Evaluation of Vulnerability Reproducibility
in Container-based Cyber Range
Ryotaro Nakata
a
and Akira Otsuka
b
Institute of Information Security, Yokohama, Kanagawa, Japan
Keywords:
Information Security Education, Cyber Range, Container-based Virtualization, Docker, Vulnerability.
Abstract:
The cyber range is a practical and highly educational information security exercise system, but it has not been
widely used due to its high introduction and maintenance costs. Therefore, there is a need for a cyber range
that can be adopted and maintained at a low cost. Recently, container type virtualization is gaining attention
as it can create a high-speed and high-density exercise environment. However, existing researches have not
clearly shown the advantages of container virtualization for building exercise environments. Moreover, it is not
clear whether sufficient vulnerabilities are reproducible, required to conduct incident scenarios in the cyber
range. In this paper, we compare container virtualization with existing virtualization type and confirm that
the amount of memory, CPU, and storage consumption can be reduced to less than 1/10 of the conventional
virtualization methods. We also compare and verify the reproducibility of the vulnerabilities used in common
exercise scenarios and confirm that 99.3% of the vulnerabilities are reproducible. The container-based cyber
range can be used as a new standard to replace existing methods.
1 INTRODUCTION
With the development of ICT technology, the scale
and impact of cyber-attacks continue to increase
worldwide.On the other hand, the shortage of human
resources for security is pointed out, and the gov-
ernment and higher education institutions are making
various efforts for human resource development. Still,
the quantitative and qualitative shortage has not been
solved (Maki et al., 2020).
Information security skills can be effectively
learned through education using cyber ranges. The
cyber range is a large scale exercise system for learn-
ing by experiencing real security incidents in an or-
ganization in a virtual environment that simulates a
real-world system. Although the educational effect is
high, the cyber range’s introduction and maintenance
are millions of dollars (Razvan et al., 2017).
Although the effectiveness and necessity of cyber
ranges are recognized, it is difficult for educational
institutions to implement and maintain them indepen-
dently. Therefore, a low-cost training environment is
needed, and the use of container type virtualization is
attracting attention (Irvine et al., 2017).
a
https://orcid.org/0000-0001-8885-848X
b
https://orcid.org/0000-0001-6862-2576
However, previous research does not show the ad-
vantages of container type virtualization in concrete
terms. Containers are not suitable for recreating real-
istic environments and are generally considered to be
limited to specific applications. As a result, most ex-
isting cyber range products and educational research
use other virtualization types (Razvan et al., 2017).
This paper uses a container-based cyber range en-
vironment to examine the differences between virtu-
alization types and confirm the performance benefits
of container type virtualization in cyber range. We
also describe the results of our comparison with other
virtualization types by applying vulnerability check-
ing tools and attack programs to see how well the vul-
nerabilities and incidents in commonly used exercise
scenarios can be reproduced in cyber range exercises.
2 THE CYBER RANGE
2.1 Definition of Cyber Range
The cyber range is a system to build and provide an
environment for information security exercises. For
smooth implementation of the exercises, with the fol-
lowing functions.
Nakata, R. and Otsuka, A.
Evaluation of Vulnerability Reproducibility in Container-based Cyber Range.
DOI: 10.5220/0010324606350642
In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 635-642
ISBN: 978-989-758-491-6
Copyright
c
2021 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
635
Creating a realistic system environment
The system environment can be faithfully repro-
duced as it is used in the real world.
Duplicate or replace the environment
Exercise environments can be reset, replicated, or
replaced flexibly and quickly.
Reproduction of vulnerabilities and incidents
Vulnerable environments and actual malware can
be used to recreate security incidents and execute
attack and defense scenarios.
These functions are made possible by virtualiza-
tion technology (Costa et al., 2020).
2.2 Typical Cyber Range Scenarios
In the cyber range exercise, various scenarios will be
developed depending on the learning objectives and
the student’s level. Figure 1 shows a network envi-
ronment that reproduces a typical attack scenario.
Figure 1: Example of a virtual network for cyber range.
