Hydra: Practical Metadata Security for Contact Discovery, Messaging,

and Dialing

David Schatz, Michael Rossberg and Guenter Schaefer

Telematics and Computer Networks Research Group, Technische Universit

at Ilmenau, Germany

Keywords:

Strong Anonymity, Onion Encryption, Circuits, Messaging.

Abstract:

Communication metadata may leak sensitive information even when content is encrypted, e.g. when contacting

medical services. Unfortunately, protecting metadata is challenging. Existing approaches for anonymous

communications either are vulnerable in a strong (but feasible) threat model or have practicability issues like

intense usage of asymmetric cryptography. We propose Hydra, a mix network that is able to provide multiple

anonymous services in a uniform way. In contrast to previous messaging systems with strong anonymity,

we deliberately use padded onion-encrypted circuits. This allows to support connectionless applications like

contact discovery with authenticated key exchange, messaging, and dialing (signalling for connection-oriented

communications) with strong anonymity and relatively low latency. Our cryptography benchmarks show that

Hydra is able to process messages an order of magnitude faster than state of the art messaging systems with

strong anonymity. At the same time, bandwidth overhead is comparable to previous systems. We further

develop an analytical model to predict the end-to-end latency of Hydra and validate it in a testbed.

1 INTRODUCTION

IP-based human-to-human communications like

email, instant messaging and Voice over IP (VoIP)

are ubiquitous in the private and professional sector.

Consequently, it is crucial to protect the privacy of

users. While conﬁdentiality of content is achieved by

cryptographic mechanisms, communication metadata

is more challenging to protect. Unfortunately, meta-

data leakage may also be a serious privacy invasion

for users. E.g., the mere fact that someone contacted

a speciﬁc counseling or medical service may allow

to infer sensitive information (Mayer et al., 2016).

One challenge for realizing metadata conﬁdentiality

(anonymity) is that various characteristics of IP pack-

ets (like size, encrypted content) may be correlated at

different positions in the network.

Using communication mixes (Chaum, 1981) is

a promising approach to overcome the challenges:

Routing uniformly sized messages across multiple re-

lays and utilizing layered encryption defeats many

attacks, even if some relays act maliciously. Mes-

sages are further mixed in batches to prevent tim-

ing analyses. A more severe challenge for protect-

ing anonymity in the presence of global observers

are long-term intersection/disclosure attacks exploit-

ing user churn (Pham et al., 2011; Oya et al., 2014).

To mitigate disclosure attacks, users should appear

to be online as long as possible, even when they are

not participating in a communication. For this, recent

anonymous messaging systems rely on synchronized

rounds, requesting every user to send a message ev-

ery round (Lazar et al., 2018; Gelernter et al., 2016;

Kwon et al., 2017). They further require asymmetric

cryptography for layered encryption, restricting their

scalability: Supporting millions of users with low

end-to-end latency requires many powerful mixes.

In contrast, scalability for connection-oriented ap-

plications is achieved by onion routing, with Tor be-

ing the most prominent implementation today (Din-

gledine et al., 2004): Users create circuits before-

hand by exchanging session keys with each relay on

selected paths. For onion encryption of application

data, only symmetric ciphers are required. How-

ever, onion routing as implemented by Tor is sus-

ceptible to attacks based on trafﬁc and timing anal-

yses. First, timing of circuit setup at different re-

lays may be correlated by malicious mixes. Sec-

ond, attackers may correlate relative timing between

data packets of the same connection at sender and

receiver. This is especially effective when attackers

introduce artiﬁcial patterns, i.e. network ﬂow water-

marking (Wang et al., 2007). Recent circuit-based

systems like TARANET (Chen et al., 2018) and Yo-

Schatz, D., Rossberg, M. and Schaefer, G.

Hydra: Practical Metadata Security for Contact Discovery, Messaging, and Dialing.

DOI: 10.5220/0010262201910203

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 191-203

ISBN: 978-989-758-491-6

191

del (Lazar et al., 2019) tackle both problems: Cir-

cuit setup packets are batched and mixed before for-

warding. Furthermore, the packet ﬂow of each cir-

cuit is shaped to a constant rate at each hop by for-

warding packets at deterministic times and injecting

dummy packets if necessary (padded circuit). Un-

fortunately, both systems share the drawback that re-

ceivers directly attach to circuit endpoints: First, this

implies that the same circuit may not be used to con-

tact two different users. Otherwise, observers could

infer that these two users have a common contact and

thus are likely to also know each other. Second, loca-

tion anonymity is weak: Malicious users may easily

disclose the IP address of their communication part-

ners, e.g. by selecting a cooperating endpoint.

In this article we present Hydra, a system that pro-

vides strong anonymity for connectionless services.

Similar to Yodel, users are synchronized to periodi-

cally create onion encrypted circuits that are used for

multiple messages. During such an epoch, only sym-

metric cryptography is required, signiﬁcantly improv-

ing scalability. Circuit padding provides unlinkabil-

ity of circuit endpoints to users, even when users dis-

connect or active attacks are performed. To support

common services like contact discovery with authen-

ticated key exchange, messaging, and dialing with

low latency, a padding rate like 3 pkt/min is sufﬁcient.

Consequently, Hydra is suited for mobile devices, en-

abling widespread deployment and large anonymity

sets. Messages are forwarded across circuit endpoints

by a rendezvous mechanism that overcomes the weak-

nesses of similar systems: Hydra provides strong lo-

cation anonymity and a circuit may be used for differ-

ent contacts, the latter inspiring the name Hydra.

The rest of this article is structured as follows:

Sec. 2 deﬁnes our objectives and threat model. Re-

lated work is discussed in Sec. 3. Design details of

Hydra are presented in Sec. 4. We evaluate Hydra in

Sec. 5 and conclude in Sec. 6.

2 SYSTEM OBJECTIVES AND

THREAT MODEL

First of all, users must be able to discover new con-

tacts. This should be possible based on the knowledge

of long-term user pseudonyms. After contact discov-

ery, users must be able to send arbitrary messages to

their contacts, with end-to-end conﬁdentiality and au-

thenticity protected by session keys. When recipients

are ofﬂine, messages must be stored for later delivery.

Non-functional objectives are categorized as follows:

Anonymity. Two forms of anonymity need to be

focused on: Communication relationships (includ-

ing metadata like frequency and duration) shall be

hidden from third parties (relationship anonymity).

To avoid geographical tracking (Mayer et al., 2016),

location anonymity is required, i.e. the mapping of

pseudonyms to IP addresses must be hidden from

third parties and contacts if they are not trusted. For

both forms of anonymity, graceful degradation is re-

quired: Small fractions of malicious or compromised

system entities shall not be able to break anonymity

to a disproportional extend. Moreover, forward se-

crecy is desirable, i.e. leaked long-term secrets shall

not compromise anonymity of past communications.

Quality of Service (QoS). End-to-end latency of

messages shall be low. Acceptable latencies depend

on the kind of application: Contact discovery is ex-

pected to be used infrequently (once per contact), per-

haps accepting latencies up to minutes or hours. Other

messages should be delivered in the order of seconds.

Efﬁciency and Scalability. For ﬁxed system re-

sources, the system shall support many active com-

munications with good QoS. Power consumption for

users shall be low to allow usage on mobile devices.

Moreover, horizontal scalability is required: The sys-

tem shall be able to support more users by adding

more system entities.

