Seam Carving for Image Classiﬁcation Privacy

James Pope

and Mark Terwilliger

Department of Computer Science and Information Systems,

University of North Alabama, Florence, Alabama, U.S.A.

Keywords:

Privacy Protection, Adversarial Perturbations, Image Classiﬁcation, Seam Carving.

Abstract:

The advent of storing images on cloud platforms has introduced serious privacy concerns. The images are rou-

tinely scanned by machine learning algorithms to determine the contents. Usually the scanning is for marketing

purposes but more malevolent purposes include criminal activity and government surveillance. The images

are automatically analysed by machine learning algorithms. Notably, deep convolutional neural networks per-

form very well at identifying image classes. Obviously, the images could be encrypted before storing to cloud

platforms and then decrypted after downloading. This would certainly obfuscate the images. However, many

users prefer to be able to peruse the images on the cloud platform. This creates a difﬁcult problem in which

users prefer images stored in a way so that a human can understand them but machine learning algorithms

cannot. This paper proposes a novel technique, termed seam doppelganger, for formatting images using seam

carving to identify seams for replacement. The approach degrades typical image classiﬁcation performance

in order to provide privacy while leaving the image human-understandable. Furthermore, the technique can

be largely reversed providing a reasonable facsimile of the original image. Using the ImageNet database for

birds, we show how the approach degrades a state-of-the-art residual network (ResNet50) for various amounts

of seam replacements.

1 INTRODUCTION

With the advent of image recognition machine learn-

ing approaches, numerous privacy issues have been

raised. More recently, deep learning techniques,

such as deep layered convolutional neural networks

(CNNs), have made signiﬁcant advances in image

(Traore et al., 2018) and speech recognition (Ku-

mar et al., 2018) compared to traditional machine

learning approaches, exacerbating the privacy con-

cerns. Recent research has been to provide privacy-

preserving image techniques to counter these clas-

siﬁers (Moosavi-Dezfooli et al., 2016). For exam-

ple, researchers (Sanchez-Matilla et al., 2020) have

suggested exploiting vulnerabilities in deep neural

networks to protect image privacy. Conversely, re-

searchers have investigated image compression tech-

niques to counter these adversarial images (Liu et al.,

2019) (Das et al., 2017).

In general, machine learning approaches attempt to

learn correlations to predict the target class. Redun-

dant information is ideal when noise is considered and

generally improves the performance of many classi-

https://orcid.org/0000-0003-2656-363X

ﬁers. Given that general machine learning approaches

exploit redundant information to improve accuracy,

an obvious counter would be to minimise redundant

information in images as much as possible while still

retaining enough for humans to recognise the image.

Of course, human recognition is very subjective.

Seam carving was proposed by Avidan and Shamir

(Avidan and Shamir, 2007) for content-aware im-

age resizing for both reduction (i.e. compression)

and expansion. Seam carving can be used to com-

press images by ﬁnding the least informative pixels

(determined to be redundant) in a corresponding en-

ergy image and discarding them along contiguous ver-

tical and horizontal paths. We propose modifying

seam carving to replace these less informative pixels

using a deterministic function of nearby pixels that

will remove the redundancy while keeping the image

human-perceptible.

To our knowledge, our work is the ﬁrst to leverage

seam carving for privacy preserving images. The con-

tributions of this paper are the following.

• Novel approach for privacy preserving images by

modifying the seam carving image compression

technique

268

Pope, J. and Terwilliger, M.

Seam Carving for Image Classiﬁcation Privacy.

DOI: 10.5220/0010249702680274

In Proceedings of the 10th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2021), pages 268-274

ISBN: 978-989-758-486-2

• Comparison with deep CNNs showing the efﬁ-

cacy of our approach

We also submit that this work can be reproduced pro-

viding sufﬁcient information to produce similar re-

sults as the images are available from ImageNet and

the code is made freely available (Pope, 2020).

(a) Original (b) Energy

Figure 1: Seam Doppelganger Example: Jacamar.

