled consid-

ering major asymmetric cryptographic accumulators

An Overview of Cryptographic Accumulators

665

Table 1: The space-, time-complexity and communication

overhead in accumulators with input set changes. Indepen-

dent cases separated using vertical line (|) and mutually ex-

clusive cases separated using slash symbol (/).

Additive Subtractive Dynamic

Space Complexity

(Size

Acc

| Size

Wit

| Size

AM

)

O(1) | O(1) | O(1) O(1) | O(1) | O(N) O(1) | O(1) | O(N)

Time Complexity at AM

(Wit

Member

| Wit

Non−member

)

O(1) | O(N) O(N) | O(N) O(1) | O(N) | O(N)

Communication Overhead

At AM

O(1) O(N) O(1)|O(N)

with the exception of the tree based strong accumu-

lator, Merkle Tree. More information about Merkle

Tree based accumulators can be found in the discus-

sion about the accumulator manager (AM) trust.

When we evaluate space complexity based on

a dynamic input set, we will investigate accumula-

tor, witness and accumulator manager storage size

changes (see Table 1). Size of an asymmetric accumu-

lator can be speciﬁed using an accumulator threshold

value N during accumulator generation. This value

deﬁnes the upper bound on the total number of val-

ues that can be accumulated securely in the accumu-

lator (Fazio and Nicolosi, 2002). Adding and remov-

ing elements to/from these accumulators do not affect

the accumulator and witness size. On the other hand,

RSA and Bilinear Map based accumulators require a

trapdoor upon the initialization of the accumulators

themselves as well as during the deletion of a member

in the accumulated set. In otherwise trapdoorless con-

structions, accumulators’ manager storage can grow

proportional to the set size.

For every element added to the set, the accu-

mulator manager must update the accumulator value

and create a membership witness. The accumulator

manager must also update the accumulator value af-

ter each deletion of an element and provide a non-

membership witness if supported by the accumulator

construction. Accumulator update upon element ad-

dition and subtraction and generating a membership

witness for a new element are constant time processes

done by the accumulator manager. On the other hand,

generating a non-membership witness for RSA and

Bilinear Map accumulators requires more time pro-

portional to the number of elements in the set.

Asymmetric accumulators provide a constant ver-

iﬁcation and witness update time in case of an addi-

tion and subtraction of an element. However, the wit-

ness update process may cause a bottleneck in RSA

and Bilinear Map accumulators during element sub-

traction since the witnesses have to be updated by the

accumulator manager itself. However, there are pro-

posed constructions in the literature that allow for the

accumulated members to update their own witnesses

after deletion by using Bezout coefﬁcients (Baldimtsi

et al., 2017; Li et al., 2007).

Table 2: The space-, time-complexity and communication

overhead experienced by accumulator managers (AM) with

different membership proof types. Symbols a, d, and S

(a − d) denote the number of elements added, deleted, and

present respectively. ‘∼’ represents the range.

AM Complexity/Work Positive Negative Universal

Space Complexity O(1) ∼ O(d) O(S) O(S) ∼ O(a)

Time Complexity O(1) O(1) O(1) ∼ O(S)

Communication Overhead

O(d) ∼ O(a + d) O(a + d) O(a + d)

In synchronous accumulators, the AMs must

broadcast information about new elements to witness

holders. This communication overhead is minimized

in asynchronous accumulators, since witness hold-

ers need not update accumulator/witness value as fre-

quently. But, RSA and bilinear-map accumulators

experience additional communication complexity af-

ter element subtraction because of the queries from

witness holders needed to retrieve updated witnesses

from the accumulator manager.

Cryptographic accumulators can be positive, neg-

ative, or universal based on the membership proof

they provide. Positive Accumulators provide only

membership proofs to determine whether an element

has been accumulated to the set of members. Negative

accumulators, on the other hand, provide only non-

membership proofs to determine whether an element

has been accumulated to the set of non-members.