Threat Model. We assume powerful attackers: A

global external attacker may observe, manipulate,

delay, drop, replay, or forge packets. However, he

cannot bypass cryptographic protections (Dolev-Yao

model). In addition, malicious system entities may

share their internal state, e.g. key material. In coop-

eration with external attackers, their goal is to break

relationship anonymity of users. Naturally, the frac-

tion of malicious entities is assumed to be limited.

Malicious users may share their view on end-to-end

messages with attackers to break location anonymity

of their contacts.

3 RELATED WORK

We focus on anonymity systems that use communi-

cation mixes (Chaum, 1981) as a building block. To

recap, the main idea of a mix is to collect ﬁxed-sized

messages in a batch, discard duplicates, transform bit

patterns in a cryptographically secure way and for-

ward messages in randomized order. Using a chain of

mixes and layered encryption defeats a limited num-

ber of malicious mixes. For completeness, we note

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

192

that there are other primitives to anonymous com-

munication, namely Dining Cryptographer networks

(DC-nets) (Chaum, 1988) and private information re-

trieval (PIR). However, these techniques suffer from

inherent scalability issues due to broadcast mecha-

nisms or computational expensive operations. Con-

sequently, they are only suited for small user popu-

lations. Riposte (Corrigan-Gibbs et al., 2015) uses

ideas from both DC-nets and PIR, but introduces la-

tencies of several hours for one million users.

Mix Networks. Many mix networks have been pro-

posed to provide anonymity for connectionless appli-

cations. Recent proposals share a core concept (Van

Den Hooff et al., 2015; Tyagi et al., 2017; Lazar

et al., 2018; Gelernter et al., 2016; Kwon et al., 2020):

Users send and receive onion-encrypted packets to ex-

change messages via some form of mailboxes. Mail-

box identiﬁers are used to match messages of contacts

even though their location is hidden behind a path of

mixes. To defeat long-term disclosure attacks, peri-

odic and synchronized rounds are enforced. In each

round, every user is expected to participate. This im-

plies creating dummy messages if no real messages

have to be sent. Atom (Kwon et al., 2017) shares sim-

ilar ideas, but does not expect users to participate ev-

ery round, facilitating disclosure attacks.

Systems mentioned so far mainly differ in path

selection, mailbox management, and defense against

active attacks. Unfortunately, they all share draw-

backs that limit their practicability: First, onion en-

cryption uses asymmetric cryptography every round,

limiting scalability. Supporting more users either de-

grades latency or requires signiﬁcantly more mix re-

sources. Second, mailbox identiﬁers (or shared se-

crets in general) rely on out-of-band exchange, in-

troducing another attack vector. Moreover, mailbox

identiﬁers are valid for exactly one round in some de-

signs (Van Den Hooff et al., 2015; Tyagi et al., 2017;

Lazar et al., 2018). As a result, contacts may only

exchange messages when both participate in the same

round (no ofﬂine storage). This also degrades location

anonymity over time because rounds in which senders

deﬁnitively were online are leaked to receivers.

Rifﬂe (Kwon et al., 2016) allows users to anony-

mously upload messages to a set of servers efﬁciently:

After a setup phase, messages are onion-encrypted

with a symmetric cipher for multiple rounds. Unfor-

tunately, anonymous download by receivers is not as

efﬁcient because it relies on PIR or broadcast.

Loopix (Piotrowska et al., 2017) introduces Pois-

son mixing: Instead of mixing in explicit batches or

synchronized rounds, users select a random waiting

time at each mix, exponentially distributed. More-

over, users send real messages and dummy messages

following a Poisson process. Its arrival rate controls

the trade-off between latency and overhead on a per-

user basis. Unfortunately, sending less messages in

an asynchronous systems leads to smaller anonymity

sets on average, accelerating disclosure attacks, de-

spite attackers’ uncertainty due to mixing and cover

trafﬁc (Oya et al., 2014). Location anonymity relies

on honest “providers” that act as ofﬂine-storage.

cMix (Chaum et al., 2017) avoids asymmetric

cryptography at users for sending messages. Asym-

metric cryptography by mixes is pre-computed, not

degrading message latency. However, the protocol

only works for a ﬁxed mix cascade. Thus, cMix ei-

ther does not scale horizontally, or anonymity sets are

partitioned by using independent cascades in parallel.

Alpenhorn (Lazar and Zeldovich, 2016) uses

identity-based encryption (IBE) to exchange a secret

between contacts, and implements a dialing protocol:

The secret is used to initialize a hash chain provid-

ing session keys and dial tokens. Using a synchro-

nized mix network, the initiator sends the current dial

token to a public mailbox server. To protect loca-

tion anonymity of responders, dial tokens are stored

in a Bloom ﬁlter that is fetched by every user. Sub-

sequently, users check the existence of all possible

tokens they know. To keep Bloom ﬁlters efﬁcient,

mailboxes may be split to multiple ﬁlters based on

the hash of users’ pseudonyms. However, this par-

titions responder anonymity sets because queries are

not protected by mixes. Due to Bloom ﬁlter encoding,

Alpenhorn is not able to support arbitrary messages.

Circuit-based Systems. To reduce the number of

asymmetric cryptographic operations, many systems

use pre-built circuits, Tor (Dingledine et al., 2004)

being the most prominent example. During circuit

setup, users and relays negotiate keys for subsequent

onion encryption with symmetric ciphers. If respon-

der anonymity is desired, users may setup hidden ser-

vices. For this, service identiﬁers are publicly mapped

to introduction points to which responders connect

via circuits. While Tor defeats weak attackers with

low overhead, it deliberately does not provide strong

anonymity: Aiming at minimal circuit setup time and

end-to-end latency allows various timing correlation

attacks like watermarking (Wang et al., 2007).

Herd (Le Blond et al., 2015) and Aqua (Le Blond

et al., 2013) are designed for anonymous VoIP and ﬁle

sharing, respectively. They use onion routing similar

to Tor, but hide activity patterns of users and circuit

setup from observers by link padding. However, there

is no protection from malicious mixes trying to corre-

late circuit setup at different positions in the network.

Hydra: Practical Metadata Security for Contact Discovery, Messaging, and Dialing

193

Yodel (Lazar et al., 2019) provides VoIP calls with

strong anonymity. To defeat disclosure attacks, users

are synchronized to build two padded circuits every

round, even when they are not in an active call. Un-

fortunately, location anonymity regarding a malicious

contact a is weak: If there is a malicious mix v, a may

simply select v as his circuit endpoint, forcing his con-

tact to attach to v without protection. Similar, circuits

cannot be used to contact multiple users. Otherwise,

observers could correlate different contacts of a user,

which are likely to also know each other.

TARANET (Chen et al., 2018) provides relation-

ship anonymity at network layer. An application’s

data ﬂow is split across different circuits, each padded

to a static rate. While circuit setup packets are batched

at each hop, users do not setup any circuits if they

are inactive, accelerating disclosure attacks. Further-

more, TARANET deliberately does not provide loca-

tion anonymity (senders have to know the network lo-

cation of receivers beforehand).

Conclusion. Defeating disclosure attacks by global

observers is challenging. In theory, it requires users

to constantly send messages or dummies, preferably

in a synchronized way. Besides bandwidth overhead,

scalability of recent connectionless systems is mainly

limited by using asymmetric cryptography for layered

encryption of every message. The opposite approach,

padded circuits, is far more promising when padding

rates are adjusted to suit common connectionless ser-

vices. Unfortunately, existing implementations have

severe drawbacks as discussed above.

