DLP-Visor: A Hypervisor-based

Data Leakage Prevention System

Guy Amit

, Amir Yeshooroon

, Michael Kiperberg

and Nezer J. Zaidenberg

Software Engineering Department, Shamoon College of Engineering Beer-Sheva, Israel

School of Computer Science, The College of Management, Academic Studies, Israel

Keywords:

Virtual Machine Monitors, Hypervisors, Trusted Computing Base, Data Leakage Prevention.

Abstract:

Data theft by insiders is considered by many organisations to be one of the most serious threats. Data leakage

prevention (DLP) systems attempt to prevent intentional or accidental disclosure of sensitive information by

monitoring the content or the context in which the information is transferred, for example, in a ﬁle system,

an email server, instant messengers. We present a context-sensitive DLP system, called DLP-Visor, which is

implemented as a thin hypervisor capable of intercepting system calls in Windows operating systems equipped

with Kernel Patch Protection. By intercepting system calls that govern the ﬁle system, inter-process commu-

nications, networking, system register and system clipboard, DLP-Visor guarantees that sensitive information

can never leave a predeﬁned set of directories. The performance overhead of DLP-Visor (7.2%) allows its

deployment in real-world applications.

1 INTRODUCTION

One of the main goals of information security is to

prevent unauthorised entities from accessing sensitive

information. Many systems protect the sensitive in-

formation from external attacks by using encryption

(Khati et al., 2017; Guo et al., 2016) or by imple-

menting an access control (Li et al., 2019; Tourani

et al., 2017). In this paper, we focus on insider at-

tacks, in which an organisation employee steals sen-

sitive information that they can legitimately access.

An insider attack can also manifest in the form of a

malicious program executed with the privileges of an

employee who has access to sensitive information. In

order to combat these attacks, researchers have pro-

posed a new type of information security — Data

Leakage Prevention (DLP) systems.

DLP systems can be divided into two types (Al-

neyadi et al., 2016): content-based and context-based.

Both types prevent certain operations that can leak

sensitive information. Context-based DLP systems

determine the validity of an operation based on its

metadata while content-based DLP systems consider

the data itself. For example, a context-based DLP

system can prevent sending of an email if the desti-

nation email is not in the organisation’s domain. A

content-based DLP system can prevent sending of an

email if it contains the name of a classiﬁed project.

Content-based DLP systems tend to have a greater

performance impact due to the analysis they perform

on the content, which is usually larger than the con-

text. Content-based DLP systems use heuristics to

determine whether the content matches a predeﬁned

rule. For example, Kantor (Kantor et al., 2012) pro-

posed to compare hashes of individual paragraphs or

sentences. Clearly, minor modiﬁcations of sentences

will produce different hashes.

On the other hand, context-based DLP systems are

less ﬂexible. A context-based DLP system can be

conﬁgured to either allow sending emails to certain

domains or block them completely. The decision can-

not be made based on the content of the email or an

attachment.

We propose a context-based DLP system, imple-

mented as a thin hypervisor (Shinagawa et al., 2009;

Seshadri et al., 2007), capable of executing a single

operating system. We call our system “DLP-Visor”.

Thin hypervisors have two beneﬁts compared with

full hypervisors: their code base is small enough to al-

low formal veiriﬁcation and their performance is bet-

ter due to the exclusion of time-consuming compo-

nents such as memory management, hardware alloca-

tion and scheduling.

In contrast to system call interception mechanisms

that are implemented in user-mode (W

uchner and

Pretschner, 2012), DLP-Visor reliably intercepts op-

416

Amit, G., Yeshooroon, A., Kiperberg, M. and Zaidenberg, N.

DLP-Visor: A Hypervisor-based Data Leakage Prevention System.

DOI: 10.5220/0010221104160423

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 416-423

ISBN: 978-989-758-491-6

erating system events by intercepting kernel-mode

functions. Moreover, DLP-Visor, having higher priv-

ileges than the operating system, can operate even in

the presence of a patch detection mechanism like Mi-

crosoft Kernel Patch Protection (Field, 2006).

