Adaptive Semantic Routing in Dynamic Environments

Stefan Jakob, Harun Baraki, Alexander Jahl, Eric Douglas Nyakam Chiadjeu, Yasin Alhamwy

and Kurt Geihs

Distributed Systems Group, University of Kassel, Wilhelmsh

oher Allee 71 - 73, Kassel, Germany

Keywords:

Knowledge Representation and Reasoning, Knowledge-based Systems, Semantic Routing.

Abstract:

Digital cities increasingly depend on IT and communication infrastructure. They can be seen as large dis-

tributed systems consisting of heterogeneous and autonomous participants. Especially during emergency sit-

uations and natural disasters, crucial knowledge about injured people and damaged infrastructure has to be

discoverable by rescuers. Since knowledge discovery is about ﬁnding semantic information, IP-based routing

mechanisms have to rely on ﬂooding as they have to query each node to locate matching information. This

leads to additional stress on the potentially damaged communication infrastructure. Therefore, we propose

a semantic routing mechanism tailored for loosely-coupled networks that can dynamically change and are

unstructured. By providing a multi-agent system, devices are enabled as part of the network to support the

communication infrastructure. The focus of the network is set on discovering semantically structured knowl-

edge, which can change at run-time. The main contributions of this paper are routing tables that incorporate

semantic information to aggregate semantically close knowledge. They are only updated if new knowledge

is available or new aggregates are created, to avoid network ﬂooding. Based on a search & rescue scenario,

we explain our new routing and update algorithms. Finally, we discuss the message complexity of the routing

mechanism and the suitability of the used knowledge representation.

1 INTRODUCTION

Future digital cites will increasingly depend on IT

and communication technologies. This includes un-

manned aerial vehicles (UAVs), mobile robots, au-

tonomous cars, and smart infrastructures. The city

infrastructure, for example, comprises smart street

lights, that can be used to charge electric vehicles,

camera systems for trafﬁc surveillance and Internet

access points. Therefore, a future digital city can be

seen as a distributed system with heterogeneous par-

ticipants that rely on communication infrastructure to

interact with each other. Hence, the underlying net-

work and the exchange of information have to be re-

silient. This is especially important for rescuers in the

case of emergency situations or during natural dis-

asters. One example is an earthquake. In this case,

parts of the communication infrastructure could be

destroyed; thus, the communication and reachability

could be limited. Buildings could collapse, gas and

water leaks could occur, and humans could be injured.

To overcome such emergency situations, rescuers

need an overview of the current situation. Therefore,

UAVs and mobile rescue robots are used to detect in-

jured people and dangers like gas leaks.

Additionally, reliable access to knowledge is

needed, which includes, among other information:

available supplies, free hospital beds, and positions

of injured people. Since parts of the communica-

tion infrastructure are damaged, access to a central

coordinator that manages the necessary knowledge is

not always given. Mission-critical knowledge, thus,

has to be maintained and stored on the nodes of the

communication network. To integrate heterogeneous

devices as part of the communication infrastructure,

a multi-agent system (MAS) is presented in (Jakob

et al., 2020). In this system, agents run on the nodes of

the network, e. g., on robots, UAVs, and smart street

lights. The agents can join and leave the MAS dy-

namically. Furthermore, the agents manage and store

knowledge, and thus, form an unstructured distributed

knowledge base. To associate a semantic meaning

with the stored knowledge, an ontology formulated

in Answer Set Programming (ASP) (Brewka et al.,

2011) has been presented in (Jakob et al., 2021). By

applying this ontology, initially classiﬁed knowledge

is assigned to more general classes in order to group

semantically related knowledge. For example, knowl-

edge about patients that have been injured during the

emergency situation may be aggregated with knowl-

Jakob, S., Baraki, H., Jahl, A., Nyakam Chiadjeu, E., Alhamwy, Y. and Geihs, K.

Adaptive Semantic Routing in Dynamic Environments.

DOI: 10.5220/0010300609971004

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 2, pages 997-1004

ISBN: 978-989-758-484-8

 2021 by SCITEPRESS – Science and Technology Publications, Lda. All rights reser ved

997

edge about other people. This is the case since each

patient is a person, and thus, they form a semantic

sub-class relation.

Rescuers using this system are mainly interested

in the contents of the knowledge base and not in the

location of the knowledge. Classical IP-based rout-

ing does not support the localisation of speciﬁc con-

tents if its address is unknown. Therefore, a seman-

tic routing mechanism is needed. Additionally, sev-

eral challenges arise. The routing mechanism has to

be performant since the network and its communica-

tion capability are limited due to the emergency sit-

uation. Central servers have to be prevented because

they would introduce a bottleneck and single point of

failure. Last but not least, knowledge can change dy-

namically. Hence, we present a novel semantic rout-

ing mechanism, which is the main contribution of this

paper.