4 SYSTEM DESIGN

Hydra uses padded circuits to achieve strong

anonymity in a scalable way. In contrast to similar

proposals, circuits are combined with a novel ren-

dezvous mechanism to overcome the deﬁciencies dis-

cussed in Sec. 3. We now deﬁne our assumptions,

give an overview of Hydra, and present design de-

tails: Path selection, circuit design, user registration,

contact discovery, and messaging. Finally, we discuss

some considerations for users on mobile devices.

4.1 Assumptions and Overview

We assume time synchronization with an accuracy

of ≈ 10ms between all system entities, e.g. via NTP

and GPS. It is used to synchronize start and end times

of epochs and multiple rounds during one epoch. Loss

of synchronization results in increased packet loss as

described in Sec. 4.3, but does not affect anonymity.

Mixes

Rendezvous

nodes

Padded circuits

setup by users

Publish/subscribe

to hydra tokens

Infrastructure (directory

and contact service)

Figure 1: Overview of Hydra’s design.

We further assume that users participate in as many

epochs as possible to maximize anonymity set sizes

and mitigate disclosure attacks.

Fig. 1 gives an overview of Hydra, including com-

munication via circuits and the rendezvous mecha-

nism. The following entities are involved:

• A user set U. Each user u ∈ U has a pseudonym

nym

and a long-term key pair (k

−

). E.g., u

may reuse an existing PGP key pair.

• A set of mixes V . We assume all honest mixes to

be independently deployed. For key exchange with

forward secrecy, each v ∈ V generates ephemeral

key pairs (g

e,v

) for each epoch e and securely

deletes old ones. For brevity, we use the classical

Difﬁe-Hellman (DH) notation throughout the sec-

tion, but elliptic curve DH and post-quantum secure

key exchange protocols are also supported.

• Mixes further implement a distributed rendezvous

service. For clarity, we denote mixes as the set of

rendezvous nodes R when acting in this role.

• A contact service cs, which is only trusted to pro-

vide availability of contact discovery. If desired by

user u, cs stores the mapping (nym

• A directory service managing available mixes with

network addresses and public keys. As the service

is trusted to provide unbiased information for path

selection, we assume de-centralized deployment,

e.g. like Tor’s directory servers (Dingledine et al.,

2004). The registration process is out of scope, but

could be a voluntary-based system like Tor.

• Direct communication between any pair of system

entities is assumed to be reliable, e.g. using TCP.

The functionality of Hydra may be summarized as

follows: Each epoch consists of two phases, namely

setup and communication. During setup, users es-

tablish padded circuits that tunnel various types of

messages in synchronized rounds. For end-to-end de-

livery, a publish/subscribe protocol based on hydra

tokens is used to forward messages between circuit

endpoints via rendezvous nodes R. Tokens are gen-

erated by cryptographic secure hash functions with

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

194

64 bit output. If collisions occur, messages are copied

so that all users subscribed to the same token receive

them. Conﬁdentiality is still protected by end-to-end

encryption of all messages. For each token, the re-

sponsible r ∈ R is determined deterministically, e.g.

the directory service could sort R by key ﬁngerprints.

Then, the modulo operation on tokens may be used to

determine the list index. Two types of tokens exist:

• The contact token ct

of a user u is a hash of k

Using ct

, other users may initiate an authenticated

key exchange. Alternatively, users may agree on

a secret out-of-band. The shared secret is used

to synchronize a hash chain that generates session

keys with forward secrecy for every epoch.

• Using the session keys, contacts further derive ren-

dezvous tokens. Each rendezvous token rt

e,a,b

valid for one epoch e and one pair of users (a,b).

4.2 Path Selection and Dummy Circuits

For each epoch e a user wants to participate in, he in-

dependently selects a path p

∈ V

of mixes for his

circuit. We denote the l possible positions on a path

as layers and the endpoints of a path as entry and

exit mixes/layers. Users select one mix for each layer

{

1,...,l

}

uniformly at random, avoiding duplicates

(sampling without replacement). As an exception, the

entry mix is selected independently, allowing it to be

on the path in one additional layer. Otherwise, attack-

ers could rule out possible entry mixes by knowing

parts of the path, e.g. the exit mix. Further optimiza-

tions of path selection are left for future work, e.g.

restricting used links between layers, considering net-

work latency and heterogeneous mix capacities.

Using a ﬁxed path length l enables horizontal scal-

ability, but has two important consequences: First, if

the number of malicious mixes is ≥ l, there is a non-

zero probability of selecting malicious mixes only,

breaking location anonymity for one epoch. This

probability may be reduced by increasing l, at the

cost of increased latency and overhead. To ﬁnd suit-

able values for l, our analytical model developed in

Sec. 5.2 may be used. Second, if p

does not intersect

with any other circuits, global observers may iden-

tify p

. We counter this with dummy circuits created

by mixes. To be more precise, mixes ensure that adja-

cent layers are fully connected, i.e. there is at least

one circuit using each possible link in V

between

layer i and i+1. Mixes use the same path selection as

users, but with shorter paths depending on the layer i.

While this results in up to (l − 1) ×

dummy cir-

cuits at exit layer when no one uses Hydra, our eval-

uation in Sec. 5 shows that horizontal scalability for

Rendezvous

nodes

Mixing packets

Mixing cells

Setup packet

Circuit cell

Send/receive

based on tokens

Dropped cell

Dummy cell

Start of

epoch

Setup

phase

One

round

∆t

Figure 2: Synchronization during one epoch, l = 3.

large user populations is not affected. To defeat ﬂood-

ing attacks, e.g. attackers manage to block all but two

users and create a matching number of circuits them-

selves, v creates at least one dummy circuit at each

layer. Dummy circuits are also used by mixes to send

messages to themselves, covering observed trafﬁc at

rendezvous nodes and the contact service.

4.3 Circuit Design

After selecting a path p

= (v

,...,v

), users initi-

ate the creation of circuits during the setup phase of

epoch e. Circuits are subsequently used to transport

ﬁxed-sized cells. The objective of circuits is to unlink

users from messages sent during one epoch. Defeat-

ing long-term disclosure attacks requires further cau-

tion as discussed later. The main threat for anonymity

during one epoch are malicious mixes and attackers

that control communication links of paths. Especially,

attackers might try to link a user to his exit mix by ma-

nipulating packet timing (network ﬂow watermark-

ing) or packet content (tagging attacks) in a way that

is observable even after packets pass honest mixes.

To avoid leaking information based on timing of

circuit setup packets or circuit cells, forwarding be-

tween layers is synchronized by time (see Fig. 2). The

communication phase is further divided into multiple

rounds. Each round consists of one upstream and a

subsequent downstream phase, each transporting ex-

actly one cell per circuit. Before forwarding setup

packets or circuit cells, mixes check for duplicates

and apply a cryptographically secure transformation

and a random permutation. During communication

rounds, mixes additionally create dummy cells if they

did not receive a cell on a circuit in time (both up-

and downstream). The duration of one epoch is fur-

ther speciﬁed by three parameters:

Hydra: Practical Metadata Security for Contact Discovery, Messaging, and Dialing

195

tokens

AEnc

)

AEnc

)

AEnc

)

Figure 3: Example for authenticated onion encryption of a

circuit setup packet for path p

= (v

), i.e. l = 3.

• The interval ∆t

between synchronized forwarding

of cells on adjacent layers. It has to be large enough

to allow each mix to receive and process (onion

decryption, random permutation) all cells from the

previous layer in time. On the other side, ∆t

should

not be too high, because the (minimum) end-to-end

latency is ≈ 2(l + 1)∆t

. Consequently, ∆t

should

dynamically be set based on the expected number

of circuits. E.g., mixes may send statistics of past

epochs to the directory service, which in turn deter-

mines a suitable value for upcoming epochs.