This paper ﬁrst details the seam doppelganger ap-

proach including seam replacement and seam restora-

tion. The approach is then evaluated using speciﬁc

images from a common image repository and a mod-

ern image classiﬁer. An experiment on several hun-

dred images is then conducted, comparing the seam

doppelganger approach to random distortions. The

paper closes with future work and the conclusion.

2 SEAM DOPPELGANGER

APPROACH

The seam doppelganger approach includes two steps,

seam replacement and seam restoration. The seam

carving technique is ﬁrst brieﬂy explained followed

by seam replacement and then restoration.

2.1 Seam Carving and Energy Function

The seam carving approach (Avidan and Shamir,

2007) uses an energy function to transform the red,

green, and blue (RGB) components of the original

image into an energy image. Energy functions can

measure the energy at a pixel in various ways and

typically include surrounding pixels as inputs. For

our research, we use a common differential energy

function that takes the difference of the left and right

pixel colours and adds to the difference of the top and

bottom pixel colours. The difference between two

colours is determined by Equation 1 and the energy at

the pixel location’s i’th row and j’th column is given

by Equation 2.

di f f (c1, c2) = (c1.red − c2.red)

+ (1)

(c1.green − c2.green)

(c1.blue − c2.blue)

= image(i − 1, j)

= image(i + 1, j)

= image(i, j − 1)

= image(i, j + 1)

e(i, j) = di f f ((c

, c

) + di f f (c

, c

) (2)

This is similar to an edge detector kernel and records

higher energy at boundaries between colour regions.

In areas with the same or similar colour, a lower en-

ergy value is computed. Note that the values com-

puted in Equation 1 and 2 are not normalised. By

normalised, we mean to keep in the range of [0, 255].

We submit that this unnormalised energy function is

sufﬁcient for computing shortest paths. Normalised

values are simply re-scaled and the same paths will

be found.

A horizontal seam is determined from the energy im-

age by ﬁnding a constrained shortest path from the left

to the right of the image. The horizontal seam length

is constrained to be the width of the image. The seam

carving authors refer to the seam as an 8-connected

path that can be found in a variety of ways, includ-

ing Dijkstra’s shortest path algorithm or dynamic pro-

gramming (Avidan and Shamir, 2007). Our imple-

mentation uses a variation of the shortest path algo-

rithm. Similarly, the vertical seam is the shortest path

in the energy image from top to bottom with a length

of the image height.

Figure 1a shows an original image and Figure 1b

show the corresponding energy image produced us-

ing the normalised energy function (slightly enhanced

to make brighter for presentation). Note that in Fig-

ure 1c, seam carving would either remove these seams

(for compression) or expand them. Instead we replace

the seams.

2.2 Seam Replacement

For each horizontal and vertical seam found, seam

carving for compression would omit it reducing the

Seam Carving for Image Classiﬁcation Privacy

269

size of the image. The seam is considered the most

redundant and therefore best to remove without loss

of information. For our purposes, we choose to re-

place the seam leaving the image the exact same size

but with the seam’s pixels replaced.

Each seam found and replaced produces a new im-

age. Should we want to replace more than one seam,

we have to run the entire procedure again including

producing a new energy image.

Algorithm 1: Seam Replacement (Horizontal).

1: Input: image X and n number of seams to replace

2: Output: image Y copy of X with n seams replaced

3: procedure HORIZONTALREPLACEMENT(X, n)

4: Y = copy(X)

5: while seams replaced < n do

6: seam = ﬁndHorizontalSeam(Y)

7: replaceHorizontalSeam(Y, seam)

8: return Y

10: procedure FINDHORIZONTALSEAM(Y )

11: E = energyImage(Y )

12: for each row i in E.height do

13: path = ﬁndShortestPath(E,i)

14: if length(path) < smallest path so far then

15: smallestSeam = path

16: return smallestSeam

17:

18: procedure REPLACEHORIZON-

TALSEAM(Y, seam)

19: for each col j in Y.width do

20: i = seam(j)

21: // Note we ignore value at i, j and set as

22: // a function of east, west pixel values

23: maskValue = mask(i, j, Y)

