Strategising RoboCup in Real Time with Uppaal Stratego

Philip I. Holler, Magnus K. Jensen, Hannah Marie K. Lockey and Michele Albano

Department of Computer Science, Aalborg University, Selma Lagerløfs Vej 300, 9220 Aalborg, Denmark

Keywords:

Multi-Agent Systems, Multi-Agent Software Platforms, Time Constraints, Agent Models and Architectures.

Abstract:

The RoboCup simulator is a playing ground for Agents and Artiﬁcial Intelligence research. One of the main

challenges provided by RoboCup is generating winning strategies for a set of agents playing soccer, given a

partial and noisy view of the game state. Additionally, RoboCup is timing sensitive, and all decisions have

to be sent to the server within each tick of 100ms. This paper presents a method for generating strategies

by modelling players and scenarios as timed automata in the Uppaal environment. The newest extension of

Uppaal, called Uppaal Stratego, allows for synthesising strategies optimising a reward function that is used

to guide the decision process. In order to stay within the time frame of 100ms, two approaches were tested,

namely forecasting the game state and generating a strategy asynchronously for a later point in time, and

generating strategies beforehand and saving them in a lookup table. Four timed automata were developed, and

were tested against publicly available methods. We found that strategies could be successfully generated and

used within the time constraints of RoboCup using our proposed method. Especially when combined together,

our strategies are able to outperform most published methods, but lose against the published world champions.

1 INTRODUCTION

Robotics involves many complex decision problems

with tight time constraints that are often difﬁcult to

solve using traditional rule based programming, es-

pecially when the scenario involves multiple robots.

This category of problems extends to higher levels of

abstraction, such as strategising to solve problems in

a dynamic environment.

The RoboCup federation aims to push the limits of

Artiﬁcial Intelligence in robotics by providing plat-

forms for soccer competitions between autonomous

robots (Robocup Federation, 2020a). In this paper

we focus on the strategisation part of the problem,

as represented in the RoboCup 2D multi-agent soc-

cer simulation (Robocup Federation, 2020b). This

simulation includes a dynamic environment with a

large amount of possible conﬁgurations that makes

linear search for optimal solutions infeasible. The

RoboCup player agents, called players for short, are

autonomous agents reacting to stimuli from the envi-

ronment. In order to make the players perform well

in the game, it is necessary to quickly create effective

strategies for the players.

Uppaal is a modelling and veriﬁcation tool that al-

lows for modelling the behaviour of timed systems in

https://orcid.org/0000-0002-3777-9981

terms of states and transitions between states. Addi-

tionally, Uppaal is able to analyse and verify prop-

erties of the models using efﬁcient algorithms (Up-

paal, 2019). The latest extension of Uppaal, called

Uppaal Stratego, enables strategy generations using

different machine learning algorithms such as Q-

learning (David et al., 2015). Uppaal Stratego has

already been applied to solve problems of real time

systems such as ﬂoor heating control (Larsen et al.,

2016) and trafﬁc light control (Eriksen et al., 2017).

In both cases, strategies are generated in real time, but

not with the tight time constraints and the large prob-

lem spaces that characterise RoboCup.

The aim of this paper is to introduce methods

for applying Uppaal Stratego to solve problems that

require swift reactions to a dynamic environment.

We created a RoboCup team named RoboPaal to

showcase our approach, and whose code is available

on (RoboPaal team, 2020).

The rest of the paper is structured as follows.

Section 2 provides background information regard-

ing RoboCup and Uppaal. Section 3 introduces our

general approach to strategising RoboCup, and Sec-

tion 4 provides insights regarding the design and im-

plementation of RoboPaal. Section 5 present and dis-

cusses the results of our experimentation, and Sec-

tion 6 wraps up the paper.

Holler, P., Jensen, M., Lockey, H. and Albano, M.

Strategising RoboCup in Real Time with Uppaal Stratego.

DOI: 10.5220/0010239602730280

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 1, pages 273-280

ISBN: 978-989-758-484-8

273

2 BACKGROUND INFORMATION

Deﬁnition 1. An objective is deﬁned as a goal for a

single player. An example of this could be: move to

position x,y on the ﬁeld. An objective can require sev-

eral player actions, i.e. dash, kick and turn, to com-

plete, or none if the objective is already fulﬁlled.