• The interval ∆t

between communication rounds,

tuning a trade-off between bandwidth overhead and

latency. To compensate for potentially long setup

(asymmetric cryptography), this time is used to

process setup packets for the next epoch.

• The number k of rounds, tuning a trade-off between

efﬁciency and robustness to mix churn: Long

epochs are efﬁcient as they avoid asymmetric cryp-

tography for a long time. But if mixes fail, affected

circuits break till the start of the next epoch.

To allow a seamless transition between subsequent

epochs, the total idle time k × ∆t

has to be long

enough to run the next setup phase. Finding suitable

values for ∆t

, ∆t

and k is part of our quantitative

evaluation in Sec. 5.2. The following paragraphs fur-

ther detail setup and communication.

Setup Phase. During circuit setup, every user u ex-

changes session keys s

with each mix v

,1 ≤ i ≤ l

on his selected path and subscribes to a set of to-

kens. For this, u sends a single onion-encrypted setup

packet (see Fig. 3) to his entry mix v

. To create the

setup packet, u generates fresh key pairs (g

). In

combination with the ephemeral public key g

e,x

mix v

, session keys s

are derived from g

e,x

. Fur-

thermore, u generates nonces n

(96 bit each) and ap-

plies an authenticated encryption scheme in layers.

Naturally, the innermost layer is destined for the exit

mix v

, containing the tokens that u wants to subscribe

to. We suggest to use 256 tokens (adding dummy to-

kens if necessary) for now, allowing enough contacts

for normal usage. Users with more contacts may also

circId

rndNo

cmd

args

token

payload

Onion-encrypted

8 B 4 B 7 B 1 B 8 B 240 B

Figure 4: Packet format of circuit cells.

subscribe to tokens by using special cells during com-

munication phase as detailed later. However, tokens

of frequent contacts should be placed in setup packets

to allow receiving matching cells in all communica-

tion rounds. Token order is randomized to avoid to-

kens of the same contact to be linkable across epochs.

After encryption of one layer, n

and g

are added

in plaintext so that mixes may decrypt their layer and

check the authentication tag τ

(128 bit). Address in-

formation (up to 144 bit for IPv6 address and port)

of mix v

is prepended before applying the next layer

of encryption. After successful decryption, mix v

strips g

, n

, τ

, and the decrypted address informa-

tion v

i+1

before mixing and forwarding the packet.

Note that packet sizes decrease deterministically and

uniformly at each layer, not leaking information. Fi-

nally, the exit mix forwards the tokens to the respon-

sible rendezvous nodes. A random circuit identiﬁer

circId is added to the setup packet and re-randomized

at every hop. For later usage, mixes map ingress

circIds to egress circId, s

, previous hop and next hop.

Moreover, setup packets include the epoch number e.

Due to layered encryption, mixes only learn pre-

vious and next hop. Honest mixes drop setup packets

if authentication fails or duplicates are detected, de-

feating tagging and replay attacks. Dropped packets

are compensated by creating dummy circuits. Replay

protection may be based on τ

: If attackers manipulate

the tag to hide a replay, authentication fails. Similar,

replays from past epochs result in failed authentica-

tion because of fresh DH values of honest mixes. Par-

tially created circuits still participate in the communi-

cation phase up to the layer the setup was successful.

Static DH exchange allows users to prepare and

send setup packets in advance without having to wait

for a response. As a result, users may participate in an

epoch e even when they miss the start of e due to loss

of connectivity. This is beneﬁcial not only for usabil-

ity but also for anonymity: Attackers cannot exclude

users from anonymity sets based on the fact whether

they were online at epoch start.

Communication Phase. During communication

phase, circuits transport ﬁxed-sized cells, see Fig. 4.

Apart from the circId, which is re-written at every hop,

a cell contains the following data:

• The round number rndNo within an epoch, used for

detection of duplicates and missing cells. More-

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

196

over, it acts as the tweak for a tweakable block ci-

pher that is used for onion encryption as motivated

later. A tweak is an additional, non-secret input to

the block cipher.

• (cmd, args) may be used to send commands to

an arbitrary mix on the circuit, inspired by Tor’s

“leaky pipe” design. Whenever a mix ﬁnds the cmd

value to be a valid command code after onion de-

cryption, he performs the speciﬁed action with op-

tional arguments args. One command may be used

to signal the exit mix that the cell contains more

tokens to subscribe to at rendezvous nodes as de-

scribed above. We deﬁne two more commands in

the corresponding sections about contact discovery

and messaging. If a user has no command to send,

he randomizes both data ﬁelds, resulting in a sufﬁ-

cient small probability of the ﬁeld being misinter-

preted as one of the three valid commands.

• The token, used by exit mixes to forward the cell

to the responsible rendezvous node. To not leak

tokens to observers, they are encrypted for this step.

If a subscription is found, the cell is forwarded to

the corresponding exit mix, which in turn injects

the data into the downstream circuit. If multiple

cells are received for one circuit in the same round,

they are queued for subsequent rounds. At epoch

end, queued cells have to be dropped. Therefore,

applications should implement an error correction

protocol on top of Hydra.

• An end-to-end encrypted payload. Its size of 240 B

is a reasonable trade-off between usability and

bandwidth overhead caused by dummy cells. It

should be large enough for most compressed text

messages and larger messages may of course be

split to multiple cells.

Onion encryption of cells works as usual: In up-

stream direction, users encrypt the cell l times using

the exchanged session keys s

, starting with s

. Subse-

quently, each mix decrypts one layer. In downstream

direction, mixes add one layer of encryption each, all

decrypted by the user. We do not apply any authen-

tication to cells. This is crucial to allow any mix to

inject dummy cells that are not distinguishable from

real cells by randomizing all bytes: Whenever a mix

does not receive a cell for a round in time, he gener-

ates, mixes and sends a dummy cell instead. When

users do not have real data to send and are online,

they also generate dummy cells. Similar, exit mixes

generate dummy cells in downstream direction if they

do not receive any data from a rendezvous node for a

circuit. Dummy cells are discarded by users (down-

stream) and rendezvous nodes (upstream) because the

cell’s token is not known (with high probability).

As encryption scheme, we propose to use a tweak-

able block cipher with a block size of 256 B, i.e.

onion encryption works on a single block. Ciphers

with a smaller block size may be “extended” to larger

blocks (Patarin et al., 2012). Using a tweakable block

cipher on a single block has two advantages:

• Decryption of the complete block depends on the

tweak, i.e. the rndNo. Consequently, replaying old

cells with an increased rndNo to avoid replay de-

tection still leaks no information. That is because

the bit pattern of the complete cell changes in an

unpredictable way at the next honest hop. Similar,

replayed cells from past epochs are transformed in

an unpredictable way due to fresh session keys.

• Not using authentication potentially allows tagging

attacks on data ﬁelds that are predictable. For Hy-

dra, these ﬁelds are (cmd, args) and token if it is a

contact token or rendezvous tokens are used more

than once during an epoch. E.g., using AES in

counter mode results in the plaintext being xored

with a key stream. Consequently, attackers could

tag messages by using xor with few 1 bits and

checking for a low hamming distance to a valid

command/known token at other hops. Contrary,

the complete cell changes in an unpredictable way

at the next honest hop when using a single block.

This also destroys the token and consequently de-

feats tagging attacks in the presence of malicious

contacts because the cell is not delivered correctly.

4.4 User Registration

Note that users may participate in epochs any time.