In the cyber range, reproduce vulnerabilities in
web servers, DB servers, client devices, etc., to carry
out the scenario. Also, security devices such as fire-
walls, IDS/IPS, etc. will be installed, depending on
the exercise’s nature. To execute scenarios in the cy-
ber range that replicate real security incidents and re-
sponses, prepare a virtual environment equivalent to
the real system environment (Stout et al., 2018).
3 VIRTUALIZATION
TECHNOLOGY
3.1 Types of Virtualization Technologies
Virtualization technology efficiently utilizes hardware
by sharing and dividing the resources required for
operating systems and applications among multiple
environments (VM: Virtual Machine) (Ameen and
Hamo, 2013). Figure 2 shows an overview of each
virtualization technology type.
Figure 2: Overview of each virtualization types.
In the hypervisor type, a program called hypervi-
sor builds a VM on specially prepared hardware, and
it operates by occupying resources such as memory
and CPU. In the host type, a VM is built by running
dedicated software that plays a hypervisor role on an
operating system (host OS) running on the actual ma-
chine. A portion of the resources recognized by the
host OS is allocated and operated.
Unlike other virtualization types, the container
type operates like a VM by creating a separate names-
pace, called a container, on a running host OS that op-
erates only the processes required for the functions to
be used. Containers do not occupy physical resources
and run as a single process on the host OS. Table 1
shows the characteristics of each virtualization types.
Table 1: Characteristics of each virtualization types.
Virtualization isolation over guest
type level head OS
Hypervisor max high require
Host high max require
Container low low unrequire
The isolation level indicates independence from
the host OS and other VMs running on the same hard-
ware. If the isolation level is low, there is a high prob-
ability that the host OS and other VMs will be affected
if processing on the VM is slow or troubles occur.
Overhead refers to the decrease in processing perfor-
mance that occurs in a virtual environment. Since the
hardware is accessed through the mechanism used to
run the VM, there is a high probability that process-
ing performance will decrease compared to the actual
environment.
Figure 3 shows the operating architecture of each
virtualization types In the hypervisor and host type,
ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy
636
Figure 3: Operating architecture of each virtualization type.
Figure 4: Comparison of resource consumption as the number of virtual instances increases.
the VMs run independently and replicate the real ma-
chine’s equivalent environment. Still, they require in-
stalling a guest OS, which consumes a large number
of physical resources (Li et al., 2017). The guest OS
does not need to be started or stopped in the container
type, and only the necessary functions can be run with
minimal configuration. Containerized systems share
kernels and resources. They can be fast and efficient.
Still, they are affected by interactions with the host
OS and other containers and may behave differently
from the real machine (Preeth E N et al., 2015).
3.2 Virtualization Type Used in the
Cyber Range
Existing cyber ranges use HV and hosted virtualiza-
tion types. In particular, virtualization solutions such
as VMWare and Citrix are being used in the com-
mercial cyber range for their stability and VM man-
agement capabilities (VMWare, 2019). However, de-
pending on the number of participants and the num-
ber of exercise groups, there are more than 100 vir-
tual instances running at the same time, requiring
high load operations such as environment replica-
tion and rapid startup/termination. Therefore, high-
performance hardware is required, causing increased
costs (Maki et al., 2020).
3.3 Advantages of Container-based
Cyber Range
Cyber range environments using containerized virtu-
alization are faster and less resource-intensive than
other virtualization types. Figure 4 shows a compari-
son of the resources consumed by VMs and contain-
ers as the number of virtual instances increases.
In the example of the figure 4, the OS was installed
on a VM with 1GB memory allocated and prepared as
a device intended to be a client for the cyber range en-
vironment. We also installed the same OS and desk-
top package as the VM in a container running on the
same host. The resource consumption was compared
by preparing the container as a container that allowed
the same operations as the VM.
VMs always consume host resources without any
particular actions, such as running a guest OS and var-
ious services. Many processes that are not necessary
to execute cyber range scenarios are also running, and
even virtual machines that are not explicitly running
consume a certain amount of resources, which is in-
efficient.
