Automated Machine Learning for Wind Farms Location

Olivier Parisot and Thomas Tamisier

Luxembourg Institute of Science and Technology (LIST),

5 Avenue des Hauts-Fourneaux, 4362 Esch-sur-Alzette, Luxembourg

Keywords:

Automated Machine Learning, Wind Farms Location.

Abstract:

Automated Machine Learning aims at preparing effective Machine Learning models with little or no data

science expertise. Tedious tasks like preprocessing, algorithm selection and hyper-parameters optimization are

then automatized: end-users just have to apply and deploy the model that best suits the real world problem. In

this paper, we experiment Automated Machine Learning to leverage open data sources for predicting potential

next wind farms location in Luxembourg, France, Belgium and Germany.

1 INTRODUCTION

The growing application of Machine Learning in a

wide range of ﬁelds has led to the design of platforms

and frameworks facilitating the production of read-

ily actionable models. Even if statistical and coding

expertise are still required for data science (Mikalef

et al., 2018), such automatized systems are intended

to non-experts in classical situations.

In this context, Automated Machine Learning

consists in generating and deploying Machine Learn-

ing models from an input raw dataset with little or no

conﬁguration and coding effort (Hutter et al., 2019).

Let us consider the traditional pipeline for supervised

classiﬁcations, regressions and forecasting tasks:

• Data preprocessing is required to adjust the raw

data to the speciﬁcity of Machine Learning al-

gorithms (Parisot and Tamisier, 2015): cleansing

(missing data imputation or outliers), dimension-

ality alteration (features removal/creation) and

quantity alteration (data sampling or outliers re-

moval).

• A Machine Learning algorithm is then applied to

a train model from the preprocessed data.

• Depending on the algorithm, some hyper-

parameters have to be optimized to improve the

accuracy of the model; in general, this is real-

ized through heuristics requiring heavy computa-

tion (Feurer and Hutter, 2019).

• The accuracy of the obtained model is evaluated

by computing standard statistical tests (AUC, Pre-

cision, Recall, F1, etc.) with a given strat-

egy (holdout or cross-validation).

In practice, all those steps are time-consuming and ex-

posed to methodological errors. Automated Machine

Learning platforms aims at systematizing the whole

pipeline in order to launch it a number of times with

various combinations: several pipelines are tested, the

leading models are then compared and the most accu-

rate model is ﬁnally selected (Raschka, 2018).

In this work, we show how we can apply Auto-

mated Machine Learning to estimate the potential lo-

cation of next wind farms in Luxembourg, France,

Belgium and Germany by analyzing data from vari-

ous available sources.

The rest of this paper is organized as follows.

Firstly, existing Automated Machine Learning plat-

forms and their application potential are brieﬂy pre-

sented (Section 2). Secondly, the wind farm use case

is detailed (Section 3). Finally, the results of experi-

ments with a selection of Automated Machine Learn-

ing platforms are discussed (Section 4).

2 RELATED WORKS

Numerous Automated Machine Learning systems

were developed in recent years and an exhaustive list

was already compiled (Milutinovic et al., 2020). We

can consider two kinds of solutions:

• Open source tools like TPOT (Olson and Moore,

2016), Auto-Weka (Kotthoff et al., 2017) and

Auto-sklearn (Feurer et al., 2019): these frame-

works are mainly based on existing data mining

222

Parisot, O. and Tamisier, T.

Automated Machine Learning for Wind Farms Location.

DOI: 10.5220/0010232102220227

In Proceedings of the 10th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2021), pages 222-227

ISBN: 978-989-758-486-2

tools (sklearn, Weka) and were recently bench-

marked (Gijsbers et al., 2019).

• Commercial cloud-based solutions such as IBM

Watson AutoAI, Google Cloud AutoML, Mi-

crosoft Azure AutoML: these platforms are in-

tegrated in complete Machine Learning develop-

ment environments and managed through a graph-

ical user interface.

As regard the application potential, Automated

Machine Learning is more and more applied in var-

ious real world problems. Below are some recent ex-

amples:

• Logistic: optimization of commute times at

Toronto by analysing a database with past trans-

port delays (Cao et al., 2019).

