A Dynamic Access Control System based on Situations of Users

Hirokazu Hasegawa

and Hiroki Takakura

Information Security Ofﬁce, Nagoya University, Nagoya, Japan

Center for Cybersecurity Research and Development, National Institute of Informatics, Tokyo, Japan

Keywords:

Cyber Security, Targeted Attacks, Network Separation, Access Control, Telecommuting, Working from Home.

Abstract:

Recently, cyber attacks have been sophisticated and cause serious damages. As one of the solutions for miti-

gating the damages, the network separation and ﬁne granularity of access controls are effective against attacks.

However, the COVID-19 changes human work style, and telecommuting comes to be generally. It may give

many chances to attackers for invading the organization’s internal network by infecting user’s vulnerable home

terminals, which are out of control by the organization. To ensure the security of organizations, we propose

a dynamic access control system based on the situations of users. The system evaluates communications

based on the user’s risk and the importance of resources in destination terminals. When a user connects to

the organization network from the outside, the system dynamically changes the access controls according to

the evaluation results. The such situation requires stricter access controls than usual ones. For example, the

communication by the high-risk user and the communication to servers storing important resources are re-

stricted. By applying such dynamic access controls, the system enables us to ensure our network security with

maintaining the convenience of users telecommuting.

1 INTRODUCTION

Recently, cyber attacks have been so sophisticated

that it is difﬁcult to protect our networks completely.

Especially, targeted attacks, which is one of the cyber

attacks, cause serious damages. In the case of targeted

attacks that target speciﬁc governments or companies

and so on, its purpose is information theft or sabotage

activities. To achieve the purpose, attackers investi-

gate targets thoroughly in advance, and they prepare

dedicated malwares for the targets. Such malwares

slip through our traditional security measures for pre-

venting the intrusion of malwares.

Because of such a situation, recent counter-

measures has focused on the mitigation of dam-

ages by the attacks after the intrusion of mal-

wares(Cichonski et al., 2012). A separated net-

work is one of the most effective countermeasures

for targeted attacks(Information-technology Promo-

tion Agency, 2011). The separated network is a net-

work design to separate the internal network into

several segments and conduct ﬁne access controls

among separated segments. In the separated net-

work, access controls among segments can restrain

unintended communications by malwares. In addi-

tion, we can minimize the impact of the attack when

we detect malwares because we can isolate infected

hosts quickly. By applying the separated network, we

can effectively prevent attacks regardless of the types

of malwares. Recently, a lot of organizations apply

such network design for security measures, and also

the Cybersecurity and Infrastructure Security Agency

recommends network segmentation and unnecessary

communications limitation(Cybersecurity and Infras-

tructure Security Agency (CISA), 2020).

The separated network is an effective measure,

however, it is heavy burden for network administra-

tors to construct such network construction. To solve

such a problem, we have proposed several systems

to support the construction of the separated network.

Our previous system judges the necessity of commu-

nications in the organization network based on the

user’s access authority to ﬁles stored in servers. If

a user has no access authority against all ﬁles in the

server, the system prohibits communication between

the server and the user’s equipment. Furthermore, we

have also proposed a system that judges the neces-

sity of communication based on the analysis of cap-

tured packets. Our previous systems make it possible

to construct a separated network easily.

However, in 2020, the COVID-19 makes the

change to human’s work style. Almost all organi-

Hasegawa, H. and Takakura, H.

A Dynamic Access Control System based on Situations of Users.

DOI: 10.5220/0010327406530660

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 653-660

ISBN: 978-989-758-491-6

653

zations all over the world adopted telecommuting to

reduce the risk of employee virus infection. Orga-

nizations were forced to construct the environments

of the telecommuting quickly, therefore, many or-

ganizations adopted stopgap ways, e.g., employees

are forced to connect their organization’s network via

VPN.. In such cases, the security level may reduce

even if the separated network is constructed because

the client terminals running the remote desktop may

not secure.