Containers, on the other hand, consume very few
resources per instance because they run on a mini-
mal number of processes. Therefore, even if the cyber
range environment is built and the number of virtual
Evaluation of Vulnerability Reproducibility in Container-based Cyber Range
637
instances increases, the physical resource consump-
tion can be significantly reduced compared to a VM
environment. By using containers to build a cyber
range environment, the required specifications of the
host machine can be significantly reduced.
3.4 Concerns of Container
Using container type virtualization can build a cyber
range environment at a lower cost. However, con-
tainer type virtualization has different characteristics
than VMs used in the existing cyber range and may
have different states and behaviors in executing sce-
narios. As a result, individual vulnerabilities and in-
cidents cannot be reproduced correctly and may not
work as envisioned. The biggest concern with the
container-based cyber range is whether the vulnera-
bilities required to execute a scenario can be repro-
duced on a container similar to on a VM.
4 EXPERIMENTS ON
VULNERABILITY
REPRODUCIBILITY
4.1 Reproducibilty Metrics
To assess the reproducibility of vulnerabilities on a
container-based cyber range, we model the OS/HW
environment in which the programs as an oracle O
and every system calls invoked by a program A is sent
to the oracle O. If a program is run in the environment
over Real, VM, container, we write the output of the
programs as A
O
Real
, A
O
VM
and A
O
Container
respectively.
Where “Real” means the physical environment where
no virtualization technology is used.
If all programs’ execution results are the same,
there is no problem executing any exercise scenario,
and it eliminates concerns of container-based cyber
range. Theoretically, the identification algorithm φ
can be defined as the inability to identify which en-
vironment the program A was executed.
We write the set of results of running the program
in each environment as A
Real
, A
V M
, and A
Container
, re-
spectively, as shown in the following equation.
A
Real
=
n
A | φ
A
O
Real
= 1
o
A
V M
=
n
A | φ
A
O
VM
= 1
o
A
Container
=
n
A | φ
A
O
Container
= 1
o
By measuring these sets’ similarity, we confirm
the reproducibility of vulnerabilities in the container-
based cyber range. The relationship between each set
is shown in Figure 5.
Figure 5: Reproducibility Comparison Model.
Considering the current use of VMs in the cyber
range, we will consider Real and VM’s nearly identi-
cal. Thus, J, which represents the similarity between
VMs and containers, be the metric for using container
type virtualization in the cyber range.
J
A
V M
, A
container
=
A
V M
A
Container
|
A
V M
A
Container
|
The higher the value of J, the less concern there
is about the container-based cyber range. In reality,
some programs that are difficult to reproduce by con-
tainers, such as those related to physical vulnerabil-
ities. These should be excluded from the container-
based cyber range and will be discussed in Chapter
6.
4.2 Experimental Method
We compared the container and VM environment
through an exhaustive experiment with programs used
in cyber range exercise scenarios. We built an equiv-
alent environment with VMs and containers to con-
firm a difference between the vulnerability assess-
ment tool’s scan results and the results of attacks
against the detected vulnerabilities. Table 2 shows the
vulnerability assessment tools used in the experiment.
Table 2: Vulnerability inspection tool used for verification.
Name
Target
Web
App
Middle
ware
OS
Net
work
OpenVAS
Nmap
Owasp ZAP
We have selected tools that can be used in cyber
range exercises and divided the target areas into four
areas: web applications, middleware, OS, and net-
works. Using tools capable of scanning for each area,
ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy
638
we thought we could perform a comprehensive exper-
iment for various vulnerabilities.
4.3 Experimental Settings
We experimented with a Docker container and a Vir-
tualBox VM. Docker is a platform for container type
virtualization, becoming more popular for various ap-
plications such as cloud services. VirtualBox is a free
hosted virtualization software widely used in verifica-
tion environments, education, and research because of
its ease of installation and many supported operating
systems. The environments used for verification are
shown in Table 3.