DLP-Visor allows the system administrator to se-

lect a set S of directories that contain sensitive ﬁles.

A process that opens a sensitive ﬁle becomes critical

and a ﬁle written by a critical process becomes sensi-

tive. The system clipboard becomes sensitive when it

receives data from a critical process. When a process

receives data from a sensitive clipboard, it becomes

critical. In other words, ﬁles and the system clip-

board act as criticality mediators. In order to prevent

information leakage through other channels provided

by the operating system, DLP-Visor does not allow

critical processes to write to the registry, use network

sockets or write to memory of another process. DLP-

Visor uses a system call interception mechanism to

keep track of the critical processes and restrict their

operations.

We make the following assumptions about the

abilities of an attacker:

• The attacker does not have kernel-mode privi-

leges.

• The attacker has full (administrator) user-mode

rights.

Under these assumptions, we claim that DLP-Visor

can provide the following guarantee: information that

resides in sensitive directories cannot be copied out-

side of them. In particular, sensitive information can-

not be copied to external media, sent in the body of an

email or as an attachment, copied to a network folder

or uploaded to a website.

The main contributions of the paper are:

• We describe the design of DLP-Visor, a

hypervisor-based data leakage prevention system.

• We compare the performance of two system call

interception mechanisms.

• We evaluate the performance and security of

DLP-Visor.

Our results show that performance degradation due to

DLP-Visor is insigniﬁcant (7.2 %), allowing its de-

ployment even in high-performance workstations.

2 BACKGROUND

Virtualization extensions to CPUs were introduced in

2005-2006 by Intel and AMD. These extensions al-

low the CPU to execute multiple operating systems si-

multaneously in isolated environments called “Virtual

Machines” (VMs). The software component that con-

ﬁgures and monitors the execution of VMs is called

a “Virtual Machine Monitor” (VMM) or a “hypervi-

sor”. In particular, the hypervisor can conﬁgure the

interception of various events that occur in the VMs,

e.g. execution of privileged instructions, interrupts,

memory accesses, etc. When an event conﬁgured for

interception occurs, the CPU transfers control from

the VM to the hypervisor.

The hypervisor inspects the information that de-

scribes the occurred event and reacts accordingly. Af-

ter completion of the event handling, the hypervisor

transfers control back to the VM.

In 2007-2008, AMD and Intel introduced a

Secondary-Level Address Translation (SLAT) mech-

anism to their virtualization extensions, allowing the

hypervisor to handle memory virtualization more efﬁ-

ciently. With SLAT, the hypervisor can deﬁne a page

table for each VM, which deﬁnes translation of the

VMs’ physical addresses to real physical addresses.

Each entry of SLAT deﬁnes not only the mapping be-

tween addresses but also the access rights, thus effec-

tively allowing the hypervisor to intercept accesses to

physical pages.

A hypervisor can intercept a wide range of events.

We will discuss only those that are relevant to this pa-

per. The ﬁrst type of event is access to MSRs, special

registers used to report the features of a CPU and con-

ﬁgure its state. They participate in the conﬁguration

• 64-bit environments via the EFER MSR;

• system call mechanism via the STAR and

SYSENTER families of MSRs; and

• physical memory caching policies via the MTRR

family of MSRs, etc.

Two special instructions allow the software to write to

and read from MSRs, which are identiﬁed by a num-

ber. The hypervisor can intercept read and write MSR

accesses separately for each MSR. Upon transition to

the hypervisor, the number of the MSR and its new

value, in the case of a write operation, are reported to

the hypervisor.

Exceptions delivery is another type of event. By

conﬁguring the exception bitmap ﬁeld, the hypervisor

can intercept an exception before it is delivered to the

operating system. Upon transition to the hypervisor,

the exception number and error code are reported to

the hypervisor.

The last type of event that has relevance to this

paper is so-called “EPT-violations”; i.e. access to the

VMs’ physical addresses that cannot be translated to

real physical addresses. In essence, EPT-violations

are page-faults in the secondary-level address trans-

DLP-Visor: A Hypervisor-based Data Leakage Prevention System

417

lation. EPT-violations can occur either due to absent

entries in the secondary-level page table or due to in-

appropriate rights, e.g. write access to a read-only

page. Upon transition to the hypervisor, the virtual

and physical addresses are reported to the hypervisor.