24: Y.set(i,j, maskValue)

25:

26: procedure MASK(i, j,Y )

27: north = Y.get(i,j-1)

28: south = Y.get(i,j+1)

29: rn = north.red

30: gn = north.green

31: bn = north.blue

32: rs = south.red

33: gs = south.green

34: bs = south.blue

35: r = ( bn + gs + j ) & 0xC5

36: g = ( rn + bs + j ) & 0xC5

37: b = ( gn + rs + j ) & 0xC5

38: return Colour(r, g, b)

Algorithm 1 shows the procedures for replacing hori-

zontal seams (vertical seams are replaced in a similar

fashion). The HorizontalReplacement (Line 3) and

ﬁndHorizontalSeam (Line 10) procedures are simi-

lar to the original seam carving approach. We differ at

Line 7 where we replace instead of elide or expand the

seam. The replaceHorizontalSeam (Line 18) proce-

dure enumerates each pixel location in the seam and

replaces with a mask colour value derived from the

surrounding pixels. The mask procedure (Line 26)

details how this colour is determined.

There are two desirable properties regarding seam re-

placement. First, we would like for subsequent seams

to not ﬁnd the replaced seam (i.e. the seam should

have relatively high energy values). The second prop-

erty is that we would like to be able to ﬁnd the seam

later so that we can attempt to restore the values.

The mask procedure ﬁrst extracts the red, green, and

blue colour components from the pixels to the north

and south of the pixel to be replaced. At Lines 35,

36, and 37, each colour component is mixed with a

combination of the north and south, however, using

different colour components. For instance at Line 35,

red is mixed with blue from the north pixel and green

from the south pixel. The intent of this mixing is to

reduce the possibility of the transformed colour be-

ing similar (i.e. to make it stand out from the east

and west colour). If the derived colour is very similar

then it is redundant and will likely be found again as

part of the next seam to replace. Furthermore, the col-

umn location j is also mixed with each colour compo-

nent. If there is a series of similar colour values to the

north and south, adding the column location causes

the mask colour to change gradually giving a gradi-

ent effect. We believe that this will better confuse an

image classiﬁer as the replaced seams will be corre-

lated creating their own patterns. Finally the sum is

a bit-wise and with 0xC5. This takes the lower eight

bits in a hash-like way to ensure the resulting value is

in the range of [0, 255]. The 0xC5 is for convenience

and other approaches may work equally well.

We submit that the replaceHorizontalSeam proce-

dure with the mask colours achieves the two desirable

properties. The colours are sufﬁciently different from

neighbouring pixels to avoid re-selection of the seam

pixels for replacement. Second, the mask colour val-

ues are computed using a deterministic function of the

neighbouring pixels (NB: as long as the neighbouring

pixel values do not change later).

2.3 Seam Restoration

Based on the seam replacement, the original picture

cannot be 100% restored perfectly. The seam values

are completely replaced as a function of the neigh-

bouring pixel values. However, the seam pixels by

deﬁnition are highly redundant. Thus, we can sim-

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

270

(a) Region 20x20 of

original image with

horizontal and vertical

seams replaced

(b) Region 20x20

seam restoration

with artefacts from

horizontal seam

Figure 2: Seam Restoration Example.

ply take the pixel value to be the average of the north

and south pixels for horizontal seams (and west and

east for vertical seams). To detect a replaced pixel we

check to see if its colour is equal to the value com-

puted by the mask procedure. We check to see if it

could have been a pixel in a vertical seam and then if

it could have been a pixel in a horizontal seam. We

check every pixel in this way. To be clear, we do not

explicitly ﬁnd the seam again. If the pixel could have

been replaced, we assume it was and take the aver-

age of the neighbouring pixel values overwriting its

current colour value.