Instead of annotated ﬁles, we focus on seman-

tically structured knowledge, which can be located

in remote parts of the network and can dynamically

change during run-time. Moreover, we assume that

the structure of the network may also change dynam-

ically in disaster scenarios. Thus, the semantic rout-

ing has to dynamically adapt to these changes. Ad-

ditionally, the semantic routing applies ASP ontolo-

gies presented as in (Jakob et al., 2021). It incor-

porates parts of the ontology to aggregate semanti-

cally close knowledge under a common base class.

These common base classes are used to create and

provide semantic routing tables, that support access to

knowledge based on its content instead of its location.

These tables dynamically adapt if the network struc-

ture changes. To prevent network ﬂooding, agents ag-

gregate semantically close knowledge and tables are

updated if new knowledge is available or new aggre-

gates are created.

The remainder of the paper is structured as fol-

lows. Section 2 introduces Answer Set Program-

ming, which is the used non-monotonic reasoning and

knowledge representation formalism. The semantic

routing is presented in Section 3. Section 4 discusses

the message complexity of the presented semantic

routing. Related work is shown in Section 5. Finally,

Section 6 concludes this paper.

2 ANSWER SET PROGRAMMING

Answer Set Programming (ASP) has its origin

in logic programming, constraint satisfaction, and

knowledge representation. Furthermore, ASP is a

declarative and non-monotonic logic programming

language. An ASP program contains rules, which are

divided into three parts. The rule head, the positive

body, and the negative body. The head is derived if all

predicates in the positive body hold and all predicates

in the negative are false. A typical example is shown

in Listing 1.

1 bi rd ( twee ty ) .

2 pen gu i n ( tux ) .

3 bi rd ( X) : - pe ng u i n ( X ) .

4 fly ( X ) : - bi r d (X ) , no t pe ng ui n ( X ) .

Listing 1: Example ASP Program.

Line 1 and 2 of Listing 1 are facts. They do not have a

body and thus are unconditionally true. Additionally,

these facts state that tweety is a bird and that tux is

a penguin. Line 3 and 4 are rules. Informally speak-

ing, Line 3 states that penguins are a bird, too, and

Line 4 states that all birds can ﬂy if they are not a pen-

guin. The solution (Answer Set) of this program is:

{penguin(tux), bird(tux), bird(tweety), ﬂy(tweety)}.

Since ASP is a declarative logic language, a solver

is needed to determine the solution of an ASP pro-

gram. The interested reader is referred to (Brewka

et al., 2011) for a comprehensive speciﬁcation of

ASP. Clingo (Gebser et al., 2014) is a state-of-the-

art ASP solver. It introduces several features, which

include multi-shot solving, External Statements, and

Program Sections. Multi-shot solving enables the us-

age of Clingo as a knowledge base since already de-

rived predicates can be queried and reused. External

Statements are predicates marked with the keyword

#external and their truth value can be dynamically

adapted at run-time. Finally, by deﬁning Program

Sections, ASP programs can be divided into param-

eterisable and reusable sub-programs. Hence, using

Clingo provides mechanisms for the creation of a dy-

namically adaptable and extendable knowledge base.

Queries given to this knowledge base are formu-

lated as ASP programs, which consists of rules and

optimisation statements. A typical query in a search

& rescue scenario is the closest patient that has to be

saved. An example of a semantic query is shown in

Listing 2.

1 { p at ie nt ( " A " , 1) ; pa ti en t ( " B " , 2) ;

pa ti en t ( " C " , 1) } = 1.

2 # m in im i z e { Y@1 : p at ie nt ( X , Y ) }.

Listing 2: Example Semantic Query.

The ﬁrst line lists all known patients with their

name and distance parameter by using a choice

rule (Brewka et al., 2011), which creates three possi-

ble solutions containing exactly one patient. The sec-

ond line is a query containing an optimisation state-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

998

ment, which selects the patients which are closest.

Solving this query results in two optimal solutions

A and C. To retrieve knowledge about all known pa-

tients, the query has to be efﬁciently routed and de-

ployed to the corresponding parts of the distributed

knowledge base.

3 CREATING SEMANTIC

ROUTING TABLES

To locate contents in an unstructured distributed

knowledge base, the most simple way is to rely on

ﬂooding. However, in scenarios with impaired com-

munication like emergency situations or natural dis-

asters, ﬂooding would introduce further stress on the

network. Therefore, an intelligent way of routing is

needed. One way would be the use of structured

P2P like Distributed Hash Tables (DHT). However,

DHTs are not suited for highly dynamic networks,

since the content is equally distributed on their nodes.