In addition, the hypervisor receives a value that re-

sembles an error-code. This value can be used to de-

termine the reason for the EPT-violation.

3 SYSTEM CALL

INTERCEPTION

System call interception enables a software module

to monitor the behaviour of an entire operating sys-

tem or a speciﬁc application. This monitoring ability

is useful in the implementation of protective, i.e. anti-

virus, and offensive, i.e. malware, software. System

call interception approaches can be divided into two

types: user-mode interception and kernel-mode inter-

ception. In user-mode interception, the code of the

wrapper functions is replaced with a call to a monitor

that eventually performs the actual system call. The

monitor can inspect: the argument of the system call

before its execution and the return values of the sys-

tem call after its completion. The monitor can also

respond to an attempt of system call execution by no-

tifying the user, preventing the system call completely

or modifying its arguments.

We note that user-mode interception is vulnerable

to user-mode attacks and, therefore, is ineffective in

our attack model. For example, a memory corruption

attack can overwrite the monitoring system call wrap-

per with the code of the original system call wrap-

per, thus disabling the monitoring functionality. Ulti-

mately, an attacker can execute the sysenter or the

syscall instruction directly, without even calling the

monitoring system call wrapper.

Kernel-mode system call interception can defeat

the user-mode attacks by installing the interception

mechanism in the kernel itself. Prior to introduc-

tion of Microsoft’s Kernel Patch Protection (KPP)

(Field, 2006), the interception was mainly performed

by changing SSDT entries to point to monitoring

functions, which then call the original functions. Be-

cause SSDT patching was frequently used for mali-

cious purposes, Microsoft decided to prohibit its mod-

iﬁcation. Microsoft’s KPP periodically computes a

checksum of SSDT and produces a BSOD when a

modiﬁcation is detected. KPP can also detect modiﬁ-

cation of the model speciﬁc registers involved in sys-

tem call handling.

Fortunately, in some cases, a hypervisor can hide

modiﬁcation of sensitive registers and data structures,

thus allowing it to intercept system calls in kernel-

mode even when KPP is active. In this section, we

explain how DLP-Visor can intercept not only entries

but also exits from system calls.

3.1 Interception of System Call Entries

In order to reduce the interception overhead of irrele-

vant events, we propose to use a targeted interception

mechanism, which allows the hypervisor to intercept

only those system calls that need to be monitored. Our

approach is inspired by the Stealth Breakpoints intro-

duced in (Deng et al., 2013; Lengyel et al., 2014).

According to this approach, the hypervisor replaces

the ﬁrst instruction of the function it wishes to inter-

cept with the INT3 instruction. The hypervisor stores

the original instruction in its internal data structures.

Finally, the hypervisor conﬁgures interception of the

breakpoint exception. When a breakpoint exception

occurs the hypervisor emulates the ﬁrst instruction,

advances the instruction pointer to the next instruc-

tion, and continues the VM’s execution. This method

allows the hypervisor to intercept only the system

calls that require monitoring.

The hypervisor can use ofﬁcially distributed sym-

bol ﬁles (Microsoft, 2020b) to ﬁnd the addresses

of the functions that need to be intercepted. Due

to address-space layout randomisation (Cook, 2013),

the actual addresses of the functions change on ev-

ery boot, but relative offsets of the functions remain

constant. The idea is to statically calculate the off-

sets of the function that require interception from the

system call handler and use them later for calcula-

tion of actual addresses. When the operating system

writes an address to the IA32 SYSENTER EIP or the

IA32 LSTAR MSRs, the hypervisor adds to this ad-

dress the offsets of the functions than require intercep-

tion and obtains the actual address in which a break-

point is inserted.