Table 3: Experimental Settings detail.
env
Hardware
VM software and Image
Spec
Host
MacBookPro-13inch
Ubuntu 18.04 LTS
2.3GHz Corei5
16GB RAM
VM
VirtualBox6.0
Metasploitable2/3
Kalilinux2019.1
1CPU
2GB RAM
cont-
ainer
DockerCE18.09
Metasploitable2/3(created from VM)
kalilinux/kali-linux-docker(official)
We used Kali-linux, a Linux distribution for pene-
tration testing, and Metasploitable2/3, which are used
as a verification environment for deliberately adding
vulnerabilities to containers and VMs, and compared
the vulnerability assessment results and exploit tests
(Kali.org, 2020; Rapid7, 2020).
Since official container images of Metasploitable
2 and 3 are not available to the public, we created
container images from each VM machine. The origi-
nal container image was created using the docker im-
port command, which collects files other than /boot,
/dev, /mnt, /proc, /sys, /tmp that are unnecessary for
container operation using the tar command creates the
base container image from the archive file. We have
created an environment that works with the same con-
figuration, although the startup process is different.
5 EXPERIMENTAL RESULTS
5.1 Measuring Reproducibility with
Vulnerability Assesment Tools
5.1.1 OpenVAS
OpenVAS is an open-source vulnerability testing tool
with rich testing capabilities. It can detect a wide
Table 4: Comparison of the number of vulnerabilities de-
tected by OpenVAS.
CWE
vulnerability classification
VM
cont-
ainer
16 Configuration 2 2
17 Code 2 2
18 Source Code 1 1
20 Improper Input Validation 82 82
22 Pass Traversal 7 7
59 Link Following 6 6
74 Injection 1 1
79 Cross Site Scripting 33 33
89 SQL Injection 7 7
93 CRLF Injection 4 4
94 Code Injection 13 13
113 HTTP Response Splitting 1 1
119 Buffer Error 66 66
125 Out-of-bounds Read 2 2
134
Use of Externally-Controlled
Format String
5 5
189 Numeric Errors 31 31
190 Integer Overflow or Wraparound 3 3
200
Exposure of Sensitive Information
to an Unauthorized Actor
42 42
254 7PK - Security Features 2 2
255 Credentials Management Errors 2 2
264
Permissions, Privileges,
and Access Controls
54 54
275 Permission Issues 1 1
284 Improper Access Control 5 5
287 Improper Authentication 8 8
295 Improper Certificate Validation 2 2
310 Cryptographic Issues 22 22
311
Missing Encryption
of Sensitive Data
22 22
320 Key Management Errors 2 2
327
Use of a Broken or Risky
Crypto-graphic Algorithm
1 1
345
Insufficient Verification
of Data Authenticity
1 1
352 Cross Site Request Forgery 5 5
362 Race Condition’ 9 9
384 Session Fixation 1 1
399 Resource Management Errors 51 51
400
Uncontrolled Resource
Consumption
2 2
415 Double Free 1 1
416 Use After Free 2 2
476 NULL Pointer Dereference 8 8
502
Deserialization of Untrusted
Data
2 2
552
Files or Directories Accessible
to External Parties
1 1
601 Open Redirect 5 5
732
Incorrect Permission Assignment
for Critical Resource
1 1
772
Missing Release of Resource
after Effective Lifetime
1 1
787 Out-of-bounds Write 1 1
835 Infinite Loop 8 8
Design Design errors 4 4
Other Other errors 50 50
noinfo Lack of information 123 123
Evaluation of Vulnerability Reproducibility in Container-based Cyber Range
639
range of vulnerabilities such as software bugs, usage
flaws, and configurations and check for correspond-
ing CVEs (Common Vulnerabilities and Exposures)
(MITRE, 2020a) using the latest database (Green-
boneNetworks, 2020). Table 4 shows the results of
an experiment by OpenVAS. Since the number of
CVE detections is very high, it is aggregated by CWE
(Common Weakness Enumeration) (MITRE, 2020b).
For the items confirmed in vulnerability scans for
Metasplotable 2 and 3 by OpenVAS, we could con-
firm the same results for the VM and container. There
was no difference in the functions and services run-
ning in both environments, and the vulnerabilities de-
tected were consistent.