This could lead to a broad distribution of contents and

queried contents could be on remote nodes of the net-

work and thus often not reachable in highly dynamic

networks. A suitable approach is the use of routing

tables. They provide information about routes to net-

work destinations. Furthermore, they can easily be

updated by adding, altering or removing entries. Yet,

in many application scenarios, like search & rescue,

the emphasis is on the content instead of its location.

Therefore, we have developed a new way to create

routing tables that focus on contents and their seman-

tic.

A major challenge is to provide a routing of se-

mantic queries in unstructured networks. The ﬁrst

fundamental requirement for solving semantic queries

are knowledge bases that provide semantic informa-

tion. Commonsense knowledge sources provide re-

lations between their classes or concepts to structure

the represented knowledge. One of these sources is

ConceptNet 5 (CN5) (Speer et al., 2017), which has

been created from veriﬁed sources like Wiktionary,

WordNet, and Wikipedia. It consists of a hypergraph

that connects concepts by directed edges that are an-

notated with predeﬁned relations. For example, the

relation IsA indicates a subclass relationship and the

relation Synonym is used to connect concepts with

similar meaning. Furthermore, each edge in CN5 is

annotated with a weight that indicates the reliability

of the represented knowledge. A weight greater than

1.0 indicates, that the edge has been extracted from a

veriﬁed source.

We leverage the structure of commonsense knowl-

edge to extract a taxonomy of classes. Taxonomies

can be used to support a hierarchical aggregation of

knowledge. An extraction of a taxonomy is shown

in Figure 1. The taxonomy is marked in green and

has been identiﬁed by relying on a subset of relation

types and a selection of the highest edge weights. In

the given example, this leads to selecting the edge be-

tween patient and person instead of patient and

human. Additional knowledge provided by CN5 is

marked in red. As you can see in this ﬁgure, the

hypergraph provides a mesh-like structure and can

contain additional types of edges, while taxonomies

provide tree-like structures. Since tree-like structures

ease the aggregation of semantically close knowledge,

we apply taxonomies to automatically generate se-

mantic routing tables that are used to distribute se-

mantic queries to the corresponding nodes of an un-

structured network.

IsA IsA

FormOf hasPropertyhuman

IsA

person

hasProperty

IsA

patient

rescuers

sufferring

from

disease

sick

person

humans good

Figure 1: Taxonomy Extracted from a Hypergraph

In other works, the Web Ontology Language (OWL)

is used to model ontologies or taxonomies since it is

the de facto standard for knowledge representation in

the semantic web. Since our focus is set on constantly

changing networks and information, OWL is inappli-

cable. Its full speciﬁcation is undecidable. The result-

ing ontologies are monotonous, which prevents the

invalidation of already derived knowledge if contra-

dicting knowledge arises. In addition, OWL does not

allow the deﬁnition of defaults, which prevents to in-

corporate commonsense knowledge that can be over-

written in individual cases. In contrast to this, ASP

is decidable and non-monotonous. Thus, already de-

rived knowledge like defaults can be invalidated. Fur-

thermore, current ASP solvers, for example, Clingo,

enable a dynamic adaption of ASP programs and thus

supports dynamic ontologies and taxonomies.

For the extraction and transformation of common-

sense knowledge into ontologies and taxonomies in

ASP, we provide a framework (Jakob et al., 2021) that

enables their automatic generation but also the man-

ual adaptation and extension with properties. Using

this framework, a taxonomy can be created by limit-

ing the considered relations of CN5 to IsA, FormOf,

and Synonym. Furthermore, only edges with a weight

of at least 1.0 are considered to extract knowledge

Adaptive Semantic Routing in Dynamic Environments

999

supported by a veriﬁed source. The general idea of the

taxonomy extraction shown in (Jakob et al., 2021) is

to provide a starting concept and applying an adapted

breadth-ﬁrst search that uses a set of relations to se-

lect edges and a minimum weight as a stopping cri-

terion. Following the search & rescue example pre-

sented above, a taxonomy is needed that provides

classes for human patients. During design time, a

rescuer can use our modelling framework to start the

generation of the ontology. Therefore, the concept

human is selected as the base concept and the weight

of 1.0 is chosen as a stopping criterion. This results

in the following excerpt of the resulting taxonomy:

1 # e xt er n a l is A ( " p at ie nt " ," pe rs on " ,1) .

2 wei gh t (1 ,100 ,0)

: - i sA ( " p at ie n t " ," p er so n " ,1) .