Unfortunately, KPP triggers a BSOD when it

detects modiﬁcation of the kernel code, such as the

breakpoint instruction that the hypervisor inserted. In

order to prevent KPP from detecting the breakpoint,

the hypervisor marks the page containing the break-

point is not readable in the SLAT. The code in the

page can run without intervention of the hypervisor

(with the exception of the INT3 instruction); however,

any attempt to read the page is intercepted by the

hypervisor. Normally, pages containing code are read

only by the KPP mechanism. The hypervisor reacts to

such read attempts by emulating the read instruction,

advancing the instruction pointer and returning to

the VM. During the emulation, the hypervisor re-

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

418

Original NtCreateFile:

NtCreateFile:

0xffffffff6b2901c0: sub rsp, 88h

0xffffffff6b2901c7: xor eax,eax

0xffffffff6b2901c9: ...

Instrumented NtCreateFile:

NtCreateFile:

0xffffffff6b2901c0: int3

0xffffffff6b2901c1: int3

0xffffffff6b2901c2: <unreachable fragment>

0xffffffff6b2901c7: xor eax,eax

0xffffffff6b2901c9: ...

Figure 1: NtCreateFile before and after instrumentation.

turns the original value if KPP attempts to ac-

cess the INT3 instruction.

3.2 Interception of System Call Returns

Interception of returns from system call handlers is a

more challenging task. The idea is to change the re-

turn address of the call frame such that the instruction

at the new address will trigger the hypervisor. The

hypervisor reacts to this event by setting the instruc-

tion pointer to the original return address and return-

ing control to the VM.

More precisely, the hypervisor installs two INT3

instructions at the beginning of a function that needs

to be intercepted. Figure 1 shows an example of

NtCreateFile instrumentation. The purpose of each

INT3 instruction is to trigger the hypervisor. The ﬁrst

INT3 instruction triggers the hypervisor on an entry to

the intercepted function while the second INT3 trig-

gers the hypervisor on an exit from the intercepted

function. The hypervisor reacts to the ﬁrst INT3 by

setting the return address in the call frame to the ad-

dress of the second INT3. Upon an exit from the in-

tercepted function the second INT3 is executed, trig-

gering the hypervisor. The hypervisor reacts to the

second INT3 by setting the instruction pointer to the

original return address. The hypervisor does not have

to record the original return address before changing

it in the call frame because this address is identical for

all the system call handlers. Algorithm 1 summarises

the operation of the hypervisor with regard to break-

point handling.

4 SYSTEM DESIGN

The main component of the DLP-Visor is the sys-

tem call interception mechanism that was described in

Section 3. During its initialization, DLP-Visor con-

Algorithm 1: Algorithm for breakpoint handling. In the

case of NtCreateFile, InstructionLength is 7 and Emu-

lateInstruction() is equivalent to RSP := RSP - 0x88.

1: handled := FALSE

2: for all intercepted functions do

3: if RIP = Address of 1

INT3 then

4: handled := TRUE

5: HandleEntry()

6: STACK[RSP - 8] := RIP + 1

7: RIP := RIP + InstructionLength

8: EmulateInstruction()

9: else if RIP = Address of 2

INT3 then

10: handled := TRUE

11: HandleExit()

12: RIP := OriginalReturnAddress

13: end if

14: end for

15: if not handled then

16: Inject the exception to the OS

17: end if

ﬁgures interception of writes to the IA32 LSTAR or

IA32 SYSENTER EIP MSRs, depending on the oper-

ating system architecture. When the operating sys-

tem writes to the appropriate MSR, the hypervisor as-

sumes that the kernel’s initialiwation is complete and

installw the breakpoints in the system call handlers

that require interception. The hypervisor can obtain

the addresses of the system call handlers from SSDT

or from symbol ﬁles. Each entry in the SSDT con-

tains the address of the system call that corresponds

to this entry. The indexes of the entries can be hard-

coded in the hypervisor or obtained synamically by

disassembling the user-mode wrappers.

After completing the breakpoint installation pro-

cess, DLP-Visor resumes the operating system. The

operating system executes normally and DLP-Visor is

notiﬁed about each entry to- and exit from the system

calls that require interception. Table 1 summarises the

intercepted system calls and the action performed by

DLP-Visor on each system call.

