Unsupervised Gaze Prediction in Egocentric Videos by Energy-based

Surprise Modeling

Sathyanarayanan N. Aakur and Arunkumar Bagavathi

Department of Computer Science, Oklahoma State University, Stillwater, OK, 74078, U.S.A.

Keywords:

Unsupervised Gaze Prediction, Egocentric Vision, Temporal Event Segmentation, Pattern Theory.

Abstract:

Egocentric perception has grown rapidly with the advent of immersive computing devices. Human gaze pre-

diction is an important problem in analyzing egocentric videos and has primarily been tackled through either

saliency-based modeling or highly supervised learning. We quantitatively analyze the generalization capa-

bilities of supervised, deep learning models on the egocentric gaze prediction task on unseen, out-of-domain

data. We ﬁnd that their performance is highly dependent on the training data and is restricted to the domains

speciﬁed in the training annotations. In this work, we tackle the problem of jointly predicting human gaze

points and temporal segmentation of egocentric videos without using any training data. We introduce an unsu-

pervised computational model that draws inspiration from cognitive psychology models of event perception.

We use Grenander’s pattern theory formalism to represent spatial-temporal features and model surprise as a

mechanism to predict gaze ﬁxation points. Extensive evaluation on two publicly available datasets - GTEA

and GTEA+ datasets-shows that the proposed model can signiﬁcantly outperform all unsupervised baselines

and some supervised gaze prediction baselines. Finally, we show that the model can also temporally segment

egocentric videos with a performance comparable to more complex, fully supervised deep learning baselines.

1 INTRODUCTION

The emergence of wearable and immersive comput-

ing devices for virtual and augmented reality has en-

abled the acquisition of images and videos from a

ﬁrst-person perspective. Given the recent advances in

computer vision, egocentric analysis could be used to

infer the surrounding scene and enhance the quality of

living through immersive, user-centric applications.

At the core of such an application is the need to under-

stand the user’s actions and where they are looking.

More speciﬁcally, gaze prediction is an essential task

in egocentric perception. It refers to the process of

predicting human ﬁxation points in the scene with re-

spect to the head-centered coordinate system. Beyond

enabling more efﬁcient video analysis, studies from

psychology have shown that human gaze estimation

capture human intent to help collaboration (Huang

et al., 2015). While the tasks of activity recognition

and segmentation have been explored in recent liter-

ature (Lea et al., 2016), we aim to tackle the task of

unsupervised gaze prediction and temporal event seg-

mentation in a uniﬁed framework.

Drawing inspiration from psychology (Horstmann

and Herwig, 2015; Horstmann and Herwig, 2016; Za-

cks et al., 2001), we identify that the notion of pre-

dictability and surprise is a common mechanism to

jointly predict gaze and perform temporal segmenta-

tion. Deﬁned broadly as the surprise-attention hy-

pothesis, studies have found that any deviations from

expectations have a strong effect on both attention

processing and event perception in humans. Specif-

ically, short-term spatial surprise, such as between

subsequent frames of a video, has a high probability

of human ﬁxation and affects saccade patterns. Long-

term temporal surprise leads to the perception of new

events (Zacks et al., 2001). We leverage such ﬁndings

and formulate a framework that jointly models both

short-term and long-term surprise using Grenander’s

pattern theory (Grenander, 1996) representations.

A signiﬁcant departure from recent pattern the-

ory formulations (Aakur et al., 2019), our framework

models bottom-up, feature-level spatial-temporal cor-

relations in egocentric videos. We represent the

spatial-temporal structure of egocentric videos us-

ing Grenander’s pattern theory formalism (Grenander,

1996). The spatial features are encoded in a local con-

ﬁguration, whose energy represents the expectation of

the model with respect to the recent past. Conﬁgu-

rations are aggregated across time to provide a local

Aakur, S. and Bagavathi, A.

Unsupervised Gaze Prediction in Egocentric Videos by Energy-based Surprise Modeling.