To ensure the security of the organization network,

we have to dynamically change the access controls

based on the situation of the users not only on the

necessity of the communication. In other words, we

need to control the intensity of the access controls

based on the situation. For example, we should re-

strict the communication by a user according to the

situation of the user even if the communication is

judged as necessary and permitted in the ordinary sit-

uation. However, it is difﬁcult for network adminis-

trators to conduct such dynamic access controls.

Therefore, this paper proposes a dynamic access

control system based on the situation of users. The

system limits the communication according to the risk

of a user and the importance of accessible resources.

The system makes us possible to control access cor-

responding to various situations of the organization’s

employees and maintain the security of the networks

even if the way of working changes.

The rest of this paper is organized as follows: In

Section II, we introduce related works. Section III

presents the proposal system. In Section IV, we dis-

cuss the effectiveness of our proposed system. Fi-

nally, we conclude this paper in Section V.

2 RELATED WORKS

Because the separated network is effective in sup-

pressing malware activities, many research works

have done to construct separated networks.

Watanabe et al. proposed a VLAN conﬁguration

method(Watanabe et al., 2005). In this method, they

focused on the frequency of communications. When a

certain amount of trafﬁc among terminals is observed,

such terminals are coordinated into the same VLAN.

Nayak et al. proposed Resonance(Nayak et al.,

2009) that is a framework of dynamic access controls

based on the security policy. It also based on real-time

monitoring, and it can isolate suspicious terminals.

As the system proposed by Tian et al. (Tian et al.,

2019), Jinjing can read the network operator’s inten-

tion and update network ACL conﬁguration automat-

ically.

In our previous work, we proposed the system

supporting the construction of the separated network.

The system refers to the employees’ human resource

information and their access authorities to resources

in the organization, and it generates access con-

trols based on the collected information automati-

cally. Moreover, to increase the accuracy of the access

control, the system also refers to the network trafﬁc to

judges the necessity of the communication.

However, these researches focus on preventing

unnecessary or malicious communications, therefore,

the communication judged as necessary is always per-

mitted in the network. For example, although our

previous system can follow the personnel changes or

changes of access authorities and can dynamically up-

date the access controls because it automatically gen-

erates access controls based on the collected informa-

tion, the system always permits necessary communi-

cation.

On the other hand, as described in Section 1, we

need ﬂexible access controls according to the user’s

situation. There are many researches of constructing

secure network for the Internet of Things (IoT) (At-

lam et al., 2017)(Rath and Colin, 2017). The recent

network situation, in which telecommuting forces al-

most every user to connect to the resources from the

external network, is an unexpected structure in con-

ventional networks. As with the IoT network, we

need a new construction method of the secure net-

work from the different viewpoint of conventional

networks.

In recent years, methods of network conﬁguration

have been improving. As one of such methods, Soft-

ware Deﬁned Networking (SDN) is often studied. As

Nguyen and Kim proposed(Nguyen and Kim, 2016),

we can ﬂexibly manage a large scale network, e.g.,

campus networks, by using SDN technics. By using

such methods, we can conﬁgure the network ﬂexibly.

Therefore, we propose the method to judges the per-

mission of users according to the situation.

3 PROPOSED SYSTEM

In this paper, we propose a dynamic access control

system based on the situation of users. When a user

connects to the internal network from the outside net-

work via the internet, the system dynamically assigns

the ACL different from the usual ACL.

3.1 Assumption

First of all, the proposed system assumes a network

that is separated into several segments and managed

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

654

ﬁne access controls. For example, we assume the or-

ganization network constructed by our previous sys-

tem, and all clients in the network can conduct only

necessary communication.

As similar to the conventional networks, there are

several ways for users to connect the resources on the

separated network from the outside of the organiza-

tion network. As one of the simple ways, for example,

a user connects to the organization’s internal network

via VPN and uses his/her own client in the ofﬁce by

the remote desktop applications, e.g., Microsoft Re-

mote Desktop. Otherwise, a user uses the terminal in

the home by directly connecting to the organization

network via VPN.