The system calls intercepted by the DLP-Visor

can be broadly divided into two categories: (a) infor-

mative and (b) operational. Informative system calls

modify the internal data structures of the DLP-Visor

and the DLP-Visor never blocks these system calls.

Operational system calls are those that require ﬁlter-

ing. For example, NtCreateUserProcess is an infor-

mative system call, whereas NtWriteFile is an oper-

ational system call.

DLP-Visor uses two sets in its internal data struc-

tures and an additional set for each critical process:

• S — the set of sensitive ﬁles and directories;

• C — the set of critical processes; and

DLP-Visor: A Hypervisor-based Data Leakage Prevention System

419

Table 1: Intercepted System Calls. The current and the target (where applies) processes are denoted by p and q, respectively.

The directory of the target ﬁle f is denoted by d.

System Call When Type Action

NtCreateFile/NtOpenFile Exit Informative If d is sensitive, mark p as critical.

NtCreateFile/NtOpenFile Exit Informative Store the directory d of the target ﬁle.

NtCreateUserProcess Exit Informative If p is critical, mark q as critical.

NtWriteFile Entry Operational Block if p is critical and d is not sensitive.

NtDeviceIoControlFile Entry Operational Block if p is critical.

NtSetInformationFile Entry Operational Block if p is critical and f is sensitive.

NtReadVirtualMemory Entry Operational Block if q is critical.

NtWriteVirtualMemory Entry Operational Block if p is critical.

NtUserSetClipboardData Exit Informative If p is critical, mark the clipboard as sensitive.

NtUserGetClipboardData Exit Informative If the clipboard is sensitive, mark p as critical

NtSetValueKey Entry Operational Block if p is critical.

• H

— the set of handles to sensitive ﬁles in a crit-

ical process p ∈ C

Initially, set S contains the directories that were se-

lected by the system administrator as sensitive and set

C is empty. Set S may contain a special item  denot-

ing the clipboard. An empty set H

is allocated for

each newly detected critical process p ∈ C. For sim-

plicity, we write f ∈ S if f belongs to S or if f resides

in a directory that belongs to S.

DLP-Visor prevents the execution of system

calls by corrupting their arguments. Speciﬁcally,

NtWriteFile and NtDeviceIoControlFile receive

a ﬁle handle as their ﬁrst argument. By setting this

argument to INVALID HANDLE VALUE (0), DLP-Visor

causes these system calls to fail.

5 EVALUATION

This section presents the evaluation of DLP-Visor

with respect to security guarantees and performance

overhead. The system was tested in a virtualized en-

vironment. The exact conﬁguration of the testing en-

vironment is presented in Table 2.

Table 2: Testing environment conﬁguration.

Host CPU Intel(R) Core(TM) i7-10610U

Host memory 16 GB

Host OS Ubuntu 20.04.1 LTS

VMM VMware Workstation 15.5.6

Guest CPU Intel(R) Core(TM) i7-10610U

Guest memory 8 GB

Guest OS Windows 10 (19041)

5.1 Security

DLP-Visor provides the following security guarantee:

information that resides in sensitive directories can-

not be copied outside of them. We assume that an

attacker does not have kernel-mode privileges and,

therefore, cannot observe the memory or the ﬁle sys-

tem directly. The attacker is forced to use system calls

to exﬁltrate information from sensitive ﬁles. A pro-

cess becomes critical on the ﬁrst attempt to access

sensitive ﬁles. Therefore, the guarantee of DLP-Visor

can be formulated as follows: Critical processes can

output their data only to ﬁles that reside in sensitive

directories.

We identify the following channels through which

critical processes can leak information:

• ﬁles — using the NtWriteFile or the

NtSetInformationFile system call;

• Inter-Process Communication (IPC) — using the

NtWriteFile system call;

• clipboard — using the

NtUserSetClipboardData system call;

• drivers — using the NtDeviceIoControlFile

system call;

• registry — using the NtSetValueKey system call;

and

• memory — using the

NtWrite/ReadVirtualMemory system call.