3 # e xt er n a l is A ( " p er so n " ," hu ma n " ,2) .

4 wei gh t (2 ,100 ,0)

: - i sA ( " p er so n " ," h uma n " ,2) .

5 wei gh t (2 ,200 ,1)

: - i sA ( " p er so n " ," h uma n " ,2) .

Listing 3: Excerpt from the Taxonomy.

Line 1 of Listing 3 states, that a patient is a person.

Furthermore, the UUID 1 is provided which is used

to link the corresponding weight rule that is shown

Line 2. Informally speaking, it states the edge with

the UUID 1 has a weight of 100 at time 0. Manu-

ally adapting weights in our framework would lead

to an additional weight rule containing the same

UUID would but a higher timestamp. Line 3 and 4

analogously deﬁne the relation between human and

person. After the extraction of the taxonomy and its

translation into ASP, a rescuer increases the weight of

edge 2 to 200 as shown in Line 5. This is done since

the inference rules presented in (Jakob et al., 2021)

only apply further base classes if their weight in-

creases to prevent impractical classiﬁcations or loops.

The resulting taxonomy is then used to classify pa-

tients and to ﬁlter knowledge not necessary in the res-

cue missions.

The novel semantic routing consists of four parts,

which are explained in the following paragraphs.

These are semantic routing tables, semantic aggrega-

tion, an update mechanism, and propagation of indi-

viduals. In the following, the four parts are presented

by the example shown in Figure 2

. In this scenario,

rescuers try to locate patients after an earthquake. The

patients are labelled A, B, and C. Each patient is asso-

ciated with a corresponding smartphone that provides

communication with robots, UAVs, and the smart en-

Created with https://app.diagrams.net/ (December 16,

2020)

vironment. Furthermore, each node in the presented

network represents an agent that has a UUID. The

dashed arrow in Figure 2 represents a query to the

system. Solid arrows indicate that nodes can commu-

nicate with each other.

1 ro ut e ( p ath ( " hu man " ," pe rs on " ,

" pa ti en t " ) , uui d ( sp1 ) , dis t (2 ) ,

uui d ( r2 ) ) : - nod e ( u u id ( r2 )) ,

not - ro u te ( pa t h (" h um a n " , " per so n "

," p a t ie nt " ) , uui d ( sp1 ) , di s t (2 ) ,

uui d ( r2 ) ) .

2 ro ut e ( p ath ( " hu man " ," pe rs on " ,

" pa ti en t " ) , uui d ( sp2 ) , dis t (1 ) ,

uui d ( sp2 ) ) : - no de ( u uid ( sp2 ) ) ,

not - ro u te ( pa t h (" h um a n " , " per so n "

," p a t ie nt " ) , uui d ( sp2 ) , di s t (1 ) ,

uui d ( sp2 ) ) .

3 ro ut e ( p ath ( " hu man " ," pe rs on " ) , uu id (

uav 2 ) , d ist (1) , uui d ( u av2 ) ) : -

nod e ( uu id ( uav2 ) ) , not -r out e (

pat h ( " h u ma n " ," p er so n " ) , uuid (

uav 2 ) , d ist (1) , uui d ( u av2 ) ) .

4 # e xt er n a l node ( uu i d ( r2 ) ) .

5 # e xt er n a l node ( uu i d ( sp 2 ) ) .

6 # e xt er n a l node ( uu i d ( u av2 ) ) .

7 # e xt er n a l - r ou te ( pat h ( " h uma n " ,"

pe rs on " , " pa ti en t " ) , uui d ( sp1 ) ,

dis t (2) , uu id ( r2 ) ) .

8 # e xt er n a l - r ou te ( pat h ( " h uma n " ,"

pe rs on " , " pa ti en t " ) , uui d ( sp2 ) ,

dis t (1) , uu id ( sp 2 ) ) .

9 # e xt er n a l - r ou te ( pat h ( " h uma n " ,"

pe rs on " ) , uui d ( u av2 ) , di st ( 1 ) ,

uui d ( ua v2 ) ) .

Listing 4: Semantic Routing Table of Robot 1.

Semantic Routing Tables. The base of the adaptive

semantic routing are routing tables that contain se-

mantically aggregated entries. The entries point to the

neighbouring nodes, which are closer to a queried se-

mantic piece of information. These tables consist of

ASP rules and Externals Statements. While ASP rules

are used to model the entries of the table, External

Statements are applied to keep track of the availability

of a node and the validity of the entries. Furthermore,

each entry indicates the type of the knowledge based

on the taxonomy, the node of the network that either

aggregated the knowledge or is its origin, the distance

to the corresponding node, and the neighbouring node

that provides access to this knowledge. The distance

is measured by the hops. Listing 4 shows the semantic

routing table of Robot 1 (r1) according to Figure 2.