DOI: 10.5220/0010288009350942

In Proceedings of the 16th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2021) - Volume 5: VISAPP, pages

935-942

ISBN: 978-989-758-488-6

935

MxNgridoninput

Time

FeatureConfiguration

LocalTemporal

ConfigurationProposal

GazePrediction

LocalProposal

Figure 1: Overall Approach. The proposed approach consists of three essential stages: constructing the feature conﬁguration,

a local temporal conﬁguration proposal and the ﬁnal gaze prediction. Note that the output of the gaze prediction module is

another conﬁguration which is visualized as an attention map.

temporal proposal for capturing the spatial-temporal

correlation of video features. An acceptor function is

used to switch between saccade and ﬁxation modes

to select the ﬁnal conﬁguration proposal. Localiz-

ing the source of maximum surprise provides atten-

tion points, and monitoring global surprise allows for

temporally segmenting videos.

Contributions. Our contributions are four-fold: (i)

We evaluate the ability of supervised gaze prediction

models to generalize to out of domain data, (ii) we in-

troduce an unsupervised gaze prediction framework

based on surprise modeling that enables gaze pre-

diction without training and outperforms all unsuper-

vised baselines and some supervised baselines, (iii)

we demonstrate that the pattern theory representation

can be used to tackle different tasks such as unsuper-

vised video event segmentation to achieve compara-

ble performance to state-of-the-art deep learning ap-

proaches, and (iv) we show that pattern theory repre-

sentations can be extended to beyond semantic, sym-

bolic reasoning mechanisms.

2 RELATED WORK

Saliency-based models treat the gaze prediction prob-

lem by modeling the visual saliency of a scene and

identifying areas that can attract the gaze of a per-

son. At the core of traditional saliency prediction

methods is the idea of feature integration (Treisman

and Gelade, 1980), which is based on the combi-

nation of multiple levels of features. Introduced by

Itti et al (Itti and Koch, 2000; Itti and Baldi, 2006),

there have been many approaches to saliency predic-

tion (Bruce and Tsotsos, 2006; Leboran et al., 2016;

Hou et al., 2011; Leboran et al., 2016), including

graph-based models (Harel et al., 2007), supervised

CNN-based saliency (Jiang et al., 2015) and video-

based saliency (Hossein Khatoonabadi et al., 2015;

Leboran et al., 2016).

Supervised Gaze Prediction has been an increas-

ingly popular way to tackle the problem of gaze pre-

diction in egocentric videos. Li et al. (Li et al.,

2013) proposed a graphical model to combine ego-

centric cues such as camera motion, hand positions,

and motion and modeled gaze prediction as a func-

tion of these latent variables. Deep learning-based

approaches have been the other primary modeling op-

tion. Zhang et al. (Zhang et al., 2017) used a Genera-

tive Adversarial Network (GAN) to handle the prob-

lem of gaze anticipation. The GAN was used to gen-

erate future frames, and a 3D CNN temporal saliency

model was used to predict gaze positions. Huang et

al. (Huang et al., 2018) used recurrent neural net-

works to predict gaze positions by combining task-

speciﬁc cues with bottom-up saliency. While very

useful, such deep learning models are increasingly

complex, and the amount of training data required by

such approaches is enormous.

3 MOTIVATION: WHY

UNSUPERVISED GAZE

PREDICTION?

In this section, we analyze the ability of current su-

pervised models to generalize beyond their training

domain. Most success in egocentric gaze prediction

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

936

Table 1: Evaluation of generalization capabilities of super-

vised models across scenes and domains.

Approach

Same Different

∆Domain Domain

(AAE) (AAE)

CNN-LSTM Predictor 9.82 16.49 6.67

2-Stream CNN 5.52 11.35 5.83

2-Stream CNN + LSTM 5.35 10.71 5.36

Ours (Unsupervised)* 11.6 9.2 -

*Does not use any training data.

has been through supervised learning. These mod-

els (Huang et al., 2018; Li et al., 2013; Zhang et al.,

2017), primarily based on deep learning approaches,

require large amounts of annotated training data in

the form of gaze locations and other auxiliary data

such as task label (Huang et al., 2018), camera mo-

tion, and hand location (Li et al., 2013), to name a

few. Such information requires manual human anno-

tation and can be expensive to obtain. Additionally,

it may not be possible to get annotated data for ev-

ery eventuality and domains for training supervised

models. The combination of these two issues means

that current systems are restricted to speciﬁc envi-

ronments. We evaluate cross-domain gaze prediction

by training supervised models on the GTEA Gaze+

dataset (Li et al., 2013) and evaluating on the GTEA

Gaze dataset (Fathi et al., 2012).

We use three supervised models as our baselines.