Registration is only required if a user u wants to pub-

lish his pseudonym nym

and public key k

with

his location anonymity protected. Alternatively, users

may use out-of-band mechanisms for contact discov-

ery, e.g. by publishing on their own website or by

meeting in person. If registration is desired, u gen-

erates (or requests) a cryptographic binding bind

for k

to defeat impersonation. If this requires com-

munication, circuits may be used to protect user lo-

cations. We do not enforce a speciﬁc implementa-

tion, but assume that u’s contacts may verify bind

A ﬁngerprint of k

could be used and veriﬁed out-

of-band, e.g. by meeting in person. Existing (veri-

ﬁed) public keys may also be reused, e.g. from PGP.

To register, u uses the payload of (multiple) cells to

send (nym

,bind

) to the contact service, using

a reserved token. However, u should participate in a

random number of epochs before registration. Other-

wise, users who setup a circuit for the ﬁrst time are

linkable to new requests to the contact service.

Hydra: Practical Metadata Security for Contact Discovery, Messaging, and Dialing

197

4.5 Contact Discovery

The objective of contact discovery is an authenticated

key exchange. A pre-condition for contacting a user b

for the ﬁrst time is to know its pseudonym nym

public key k

. Furthermore, b has to subscribe to

his contact token ct

on a regular, but random ba-

sis. Subscribing to ct

every epoch is risky for lo-

cation anonymity: If attackers block all packets of b

(and only his), a malicious contact service may ob-

serve the missing subscription and link b’s IP address

to nym

. To resist longer blocking, a distribution with

a large average (hours) should be used to draw wait-

ing times between subscriptions. To further mitigate

the attack, mixes use cells of their dummy circuits to

randomly subscribe to publicly known contact tokens.

However, b should also use cells for his subscriptions

(instead of setup packets) to not be distinguishable.

He may further send contact requests to himself to

cover how many real requests he gets.

If only nym

is known, a user a may re-

quest (k

,bind

) from the contact service by using

his circuit. Then, a initializes a temporary hash chain

with a random seed s, starting at the current epoch e

Using the hash chain, temporary session keys and ren-

dezvous tokens may be derived for epochs e ≥ e

Using circuit cells, a initiates the contact discovery

by sending s addressed to contact token ct

and en-

crypted using k

. As b’s subscription is not per-

formed every epoch, the cells are likely dropped by

the responsible rendezvous node if no further action is

taken. Therefore, we use a special command in these

cells to signal that its purpose is contact discovery.

Then, the cell is forwarded to the contact service for

later delivery instead of being dropped. Missed cells

may be polled by b whenever he subscribes to his con-

tact token. We expect this delay in contact discovery

to be acceptable because it has to be performed only

once per contact. Starting with epoch e

+ 1, a sub-

scribes to the temporary rendezvous tokens to receive

the response from b. Similar, b subscribes to the tem-

porary tokens as soon as he sends the response, start-

ing at epoch e

> e

. Then, a and b may tunnel an

arbitrary key exchange protocol by using circuit cells

addressed to the temporary tokens, protected by us-

ing the temporary session keys. Note that a must not

initiate discovery for multiple contacts on the same

circuit: This would allow to link the contact tokens.

As soon as a and b share a secret, they use

it to synchronize a long-term hash chain to derive

future session keys and rendezvous tokens as de-

scribed in Sec. 4.1. Only then a may reveal his iden-

tity (nym

,bind

) to b. While this implies that b

cannot reject a request before key exchange is done,

it is inevitable to protect anonymity with forward se-

crecy: If k

−

was compromised, attackers could de-

crypt anything based on the temporary hash chain.

4.6 Messaging

To receive messages from contact a in epoch e, user b

subscribes to the shared rendezvous token rt

e,a,b

Then, a can send arbitrary messages using the payload

of one or multiple cells during the communication

phase of e. Note that using the same rendezvous token

for a complete epoch leaks the number of exchanged

cells to exit mixes, but they cannot link rt

e,a,b

to a

or b. The payload of each cell is secured end-to-end

by using authenticated encryption with a session key

derived from the hash chain. In contrast to onion en-

cryption, we do not impose restrictions on the used

scheme. In case of temporary disconnected users, en-

try mixes may act as ofﬂine storage. Alternatively,

a non-trusted storage service may be used, mapping

circuit ids to cells. Using reliable communication for

all direct communication channels, the message loss

probability is expected to be negligible in absence of

active attacks. Nevertheless, the messaging applica-

tion may still run an error correction protocol on top.

End-to-end latency is minimized when every cell

is delivered to b the same round i as a sends it.

However, this leaks that a was online in round i to

malicious contacts. Cooperating with a global ob-

server, b could then perform an intersection attack

to disclose a’s location over time due to inevitable

user churn. Pre-sending cells for future rounds does

not help either if a’s entry mix is malicious. Conse-

quently, if a does not trust b, he proceeds as follows:

For every cell he sends to b, he uses (cmd, args) of the

preceding cell to instruct a random mix v on the cir-

cuit to delay forwarding by args rounds. If v is neither

the entry nor the exit mix, the sending round is un-

linked from the receiving round. That is because even

if v is malicious, he does not know both circuit end-

points if l > 3. Note that a has to consider the “shift”

in the rndNo at v to derive the correct tweaks for onion

encryption. If v fails to delay the cell correctly, onion

decryption fails and the cell is turned into a dummy.

Our protocol is best suited for text-based messag-

ing. When aiming at a low bandwidth overhead dur-

ing communication, sending rates are low. Conse-

quently, sending application data that requires many

cells to be encapsulated is possible, but introduces

large end-to-end latencies. Still, Hydra can be used to

dial a contact and agree on a switch to an anonymous

protocol that supports higher bandwidth. E.g., an

anonymous VoIP service could be used to also trans-

port pictures. Unfortunately, user populations are ex-

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

198

pected to be smaller for these applications, possibly

degrading anonymity. Further note that users send-

ing/receiving many messages in a short time-frame

might experience increased end-to-end latency due to

queuing delay. That is because messages have to be

multiplexed over one circuit with low sending rates. If

users do not mind leaking the fact that they (plan to)

send/receive with high rates, they may create multiple

circuits per epoch to increase throughput.

4.7 Notes on Mobile Devices

While the timing shown in Fig. 2 achieves the lowest

end-to-end latency, it requires users to be active twice

per communication round (send and receive at differ-

ent times). To optimize battery life on mobile devices

at the cost of an increased latency of ≈ ∆t

, users may

instead fetch the downstream cell of round r while

sending the upstream cell of round r + 1.

While developing a prototype client application

for Android, we further noticed that new versions of

Android enter “doze mode” very quickly after turn-

ing off the screen. During doze, an application cannot

schedule an accurate wake timer (it may be delayed

up to some minutes). Even explicitly asking the user

for permissions cannot completely circumvent these

restrictions. A workaround is to use Google’s ﬁre-

base service to periodically send an “external wake

timer” to mobile users, using a high priority message.

These are guaranteed to not be delayed as long as the

application is frequently used (“working set bucket”).

Our ﬁrst prototype conﬁrms that ≈ 90% of “timers”

arrive within 1 s. Nevertheless, native support for ac-

curate timers during doze mode is desirable in future.

5 EVALUATION

We start with a qualitatively discussion if and to what

extend our objectives (Sec. 2) are met. Many aspects

were also discussed in Sec. 4 to guide our design, but

are summarized here. Subsequently, a quantitative

evaluation shows the practicability of Hydra using an

analytical model, validated by a prototype.