The Lines 1 to 3 of this listing are the actual en-

tries of the semantic routing table. As can be seen in

Line 1, a path indicates the base classes, which have

been obtained through aggregation and updating pro-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

1000

sp4 1

human/person/D

human/person

r1 2

Smartphone 3Smartphone 2

Smartphone 1

UAV 2

Street Light 2Street Light 1

Robot 2

Robot 1

UAV 3

human/person/patient/B human/person/patient/C

human/person/patient/A

UAV 1

Smartphone 4

human/person/D

Rescuers

human/person

r1 2

human/person

uav2 2

human/person

1uav2

human/person

r1 1

human/person/patient

r1 1

human/person/patient

sp2 2

human/person/patient

sp2 3

human/person/patient

sp1 1

human/person/patient

sp1 1

human/person/patient

sp1 2

human/person/patient

sp2 1

human/person/patient

sp2 1

human/person/patient/C

sp3 1

Aggregation

Text UUID of Node

Number Distance

Knowledge available from Node

Query

concept/Individual Knowledge

human/person

1uav2

human/person

r1 1

Figure 2: Semantic Routing Information

cesses or are part of the initial classiﬁcation of an in-

dividual. In this line, the path states that knowledge

about patients with the base classes person and

human can be found at Smartphone 1 (sp1), which

is reachable in 2 hops via robot r2. To derive this

route, the External Statement in Line 4 has to be set

to true, which indicates that robot r2 is reachable.

Additionally, the External Statement in Line 7 has to

be false since it is used to invalidate the route in

case r1 receives contrary information. Thus, routes

can be adapted dynamically during the run-time of the

system. The remaining combinations of rules and Ex-

ternal Statements work analogously.

In contrast to the routes presented in Listing 4,

individuals that are managed on a node are modelled

as External Statements. This enables a node to

remove knowledge on its own, e. g., if it is outdated.

For example, sp1 in Figure 2 manages knowledge

about individual A. Therefore, the External Statement

route(path("human","person","patient","A"),

uuid(sp1), dist(0), uuid(sp1)) is added to

the semantic routing table. This External Statement

indicates, that knowledge about patient A is available

on this node, because the distance is 0. Since the

node manages the knowledge about patient A itself,

it can set the External Statement to false if this is no

longer the case. To minimise the size of the tables,

semantically close knowledge is aggregated.

Semantic Aggregation. A central aspect of the se-

mantic routing tables is the aggregation of semanti-

cally related knowledge. As already discussed above,

a taxonomy is used since it provides a tree-like clas-

siﬁcation which eases the aggregation based on its

branches. Furthermore, several distinct taxonomies

can be applied which allows managing knowledge

originating from several independent base classes.

There are two situations when knowledge can be ag-

gregated.

The ﬁrst one is the aggregation based on the

taxonomy. In this case, entries of a routing table are

aggregated if they represent individuals that share

the same base classes. Figure 2 shows an example

for this kind of aggregation. All possible aggregation

points of this scenario are marked with a blue dot.

Smartphone 2 (sp2), which has knowledge about

patient B aggregates a routing table entry provided by

Smartphone 3 (sp3), which has knowledge about

patient C. After sp3 receives the knowledge about

patient C, it propagates a corresponding routing

table entry to sp2, which already has knowledge

about patient B. Since both, B and C, share the

same base classes, the knowledge is aggregated to

a new routing table entry, which associates both

individuals to a base class. In this case, the route

route(path("human","person","patient"),

uuid(sp2), dist(0), uuid(sp2)) is created

on sp2 and is propagated to the neighbouring

nodes except the origin of the routing entry that

caused the aggregation. Base classes are aggre-

gated analogously. For example, UAV 2 aggregates

knowledge about path("human","person") with

path("human","person","patient").

The second type of aggregation is based on

Adaptive Semantic Routing in Dynamic Environments

1001

distance. In the case that a node receives a routing

entry, which has the same base classes, a lower or

the same distance, and has the identical origin of

information (second UUID entry of a route), an

aggregation step is conducted. For example, r1

receives an entry from sp2 while its routing table

already has an entry from r2. Both entries share

the same base classes and the entry received from

sp2 has a lower distance, thus, the new aggregation

route(path("human","person","patient"),

uuid(r1), dist(1), uuid(r1)) is created and

forwarded to the remaining neighbours. The routing

table entries are added by an update mechanism.