Because this paper focuses on the precise access

control supposing telecommuting, the control to users

at an ofﬁce is out of scope. Thus, to simplify the dis-

cussion, it is assumed that all users connect to their of-

ﬁce PCs by the remote desktop applications via VPN,

and our system can identify their situation based on

access information of VPN servers.

3.2 System Overview

The proposed system classiﬁes the usually permitted

communications concerning the connected user into

three types shown below by evaluating the security

risk of communication. According to the classiﬁed

result, the system generates the new ACL automati-

cally.

• Conventional

Communication permitted like a user at the ofﬁce.

• Temporal

Communication permitted within a certain period.

The period is automatically calculated by the pro-

posed system.

• Restriction

Communication permitted only when a responsi-

ble person permits.

3.2.1 Evaluation of Communications

The system evaluates the security risk of each com-

munication usually permitted to conduct by a user and

decides its type based on the evaluation results. The

system deﬁnes the RC

as the risk of communication

c. To evaluate RC

, the system applies two factors,

i.e., risk of users and importance of resources.

The ﬁrst factor is the risk of users because a secu-

rity incident is sometimes caused by human error. To

calculate the risk of users, the system uses the mail

quarantine log and the security log. The mail quar-

antine log indicates the volume of deleted malicious

messages. If the volume of deleted malicious mes-

sages against the user is high, the user has a high risk

of malware infection. The security log includes var-

ious logs concerning the user. In this paper, we take

the incident logs that the user caused, malicious activ-

ities, and the learning state of the information security

seminar. However, the system can apply various types

of information to calculate the risk depending on the

actual environment. If a user caused a security inci-

dent previously, the system considers the user as high

risk. Similarly, the malicious activity of the user, e.g.,

he/she neglects to perform security updates, is taken

into account in risk calculation. In addition, the sys-

tem checks the learning state of employee education

about information security by the organization, and

the system treats the user as high risk if the user has

not taken the education.

The system deﬁnes RU

as the risk of the user u. In

addition, the system uses M

as the parameter for the

maximum value of RU

. To simplify the discussion of

the paper, we set 100 to M

. In this paper, we use the

mail quarantine log, the incident log, the malicious

activities, and the learning state, and we call each of

these is a user concerning content.

To calculate the RU

, the system calculates that

100 (the parameter M

) divides by the total number

of the user concerning contents in advance, and it

treats the calculated number as the maximum value of

the risk of each user concerning contents. In this pa-

per, we use four user concerning contents, therefore,

the maximum value of each risk comes to 25. Then,

the system calculates each risk of the user concerning

contents.

As the risk of malicious messages, the system ap-

plies the ratio of malicious messages to total receiving

messages. Therefore, the system obtains the risk of

malicious messages by the multiplication of the ratio

of malicious messages and 25 (the maximum value of

the risk).

Then, as the calculation of risk of the incident log

which the user caused, the system checks all incident

logs. Generally, the incident log includes the contents

of the incident and its severity. According to the level

of severity, the system calculates the risk of incidents

caused by the user. The system divides the maximum

value of the risk of a user concerning content by the

total number of such levels. Then, by multiplication

of the calculated number and the level of the severity,

the system calculates the risk value of the incidents.

For example, as shown in Figure 1, when an organi-

zation deﬁnes the 4 levels of severity, the system cal-

culates the sum of 1, 2, 3, and 4, and divides 25 by

it.

A Dynamic Access Control System based on Situations of Users

655

Severity

SUM

Maximum Value of the Risk

of a User Concerning Content

Risk Value of

Incidents

2.5

5.0

7.5

10.0

X Severity

Figure 1: Calculation example of the risk of incidents.

Then, the risk value of each incident level ob-

tained by the multiplication of the calculated number

and the level of the severity. If the incident report con-

cerning the user is detected, the risk value of the inci-

dent is added regardless of the number of incidents.

The malicious activity of the user directly indi-

cates the credit of the user. If the user conducted ma-

licious activity, even if it is once, the system adds the

maximum number of the risk.