• Education: support to educators in anticipating

students progression in online learning platforms

(Tsiakmaki et al., 2020).

• Healthcare: improvement of the care qual-

ity for British patients by analysing biomedical

databasets (Waring et al., 2020).

Moreover, recent works concern trustability of

models obtained with Automated Machine Learning.

As an example, a study has investigated why experi-

enced data scientists would use such automatic ap-

proaches. An other article even produces human-

readable reports with natural language to interpret

automatically obtained models (Steinruecken et al.,

2019).

In this paper, we apply Automated Machine

Learning to produce a model to assess the suitabil-

ity of a given area to host wind farms. Even if var-

ious computational methods for wind farms place-

ment have been proposed (Shahab and Singh, 2019),

no speciﬁc approach based on Automated Machine

Learning seems available.

3 USE CASE

Nowadays, the production of wind energy is more

than ever an environmental and political priority

(Hevia-Koch and Ladenburg, 2019). We can notice

the installation of new wind farms everywhere. To

understand and therefore anticipate this trend from a

data-driven approach, Machine Learning can be use-

ful. Positioning of wind farms is a complex problem:

weather conditions like wind speed are obviously im-

portant to justify their location, but other parameters

such as environment, performance, societal impact

are taken into account (Kazak et al., 2017).

To collect data that could be meaningful for the

prediction of the next wind farms locations in Luxem-

bourg, France, Belgium and Germany, we have con-

sidered various open data sources:

• Geographical locations of the current onshore

wind farms

• Historical time series of daily minimal/maxi-

mal/average wind speed values: each time serie

corresponds to a geolocated area and two years of

data have been considered.

• Elevations of the current wind farms by using the

STRM digital elevation model

: it may help de-

termine how much topology is taken into account

for installing wind farms.

• Cities positions and populations

: it may help to

check the relationships between wind farms loca-

tions and town centers.

• Points of Interests positions

: it may have an im-

pact on wind farms installation.

Combining these heterogeneous data sources and

by considering geographical areas with a width of

2500 meters, we have built an aggregated dataset with

ten features (Table 1). The last feature is a binary ﬂag

indicating if the location holds at least a wind farm

and can be used as a decision class. The area width

was empirically deﬁned after several experiments and

by considering the weather data coverage.

As a result, we considered the prediction of next

wind farms location as a supervised binary classiﬁca-

tion problem. The input dataset is class-imbalanced

since most of the considered geographical areas do

not accommodate wind farms. The challenge of deal-

ing with such imbalanced classes is found in vari-

ous domains like medical diagnosis or fraud detection

(Haixiang et al., 2017).

In the next section, we detail some experiments

to check if an accurate model can be obtained with a

selection of Automated Machine Learning platforms.

4 EXPERIMENTS

Starting from the previously described input dataset,

we have tested two commercial cloud platforms (IBM

Watson AutoAI, Microsoft Azure AutoML) and an

open source tool (TPOT). The goal is to build an ef-

ﬁcient Machine Learning model for wind farms pre-

diction rather than realizing a strict evaluations of Au-

https://data.open-power-system-data.org

http://srtm.csi.cgiar.org

https://www.geonames.org/

http://openpoimap.org

Automated Machine Learning for Wind Farms Location

223

Table 1: The structure of the dataset describing the location of existing onshore wind farms in Luxembourg/France/Bel-

gium/West of Germany (117278 records).

Numeric Latitude of the geographical area (degrees)

Numeric Longitude of the geographical area (degrees)

Numeric Elevation of the geographical area (meters)

Numeric Average wind speed on a recent time frame (meters per second)

Numeric Maximum wind speed on a recent time frame (meters per second)

Numeric Distance between the geographical area center and the nearby POI (meters)

Numeric Count of POIs in the considered geographical area

Numeric Distance between the geographical area center and the nearby town (meters)

Numeric Population of the nearby town

Binary TRUE if there is at least a wind farm in the geographical area, FALSE otherwise

tomated Machine Learning platforms; it was already

proposed by (Milutinovic et al., 2020).