Updates. Besides the aggregation of routing en-

tries, a reliable update mechanism is needed to keep

the semantic routing tables viable. The update mech-

anism is responsible for three kinds of updates, which

are conducted if corresponding messages are re-

ceived.

The ﬁrst kind is the arrival of additional

routes. During this kind of update, new routes

are received via a message containing corre-

sponding ASP rules. First, possible aggregates

are checked. If an aggregation is possible,

the negative External Statement, for example

-route(path("human","person","patient"),

uuid(sp1), dist(2), uuid(r2)), of the corre-

sponding existing routes are set to true and thus the

routes are removed from the routing table. After-

wards, the created aggregate is added to the table and

propagated to the neighbouring nodes. In case that no

aggregation is possible, the received route is added to

the table.

The second kind of updates are overwrites. They

occur if new routing table entries arrive which match

existing ones, i. e., if they have the same classes and

origin. In case that a new routing table entry has a

lower distance, the old entry is removed by setting

the corresponding external statement to false and by

adding the new entry to the routing table. In the last

step, it is checked if any aggregation is possible.

The third kind of updates happens if a neighbour-

ing node is no longer reachable. For example, con-

sider that in Figure 2 r1 is no longer able to reach r2,

which is detected by periodical ping requests. Since

r2 can no longer provide the knowledge accessible

via the corresponding routing table entries, the entries

have to be removed. Therefore, r1 sets the Exter-

nal Statement that represents r2 (node(uuid(r2)))

to false. Since this External Statement is set to false,

all routing entries are removed from the table, as their

rule body positively depends on it. During this kind of

update, no aggregation is needed since no new knowl-

edge is received.

Propagation of Individuals. A key aspect of se-

mantic routing is to distribute knowledge about man-

aged individuals. Therefore, their existence needs to

be published. Once a node of the system receives

knowledge about a new individual, e. g. individ-

ual path("human","person","D") is introduced to

Smartphone 4 (sp4), corresponding routing entries

are created. To prevent the distribution of unaggre-

gated routes, the routing table is checked for potential

aggregations. If possible, the entries are aggregated

and the routing table is updated. Finally, the appear-

ance of a new entry is published to the neighbouring

nodes via messages.

By combing these four steps, dynamically

adaptable semantic routing tables are created.

Queries to these tables are formulated as ASP

programs, too. Therefore, the arity of the path

predicate can be used to reduce the possible an-

swers. For example, the rule patientEntry(X) :-

route(path("human","person","patient"),

uuid( ), dist( ), uuid(X)). selects all aggre-

gated patient entries of a semantic routing table and

returns the UUIDs of the nodes which provides the

corresponding knowledge. In case of the semantic

routing table of r1 shown in Listing 4, r2 and sp2

are returned, since the corresponding routing entries

indicate that they are able to provide the knowledge

about patients.

4 DISCUSSION

A central aspect of the evaluation of a routing algo-

rithm is its message complexity. Achieving a low

message complexity in a loosely-coupled network

with dynamic conﬁguration is particularly challeng-

ing, since nodes and information may enter and leave

the system at any time. Content-based routing algo-

rithms rely on semantic information and, hence, no

distance metric and no clear addressing are given,

which adds to the challenge. In the case of content-

based routing, queried information can be located

on any node of the network. A typical approach is

to use ﬂooding to reliably discover all information

corresponding to a search query. However, ﬂood-

ing has a high message complexity. Considering a

fully connected network, naive ﬂooding, which sim-

ply forwards messages to all neighbours except to the

origin of the message has a message complexity of

O(n ∗ (n − 1)) in the best and the worst case. Al-

ready received messages are ignored. If a mesh net-

work is not fully connected, the message complex-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

1002

ity is reduced to O(n ∗ m), where m is the number

of neighbours of each node. Again, this complexity

holds for the best and the worst case. To further re-

duce the complexity, selective ﬂooding can be intro-

duced, which has a message complexity of O(n) since

it relies on a tree-like structure to forward messages.

However, the direction leading to the target, a distance

metric, and the approximate location of the target are

needed.

In the worst case, our semantic routing mecha-

nism has the same message complexity of O(n ∗ m)

like ﬂooding in a mesh network. There are two pos-

sible cases in which this complexity can arise. The

ﬁrst case is the introduction of the ﬁrst individual of

a completely new taxonomy path to the system since

there are no possibilities to form aggregates. The sec-

ond case can occur during the ﬁrst aggregations, as

the aggregated path has to be disseminated. Since

there are no other aggregation points, all routing ta-

bles have to be updated. However, after the ﬁrst ag-

gregations have been introduced, the message com-

plexity is reduced since aggregation points summarise

routes, and thus, may stop the propagation. For exam-

ple, this is the case if routes containing more speciﬁc

taxonomy paths are received. In the best case, this

results in a message complexity of O(0) if a new in-

dividual is introduced at an aggregation point, which

already contains a routing entry with the correspond-

ing taxonomy path. Furthermore, aggregation points

reduce the message complexity of additional aggrega-

tions to O(m) if neighbouring nodes already possess

routes with the corresponding aggregate.