Deﬁnition 2. A strategy is a set of objectives as-

signed to one or more players.

Deﬁnition 3. In this paper, a model is a timed au-

tomata modelled within Uppaal (David et al., 2015).

2.1 RoboCup

RoboCup is a set of annual competitions where teams

of autonomous robots compete in the game of soc-

cer. RoboCup features tournaments for both physi-

cal robots as well as simulated robots in 2D and 3D

environments (Robocup Federation, 2020a). This pa-

per focuses on the 2D simulator. Agents in the sim-

ulator must tackle problems such as interpretation of

noisy data, strategisation and coordination with other

robots, and ﬁnally time sensitivity as the server en-

forces a 100ms tick rate. The simulator is publicly

available through GitHub (Rodrigues et al., 2020).

The Soccer Server is the main component of the sim-

ulator, and is responsible for storing and updating the

game state. All communication between the agents

must be done through the server.

Three different types of agents can connect to the

server. The Trainer and the Online Coach have both

access to a perfect view of the game state. The Trainer

can move objects and change the game state, it can-

not be used in ofﬁcial matches, and it is meant to

test strategies in controlled environments. The Online

Coach can communicate via short messages broadcast

to the players (through the server), and can issue sub-

stitutions of the players during a match.

The Players can communicate with each other

(through the server), they periodically receive sen-

sory data, and they send back actions to be performed.

Sensory data come of three different types. Visual

data consists of distances and relative directions to

ﬂags, other players and the ball, and it is distorted

depending on how far away the objects are located.

Body sensor data include current values of stamina

and head angle; auditory data include messages from

the referee, other players and the coach. Player ac-

tions are executed to inﬂuence the game state, and in-

clude dash, kick, turn, turn neck and say. The kick

and dash actions are accompanied by a power parame-

ter between 0 and 100 indicating how hard to kick and

how fast to dash. The player state has a stamina level

that dictates the effectiveness of the dash and kick ac-

tions, which by default starts starts at the upper limit

of 8000 stamina, and dash actions consume stamina

equal to the power of the action. Stamina regenerates

at a rate of at most 30 units per tick throughout the

game (The RoboCup Simulator Committee, 2020).

2.2 Uppaal Toolsuite

Uppaal is a modelling and veriﬁcation toolsuite. The

latest edition of Uppaal comprises Uppaal Stratego,

which is a tool for generating strategies (Uppaal,

2019). A strategy in Uppaal Stratego consists of a

number of transitions in a timed automata depending

on the values of variables and clocks, the latter repre-

senting the passing of time.

A common issue for model checking of timed

automata is the state space explosion, which hap-

pens when the state space gets too big to analyse.

Within Uppaal Stratego, the strategies are generated

according to a query formulated in a query language

containing variables or clocks that should be opti-

mised (David et al., 2015). Strategies are generated

using different machine learning methods, among

which co-variance, Splitting, Regression, Naive, M-

Learning and Q-learning (the default method). In this

paper, Uppaal Stratego will only be used in its de-

fault setting using Q-learning. Models in Uppaal are

saved as XML ﬁles, which allows for easy direct ma-

nipulation of the model. The Uppaal veriﬁer, called

verifyta, is a binary ﬁle used to run strategy gener-

ation queries on the models.

Timed automata have been used to strategise real

time systems in the past. The work in (Larsen et al.,

2016) used Uppaal for online synthesis of short-

period strategies on the ﬂy. In fact, the computations

needed to learn an effective strategy in Uppaal grows

exponentially with the number of states, which grows

steepily with the time horizon for the strategy. A heat-

ing control strategy is created for the near future, and

then recalculated periodically. The trafﬁc controller

described in (Eriksen et al., 2017) uses Uppaal to re-

duce waiting times at trafﬁc lights by continuously

creating new strategies for intelligent trafﬁc lights.

3 STRATEGISING RoboCup

Our approach, whose reference architecture is shown

in ﬁgure 1, employs Uppaal to create strategies for the

Players and for the Online Coach.

A player can represent its view of the world as a

Uppaal model, which is then used to generate a strat-

egy. The player then translates the strategy into ob-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

274

Figure 1: Reference architecture.

jectives and acts upon them by sending actions to the

soccer server. This approach allows creating individ-

ual strategies for each player, based on its view of the

world. The approach for the Online Coach is similar,

but it requires the additional step of communicating

the strategy to the players with a Say action.