A notable exception to replaced pixels is when we

ﬁrst replace horizontal seams followed by replacing

vertical seams. Horizontal seams have to intersect

with vertical seams. The vertical replacement will

overwrite the neighbouring pixels used to mask the

horizontal seam and it will not be able to detect that

it was replaced. Though the vertical seam’s masked

value will be found, the horizontal seam’s pixel will

not be detected, leaving artefacts. Figure 2a shows

the results of a 20x20 pixel region (near the back of

the bird) of the image in Figure 1c where a horizon-

tal and then vertical seam were replaced. Figure 2b

shows the corresponding results of the seam restora-

tion. A masked horizontal pixel near the centre was

not detected and remains as an objectionable artefact

(darker blue). Future work is to address this issue.

Note that the vertical seam was replaced and the dark

green pixel near the centre was restored as the average

of the left and right colours (this shows as a lighter

blue pixel next to the darker blue artefact).

Figure 2 clearly shows that the horizontal and vertical

seams can largely be restored with minimal distortion

of the original image. This is because, by design, the

pixels replaced were redundant and not very informa-

tive. Restoring then from neighbouring pixels results

in a near facsimile of the original image.

Table 1: ImageNet Query.

Class # Instances Search

bird 608

Animal, animate being,

beast, brute, ...

Chordate

Vertebrate, craniate

Bird

3 EVALUATION

This section evaluates the seam doppelganger ap-

proach by applying it to selected images from a com-

mon image repository and examining how it affects an

image classiﬁer. The evaluation shows that many re-

placed images are still human perceptible but degrade

the classiﬁer’s performance. We also show a counter

example where the approach fails.

3.1 Experimental Data

The images are retrieved from ImageNet (Rus-

sakovsky et al., 2014). To make the analysis more co-

herent, we narrowed to just the birds synsets. The im-

ages for each were queried from the ImageNet repos-

itory where the image URLs were saved to a ﬁle.

The images were then retrieved restricting to just the

URLs starting with http://farm. The ImageNet query

(IMA, ease) and resulting number of instances are

shown in Table 1.

The images were resized to be 244 x 244 (similar

to VGG (Simonyan and Zisserman, 2014)) with the

three red, green, and blue channels. The values were

normalised to be between 0.0 and 1.0.

We would like to show that our seam doppelganger

approach works comparable to randomly modifying

the image. To ensure comparisons are valid, the same

number of pixels are modiﬁed for both the random

and seam doppelganger approaches. The following

equation is used to calculate the number of pixels

modiﬁed for the seam approach.

p = r × image.width + c × image.height −(r × c)

where p is the number of pixels modiﬁed, r is the

number of rows seamed, and c is the number of

columns seamed.

Note that we are careful to subtract the row-column

intersections as they are modiﬁed twice.

3.2 Albatross

Figure 3 shows the four variations of the image. Sub-

ﬁgure 3a shows the original image from ImageNet

Seam Carving for Image Classiﬁcation Privacy

271

(a) Original (b) Random

Figure 3: Examples Images: Albatross 30% Replacement.

Table 2: Example Prediction Comparison Albatross.

Scenario Class Probability

albatross 0.974

Original pelican 0.006

stork 0.006

ptarmigan 0.383

Random albatross 0.313

drake 0.160

ptarmigan 0.848

Replaced bustard 0.065

albatross 0.044

(ALBATROSS 027) that is 224 pixels wide by 224

pixels tall. Sub-ﬁgure 3c shows where 34 row seams

and × 34 column seams have been replaced. This

replaces a total of 14076 pixels, roughly 30% of the

image (34 is roughly 15% of the width and height).

Sub-ﬁgure 3b shows the same number of pixels mod-

iﬁed by randomly selecting pixels and then changing

them to a random colour. To avoid modifying the

same pixel twice, we assign a unique integer to each

pixel location, shufﬂe these indices, and then select

the ﬁrst p to modify. Finally, sub-ﬁgure 3d shows the

results of the restoration process run on sub-ﬁgure 3c.

There are clear artefacts where the seams cross and

also where two parallel seams were close and over-

wrote each other (e.g. back of the bird’s neck). How-

ever, the image well represents the original.

We use ResNet50 to predict the original, random, and

replaced images. We take the top-3 predicted classes

and show their probabilities in Table 2.