The next sections detail the results obtained with

these different approaches (Table 2). Each statistical

test is computed by following the hold-out strategy

(Kohavi et al., 1995): 90% for training set, 10% for

test set.

4.1 Simple Python Code

To have a point of reference, we have developed a

simple Python source code to run the standard Gra-

dient Tree Boosting algorithm with the widely-used

scikit-learn package (Pedregosa et al., 2011). The

script executes the following steps: data loading, no

data preprocessing, training with default parameters

and then evaluation of the leading model.

. . .

r f c = G r a d i e n t B o o s t i n g C l a s s i f i e r ( )

t r a i n i n g F = [ . . . ]

t r a i n i n g T = [ . . . ]

r f c . f i t ( t r a i n i n g F , t r a i n i n g T )

. . .

As a result, the output model has a good-enough

Precision score but a insufﬁcient Recall score (Table

2). The next sections will show if Automated Ma-

chine Learning platforms can provide better results

for the current use case.

4.2 IBM Watson AutoAI

Watson AutoAI is a module integrated into the on-

line IBM Watson Machine Learning service which is

mainly accessible through a graphical user-interface

(Figure 1).

The result of our test with Watson AutoAI is as

follows: after the data ingestion and some computa-

tion time, the platform proposes a short list of four

predictive models obtained with the LGBM classi-

ﬁer (i.e. an implementation of Gradient Boosting

Tree). The best model is obtained with the following

pipeline:

• The features engineering phase leads to the

generation of twelve additional features like

square(sin(elevation)).

• Two hyper-parameters have been optimized

though optimizations are not clariﬁed.

Despite various efforts to optimize the conﬁgura-

tion, we did not succeed in improving the best model

produced by of Watson AutoML, above the score (low

F1: 0.343). The model obtained with the simple

Python script remains therefore the best one.

4.3 Microsoft Azure AutoML

AutoML is integrated in Azure Machine Learning

Studio, an integrated development environment for

designing Machine Learning workﬂow on the Mi-

crosoft cloud platform.

From a user point of view, Azure AutoML and

IBM Watson AutoAI are slightly different. Once in-

put data are loaded into Microsoft Azure AutoML, a

data guards step checks the data characteristics and

produces warnings if some issues are detected (miss-

ing data, imbalanced class, cardinaltity check, etc.).

These warnings do not trigger automatical data pre-

processing: they are just provided to inform the end-

user that those issues may have an impact on the ﬁnal

results. After these checks, Azure AutoAI launches a

list of 74 jobs to run various pipelines (data prepro-

cessing, algorithm selection, hyper-parameters opti-

mization). At the end, the best model has good esti-

mators (F1, Precision, Recall) that are really similar

to the one obtained with Python source code. This

model is computed with this pipeline:

• Algorithm: Voting Ensemble, i.e. a weighted en-

semble of other models (not described).

• Features preprocessing and hyper-parameters op-

timization are not described too.

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

224

Table 2: Hold-out evaluation of the produced models for wind farms location prediction (90% for training set, 10% for

test set). Two commercial platforms were tested, an open-source solution was used and a simple Python source code was

implemented to have a reference.

Test Preprocessing Best algorithm Precision Recall F1

Python code Nothing Gradient Tree Boosting 0.825 0.540 0.567

Watson AutoAI Described LGBM 0.240 0.599 0.343

Azure AutoML Not described VotingEnsemble 0.783 0.623 0.670

TPOT Fully reproductible Random Forests cascade 0.759 0.693 0.721

Figure 1: Interactive Dashboard of IBM Watson Studio AutoAI: the Automated Machine Learning steps are then represented

during the computation of a predictive model for next wind farms location.

Figure 2: Interactive Dashboard of Microsoft Azure AutoML during the generation of a machine learning model for next

wind farms location prediction.

Automated Machine Learning for Wind Farms Location

225

4.4 TPOT

TPOT (Tree-based Pipeline Optimization Tool) is an

open source Automated Machine Learning solution

based on a Genetic Algorithm (Olson and Moore,

2016) As a Python package, TPOT aims at building

optimized classiﬁcations and regressions models by

writing some source code or by launching a conﬁg-

urable command-line tool. In this work, we have used

the second method to analyze our dataset (Figure 3).