Modelling the whole game state within Uppaal is

unfeasible since a game of RoboCup can have up to

11 players for each team and each player is charac-

terized by more than 40 variables, leading to massive

state explosion. For this reason, one primary problem

we studied was the choice of a proper part of the game

state to model. We considered speciﬁc scenarios (free

kicks), characteristics of a player (its stamina level),

and choices (passing the ball or trying to keep it).

We created two distinct families of methods for

generating strategies for RoboCup with Uppaal. A

ﬁrst family called Online Strategy considers to gen-

erate a strategy on the ﬂy when it is needed. The ap-

proach must adhere to tight time constraints (100ms).

The models for generating online strategies are al-

tered using the data received from the server, and the

output strategies focus on objectives of immediate ap-

plicability, such as ﬁnding the optimal target for pass-

ing the ball. If strategy generation takes too long, the

strategy might be ready too late to be useful. We

reduce this risk by forecasting the game state, even

though we could generate a strategy for a game state

that never materialises.

A second family called Ofﬂine Strategy consid-

ers to generate strategies before a game is run. Rel-

evant ofﬂine strategies are stored in a lookup table.

Ofﬂine strategies cannot feasibly be generated for all

scenarios of the game, due to the large amount of pos-

sible states. Instead, this kind of strategy can be devel-

oped for scenarios that are predictable and repeated

often. At run time the agent can then search through

the ofﬂine strategies, and apply them if they match the

current game state.

4 DESIGN & IMPLEMENTATION

This section describes how the architecture and all of

its modules were realized in the Python programming

language.

4.1 Players

The biggest development effort was devoted to

the Players. Each of them is run on an independent

thread and can communicate with the server only (see

Section 2.1). Each player consists of two sub-threads:

the Communication thread for communicating mes-

sages with the soccer server, and the Thinker thread

that is responsible for parsing the received messages

and generating actions given a game state. The two

threads communicate through a thread-safe queue.

As mentioned in Section 2.1, players receive in-

accurate sensory data from the server, or even not re-

ceive some data at all, which can lead to generating

strategies based on wrong information. An example

of the noisy data is the distance to the ball and to ev-

ery other object, which is judged incorrectly by up to

10 percent (Akiyama, 2010). To mitigate this prob-

lem, the players estimate their own positions and di-

rections by using trilateration on all visible ﬂags on

the ﬁeld, and then leverage this information to esti-

mate the position of the rest of the objects.

We also mitigate the noise problem by keeping a

history of the perceived game state, to spot and cor-

rect inconsistencies in the data received by the server.

Finally, we associate a time stamp with every sensory

data received from the server, to both estimate the lo-

cation of non perceived objects, and to forecast the

future position of ball and players for online models

such as the possession model (see Section 4.3.2).

Every time a message from the server is parsed

by a Thinker thread, the player assesses if the current

game state matches the requirements for one or more

strategies. If the game state matches the requirements

for an ofﬂine strategy, the strategy is retrieved from

the lookup table and objectives are immediately ap-

plied for the player. If the game state matches an on-

line strategy conﬁguration, then the agent constructs

an Uppaal model to generate the strategy (see Sec-

tion 4.3). Since generating an online strategy may

take longer than 100ms, it is done asynchronously us-

ing a separate thread. Upon completion, the Uppaal

module returns a series of objectives to the player.

Players can also receive objectives for a strategy

generated by the online coach, as say messages (see

Section 4.2). In case no suitable strategy is found,

objectives are determined by default hard coded be-

haviours.

Strategising RoboCup in Real Time with Uppaal Stratego

275

4.2 Online Coach and Trainer

Similarly to the player, the Online Coach and the

Trainer are run as two sub-threads (Communication

thread and Thinker thread). Their data on game state

are complete and not distorted, which eliminates the

need for the techniques from Section 4.1. If the data

received in one tick trigger the generation of a strat-

egy, a Uppaal model is generated, run, and the Objec-

tives it produces are communicated to the players (see

for example Section 4.3.1).

4.3 Implemented Strategies

To showcase our approach, we implemented one of-

ﬂine strategy generation module (the Goalie Defence

Model) and three online strategy generation modules

(the Pass-chain Model, the Stamina Model and the

Possession Model).