5.1.2 Nmap
Nmap is an open source port scanner with exten-
sive OS and service version detection capabilities
(Nmap.org, 2020). In cyber-range exercises, they are
often used in the early stages of exercise scenarios, for
example, to respond to incidents after port scan detec-
tion. Therefore, experimental results from Nmap are
also important in a container-based Cyber-range en-
vironment. Table 5 shows the results of detection by
NMAP.
Table 5: Detection results by Nmap, and CWE classifica-
tion.
CWE Port Service Version
189,339 21 ftp
vsftpd 2.3.4
ProFTPD 1.3.5
119,200 22 ssh
OpenSSH 4.7p1
OpenSSH 6.6 1p1
254,416 53 dns ISC BIND 9.4.2
79,287 80 http
Apache 2.2.8
Apache 2.4.7
399 111 rpcbind 2 (RPC #100000)
22,275 139 samba Samba smbd 3.X-4.X
264,290 631 ipp CUPS 1.7
94,119 1099 java-rmi Java Rmi Registry
264 2049 nfs 2-4(RPC #100003)
22,399 2121 ftp ProFTPD 1.3.1
134,189 3306 MySQL
MySQL 5.0.51a
MySQL 5.5.62
20 8181 http Webrick httpd 1.3.1
other 3632 distccd distccd v1
264,284 5432 postgresql
PostgreSQL
DB8.3.0-8.3.7
other 5900 vnc VNC protocol 3.3
20,189 6667 irc UnrealIRCd
16 8009 ajp13
Apache Jserv
(Protocol v1.3)
20,119 8180 http
Tomcat/Coyte
JSP engine 1.1
189,399 8787 drb Ruby DRb RMI
Table 6: Comparison of the number of detected vulnerabil-
ities by ZAP.
CWE Vulnerability
Metasploi-
table2
Metasploi-
table3
VM
cont-
ainer
VM
cont-
ainer
89 SQL Injection 358 422 2 2
97 Server Side Include 1 1 0 0
79 XSS(refrected) 1075 1000 1 1
79 XSS(stored) 5 5 0 0
22 Pass Traversal 21 21 0 0
78 Command Injection 361 342 0 0
98 File Inclusion 209 206 0 0
200
Application error
disclosure
242 246 1 1
548 Directory Browsing 14 15 21 21
472
Parameter
tampering
13 14 1 0
200
Buffer Error
disclosure
291 287 1 1
200 Private IP disclosure 136 139 1 1
Experiments of port scanning by Nmap gave the
same detection results in VM and container. As
shown in Table 5, we checked the vulnerabilities in
the detected contents and confirmed the correspond-
ing CWE.
5.1.3 OWASP ZAP
ZAP is an open-source web application vulnerabil-
ity assessment tool that can detect many vulnerabil-
ities and check how to deal with them (Makino and
Klyuev, 2015). Metasploitable 2 and 3, prepared as
vulnerable environments, have several web applica-
tion environments, and web pages with various vul-
nerabilities, can be checked. Table 6 shows a compar-
ison of the results of the ZAP vulnerability check.
In some cases, more vulnerabilities were detected
by containers. This result was unexpected. It could
not be determined whether this was due to the char-
acteristics of the container or the ZAP characteristics.
Since many vulnerabilities have been detected, it is
possible to utilize them in a cyber range environment
fully, but we think that clarifying the causes of the
lack of matches will help to define the possible use of
containers better.
5.2 Measuring Reproducibility with
Exploit Modules
The Metasploit framework included in Kali-linux can
use a variety of exploit modules. We compared the re-
sults of the attack experiments against Metasploitable
2 and 3 in the VM and container environments to see
if the attacks were successful and if the display and
behavior were identical. The exploit modules were
ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy
640
Figure 6: Match rate of vulnerability reproducibility about VM and container.
Table 7: Modules used for attack testing and CWE classifi-
cation.