Namely, we evaluate a two-stream CNN architecture

to model spatial and temporal dynamics for saliency-

based attention prediction. We also add an LSTM-

based predictor to the two-stream model to add a sac-

cade model on top of the ﬁxation points provided by

the CNN models. Finally, we train a simple CNN-

LSTM model to predict the gaze position from RGB

videos. Combined, these three baselines represent the

basic architectures used in the gaze prediction task us-

ing deep learning models. We quantify performance

using the Average Angular Error (AAE) and summa-

rize the results in Table 1. We denote GTEA Gaze+

as the same domain data and GTEA Gaze as the dif-

ferent domain data. We use the GTEA Gaze+ dataset

as the training domain since it has signiﬁcantly more

annotated data than the GTEA Gaze dataset.

It can be seen that increasing the complexity of

the model provides exciting results on scenes from the

same domain (i.e., testing within the same dataset) but

also suffers a tremendous loss of performance when

testing on scenes from different domains. The 2-

Stream CNN models perform very well on the same

domain, achieving an average angular error as low as

5.52, but also sees a signiﬁcant drop (5.83 and 5.36,

with and without an LSTM predictor, respectively).

The simple CNN-LSTM baseline performs reason-

ably well on the same domain data without any bells

and whistles but performs worse than saliency-based

models on out-of-domain data. In fact, all three mod-

els perform worse than Center Bias, which always

predicts the center point of the frame as the gaze po-

sition. We also show the performance of our unsu-

pervised model that does not use any training data.

Our model performs well across both domains with-

out signiﬁcant loss in performance.

4 ENERGY-BASED SURPRISE

MODELING

In this section, we introduce our energy-based sur-

prise modeling approach for gaze prediction, as illus-

trated in Figure 1 and described in Algorithm 1. We

ﬁrst introduce the necessary background on the pat-

tern theory representation and present the proposed

gaze prediction formulation.

4.1 Pattern Theory Representation

Representing Features. Following Grenander’s no-

tations ((Grenander, 1996)), the basic building blocks

of our representation are atomic components called

generators (g

). The collection of all possible gen-

erators in a given environment is termed the genera-

tor space (G

). While there can exist various types

of generators, as explored in prior pattern theory ap-

proaches (Aakur et al., 2019), we consider only one

type of generator, namely the feature generator. We

deﬁne feature generators as features extracted from

videos and are used to estimate the gaze at each time

step. Each generator represents both appearance- and

motion-based features at different spatial locations in

each frame of the video.

Capturing Local Regularities. We model tempo-

ral and spatial associations among generators through

bonds. Each generator g

has a ﬁxed number of

bonds called the arity of a generator (w(g

)∀g

∈

). These bonds are symbolic representations of

the structural and contextual relationships shared be-

tween generators. Each bond is directed and are dif-

ferentiated through the direction of information ﬂow

as either in-bonds or out-bonds. Each bond is iden-

tiﬁed by a unique coordinate and bond value such

that the j

bond of a generator g

∈ G

is denoted as

dir

), where dir denotes the direction of the bond.

The energy of a bond is used to quantify the

strength of the relationship expressed between two

generators and is given by the function:

struct

(β

), β

)) = w

tanh(φ(g

, g

)). (1)

Unsupervised Gaze Prediction in Egocentric Videos by Energy-based Surprise Modeling

937

where β

and β

represent the bonds from the gen-

erators g

and g

, respectively; φ(·) is the strength

of the relationship expressed in the bond; and w

a constant used to scale the bond energies. In our

framework, φ(·) is a distance metric and provides a

measure of similarity between the features expressed

through their respective generators. Generators com-

bine through their corresponding bonds to form com-

plex structures called conﬁgurations. Each conﬁgura-

tion has an underlying graph topology, speciﬁed by a

connector graph σ ∈Σ, where Σ is the set of all avail-

able connector graphs. σ is also called the connection

type and is used to deﬁne the directed connections be-

tween the elements of the conﬁguration. In our work,

we restrict Σ to a lattice conﬁguration, as illustrated

in Figure 1, with bonds extending spatially and ag-

gregated temporally.