Universal accumulators can provide both member-

ship and non-membership proofs. Table 2 describes

the time complexity, space complexity, and commu-

nication overhead of an accumulator based on the

(non-)membership proof. They show the minimum

and maximum values observed across all membership

proof types. To identify generalized operations found

across a class of accumulators with similar applica-

tions, we limited the scope by selecting dynamic ac-

cumulators that require a trusted setup with an accu-

mulator manager (AM) and synchronized communi-

cation. Also, the values for the Merkle Tree accu-

mulator were omitted from Table 2; they will be dis-

cussed in the evaluation of Table 3.

The values in Table 2 convey the range of per-

formance, including bottlenecks, one may achieve by

utilizing positive, negative, or universal accumula-

tors. The Universal Accumulator has the highest com-

plexity in all three dimensions when compared with

(Strictly) Positive or (Strictly) Negative accumulators.

However, the time complexity in Universal Accumu-

lators may be reduced by implementing a separate ac-

cumulator of positive and negative types.

The space complexity for applying positive cryp-

tographic accumulators is of the order of O(1)

for positive accumulators with the exception of

BraavosB’s (Baldimtsi et al., 2017) construction, due

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

666

Table 3: The space-, time-complexity and communication

overhead in accumulators with Trusted AM and Untrusted

AM. Symbols a, d, and S (a − d) denote the number of

elements added, deleted, and present respectively.

Trusted AM Untrusted (Strong) AM

Space Complexity

(Size

Acc

|Size

Wit

|Size

AM

)

O(1) | O(1) | O(S) O(1) | O(loga) | O(a)

Time Complexity

(For all operations)

O(1) O(loga)

Communication Overhead O(a+d) O((a + d)loga)

to its reliance on the Range-RSA construction for ac-

cumulating deleted elements. For negative and uni-

versal accumulators, space complexity is generally

O(S), which is the number of elements that are part

of the accumulator at any given moment (not includ-

ing elements that were deleted).

The computation time complexities mentioned in

Table 2 show that all operations are typically of O(1)

except the NonMemWitCreate operation, which is the

most expensive operation if using Universal accumu-

lators built upon RSA and Bilinear Mapping crypto-

graphic algorithms.

The communication overhead is O(a + d) for dy-

namic accumulators, regardless of whether they are

positive or negative or universal, due to communica-

tion being required for Member Witness updates after

both additions and deletions of elements. For positive

accumulators like CL-RSA-B, Braavos or BraavosB

that are custom designed to minimize communica-

tion, the communication overhead is O(d) because

they don’t require communication after addition of el-

ements but only after deletion of elements.

Based on system requirements, a cryptographic

accumulator can be designed either on the foundation

of a trusted or untrusted accumulator manager. The

RSA and bilinear map implementations are restricted

to only trusted accumulator manager setups as a result

of their reliance on a secret trapdoor value for initial-

ization and constant time operations. The only known

family of accumulators that can be safely used in an

untrusted system are those based on Merkle Trees.

This is because Merkle Trees do not require trapdoor

values at any point during their operations.

Trusted accumulator manager systems use accu-

mulators that do not provide the strong accumulator

property. Accumulators based on RSA and bilinear

maps fall into these types of accumulators. As shown

in Table 3, trusted systems are relatively more scal-

able with O(1) time and space complexities. And,

similar to systems without trusted AM, the commu-

nication overhead grows linearly with the number of

member additions and deletions. However, systems

with trusted accumulator managers (AM) are central-

ized. The AM is required to maintain the integrity of

the accumulator by safeguarding the trapdoor value.

In case the trusted AM gets compromised, then the

entire system may be brought down. Acquisition of

the trapdoor value would allow an adversary to pro-

duce membership witnesses that are compatible with

the accumulator value even for non-accumulated ele-

ments, threatening the soundness of the accumulator.

This centralized infrastructure also limits the system’s

ability to distribute computational load, placing more

responsibility on the trusted accumulator manager.

Untrusted accumulator manager (AM) systems

use strong (trapdoorless) accumulators like Merkle

Trees. Their operations require O(loga) time com-

plexity; they produce witnesses of size O(log a), and

their communication overhead is of superlinear time

complexity of O((a + d) log a). Systems with un-

trusted AMs require relatively more space and can

be expensive to maintain. The size of a Merkle Tree

scales like O(a) and does not reduce in size after dele-

tions. Thus, the Merkle Tree will continue to grow

regardless of the number of deletions.