CWE Metasploit Module
119 auxiliary/scanner/ssl/openssl heartbleed
200
auxiliary/scanner/ssh/ssh enumusers
auxiliary/scanner/http/options
auxiliary/scanner/http/trace
auxiliary/scanner/http/tomcat enum
310
auxiliary/scanner/http/ssl version
auxiliary/scanner/ssl/openssl ccs
416 auxiliary/scanner/http/apache optionsbleed
other
auxiliary/scanner/rservices/rexec login
auxiliary/scanner/rservices/rlogin login
auxiliary/scanner/rservices/rsh login
119 auxiliary/server/openssl heartbeat client memory
94 exploit/linux/samba/is known pipename
189 exploit/linux/samba/setinfopolicy heap
16 exploit/unix/misc/distcc exec
20 exploit/unix/irc/unreal ircd 3281 backdoor
284 exploit/unix/ftp/proftpd modcopy exec
other exploit/unix/webapp/twiki history
20 exploit/multi/browser/java storeimagearray
other exploit/multi/http/php cgi arg injection
noinfo exploit/multi/samba/usermap script
selected from those capable of attacking vulnerabili-
ties detected by the vulnerability assessment tool used
in the 5.1 experiment.
Table 7 shows the modules used in the attack ex-
periments. All the exploit modules used worked as
expected. We confirmed the reproducibility of the at-
tacks when used in the cyber range exercise, including
the detection of account information using vulnera-
bilities, unauthorized login, and successful privilege
escalation.
5.3 Overall Results
We checked the percentage of coincidence between
VMs and containers for all experiments performed.
Figure 6 shows the total number of detections for
each CWE and the percentage of identical results be-
tween VMs and containers for the vulnerabilities and
detection items identified in each experiment. Be-
cause the items are displayed in order of number,
there are many CWE items that were detected but are
not shown or that do not correspond to CWEs.
The similarity J calculated from the results of the
experiment was 0.993. This value is higher than ex-
pected, and we believe it is an acceptable value for
the construction of a suitable cyber range environ-
ment and the use of exercise scenarios. This exper-
iment largely eliminates the cyber range concerns of
container-based cyber range.
6 LIMITATIONS OF
REPRODUCIBILITY
Vulnerabilities related to physical resources are dif-
ficult to reproduce due to the characteristics of con-
tainerized virtualization. These are not suitable for
cyber range environments and should be excluded. In
reality, we checked what differences occur between
containers and VMs. Table 8 shows the results of an
attack on a VM and a container.
Table 8: Physical resource consumption and behavior of vir-
tual environment.
resource type results
memory
VM
Program is delayed at VM
memory allocation limit, but other
VMs are not affected.
cont-
ainer
When physical memory usage
reaches a limit, the entire operation,
including the host OS, is delayed.
strage
VM
Machine stops at VM storage
allocation limit, but other VMs are
not affected.
cont-
ainer
When physical storage usage
reaches a limit, the entire operation,
including the host OS, is stopped.
A VM occupies a portion of the resources on the
host OS and operates as an independent machine.
Therefore, even if an attack slows down or stops the
VM, it does not interfere with the host OS’s operation.
However, the standard configuration of the container
shares resources with the host OS and other contain-
Evaluation of Vulnerability Reproducibility in Container-based Cyber Range
641
ers. An attack on the container can affect the entire
system, including the host OS, which is a clear differ-
ence from the VM. Against such attacks, it was con-
firmed that container type virtualized environments
are unsuitable for cyber range exercises. Similarly,
vulnerabilities such as kernel vulnerabilities, host OS
configuration, and files required for container execu-
tion, and attacks against them, should be excluded
from container-based cyber range exercises.
7 CONCLUSIONS
With the shortage of information security personnel,
the cyber range is expected to be highly effective in
education. However, the cost of cyber range is high,
making it difficult for educational institutions to im-
plement them independently.
Therefore, to disseminate an inexpensive and de-
ployable cyber range using container-based virtu-
alization, we confirmed the superiority of contain-
ers and the performance of reproducing vulnerabili-
ties through comprehensive experiments. Comparing
the performance of containers and VMs in a typical
cyber-range environment, the containers consumed
less than 1/10th of the resources of the VMs. Con-
tainers can run more virtual instances than VMs on
the same host, building a lower cost cyber range.