In the Uppaal models, the possible objectives that

the player can pursue are represented as controllable

transitions. For example a transition might represent

passing the ball to a speciﬁc player. The Uppaal veri-

ﬁer verifyta is executed on the model to synthesise

a strategy, which provides an estimated utility that can

be gained by taking each possible transition in the

model. Uncontrollable factors, such as the movement

of opponents, are represented as dotted lines (see ﬁg-

ures 2 – 4). These transitions can inﬂuence the state

of the model and the estimated reward of the control-

lable actions, but will not appear in the output strategy

ﬁle since they do not correspond to actions that can be

taken.

4.3.1 Pass-chain Model

Similarly to the real world, it is impossible for a

player to kick the ball hard enough for it to cross the

entire ﬁeld and score a goal. Instead, the players must

either dribble or pass the ball to each other multiple

times, while avoiding interception by the opposing

team, until they are close enough to the goal. The pro-

posed pass-chain model is used by the online coach,

which observes the game state and builds a model.

The model generates a list of players, and the coach

communicates to each player the next player to pass

to via a Say message. The last player in the list is

instructed to dribble the ball forward.

The model consists of a series of team players, in-

stantiated from the template in ﬁgure 2, and the one-

state model in ﬁgure 3 for measuring rewards. Oppo-

nents are represented as a list of coordinates. A player

may either be in possession of the ball or free. From

the possession state, the player may either choose to

dribble or pass the ball to a teammate. In the latter

Figure 2: Player template of the pass-chain model.

Figure 3: Ball/reward template of the pass-chain model.

case, there is a probability that the ball is lost to the

opponent, which is estimated based on the positions

of the pass target and of the opponents. The reward is

modelled by means of a clock variable having a rate

determined by how far the ball is currently positioned

from the opponents’ goal, and by which team is in

possession of the ball. The query for generating the

strategy tries to optimize the reward value over a pe-

riod of 10 simulated seconds.

4.3.2 Possession Model

When a player is in possession of the ball, it must de-

cide whether to pass the ball to a teammate or to drib-

ble forward using a series of low power kicks. The

possession model estimates the effectiveness of these

choices. The model is highly dependant on a large

number of uncontrollable and unpredictable variables

such as the current positions of the opponents. Thus,

it is infeasible to precompute ofﬂine strategies for all

possible scenarios, which makes online strategy gen-

eration the only option for this model. On the other

hand, generating the strategy as it is needed can in-

volve computation time spanning one or more server

ticks, which is sometimes enough for the opponents

to take control of the ball. Thus, in several sce-

narios (e.g.: when chasing the ball, when attempt-

ing an interception, when the ball is moving towards

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

276

Figure 4: Possessor template from the possession model.

the player) players estimate periodically the time that

they will come into contact with the ball, to gener-

ate a strategy a few ticks before the estimated contact

time. The model is built using an extrapolation on the

position of all visible moving objects.

The possessor template of the model is repre-

sented in ﬁgure 4. The generated strategy ﬁle contains

rewards for performing passes to each of the visible

teammates, and for performing a forward dribble. The

rewards are based on the estimated probability that the

action will succeed, as well as how much the ball will

advance towards the opponent’s goal.

4.3.3 Goalie Defence Model

The goalie is the last defence when the opposing team

is close to scoring a goal. A good strategy for this

situation aims to maximise the chance of a save by

positioning the goalie in the best spot.

When an opposing striker approaches the goal, we

assume that, if the striker shoots, it will be within the

cone to the goal. Figure 5 represents the cone between

B1 and B2, and G1 and G2 are the shortest (perpendic-

ular) segments from the goalie to the edge of the cone.

The objective of the goalie is to keep the longest seg-

ment between G1 and G2 as short as possible, since if

one of these were long, the goalie would take longer

to intercept the ball if kicked along that trajectory.

Two timed automata for the goalie and the striker

respectively are run in parallel. All transitions in the

striker model are uncontrollable, since the striker is

not under RoboPaal’s control. The model for the

striker is represented in ﬁgure 6. At each step both

goalie and striker can choose to accelerate or decel-

erate in some direction. After this, the striker non-

Figure 5: Goalie defender idea illustrated.

Figure 6: Striker part of the goalie model.

deterministically decides to either kick the ball or

move further, and the goalie can respond by either

moving or standing still. When the striker eventually

kicks, the goal chance is calculated as a function of

the goalie and the striker positions. The query used

to synthesise the strategy aims to generate a strategy

minimizing the goal chance.