Advanced security is the main advantage of un-

trusted accumulator manager systems. The use of a

trapdoor is not required in a strong accumulator, and

the responsibility of maintaining the integrity of the

accumulated set is distributed amongst all participat-

ing untrusted accumulator managers. Further, he ab-

sence of a trapdoor allows for distribution of the com-

putational load among the untrusted managers and ac-

cumulated members.

An asynchronous accumulator must hold both the

low-update-frequency property and backwards com-

patibility property. To the best of our knowledge, the

only construction that provides a fully asynchronous

accumulator was deﬁned by (Reyzin and Yakoubov,

2016). Another asymmetric accumulator that exhibits

the low-update-frequency property but not the old ac-

cumulator compatibility property is the CL-RSA-B

accumulator, presented by (Camenisch and Lysyan-

skaya, 2002). We refer to accumulators that only hold

the low-update-frequency property as partially asyn-

chronous. These accumulators are notably only pos-

itive accumulators. But, we are not claiming that the

construction of a negative or universal asynchronous

accumulator is infeasible; this remains an open ques-

tion.

The asynchronous accumulator deﬁned by

(Reyzin and Yakoubov, 2016) takes the form of a

dynamic set of Merkle Trees. The number of Merkle

Trees grows by a factor of D = log

2

(n + 1). Each

subsequent Merkle Tree holds varying numbers of

members and the entire construction follows a com-

binatorial approach when additions are made (Reyzin

and Yakoubov, 2016). The beneﬁt of using this

An Overview of Cryptographic Accumulators

667

Table 4: The space-, time-complexity and communication overhead in accumulators with varying frequency in updates.

Symbols a, d, and S (a − d) denote the number of elements added, deleted, and present respectively. ‘∼’ represents the range

Partially

Asynchronous

(Trusted)

Asynchronous

(Untrusted)

Synchronous (Trusted & Untrusted)

Space Complexity

(Size

Acc

|Size

Wit

|Size

AM

)

O(1) | O(1) | O(1) O(log a) | O(loga) | O(a) O(1) | O(1) ∼ O(loga) | O(S) ∼ O(a)

Time Complexity

(For all operations)

O(1) O(loga) O(1) ∼ log a

Communication Overhead O(d) O(loga + log d) O(a + d) ∼ O((a + d) log a)

accumulator is the reduced communication overhead

by a factor of O(loga + logb), as shown in Table 4.

The asynchronous accumulator can also be applied in

decentralized, untrusted systems because of its strong

accumulator construction. The disadvantages are the

dynamic sizes of the accumulator value and witnesses

by a factor of O(loga). The accumulator manager

(AM) also requires storage of O(a). Veriﬁcation

takes O(log a) as well. To support deletion, a list of

all member values must also be stored and maintained

(Reyzin and Yakoubov, 2016).

The partially asynchronous variant in the form of

the CL-RSA-B accumulator has the advantage of con-

stant time operations and constant size accumulator

and witness values. It also only has to update wit-

nesses after a member is deleted from the set; witness

updates are not required after additions. For an ac-

cumulator scheme that is not expecting a signiﬁcant

number of deletions compared to additions, this fea-

ture is ideal because the communication overhead is

only d as shown in Table 4. The main drawback of a

partially asynchronous accumulator is its inability to

exhibit the old accumulator compatibility property, so

the most up-to-date accumulator value must be held.

Another disadvantage is its restriction to trusted ac-

cumulator schemes in which the trusted accumula-

tor manager is the only entity that can generate wit-

nesses upon the addition of new members and up-

date the accumulator value when a member is deleted.

This is due to the requirement of a trapdoor to per-

form deletions in a CL-RSA-B accumulator. Once

a member is deleted, the new accumulator value as

well as the deleted member’s ID is broadcasted to the

other members to update their respective witness val-

ues (Baldimtsi et al., 2017).