5.1 Qualitative Discussion

Hydra supports contact discovery, messaging, and di-

aling with key exchange and ofﬂine storage. The fol-

lowing paragraphs discuss non-functional properties.

QoS, Efﬁciency, and Scalability. Using circuits for

many rounds enables an efﬁcient deployment. Over-

lapping epochs allow compensation of potentially

long circuit setup times (asymmetric cryptography).

However, epochs should not be too long with regard

to robustness: A failing mix disrupts communication

for many circuits for up to two epochs because the

setup phase of the subsequent epoch may also be af-

fected. The minimum epoch length to compensate for

the setup phase is part of our quantitative evaluation.

The interval ∆t

between subsequent rounds tunes a

trade-off between end-to-end latency and overhead.

The overhead is limited to efﬁcient symmetric cryp-

tography and small dummy cells. We further evalu-

ate this trade-off in our quantitative evaluation as it

also affects setup time. Preparing setup packets be-

forehand and using padded circuits enable users to

skip some rounds or complete epochs without degrad-

ing anonymity. This is especially useful for usage

on mobile devices (power saving, temporary loss of

connectivity). Increased latency for receiving mes-

sages often is acceptable, e.g. when a user does not

want to be disturbed anyway. Horizontal scalability is

part of our quantitative evaluation: On the one hand,

adding more mixes decreases the number of user cir-

cuits one mix has to handle at each layer. On the other

hand, adding more mixes potentially increases the to-

tal number of circuits due to more dummy circuits.

Anonymity. We start by discussing possible attack

vectors by weak attackers and (cumulatively) move

on to more powerful attackers. The weakest attack-

ers we assume are global observers. They observe

when users join Hydra and in which epochs they par-

ticipate. However, they cannot track paths of circuits

due to onion encryption and synchronization for both

setup and communication phase. This is true even

when only few users participate (e.g. bootstrapping

Hydra) because mixes also create dummy circuits to

ensure that every possible link carries a circuit. If only

two users are online, observers cannot decide whether

they are communicating or not: They observe trafﬁc

to/from both users, and to/from rendezvous nodes and

the contact service in any case because mixes also

send subscriptions, contact requests and end-to-end

messages on dummy circuits. Furthermore, observers

cannot read any tokens due to encryption between exit

mixes and rendezvous nodes/contact service.

Active external attackers may further drop, delay,

replay, manipulate, or forge packets. Dropping setup

packets does not leak information as it is similar to a

scenario where only few users participate. Especially,

missing subscriptions to contact tokens are covered

by mixes randomly subscribing to user tokens. Drop-

ping or delaying circuit cells has no observable ef-

fect on circuit endpoints due to synchronization and

padding: Because authentication of cells is avoided,

Hydra: Practical Metadata Security for Contact Discovery, Messaging, and Dialing

199

dummies are not distinguishable from real cells. In-

cidentally dropping a cell, with content (cmd/contact

tokens) that is predictable for attackers, has no ob-

servable effect either, because attackers do not know

when those are sent. Replay protection is employed

for both phases. Tagging attacks are defeated by lay-

ered authentication for setup packets and by using a

tweakable block cipher with a large block size for

cells. Forging setup packets is detectable due to au-

thentication. Forging a cell for round i is possible

and potentially has the same effect as dropping the

cell with rndNo = i because mixes only forward one

cell per round. Nevertheless, the bit pattern of forged

cells changes at the next mix in an unpredictable way,

leaking no information. In summary, anonymity sets

include all active users. Disclosure attacks based on

user churn are still possible in theory and will always

be in any anonymity system. Nevertheless, by sup-

porting large users populations and minimizing ob-

servable churn by pre-sending setup packets, disclo-

sure attacks are mitigated as good as possible.

If at least one mix v on a path is honest, malicious

mixes positioned before and after v cannot infer that

they are part of the same circuit: Any manipulation

of packets before they reach v has no observable ef-

fects after passing v. If the honest mix v further is

not the entry mix, dummy circuits ensure that attack-

ers cannot further track possible path preﬁxes/sufﬁxes

as there is at least one circuit between v and all other

mixes in both adjacent layers. If only the entry mix

of a circuit is honest, attackers can narrow down the

location anonymity set to all users that use this en-

try mix. At worst, all mixes are malicious and lo-

cation anonymity is broken. Relationship anonymity

is preserved unless the circuits of both contacts are

completely malicious. Malicious exit mixes further

observe the number of exchanged real messages for a

rendezvous token, but cannot link them to users.

Malicious directory servers may try to manipu-

late path selection by not announcing honest mixes

or replacing address information and public keys.

This is defeated by a distributed consent of multiple

servers. Nevertheless, the number of malicious direc-

tory servers has to be limited to guarantee security. A

malicious contact service may observe the number of

contact requests to a given contact token. However,

this information is fuzzy because users also contact

themselves. Apart from the contact token, packets re-

layed by the contact service only contain an encrypted

random seed. The contact service cannot manipulate

the user database because of cryptographic bindings.

Malicious users may attack location anonymity by

intersection if they can infer in which round their con-

tacts were deﬁnitively sending cells. To defeat such

attacks, we allow users to delay forwarding of cells

within their circuit. There is a theoretical attack on

location anonymity of user a in epoch e by a mali-

cious user b, an external attacker (or entry mix) and

a malicious rendezvous node r responsible for rt

e,a,b

If the setup packet of a is dropped (and only his) r

observes the missing subscription to rt

e,a,b

. However,

attackers have to guess which setup packet to drop. If

they drop the wrong one, they can only exclude a sin-

gle user from the anonymity set. And even if attack-

ers guess correctly, a is still indistinguishable from all

users that do not participate in epoch e, e.g. because

they are temporarily ofﬂine. Further note that a simi-

lar attack on location anonymity exists in any system:

If one user is permanently blocked and the malicious

contact does not receive new messages afterwards, at-

tackers may assume that the guess was correct.

If attackers manage to forge cryptographic bind-

ings of public keys to users, they may impersonate

users at the contact service. Subsequently, they may

wait for contact requests to disclose communication

relationships. Consequently, secure handling of pub-

lic keys is crucial, but outside the scope of this article.

5.2 Quantitative Evaluation

We aim to answer the following research questions:

• Given ﬁxed capacities (number of mixes, their pro-

cessing power and bandwidth), how many users

may be supported with good end-to-end latency?

• How does Hydra’s performance compare to other

approaches that provide strong anonymity? To the

best of our knowledge, Karaoke (Lazar et al., 2018)

is one of the most efﬁcient candidates to date and

is therefore used for our comparison.

• Can Hydra support more users by adding more

mixes, despite increased overhead due to dummy

circuits (horizontal scalability)?

• How many rounds must circuits be used to allow

the next setup phase to complete in time?

We answer the questions using an analytical model.

Furthermore, performance results are validated using

a prototype of Hydra deployed on a small testbed.

Model. Let n = |U| be the number of users

and m = |V | the number of mixes. We assume each

mix to have identical performance characteristics, i.e.

using the minimum. The available bandwidth is de-

noted by β (full duplex). To model bandwidth over-

head caused by a reliable transport protocol, the ef-

fective bandwidth is η

× β, with η

< 1. Each mix

may process setup packets on a single core with a rate

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

200

Table 1: Default parameters.