(a) Original (b) Random

Figure 4: Examples Images: Dowitcher 30% Replacement.

Table 3: Example Prediction Comparison Dowitcher.

Scenario Class Probability

dowitcher 0.827

Original red-backed sandpiper 0.154

ruddy turnstone 0.014

chainlink fence 0.233

Random ant 0.222

window screen 0.123

padlock 0.320

Replaced window screen 0.181

jigsaw puzzle 0.161

3.3 Dowitcher

Figure 4 shows several dowicher birds on the beach

with a 30% random and seam replacement. Table 3

shows the top-3 results of running ResNet50 against

the original, random, and replaced images.

3.4 Goose

Figure 5 shows a single goose with 30% of the pixels

replaced randomly and by seam replacement. Table 4

shows the top-3 results of running ResNet50 against

the original, random, and replaced images.

Table 4: Example Prediction Comparison Goose.

Scenario Class Probability

goose 0.496

Original ﬂamingo 0.394

albatross 0.045

ostrich 0.736

Random eel 0.200

starﬁsh 0.013

ostrich 0.968

Replaced ﬂamingo 0.022

crane 0.003

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

272

(a) Original (b) Random

Figure 5: Examples Images: Goose 30% Replacement.

(a) Original (b) Random

Figure 6: Examples Images: Peacock 30% Replacement.

In the original image, the classiﬁer is already con-

fused between goose and ﬂamingo. Interestingly in

this case, the certainty of the classiﬁer is increased for

both the random and replaced images, however, with

a class that is not in the top three of the original image.

3.5 Peacock

Figure 6 shows a peacock with 30% of the pixels re-

placed randomly and by seam replacement. Table 5

shows the top-3 results of running ResNet50 against

the original, random, and replaced images.

This counter example shows that the seam replace-

ment approach does not always work. The peacock

image does not have easily identiﬁed redundancy and

the seam replaced image is not noticeably different

than the original. The classiﬁer performance is hardly

degraded at 0.997 certain that the image is a peacock.

Table 5: Example Prediction Comparison Peacock.

Scenario Class Probability

peacock 0.999

Original fountain 0.000

doormat 0.000

chainlink fence 0.593

Random chain 0.208

chain mail 0.121

peacock 0.997

Replaced chainlink fence 0.000

shovel 0.000

4 EXPERIMENT AND RESULTS

To demonstrate the effectiveness of the approach, the

predictions of Resnet50 are compared to random and

seam replaced images with varying amounts of re-

placement (a.k.a. distortion). We use the average pre-

diction probability for measurement comparison.

4.1 Average Prediction Probability

Based on the 608 bird images from ImageNet, we

seam replace each image with 10%, 20%, 30%, 40%,

and 50% of the pixels replaced. For comparison, we

also change exactly this same number of pixels ran-

domly. Resnet50 is run on the original images (0%

distortion), the seam replaced images, and the ran-

domly distorted images. As shown previously, some

image probabilities will be worse and some may be

better. We take the average of the image predictions

for each distortion percentage. Ideally, increasing the

distortion will cause the average probability to de-

crease for both the seam replaced and randomly dis-

torted images. As a comparison, the random results

are treated as an ideal distortion of the images for our

privacy preserving scenario. We expect the random

distortions to reduce more than the seam replacement.

However, it is desirable that the seam replacement re-

sults be close to the random results.

Figure 7 shows the results of the experiment. The

results for both the seam replaced and randomly dis-

torted images does indeed decrease as the distortion

increases. Importantly, the seam replaced results re-

main close to the random results for each amount of

distortion. These results provide evidence that the

seam carving approach can be used to degrade the

prediction probability of deep neural network image

classiﬁers.