The current implementation of DLP-Visor pre-

vents critical processes from writing to drivers

(NtDeviceIoControlFile), the system registry

(NtSetValueKey) and the memory of another process

(NtWriteVirtualMemory). Likewise, DLP-Visor

prohibits reading from the memory of a critical pro-

cess (NtReadVirtualMemory). In additional, DLP-

Visor prohibits moving (renaming) sensitive ﬁles us-

ing the NtSetInformationFile system call. Writ-

ing to ﬁle handles that correspond to: ﬁles that reside

outside sensitive directories, mail slots, and pipes is

prohibited as well. The sensitive data can pass freely

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

420

between critical processes using the system clipboard,

but the critical processes will not be able to output this

data outside the sensitive directories.

The current implementation of DLP-Visor is re-

strictive in terms of functionality available for criti-

cal processes. In order to assess the applicability of

DLP-Visor to real-world applications, we selected a

set of common desktop applications. All applications

worked normally, until we pasted a sensitive text. The

behaviour of the tested applications after becoming

critical was as follows:

• Microsoft Word and Microsoft PowerPoint after

pasting sensitive data, worked normally but failed

to save a ﬁle in a non-sensitive directory. An error

message appeared in response.

• Microsoft Outlook after pasting sensitive data,

worked normally but it failed to send an email.

An error message appeared in response.

• Microsoft Edge after pasting sensitive data, dis-

played an error message about loss of internet

connection.

• FileZilla on an attempt to transfer a sensitive ﬁle

to a remote FTP directory, an error message ap-

peared.

• PuTTY on an attempt to transfer a sensitive ﬁle via

SFTP, aborted the connection.

• Firefox and Chrome terminated after pasting sen-

sitive data due to excessive use of inter-process

communication.

In most test cases, the applications behaved in a pre-

dictable fashion: after becoming critical, the appli-

cations continue to function normally but with cer-

tain limitations. Notable exceptions are Firefox and

Chrome, which terminated after becoming critical.

This can be explained by the design of these appli-

cations. Firefox and Chrome consist of multiple pro-

cesses that use inter-process communication mech-

anisms. Unfortunately, the current implementation

of DLP-Visor blocks these mechanisms, resulting in

hangs and termination of these applications. We plan

to address this issue in future versions of DLP-Visor.

5.2 Performance

DLP-Visor intercepts several system calls. Some of

these system calls, notably the NtWriteFile system

calls, are frequently called during normal execution.

In order to assess the performance degradation due

to these interceptions, we ran a benchmarking tool

called PCMark (Sibai, 2008) in four conﬁgurations:

(a) without a hypervisor, (b) with a thin hypervi-

sor without interceptions, (c) with DLP-Visor and (d)

Table 3: PCMark scores in four conﬁgurations.

Category

No Hypervisor

Thin Hypervisor

DLP-Visor

VirtualBox

App start-up 7277 7110 6358 4008

Video 2129 2307 1862 1197

Web browsing 2067 2012 2028 1390

Spreadsheet 4473 4420 4215 2688

Writing 5005 4928 4861 2870

Photo editing 850 852 817 524

Video editing 903 887 804 650

with Oracle VirtualBox (6.1.14) as an example of a

full hypervisor, running the same version of Windows

with 8GB of RAM. The exact conﬁguration of our

testing environment is summarised in Table 2. Table

3 presents the scores that were given by PCMark in

each conﬁguration for every category. As expected,

the performance degradation of a thin hypervisor is

negligible (≈ 1.7% on average), whereas the perfor-

mance degradation of a full hypervisor is unaccept-

ably high (≈ 38.6% on average). The average perfor-

mance overhead of DLP-Visor is ≈ 7.2%. We believe

that this performance degradation will not have a con-

siderable negative impact on user experience.

In some tests, the results seem counter-intuitive

due to measurement errors. For example, in the

“Video conferencing” test, the system performed bet-

ter in the “Thin hypervisor” conﬁguration than with-

out a hypervisor. Another example is the “Web

browsing” test, in which DLP-Visor performed better

than a thin hypervisor.