Generally, an organization conducts the education

of basic knowledge about information security to em-

ployees. The system simply judges the risk of users

by checking whether he/she attended the lecture or

not. The style or contents of education depends on

the organization. Therefore, the system calculates

that 25 divides by the total number of educations con-

ducted by the organization, and it obtains the risk of

the learning state by multiplication of the calculated

number and number of the absence of the user.

The system obtains the RU

by the sum total of the

user concerning contents. (0 ≤ RU

≤ 100)

The second factor is the importance of resources.

Generally, an organization assigns importance to each

ﬁle treated in the ofﬁce. Based on the importance, the

access authority is assigned. For example, only a re-

sponsible person can treat a conﬁdential ﬁle, which

has very high importance. The system deﬁnes the I

as the importance of the resource r, and sets its mini-

mum value to zero and maximum value to M

. Simi-

lar to M

, we set 100 to M

in this paper. The system

converts the value of the importance of the resource r

decided by the organization to I

by adjusting a ratio.

Finally, the system earns RC

by Equation (1).

= RU

× I

(0 ≤ RC

≤ 10000) (1)

By using obtained RC

, the system decides the ac-

cess control of communication c. To decide the access

control, network administrators have to set and adjust

two parameters, i.e., th

and th

, in advance according

to the security policy of the organization.

The th

is the threshold to treat communication as

holding a certain risk. Only when RC

is less than

, communication c is permitted access similar to

regular permission.

The th

is the threshold to judge whether the sys-

tem permits communication or not. If the RC

higher than th

, the system decides that the commu-

nication c has high risk, and judges to restrict it. Only

when a responsible person permits communication,

the system resumes permission of the communication.

If the RC

is higher than th

and less than th

, the

system permits communication for a certain period.

The system deﬁnes the permitting time PT

as a pe-

riod for permitting communication c, and it calculates

the permitting time by Equation (2).

× T (2)

In this equation, the T is the parameter to adjust the

permitting time according to the work style of the or-

ganization. The value of T is different for each or-

ganization. For example, in an organization in which

users need to exchange big size data, the network ad-

ministrator set a big value to the T .

3.2.2 Example of Evaluation

We introduce the example of an evaluation. As shown

in Figure 2, we assume two users. In the organization,

the severity of the incident is assigned to 4 levels sim-

ilar to Figure 1.

The user A receives 1,500 messages including 30

malicious messages, and he has no concerning inci-

dent log and malicious activity. In addition, he com-

pletely attended the learning by the organization. In

this situation, the RU

comes to be 0.5.

On the other hand, the user B receives 800 mes-

sages including 40 malicious messages, and he caused

the incident in which severity is 4. Moreover, he con-

ducted the malicious activity in advance, and he was

absent from three lectures. The risk of the user B is

high, and the RU

comes to be 51.25.

When the user A and the user B access the ﬁle a

and the ﬁle b, the system calculates the risk of such

communication. For example, the organization as-

signs I

= 90 and I

= 10.

In this case, the risk of communication RC is cal-

culated, as shown in Figure 2. In addition, the organi-

zation sets value of each parameter as shown in Table

Table 1: Value of parameters.

Parameter Value

500

4500

T 6000

Finally, the system decides that the communica-

tion from the user A to the ﬁle a and the ﬁle b is per-

mitted and the communication between the user B and

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

656

User A

User B

Message

Total Malicious

1,500 30

800 40

Incident

Report

NONE

Severity 4

Malicious

Activity

NONE

✔

Learning

State

5 / 5

All Attended

2 / 5

3 Absences

= 025 x (30 / 1500) + 0+

= 0.5

25 x (40 / 800) + 25+ 5 x 3+ = 51.25

File a (Conﬁdential)

= 90

File b

= 10

When the User A accesses File a Communication Aa

= 0.5 x 90 = 45

= 0.5 x 10 = 5

= 51.25 x 90 = 4612.5

= 51.25 x 10 = 512.5

Threshold th

= 500 , th

= 4500 , Parameter T = 6000

, RC

< th

Permitted

< RC

< th

Temporarily

Permitted

< RC

Restricted

= 1 / 512.5 x 6000 = 11.7

Figure 2: Example of the evaluation.

the ﬁle b is permitted for 11 minutes. The communi-

cation between the user B and the ﬁle a is restricted

by the system.