At 30% distortion, the probability prediction of

Resnet50 on the random images continues to reduce

closer to zero. In actuality, each of the 1000 image

Seam Carving for Image Classiﬁcation Privacy

273

0.00 0.10

0.20 0.30 0.40

0.50

0.00

0.20

0.40

0.60

Distortion

Prediction

Seam Replaced

Random

Figure 7: Resnet50 predictions on 608 distorted bird im-

ages.

classes is becoming equally likely (i.e. maximum en-

tropy). The seam carving approach is levelling out at

about 3-4% for the 50% distorted images.

4.2 Experimental Issues and Future

Work

We are careful to note several issues with our ex-

perimental setup and exposition. We use ResNet50

as an example of a deep CNN. However, this was

trained with 1000 classes that include many other

non-bird classes. Speciﬁcally, ResNet50 includes

chainlink fence, windows screen, and jigsaw puzzle.

The seam carving moves the bird images closer in ap-

pearance to these classes. If the deep CNN was re-

stricted to only bird images, it may not be so easily

fooled. Future work is to train a more modest CNN

on a restricted set of classes and evaluating other Im-

ageNet categories. Future work also includes using

different energy functions such as histogram of gradi-

ents and entropy (Avidan and Shamir, 2007).

5 CONCLUSIONS

In this paper, we presented the seam doppelganger ap-

proach for privacy preserving images. The paper de-

tailed how redundant pixels can be identiﬁed using

the seam carving technique and then replaced. This

produced distorted, though still human recognisable,

images. We also demonstrated how the image can be

restored to a close facsimile of the original, though

with some objectionable artefacts. We then showed

how the distorted images degraded the accuracy per-

formance of a leading edge image classiﬁer.

ACKNOWLEDGEMENTS

This work was supported in part by the University

of Montevallo Contract #19-0501-001. The authors

greatly appreciate the support of the staff involved in

the project. Without their efforts this research could

not have been conducted.

REFERENCES

(Fall 2011 Release). ImageNet: Explore WordNet Structure.

Avidan, S. and Shamir, A. (2007). Seam carving for

content-aware image resizing. ACM Trans. Graph.,

26(3):10–es.

Das, N., Shanbhogue, M., Chen, S.-T., Hohman, F., Chen,

L., Kounavis, M. E., and Chau, D. H. (2017). Keeping

the bad guys out: Protecting and Vaccinating Deep

Learning with JPEG Compression.

Kumar, A., Verma, S., and Mangla, H. (2018). A sur-

vey of deep learning techniques in speech recogni-

tion. In 2018 International Conference on Advances

in Computing, Communication Control and Network-

ing (ICACCCN), pages 179–185.

Liu, Z., Liu, Q., Liu, T., Xu, N., Lin, X., Wang, Y., and

Wen, W. (2019). Feature distillation: DNN-oriented

JPEG compression against adversarial examples. In

2019 IEEE/CVF Conference on Computer Vision and

Pattern Recognition (CVPR), pages 860–868.

Moosavi-Dezfooli, S., Fawzi, A., and Frossard, P. (2016).

DeepFool: A Simple and Accurate Method to Fool

Deep Neural Networks. In 2016 IEEE Conference

on Computer Vision and Pattern Recognition (CVPR),

pages 2574–2582.

Pope, J. (2020 (accessed September 16, 2020)). Seam

Doppelganger on Open Science Foundation.

https://osf.io/gmn97/.

Russakovsky, O., Deng, J., Su, H., Krause, J., Satheesh, S.,

Ma, S., Huang, Z., Karpathy, A., Khosla, A., Bern-

stein, M., Berg, A. C., and Fei-Fei, L. (2014). Ima-

genet large scale visual recognition challenge.

Sanchez-Matilla, R., Li, C. Y., Shahin Shamsabad, A., Maz-

zon, R., and Cavallaro, A. (2020). Exploiting vulnera-

bilities of deep neural networks for privacy protection.

IEEE Transactions on Multimedia, pages 1–1.

Simonyan, K. and Zisserman, A. (2014). Very deep convo-

lutional networks for large-scale image recognition.

Traore, B. B., Kamsu-Foguem, B., and Tangara, F. (2018).

Deep convolution neural network for image recogni-

tion. Ecological Informatics, 48:257 – 268.

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

274