Since the goalie needs fast reaction times and the

state space is relatively small, this strategy was made

as an ofﬂine strategy. The penalty area was divided

into a grid of 1x1 meter squares, and a strategy was

generated for each combination of goalie and striker

positions within the grid. All the combinations were

then saved in a dictionary, with the key being the po-

sitions of striker and goalie and the value being move-

ment instructions for the goalie.

4.3.4 Stamina Model

If players dash as fast as they can throughout a game,

they will run out of stamina quickly. As mentioned

in Section 2.1, the player’s stamina is a value be-

tween 0 and 8000 and it get lowered when dashing,

and the effect of all player’s actions is reduced when

the stamina drops below 1000. We introduce a model

for online stamina strategy generation. The strategy is

generated every 11 seconds, or 110 ticks. The model

uses stamina intervals 0 to 9 to reduce the number of

possible states, and it searches for the maximal dash

power that keeps the stamina level above 2000.

Strategising RoboCup in Real Time with Uppaal Stratego

277

5 EXPERIMENTAL RESULTS

This section presents the experimental results we col-

lected regarding the performance of RoboPaal. Every

time the soccer server is quit, log ﬁles are generated.

The log ﬁles can be used for analysing how teams per-

formed in the game.

We performed two sets of experiments. The ﬁrst

set focused on speciﬁc scenarios, with each experi-

ment repeated a number of times with different ran-

dom seeds to reach statistical signiﬁcance. In the sec-

ond set of experiments, we let RoboPaal play against

teams retrieved from public repositories.

We deﬁned a number of metrics in order to mea-

sure the beneﬁts provided by the strategies. The pos-

session metric measures for how long the ball is kept,

and it is used for the performance of the pass-chain

model (section 4.3.1). The ﬁeld progress metric mea-

sures the meters progressed toward the center of the

goal of the opposing team without losing possession

of the ball, and it is used to judge the performance

of the pass-chain model. For the stamina model,

we measured the metrics minimum stamina (the

stamina of the team player with the minimum stamina

level) and the average stamina (average stamina of

all players in a team). The goalie intervention met-

ric measures if the goalie is within 1.2 meters of the

ball, i.e close enough to catch the ball, at any point

during the attack, and it is used for to judge the goalie

defender strategy.

5.1 Goalie Defender Strategy

For the goalie defender model (see section 4.3.3), we

generated random striker attacks with the striker at a

random position on the y-axis and at the edge of the

penalty area on the x-axis. The ball is spawned right

in front of the striker. The goalie is given 75 ticks to

position according to the strategy, since in a real game

the goalie would position itself gradually as the striker

approaches the penalty area. Later on, both the goalie

and the striker are allowed to proceed normally. The

strategy is compared with: an idle strategy where

the goalie positions itself in the middle between the

two posts of the goal; a following strategy where the

goalie follows the ball’s y-coordinate.

Table 1 reports the results. We tested the Null Hy-

pothesis 1, considering a signiﬁcance level of 0.05.

The binomial distribution is run with n = 100, ex-

pected probability 0.48, and actual number of suc-

cesses 58. We got a p-value of 0.029, which allowed

us to reject hypothesis 1 and to conclude that the de-

fender strategy performs statistically better than the

idle strategy.

Table 1: Successful goalie interventions out of 100 attacks.

Successful

interventions

Idle in front of goal 48

Goalie Defender Strategy 58

Manual Y-axis adjustment 60

Null Hypothesis 1. The goalie defender strategy does

not perform better, than the idle strategy.

We then tested Null Hypothesis 2 using a binomial

distribution with a signiﬁcance level of 0.05. The test

was run with n = 100, expected probability 0.60, and

the actual number of successes set to 58. The results

of the test did not allow us to reject hypothesis 2.

Null Hypothesis 2. The manual y-axis adjustment

and goalie defender strategy perform identically given

the same random attacks.

5.2 Stamina Strategy

The performance of the stamina model (see sec-

tion 4.3.4) was tested by means of a beep test, and

of full games.