Parameter Default Comments

m 100

t 18 AWS c4.8xlarge

f 0.2

l 14 Pr(

C) ≤ 1.7×10

–10

l×102B+2064B ECDH, Curve448

268B

δ 100 ms

ω 10 ms

β 10 Gbit s

−1

, η

0.25

∆t

30 s

of µ

, and circuit cells with a ratio of µ

, both given

in pkt/s. To model the total processing power, µ

and µ

are further multiplied by the number t of cores

and a factor η

< 1 that models additional overhead,

like key lookups and thread synchronization. We fur-

ther denote the maximum propagation delay between

any pair of mixes by δ and the maximum clock off-

set (time synchronization) by ω. The size of setup

packets (at clients) is denoted by σ

, cell size by σ

For our model, a constant fraction f < 1 of mixes is

malicious, i.e. a total of ˜m = b f × mc. If l ≤ ˜m, the

probability Pr(

C) of a circuit to consist of malicious

mixes only (the entry mix may be duplicated) is:

Pr(

C) =

˜m

˜m − 1

m − 1

× ··· ×

˜m − l + 2

m − l + 2

≤



˜m



(1)

If not stated otherwise, we use the parameters shown

in Table 1. For fair comparison with Karaoke, the

values are inspired by their setup using 100 Ama-

zon AWS c4.8xlarge instances as mixes (Lazar

et al., 2018). Note that they use very long

paths, l = 14, which should be reconsidered in prac-

tical deployments. Our default cryptographic algo-

rithms are ECDH on Curve448 for key exchange and

AES-256-GCM for authenticated encryption during

setup. Onion encryption of cells uses the Three-

ﬁsh cipher with 128 B block size and 12 rounds of a

Feistel network to double the block size as described

in (Patarin et al., 2012). To ﬁnd reasonable values

for µ

and µ

, we benchmarked single core perfor-

mance for one minute, using openssl speed (asym-

metric cryptography) and our prototype code (Three-

ﬁsh). To approximate single core performance of an

AWS c4.8xlarge instance, we benchmarked an In-

tel Core i7-7500U. Mixes in our testbed use an AMD

GX-412TC at 1 GHz. The results are shown in Ta-

ble 2 and already indicate the signiﬁcant advantage of

Threeﬁsh for onion encryption of cells.

Dummy Circuits. As the processing time at each

layer highly depends on the total number of circuits,

we ﬁrst approximate the expected number E(F) of

Table 2: Cryptography benchmark, single core.

Algorithm i7-7500U GX-412TC

Curve448 1745 pkts

−1

128 pkts

−1

Curve25519 29705 pkt s

−1

1550 pkts

−1

Threeﬁsh 336604 pkt s

−1

39245 pkt s

−1

dummy circuits. For this, we approximate our path

selection strategy by allowing duplicates at any layer.

Then, there are m

possible links between each pair of

adjacent layers, i.e. up to m

new dummy circuits at

each layer. Furthermore, every mix creates at least

one dummy circuit per layer. Given the expected

number n

of “regular” circuits (users and dummy cir-

cuits created in previous layers) arriving at layer i, the

expected number of new dummy circuits E(F

) is:

E(F

) = m + m

× (1 −

)

(2)

Summing all E(F

),1 ≤ i ≤ l − 1 yields the total ex-

pected number of dummy circuits E(F).

End-To-End Latency. The duration of both setup

phase and one round of communication depends on

the number c

i,v

of circuits a mix v has to handle at

layer i. A reasonable (with high probability) up-

per bound for all c

i,v

may be determined as fol-

lows: First, the exit layer l has the highest load due

to E(F) additional dummy circuits. Second, c

l,v

may

be modelled by a Binomial distribution because all

mixes have the same probability of being used as exit

mix: c

l,v

∼ B(n + E(F),

/m) = B

l,v

. Consequently,

reasonable upper bounds for all c

i,v

,1 ≤ i ≤ l, v ∈ V

are given by the quantiles ˜c

of B

l,v

. We use q = 0.99

for the remaining evaluation.

To process the cells of all circuits in time without

packet loss, the lower bound for ∆t

(interval between

synchronized forwarding on adjacent layers during

communication phase) is as follows:

∆t

≥ ω + δ + max



˜c

× σ

× β

˜c

×t × µ



(3)

It is dictated by the (assumed) accuracy of time syn-

chronization (receiver clock may be ahead of sender

clock by ω), the maximum propagation delay δ be-

tween any pair of mixes and the forwarding bot-

tleneck (either communication bandwidth or crypto-

graphic performance). The lower bound for the dura-

tion of one communication round and thus the end-to-

end latency of a message is given by d

= 2(l + 1)∆t

Additionally, the end-to-end latency is increased

+∆t

)

/2 on average because users ﬁrst have to

wait for the start of the next round. The resulting av-

erage end-to-end latency is depicted in Fig. 5. For

comparison, we included the empirical results from

Hydra: Practical Metadata Security for Contact Discovery, Messaging, and Dialing

201

100

150

0 M 10 M 20 M 30 M 40 M 50 M

Number of users

(in millions)

End-to-end latency [s]

(average)

Karaoke, c4.8xlarge

Model, Curve25519 for cells

Hydra, Δt_w = 30s

Hydra, Δt_w = 10s

Figure 5: Average end-to-end latency for Karaoke, Hydra,

and an instantiation of our model with Curve25519 for cells.

100 M 200 M 300 M

Number of users

(in millions)

End-to-end latency [s]

(average)

1 mix per million users

2 mixes per million users

3 mixes per million users

Figure 6: Average end-to-end latency of Hydra for vary-

ing m and n, with ﬁxed ratios

/n.

Karaoke (Lazar et al., 2018), scenario with 100 AWS

c4.x8large instances (up to 16 million users). Note

that we multiplied their results by 1.5 to compensate

for the average waiting time till the next round starts

(while ∆t

= 0 in Karaoke, rounds cannot overlap).

Furthermore, we also instantiated our model by using

Curve25519 for onion encryption of cells instead of

Threeﬁsh. This basically models a generic anonymity

system that works similar to Karaoke and uses asym-

metric cryptography for every message. Note that

this instantiation (with η

= η

= 0.25, ∆t

= 0) pre-

dicts the performance of Karaoke quite accurately and

thus can be used as an extrapolation for more users.

Further note that optimized implementations of both

Karaoke and Hydra potentially yield higher values

for η

and η

, i.e. lower end-to-end latency.

As expected, our results show that using a sym-

metric cipher for cells drastically improves the scala-

bility. Nevertheless, the end-to-end latency may be

comparatively high for very small user populations

due to the inevitable waiting time between rounds.

Scalability. Fig. 6 shows the average end-to-end

latency of Hydra for varying number of users and

mixes, with ﬁxed ratios

/n of mixes per users. The

results show that Hydra is able to scale horizontally:

More users can be supported without degrading la-

tency by proportionally adding more mixes. Note that

for ﬁxed n, deploying more mixes has limited advan-

tages: Many mixes per user may increase the over-

head due to additional dummy circuits and waiting

times between rounds still impose a lower bound on

average end-to-end latency (15 s for ∆t

= 30 s).

1000

2000

3000

4000

0 M 10 M 20 M 30 M 40 M 50 M

Number of users

(in millions)

Minimum

epoch duration [s]

Curve448, Δt_w = 10s

Curve448, Δt_w = 30s

Curve25519, Δt_w = 10s

Curve25519, Δt_w = 30s

Figure 7: Minimum epoch duration in Hydra.