4.2 Local Conﬁguration Proposal

The ﬁrst step in the framework is the construction of

a lattice conﬁguration called the feature conﬁguration

( ˆc). The lattice conﬁguration is a N ×N grid, with

each point (generator) in the conﬁguration represent-

ing a possible region of ﬁxation. We construct the

feature conﬁguration at time t (deﬁned as ˆc(t)) by di-

viding the input image into an N ×N grid. Each gen-

erator is populated by extracting features from each of

these grids. These features can be appearance-based

such as RGB values, motion features such as optical

ﬂow (Brox and Malik, 2010), or deep learning fea-

tures (Redmon et al., 2016). We experiment with both

appearance and motion-based features and ﬁnd that

motion-based features (Section 5) provide distract-

ing cues, especially with signiﬁcant camera motion

associated with egocentric videos. Bonds are quanti-

ﬁed across generators with the spatial locality, i.e., all

neighboring generators are connected through bonds.

The bond energy is set to 1 by default.

A local proposal for the time steps t is done

through a temporal aggregation of the previous k con-

ﬁgurations across time. The aggregation enforces

temporal consistency into the prediction and selec-

tively inﬂuences the current prediction. Bonds are

established across time by computing bonds between

generators with a spatial locality and are quantiﬁed

using the energy function deﬁned in Equation 1. For

example, a bond can be established with generator

(t) in feature conﬁguration at time t and the conﬁg-

uration at time t −1. We deﬁne φ(g

, g

) to be a met-

ric that combines both appearance-based and motion-

based features. We ensure that the function φ(g

, g

)

produces nonzero values proportional to the degree

of correlation between the features, both spatially and

Algorithm 1: Gaze Prediction using Pattern

Theory.

1 Gaze Prediction (I

, G

t−1

, k, p, p

, c

);

2 ˆc(t) ← f eatureCon f ig(I

, G

)

3 c

(t) ←temporalAggregate(ˆc

t−1

)

4 t ←Uni f ormSample(0, 1)

5 if t < p

then

6 c(t) ← c

(t)

7 else

8 c(t) ← c

9 G

(t) ← {g

, g

, . . . , g

∈ c(t)}

10 g

pred(t)

← selectGenerator(G

(t))

11 foreach g

∈ c(t) do

12 if E(g

pred

|c(t)) < E(g

|c(t)) then

13 t ←Uni f ormSample(0, 1)

14 if t < p then

15 E(g

) ←

E(g

)

d(g

pred

(t),g

pred

(t−1))

16 g

pred

(t) ← g

17 end

18 return g

pred

(t)

temporally and is formally deﬁned as

φ(g

, g

) = min(α, φ

, g

) + φ

, g

)) (2)

where α is a modulating factor to ensure that the

energy does not explode to inﬁnity, φ

, g

) and

, g

) are appearance-based and motion-based

features, respectively; φ

, g

) is used to quan-

tify the appearance-based afﬁnity and is given by

, g

) = 1 −

∑

i=1

√

∑

i=1

)

√

∑

i=1

)

, and is used to

capture the spatial correlation between the visual fea-

tures at a given location in the current frame. On the

other hand, φ

, g

) is used to quantify the motion-

based bond afﬁnity and is given by φ

, g

) =

∑

i=1

−g

)(g

−g

)

. Both metrics produce nonzero val-

ues proportional to the degree of correlation. Hence,

their use in Equation 1 ensures that the bond energy is

reﬂective of the predictability of generators at various

time steps.

The temporal consistency is enforced through an

ordered weighted averaging aggregation operation of

conﬁgurations across time. Formally, the temporal

aggregation is a mapping function F : c

−→ c that

maps n conﬁgurations from previous time steps into

a single conﬁguration as a local proposal for time

t. The function F has an associated set of weights

W = [w

, w

, . . . w

] lying in the unit interval and sum-

ming to one. W is used to aggregate conﬁgurations

across time using the function F given by

F(c

t−i

, . . . c

) =

∑

i=1

c

t−i

) (3)

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

938

where  refers to pairwise aggregation of bonds

across conﬁgurations c

and c

t−i

. W is a set of weights

used to scale the inﬂuence of each conﬁguration from

the past on the current prediction. W is set to be an

exponential decay function given by a(1 −b)

, where

b is the decay factor and a is the initial value. We set

k to video fps, a and b are is set to 1 and 0.95. Hence,

the temporally local conﬁguration has a more signif-

icant inﬂuence on the current conﬁguration proposal

compared to temporally distant conﬁgurations.