Besides the creation of routing tables, the message

complexity of query resolution is of high relevance.

The worst message complexity of O(n) emerges if in-

dividuals that match a given concept query are dis-

tributed on the nodes of the whole network, for exam-

ple, a query for all humans in Figure 2. In contrast,

a complexity of O(0) is achieved if the answer solely

exists in the own routing table. Adding a new node to

the network has a complexity of O(1), due to transfer

of the routing table from a neighbouring node.

A prototypical implementation of the semantic

routing is available at Bitbucket

. For the scenario

given in Figure 2 the presented semantic routing ta-

bles are roughly 10 times faster than naive ﬂooding.

The suitability of ASP for the creation of ontolo-

gies and taxonomies has been shown in (Jakob et al.,

2021). Ontologies and taxonomies are extracted from

a hypergraph-based knowledge source and formulated

in a way that enables dynamic adaptations at run-

time. Furthermore, it is shown that several hundreds

https://bitbucket.org/sjakob872/semantic routing

(December 16, 2020)

of thousands ASP rules are usable in a reasonable

time. Typical queries can be solved in a few millisec-

onds. Clearly, the more complex the query, the higher

is the run-time. Nonetheless, queries to a routing table

have a simple structure.

5 RELATED WORK

Typical well-known P2P search and routing mecha-

nisms, such as ﬂooding, random walks, distributed

hashing, and central repositories, do not provide an

efﬁcient solution for knowledge discovery in an un-

structured or unstable network. Extensive ﬂooding of

an unstable network by many users, authorities and

rescue teams may lead to a complete communica-

tion breakdown in disaster situations. Random walks

cannot guarantee to ﬁnd information, irrespective of

whether it is available in the network or not. Cen-

tral repositories constitute a bottleneck and a single

point of failure. Distributed hashing approaches such

as (Visala et al., 2009) violate the autonomy of nodes

and are not designed for unstable and dynamic net-

works. The key of a document or information may

map to a remote node that is not reachable.

Related works that try to optimize knowledge

discovery in dynamic networks can be found in

the areas of Semantic Query Routing and Content-

Based Routing in P2P and mobile ad hoc networks.

In (G

omez Santill

an et al., 2010), Gomez et al. ex-

tend and combine different approaches known from

unstructured P2P systems to address the Semantic

Query Routing Problem. The problem can be sum-

marized with locating textual information, more pre-

cisely documents annotated with topics, in a P2P net-

work. They apply an Ant Colony algorithm to adapt

the pheromone level of routes depending on the hit

rates and hops for a certain topic query. The rout-

ing for a certain query converges, the more often the

query is sent through the network. Since a learn-

ing phase is required, rather static networks with re-

curring topic queries will beneﬁt from this approach.

Michlmayr et al. (Michlmayr et al., 2007) apply ad-

ditionally a taxonomy to search for similar concepts.

Concepts are considered as similar, if they share the

same super concepts in the taxonomy. However, in

contrast to our work and to (Pireddu and Nascimento,

2004), taxonomies are not used to aggregate entries

in routing tables. Pireddu and Nascimento utilise tax-

onomies to summarise the number of documents each

neighbour has in each category. A node is aware

of these numbers for each direct neighbour, whereas

only the aggregated numbers for upper-level cate-

gories are known for the neighbours of neighbours.

Adaptive Semantic Routing in Dynamic Environments

1003

If the number of hops to a remote node exceeds the

depth of the taxonomy tree, no information is kept

about this remote node. The taxonomy thus serves

here as a summarised directory of documents in the

local neighbourhood and is not designed for routing

queries to far distant nodes.

In (Koloniari and Pitoura, 2004), knowledge is

kept in XML ﬁles by nodes that are organised in a

hierarchy. Each node possesses a local Bloom ﬁlter

that is triggered whenever an incoming query poten-

tially matches with locally stored knowledge. Nodes

also contain a merged Bloom ﬁlter that encompasses

the Bloom ﬁlters of the child nodes. A query match-

ing to a merged ﬁlter is redirected to child nodes. If

no positive local or child matching is obtained, the

query is redirected to the parent node. The approach

is rather suited for static P2P networks as nodes have

to stay in a hierarchy. The resource capacities of the

root node have to be sufﬁciently dimensioned since it

has to handle the most search and update queries. In

addition, the usage of Bloom ﬁlters may lead to a high

number of false positive matchings and thus routings,

if they are not conﬁgured and adapted well.