Epoch Duration. As shown above, ∆t

should not

be too high. However, smaller values for ∆t

decrease

energy efﬁciency for mobile devices. Furthermore,

an epoch needs more communication rounds k to al-

low the setup to ﬁnish in time when ∆t

is small, po-

tentially degrading robustness. Consequently, a good

trade-off has to be found. Similar to our calculations

above, the total setup time d

is:

= (l − 1)



ω + δ + max



˜c

× σ

× β

˜c

×t × µ



(4)

To allow the setup to ﬁnish in time, d

further has to be

less or equal to the total idle time during one epoch:

≤ k × ∆t

(5)

Then, the epoch duration d

, which is the twice the

communication duration, is bounded as follows:

≥ 2k(d

+ ∆t

) ≥ 2



∆t



+ ∆t

) (6)

The lower bound increases quadratically with the

number of users, because both d

and d

increase.

This can also be seen in Fig. 7. Consequently, using a

“weaker” curve (Curve25519 still has a security level

of ≈ 128 bit) may be a reasonable trade-off to avoid

very long epochs when user population grows.

Testbed. We implemented a prototype of the

core Hydra mix functionality (synchronized for-

warding and rendezvous) in Rust, using gRPC as

user API and plain TCP for relaying cells be-

tween mixes. We deployed m = 9 mixes us-

ing PC Engines APU3c4 SoCs (system on a

chip, β = 1Gbits

−1

, t = 4 cores at 1 GHz). As all

mixes are directly attached to one switch, ω + δ

should be negligible. Remaining parameters for the

testbed are l = 4, ∆t

= 0.5 s, ∆t

= 25 s and k = 20.

Circuit setup uses Curve25519. We further imple-

mented a load generator that mimics many users, us-

ing their circuits to send one message to themselves

every round and measuring packet loss. Our experi-

ments, each running 3 consecutive epochs, show that

the small deployment can support up to 260 thou-

sand users with packet loss below 1 %. The bottle-

neck is the comparatively weak CPU. Compared to

our model, the results indicate a value of η

≈ 0.37.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

202

Summary. Compared to previous messaging sys-

tems with strong anonymity, our model shows that

Hydra is able to support signiﬁcantly more users with

acceptable latency by not using asymmetric cryptog-

raphy for every message. Even more users are sup-

ported by deploying more mixes. Our ﬁndings are

supported by benchmarks and a prototype of Hydra.

6 CONCLUSION

Using padded circuits for multiple rounds allows Hy-

dra to support millions of users with strong anonymity

and relatively low latency. Further, our rendezvous

mechanism avoids shortcomings of previous circuit-

based systems with strong anonymity: A circuit may

be used to communicate with multiple contacts and

location anonymity is signiﬁcantly improved.

In future, we want to combine Hydra with an

anonymity system that is able to support applications

with higher bandwidth and stricter latency require-

ments, like VoIP. For this, a similar protocol may be

used, but with tuned parameters and path selection.

Moreover, we evaluate post-quantum secure key ex-

change protocols for circuit setup. Our prototypes are

published at https://github.com/hydra-acn.

REFERENCES

Chaum, D. (1981). Untraceable electronic mail, return ad-

dresses, and digital pseudonyms. Communications of

the ACM, 24(2):84–90.

Chaum, D. (1988). The dining cryptographers prob-

lem: Unconditional sender and recipient untraceabil-

ity. Journal of Cryptology, 1(1):65–75.

Chaum, D., Das, D., Javani, F., Kate, A., Krasnova, A.,

De Ruiter, J., and Sherman, A. T. (2017). cMix: Mix-

ing with minimal real-time asymmetric cryptographic

operations. In International Conference on Applied

Cryptography and Network Security, pages 557–578.

Chen, C., Asoni, D. E., Perrig, A., Barrera, D., Danezis, G.,

and Troncoso, C. (2018). TARANET: Trafﬁc-analysis

resistant anonymity at the network layer. In IEEE Eu-

roS&P, pages 137–152.

Corrigan-Gibbs, H., Boneh, D., and Mazi

eres, D. (2015).

Riposte: An anonymous messaging system handling

millions of users. In IEEE Symposium on Security and

Privacy, pages 321–338.

Dingledine, R., Mathewson, N., and Syverson, P. (2004).

Tor: The second-generation onion router. In 13th

USENIX Security.

Gelernter, N., Herzberg, A., and Leibowitz, H. (2016). Two

cents for strong anonymity: The anonymous post-

ofﬁce protocol. PETS, 2016(2):1–20.

Kwon, A., Corrigan-Gibbs, H., Devadas, S., and Ford, B.

(2017). Atom: Horizontally scaling strong anonymity.

In 26th ACM SOSP, pages 406–422.

Kwon, A., Lazar, D., Devadas, S., and Ford, B. (2016). Rif-

ﬂe: An efﬁcient communication system with strong

anonymity. PETS, 2016(2):115–134.

Kwon, A., Lu, D., and Devadas, S. (2020). XRD: Scalable

messaging system with cryptographic privacy. In 17th

USENIX NSDI, pages 759–776.

Lazar, D., Gilad, Y., and Zeldovich, N. (2018). Karaoke:

Distributed private messaging immune to passive traf-

ﬁc analysis. In 13th USENIX OSDI, pages 711–725.

Lazar, D., Gilad, Y., and Zeldovich, N. (2019). Yodel:

Strong metadata security for voice calls. In 27th ACM

SOSP, pages 211–224.

Lazar, D. and Zeldovich, N. (2016). Alpenhorn: Bootstrap-

ping secure communication without leaking metadata.

In 12th USENIX OSDI, pages 571–586.

Le Blond, S., Choffnes, D., Caldwell, W., Druschel, P., and

Merritt, N. (2015). Herd: A scalable, trafﬁc analysis

resistant anonymity network for VoIP systems. ACM

SIGCOMM, 45(4):639–652.

Le Blond, S., Choffnes, D., Zhou, W., Druschel, P., Bal-

lani, H., and Francis, P. (2013). Towards efﬁcient

trafﬁc-analysis resistant anonymity networks. ACM

SIGCOMM, 43(4):303–314.

Mayer, J., Mutchler, P., and Mitchell, J. C. (2016). Eval-

uating the privacy properties of telephone metadata.

Proceedings of the National Academy of Sciences,

113(20):5536–5541.

Oya, S., Troncoso, C., and P

erez-Gonz

alez, F. (2014). Do

dummies pay off? Limits of dummy trafﬁc protection

in anonymous communications. In International Sym-

posium on Privacy Enhancing Technologies, pages

204–223. Springer.

Patarin, J., Gittins, B., and Treger, J. (2012). Increasing

block sizes using feistel networks: The example of the

aes. In Cryptography and Security: From Theory to

Applications, pages 67–82. Springer.

Pham, D. V., Wright, J., and Kesdogan, D. (2011). A prac-

tical complexity-theoretic analysis of mix systems. In

European Symposium on Research in Computer Secu-

rity, pages 508–527. Springer.

Piotrowska, A. M., Hayes, J., Elahi, T., Meiser, S., and

Danezis, G. (2017). The loopix anonymity system.

In 26th USENIX Security, pages 1199–1216.

Tyagi, N., Gilad, Y., Leung, D., Zaharia, M., and Zeldovich,

N. (2017). Stadium: A distributed metadata-private

messaging system. In 26th ACM SOSP, pages 423–

440.

Van Den Hooff, J., Lazar, D., Zaharia, M., and Zeldovich,

N. (2015). Vuvuzela: Scalable private messaging re-

sistant to trafﬁc analysis. In 25th ACM SOSP, pages

137–152.

Wang, X., Chen, S., and Jajodia, S. (2007). Network ﬂow

watermarking attack on low-latency anonymous com-

munication systems. In IEEE Symposium on Security

and Privacy, pages 116–130.

Hydra: Practical Metadata Security for Contact Discovery, Messaging, and Dialing

203