4.3 Gaze Prediction

Intuitively, each generator in the conﬁguration corre-

sponds to the predictability of each spatial segment

in the image. Hence, the predicted gaze position cor-

responds to the grid cell with most surprise, i.e., the

generator with maximum energy. We begin by con-

structing the initial feature conﬁguration for time t

and temporally aggregating it to obtain the initial con-

ﬁguration c0(t) as described in Section 4.2. Algo-

rithm 1 illustrates the process of ﬁnding the generator

with maximum energy. C

t−1

, I

, G

refer to the set of

past k conﬁgurations, the video frame at time t, and

the generator space, respectively.

In addition to na

ıve surprise modeling, we intro-

duce additional constraints to more closely model hu-

man gaze, such as the choice between saccade and

ﬁxation using two approaches. First, we do so by hav-

ing two acceptor functions (lines 5 −8 and 12 −15).

In the ﬁrst function, the local temporal proposal is ac-

cepted with a probability of p

or rejected in favor

of a conﬁguration with strong center bias (c

) as the

ﬁnal prediction for time t. The role of this acceptor

function is to prevent the model from being distracted

due to spurious patterns in the input visual stream.

In the second acceptor function, we allow the model

to switch between saccade and ﬁxation modes by not

forcing the model to always choose the generator with

the highest energy as the gaze position.

Every newly proposed generator is accepted if it

passes the test at line 12-14, which is either true for

new generators with energy lower than the current

generator’s or true with a certain probability (p) that

is proportional to the energy difference between the

recent and the old generators. Second, we scale each

generator’s energy with a distance function (d(·) in

line 15) that quantiﬁes the distance between the pre-

vious predicted gaze point and the current generator.

This scaling ensures that the model can ﬁxate on a

chosen target while allowing for the saccade function

to select a different target if required. Once the gener-

ator (g

pred

) is chosen, the ﬁnal gaze point (x

pred

, y

pred

)

is computed as

pred

, y

pred

) = (c

+ 0.5 ∗W

, c

+ 0.5 ∗H

) (4)

where (c

, c

) is the offset of the grid from the top

left corner of the image; (W

, H

) are grid width and

height respectively.

5 EXPERIMENTAL EVALUATION

In this section, we describe the experimental setup

used to evaluate our approach and present quantita-

tive and qualitative results on both gaze prediction and

event segmentation.

5.1 Data and Evaluation Setup

Data. We evaluate our approach on the GTEA (Fathi

et al., 2012) and GTEA+ (Li et al., 2013) datasets.

The two datasets consist of video sequences on meal

preparation tasks. GTEA contains 17 sequences of

tasks from 14 subjects, with each sequence lasting

about 4 minutes. GTEA+ contains longer sequences

of 5 subjects performing 7 activities. We use the of-

ﬁcial splits for both GTEA and GTEA+ as deﬁned in

prior works (Fathi et al., 2012; Li et al., 2013).

Evaluation Metrics. We use Average Angular Er-

ror (AAE) (Riche et al., 2013) as our primary eval-

uation metric, following prior efforts (Itti and Baldi,

2006; Fathi et al., 2012; Li et al., 2013). AAE is the

angular distance between the predicted gaze location

and the ground truth. Area Under the Curve (AUC)

measures the area under a curve for true positive ver-

sus false-positive rates under various threshold val-

ues on saliency maps. AUC is not directly applicable

since our prediction is not a saliency map.

5.2 Baseline Approaches and Ablation

Baselines. We compare with state-of-the-art unsuper-

vised and supervised approaches. We consider un-

supervised saliency models such as Graph-Based Vi-

sual Saliency (GBVS) (Harel et al., 2007), Attention-

based Information Maximization (AIM) (Bruce and

Tsotsos, 2006), Itti’s model (Itti and Koch, 2000),

Adaptive Whitening Saliency (AWS) (Leboran et al.,

2016), Image Signature Saliency (ImSig) (Hou et al.,

2011), OBDL (Hossein Khatoonabadi et al., 2015)

and AWS-D (Leboran et al., 2016). We also com-

pare against supervised models (DFG (Zhang et al.,

2017), Yin (Li et al., 2013) and SALICON (Jiang

et al., 2015), LDTAT (Huang et al., 2018)) that lever-

age annotations and representation learning capabili-

ties of deep neural networks.

Unsupervised Gaze Prediction in Egocentric Videos by Energy-based Surprise Modeling

939

Table 2: Evaluation on GTEA and GTEA+ datasets. We

outperform all unsupervised and some supervised baselines.