3.3 Architecture

Figure 3 shows the architecture of the proposed sys-

tem. The system consists of seven modules and one

database.

3.3.1 Log-on/out Detector

First of all, when a user connects to the VPN server in

the ofﬁce, the log of the connection is sent to the Log-

in/out Detector module. If the received log indicates

the log-in of the user, the module sends the log-in in-

formation which includes the user’s information to the

User’s Risk Calculator module. On the other hand, if

the log indicates the user’s log-out, the module sends

the log-out information to the Termination Manager

module.

3.3.2 User’s Risk Calculator

User’s Risk Calculator calculates the risk of users.

When the module receives the user’s log-in informa-

tion, it investigates the human resource information

and his/her client information by using the directory

service server.

Then, the module ﬁnds out the mail quarantine

month, to investigate the reception of malicious e-

mails against the user’s e-mail address. Moreover, it

receives the security log concerning the user from the

database in the network. The security log includes the

previous incident report, malicious activity, and learn-

ing state of the seminar about information security.

By using the obtained information, the module

calculates the risk of the user. Finally, it sends the risk

of the user in addition to the human resource informa-

tion and client information to ACL’s Risk Calculator.

3.3.3 ACL’s Risk Calculator

ACL’s Risk Calculator calculates the risk of access

controls concerning the user’s client. When it re-

ceives client information, it ﬁnds concerning access

controls that permit access to the resources about the

client from the applied ACL. Moreover, it investigates

the importance of each resource in which each access

control permits access from the clients.

After the investigation of resource importance, the

module calculates the risk of each access control.

Then, if the calculated risk of access control exceeds

the threshold th

, the module generates the new ACL,

which does not include the access control permitting

access to the resources.

In addition, the module investigates the recent ac-

cess situation to the resources from the client by using

mirrored packets stored in Packet Collector. Even if

the risk of access control does not exceed the thresh-

old, the system restricts the communication when the

client has not accessed the resources.

If the risk of access control is less than the thresh-

old th

, the module calculates the permitting time in

order to permit the communication for a short period

when the user tries to communicate.

Finally, the module registers the generated new

ACL and the permitting time to Dynamic ACL DB

and sends it to Conﬁgurator, and then, Conﬁgurator

conﬁgures the network equipments in the organiza-

tion.

3.3.4 Packet Collector

Packet Collector module receives mirrored packets in

the network and stores them in the database. When

A Dynamic Access Control System based on Situations of Users

657

Mail Quarant ine

Log

VPN

Server

User

Connect ion

Log

Packet

Collector

Mirrored Pac k et s

/ Restriction Log

Configurator

Config

Mail

Gateway

Directory

Service

Security

Information

User’s Risk

Calculator

Log-in

Info

Human Resourc e

/ Client Info

Security Log

ACL’s Risk

Calculator

ACL /

Resourc e

Importance

Human Resourc e

/ Client Info

/ User’s Risk

Packet

Dynamic

ACL DB

Temporary ACL

Generator

Limited

Packet

Termination

Manager

Log-in/out

Detector

Log-out

Info

Deleting ACL

Inserting ACL

Condition

Confirmat ion

Inserting ACL

Deleting ACL

Temporary ACL

Proposed System

Organization Network

Respons ible

Person

Confirmat ion

The

Internet

Figure 3: Architecture of the proposed system.

ACL’s Risk Calculator ﬁnds the packets concern-

ing the client, Packet Collector ﬁnds them from the

database and sends the found packets to ACL’s Risk

Calculator module.

In addition to the mirrored packets, the module re-

ceives restriction logs of network equipments. The

logs include the communication restricted by the pro-

posed system, and a part of them will be permitted for

a short period. When the communication is restricted

by the ACL generated by the proposed system, the

module sends the log of such communication to Tem-

porary ACL Generator module.