The resulting model is much better than those ob-

tained with the Python script and with the tested Au-

tomated Machine Learning platforms. The following

piece of Python source code is generated by TPOT

and allows to understand exactly the pipeline leading

to the best model (data preprocessing, algorithm train-

ing, hyper-parameters optimization):

. . .

p i p e l i n e = m a k e p i p e l i n e (

S t a c k i n g E s t i m a t o r (

e s t i m a t o r = R a n d o m F o r e s t C l a s s i f i e r (

b o o t s t r a p = F a ls e ,

c r i t e r i o n =” e n t r o p y ” ,

m a x f e a t u r e s = 0 . 5 5 ,

m i n s a m p l e s l e a f = 3 ,

m i n s a m p l e s s p l i t = 1 6 ) ) ,

R a n d o m F o r e s t C l a s s i f i e r (

b o o t s t r a p = F a l s e ,

c r i t e r i o n =” e n t r o p y ” ,

m a x f e a t u r e s = 0 . 6 5 ,

m i n s a m p l e s l e a f = 10 ,

m i n s a m p l e s s p l i t = 1 6)

)

t r a i n i n g F = [ . . . ]

t r a i n i n g T = [ . . . ]

p i p e l i n e . f i t ( t r a i n i n g F , t r a i n i n g T )

. . .

Figure 3: Command-line Dashboard of TPOT during the

computation of an optimized model.

4.5 Discussion

According to our experiments (Table 2), we have ob-

served that the tested Automated Machine Learning

platforms can produce different pipelines and then

models for the prediction of next wind farms location.

Even if the computation takes time and resources, the

accuracy of the yielded out models does not always

supasses the accuracy of the simple Python source

code.

Azure AutoAI provides a good model with few

effort (no source code and very little conﬁguration)

while Watson AutoML generates a poor one: it could

be explained by the class-imabalanced input dataset

(Azure AutoAI has detected this point, AutoML not).

By using these two commercial platforms, the result-

ing models can be deployed and then used with one

click. However, we notice some limitations:

• The ﬁrst one is due to the feature engineering

phase: it may lead to features creation that are

hard to interpret (example: square(sin(elevation))

in Watson AutoML), or the result is not described

at all by the platform (Azure AutoML). As shown

in (Drozdal et al., 2020), it may be a major draw-

back in case of we need to adapt the model.

• A further limitation is the lack of customisation

in order to adapt manually the resulting pipelines

(preprocessing and hyper-parameters). There is

now way to change anything, the end-user can

just choose a model among the list of those which

were computed.

According to our experiments, an open source tool

like TPOT produces better models to predict the next

wind farms location, It is clearly more complex to use

for non experts (there is no user-friendly interface and

the deployment requires a lot of coding), but it allows

a higher level of customization (many parameters can

be set before the Automated Machine Learning pro-

cess and it is possible to generate ready-to-use Python

code for running computed models).

5 CONCLUSION

In this work, we applied Automated Machine Learn-

ing to build a model checking if a geographical

zone is suitable to host wind farms in Luxembourg,

France, Belgium and Germany. A relevant dataset

was built from open data sources and predictive mod-

els have been trained with various commercial and

open source Automated Machine Learning platforms.

In future work, we will take advantage of High-

Performance Computing infrastructure (HPC) to

efﬁciently analyze the evolution over time of wind

farms installation policies.

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

226

ACKNOWLEDGMENTS

This work was funded by the FEDER Data Analyt-

ics Platform project (http://tiny.cc/feder-dap-project).

Special thanks to Anne Hendrick, Samuel Renault

and Raynald Jadoul for their support.

REFERENCES

Cao, T., Roy, D., and Nedelescu, T. (2019). Optimizing

Commute Time with IBM Watson Studio. In CCSE

2019, pages 388–390.