Supervision

Approach GTEA GTEA+

(AAE) (AAE)

None

Ours 9.2 11.6

Ours (Optical Flow) 10.1 13.8

Ours (Saccade) 12.5 14.6

AIM 14.2 15.0

GBVS 15.3 14.7

OBDL 15.6 19.9

AWS 17.5 14.8

AWS-D 18.2 16.0

Itti’s model 18.4 19.9

ImSig 19.0 16.5

Full

LDTAT 7.6 4.0

Yin 8.4 7.9

DFG 10.5 6.6

SALICON 16.5 15.6

Ablation. We perform ablations of our approach to

test the effectiveness of each component. We evalu-

ate the effect of different features by including optical

ﬂow (Brox and Malik, 2010) as input to the model.

We remove the prior spatial constraint and term the

model “Ours (Saccade)”, highlighting its tendency to

saccade through the video without ﬁxating.

5.3 Quantitative Evaluation

We present the results of our experimental evaluation

in Table 2. We present the Average Angular Error

(AAE) for both the GTEA and GTEA+ datasets and

group the baseline approaches into two categories - no

supervision and full supervision. Our approach out-

performs all unsupervised methods on both datasets.

The overall performance on GTEA Gaze is lower than

that on GTEA Gaze Plus, which could arguably be at-

tributed to the fact that 25% of ground truth gaze mea-

surements are missing. Note that the gap between the

performance of fully supervised models between the

two datasets is high and shows that they suffer from

the lack of a large number of training examples, which

is signiﬁcantly lower in GTEA.

It is interesting to note that our model outperforms

saliency based methods, including the closely related

graph based visual saliency model and Itti’s model.

We attribute it to the use of multiple acceptor func-

tions (Section 4.3), which allows us to switch between

ﬁxation and saccade modes and hence is not hin-

dered by saliency-based features that do not capture

task-dependent attention. Note that we signiﬁcantly

outperform SALICON (Jiang et al., 2015), a fully

supervised convolutional neural network trained on

ground-truth saliency maps on both datasets. We also

outperform the GAN-based gaze prediction model

DFG (Zhang et al., 2017) on the GTEA dataset, where

Table 3: Evaluation on the temporal video segmentation

task on the GTEA Gaze datasets.

Supervision Approach Accuracy

Full

Spatial-CNN (S-CNN) 54.1

Bi-LSTM (Lea et al., 2016) 55.5

EgoNet (Singh et al., 2016) 57.6

Dilated TCN (Lea et al., 2016) 58.3

TCN (Lea et al., 2016) 64.1

None

Ours w/ 3D-CNN features 35.17

Ours (Streaming Eval.) 57.92

the amount of training data is limited. We also offer

competitive performance to Yin et al. (Li et al., 2013),

who use auxiliary information in the form of visual

cues such as hands, objects of interest, and faces.

This gap is particularly narrowed when considering

domains with lower data (GTEA Gaze) and the lack

of generalization (Section 3) shown by common deep

learning approaches to domains outside their training

environment. It should be noted that our approach

runs at 45 fps in a single threaded application, run on

an AMD ThreadRipper CPU, a signiﬁcantly acceler-

ated method compared to deep learning approaches

and offers a way forward for resource-constrained

prediction.

5.4 Video Event Segmentation

To highlight our model’s ability to understand video

semantics and its subsequent ability to predict gaze

locations, we adapt the framework to perform event

segmentation in streaming videos. Instead of local-

izing speciﬁc generators, we monitor the global sur-

prise by considering the energy of the entire conﬁgu-

ration c(t). The energy of a conﬁguration c is the sum

of the bond energies (Equation 1) in a conﬁguration

and is given by

E(c) = −

∑

(β

,β

)∈c

struct

(β

), β

)) (5)

where a lower energy indicates that the generators are

closely associated with each other. Hence, a higher

energy suggests that the surprise faced by the frame-

work is higher. The conﬁguration (frame) with the

highest energy is considered to hold the highest sur-

prise and is selected as an event boundary. We use the

error gating-based segmentation used in (Aakur and

Sarkar, 2019). We set the error threshold to be 2.5 as

opposed to 1.5, and the energy of the conﬁguration

as the perceptual quality metric for event segmenta-

tion. We evaluate the performance of the approach on

the GTEA dataset and quantify its performance us-

ing accuracy. We use a 3D-CNN (Ji et al., 2012) net-

work pre-trained on UCF-101 (Soomro et al., 2012)