The beep test is a real world ﬁtness test for ath-

letes, where the players have to run continuously back

and forth between the two posts with less and less

time to reach the next target (Wood, 2008). We mea-

sure the performance of our strategy against a base-

line where a player simply dashes at full power all the

time. Figure 7 shows that the average stamina at each

tick is kept higher by our strategy, and ﬁgure 8 shows

that the running performance of the stamina strategy

overpowers the baseline since tick 2000. The ﬂuc-

tuations around tick 3000 are caused by the server

replenishing the stamina of the players at half time.

The decrease in stamina just before half time and end

game is due to the player being allowed to use the rest

of his stamina when the game is about to end.

We also tested the stamina strategy in 40 full

games between two teams of identical implementa-

tions, except for one team using the stamina strategy.

Figure 7: Stamina comparison of stamina strategy against

dashing at full speed.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

278

Figure 8: Lap comparison of stamina strategy against dash-

ing at full speed.

The results can be seen in Table 2. We proposed the

Null Hypothesis 3, and test it with a signiﬁcance level

of 0.05 against a binomial distribution, with n = 40,

expected probability of 0.5 wins and actual number

of successes 28. This yields a p-value of 0.008853,

which is enough to conﬁrm that the stamina strategy

increases the chance of winning.

Null Hypothesis 3. The stamina strategy does not in-

crease the chance of winning.

Figure 9 reports on the average stamina of the

most tired player at every tick over the 40 games

(the average stamina metric yields similar results),

and it shows that players can preserve stamina while

still winning more games. Another indicator that the

stamina strategy can indeed make a difference is the

fact that the team using it scores most of the goals

in the latter half of each half time, which is when

some players without the stamina strategy are out of

stamina (see ﬁgure 9). An extreme example of this

effect was noticed in one of the 40 games, where the

stamina strategy team won 1-11 and only 1 of the 11

goals scored by the winning team fell within the ﬁrst

third of the half times.

Table 2: Game results of 40 games with one team using the

stamina strategy.

Team Goals Scored Wins

Stamina Strategy 247 28

Default Dashing 160 11

Figure 9: Average stamina of lowest stamina player in the

40 games.

5.3 Possession Strategy

Table 3 shows the cumulative results of 50 full games,

where the team with the possession model performed

signiﬁcantly worse than the default implementation.

The poor performance could be a result of consider-

ing backwards passes in the strategy, which in certain

situations appears to be a good idea, but often results

in losing the ball closer to a player’s own goal.

Table 3: Results of 50 games with possession model against

default.

Team Goals Scored Wins

Possession Strategy 167 11

Default 233 28

5.4 Pass-chain Strategy

The strategy was tested by setting up scenarios with

one team using the strategy and one having default

behaviour. 5 players were part of each team, and each

scenario was run for 100 ticks. The metric used is

ﬁeld progress, calculated as an average on 200 runs

per strategy. As seen in table 4 the pass-chain strategy

has a better average ﬁeld progress.

Table 4: Results of 200 games in average ﬁeld progress.

Teams Average Field Progress

Pass-Chain 17.81

Default 16.58

To test the results statistically, a Wilcoxon signed-

rank test was used. We tested the data against the

null hypothesis 4, with signiﬁcance level 0.05. The

outcome of the test was a p-value of 0.52218, which

is not p < 0.05, thus we could not reject the null hy-

pothesis.

Null Hypothesis 4. The pass-chain performance is

identical to the default behaviour in terms of ﬁeld

progress.

5.5 Games against Other

Implementations

Finally, we have tested RoboPaal against other imple-

mentations. Since the stamina strategy and goalie de-

fender strategies appear to improve performance (see

sections 5.1 and 5.2) we utilised them for our team,

and we played using all the ofﬁcial rules.

The Keng implementation is available on

GitHub (Keng, 2015), and it was developed as part of

a course in machine learning at the Lafayette College

Strategising RoboCup in Real Time with Uppaal Stratego

279

Table 5: Results of games against other implementations.

RoboPaal vs RoboPaal vs

Keng HfutEngine

19 - 0 0 - 34

21 - 0 0 - 34

21 - 0 0 - 36

16 - 0 0 - 36

15 - 0 0 - 35

in the United States. This implementation won the

class tournament, and it employs a hybrid of reﬂex,

utility and goal-based agents using swarm intelli-

gence. Keng’s players were developed manually and

in the Python language, just like our ones. The games

were very one sided and all ended with a win for our

implementation, as seen in table 5.