In comparison with synchronous accumulators,

overall system’s communication cost is reduced in

both asynchronous and partially asynchronous accu-

mulators. Synchronous accumulators never have a

communication overhead less than O(a + b). This is

because all witnesses must be updated after an mem-

ber addition or deletion in the set and witnesses are

incompatible with old accumulator values. The deci-

sion of which asynchronous accumulator type to pick

comes down to whether the system requires a trusted

or untrusted setup. Dynamic or static sizes of witness

and accumulator values should be taken into consid-

eration too.

4 CONCLUSION

We provided a concise guide on cryptographic accu-

mulators. We presented their security and optional

properties. Also, we discussed the effects of differ-

ent optional properties on accumulator performance

in terms of space, time, and communication complex-

ity.

Cryptocurrencies were early adopters of crypto-

graphic accumulators. Bitcoin uses a Bloom Filter for

set-membership testing of transactions (Bitcoin.org,

2020a) . Bitcoin also uses Merkle Block (Bitcoin.org,

2020b) to conﬁrm the validity of transactions without

having to download and/or maintain the entire copy

of blockchain by every participating node. In Ze-

rocoin (Miers et al., 2013), a CL-RSA-B based ac-

cumulator is implemented to represent a set of all

transactions that have been committed to blockchain

(Miers et al., 2013). The accumulator additionally

eliminates trackable linkage of addresses and facili-

tates anonymous and untraceable public transactions

(Miers et al., 2013).

Other applications of crypto accumulators in-

clude, but are not limited to, maintaining a certiﬁ-

cate revocation list, blacklisting or whitelisting user

credentials in an authentication system and generat-

ing important client groups such as lists of high risk

and/or bankrupt clients

Cryptographic accumulators can also help main-

tain dataset privacy while sharing. They can be im-

plemented to share and maintain a list of such users

without actually revealing their identities. This prop-

erty could simplify sharing critical data sharing with

third parties. Cryptographic accumulators can also be

used in ofﬂine ID veriﬁcation, credit score checking,

and medical-data veriﬁcation.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

668

ACKNOWLEDGMENTS

This material is based upon work supported by, or

in part by,the National Science Foundation (NSF)

under grants CCF-1562659, CCF-1562306, CCF-

1617690, CCF-1822191, CCF-1821431, and The Sci-

entiﬁc and Technological Research Council of Turkey

(TUBITAK). The views and conclusions contained

herein are those of the authors and should not be in-

terpreted as representing the ofﬁcial policies, views,

or endorsements, either expressed or implied, of the

NSF or TUBITAK.

REFERENCES

Akkaya, K. and Cebe, M. (2018). Efﬁcient public-key revo-

cation management for secure smart meter communi-

cations using one-way cryptographic accumulators. In

IEEE International Conference on Communications.

Florida International University.

Au, M. H., Tsang, P. P., Susilo, W., and Mu, Y. (2009). Dy-

namic universal accumulators for ddh groups and their

application to attribute-based anonymous credential

systems. In Cryptographers’ track at the RSA con-

ference, pages 295–308. Springer.

Baldimtsi, F., Camenisch, J., Dubovitskaya, M., Lysyan-

skaya, A., Reyzin, L., Samelin, K., and Yak-

oubov, S. (2017). Accumulators with applications

to anonymity-preserving revocation. In 2017 IEEE

European Symp. on Security & Privacy (EuroS&P),

pages 301–315. IEEE.

Bari

´

c, N. and Pﬁtzmann, B. (1997). Collision-free accumu-

lators and fail-stop signature schemes without trees.

In International Conference on the Theory and Appli-

cations of Cryptographic Techniques, pages 480–494.

Springer.

Benaloh, J. and De Mare, M. (1993). One-way accumula-

tors: A decentralized alternative to digital signatures.

In Workshop on the Theory and Application of of

Cryptographic Techniques, pages 274–285. Springer.

Bitcoin.org (2020a). Application of Bloom ﬁlters.

https://bitcoin.org/en/operating-modes-guide#

application-of-bloom-ﬁlters. [ Online; Ac-

cessed:March/2020 ].

Bitcoin.org (2020b). Merkleblock. https://bitcoin.org/

en/developer-reference#merkleblock. [ Online; Ac-

cessed:March/2020 ].