3.3.5 Temporary ACL Generator

Temporary ACL Generator module receives packets

which restricted by the proposed system, and then,

it inquires the condition of permission about such

packet to Dynamic ACL DB.

If the permitting time is registered, the module

sends the ACL including permission of the restricted

communication to Conﬁgurator and it measures the

time. After the permitting time passes, the module

sends the new ACL to Conﬁgurator again in order to

restore the ACL.

On the other hand, if the permitting time is not

registered, such communication is judged should be

restricted by the proposed system. If the communica-

tion is usually permitted for users at ofﬁce, the system

asks a responsible person whether permit or not. If

permitted, the module sends new ACL to Conﬁgura-

tor module.

3.3.6 Termination Manager

When Log-in/out Detector module conﬁrms the log-

out of a user, it sends such log-out information to

Termination Manager module. Termination Manager

module ﬁnds the access controls concerning the user

from Dynamic ACL DB, and then, it deletes found

access controls from Dynamic ACL DB and sends a

new ACL to Conﬁgurator module to restore the orig-

inal ACL.

4 VERIFICATION OF THE

PROPOSED SYSTEM

In this section, we discuss about veriﬁcation of the

proposed system. As a veriﬁcation experiment, we

compare the proposed system to simple separated net-

work and ﬂat network in the assumed scenario. We

assume the scenario that a user, who is judged to have

a high risk and his home device is infected by mal-

ware, telecommutes by connecting to the internal net-

work via VPN. In addition, the attacker remotely con-

trols the infected host to attack organization’s internal

network.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

658

4.1 Security Effectiveness

From the viewpoint of security effectiveness, we dis-

cuss resource protection and harmful effects on other

devices. Figure 4 shows the accessible area from a

user.

When an organization does not apply the sepa-

rated network, the user can communicate with all

other terminals. In this case, all terminals have the

risk of attack via the internal network connection. In

addition, the attacker can access resources to which

the user has access authority and resources with no

authentication, therefore, a lot of resources have the

risk of leakage.

On the other hand, if the separated network is

constructed, the proposed system supposes such net-

works, the attacker can access to the only user con-

cerning servers and terminals. In other words, the

number of terminals which has the risk to be targeted

by the attack decreases. Besides, only the resources

that authorize the user are communicated by the user’s

terminal. The separated network can reduce the risk

of attacks.

By the proposed system, accessible resources and

terminals are strictly limited. Only ordinarily used re-

sources that have moderate importance are accessible

by the user. The high important resources are pro-

tected by access controls.

When the user works at the ofﬁce as usual, we

have several chances to detect the malicious activi-

ties controlled by external attackers targeting impor-

tant resources by the IDS or the network quarantine

logs and so on. However, when the terminal in the of-

ﬁce is remotely controlled from the user’s home, it is

difﬁcult to distinguish whether it is conducted by the

genuine user or the attacker. Therefore, the communi-

cation limitation according to the situation of the user

is effective.

Accessible Area

Resource Other Equipment

Without

Access Control

Separ ated

Network

Sep arated Network

with Dynamic Access Control

All other

Servers, Terminals

Concerning

Servers, Terminals

Limited

Servers,

Terminals

All Resources

(with no Authentication)

Concerning

Resources

Limited

Resources

Figure 4: Accessible resources and equipments from a user.

4.2 Accessibility Effectiveness

From the viewpoint of accessibility effectiveness, the

proposed system can provide effective access con-

trol. Generally, to ensure security, organizations re-

strict the communication to important information by

telecommuting. Such restriction is conducted under

uniform conditions against all users in the organiza-

tion. It can protect important information, however,

the convenience of users decrease.

There are low-security awareness users in the or-

ganization, therefore it is effective against such users.

However, for high-security awareness users, it is an

onerous restriction. In the assumed scenario, the in-

fected terminal is restricted to access the important in-

formation, however, other terminals are similarly re-

stricted to conduct communication.