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

940

(a)

(b)

(c)

Figure 2: qualitative Examples: We present the predictions made by our model for three different sequences across different

tasks and domains. The predictions are shown as a gaussian map and the ground truth is highlighted in red.

to extract features. We use k-means clustering to as-

sign each segment to a cluster label. We then align

the prediction and ground-truth using the Hungarian

method before computing accuracy, following prior

works (Lea et al., 2016). As can be seen from Ta-

ble 3, our unsupervised approach achieves a tempo-

ral segmentation accuracy of 35.17%. We compare

against several state-of-the-art supervised deep learn-

ing approaches such as Spatial-CNN, Bi-LSTM, and

Temporal Convolutional Networks (TCN) (Lea et al.,

2016), which achieve accuracy of 54.1%, 55.5% and

64.1, respectively. Note that the class-agnostic accu-

racy, i.e., when evaluated in a streaming manner per

video, we obtain a segmentation accuracy of 57.92%,

which suggests that the actual segmentation is robust.

5.5 Qualitative Evaluation

We present some qualitative visualizations in Fig-

ure 2. We illustrate three cases from our model’s pre-

dictions. The ground-truth gaze position is shown in

red, and our predictions are shown as a heatmap. It

is interesting to note (particularly highlighted in Fig-

ure 2(b)) is the tendency of our model to ﬁxate on

highly relevant regions and subsequent objects, even

though the ground-truth gaze positions vary. The pre-

dicted gaze then quickly adapts to the newer position

and starts ﬁxating on the relevant object. This charac-

teristic suggests that despite purely bottom-up visual

processing, the notion of “surprise” has an underlying

task-bound nature. We attribute this to the two accep-

tor functions (lines 5−8 and 12−15) deﬁned in Algo-

rithm 1). The former allows us to enforce some spatial

bias into the model and force the gaze prediction back

to the center of the image (the effect is highlighted in

Figure 2(a)). The latter helps ﬁxate on certain objects

for a longer duration and help handle clutter and oc-

clusion for deriving task-speciﬁc object affordances,

without any speciﬁc training objectives and data.

6 CONCLUSION

In this work, we analyze the generalization ability

of supervised deep learning models to different do-

mains and scenes for the egocentric gaze prediction

task and ﬁnd that their performance suffers when pre-

sented with out-of-domain data. To break the increas-

ing dependence on training data, we present one of the

ﬁrst approaches to a uniﬁed framework for tackling

unsupervised gaze prediction and temporal segmenta-

tion, based on energy-based surprise modeling. Using

a novel formulation, we demonstrate that pattern the-

ory can be used to predict gaze locations in egocentric

Unsupervised Gaze Prediction in Egocentric Videos by Energy-based Surprise Modeling

941

videos. Our pattern theory representation also forms

the basis for unsupervised temporal video segmenta-

tion. Through extensive experiments, we demonstrate

that we obtain state-of-the-art performance on the un-

supervised gaze prediction task and provide compet-

itive performance on the unsupervised temporal seg-

mentation task on egocentric videos.

ACKNOWLEDGEMENT

This research was supported in part by the US Na-

tional Science Foundation grant IIS 1955230.

REFERENCES

Aakur, S., de Souza, F., and Sarkar, S. (2019). Generating

open world descriptions of video using common sense

knowledge in a pattern theory framework. Quarterly

of Applied Mathematics, 77(2):323–356.

Aakur, S. N. and Sarkar, S. (2019). A perceptual prediction

framework for self supervised event segmentation. In

Proceedings of the IEEE Conference on Computer Vi-

sion and Pattern Recognition, pages 1197–1206.

Brox, T. and Malik, J. (2010). Large displacement optical

ﬂow: descriptor matching in variational motion esti-

mation. IEEE Transactions on Pattern Analysis and

Machine Intelligence, 33(3):500–513.

Bruce, N. and Tsotsos, J. (2006). Saliency based on infor-

mation maximization. In Advances in Neural Infor-

mation Processing Systems, pages 155–162.

Fathi, A., Li, Y., and Rehg, J. M. (2012). Learning to recog-

nize daily actions using gaze. In European Conference

on Computer Vision, pages 314–327. Springer.

Grenander, U. (1996). Elements of pattern theory. JHU

Press.