Bloom, B. H. (1970). Space/time trade-offs in hash coding

with allowable errors. Comm. of the ACM, 13(7):422–

426.

Camenisch, J. and Lysyanskaya, A. (2002). Dynamic

accumulators and application to efﬁcient revocation

of anonymous credentials. In Annual International

Cryptology Conference, pages 61–76. Springer.

Derler, D., Hanser, C., and Slamanig, D. (2015). Revisit-

ing cryptographic accumulators, additional properties

and relations to other primitives. In Cryptographers’

track—RSA conf., pages 127–144. Springer.

Fan, B., Andersen, D. G., Kaminsky, M., and Mitzen-

macher, M. D. (2014). Cuckoo ﬁlter: Practically better

than bloom. In Proceedings of the 10th ACM Interna-

tional on Conference on emerging Networking Exper-

iments and Technologies, pages 75–88.

Fazio, N. and Nicolosi, A. (2002). Cryptographic ac-

cumulators: Deﬁnitions, constructions and applica-

tions. Paper written for course at New York Univer-

sity: www. cs. nyu. edu/nicolosi/papers/accumulators.

pdf.

Ghosh, E., Ohrimenko, O., Papadopoulos, D., Tamassia, R.,

and Triandopoulos, N. (2016). Zero-knowledge accu-

mulators and set algebra. In International Conference

on the Theory and Application of Cryptology and In-

formation Security, pages 67–100. Springer.

Ghosh, E., Ohrimenko, O., and Tamassia, R. (2014). Ver-

iﬁable member and order queries on a list in zero-

knowledge. arXiv preprint arXiv:1408.3843.

Goldwasser, S., Micali, S., and Rackoff, C. (1989). The

knowledge complexity of interactive proof systems.

SIAM Journal on computing, 18(1):186–208.

Goodrich, M. T., Tamassia, R., and Hasi

´

c, J. (2002). An

efﬁcient dynamic and distributed cryptographic accu-

mulator. In Int. Conf. on Info. Security, pages 372–

388. Springer.

Kumar, A., Lafourcade, P., and Lauradoux, C. (2014). Per-

formances of cryptographic accumulators. In 39th An-

nual IEEE Conference on Local Computer Networks,

pages 366–369. IEEE.

Li, J., Li, N., and Xue, R. (2007). Universal accumula-

tors with efﬁcient nonmembership proofs. In Interna-

tional Conference on Applied Cryptography and Net-

work Security, pages 253–269. Springer.

Merkle, R. C. (1989). A certiﬁed digital signature. In Conf.

on the Theory and Application of Cryptology, pages

218–238. Springer.

Miers, I., Garman, C., Green, M., and Rubin, A. D. (2013).

Zerocoin: Anonymous distributed e-cash from bit-

coin. In 2013 IEEE Symposium on Security and Pri-

vacy, pages 397–411. IEEE.

Morais, E., van Wijk, C., and Koens, T. (2018). Zero knowl-

edge set membership.

Reyzin, L. and Yakoubov, S. (2016). Efﬁcient asynchronous

accumulators for distributed pki. In International

Conference on Security and Cryptography for Net-

works, pages 292–309. Springer.

Slamanig, D. (2012). Dynamic accumulator based discre-

tionary access control for outsourced storage with un-

linkable access. In Int. Conf. on Financial Crypto. &

Data Security, pages 215–222. Springer.

Sudarsono, A., Nakanishi, T., and Funabiki, N. (2011). Efﬁ-

cient proofs of attributes in pairing-based anonymous

credential system. In International Symposium on Pri-

vacy Enhancing Technologies Symposium, pages 246–

263. Springer.

Tremel, E. (2013). Real-world performance of crypto-

graphic accumulators. Thesis, Brown U.

Weisstein, E. W. One-way function. from Mathworld - a

Wolfram web resource. https://mathworld.wolfram.

com/One-WayFunction.html. [ Online; Accessed:

March/2020 ].

Weisstein, E. W. One-way hash function. from math-

world - a wolfram web resource. https://mathworld.

wolfram.com/One-WayHashFunction.html. [ Online;

Accessed: March/2020 ].

An Overview of Cryptographic Accumulators

669