We also compared the reproducibility of vulnera-
bilities between containers and VMs in an exhaustive
experiment using the vulnerability assessment tool
and the exploit module. We can confirmed a very high
similarity J of 0.993. Although content derived from
container characteristics must be excluded, contain-
ers have a very high vulnerability reproduction perfor-
mance, confirming that container-based virtualization
can be fully used in the cyber range.
These contents can be used as a benchmark for
developing scenarios and conducting exercises for
container-based cyber ranges. In the future, we will
experiment with more situations and conduct more
detailed research, including the ability to carry out
attack and defense scenarios. We will also promote
research and studies to increase the container-based
cyber range’s effectiveness, such as examining the ef-
fectiveness of education and refining exercise scenar-
ios based on behavioral analysis, to broaden the base
of security personnel training.
ACKNOWLEDGEMENTS
This work is supported in part by the Telecommuni-
cation Advancement Foundation.
REFERENCES
Ameen, R. Y. and Hamo, A. Y. (2013). Survey of server
virtualization.
Costa, G., Russo, E., and Armando, A. (2020). Automating
the generation of cyber range virtual scenarios with
vsdl.
GreenboneNetworks (2020). Openvas - open vulnerability
assessment scanner. https://www.openvas.org.
Irvine, Cynthia, E., Thompson, Michael, F., and Khosalim,
J. (2017). Labtainers: a framework for parameterized
cybersecurity labs using containers.
Kali.org (2020). Official kali linux docker im-
ages. https://www.kali.org/docs/containers/official-
kalilinux-docker-images/.
Li, Z., Kihl, M., Lu, Q., and Andersson, J. A. (2017).
Performance overhead comparison between hypervi-
sor and container based virtualization. In 2017 IEEE
31st International Conference on Advanced Informa-
tion Networking and Applications (AINA), pages 955–
962.
Maki, N., Nakata, R., Toyoda, S., Kasai, Y., Shin, S., and
Seto, Y. (2020). An effective cybersecurity exercises
platform cyexec and its training contents. In 2020 In-
ternational Conference on Advances in Education and
Information Technology(AEIT’20).
Makino, Y. and Klyuev, V. (2015). Evaluation of web vul-
nerability scanners. In 2015 IEEE 8th International
Conference on Intelligent Data Acquisition and Ad-
vanced Computing Systems: Technology and Applica-
tions (IDAACS), volume 1, pages 399–402.
MITRE (2020a). Common vulnerabilities and exposures.
https://cve.mitre.org/.
MITRE (2020b). Common weakness enumeration.
https://cwe.mitre.org/index.html.
Nmap.org (2020). Port scanning techniques.
https://nmap.org/book/man-port-scanning-
techniques.html.
Preeth E N, Mulerickal, F. J. P., Paul, B., and Sastri,
Y. (2015). Evaluation of docker containers based
on hardware utilization. In 2015 International Con-
ference on Control Communication Computing India
(ICCC), pages 697–700.
Rapid7 (2020). Metasploitable2.
https://docs.rapid7.com/metasploit/metasploitable-2/.
Razvan, B., Cuong, P., Dat, T., Ken-ichi, C., Yasuo, T., and
Yoichi, S. (2017). Cytrone: An integrated cyberse-
curity training framework. In Proceedings of the 3rd
International Conference on Information Systems Se-
curity and Privacy (ICISSP 2017): 157-166.
Stout, W. M., Urias, V., Van Leeuwen, B. P., and Lin, H. W.
(2018). An effective cybersecurity exercises platform
cyexec and its training contents. In Proposed for pre-
sentation at the IEEE International Carnahan Confer-
ence on Security Technology (ICCST).
VMWare, I. (2019). Vmware digital learn-
ing platform - cyber range solution.
https://www.vmware.com/content/dam/digitalmarket
ing/vmware/en/pdf/solutions/industry/vmware-cyber
range-datasheet.pdf.
ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy
642