In (Jacobson et al., 2009) and (Gritter and Cheri-

ton, 2001), hierarchical names, similar to the taxon-

omy paths in our work, are used for content-based

routing. Also, routing entries are merged to reduce

the size of routing tables. However, taxonomies are

not applied. Instead, a hierarchical name could start

with the URL of the owner of a content. Consistent

names and annotations of content are not given. Ad-

ditionally, typical semantic queries cannot be used as

no solver is included in the routing procedure.

6 CONCLUSION

In this paper, we have presented a novel routing mech-

anism for loosely coupled networks. The main con-

tribution are the creation of semantic routing tables

and an efﬁcient update mechanism. Their entries are

based on semantic aggregations, which rely on tax-

onomies and a distance measure to obtain the shortest

path to queried individuals. The usage of ASP enable

the application of the same formalism for knowledge

representation, reasoning, and query resolution. The

applied taxonomies are automatically extracted from

a commonsense knowledge source and are provided

as an ontology in ASP. Additionally, they can be dy-

namically adapted to the current situation. The frame-

work for the extraction has been presented in (Jakob

et al., 2021).

In our future work, we plan to integrate the

presented semantic routing mechanism into the dis-

tributed and multi-agent-based knowledge base intro-

duced in (Jakob et al., 2020). To prevent that all rout-

ing entries are merged to the same base class, we plan

to provide methods to adjust the depth of the aggre-

gation. Finally, we want to comprehensively evaluate

the proposed routing algorithm in a large scale search

& rescue scenario simulation

and aim to compare the

presented approach with other semantic or content-

based approaches.

REFERENCES

Brewka, G., Eiter, T., and Truszczy

nski, M. (2011). Answer

Set Programming at a Glance. Communications of the

ACM, 54(12):92–103.

Gebser, M., Kaminski, R., Kaufmann, B., and Schaub,

T. (2014). Clingo=ASP+Control: Extended Report.

Technical report, Knowledge Processing and Informa-

tion Systems.

omez Santill

an, C., Cruz Reyes, L., Meza Conde, E.,

Schaeffer, E., and Castilla Valdez, G. (2010). A

Self-Adaptive Ant Colony System for Semantic Query

Routing Problem in P2P Networks. Computaci

on y

Sistemas, 13(4):433–448.

Gritter, M. and Cheriton, D. R. (2001). An architecture for

content routing support in the internet. In USITS, vol-

ume 1, pages 4–4.

Jacobson, V., Smetters, D. K., Thornton, J. D., Plass, M. F.,

Briggs, N. H., and Braynard, R. L. (2009). Network-

ing named content. In Proceedings of the 5th inter-

national conference on Emerging networking experi-

ments and technologies, pages 1–12.

Jakob, S., Jahl, A., Baraki, H., and Geihs, K. (2020). A Self-

Organizing Multi-Agent Knowledge Base. Accepted

for publication at IEEE ICWS 2020.

Jakob, S., Jahl, A., Baraki, H., and Geihs, K. (2021). Gen-

erating Commonsense Ontologies with Answer Set

Programming. Accepted for publication at ICAART

2021.

Koloniari, G. and Pitoura, E. (2004). Content-based Rout-

ing of Path Queries in Peer-to-Peer Systems. In Inter-

national Conference on Extending Database Technol-

ogy, pages 29–47. Springer.

Michlmayr, E., Pany, A., and Kappel, G. (2007). Using Tax-

onomies for Content-based Routing with Ants. Com-

puter Networks, 51(16):4514–4528.

Pireddu, L. and Nascimento, M. A. (2004). Taxonomy-

Based Routing Indices for Peer-to-Peer Networks. In

Workshop on Peer-to-Peer Information Retrieval.

Speer, R., Chin, J., and Havasi, C. (2017). ConceptNet 5.5:

An Open Multilingual Graph of General Knowledge.

In Proceedings of the Thirty-First AAAI Conference

on Artiﬁcial Intelligence, pages 4444–4451.

Visala, K., Lagutin, D., and Tarkoma, S. (2009). LANES:

An Inter-Domain Data-Oriented Routing Architec-

ture. In Proceedings of the 2009 workshop on Re-

architecting the internet, pages 55–60.

https://www.emergencity.de/ (December 16, 2020)

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

1004