Harel, J., Koch, C., and Perona, P. (2007). Graph-based

visual saliency. In Advances in Neural Information

Processing Systems, pages 545–552.

Horstmann, G. and Herwig, A. (2015). Surprise attracts

the eyes and binds the gaze. Psychonomic Bulletin &

Review, 22(3):743–749.

Horstmann, G. and Herwig, A. (2016). Novelty biases at-

tention and gaze in a surprise trial. Attention, Percep-

tion, & Psychophysics, 78(1):69–77.

Hossein Khatoonabadi, S., Vasconcelos, N., Bajic, I. V., and

Shan, Y. (2015). How many bits does it take for a stim-

ulus to be salient? In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 5501–5510.

Hou, X., Harel, J., and Koch, C. (2011). Image signature:

Highlighting sparse salient regions. IEEE Transac-

tions on Pattern Analysis and Machine Intelligence,

34(1):194–201.

Huang, C.-M., Andrist, S., Saupp

e, A., and Mutlu, B.

(2015). Using gaze patterns to predict task intent in

collaboration. Frontiers in Psychology, 6:1049.

Huang, Y., Cai, M., Li, Z., and Sato, Y. (2018). Predicting

gaze in egocentric video by learning task-dependent

attention transition. In Proceedings of the European

Conference on Computer Vision (ECCV), pages 754–

769.

Itti, L. and Baldi, P. F. (2006). Bayesian surprise attracts

human attention. In Advances in Neural Information

Processing Systems, pages 547–554.

Itti, L. and Koch, C. (2000). A saliency-based search mech-

anism for overt and covert shifts of visual attention.

Vision Research, 40(10-12):1489–1506.

Ji, S., Xu, W., Yang, M., and Yu, K. (2012). 3d convolu-

tional neural networks for human action recognition.

IEEE transactions on pattern analysis and machine

intelligence, 35(1):221–231.

Jiang, M., Huang, S., Duan, J., and Zhao, Q. (2015). Sali-

con: Saliency in context. In Proceedings of the IEEE

Conference on Computer Vision and Pattern Recogni-

tion, pages 1072–1080.

Lea, C., Vidal, R., Reiter, A., and Hager, G. D. (2016).

Temporal convolutional networks: A uniﬁed approach

to action segmentation. In European Conference on

Computer Vision, pages 47–54. Springer.

Leboran, V., Garcia-Diaz, A., Fdez-Vidal, X. R., and Pardo,

X. M. (2016). Dynamic whitening saliency. IEEE

Transactions on Pattern Analysis and Machine Intel-

ligence, 39(5):893–907.

Li, Y., Fathi, A., and Rehg, J. M. (2013). Learning to predict

gaze in egocentric video. In Proceedings of the IEEE

International Conference on Computer Vision, pages

3216–3223.

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You only look once: Uniﬁed, real-time object

detection. In Proceedings of the IEEE Conference on

Computer Vision and Pattern Recognition, pages 779–

788.

Riche, N., Duvinage, M., Mancas, M., Gosselin, B., and

Dutoit, T. (2013). Saliency and human ﬁxations:

State-of-the-art and study of comparison metrics. In

Proceedings of the IEEE International Conference on

Computer Vision, pages 1153–1160.

Singh, S., Arora, C., and Jawahar, C. (2016). First person

action recognition using deep learned descriptors. In

Proceedings of the IEEE Conference on Computer Vi-

sion and Pattern Recognition, pages 2620–2628.

Soomro, K., Zamir, A. R., and Shah, M. (2012). Ucf101:

A dataset of 101 human actions classes from videos in

the wild. arXiv preprint arXiv:1212.0402.

Treisman, A. M. and Gelade, G. (1980). A feature-

integration theory of attention. Cognitive Psychology,

12(1):97–136.

Zacks, J. M., Tversky, B., and Iyer, G. (2001). Perceiv-

ing, remembering, and communicating structure in

events. Journal of Experimental Psychology: Gen-

eral, 130(1):29.

Zhang, M., Teck Ma, K., Hwee Lim, J., Zhao, Q., and Feng,

J. (2017). Deep future gaze: Gaze anticipation on ego-

centric videos using adversarial networks. In Proceed-

ings of the IEEE Conference on Computer Vision and

Pattern Recognition, pages 4372–4381.

VISAPP 2021 - 16th International Conference on Computer Vision Theory and Applications

942