The proposed system judges access controls ac-

cording to the situation of users, therefore, it can ap-

ply ﬂexibly access controls. For example, the high-

security awareness user can access the resources from

home almost the same as the ofﬁce. On the other

hand, a low-security awareness user is restricted to

access the resources, however, the methods of tempo-

rary permission of communication and permission by

a responsible person can improve the convenience of

users and business continuity.

5 CONCLUSIONS

In this paper, we proposed a dynamic access control

system based on the situation of users. The COVID-

19 changes the human work style, and working from

home comes to be a more generic style. To ensure

the organization’s network security to which a lot of

clients connect from home, we have to ﬂexibly change

the access controls in the network according to the sit-

uation of users. The proposed system makes such dy-

namic access control possible by evaluating the risk of

the user and the importance of communication desti-

nation resources. Based on the evaluation results, the

system dynamically changes the permission of com-

munication, i.e., no change, permitting for a certain

period, restricting. We can reduce the risk of attack

against important resources, and ensure the security

of organization networks.

In future works, we will implement the system and

deploy it to a large-scale experimental network for

evaluation of the system. In addition, we will extend

the system to focus on the access authority of ﬁles.

When a server stores a high important resource, the

proposed system may restrict the communication be-

tween a user and the server even if the user wants to

A Dynamic Access Control System based on Situations of Users

659

access the other low important resource because the

proposed system focuses only on the network access

controls. To solve such a problem, we will extend

the proposed system to conduct more ﬂexible controls

by collaborating network access and user’s access au-

thority to resources.

ACKNOWLEDGEMENT

Part of this work is supported by the Cabinet Ofﬁce

(CAO), Cross-ministerial Strategic Innovation Pro-

motion Program (SIP), “Cyber Physical Security for

IoT Society” (funding agency: NEDO).

REFERENCES

Atlam, H. F., Alenezi, A., Walters, R. J., and Wills, G. B.

(2017). An overview of risk estimation techniques in

risk-based access control for the internet of things. In

Proceedings of the 2nd International Conference on

Internet of Things, Big Data and Security - IoTBDS,,

pages 254–260. INSTICC, SciTePress.

Cichonski, P., Miller, T., Grance, T., and Scarfone, K.

(2012). Computer Security Incident Handling Guide.

NIST Special Publication 800-61 Revision 2.

Cybersecurity and Infrastructure Security Agency (CISA)

(2020). Alert (AA20-280A) Emotet Malware.

URL: https://us-cert.cisa.gov/ncas/alerts/aa20-280a

[accessed: 2020-10-29].

Information-technology Promotion Agency, J. (2011). De-

sign and Operational Guide to Protect against “Ad-

vanced Persistent Threats” Revised 2nd edition. URL:

https://www.ipa.go.jp/ﬁles/000017299.pdf [accessed:

2020-10-29].

Nayak, A. K., Reimers, A., Feamster, N., and Clark, R.

(2009). Resonance: dynamic access control for enter-

prise networks. In Proceedings of the 1st ACM work-

shop on Research on enterprise networking, pages 11–

18.

Nguyen, V.-G. and Kim, Y. (2016). Sdn-based enterprise

and campus networks: A case of vlan management.

JIPS, 12(3):511–524.

Rath, T. A. and Colin, J.-N. (2017). Adaptive risk-aware

access control model for internet of things. In 2017

International Workshop on Secure Internet of Things

(SIoT), pages 40–49. IEEE.

Tian, B., Zhang, X., Zhai, E., Liu, H. H., Ye, Q., Wang,

C., Wu, X., Ji, Z., Sang, Y., Zhang, M., et al. (2019).

Safely and automatically updating in-network acl con-

ﬁgurations with intent language. In Proceedings of the

ACM Special Interest Group on Data Communication,

pages 214–226.

Watanabe, T., Kitazaki, T., Ideguchi, T., and Murata, Y.

(2005). A Proposal of Dinamic VLAN Conﬁgura-

tion with Trafﬁc Analyzation and Its Evaluation Using

a Computer Simulation (in Japanese). IPSJ Journal,

46(9):2196–2204.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

660