6 RELATED WORK

DLP-Visor is based on two somewhat independent

ﬁelds in software security: data leakage prevention

and virtual machine introspection. In this section, we

describe the similarities (and dissimilarities) among

previous works in these ﬁelds and DLP-Visor.

Data leakage prevention systems can be divided

into two categories (Alneyadi et al., 2016): context-

sensitive and content-sensitive. Content-sensitive

DLP systems use regular expressions, statistical

methods or advanced hashing techniques to identify

sensitive data exﬁltration attempts (McAfee, 2020;

Microsoft, 2020a; Google, 2020; Checkpoint, 2020;

Shvartzshnaider et al., 2019). As such, these meth-

ods are not able to identify leakage of transformed or

encrypted data.

DLP-Visor: A Hypervisor-based Data Leakage Prevention System

421

Some context-sensitive DLP systems work ac-

cording to coarse security policies, such as preventing

users from using removable media (Halpert, 2004).

DLP-Visor provides a more ﬁne-grained conﬁgura-

tion of sensitive and restricted locations.

The idea of sensitiveness that spreads between

ﬁles touched by processes was ﬁrst introduced in

(Petkovic et al., 2012). The authors proposed a kernel

module for the Linux operating system that monitors

the operations performed on the ﬁlesystem. Speciﬁ-

cally, after a process performs a read from a sensitive

ﬁle, all its subsequent writes mark the target ﬁles as

sensitive. DLP-Visor generalises this idea to the clip-

board, memory and network channels, and adapts to

the Windows operating system.

UC4Win (W

uchner and Pretschner, 2012) is prob-

ably closest to DLP-Visor’s approach. UC4Win mon-

itors system calls and matches them against a set

of predeﬁned rules. The rules determine whether

the system call shall be allowed. Unlike DLP-

Visor, UC4Win uses user-mode interception of sys-

tem, which can be easily circumvented.

Virtual machine introspection allows the hypervi-

sor to intercept various events occurring in the operat-

ing system. The ﬁrst system to use virtualization ex-

tensions for introspection was Ether (Dinaburg et al.,

2008), which used page-faults for system call trac-

ing. We showed that interception of page-faults can

severely degrade overall system performance.

Spider (Deng et al., 2013) is a stealthy breakpoint

installation framework based on KVM, a full hyper-

visor. Spider is suitable for installing breakpoints in

user-mode applications. The idea of stealthy break-

points was later extended in Drakvuf (Lengyel et al.,

2014), which is based on Xen, another full hypervi-

sor. As shown by our experimental results, full hyper-

visors have a much higher performance overhead than

thin hypervisors, like DLP-Visor. Recently, Drakvuf

was ported to ARM (Proskurin et al., 2018), Because

Drakvuf and DLP-Visor use similar underlying mech-

anisms, we believe that DLP-Visor can be ported as

well.

7 CONCLUSIONS

In this paper, we presented DLP-Visor, a hypervisor-

based context-sensitive data leakage prevention sys-

tem. We showed that the performance overhead al-

lows DLP-Visor to be deployed in practice. Despite

the limitations imposed by current implementation of

DLP-Visor, it can be applied to most real-world appli-

cations. We believe that future versions of DLP-Visor

will address these limitations.

REFERENCES

Alneyadi, S., Sithirasenan, E., and Muthukkumarasamy, V.

(2016). A survey on data leakage prevention sys-

tems. Journal of Network and Computer Applications,

62:137–152.

Checkpoint (2017 (accessed Sep 19, 2020)). Data Loss Pre-

vention Software Blade. Checkpoint.

Cook, K. (2013). Kernel address space layout randomiza-

tion. Linux Security Summit.

Deng, Z., Zhang, X., and Xu, D. (2013). Spider: Stealthy

binary program instrumentation and debugging via

hardware virtualization. In Proceedings of the 29th

Annual Computer Security Applications Conference,

pages 289–298.

Dinaburg, A., Royal, P., Sharif, M., and Lee, W. (2008).

Ether: malware analysis via hardware virtualization

extensions. In Proceedings of the 15th ACM con-

ference on Computer and communications security,

pages 51–62.

Field, S. (2006). An introduction to kernel patch protection.