We tested our implementation against the team

that won the 2019 World Championship, namely the

HfutEngine team (Lu et al., 2019). The players were

developed using neural networks combined with the

Helios Base player code (Zhiwei-Le et al., 2015),

which is a heavily optimised C++ code library that

takes care of most agent mechanisms and allows

teams to focus on the AI part of the players. As seen

in table 5 HfutEngine wins with a big lead against our

RoboPaal implementation.

Both the comparisons have, however, limited va-

lidity since there are large differences in the ability

of the players to analyse sensory input and perform

maneuvers such as dribbles, intercepts and passes.

The Keng implementation is created from scratch and

the players turn and move signiﬁcantly slower than

the RoboPaal agents. Inversely, the HfutEngine play-

ers are much more adept than the RoboPaal agents.

A more interesting comparison would involve future

work aimed at developing players using our strategies

over the Helios Base.

6 CONCLUSION

Generating strategies in real time for RoboCup

players using timed automata modelled in Uppaal

was proved to be possible. Challenges like time-

sensitivity can be mitigated using game state forecast-

ing combined with asynchronous computing, or of-

ﬂine strategy generation. In this work, we were able

to implement both kinds of strategies and compared

them in real games against existing RoboCup teams.

Future work considers to port our team to a better

codebase to be able to compete with world champi-

ons. In a wider sense, we also plan to apply the two

methods (state forecasting, and ofﬂine computation)

to other problems.

ACKNOWLEDGEMENTS

This work was partly founded by the TECH faculty

project “Digital Technologies for Industry 4.0”, Aal-

borg University.

REFERENCES

Akiyama, H. (2010). Robo cup soccer simulation 2d league

winning guide. ftp://ftp.iij.ad.jp/pub/sourceforge.jp/

rctools/46021/RoboCup2DGuideBook-1.0.pdf.

David, A., Jensen, P. G., Larsen, K. G., Miku

cionis, M., and

Taankvist, J. H. (2015). Uppaal stratego. In Baier, C.

and Tinelli, C., editors, Tools and Algorithms for the

Construction and Analysis of Systems, volume 9035

of LNCS, pages 206–211. Springer Berlin Heidelberg.

Eriksen, A. B., Huang, C., Kildebogaard, J., Lahrmann,

H., Larsen, K. G., Mu

niz, M., and Taankvist, J. H.

(2017). Uppaal stratego for intelligent trafﬁc lights.

http://people.cs.aau.dk/

∼

muniz/strategoTrafﬁc.pdf.

Keng, W. L. (2015). Cs 420, artiﬁcial intelligence,

robot soccer project, lafayette college department

of computer science. https://github.com/kengz/

robocup-soccer/blob/master/report/paper.pdf.

Larsen, K. G., Miku

cionis, M., Mu

niz, M., Srba, J.,

and Taankvist, J. H. (2016). Online and com-

positional learning of controllers with application

to ﬂoor heating. http://people.cs.aau.dk/

∼

muniz/

LMMST-TACAS-16.pdf.

Lu, K., Ma, J., Cai, Z., Wang, H., and Fang,

B. (2019). Hfutengine simulation 2d team.

http://archive.robocup.info/Soccer/Simulation/

2D/binaries/RoboCup/2019/PreliminaryRound/

HfutEngine SS2D RC2019 R1 BIN.tar.gz.

Robocup Federation (2020a). A brief history of robocup.

https://www.robocup.org/a brief history of robocup.

Robocup Federation (2020b). Robocup 2d simulation

league. https://www.robocup.org/leagues/24.

RoboPaal team (2020). Repository for robopaal codebase.

https://github.com/philipholler/RocoCup Soccer P6.

Rodrigues, H., Akiyama, H., Zare, N., and Obst, O. (2020).

The robocup soccer simulator. https://github.com/

rcsoccersim.

The RoboCup Simulator Committee (2020). The robocup

soccer simulator documentation. https://rcsoccersim.

github.io/manual/.

Uppaal (2019). About uppaal. http://www.uppaal.org/

about.

Wood, R. (2008). Beep test variations and mod-

iﬁcations. https://www.topendsports.com/testing/

beep-variations.htm.

Zhiwei-Le, Keting-LU, Wang, G., Hao-Wang, and Baofu-

Fang (2015). Hfutengine2015 simulation 2d team de-

scription paper. https://www.robocup2015.org/show/

article/95.html.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

280