Drozdal, J., Weisz, J., Wang, D., Dass, G., Yao, B., Zhao,

C., Muller, M., Ju, L., and Su, H. (2020). Trust in

AutoML: exploring information needs for establishing

trust in automated machine learning systems. In ACM

IUI 2020, pages 297–307.

Feurer, M. and Hutter, F. (2019). Hyperparameter optimiza-

tion. In Automated Machine Learning, pages 3–33.

Springer, Cham.

Feurer, M., Klein, A., Eggensperger, K., Springenberg,

J. T., Blum, M., and Hutter, F. (2019). Auto-

sklearn: efﬁcient and robust automated machine learn-

ing. In Automated Machine Learning, pages 113–134.

Springer, Cham.

Gijsbers, P., LeDell, E., Thomas, J., Poirier, S., Bischl, B.,

and Vanschoren, J. (2019). An open source AutoML

benchmark. arXiv preprint.

Haixiang, G., Yijing, L., Shang, J., Mingyun, G., Yuanyue,

H., and Bing, G. (2017). Learning from class-

imbalanced data: Review of methods and applica-

tions. Expert Systems with Applications, 73:220–239.

Hevia-Koch, P. and Ladenburg, J. (2019). Where should

wind energy be located? a review of preferences and

visualisation approaches for wind turbine locations.

Energy Research and Social Science, 53:23–33.

Hutter, F., Kotthoff, L., and Vanschoren, J. (2019). Au-

tomated machine learning: methods, systems, chal-

lenges. Springer Nature.

Kazak, J., Van Hoof, J., and Szewranski, S. (2017). Chal-

lenges in the wind turbines location process in central

europe–the use of spatial decision support systems.

Renewable and Sustainable Energy Reviews, 76:425–

433.

Kohavi, R. et al. (1995). A study of cross-validation and

bootstrap for accuracy estimation and model selec-

tion. In Ijcai, volume 14, pages 1137–1145. Montreal,

Canada.

Kotthoff, L., Thornton, C., Hoos, H. H., Hutter, F., and

Leyton-Brown, K. (2017). Auto-WEKA 2.0: Auto-

matic model selection and hyperparameter optimiza-

tion in WEKA. The Journal of Machine Learning Re-

search, 18(1):826–830.

Mikalef, P., Giannakos, M. N., Pappas, I. O., and Krogstie,

J. (2018). The human side of big data: Understanding

the skills of the data scientist in education and indus-

try. In IEEE Global Engineering Education Confer-

ence, pages 503–512.

Milutinovic, M., Schoenfeld, B., Martinez-Garcia, D., Ray,

S., Shah, S., and Yan, D. (2020). On evaluation of

AutoML systems.

Olson, R. S. and Moore, J. H. (2016). TPOT: A tree-

based pipeline optimization tool for automating ma-

chine learning. In Workshop on automatic machine

learning, pages 66–74. PMLR.

Parisot, O. and Tamisier, T. (2015). An interactive tool for

transparent data preprocessing. ERCIM NEWS, 100(1-

4):33.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer, P.,

Weiss, R., Dubourg, V., et al. (2011). Scikit-learn:

Machine learning in python. Journal of ML research,

12:2825–2830.

Raschka, S. (2018). Model evaluation, model selection,

and algorithm selection in machine learning. arXiv

preprint.

Shahab, A. and Singh, M. (2019). Comparative analysis of

different machine learning algorithms in classiﬁcation

of suitability of renewable energy resource. In ICCSP

2019, pages 0360–0364.

Steinruecken, C., Smith, E., Janz, D., Lloyd, J., and Ghahra-

mani, Z. (2019). The automatic statistician. In Auto-

mated Machine Learning, pages 161–173. Springer,

Cham.

Tsiakmaki, M., Kostopoulos, G., Kotsiantis, S., and Ra-

gos, O. (2020). Implementing AutoML in educational

data mining for prediction tasks. Applied Sciences,

10(1):90.

Waring, J., Lindvall, C., and Umeton, R. (2020). Automated

machine learning: Review of the state-of-the-art and

opportunities for healthcare. Artiﬁcial Intelligence in

Medicine, page 101822.

Automated Machine Learning for Wind Farms Location

227