Google (2016 (accessed Sep 19, 2020)). Scan your email

trafﬁc using data loss prevention.

Guo, C., Zhuang, R., Jie, Y., Ren, Y., Wu, T., and Choo, K.-

K. R. (2016). Fine-grained database ﬁeld search us-

ing attribute-based encryption for e-healthcare clouds.

Journal of medical systems, 40(11):235.

Halpert, B. (2004). Mobile device security. In Proceedings

of the 1st annual conference on Information security

curriculum development, pages 99–101.

Kantor, A., Antebi, L., Kirsch, Y., and Bialik, U. (2012).

Methods for document-to-template matching for data-

leak prevention. US Patent 8,254,698.

Khati, L., Mouha, N., and Vergnaud, D. (2017). Full disk

encryption: bridging theory and practice. In Cryp-

tographers’ Track at the RSA Conference, pages 241–

257. Springer.

Lengyel, T. K., Maresca, S., Payne, B. D., Webster, G. D.,

Vogl, S., and Kiayias, A. (2014). Scalability, ﬁdelity

and stealth in the drakvuf dynamic malware analysis

system. In Proceedings of the 30th Annual Computer

Security Applications Conference, pages 386–395.

Li, J., Chen, N., and Zhang, Y. (2019). Extended ﬁle hier-

archy access control scheme with attribute based en-

cryption in cloud computing. IEEE Transactions on

Emerging Topics in Computing.

McAfee (2017 (accessed Sep 19, 2020)). Total Protection

for Data Loss Prevention (DLP).

Microsoft (2018 (accessed Sep 19, 2020)b). Microsoft pub-

lic symbol server.

Microsoft (2020 (accessed Sep 19, 2020)a). Data loss pre-

vention in Exchange Server.

Petkovic, M., Popovic, M., Basicevic, I., and Saric, D.

(2012). A host based method for data leak protec-

tion by tracking sensitive data ﬂow. In 2012 IEEE

19th International Conference and Workshops on En-

gineering of Computer-Based Systems, pages 267–

274. IEEE.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

422

Proskurin, S., Lengyel, T., Momeu, M., Eckert, C., and

Zarras, A. (2018). Hiding in the shadows: Empow-

ering arm for stealthy virtual machine introspection.

In Proceedings of the 34th Annual Computer Security

Applications Conference, pages 407–417.

Seshadri, A., Luk, M., Qu, N., and Perrig, A. (2007).

Secvisor: A tiny hypervisor to provide lifetime ker-

nel code integrity for commodity oses. In Proceedings

of twenty-ﬁrst ACM SIGOPS symposium on Operating

systems principles, pages 335–350.

Shinagawa, T., Eiraku, H., Tanimoto, K., Omote, K.,

Hasegawa, S., Horie, T., Hirano, M., Kourai, K.,

Oyama, Y., Kawai, E., et al. (2009). Bitvisor: a

thin hypervisor for enforcing i/o device security. In

Proceedings of the 2009 ACM SIGPLAN/SIGOPS in-

ternational conference on Virtual execution environ-

ments, pages 121–130.

Shvartzshnaider, Y., Pavlinovic, Z., Balashankar, A., Wies,

T., Subramanian, L., Nissenbaum, H., and Mittal, P.

(2019). Vaccine: Using contextual integrity for data

leakage detection. In The World Wide Web Confer-

ence, pages 1702–1712.

Sibai, F. N. (2008). Evaluating the performance of sin-

gle and multiple core processors with pcmark

 05

and benchmark analysis. ACM SIGMETRICS Perfor-

mance Evaluation Review, 35(4):62–71.

Tourani, R., Misra, S., Mick, T., and Panwar, G. (2017).

Security, privacy, and access control in information-

centric networking: A survey. IEEE communications

surveys & tutorials, 20(1):566–600.

uchner, T. and Pretschner, A. (2012). Data loss preven-

tion based on data-driven usage control. In 2012 IEEE

23rd International Symposium on Software Reliability

Engineering, pages 151–160. IEEE.

DLP-Visor: A Hypervisor-based Data Leakage Prevention System

423
